This device has a 3 Year limited warranty for the original purchaser from the date of purchase against workmanship and
defects in material. If under normal use, your product fails to operate, a replacement or refund will be provided to you
with proof of purchase. Star Elite Inc. may deny claims of damage caused by misuse or modifications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at:
www.getholmesfans.com
1-866-769-3166 (8:30 am - 5:00 pm EST) Monday - Friday
Our customer service will be happy to assist you.
© 2024 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH026-010424
Instruction Manual
Item: 12860 / 12965 / 12972
Model: 32510394
9inch Digital Twin-Blade
Window Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
覆膜上光油 上水油
DOCKET: KT-512
DATE: November 6, 2023
ITEM/SKU#: 12860
DESCRIPTION: Holmes 9in Digital Window
Fan with Reversible Airflow
CUSTOMER/RETAILER: Target
DESIGNER: RG
FILE TYPE
ALL ARTWORK, DESIGN &
CREATIVE ARE PROPERTY OF:
1175 PLACE DU FRÈRE-ANDRÉ
MONTRÉAL (QUÉBEC)
CANADA H3B 3X9
1 800 890 4076
PKG
PKG FINISHING
Varnish (oil, gloss by default)
NOTE:
Aqueous Coating
Matte
Gloss
IM
RL
PDQ TRAY
COLOURS
PANTONE COLOR
DIMENSION
PHOTOS
ARTWORK IS THE PROPERTY OF L’IMAGE HOME PRODUCTS INC. Printers changing Pantone spot colors to
CMYK do so at their own risk and expense. Print artwork at 100% from PDF supplied, unless otherwise
specified. Proofs/samples must be sent for approval before mass printing.
DO NOT CHANGE ARTWORK IN ANY WAY.
BEFORE MASS PRODUCTION: ELECTRONIC PDF ARTWORK PROOF MUST
BE SENT TO L’IMAGE HOME PRODUCTS GRAPHICS DEPT FOR APPROVAL.
PROCESS COLOR
DIELINE
Spot-UV
PP Lamination
Other (See notes)
High Res Photo
Matte
Gloss
HEIGHT: 19 cm
WIDTH: 56 cm
BLACK
CLEANING / MAINTENANCE
USER SERVICING INSTRUCTIONS
REPLACEABLE FUSE
If the (2.5 Amp, 125 Volt) replaceable fuse blows, please
contact customer service for information on how to order
a new fuse.
REPLACING THE FUSE
Follow the below instructions to replace the fuse on
the plug.
1. Unplug the fan.
Grasp plug and remove from the receptacle or other
outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover towards the prongs.
NOTE: Ensure the fuse
cover is completely open
before attempting to
remove fuse.
3. Remove fuse carefully by
using a small screwdriver to
pry it from the compart-
ment at the metal ends of
the fuse. (See Figure 2)
4. Place plug on a solid, flat surface. Insert new 2.5
Amp, 125 Volt fuse into fuse compartment. Use a
small screwdriver to secure the metal ends of the fuse
into the compartment.
CAUTION: Risk of fire. Replace fuse only with 2.5
Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure
the fuse is completely secured in place by pressing on
metal ends of the fuse.
CAUTION: Risk of fire. Do not replace the
attachment plug. It contains a safety device (fuse)
that should not be removed. Discard product if the
attachment plug is damaged.
Figure 2
Fuse
Fuse cover
Metal ends
CLEANING/MAINTENANCE
Follow these instructions to correctly and safely care for
this window fan.
FAN CLEANING
• Always unplug the fan before cleaning
or disassembling.
• Do not allow water to drip on or into the fan
motor housing.
• Use only a soft cloth moistened with a mild
soap solution.
• Do not use harsh chemicals such as gasoline, thinner
or benzene as a cleaner.
• Do not attempt to remove the fan blade.
• Use CAUTION around the motor housing area. Do not
allow the motor or other electrical components to be
exposed to water.
• It is recommended to periodically clean this fan by
lightly running a vacuum cleaner nozzle over the fan
grill to remove any dust or dirt.
FAN STORAGE
• It is recommended to use the original (or appropriately
sized) box.
• Protect the fan from dirt, dust, and moisture.
For inquiries regarding recycling and proper disposal
of this product, please contact your local waste
management facility.
FCC STATEMENT
Potential for Radio/Television interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. The product
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a
particular installation. If the product does cause harmful interference to radio or television reception, which can be determined by
turning the product on or off, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
The following importer is the responsible party:
Company Name: SEG Products US Corp.
Address: 8 The Green, Suite #6962, Dover, DE 19901
Telephone: 1-959-202-4223
11. WARNING: To reduce the risk of fire, electric shock,
or injury to persons, do not use replacement parts or
attachments not recommended by the manufacturer
(e.g. parts made at home using a 3D printer).
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all parts
properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
19. This fan employs overload protection (fuse). A blown
fuse indicates an overload or short-circuit situation.
If the fuse blows, unplug the product from the outlet.
Replace the fuse as per the user servicing instructions
(follow product marking for proper fuse rating) and
check the product. If the replacement fuse blows, a
short circuit may be present and the product should be
discarded or contact our customer service.
LOW
MED
HIGH
INTAKE
EXHAUST
AIR
FLOW
SPEED
POWER
EXCHANGE
POWER MUTE
SPEED INTAKE
EXHAUST EXCHANGE
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
OPERATING INSTRUCTION (SEE FIGURE 5)
1. Set the fan in the window ensuring the control panel
is facing inward.
2. Plug the fan into a 120V AC electrical outlet.
3. To turn the fan ON, press the Speed / Power Button
(A) located on the control panel or the Power Button
on the remote control. The fan will start running on
the highest setting (HIGH).
4. Press the Speed / Power Button (A) on the control
panel or the Speed Button located on the remote to
move through the speed settings in order:
HIGH
MEDIUM
LOW
5. To set the AIRFLOW direction, press the Airflow Button
(C) on the control panel to select EXHAUST (out),
INTAKE (in), or EXCHANGE (one blade blows air in and
one blade blows air out).
6. To turn the fan OFF using the remote control, press
the Power Button. To turn the fan OFF using the
control panel, press the Speed / Power Button (A)
to toggle through the three speeds. When the fan is
on the lowest speed (LOW) press the Speed / Power
button (A).
NOTE: TO SILENCE CONFIRMATION BEEPS, PRESS THE
MUTE BUTTON ON THE REMOTE CONTROL.
REMOTE CONTROL (SEE FIGURE 6)
NOTE: REMOVE THE PROTECTIVE STICKER FROM THE
REMOTE CONTROL BATTERY BEFORE OPERATION.
This unit includes one lithium button cell battery,
CR2025/3V. Remove battery before discarding the
remote.
Battery Replacement
Button cell batteries should be disposed of properly,
including keeping it away from children. Even used button
cell batteries may cause injury.
1. Locate the battery compartment on the bottom back
of the remote control handset. Push tab and pull
battery tray.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
ASSEMBLY, PARTS
AND OPERATING INSTRUCTIONSS
OPERATING INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Not intended for use by children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on or
taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under rugs
or any parts near an open flame, cooking or other
heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
A. Speed/Power Button
B. Speed Indicator Lights
C. Airflow Button
D. Airflow Indicator Lights
E. Power Button
F. Mute Button
G. Speed Button
H. Intake Button
I. Exhaust Button
J. Exchange Button
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
• The window fan comes fully assembled and is ready
for immediate installation.
• Before installation, familiarize yourself with the
6.5 inch (16.5cm) built-in extender (A) on both sides
of the fan housing (see Figure 1).
NOTE: IT IS RECOMMENDED TO KEEP YOUR WINDOW
SCREEN IN PLACE.
For double-hung windows (designed to fit
windows with minimum openings of 23.25 inches
(60cm) wide and 11.75 inches (30cm) high
1. Align the Window Fan horizontally in the window and
the Built-In-Extender Panels on both sides.
2. With the window open at least 12 inches, take an
accurate measurement of the opening where the unit
will be placed.
3. Match your window measurement with the
INSTALLATION GUIDE (SEE NEXT SECTION).
4. Set the fan in the window ensuring the control panel is
facing inward.
5. Carefully close the window onto the top of the fan so
that the bottom edge of the window rests behind top
line of fan housing. This helps keep the fan in place.
6. Feet (D) should not be installed when mounting in window.
B A
E F
G H
I J
C D
2. Remove the old battery.
3. Place the new battery into the battery tray.
4. Slide battery tray into the battery compartment of
the remote control handset.
NOTES:
1. Remove the battery from the remote control when it
is not being used for an extended period of time.
2. Remove used battery promptly.
3. Do not discard used batteries into household trash
containers. Contact your local government for
disposal or recycling practices in your area.
PLEASE READ AND SAVE THESE IMPORTANT
SAFETY INSTRUCTIONS
Figure 5
Figure 2
Figure 6
INSTALLATION GUIDE
For 23.25 inches (60cm) to 29.75 inches (75.6cm):
Use up to 6.5 inches (15cm) of either side, pull out
extender panel.
For 29.75 inches (75.6cm) to 35.75 inches (89.5cm):
Use up to 6.5 inches (15cm) of both sides, pull out
extender panels.
INSTRUCTIONS FOR FLOOR OR
TABLE USE:
Simple assembly is required to use this fan on a table
or floor.
1. Locate 2 slots on the base of fan (see Figure 2).
2. Push fan foot into slot to lock in place (see Figure 3).
3. Repeat this action on the other foot.
4. Turn the fan right-side up (see Figure 4).
WARNING: BE SURE THE FAN IS SECURELY
INSTALLED IN YOUR WINDOW AT ALL TIMES.
DO NOT LEAN OR PUSH ON THE FAN WHILE IT IS
IN THE WINDOW.
A. 6.5 inches (16.5cm) Built-in Extender Panels
B. Top Window Support
C. Control Panel
D. Fan Feet
A
A
C
D
D
B
Figure 3 Figure 4
Figure 1
WARNING
CR2025/3V
• INGESTION HAZARD: This product contains a button cell or coin battery.
• DEATH or serious injury can occur if ingested.
• A swallowed button cell or coin battery can cause Internal
Chemical Burns in as little as 2 hours.
• KEEP new and used batteries OUT OF REACH of CHILDREN
• Seek immediate medical attention if a battery is suspected to be
swallowed or inserted inside any part of the body.
20. a) Remove and immediately recycle or dispose of used
batteries according to local regulations and keep away
from children. Do NOT dispose of batteries in household
trash or incinerate.
b) Even used batteries may cause severe injury or death.
c) Call a local poison control center for treatment
information.
d) Always use the same size and grade battery as CR2025
for this product.
e) Always use a voltage 3V battery for this product.
f) Non-rechargeable batteries are not to be recharged.
g) Do not force discharge, recharge, disassemble, heat
above 104ºF or incinerate. Doing so may result in injury
due to venting, leakage or explosion resulting in chemical
burns.
h) Ensure the batteries are installed correctly according to
polarity (+ and -).
i) Do not mix old and new batteries, different brands
or types of batteries, such as alkaline, carbon-zinc, or
rechargeable batteries.
j) Remove and immediately recycle or dispose of batteries
from equipment not used for an extended period of time
according to local regulations.
k) Always completely secure the battery compartment.
If the battery compartment does not close securely, stop
using the product, remove the batteries, and keep them
away from children.
11. WARNING: To reduce the risk of fire, electric shock,
or injury to persons, do not use replacement parts or
attachments not recommended by the manufacturer
(e.g. parts made at home using a 3D printer).
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all parts
properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
19. This fan employs overload protection (fuse). A blown
fuse indicates an overload or short-circuit situation.
If the fuse blows, unplug the product from the outlet.
Replace the fuse as per the user servicing instructions
(follow product marking for proper fuse rating) and
check the product. If the replacement fuse blows, a
short circuit may be present and the product should be
discarded or contact our customer service.
LOW
MED
HIGH
INTAKE
EXHAUST
AIR
FLOW
SPEED
POWER
EXCHANGE
POWER MUTE
SPEED INTAKE
EXHAUST EXCHANGE
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
OPERATING INSTRUCTION (SEE FIGURE 5)
1. Set the fan in the window ensuring the control panel
is facing inward.
2. Plug the fan into a 120V AC electrical outlet.
3. To turn the fan ON, press the Speed / Power Button
(A) located on the control panel or the Power Button
on the remote control. The fan will start running on
the highest setting (HIGH).
4. Press the Speed / Power Button (A) on the control
panel or the Speed Button located on the remote to
move through the speed settings in order:
HIGH
MEDIUM
LOW
5. To set the AIRFLOW direction, press the Airflow Button
(C) on the control panel to select EXHAUST (out),
INTAKE (in), or EXCHANGE (one blade blows air in and
one blade blows air out).
6. To turn the fan OFF using the remote control, press
the Power Button. To turn the fan OFF using the
control panel, press the Speed / Power Button (A)
to toggle through the three speeds. When the fan is
on the lowest speed (LOW) press the Speed / Power
button (A).
NOTE: TO SILENCE CONFIRMATION BEEPS, PRESS THE
MUTE BUTTON ON THE REMOTE CONTROL.
REMOTE CONTROL (SEE FIGURE 6)
NOTE: REMOVE THE PROTECTIVE STICKER FROM THE
REMOTE CONTROL BATTERY BEFORE OPERATION.
This unit includes one lithium button cell battery,
CR2025/3V. Remove battery before discarding the
remote.
Battery Replacement
Button cell batteries should be disposed of properly,
including keeping it away from children. Even used button
cell batteries may cause injury.
1. Locate the battery compartment on the bottom back
of the remote control handset. Push tab and pull
battery tray.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
ASSEMBLY, PARTS
AND OPERATING INSTRUCTIONSS
OPERATING INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Not intended for use by children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on or
taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under rugs
or any parts near an open flame, cooking or other
heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
A. Speed/Power Button
B. Speed Indicator Lights
C. Airflow Button
D. Airflow Indicator Lights
E. Power Button
F. Mute Button
G. Speed Button
H. Intake Button
I. Exhaust Button
J. Exchange Button
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
• The window fan comes fully assembled and is ready
for immediate installation.
• Before installation, familiarize yourself with the
6.5 inch (16.5cm) built-in extender (A) on both sides
of the fan housing (see Figure 1).
NOTE: IT IS RECOMMENDED TO KEEP YOUR WINDOW
SCREEN IN PLACE.
For double-hung windows (designed to fit
windows with minimum openings of 23.25 inches
(60cm) wide and 11.75 inches (30cm) high
1. Align the Window Fan horizontally in the window and
the Built-In-Extender Panels on both sides.
2. With the window open at least 12 inches, take an
accurate measurement of the opening where the unit
will be placed.
3. Match your window measurement with the
INSTALLATION GUIDE (SEE NEXT SECTION).
4. Set the fan in the window ensuring the control panel is
facing inward.
5. Carefully close the window onto the top of the fan so
that the bottom edge of the window rests behind top
line of fan housing. This helps keep the fan in place.
6. Feet (D) should not be installed when mounting in window.
B A
E F
G H
I J
C D
2. Remove the old battery.
3. Place the new battery into the battery tray.
4. Slide battery tray into the battery compartment of
the remote control handset.
NOTES:
1. Remove the battery from the remote control when it
is not being used for an extended period of time.
2. Remove used battery promptly.
3. Do not discard used batteries into household trash
containers. Contact your local government for
disposal or recycling practices in your area.
PLEASE READ AND SAVE THESE IMPORTANT
SAFETY INSTRUCTIONS
Figure 5
Figure 2
Figure 6
INSTALLATION GUIDE
For 23.25 inches (60cm) to 29.75 inches (75.6cm):
Use up to 6.5 inches (15cm) of either side, pull out
extender panel.
For 29.75 inches (75.6cm) to 35.75 inches (89.5cm):
Use up to 6.5 inches (15cm) of both sides, pull out
extender panels.
INSTRUCTIONS FOR FLOOR OR
TABLE USE:
Simple assembly is required to use this fan on a table
or floor.
1. Locate 2 slots on the base of fan (see Figure 2).
2. Push fan foot into slot to lock in place (see Figure 3).
3. Repeat this action on the other foot.
4. Turn the fan right-side up (see Figure 4).
WARNING: BE SURE THE FAN IS SECURELY
INSTALLED IN YOUR WINDOW AT ALL TIMES.
DO NOT LEAN OR PUSH ON THE FAN WHILE IT IS
IN THE WINDOW.
A. 6.5 inches (16.5cm) Built-in Extender Panels
B. Top Window Support
C. Control Panel
D. Fan Feet
A
A
C
D
D
B
Figure 3 Figure 4
Figure 1
WARNING
CR2025/3V
• INGESTION HAZARD: This product contains a button cell or coin battery.
• DEATH or serious injury can occur if ingested.
• A swallowed button cell or coin battery can cause Internal
Chemical Burns in as little as 2 hours.
• KEEP new and used batteries OUT OF REACH of CHILDREN
• Seek immediate medical attention if a battery is suspected to be
swallowed or inserted inside any part of the body.
20. a) Remove and immediately recycle or dispose of used
batteries according to local regulations and keep away
from children. Do NOT dispose of batteries in household
trash or incinerate.
b) Even used batteries may cause severe injury or death.
c) Call a local poison control center for treatment
information.
d) Always use the same size and grade battery as CR2025
for this product.
e) Always use a voltage 3V battery for this product.
f) Non-rechargeable batteries are not to be recharged.
g) Do not force discharge, recharge, disassemble, heat
above 104ºF or incinerate. Doing so may result in injury
due to venting, leakage or explosion resulting in chemical
burns.
h) Ensure the batteries are installed correctly according to
polarity (+ and -).
i) Do not mix old and new batteries, different brands
or types of batteries, such as alkaline, carbon-zinc, or
rechargeable batteries.
j) Remove and immediately recycle or dispose of batteries
from equipment not used for an extended period of time
according to local regulations.
k) Always completely secure the battery compartment.
If the battery compartment does not close securely, stop
using the product, remove the batteries, and keep them
away from children.
11. WARNING: To reduce the risk of fire, electric shock,
or injury to persons, do not use replacement parts or
attachments not recommended by the manufacturer
(e.g. parts made at home using a 3D printer).
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all parts
properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
19. This fan employs overload protection (fuse). A blown
fuse indicates an overload or short-circuit situation.
If the fuse blows, unplug the product from the outlet.
Replace the fuse as per the user servicing instructions
(follow product marking for proper fuse rating) and
check the product. If the replacement fuse blows, a
short circuit may be present and the product should be
discarded or contact our customer service.
LOW
MED
HIGH
INTAKE
EXHAUST
AIR
FLOW
SPEED
POWER
EXCHANGE
POWER MUTE
SPEED INTAKE
EXHAUST EXCHANGE
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
OPERATING INSTRUCTION (SEE FIGURE 5)
1. Set the fan in the window ensuring the control panel
is facing inward.
2. Plug the fan into a 120V AC electrical outlet.
3. To turn the fan ON, press the Speed / Power Button
(A) located on the control panel or the Power Button
on the remote control. The fan will start running on
the highest setting (HIGH).
4. Press the Speed / Power Button (A) on the control
panel or the Speed Button located on the remote to
move through the speed settings in order:
HIGH
MEDIUM
LOW
5. To set the AIRFLOW direction, press the Airflow Button
(C) on the control panel to select EXHAUST (out),
INTAKE (in), or EXCHANGE (one blade blows air in and
one blade blows air out).
6. To turn the fan OFF using the remote control, press
the Power Button. To turn the fan OFF using the
control panel, press the Speed / Power Button (A)
to toggle through the three speeds. When the fan is
on the lowest speed (LOW) press the Speed / Power
button (A).
NOTE: TO SILENCE CONFIRMATION BEEPS, PRESS THE
MUTE BUTTON ON THE REMOTE CONTROL.
REMOTE CONTROL (SEE FIGURE 6)
NOTE: REMOVE THE PROTECTIVE STICKER FROM THE
REMOTE CONTROL BATTERY BEFORE OPERATION.
This unit includes one lithium button cell battery,
CR2025/3V. Remove battery before discarding the
remote.
Battery Replacement
Button cell batteries should be disposed of properly,
including keeping it away from children. Even used button
cell batteries may cause injury.
1. Locate the battery compartment on the bottom back
of the remote control handset. Push tab and pull
battery tray.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
ASSEMBLY, PARTS
AND OPERATING INSTRUCTIONSS
OPERATING INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Not intended for use by children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on or
taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under rugs
or any parts near an open flame, cooking or other
heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
A. Speed/Power Button
B. Speed Indicator Lights
C. Airflow Button
D. Airflow Indicator Lights
E. Power Button
F. Mute Button
G. Speed Button
H. Intake Button
I. Exhaust Button
J. Exchange Button
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
• The window fan comes fully assembled and is ready
for immediate installation.
• Before installation, familiarize yourself with the
6.5 inch (16.5cm) built-in extender (A) on both sides
of the fan housing (see Figure 1).
NOTE: IT IS RECOMMENDED TO KEEP YOUR WINDOW
SCREEN IN PLACE.
For double-hung windows (designed to fit
windows with minimum openings of 23.25 inches
(60cm) wide and 11.75 inches (30cm) high
1. Align the Window Fan horizontally in the window and
the Built-In-Extender Panels on both sides.
2. With the window open at least 12 inches, take an
accurate measurement of the opening where the unit
will be placed.
3. Match your window measurement with the
INSTALLATION GUIDE (SEE NEXT SECTION).
4. Set the fan in the window ensuring the control panel is
facing inward.
5. Carefully close the window onto the top of the fan so
that the bottom edge of the window rests behind top
line of fan housing. This helps keep the fan in place.
6. Feet (D) should not be installed when mounting in window.
B A
E F
G H
I J
C D
2. Remove the old battery.
3. Place the new battery into the battery tray.
4. Slide battery tray into the battery compartment of
the remote control handset.
NOTES:
1. Remove the battery from the remote control when it
is not being used for an extended period of time.
2. Remove used battery promptly.
3. Do not discard used batteries into household trash
containers. Contact your local government for
disposal or recycling practices in your area.
PLEASE READ AND SAVE THESE IMPORTANT
SAFETY INSTRUCTIONS
Figure 5
Figure 2
Figure 6
INSTALLATION GUIDE
For 23.25 inches (60cm) to 29.75 inches (75.6cm):
Use up to 6.5 inches (15cm) of either side, pull out
extender panel.
For 29.75 inches (75.6cm) to 35.75 inches (89.5cm):
Use up to 6.5 inches (15cm) of both sides, pull out
extender panels.
INSTRUCTIONS FOR FLOOR OR
TABLE USE:
Simple assembly is required to use this fan on a table
or floor.
1. Locate 2 slots on the base of fan (see Figure 2).
2. Push fan foot into slot to lock in place (see Figure 3).
3. Repeat this action on the other foot.
4. Turn the fan right-side up (see Figure 4).
WARNING: BE SURE THE FAN IS SECURELY
INSTALLED IN YOUR WINDOW AT ALL TIMES.
DO NOT LEAN OR PUSH ON THE FAN WHILE IT IS
IN THE WINDOW.
A. 6.5 inches (16.5cm) Built-in Extender Panels
B. Top Window Support
C. Control Panel
D. Fan Feet
A
A
C
D
D
B
Figure 3 Figure 4
Figure 1
WARNING
CR2025/3V
• INGESTION HAZARD: This product contains a button cell or coin battery.
• DEATH or serious injury can occur if ingested.
• A swallowed button cell or coin battery can cause Internal
Chemical Burns in as little as 2 hours.
• KEEP new and used batteries OUT OF REACH of CHILDREN
• Seek immediate medical attention if a battery is suspected to be
swallowed or inserted inside any part of the body.
20. a) Remove and immediately recycle or dispose of used
batteries according to local regulations and keep away
from children. Do NOT dispose of batteries in household
trash or incinerate.
b) Even used batteries may cause severe injury or death.
c) Call a local poison control center for treatment
information.
d) Always use the same size and grade battery as CR2025
for this product.
e) Always use a voltage 3V battery for this product.
f) Non-rechargeable batteries are not to be recharged.
g) Do not force discharge, recharge, disassemble, heat
above 104ºF or incinerate. Doing so may result in injury
due to venting, leakage or explosion resulting in chemical
burns.
h) Ensure the batteries are installed correctly according to
polarity (+ and -).
i) Do not mix old and new batteries, different brands
or types of batteries, such as alkaline, carbon-zinc, or
rechargeable batteries.
j) Remove and immediately recycle or dispose of batteries
from equipment not used for an extended period of time
according to local regulations.
k) Always completely secure the battery compartment.
If the battery compartment does not close securely, stop
using the product, remove the batteries, and keep them
away from children.
11. WARNING: To reduce the risk of fire, electric shock,
or injury to persons, do not use replacement parts or
attachments not recommended by the manufacturer
(e.g. parts made at home using a 3D printer).
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all parts
properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
19. This fan employs overload protection (fuse). A blown
fuse indicates an overload or short-circuit situation.
If the fuse blows, unplug the product from the outlet.
Replace the fuse as per the user servicing instructions
(follow product marking for proper fuse rating) and
check the product. If the replacement fuse blows, a
short circuit may be present and the product should be
discarded or contact our customer service.
LOW
MED
HIGH
INTAKE
EXHAUST
AIR
FLOW
SPEED
POWER
EXCHANGE
POWER MUTE
SPEED INTAKE
EXHAUST EXCHANGE
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
OPERATING INSTRUCTION (SEE FIGURE 5)
1. Set the fan in the window ensuring the control panel
is facing inward.
2. Plug the fan into a 120V AC electrical outlet.
3. To turn the fan ON, press the Speed / Power Button
(A) located on the control panel or the Power Button
on the remote control. The fan will start running on
the highest setting (HIGH).
4. Press the Speed / Power Button (A) on the control
panel or the Speed Button located on the remote to
move through the speed settings in order:
HIGH
MEDIUM
LOW
5. To set the AIRFLOW direction, press the Airflow Button
(C) on the control panel to select EXHAUST (out),
INTAKE (in), or EXCHANGE (one blade blows air in and
one blade blows air out).
6. To turn the fan OFF using the remote control, press
the Power Button. To turn the fan OFF using the
control panel, press the Speed / Power Button (A)
to toggle through the three speeds. When the fan is
on the lowest speed (LOW) press the Speed / Power
button (A).
NOTE: TO SILENCE CONFIRMATION BEEPS, PRESS THE
MUTE BUTTON ON THE REMOTE CONTROL.
REMOTE CONTROL (SEE FIGURE 6)
NOTE: REMOVE THE PROTECTIVE STICKER FROM THE
REMOTE CONTROL BATTERY BEFORE OPERATION.
This unit includes one lithium button cell battery,
CR2025/3V. Remove battery before discarding the
remote.
Battery Replacement
Button cell batteries should be disposed of properly,
including keeping it away from children. Even used button
cell batteries may cause injury.
1. Locate the battery compartment on the bottom back
of the remote control handset. Push tab and pull
battery tray.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
ASSEMBLY, PARTS
AND OPERATING INSTRUCTIONSS
OPERATING INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Not intended for use by children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on or
taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under rugs
or any parts near an open flame, cooking or other
heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
A. Speed/Power Button
B. Speed Indicator Lights
C. Airflow Button
D. Airflow Indicator Lights
E. Power Button
F. Mute Button
G. Speed Button
H. Intake Button
I. Exhaust Button
J. Exchange Button
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
• The window fan comes fully assembled and is ready
for immediate installation.
• Before installation, familiarize yourself with the
6.5 inch (16.5cm) built-in extender (A) on both sides
of the fan housing (see Figure 1).
NOTE: IT IS RECOMMENDED TO KEEP YOUR WINDOW
SCREEN IN PLACE.
For double-hung windows (designed to fit
windows with minimum openings of 23.25 inches
(60cm) wide and 11.75 inches (30cm) high
1. Align the Window Fan horizontally in the window and
the Built-In-Extender Panels on both sides.
2. With the window open at least 12 inches, take an
accurate measurement of the opening where the unit
will be placed.
3. Match your window measurement with the
INSTALLATION GUIDE (SEE NEXT SECTION).
4. Set the fan in the window ensuring the control panel is
facing inward.
5. Carefully close the window onto the top of the fan so
that the bottom edge of the window rests behind top
line of fan housing. This helps keep the fan in place.
6. Feet (D) should not be installed when mounting in window.
B A
E F
G H
I J
C D
2. Remove the old battery.
3. Place the new battery into the battery tray.
4. Slide battery tray into the battery compartment of
the remote control handset.
NOTES:
1. Remove the battery from the remote control when it
is not being used for an extended period of time.
2. Remove used battery promptly.
3. Do not discard used batteries into household trash
containers. Contact your local government for
disposal or recycling practices in your area.
PLEASE READ AND SAVE THESE IMPORTANT
SAFETY INSTRUCTIONS
Figure 5
Figure 2
Figure 6
INSTALLATION GUIDE
For 23.25 inches (60cm) to 29.75 inches (75.6cm):
Use up to 6.5 inches (15cm) of either side, pull out
extender panel.
For 29.75 inches (75.6cm) to 35.75 inches (89.5cm):
Use up to 6.5 inches (15cm) of both sides, pull out
extender panels.
INSTRUCTIONS FOR FLOOR OR
TABLE USE:
Simple assembly is required to use this fan on a table
or floor.
1. Locate 2 slots on the base of fan (see Figure 2).
2. Push fan foot into slot to lock in place (see Figure 3).
3. Repeat this action on the other foot.
4. Turn the fan right-side up (see Figure 4).
WARNING: BE SURE THE FAN IS SECURELY
INSTALLED IN YOUR WINDOW AT ALL TIMES.
DO NOT LEAN OR PUSH ON THE FAN WHILE IT IS
IN THE WINDOW.
A. 6.5 inches (16.5cm) Built-in Extender Panels
B. Top Window Support
C. Control Panel
D. Fan Feet
A
A
C
D
D
B
Figure 3 Figure 4
Figure 1
WARNING
CR2025/3V
• INGESTION HAZARD: This product contains a button cell or coin battery.
• DEATH or serious injury can occur if ingested.
• A swallowed button cell or coin battery can cause Internal
Chemical Burns in as little as 2 hours.
• KEEP new and used batteries OUT OF REACH of CHILDREN
• Seek immediate medical attention if a battery is suspected to be
swallowed or inserted inside any part of the body.
20. a) Remove and immediately recycle or dispose of used
batteries according to local regulations and keep away
from children. Do NOT dispose of batteries in household
trash or incinerate.
b) Even used batteries may cause severe injury or death.
c) Call a local poison control center for treatment
information.
d) Always use the same size and grade battery as CR2025
for this product.
e) Always use a voltage 3V battery for this product.
f) Non-rechargeable batteries are not to be recharged.
g) Do not force discharge, recharge, disassemble, heat
above 104ºF or incinerate. Doing so may result in injury
due to venting, leakage or explosion resulting in chemical
burns.
h) Ensure the batteries are installed correctly according to
polarity (+ and -).
i) Do not mix old and new batteries, different brands
or types of batteries, such as alkaline, carbon-zinc, or
rechargeable batteries.
j) Remove and immediately recycle or dispose of batteries
from equipment not used for an extended period of time
according to local regulations.
k) Always completely secure the battery compartment.
If the battery compartment does not close securely, stop
using the product, remove the batteries, and keep them
away from children.
This device has a 3 Year limited warranty for the original purchaser from the date of purchase against workmanship and
defects in material. If under normal use, your product fails to operate, a replacement or refund will be provided to you
with proof of purchase. Star Elite Inc. may deny claims of damage caused by misuse or modifications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at:
www.getholmesfans.com
1-866-769-3166 (8:30 am - 5:00 pm EST) Monday - Friday
Our customer service will be happy to assist you.
© 2024 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH026-010424
Instruction Manual
Item: 12860 / 12965 / 12972
Model: 32510394
9inch Digital Twin-Blade
Window Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
覆膜上光油 上水油
DOCKET: KT-512
DATE: November 6, 2023
ITEM/SKU#: 12860
DESCRIPTION: Holmes 9in Digital Window
Fan with Reversible Airflow
CUSTOMER/RETAILER: Target
DESIGNER: RG
FILE TYPE
ALL ARTWORK, DESIGN &
CREATIVE ARE PROPERTY OF:
1175 PLACE DU FRÈRE-ANDRÉ
MONTRÉAL (QUÉBEC)
CANADA H3B 3X9
1 800 890 4076
PKG
PKG FINISHING
Varnish (oil, gloss by default)
NOTE:
Aqueous Coating
Matte
Gloss
IM
RL
PDQ TRAY
COLOURS
PANTONE COLOR
DIMENSION
PHOTOS
ARTWORK IS THE PROPERTY OF L’IMAGE HOME PRODUCTS INC. Printers changing Pantone spot colors to
CMYK do so at their own risk and expense. Print artwork at 100% from PDF supplied, unless otherwise
specified. Proofs/samples must be sent for approval before mass printing.
DO NOT CHANGE ARTWORK IN ANY WAY.
BEFORE MASS PRODUCTION: ELECTRONIC PDF ARTWORK PROOF MUST
BE SENT TO L’IMAGE HOME PRODUCTS GRAPHICS DEPT FOR APPROVAL.
PROCESS COLOR
DIELINE
Spot-UV
PP Lamination
Other (See notes)
High Res Photo
Matte
Gloss
HEIGHT: 19 cm
WIDTH: 56 cm
BLACK
CLEANING / MAINTENANCE
USER SERVICING INSTRUCTIONS
REPLACEABLE FUSE
If the (2.5 Amp, 125 Volt) replaceable fuse blows, please
contact customer service for information on how to order
a new fuse.
REPLACING THE FUSE
Follow the below instructions to replace the fuse on
the plug.
1. Unplug the fan.
Grasp plug and remove from the receptacle or other
outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover towards the prongs.
NOTE: Ensure the fuse
cover is completely open
before attempting to
remove fuse.
3. Remove fuse carefully by
using a small screwdriver to
pry it from the compart-
ment at the metal ends of
the fuse. (See Figure 2)
4. Place plug on a solid, flat surface. Insert new 2.5
Amp, 125 Volt fuse into fuse compartment. Use a
small screwdriver to secure the metal ends of the fuse
into the compartment.
CAUTION: Risk of fire. Replace fuse only with 2.5
Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure
the fuse is completely secured in place by pressing on
metal ends of the fuse.
CAUTION: Risk of fire. Do not replace the
attachment plug. It contains a safety device (fuse)
that should not be removed. Discard product if the
attachment plug is damaged.
Figure 2
Fuse
Fuse cover
Metal ends
CLEANING/MAINTENANCE
Follow these instructions to correctly and safely care for
this window fan.
FAN CLEANING
• Always unplug the fan before cleaning
or disassembling.
• Do not allow water to drip on or into the fan
motor housing.
• Use only a soft cloth moistened with a mild
soap solution.
• Do not use harsh chemicals such as gasoline, thinner
or benzene as a cleaner.
• Do not attempt to remove the fan blade.
• Use CAUTION around the motor housing area. Do not
allow the motor or other electrical components to be
exposed to water.
• It is recommended to periodically clean this fan by
lightly running a vacuum cleaner nozzle over the fan
grill to remove any dust or dirt.
FAN STORAGE
• It is recommended to use the original (or appropriately
sized) box.
• Protect the fan from dirt, dust, and moisture.
For inquiries regarding recycling and proper disposal
of this product, please contact your local waste
management facility.
FCC STATEMENT
Potential for Radio/Television interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. The product
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a
particular installation. If the product does cause harmful interference to radio or television reception, which can be determined by
turning the product on or off, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
The following importer is the responsible party:
Company Name: SEG Products US Corp.
Address: 8 The Green, Suite #6962, Dover, DE 19901
Telephone: 1-959-202-4223
This device has a 3 Year limited warranty for the original purchaser from the date of purchase against workmanship and
defects in material. If under normal use, your product fails to operate, a replacement or refund will be provided to you
with proof of purchase. Star Elite Inc. may deny claims of damage caused by misuse or modifications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at:
www.getholmesfans.com
1-866-769-3166 (8:30 am - 5:00 pm EST) Monday - Friday
Our customer service will be happy to assist you.
© 2024 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH026-010424
Instruction Manual
Item: 12860 / 12965 / 12972
Model: 32510394
9inch Digital Twin-Blade
Window Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
覆膜上光油 上水油
DOCKET: KT-512
DATE: November 6, 2023
ITEM/SKU#: 12860
DESCRIPTION: Holmes 9in Digital Window
Fan with Reversible Airflow
CUSTOMER/RETAILER: Target
DESIGNER: RG
FILE TYPE
ALL ARTWORK, DESIGN &
CREATIVE ARE PROPERTY OF:
1175 PLACE DU FRÈRE-ANDRÉ
MONTRÉAL (QUÉBEC)
CANADA H3B 3X9
1 800 890 4076
PKG
PKG FINISHING
Varnish (oil, gloss by default)
NOTE:
Aqueous Coating
Matte
Gloss
IM
RL
PDQ TRAY
COLOURS
PANTONE COLOR
DIMENSION
PHOTOS
ARTWORK IS THE PROPERTY OF L’IMAGE HOME PRODUCTS INC. Printers changing Pantone spot colors to
CMYK do so at their own risk and expense. Print artwork at 100% from PDF supplied, unless otherwise
specified. Proofs/samples must be sent for approval before mass printing.
DO NOT CHANGE ARTWORK IN ANY WAY.
BEFORE MASS PRODUCTION: ELECTRONIC PDF ARTWORK PROOF MUST
BE SENT TO L’IMAGE HOME PRODUCTS GRAPHICS DEPT FOR APPROVAL.
PROCESS COLOR
DIELINE
Spot-UV
PP Lamination
Other (See notes)
High Res Photo
Matte
Gloss
HEIGHT: 19 cm
WIDTH: 56 cm
BLACK
CLEANING / MAINTENANCE
USER SERVICING INSTRUCTIONS
REPLACEABLE FUSE
If the (2.5 Amp, 125 Volt) replaceable fuse blows, please
contact customer service for information on how to order
a new fuse.
REPLACING THE FUSE
Follow the below instructions to replace the fuse on
the plug.
1. Unplug the fan.
Grasp plug and remove from the receptacle or other
outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover towards the prongs.
NOTE: Ensure the fuse
cover is completely open
before attempting to
remove fuse.
3. Remove fuse carefully by
using a small screwdriver to
pry it from the compart-
ment at the metal ends of
the fuse. (See Figure 2)
4. Place plug on a solid, flat surface. Insert new 2.5
Amp, 125 Volt fuse into fuse compartment. Use a
small screwdriver to secure the metal ends of the fuse
into the compartment.
CAUTION: Risk of fire. Replace fuse only with 2.5
Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure
the fuse is completely secured in place by pressing on
metal ends of the fuse.
CAUTION: Risk of fire. Do not replace the
attachment plug. It contains a safety device (fuse)
that should not be removed. Discard product if the
attachment plug is damaged.
Figure 2
Fuse
Fuse cover
Metal ends
CLEANING/MAINTENANCE
Follow these instructions to correctly and safely care for
this window fan.
FAN CLEANING
• Always unplug the fan before cleaning
or disassembling.
• Do not allow water to drip on or into the fan
motor housing.
• Use only a soft cloth moistened with a mild
soap solution.
• Do not use harsh chemicals such as gasoline, thinner
or benzene as a cleaner.
• Do not attempt to remove the fan blade.
• Use CAUTION around the motor housing area. Do not
allow the motor or other electrical components to be
exposed to water.
• It is recommended to periodically clean this fan by
lightly running a vacuum cleaner nozzle over the fan
grill to remove any dust or dirt.
FAN STORAGE
• It is recommended to use the original (or appropriately
sized) box.
• Protect the fan from dirt, dust, and moisture.
For inquiries regarding recycling and proper disposal
of this product, please contact your local waste
management facility.
FCC STATEMENT
Potential for Radio/Television interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. The product
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a
particular installation. If the product does cause harmful interference to radio or television reception, which can be determined by
turning the product on or off, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
The following importer is the responsible party:
Company Name: SEG Products US Corp.
Address: 8 The Green, Suite #6962, Dover, DE 19901
Telephone: 1-959-202-4223
This device has a 3 Year limited warranty for the original purchaser from the date of purchase against workmanship and
defects in material. If under normal use, your product fails to operate, a replacement or refund will be provided to you
with proof of purchase. Star Elite Inc. may deny claims of damage caused by misuse or modifications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at:
www.getholmesfans.com
1-866-769-3166 (8:30 am - 5:00 pm EST) Monday - Friday
Our customer service will be happy to assist you.
© 2024 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH026-010424
Instruction Manual
Item: 12860 / 12965 / 12972
Model: 32510394
9inch Digital Twin-Blade
Window Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
覆膜上光油 上水油
DOCKET: KT-512
DATE: November 6, 2023
ITEM/SKU#: 12860
DESCRIPTION: Holmes 9in Digital Window
Fan with Reversible Airflow
CUSTOMER/RETAILER: Target
DESIGNER: RG
FILE TYPE
ALL ARTWORK, DESIGN &
CREATIVE ARE PROPERTY OF:
1175 PLACE DU FRÈRE-ANDRÉ
MONTRÉAL (QUÉBEC)
CANADA H3B 3X9
1 800 890 4076
PKG
PKG FINISHING
Varnish (oil, gloss by default)
NOTE:
Aqueous Coating
Matte
Gloss
IM
RL
PDQ TRAY
COLOURS
PANTONE COLOR
DIMENSION
PHOTOS
ARTWORK IS THE PROPERTY OF L’IMAGE HOME PRODUCTS INC. Printers changing Pantone spot colors to
CMYK do so at their own risk and expense. Print artwork at 100% from PDF supplied, unless otherwise
specified. Proofs/samples must be sent for approval before mass printing.
DO NOT CHANGE ARTWORK IN ANY WAY.
BEFORE MASS PRODUCTION: ELECTRONIC PDF ARTWORK PROOF MUST
BE SENT TO L’IMAGE HOME PRODUCTS GRAPHICS DEPT FOR APPROVAL.
PROCESS COLOR
DIELINE
Spot-UV
PP Lamination
Other (See notes)
High Res Photo
Matte
Gloss
HEIGHT: 19 cm
WIDTH: 56 cm
BLACK
CLEANING / MAINTENANCE
USER SERVICING INSTRUCTIONS
REPLACEABLE FUSE
If the (2.5 Amp, 125 Volt) replaceable fuse blows, please
contact customer service for information on how to order
a new fuse.
REPLACING THE FUSE
Follow the below instructions to replace the fuse on
the plug.
1. Unplug the fan.
Grasp plug and remove from the receptacle or other
outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover towards the prongs.
NOTE: Ensure the fuse
cover is completely open
before attempting to
remove fuse.
3. Remove fuse carefully by
using a small screwdriver to
pry it from the compart-
ment at the metal ends of
the fuse. (See Figure 2)
4. Place plug on a solid, flat surface. Insert new 2.5
Amp, 125 Volt fuse into fuse compartment. Use a
small screwdriver to secure the metal ends of the fuse
into the compartment.
CAUTION: Risk of fire. Replace fuse only with 2.5
Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure
the fuse is completely secured in place by pressing on
metal ends of the fuse.
CAUTION: Risk of fire. Do not replace the
attachment plug. It contains a safety device (fuse)
that should not be removed. Discard product if the
attachment plug is damaged.
Figure 2
Fuse
Fuse cover
Metal ends
CLEANING/MAINTENANCE
Follow these instructions to correctly and safely care for
this window fan.
FAN CLEANING
• Always unplug the fan before cleaning
or disassembling.
• Do not allow water to drip on or into the fan
motor housing.
• Use only a soft cloth moistened with a mild
soap solution.
• Do not use harsh chemicals such as gasoline, thinner
or benzene as a cleaner.
• Do not attempt to remove the fan blade.
• Use CAUTION around the motor housing area. Do not
allow the motor or other electrical components to be
exposed to water.
• It is recommended to periodically clean this fan by
lightly running a vacuum cleaner nozzle over the fan
grill to remove any dust or dirt.
FAN STORAGE
• It is recommended to use the original (or appropriately
sized) box.
• Protect the fan from dirt, dust, and moisture.
For inquiries regarding recycling and proper disposal
of this product, please contact your local waste
management facility.
FCC STATEMENT
Potential for Radio/Television interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. The product
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a
particular installation. If the product does cause harmful interference to radio or television reception, which can be determined by
turning the product on or off, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
The following importer is the responsible party:
Company Name: SEG Products US Corp.
Address: 8 The Green, Suite #6962, Dover, DE 19901
Telephone: 1-959-202-4223
