English
USER´S OPERATION MANUAL
Before operating this unit, please read this manual
thoroughly, and retain for future reference.
The following symbols are used throughout the manual and they have the following meanings:
Information, advice, tip, or recommendation
Warning – general danger
Warning – danger of electric shock
Warning – danger of hot surface
Warning – danger of fire
It is important that you carefully read the instructions.
864036
3
4 SAFETY PRECAUTIONS
8 WASHING MACHINE DESCRIPTION
9 Technical specifications
10 Control unit
12 INSTALLATION AND CONNECTION
12 Removing the blocking rods
13 Moving and transport after installation
13 Selecting the room
13 Adjusting the washing machine feet
14 Washing machine placement
16 Connecting to water supply
17 Connecting and securing the water discharge hose
18 Connecting the appliance to the power mains
19 BEFORE USING THE APPLIANCE FOR THE FIRST TIME
20 WASHING PROCESS, STEP BY STEP (1–6)
20 Step 1: Heed the labels on the laundry
21 Step 2: Preparing the washing process
23 Step 3: Choosing the washing programme
28 Step 4: Selecting additional functions
33 Step 5: Starting the washing programme
33 Step 6: End of the washing programme
34 INTERRUPTIONS AND CHANGING THE PROGRAMME
36 MAINTENANCE & CLEANING
36 Cleaning the dispenser tray
37 Cleaning the water supply hose, detergent dispenser housing, and rubber
door gasket
38 Cleaning the pump filter
39 Cleaning the washing machine exterior
40 TROUBLESHOOTING
40 What to do ...?
40 Troubleshooting and error table
45 Servicing
46 RECOMMENDATIONS FOR WASHING AND ECONOMIC USE YOUR
WASHING MACHINE
49 PRODUCT INFORMATION
51 DISPOSAL
STEPS OF
THE WASHING
PROCESS
WASHING
MACHINE
CLEANING AND
MAINTENANCE
INTRODUCTION
TROUBLE-
SHOOTING
PREPARING
THE WASHING
MACHINE
BEFORE FIRST
USE
MISCELLANE-
OUS
CONTENTS
864036
4
Carefully read the instructions for use before using the
washing machine.
Please, do not use the washing machine without reading and
understanding these instructions or use first.
These instructions for use of a washing machine are
supplied with different types or models of washing machines.
Therefore, they may include descriptions of settings or
equipment that are not available in your washing machine.
Failure to observe the instructions for use or inappropriate use of
the washing machine may result in damage to the laundry or the
appliance, or injury to the user. Keep the instruction manual handy,
near the washing machine.
Instructions for use are available through Hisense customer
service centers.
This appliance is intended to be used in household and similar
applications such as:
• staff kitchen areas in shops, offices and other working
environments;
• farm houses;
• by clients in hotels, motels and other residential type
environments;
• bed and breakfast type environments.
Follow the instructions for correct installation of the Hisense
washing machine and connection to the water and power mains
(see chapter »INSTALLATION AND CONNECTION«).
SAFETY PRECAUTIONS
864036
5
Connection to water and power supply has to be executed by an
adequately trained technician or expert.
Any repair and maintenance pertaining to safety or performance
should be done by trained experts.
To avoid danger, a damaged power cord may only be replaced
by the manufacturer, a service technician, or an authorized
person.
Do not connect the washing machine to power mains using
an external switching device such as a programme timer, or
connect it to power mains that is regularly switched on and off
by the power supply provider.
Do not connect the washing machine to an electrical outlet
intended for an electric shaver or hair dryer.
Do not install the washing machine in a room where the
temperature can drop to below 5°C, as washing machine
parts may be damaged in case of water freezing.
The ventilation openings in the base of washing machine must
not be obstructed by a carpet.
To connect the washing machine to water supply, make
sure to use the supplied water supply hose and gaskets. Water
pressure has to be between 0.05 and 0.8 MPa (0.5 – 8 bar).
Always use a new water supply hose to connect the washing
machine to water supply; do not reuse an old water supply hose.
The end of the water discharge hose should reach into a water
drain line.
Before the start of the washing cycle, press the door on the
indicated spot until it locks into place. The door cannot be
opened during washing machine operation.
864036
6
We recommend removing any impurities from the washing
machine drum before the first wash using the Cotton 90°C
programme (see PROGRAMME TABLE).
After the washing cycle, close the water tap and pull out the
washing machine plug from the power socket.
Only use the washing machine for washing laundry, as described
in the instruction manual. The machine is not intended for dry
cleaning.
Only use agents for machine washing and care of laundry. We
shall not be responsible for any damages or discolouration
of gaskets and plastic parts resulting from incorrect use of
bleaching or colouring agents.
When descaling, only use descaling agents with added anti-
corrosion protection. (Only use non-corrosive descaling agents.)
Follow the manufacturer's instructions. Finish the descaling
process with several rinse cycles or by running the Drum Clean
(Self-cleaning programme) in order to remove any residual acid
(e.g. vinegar etc.).
Do not use detergents that contain solvents as this could
lead to release of poisonous gases, damage to the washing
machine, and risk of fire and explosion.
No silver ions are released during the washing programme.
The washing machine is not intended for use by persons
(including children) with physical or mental impairments, or
persons with lacking experience and knowledge. These persons
should be instructed about the use of the washing machine by a
person responsible for their safety.
864036
7
CHILD SAFETY
Before closing the washing machine door and running the
programme, make sure there is nothing except laundry in the
drum (e.g. if a child climbed into the washing machine drum and
closed the door from the inside).
Keep the detergent and conditioner out of reach of children.
Activate the child lock. See chapter »CHOOSING THE
SETTINGS/Child lock«.
Do not let children younger than three years come near the
appliance, unless they are under constant supervision.
The washing machine is made in compliance with all
relevant safety standards.
This washing machine may be used by children aged 8 years
and above and by persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge,
but only if they are supervised during the use of the washing
machine, if they have been provided relevant instructions
regarding safe use of the washing machine, and if they
understand the hazards of inappropriate use. Make sure children
do not play with the appliance. Children may not clean the
washing machine or perform any maintenance tasks without
supervision.
DANGER OF HOT SURFACE
At higher washing temperatures, the door glass will heat up. Be
careful to avoid burns. Make sure children do not play near the
door glass.
The washing machine may only be used with the supplied
power cord.
864036
8
BACK
1 Water supply hose
2 Power cord
3 Water discharge hose
4 Adjustable feet
FRONT
1 Control unit
2 Start/pause button
3 Programme selector knob
4 On/off button
5 Dispenser tray
6 Door
7 Rating plate
8 Pump filter
34 25
6 87
1
WASHING MACHINE DESCRIPTION
2
1
3
4
864036
9
Rating plate
TECHNICAL SPECIFICATIONS
(DEPENDING ON THE MODEL)
Rating plate with basic information about the washing machine is fitted on the front wall of the
washing machine door opening (see chapter »WASHING MACHINE DESCRIPTION«).
Maximum load See rating plate
Width 600 mm 600 mm 600 mm
Height 850 mm 850 mm 850 mm
Washing machine depth (a) 465 mm 545 mm 610 mm
Depth with door closed 495 mm 577 mm 640 mm
Depth with door open (b) 980 mm 1062 mm 1125 mm
Washing machine weight X kg (depending on the model)
Rated Voltage See rating plate
Nominal power See rating plate
Connection See rating plate
Water pressure See rating plate
Current See rating plate
Frequency See rating plate
TYPE: PS22/XXXXX MODEL: XXXXXX.X
Art.No.: XXXXXX Ser.No.: XXXXXXXX
XXX-XXX V ~ XX Hz XX A Pmax.: XXXX W
XXXX W XXXX/min X kg 0,05-0,8 MPa
IPX4
MADE IN SLOVENIA
864036
10
2
PROGRAMME
SELECTOR KNOB
3
START/PAUSE BUTTON
Use this button to start or
pause a programme.
Upon start-up or during pause,
the button backlight will flash;
when the programme is started
and in progress, it will be lit
continuously.
1
ON/OFF BUTTON
Use this button to turn
the washing machine on and
off, and to reset the washing
programme.
CONTROL UNIT
1 32
864036
11
9
DELAY END
Option to set the time
of washing programme
completion
10
STEAM
Option to activate the
laundry refresh function
11
WATER+
Option to set a higher
water level
6
CHILD LOCK symbol
lighting
7
WASHING
TEMPERATURE
Option to set washing
temperature
5+7
Child lock
ON/OFF
Press the positions 5+7 and
hold them for 3 seconds.
8
The following is displayed
on the DISPLAY UNIT:
• Available functions
• Time remaining to programme
completion
• Information for the user
4
FAST function
4a FAST
4b SUPER FAST
Shorter washing programme
duration
5
SPIN (SPINNING RATE
1600/DRAIN /PUMP
STOP )
Option to set the spinning rate
4+5
Sound
ON/OFF
Press the positions 4+5 and
hold them for 3 seconds.
6 8
10 911
5 744a4b
864036
12
1
Move the hoses and
undo the screws on
the back of the washing
machine.
Remove the two angular
pieces.
2
Slide the angular
pieces onto the
grove in the blocking rod;
before doing so, rotate
the right angular piece to
the opposite side.
3
Use the angular
pieces to rotate the
blocking rods by 90°and
pull them out.
4
Cover the two holes
through which the
blocking rods were
inserted with plastic
plugs, and redo the
screws that you undid
in step 1. The plastic
plugs are supplied in the
bag with the washing
machine instruction
manual.
INSTALLATION AND CONNECTION
Remove all packaging. When removing the packaging, make sure not to damage the appliance
with a sharp object.
REMOVING THE BLOCKING RODS
Before the first use of the appliance, transport rods must be removed. A blocked washing
machine may be damaged when it is switched on for the first time. Warranty shall be void in
cases of such damage!
864036
13
MOVING AND TRANSPORT AFTER INSTALLATION
If you wish to move the washing machine after it has been installed, the angular pieces and at
least one blocking rods have to be re-installed to prevent vibration damage to the washing machine
during transport (see chapter »INSTALLATION AND CONNECTION/Removing the blocking rods«). If
you lost the angular pieces and the blocking rods, they can be ordered from the manufacturer.
SELECTING THE ROOM
Floor on which the washing machine is placed must have a concrete base. It should be clean
and dry; otherwise, the washing machine may slide. Also, clean the bottom surface of adjustable
feet.
The washing machine must stand level and stable on a solid base.
If the washing machine is placed on an elevated stable base, the washing machine has to be
additionally secured against tipping.
ADJUSTING THE WASHING MACHINE FEET
Use a water scale and spanner No. 32 (for feet) and 17 (for the nut).
1
Level the washing
machine in
longitudinal and
traverse direction by
rotating the adjustable
feet.
2
After adjusting
the height of the
feet, firmly tighten the
jam nuts (counter nuts)
using a spanner No
17, by turning them
towards the bottom of
the washing machine
(see figure).
864036
14
Incorrect levelling of the washing machine with the adjustable legs may cause vibration,
appliance sliding across the room, and loud operation. Incorrect levelling of the washing machine is
not subject to warranty.
Sometimes, unusual or louder noise may appear during appliance operation; these are mostly
the result of improper installation.
WASHING MACHINE PLACEMENT
If you also have a Hisense dryer of corresponding (same) dimensions, it can be placed on top of the
Hisense washing machine (in this case, vacuum feet must be used) or next to it (figures 1 and 3).
If your Hisense washing machine is smaller (minimum depth 545 mm) than your Hisense dryer, then
the dryer support has to be purchased (figure 2). It is essential to use the vacuum feet! Additional
equipment (dryer support (a), vacuum feet (b) and wall fixing bracket (c)) can be purchased at the
service centre.
The surface on which the appliance is placed should be clean and level.
Hisense washing machine onto which you intend to place the Hisense dryer should hold the weight
of the Hisense dryer (see chapter »WASHING MACHINE DESCRIPTION/Technical information«).
12 3
4X
b
a
5 cm
c
864036
15
Opening the washing machine door (bird's-eye view)
b
a
180°
See chapter »WASHING MACHINE
DESCRIPTION/Technical information«).
a = Washing machine depth
b = Depth with door open
The washing machine may not be in contact with a wall or adjacent furniture. For optimum
washing machine operation, we recommend observing the clearances from the walls as indicated in
the figure.
In case of failure to observe the minimum required clearances, safe and correct washing machine
operation cannot be ensured. Moreover, overheating can also occur (figures 1 and 2).
Installing the washing machine under a countertop is not recommended.
Washing machine installation clearances
3
25 mm
25 mm
1
50 mm
2
864036
16
For normal washing machine operation, the pressure in the water mains should be between 0.05
and 0.8 MPa (0,5 - 8 bar). Minimum dynamic water pressure can be determined by measuring the
water flow. In 30 seconds, 1.2 litres of water should flow from a fully open tap.
Tighten the water supply hose by hand, firmly enough for the hose to have a good seal (max. 2
Nm). After connecting the hose, the seal must be checked for any leaks. Do not use pliers or similar
tools when connecting the hose as this could damage the nut thread.
Only use the water supply hose supplied with the appliance. Do not use any used or other hoses.
When connecting the water supply hose, make sure to connect it in a way that allows adequate
and unobstructed water supply.
CONNECTING TO WATER SUPPLY
Attach the hose to the water tap by screwing it onto the thread.
A
B
A
AQUA - STOP
(only with some
models)
If an internal tube or
hose is damaged, a
shut-off system is
activated that cuts the
water supply to the
washing machine. In
such case, the control
glass (a) will turn red.
Replace the water
supply hose.
B
REGULAR
CONNECTION
864036
17
A
Discharge
hose end may
be placed over a
washbasin or a
bathtub. B Use a
string fed through the
opening in the elbow
support to attach the
hose and prevent it
from slipping to the
floor.
B
Discharge hose
may also be
attached directly to the
washbasin drain.
C
Discharge hose
can also be
attached to a wall
drain with a trap;
such trap should be
properly installed to
allow cleaning.
D
The discharge
hose has to be
attached and affixed to
the pin on the back of
the washing machine,
as shown in the figure.
CONNECTING AND SECURING THE WATER DISCHARGE
HOSE
Feed the water discharge hose into a washbasin or a bathtub, or connect it directly to a drain
(discharge hose minimum diameter 4 cm). The vertical distance from the floor to the end of the
discharge hose may be no more than 100 cm and no less than 60 cm. It can be attached in three
ways (A, B, C).
A
B
C
max 100 cm
min 60 cm
max 90 cm
max 150 cm
max 150 cm
max 150 cm
max 150 cm
max 90 cm
If the discharge hose is not correctly attached, safe and correct washing machine operation
cannot be ensured.
864036
18
2 h
Before connecting the washing machine to the power mains, wait for at least 2 hours until
it reaches room temperature.
Connect the washing machine to a grounded power outlet. After installation, the wall outlet should
be freely accessible. The outlet should be fitted with an earth contact (in compliance with the
relevant regulations).
Information on your washing machine is indicated on the rating plate (see chapter »WASHING
MACHINE DESCRIPTION/Technical information«).
We recommend using over-voltage protection to protect the appliance in case of a
lightning strike.
The washing machine may not be connected to the power mains using an extension cord.
Do not connect the washing machine to an electrical outlet intended for an electric shaver or hair
dryer.
Any repair and maintenance pertaining to safety or performance should be done by trained
experts.
CONNECTING THE APPLIANCE TO THE POWER MAINS
864036
19
Do not use any solvents or cleaning agents that could damage the washing machine (please
observe the recommendations and warnings provided by the cleaning agent manufacturers).
BEFORE USING THE APPLIANCE
FOR THE FIRST TIME
Make sure the washing machine is disconnected from the power mains; then, open the door
towards you (figures 1 and 2).
Before first use, clean the washing machine drum with a soft moist cotton cloth and water, or use
the Cotton 90°C programme. There should be no laundry in the washing machine drum; the drum
should be empty (figures 3 and 4).
3
12
4
864036
20
WASHING PROCESS, STEP BY STEP
(1–6)
STEP 1: HEED THE LABELS ON THE LAUNDRY
Normal wash;
Sensitive laundry
Max.
washing
temp.
95°C
95
95
Max.
washing
temp.
60°C
60
60
Max.
washing
temp.
40°C
40
40
Max.
washing
temp.
30°C
30
30
Hand wash
only
Do not
wash
Bleaching Bleaching in cool water
c1
Bleaching not allowed
Dry cleaning Dry cleaning
with all agents
A
Petroleum
solvent R11,
R113
P
Dry cleaning in
kerosene, pure
alcohol, and
R113
F
Dry cleaning not
allowed
Ironing Hot ironing,
max.
200°C
Hot ironing,
max.
150°C
Hot ironing, max.
110°C
Ironing not
allowed
Drying Dry flat (place on
a flat surface)
Drip dry
Line dry
High temperature
Low temperature
Do not tumble
dry
864036
21
STEP 2: PREPARING THE WASHING PROCESS
1. Sort the laundry by type of fabric, colour, soiling, and allowed washing temperature (see
PROGRAMME TABLE).
2. Wash the laundry that sheds a lot of fibre or lint separately from other laundry.
3. Close the buttons and zippers, tie any ribbons, and turn the pockets inside out; remove any
metal clips that could damage the laundry and washing machine interior, or clog the drain.
4. Place very sensitive clothes and small items in a special-purpose laundry washing bag.
(The special purpose laundry bag is available as an optional accessory.)
SWITCHING ON THE WASHING MACHINE
Use the power cord to connect the washing machine to power mains, and connect the washing
machine to water supply.
Press the (1) ON/OFF button to switch on the washing machine (figures 1 and 2).
12
1
864036
22
LOADING THE WASHING MACHINE
Open the washing machine door by pulling the handle towards you (figure 1).
Insert the laundry into the drum (after making sure the drum is empty) (figure 2).
Make sure that no garment is stuck between the door and the rubber gasket. Close the washing
machine door (figure 3).
Do not overload the drum! See PROGRAMME TABLE and observe your nominal load as indicated
on the rating plate.
If the washing machine drum is too full, the laundry will not be washed as thoroughly.
123
864036
23
During operation, the programme selector knob (2) will not rotate automatically.
Washing programmes are comprehensive programmes that include all washing stages, including
softening and spinning (this does not apply to Partial programmes).
Partial programmes are independent programmes. Use them when you feel you do not need the
entire washing programme.
STEP 3: CHOOSING THE WASHING PROGRAMME
Choose the programme by rotating the programme selector knob (2) to the left or to the right
(depending on the type of laundry and how heavily soiled it is). See PROGRAMME TABLE.
2
2
864036
24
PROGRAMME TABLE
Programme
Max. load
Maximum
spinning rate
Programme description
Cotton White
40°C - 90°C
* MAX MAX
1)
Programme for washing white and coloured cotton
laundry, towels, bed linen, T-shirts etc.
The temperature can be set separately; therefore,
observe the instructions indicated on the clothing.
Spinning speed can be set to your preference.
Programme duration and amount of water will be
adjusted to the amount of laundry.
To treat your laundry with steam, press the button
before the start of the wash.
Colour
20°C - 90°C
* MAX MAX
1)
Programme for coloured laundry made of cotton and
cotton mix/blend fabrics.
The temperature can be set separately; therefore,
observe the instructions indicated on the clothing.
Spinning speed can be set to your preference.
Programme duration and amount of water will be
adjusted to the amount of laundry.
Mix
(Mixed laundry/
Synthetics)
20°C - 60°C
3,5 kg 1200
2)
Washing programme for delicate clothing made of
synthetic and mixed fibres or viscose, and for simple
care of cotton. Observe the instructions indicated on
the clothing.
Wool
20°C - 40°C
2 kg 800 Gentle washing programme for washing wool, silk,
and clothes that require manual washing. Maximum
temperature is 40°C. This programme has a short
spinning cycle. Top spinning speed available is 800
rpm.
Eco 40-60 * MAX MAX
1)
Washing cycle, which is able to clean normally soiled
cotton laundry declared to be washable at 40°C or
60°C.
Power Wash 59´/32´
40°C
* MAX MAX
1)
Washing programme automatically adjusts the
duration of the main wash and the number of rinses
depending on the amount of laundry in the machine.
Quick 20´
30°C
2,5 kg 1000
2)
Quick washing programme for laundry that only
needs refreshing.
* Maximum declared load (MAX) - see rating plate
** Half load (1/2)
/ Any load (0 kg – MAX kg)
1)
Maximum spinning rate (MAX) - see rating plate
2)
Depending on the model
864036
25
Programme
Max. load
Maximum
spinning rate
Programme description
Drum Clean
(Self-cleaning
programme)
0 kg This programme is used for cleaning the drum and
removing the residue of detergent and bacteria.
To select the programme, rotate the programme
selector knob to the left or to the right to the Drum
Clean (Self-cleaning programme) position. Other
extra functions cannot be selected.
The drum has to be empty. Do not add detergent
and softener! You can add some distilled (spirit)
vinegar (approx. 2 dl) or sodium bicarbonate (1
tablespoon, or 15 g). We recommend running the
programme at least once a month.
Spin
(Spinning rate/Drain)
(Partial programme)
/ MAX
1)
Use the programme when you only wish to spin the
laundry.
If you only wish to pump out the water from the
washing machine, press the SPIN
(5) button to
select (drain)
.
Rinse&Softening
(Partial programme)
/ MAX
1)
For softening, starching, or impregnating the washed
laundry. It can also be used as a rinse cycle, but do
not add any detergent or softener/conditioner. It is
completed with an additional rinse.
You can also choose WATER+
by selecting the
extra function.
Down
20°C - 40°C
** (1/2) 800 Washing programme is suitable for pillows and
jackets stuffed or padded with down. The wash takes
place at a low temperature, with a large amount of
water, with gentle tumbling, and a gentle spin cycle.
Shirts
(Shirts with steam)
20°C - 40°C
3,5 kg 1200
2)
This program is intended for washing garments
made of cotton, microfibres and synthetics; for
washing collars and cuffs. The wash takes place at a
low temperature, with a greater amount of water and
gentle tumbling. Preset spinning speed is 800 rpm.
To treat your laundry with steam, press the button
before the start of the wash.
* Maximum declared load (MAX) - see rating plate
** Half load (1/2)
/ Any load (0 kg – MAX kg)
1)
Maximum spinning rate (MAX) - see rating plate
2)
Depending on the model
864036
26
Programme
Max. load
Maximum
spinning rate
Programme description
Pets
(Pet hair removal)
30°C - 60°C
* MAX MAX
1)
During this programme, pet hair is removed from
your garments. The washing programme includes an
automatic prewash and additional rinses.
After the washing programme completion, clean
the glass on the washing machine door and the
pump filter in which pet hair could be trapped. We
recommend running the Drum Clean (Self-cleaning
programme) programme after the wash, in order to
thoroughly remove any pet hair from the washing
machine. Prewash is already included in the
programme.
To treat your laundry with steam, press the button
before the start of the wash.
Baby Care
(Baby clothes)
40°C - 90°C
* MAX MAX
1)
This programme is used for washing clothes that
require special care, such as baby clothes or
clothes for people suffering from skin allergies. We
recommend turning the garments inside out as this
will also thoroughly wash out the skin scales or
residues of skin treatment products. The programme
is a combination of a prolonged heating and an extra
rinse that removes any detergent residue.
The washing temperature is maintained. Prewash is
already included in the programme.
To treat your laundry with steam, press the button
before the start of the wash.
Allergy Steam
40°C - 90°C
* MAX MAX
1)
This washing programme is used for washing cotton
garments that require special care, such as clothes
for people with highly sensitive skin or allergies. We
recommend turning the garments inside out, as this
will also thoroughly wash out the skin and other
residues.
To treat your laundry with steam, press the button
before the start of the wash.
Auto Wash
30°C
* MAX MAX
1)
Washing programme automatically adjusts the
duration of the main wash and the number of rinses
depending on the amount of laundry in the machine.
Use it for daily care of coloured garments made of
cotton, synthetic fabrics and mixed/blended fabrics.
* Maximum declared load (MAX) - see rating plate
** Half load (1/2)
/ Any load (0 kg – MAX kg)
1)
Maximum spinning rate (MAX) - see rating plate
2)
Depending on the model
Add powder or liquid detergents according to the manufacturer's instructions, considering the
washing temperature, washing program, how soiled the laundry is, and water hardness.
864036
27
In case of excessive foaming in the washing machine or leak of foam through the detergent
dispenser tray, the washed laundry must be rinsed thoroughly with a large amount of water. Choose
a washing program, but do not add any detergent.
Maximum amount of laundry in kg (for the cotton programme) is indicated on the rating plate
fitted under the washing machine door (see chapter »WASHING MACHINE DESCRIPTION/
Technical information«).
Maximum or nominal load applies to laundry prepared pursuant to the IEC 60456 standard.
For better washing effect, we recommend loading the drum to 2/3 when using the cotton
programmes.
Low water temperature, low mains voltage and different washing loads may affect the washing
time; the remaining time displayed is adjusted accordingly during the washing process.
Time optimization during the programme progress
In the early stage of the washing programme, the washing machine uses advanced technology to
detect the amount of laundry. After load detection, the washing machine adjusts the programme duration.
WASHING PROGRAMS WITH STEAM
Adding steam during the last washing step loosens the laundry, slightly disinfects it and eliminates
some allergens. After using such program, the laundry will be soft, supple and fresh, and it will
require less ironing.
Use of steam (press the 10 button) also allows omitting or reducing the amount of conditioner.
WASHING PROGRAMS WITH LAUNDRY DISINFECTION
FUNCTION
With programs featuring the icon, you can replace the pre-wash with the disinfection function
(Superhygiene ).
After choosing the disinfection function, add the disinfectant into the special-purpose dispenser
found in the prewash compartment. Only add the amount of disinfectant recommended by its
manufacturer.
Recommended drum load is no more than to 3 kilograms.
Observe the instructions provided by the manufacturer of the product you
are using.
Only use disinfectants intended for clothing. Use of other disinfectants
could damage your clothes (discoloration, stains etc.).
If you are washing delicate laundry, inquire with the garment manufacturer
whether it can be washed with disinfectants, in order to avoid any damage
to your clothes.
You take full responsibility for the use of disinfectants.
If you have selected a program with a prewash cycle and you have added powder detergent to
the pre-wash compartment, remove the disinfectant dispenser tray.
864036
28
STEP 4: SELECTING ADDITIONAL FUNCTIONS
Most programmes feature basic settings, but these settings can be changed.
Adjust the settings by pressing the relevant function button (before pressing the (3) START/PAUSE
button).
Functions that cannot be changed with the selected washing programme are partly lit (dimmed).
Certain settings cannot be selected with some programmes. Such settings will not be lit, and the
button will flash when pressed (see FUNCTION TABLE).
Description of function indicators for selected washing programme:
• Lit (Basic/preset setting);
• Dimmed (Functions that can be adjusted) and
• Unlit (Functions that cannot be selected).
FAST
When the FAST function is activated, the washing programme will be
carried out with a shorter washing duration.
Two options are available. Signal light on the selected washing method is
on (FAST (4a) or SUPER FAST (4b)).
We recommend a half-load for the Cotton programme.
4
6 8
10 911
4 5 74a4b
864036
29
SPIN
(SPINNING RATE/DRAIN/PUMP STOP)
To adjust the spinning rate. Every programme (except for Drum Clean
(Self-cleaning programme)) has a preset spinning rate that can be
adjusted by pressing on position (5) SPIN (SPINNING RATE/DRAIN/
PUMP STOP).
If you select draining without spinning, the symbol will appear on the
display unit.
If you select »Pump stop«, the symbol will appear on the display unit.
Select the »Pump stop« function when you wish the laundry to
stay soaked in the water from the last rinse cycle in order to prevent it
from creasing when you are unable to take it from the washing machine
immediately after the washing programme is complete. You may set the
desired spinning rate. To continue the program, press the (3) START/
PAUSE button that is lit. Water will be drained (pumped out) and the final
spin cycle will be run.
WASHING TEMPERATURE
Changing the temperature for the selected program.
Each program has a preset temperature that can be changed by pressing
the position (7) (WASHING TEMPERATURE).
The temperature is displayed on the display unit (8) above the button.
DELAY END
Press on the position (9) DELAY END to delay the programme completion
time by up to 24 hours.
Settings procedure:
• Select the desired programme and extra functions.
• Press the position (9) DELAY END to activate the function.
• Repeatedly press this position to set the desired programme
completion time (with 30-minute increments up to 6 hours, and
1-hour increments thereafter, up to 24 hours.)
• To activate the function, press the (3) START/PAUSE button.
Washing machine starts counting down the set time. When the
countdown reaches the programme duration (e.g. 2:30), the washing
programme starts automatically.
To interrupt or change the programme completion time, press the (1)
ON/OFF button. To quickly cancel the programme completion delay,
press the position(9) DELAY END and hold it for 3 seconds. The washing
programme will resume.
Example of function setting:
It is now 9 PM, and you wish the washing programme to be completed at
6 AM the next morning. In this case, set the DELAY END time to 9 hours.
5
7
9
864036
30
Some settings cannot be selected with certain programmes. Such functions will not be lit on the
display unit, and when the corresponding button is pressed, an acoustic signal will be emitted and
the light on the button will flash (see FUNCTION TABLE).
Activate/deactivate the functions by pressing the desired function (before pressing the (3) START/
PAUSE button). An indicator will light up next to the selected functions.
If you have set the DELAY END function and you are using liquid detergent, we do not
recommend setting a programme without a pre-wash.
STEAM
Adding a 20-minute steam cycle at the end of the program will soften and
disinfect your garments, and reduce or do away with the need for ironing
and using softener/conditioner for your laundry.
WATER+
Use this function to wash with a larger amount of water on some
programmes.
10
11
864036
31
When the washing machine is switched off, all extra functions return to their basic or custom
settings, except for the acoustic signal setting.
CHILD LOCK
A safety feature. To activate the child lock, simultaneously press the
(5) SPIN
(SPINNING RATE/DRAIN/PUMP STOP) and (7) WASHING
TEMPERATURE positions and hold them for at least three seconds.
Countdown timer is displayed on the display unit. The selection will be
confirmed by an acoustic signal and by a signal light (the symbol (6)
will be lit). Follow the same procedure to deactivate the child lock. As long
as the child lock is activated, programme, settings, or additional functions
cannot be changed.
Child lock remains active even after the washing machine is switched
off. For safety reasons, the child lock does not prevent switching off
the washing machine with the (1) ON/OFF button. To select a new
programme, the child lock must first be deactivated.
764 5
SOUND OFF
To turn off the sounds, simultaneously press the positions (4) FAST
and (5) SPIN (SPINNING RATE/DRAIN/PUMP STOP) and hold them for
at least 3 seconds.
To reactivate the sound, simultaneously press the positions (4) and (5) and
hold them for at least 3 seconds.
If you turn off the sounds, then there is no audible signal at the end of a
washing programme.
5 7
+
4 5
+
864036
32
FUNCTION TABLE
Programmes
FAST
SUPER FAST
DELAY END
STEAM
WATER+
SPIN
(SETTING
THE SPINNING RATE)
PUMP STOP
Cotton White
40°C - 90°C
•• • ••••
Colour
20°C - 90°C
•• • •••
Mix
(Mixed laundry/Synthetics)
20°C - 60°C
•• • •••
Wool
20°C - 40°C
•• • •••
Eco 40-60
Power Wash 59´/32´
40°C
•• • •••
Quick 20´
30°C
•••
Drum Clean
(Self-cleaning programme)
•••
Spin
(Spinning rate/Drain)
(Partial programme)
•
Rinse&Softening
(Partial programme)
•••
Down
20°C - 40°C
•• • •••
Shirts
(Shirts with steam)
20°C - 40°C
•• • ••••
Pets
(Pet hair removal)
30°C - 60°C
•• • ••••
Baby Care
(Baby clothes)
40°C - 90°C
•• • ••••
Allergy Steam
40°C - 90°C
•• • ••••
Auto Wash
30°C
•• • •••
• Additional functions can be used
864036
33
STEP 5: STARTING THE WASHING PROGRAMME
Press the (3) START/PAUSE button.
3
TIME REMAINING TO PROGRAMME COMPLETION or DELAY END time (if set) will appear on
the display.
Symbols will be lit on the selected functions.
After pressing the (3) START/PAUSE button, the spinning rate can be adjusted (except in the case
of the Drum Clean (Self-cleaning programme) and SPIN (SPINNING RATE/DRAIN/PUMP STOP))
and child lock can be activated or deactivated, while other settings cannot be changed.
If the TIME REMAINING UNTIL PROGRAMME COMPLETION flashes three times on the
display unit, and there is an audible signal, this means that the washing machine door is open or not
closed tightly. Close the washing machine door and press the (3) button START/PAUSE again to
resume the washing programme.
STEP 6: END OF THE WASHING PROGRAMME
The washing machine will indicate the end of the washing programme with an acoustic signal
and will appear on the display until the washing machine switches into low standby mode or
switches off. After 5 minutes, the sign will no longer be displayed.
1. Open the washing machine door.
2. Take the laundry from the drum.
3. Wipe the rubber door gasket and the door glass.
4. Close the door!
5. Shut off the water supply tap.
6. Switch off the washing machine (press the (1) ON/OFF button).
7. Unplug the power cord from the outlet.
1
864036
34
INTERRUPTIONS AND CHANGING
THE PROGRAMME
MANUAL INTERRUPTION
To pause and cancel the washing programme, press the (1) ON/OFF button. Signal lights will
flash on the display. At the same time, the washing machine pumps the water out of the washing
machine drum. When the water is pumped out, washing machine door will be unlocked. If the water
in the washing machine is hot, the washing machine will automatically cool it and pump/drain it out.
PERSONAL SETTINGS
Basic or default settings for each washing programme can also be changed. When you select the
washing programme and Additional functions, the combination can be stored by pressing the (3)
START/PAUSE button and holding it for 3 seconds (the time is counted down on the display unit).
will appear on the display.
The programme will remain stored until it is changed using the same procedure.
Personal settings can also be reset to factory settings in the user menu.
PERSONAL SETTINGS MENU
Switch on the washing machine by pressing the (1) ON/OFF button. Simultaneously press the
(4) FAST and (7) WASHING TEMPERATURE positions to open the Personal Settings Menu.
Signal lights for STEAM and WATER+ will light up on the display unit. Number 1 will appear
on the LED display, which also indicates the settings function. Rotate the programme selector
knob (2) to the left or to the right to choose the function to change. Number 1 indicates sound
settings and number 2 indicates resetting of Personal programme settings to factory defaults. If
the desired settings are not selected in 20 seconds, the programme will automatically return to
main menu. Press the (5) SPIN (SPINNING RATE/DRAIN/PUMP STOP) position to confirm the
desired functions and their settings; press the (4) FAST position to go back one step. Acoustic
signal volume can be set at four levels (0 means the sound is off; 1 means that the button sound is
activated; 2 means low volume, and 3 means high volume). Choose the volume level by rotating the
programme selector knob (2) to the left or to the right. The lowest setting means that the acoustic
signal is switched off.
PAUSE BUTTON
The washing programme can always be stopped by pressing the (3) START/PAUSE button. The
washing programme is temporarily paused when the time remaining until programme completion
is flashing on the display unit. If there is no water in the drum and water temperature is not too
high, then the door will unlock after a certain period of time, and they can be opened. To resume
the washing program, first close the door and then press the key (3) START/PAUSE button.
ADDING/REMOVING LAUNDRY DURING WASHING MACHINE OPERATION
After a certain period of time, the washing machine door can be opened if the water level and
temperature are below a predefined threshold.
If the conditions below are met, then the electronic door lock is released and the washing machine
door can be opened:
864036
35
• water temperature in the drum has to be suitable,
• water level in the drum has to be below a certain value.
In order to add or remove laundry from the washing machine during programme operation, proceed
as follows:
1. Press the (3) START/PAUSE button.
2. If all conditions for release of electronic door lock are met, then you can open the washing
machine door and add or remove laundry from the drum.
3. Close the washing machine door!
4. Press the (3) START/PAUSE button.
The washing program will resume.
If you add a considerable amount of laundry during the wash, the laundry could be washed less
effectively, since the washing machine initially sensed a lower weight of the load of laundry and
added a smaller amount of water. Insufficient amount of water relative to the amount of laundry
could also cause damage to the laundry (rubbing of dry laundry),
and washing time can be longer.
Washing time will resume from the point at which the washing programme was interrupted.
ERRORS
In case of an error or fault, the programme will be interrupted.
An acoustic signal will warn about such occurrence (see TROUBLESHOOTING AND ERROR
TABLE), and the error will be indicated on the display unit (E:XX).
POWER SUPPLY FAILURE
In case of a power supply failure, the washing programme is interrupted. When power supply is
restored, the washing programme is resumed from the point at which it was interrupted. Upon
completion of the washing cycle,
/ will alternate on the display unit. This informs the user
about a power supply failure and on the effect on the execution of the washing programme.
Washing time will resume from the point at which the washing programme was interrupted.
OPENING THE DOOR (PAUSE/CANCEL/CHANGE PROGRAMME)
Washing machine door can be opened, if the water level in the machine is low enough and if the
water temperature is not excessively high.
If the washing machine is not connected to the power mains or in case of a power supply failure
during the programme execution, then the washing machine door cannot be opened.
In such case, the washing machine has to be properly connected, or a service technician should be
contacted.
864036
36
Do not wash the dispenser tray in a dishwasher.
MAINTENANCE & CLEANING
Before cleaning, unplug the washing machine from the power mains.
Children should not clean the washing machine or perform maintenance tasks without proper
supervision!
CLEANING THE DISPENSER TRAY
The dispenser tray should be cleaned at least twice per month.
1
To remove the
dispenser tray from
the housing, press the
small tab.
2
Clean the
dispenser tray
under running water
using a brush, and
dry it. Also, remove
any detergent residue
from the bottom of the
housing.
3
If necessary, clean
the disinfectant
dispenser tray.
4
If required, remove
and clean the plug
cap.
5
Clean the plug cap
and the disinfectant
tray under running
water and replace
them.
864036
37
1
Clean the net
filter often under
running water.
2
Use a brush to
clean the entire
washing machine
rinsing section,
especially the nozzles
on the upper side of
the rinsing chamber.
3
After every wash,
wipe the rubber
door seal to extend its
useful life.
CLEANING THE WATER SUPPLY HOSE, DETERGENT
DISPENSER HOUSING, AND RUBBER DOOR GASKET
864036
38
The pump filter must be occasionally cleaned, especially after washing very fleecy, woolly, or
very old laundry.
CLEANING THE PUMP FILTER
During cleaning, some water may be spilled. It is therefore recommended to place an absorbent
cloth on the floor.
1
Open the pump
filter cap using
a suitable tool (flat
screwdriver or a similar
tool).
2
Pull out the water
outlet funnel
before cleaning the
pump filter.
Rotate the pump filter
slowly in the counter-
clockwise direction.
Pull out and remove
the pump filter to allow
the water to slowly
drain.
3
Clean the pump
filter thoroughly
under running water.
4,5
Remove
all and any
objects and impurities
from the filter housing
and the pump
propeller.
Replace the pump
filter as shown in the
figure and fasten it
by rotating in the
clockwise direction.
For a good seal, the
filter gasket surface
should be clean.
864036
39
CLEANING THE WASHING MACHINE EXTERIOR
Always disconnect the washing machine from the power mains before cleaning.
Clean the washing machine exterior and display unit using a soft damp cotton cloth and water.
Do not use any solvents or cleaning agents that could damage the washing machine (please
observe the recommendations and warnings provided by the cleaning agent manufacturers).
Do not clean the washing machine with a jet of water!
864036
40
TROUBLESHOOTING
WHAT TO DO ...?
The washing machine shall automatically control the operation of particular functions during the
washing cycle. If any irregularity is identified, this will be indicated by reporting (E:XX) on the
display. The washing machine will report the error until it is switched off. Disturbances from the
environment (e.g. the power grid) may result in various error reports (see TROUBLESHOOTING
TABLE). In such case:
• Switch off the washing machine and wait for a few seconds.
• Switch on the washing machine and repeat the washing programme.
• Most errors during operation can be resolved by the user (see TROUBLESHOOTING TABLE).
• If the error persists, call an authorized service unit.
• Repairs may only be carried out by an adequately trained person.
TROUBLESHOOTING AND ERROR TABLE
Errors indicated on the display unit may include the following:
Problem/
error
Indication on the display unit
and problem description
What to do?
Incorrect settings Restart the programme. If the error reoccurs,
call a service technician.
Temperature sensor error Inlet water too cold. Repeat the washing
programme.
If the washing machine reports this error again,
call a service technician.
Door lock error. Make sure the washing machine door is
closed.
Unplug the power cord from the outlet; then,
plug the power cord back into the outlet and
switch on the washing machine.
If the error reoccurs, call a service technician.
Water filling error. Check the following:
• is the water inlet valve open,
• is the filter on the water supply hose clean,
• is the water supply hose deformed (clipped,
clogged etc.),
• is the pressure in the water mains between
0.05 and 0.8 MPa (0,5–8 bar).
Then, press the (3) START/PAUSE button to
resume the programme. If the error reoccurs,
call a service technician.
864036
41
Problem/
error
Indication on the display unit
and problem description
What to do?
Water heating error Restart the programme. If the error reoccurs,
call a service technician.
Water draining error
Check the following:
• is the pump filter clean,
• is the discharge hose clogged,
• is the drain clogged,
• if the discharge hose placed is placed below
the maximum and above the minimum
height (see chapter »INSTALLATION AND
CONNECTION/ Connecting and securing the
water discharge hose«);
then, press the (3) START/PAUSE button
again. If the error reoccurs, call a service
technician.
Excessive amount of detergent
Too much detergent may cause excessive
foaming in the drum. See description for
.
Water leak detected in the
washing machine area
Turn off the appliance and turn it back on.
If the error reoccurs, call a service technician.
Water level sensor error
Unplug the power cord from the outlet; then,
plug the power cord back into the outlet and
switch on the washing machine.
If the error reoccurs, call a service technician.
Water overflow If there is water in the drum that exceeds a
certain level, and an error is reported on the
display unit, the washing program will be
interrupted and water will be pumped out of
the washing machine. Restart the programme.
If the error reoccurs, call a service technician.
If there is water in the drum that exceeds
a certain level, and an error is reported on
the display unit, while the washing machine
continues to add water, close the water tap
and call a service technician.
Excessive amount of detergent
Too much detergent may cause excessive
foaming in the drum. See description for
.
Motor control error Restart the programme. If the error reoccurs,
call a service technician.
Error while locking the door Door is closed, but it cannot be locked. Switch
off the washing machine. Switch it back on
and restart the washing program.
If the error reoccurs, call a service technician.
864036
42
Problem/
error
Indication on the display unit
and problem description
What to do?
Error while unlocking the door. Door is closed, but it cannot be unlocked.
Turn off the washing machine, then turn it
back on. If the error reoccurs, call a service
technician. To open the door, see chapter
»INTERRUPTIONS AND CHANGING THE
PROGRAMME/Opening the door manually«.
Electronics communication
failure in the washing machine
Unplug the power cord from the outlet; then,
plug the power cord back into the outlet and
switch on the washing machine.
If the error reoccurs, call a service technician.
Electronics communication
failure in the washing machine
Unplug the power cord from the outlet; then,
plug the power cord back into the outlet and
switch on the washing machine.
If the error reoccurs, call a service technician.
Warning from the system for
detecting extended washing
machine voltage fluctuation –
180 V > U > 260 V
A prolonged drop of voltage do below 180 V,
or voltage in excess of 260 V was detected,
which can affect the washing machine
operation.
Check the power supply network to which your
washing machine is connected.
Warning from the system for
detecting incorrect power
mains frequency (50/60 Hz)
When the washing machine was switched
on, the system detected incorrect supply
power frequency, which could affect washing
machine functionality.
Any problems on the power network should be
checked and corrected.
Warnings/information for the user, which can be indicated on the display unit, may include the
following:
Warning/
information
Indication on the display unit Error cause and description, what to do?
ANTICREASE function that
you have selected as a part
of the washing programme is
activated and in progress.
To stop the ANTICREASE function, press
the (1) ON/OFF button.
Water drain system alert
Display of warning
.
Alert about reduced water flow in the pumping
stage. Check the following:
• is the pump filter clean,
• is the discharge hose clogged,
• is the drain clogged,
• if the discharge hose placed is placed below
the maximum and above the minimum
height (see chapter »INSTALLATION AND
CONNECTION/Connecting and securing the
water discharge hose«).
864036
43
Warning/
information
Indication on the display unit Error cause and description, what to do?
System warning to run the
Drum Clean (Self-cleaning
programme)
After the washing programme is
complete, the signs
and
will alternate on the display unit.
We recommend running the Drum Clean (Self-
cleaning programme).
Warning by the system
for detecting excessive
foaming during the washing
programme.
In case of excessive foaming in the washing
machine or leak of foam through the detergent
dispenser tray, the washed laundry has to be
rinsed thoroughly with a large amount of water.
Choose a washing programme, but do not add
any detergent.
• We recommend choosing the Rinse &
Softening programme.
• Decrease the amount of detergent added.
Power supply failure warning
(»PF«/Power Failure)
The system detected a power supply failure
during the washing programme progress,
which affected functional execution of the
washing programme.
Check the power supply network to which your
washing machine is connected.
Unresponsive display unit and
all buttons
Unplug the power cord from the outlet. Check
if the supply voltage is suitable for the washing
machine (220–240 V); then, plug the power
cord back into the outlet and switch on the
washing machine.
Washing machine standing by,
ready to resume the washing
programme
The time remaining until
programme completion is
alternately lit and off on the
display unit.
To resume the washing programme, press the
(3) button START/PAUSE.
Preparation for unlocking the
door
Signal lights will flash on the
display unit.
Wait until the process is completed. If no error
is indicated after the process, then a new
programme can be started.
Water has to be drained. Wait for the door to
unlock.
Noise and vibration - Make sure the appliance is levelled using the adjustable legs and that the
jam nuts are securely tightened.
Unevenly distributed laundry or lumps of laundry in the washing machine drum can cause problems
such as vibration and noisy operation. The washing machine detects such problems and the UKS*
(*stability control system) will be activated.
Smaller loads (e.g. one towel, one sweater, one bathrobe etc.) or clothes made of materials with
864036
44
special geometrical properties are virtually impossible to distribute evenly across the washing
machine drum (slippers, large items etc.). This results in several attempts to redistribute the laundry,
which in turn leads to longer programme duration. In extreme cases of unfavourable conditions, the
programme can be completed without the spinning cycle.
The UKS* (*stability control system) allows stable operation and a longer washing machine useful
life.
If the problems persist despite observing the advice above, call an authorized service technician.
864036
45
In case of a defect, only use approved spare parts by authorized manufacturers.
Repair or any warranty claim resulting from incorrect connection or use of the washing
machine shall not be covered by the warranty. In such cases, the costs of repair shall be charged
to the user.
The warranty does not cover consumables, minor deviations in colour, increased noise that
results from appliance age and which does not affect the functionality of the appliance, and
aesthetic defects on components, which do not affect the functionality and safety of the appliance.
The warranty does not cover the errors or failures resulting from disturbances from the
environment (lightning strike, power grid failures, natural disasters etc.).
Additional information, equipment and accessories for maintenance can be obtained through
Hisense customer service centers.
SERVICING
Before calling a service technician
When you contact a service centre, please state your washing machine´s type (1), code/ID (2),
model number (3), and serial number (4).
Type, code/ID, model, and serial number are indicated on the rating (type) plate located on the front
side of the washing machine door opening.
TYPE: PS22/XXXXX MODEL: XXXXXX.X
Art.No.: XXXXXX Ser.No.: XXXXXXXX
XXX-XXX V ~ XX Hz XX A Pmax.: XXXX W
XXXX W XXXX/min X kg 0,05-0,8 MPa
IPX4
MADE IN SLOVENIA
431 2
864036
46
RECOMMENDATIONS FOR WASHING
AND ECONOMIC USE YOUR
WASHING MACHINE
Wash new coloured garments separately the first time.
Wash heavily soiled laundry in smaller amounts, with more powder detergent or with a pre-wash
cycle.
Apply a special stain remover on stubborn stains before the wash.
With slightly soiled laundry, we recommend a programme without a pre-wash cycle, use of shorter
programmes (e.g. FAST) and a lower washing temperature.
If you often wash laundry at low temperatures and with liquid detergents, bacteria may spawn
which can cause odour in the washing machine. To prevent such odour, we recommend
occasionally running the Drum Clean (Self-cleaning programme) (see PROGRAMME TABLE).
We recommend avoiding washing very small amounts of laundry as this will lead to excessive use
of energy and poorer washing machine performance.
Loosen any folded laundry before putting it into the drum.
Only use detergents for machine washing.
If water hardness exceeds 14°dH, water softener should be used. Heater damage resulting from
incorrect use of water softeners shall not be covered by the warranty. Check the information on
water hardness with your local water supply company or authority.
Use of chlorine-based bleaches is not recommended as they can damage the heater.
Do not add hardened lumps of powder detergent into the detergent dispenser as this may clog the
piping in the washing machine.
When using thick liquid laundry care products, we recommend diluting them with water to prevent
clogging the dispenser tray drain.
Liquid detergents are intended for washing programmes without a prewash cycle.
At higher spinning rates, there will be less residual moisture in the laundry. As a result, drying in a
tumble dryer will be more economical and faster.
864036
47
Water hardness
Hardness levels
°dH (°N) m mol/l °fH(°F) p.p.m.
1 – soft < 8,4 < 1,5 < 15 < 150
2 – normal 8,4 - 14 1,5 - 2,5 15 - 25 150 - 250
3 – hard > 14 > 2,5 > 25 > 250
Check the information on water hardness with your local water supply company or authority.
1
A separator/divider
tab is supplied
with the washing
machine, which
allows adding liquid
detergent to the main
wash compartment
(left compartment).
There is a disinfectant
tray (A) in the prewash
compartment. It can be
removed.
2
Powder and liquid
detergent level
indicator.
3
When using
powder detergent,
the separator/divider
tab should be lifted.
4
When using liquid
detergent, the
separator/divider tab
should be lowered.
A
A
Symbols of detergent dispenser compartments
prewash
main wash
softening
A
disinfectant tray
864036
48
We recommend adding powder detergent immediately before the washing cycle. If you add it
sooner, make sure the detergent compartment in the dispenser tray is completely dry before adding
the powder detergent: otherwise, the powder detergent may cake before the start of the washing
process.
Pour the conditioner into the dispenser tray, into the compartment with the symbol . Observe
the recommendation on the conditioner packaging.
Do not fill the conditioner compartment over the max. indication (maximum indicated level).
Otherwise, the conditioner will be added to the laundry too soon, leading to poorer washing effect.
864036
49
PRODUCT INFORMATION
PRODUCT INFORMATION SHEET According to EU-Regulation No. 2019/2014
(depending on the model)
Supplier’s name or trade mark:
Supplier’s adress (
b
):
Model identifier:
General product parameters:
Parameter Value Parameter Value
Rated capacity (
a
) (kg) x,x Dimensions in cm
Height x
Width x
Depth x
EEI
W
(
a
) x,x Energy efficiency class (
a
) [A/B/C/D/E/F/G] (
c
)
Washing efficiency index (
a
) x,xx Rinsing effectiveness
(g/kg) (
a
)
x,x
Energy consumption in
kWh per cycle, based
on the »eco 40-60«
programme. Actual energy
consumption will depend
on how the appli ance is
used.
x,xxx
Water consumption in litre
per cycle, based on the
»eco 40-60« programme.
Actual water con sumption
will depend on how the
appliance is used and on
the hardness of the water.
x
Maximum temperature
inside the treated
textile (
a
) (°C)
Rated
capacity
x
Remaining moisture
content (
a
) (%)
Rated
capacity
x
Half x Half x
Quarter x Quarter x
Spin speed (
a
) (rpm)
Rated
capacity
x
Spin-drying efficiency
class (
a
)
[A/B/C/D/E/F/G] (
c
)
Half x
Quarter x
Programme duration (
a
)
(h:min)
Rated
capacity
x:xx
Type
[built-in/
free standing]Half x:xx
Quarter x:xx
Airborne acoustical noise
emissions in the spinning
phase (
a
) (dB(A) re 1 pW)
x
Airborne acoustical
noise emissions class (
a
)
(spinning phase)
[A/B/C/D] (
c
)
Off-mode (W) x,xx Standby mode (W) x,xx
Delay start (W)
(if applicable)
x,xx
Networked standby (W)
(if applicable)
x,xx
864036
50
Minimum duration of the guarantee offered by the supplier (
b
):
This product has been designed to release
silver ions during the washing cycle
[YES/NO]
Additional information:
Weblink to the supplier's website, where the information from point 9 Anex II to Commition
Regulation (EU) 2019/2023 (
a
) (
b
) is found:
(
a
) for the »eco 40-60« programme.
(
b
) changes to these items shall not be considered relevant for the purposes of paragraph 4 of
Article 4 of Regulation (EU) 2017/1369.
(
c
) if the product database automatically generates the definitive content of this cell the supplier
shall not enter these data.
LOW STANDBY MODE
If you do not run any program or choose any settings after switching on the washing machine (ON/
OFF button (1)), the display unit will be switched off after 5 minutes and switched to stand-by mode
in order to save energy.
The display unit will be reactivated if you rotate the programme selector knob (2) or press the ON/
OFF button (1). If you do not do anything for 5 minutes after the end of a programme, the display
unit will be switched off to save power.
P o = weighted power when off [W] < 0,5
P I = weighted power when in standby [W] < 0,5
T I = standby time [min] 5,00
864036
51
We reserve the right to any changes and errors in the instructions for use.
Packaging is made of environmentally friendly materials that can
be recycled, disposed of, or destroyed without any hazard to the
environment. To this end, packaging materials are labelled appropriately.
The symbol on the product or its packaging indicates that the product
should not be treated as normal household waste. Take the product to an
authorized collection centre for waste electric and electronic equipment
processing.
When disposing of the washing machine at the end of its useful life,
remove all power cords, and destroy the door latch and switch to prevent
the door from locking or latching (child safety).
Correct disposal of the product will help prevent any negative effects
on the environment and health of people, which could occur in case
of incorrect product removal. For detailed information on removal and
processing of the product, please contact the relevant municipal body in
charge of waste management, your waste disposal service, or the store
where you bought the product.
DISPOSAL
en (09-21)PS22 B2 ESSENTIAL ENTRY HYG
