10.8V 2AH 1/4”HEX DRIVE CORDLESS IMPACT
DRIVER KIT
MODEL NO: CP108VCID
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETYi
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
9 Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and
all electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products.
Electrical safety information. It is important that the following information is read and understood:
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the
correct fuse.
8 DO NOT pull or carry the appliance by the power cable.
8 DO NOT pull the plug from the socket by the cable.
8 DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is replaced immediately by a
qualied electrician.
If the cable or plug is damaged during use, switch o the electricity supply and remove from use.
Ensurethatrepairsarecarriedoutbyaqualiedelectrician.
1.2. BATTERY CHARGER SAFETY INSTRUCTIONS
WARNING! DO NOT use the charging base to charge any battery other than that required for the tool. Other types of batteries may
explode!
9 Inspect the plug, cable and the charging base for wear and damage to ensure items are safe before connecting to the mains power
supply. If worn or damaged DO NOT use, immediately replace, or contact a qualied electrician.
9 Check cables are always protected against short circuit and overload.
9 Uncoil the power cable between the plug and the charging base before use.
8 DO NOT pull or carry the charging base by the charger power lead, or pull the plug from the mains socket by the power lead.
8 DO NOT use any other type of transformer with the charging base.
8 DO NOT try to open or dis-assemble the plug or charging base.
8 DO NOT use the plug to power any other electrical item.
9 Disconnect the charging base from the mains power supply when not in use.
8 DO NOT expose the charging base to damp or wet conditions (for indoor use only).
8 DO NOT operate the charging base if it has been dropped, or has received a sharp knock, or is damaged. Contact an authorised
service agent.
8 DO NOT dismantle the charging base as this may cause damage or personal injury and will invalidate your warranty.
8 DO NOT insert foreign objects or material into the slot reserved for the battery.
8 DO NOT immediately charge a second battery. Consecutive charging will overheat the charging base. Allow the unit to cool for 15
minutes before charging the next battery.
9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9 Ensure that cables are always protected against short circuit and overload.
8 DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty item replaced by a qualified electrician.
1.3. BATTERY SAFETY PRECAUTIONS
WARNING! Battery contains Lithium-ion which is dangerous. Handle with care to avoid damage, re, corrosion or personal injury.
9 Charge battery prior to its rst use. The battery will have been shipped in a low charge state. To reduce the risk of burns or re:
8 DO NOT Attempt to open, disassemble, modify or service the battery pack.
8 DO NOT Crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT Expose to temperatures above 40°C (104°F).
9 Replace only with the battery pack designated for this product.
9 Use only the supplied charging base provided to charge the battery.
8 DO NOT attempt recharging the battery by means of an engine generator or a DC power source.
WARNING! Dispose of spent batteries correctly as they contain Lithium-ion. DANGER! DO NOT attempt to disassemble the
battery. For safety and environmental reasons DO NOT discard in domestic waste or by burning. ONLY discard or recycle
according to local authority regulations.
WARNING! DO NOT allow a leaking battery to contact your person.
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear protective
gloves
Wear eye
protection
Wear ear
protection
Charger:
Indoor
use only
Wear a mask
CP108VCID Issue:2 25/10/23
1.4. GENERAL SAFETY
9 Maintain the tool and battery in good condition. Check moving parts alignment on a regular basis.
9 Replace or repair damaged parts. Use an authorised service agent and recommended parts only. Unauthorised parts may be
dangerous and will invalidate the warranty.
9 Ensure the tool is switched o before installing the battery pack.
9 Keep the tool and charger clean for best and safest performance.
9 Remove ill tting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.
9 Evaluate your working area before using the tool; e.g. ceilings, oors and enclosures may contain electrical items or water piping.
9 Ensure battery pack is correctly inserted into the handle and latched in place before attempting to switch on tool.
9 Secure loose work pieces with a clamp, vice or other adequate holding device.
9 Avoid unintentional starting.
9 Wear approved safety eye protection (standard spectacles are not adequate).
9 Maintain correct balance and footing. Ensure the floor is not slippery and wear non-skid shoes.
9 Keep direction switch in the locked position until the tool is required for use.
9 Keep children and unauthorised persons away from the working area.
8 DO NOT use the tool where there are ammable liquids, solids or gases, such as paint solvents, etc.
8 DO NOT allow children to operate the tool.
8 DO NOT operate the tool if any parts are missing as this may cause failure and/or personal injury.
8 DO NOT hold unsecured work piece in your hand.
8 DO NOT leave the tool operating unattended.
8 DO NOT carry the tool with your finger on the power switch. Keep chuck direction switch in the locked position.
8 DO NOT use the tool for a task it is not designed to perform.
8 DO NOT operate the tool when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT get the tool or battery charger wet or use in damp or wet locations.
2. INTRODUCTION
Compact, lightweight cordless 1/4”Hex drive impact driver. Comfortable housing with soft grip to reduce vibration. Variable speed gives
more control during application. Integrated LED battery level indicator and LED worklight. Supplied with fast charge mains charger and
1 x 2Ah rechargeable lithium-ion battery.
3. SPECIFICATION
Model no .....................................................CP108VCID
Battery .......................10.8V 2Ah Lithium-ion (Included)
Consumable parts .....................CP108VBP 2Ah Battery
Drive .................................................................1/4” hex
Impact rate ................................................. 0-40500bpm
Max. torque .........................................................120Nm
Noise power/pressure .................................84/73 dB(A)
No-load speed ...............................................0-2700rpm
Power supply cable: ............................................... 1.5m
Replacement parts .............CP108VMC - mains charger
Vibration/uncertainty ..................................0.57/1.5m/s²
4. BATTERY CHARGING
4.1. Fully charge the battery before rst use.
WARNING! Only recharge batteries with the charger supplied.
4.2. Remove battery by squeezing buttons in on each side.
Insert into battery charger.
4.3. Connect charger to mains supply and red LED will light to signal charging.
Once charging is complete LED turns green.
4.4. Remove from mains supply, remove battery and insert into tool until a click
is heard.
4.5. BATTERY CHARGE STATUS TEST
4.5.1. Press trigger, all LEDs lit: battery charged, one LED lit: battery needs charging.
4.6. In order to maintain battery eciency:
DO NOT fully discharge. After every use fully charge the battery, charge every 4 months even if tool is not used.
If a decrease of performance of the tool is noticed, charge the battery.
5. OPERATION
5.1. Ensure the direction selector is in the mid (lock) position.
5.2. Only make the following function selections with the tool stationary:
5.2.1. DIRECTION: Select clockwise or anticlockwise direction by means of the direction selector. Only use when tool is stationary.
5.2.2. Insert the required driver bit into the chuck by pulling the locking collar forward and sliding the bit in until the locking collar snaps back.
6. MAINTENANCE
WARNING! Remove battery from tool before performing any maintenance or making adjustments.
6.1. Remove dust with a soft bristled brush.
8 DO NOT use solvents clean with a soft damp cloth. DO NOT use compressed air (risk of ejection).
6.2. Tool does not require any special maintenance (it is permanently lubricated inside). Professional repair only, contact authorised service
centre.
6.3. STORAGE: Store in a child free,dry location.
Original Language Version
© Jack Sealey Limited
CP108VCID Issue:2 (F) 25/10/23
WARNING! – Risk of Hand Arm Vibration Injury.
This tool may cause Hand Arm Vibration Syndrome if its use is not managed adequately.
This tool is subject to the vibration testing section of the Machinery Directive 2006/42/EC.
This tool is to be operated in accordance with these instructions.
Measured vibration emission value (a): 0.57 m/s²
Uncertainty value (k): 1.5 m/s²
Please note that the application of the tool to a sole specialist task may produce a different average vibration emission. We recommend
that a specific evaluation of the vibration emission is conducted prior to commencing with a specialist task.
A health and safety assessment by the user (or employer) will need to be carried out to determine the suitable duration of use for each
tool.
NB: Stated Vibration Emission values are type-test values and are intended to be typical.
Whilst in use, the actual value will vary considerably from and depend on many factors.
Such factors include; the operator, the task and the inserted tool or consumable.
NB: ensure that the length of leader hoses is sufficient to allow unrestricted use, as this also helps to reduce vibration.
The state of maintenance of the tool itself is also an important factor, a poorly maintained tool will also increase the risk of Hand Arm
Vibration Syndrome.
Health surveillance.
We recommend a programme of health surveillance to detect early symptoms of vibration injury so that management procedures can be
modified accordingly.
Personal protective equipment.
We are not aware of any personal protective equipment (PPE) that provides protection against vibration injury that may result from the
uncontrolled use of this tool. We recommend a sufficient supply of clothing (including gloves) to enable the operator to remain warm and
dry and maintain good blood circulation in fingers etc. Please note that the most effective protection is prevention, please refer to the
Correct Use and Maintenance section in these instructions. Guidance relating to the management of hand arm vibration can be found on
the HSC website
www.hse.gov.uk - Hand-Arm Vibration at Work
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
