Instruction Manual
Item: 17101
Model: 32510027
Twin Window Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 years from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc. may
deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166
(8:30 am - 5:00 pm EST) Monday - Friday
or contact us at info@getholmesfans.com.
Our customer service will be happy to assist you.
www.getholmesfans.com
© 2021 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH015-120321
CLEANING / MAINTENANCE
USER SERVICING INSTRUCTIONS
REPLACEABLE FUSE
If your (5 Amp, 125 Volt) replaceable fuse blows,
please visit our website at www.getholmesfans.com for
information on how to order a new fuse.
REPLACING THE FUSE
1. Unplug your fan.
Grasp plug and remove from the receptacle or other
outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover towards the prongs.
NOTE: Ensure the fuse cover is completely open
before attempting to remove fuse.
3. Remove fuse carefully by
using a small screwdriver to
pry it from the compart-
ment at the metal ends of
the fuse. (See Figure 3)
4. Place plug on a solid, flat
surface. Insert new 5 Amp,
125 Volt fuse into fuse
compartment. Use a small
screwdriver to secure the metal ends of the fuse into
the compartment.
CAUTION: Risk of fire. Replace fuse only with 5
Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure
the fuse is completely secured in place by pressing on
metal ends of the fuse.
CAUTION: Risk of fire. Do not replace the
attachment plug. It contains a safety device (fuse)
that should not be removed. Discard product if the
attachment plug is damaged.
Figure 3
Fuse
Fuse cover
Metal ends
CLEANING/MAINTENANCE
Follow these instructions to correctly and safely care for
your window fan.
FAN CLEANING
• Always unplug the fan before cleaning or
disassembling.
• Do not allow water to drip on or into the fan motor
housing.
• Do not use harsh chemicals such as gasoline, thinner
or benzene as a cleaner.
FAN BLADE AND FRONT GRILL CLEANING
1. Make sure the fan is unplugged.
2. Using a Phillips head screwdriver, remove the screws
located around the perimeter of the rear grill.
3. Carefully separate the front and the rear grills from
the end opposite the built in extender.
NOTE: Do not completely detach the grills as this
may damage the extender clips. Separate them only
enough to access the blades with one hand.
4. Clean the blades and grills with a soft cloth moistened
with a mild soap solution.
5. Securely fasten the front and rear grill back together.
FAN STORAGE
• It is recommended to use the original (or appropriately
sized) box.
• Protect the fan from dirt, dust, and moisture.
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to info@getholmesfans.com. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste
management facility.
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
• The window fan comes fully assembled and is ready
for immediate installation.
• Before installation, familiarize yourself with the
built-in 7 inches (17cm) extender (D) on the right
side of the fan housing, and the additional 4.25
inches (10cm) extender (A) which attach to the left
side of the fan housing (see Figure 1).
NOTE: WE RECOMMEND KEEPING YOUR WINDOW
SCREEN IN PLACE.
For double-hung windows (designed to fit
windows with minimum openings of 22 inches
(55cm) wide and 10 inches (25cm) high)
1. Align the Window Fan horizontally in the window and
the Built-In Extender Panel to the right.
2. With the window open, take an accurate measurement
of the opening where the unit will be placed.
3. Match your window measurement with the
INSTALLATION GUIDE (SEE NEXT SECTION).
4. Once you have attached the extender panel(s) (if
needed), set the fan in the window. You will complete
installation with built-in extender. Pull out both clips on
right side of the fan, then pull out the built-in extender.
To lock extender into place, press the clips down.
• Make sure rotary switch is in the OFF position.
• Plug into 120V AC electric outlet.
• To use in EXHAUST mode, manually turn the unit
around in the window. (Controls can be operated
from both sides.)
• To start the unit, turn the rotary switch (C) to desired
speed (high or low).
WARNING: BE SURE FAN IS SECURELY INSTALLED IN
YOUR WINDOW AT ALL TIMES. DO NOT LEAN OR PUSH
ON FAN WHILE IT IS IN THE WINDOW.
5. Carefully close the window onto the top of the fan so
that the bottom edge of the window rests behind top
line of fan housing. This helps keep the fan in place.
For slider windows (will fit windows 10
inches/25cm wide and 36 inches/91cm high)
In a slider window, the control must face inward, towards
the window. The 7 inch (17cm) built-in extender will be
positioned on top. Prior to installing unit in window,
measure the height and adjust the upper extender for a
snug t.
NOTE: In some slider windows you may need to remove
the screen.
INSTALLATION GUIDE
For 22 inches (55cm) to 29 inches (73cm):
Use up to 7 inches (17cm) of right side, pull out extender
panel.
For 29 inches (73cm) to 33.25 inches (83cm):
Use one 4.25 inches (10cm) extender panel on the left
side. Adjust the pull out extender on the right side for a
tight t (from 0.5 inches (1cm) to 7 inches (17cm)).
Larger than 33.25 inches (83cm):
Additional extender panels will be required
(contact customer service for ordering information).
WARNING: BE SURE THE FAN IS SECURELY
INSTALLED IN YOUR WINDOW AT ALL TIMES.
DO NOT LEAN OR PUSH ON THE FAN WHILE IT IS
IN THE WINDOW.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
INSTALLATION
OPERATING INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the
instruction manual.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7 . Do not operate in the presence of explosive and/or
ammable fumes.
8. To avoid re hazard, NEVER place the cord under
rugs or any parts near an open ame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has
been dropped/damaged in any manner. Discard fan
or contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from trafc area and where it will not be
tripped over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high trafc areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all
parts properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of re or electric
shock, do not use this fan with any solid-state speed
control device.
19. This product employs overload protection (fuse).
A blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or contact customer service.
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
A
B
D
Figure 1
A. 4.25 inches (10cm)
Slide on Extender
B. Top Window Support
C. 2 Speed Motor Control
D. Built-in Adjustable
Extender Panel (pulls
out 7 inches/17cm )
FRONT VIEW
Figure 2
LEFT
4.25 inch (10cm)
extender panel
RIGHT
Built-in extender, pulls out
up to 7 inches (17cm)
22 inches (55 cm)
UNIT’S LENGTH
C
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
• The window fan comes fully assembled and is ready
for immediate installation.
• Before installation, familiarize yourself with the
built-in 7 inches (17cm) extender (D) on the right
side of the fan housing, and the additional 4.25
inches (10cm) extender (A) which attach to the left
side of the fan housing (see Figure 1).
NOTE: WE RECOMMEND KEEPING YOUR WINDOW
SCREEN IN PLACE.
For double-hung windows (designed to fit
windows with minimum openings of 22 inches
(55cm) wide and 10 inches (25cm) high)
1. Align the Window Fan horizontally in the window and
the Built-In Extender Panel to the right.
2. With the window open, take an accurate measurement
of the opening where the unit will be placed.
3. Match your window measurement with the
INSTALLATION GUIDE (SEE NEXT SECTION).
4. Once you have attached the extender panel(s) (if
needed), set the fan in the window. You will complete
installation with built-in extender. Pull out both clips on
right side of the fan, then pull out the built-in extender.
To lock extender into place, press the clips down.
• Make sure rotary switch is in the OFF position.
• Plug into 120V AC electric outlet.
• To use in EXHAUST mode, manually turn the unit
around in the window. (Controls can be operated
from both sides.)
• To start the unit, turn the rotary switch (C) to desired
speed (high or low).
WARNING: BE SURE FAN IS SECURELY INSTALLED IN
YOUR WINDOW AT ALL TIMES. DO NOT LEAN OR PUSH
ON FAN WHILE IT IS IN THE WINDOW.
5. Carefully close the window onto the top of the fan so
that the bottom edge of the window rests behind top
line of fan housing. This helps keep the fan in place.
For slider windows (will fit windows 10
inches/25cm wide and 36 inches/91cm high)
In a slider window, the control must face inward, towards
the window. The 7 inch (17cm) built-in extender will be
positioned on top. Prior to installing unit in window,
measure the height and adjust the upper extender for a
snug t.
NOTE: In some slider windows you may need to remove
the screen.
INSTALLATION GUIDE
For 22 inches (55cm) to 29 inches (73cm):
Use up to 7 inches (17cm) of right side, pull out extender
panel.
For 29 inches (73cm) to 33.25 inches (83cm):
Use one 4.25 inches (10cm) extender panel on the left
side. Adjust the pull out extender on the right side for a
tight t (from 0.5 inches (1cm) to 7 inches (17cm)).
Larger than 33.25 inches (83cm):
Additional extender panels will be required
(contact customer service for ordering information).
WARNING: BE SURE THE FAN IS SECURELY
INSTALLED IN YOUR WINDOW AT ALL TIMES.
DO NOT LEAN OR PUSH ON THE FAN WHILE IT IS
IN THE WINDOW.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
INSTALLATION
OPERATING INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the
instruction manual.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7 . Do not operate in the presence of explosive and/or
ammable fumes.
8. To avoid re hazard, NEVER place the cord under
rugs or any parts near an open ame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has
been dropped/damaged in any manner. Discard fan
or contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from trafc area and where it will not be
tripped over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high trafc areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all
parts properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of re or electric
shock, do not use this fan with any solid-state speed
control device.
19. This product employs overload protection (fuse).
A blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or contact customer service.
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
A
B
D
Figure 1
A. 4.25 inches (10cm)
Slide on Extender
B. Top Window Support
C. 2 Speed Motor Control
D. Built-in Adjustable
Extender Panel (pulls
out 7 inches/17cm )
FRONT VIEW
Figure 2
LEFT
4.25 inch (10cm)
extender panel
RIGHT
Built-in extender, pulls out
up to 7 inches (17cm)
22 inches (55 cm)
UNIT’S LENGTH
C
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
• The window fan comes fully assembled and is ready
for immediate installation.
• Before installation, familiarize yourself with the
built-in 7 inches (17cm) extender (D) on the right
side of the fan housing, and the additional 4.25
inches (10cm) extender (A) which attach to the left
side of the fan housing (see Figure 1).
NOTE: WE RECOMMEND KEEPING YOUR WINDOW
SCREEN IN PLACE.
For double-hung windows (designed to fit
windows with minimum openings of 22 inches
(55cm) wide and 10 inches (25cm) high)
1. Align the Window Fan horizontally in the window and
the Built-In Extender Panel to the right.
2. With the window open, take an accurate measurement
of the opening where the unit will be placed.
3. Match your window measurement with the
INSTALLATION GUIDE (SEE NEXT SECTION).
4. Once you have attached the extender panel(s) (if
needed), set the fan in the window. You will complete
installation with built-in extender. Pull out both clips on
right side of the fan, then pull out the built-in extender.
To lock extender into place, press the clips down.
• Make sure rotary switch is in the OFF position.
• Plug into 120V AC electric outlet.
• To use in EXHAUST mode, manually turn the unit
around in the window. (Controls can be operated
from both sides.)
• To start the unit, turn the rotary switch (C) to desired
speed (high or low).
WARNING: BE SURE FAN IS SECURELY INSTALLED IN
YOUR WINDOW AT ALL TIMES. DO NOT LEAN OR PUSH
ON FAN WHILE IT IS IN THE WINDOW.
5. Carefully close the window onto the top of the fan so
that the bottom edge of the window rests behind top
line of fan housing. This helps keep the fan in place.
For slider windows (will fit windows 10
inches/25cm wide and 36 inches/91cm high)
In a slider window, the control must face inward, towards
the window. The 7 inch (17cm) built-in extender will be
positioned on top. Prior to installing unit in window,
measure the height and adjust the upper extender for a
snug t.
NOTE: In some slider windows you may need to remove
the screen.
INSTALLATION GUIDE
For 22 inches (55cm) to 29 inches (73cm):
Use up to 7 inches (17cm) of right side, pull out extender
panel.
For 29 inches (73cm) to 33.25 inches (83cm):
Use one 4.25 inches (10cm) extender panel on the left
side. Adjust the pull out extender on the right side for a
tight t (from 0.5 inches (1cm) to 7 inches (17cm)).
Larger than 33.25 inches (83cm):
Additional extender panels will be required
(contact customer service for ordering information).
WARNING: BE SURE THE FAN IS SECURELY
INSTALLED IN YOUR WINDOW AT ALL TIMES.
DO NOT LEAN OR PUSH ON THE FAN WHILE IT IS
IN THE WINDOW.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
INSTALLATION
OPERATING INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the
instruction manual.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7 . Do not operate in the presence of explosive and/or
ammable fumes.
8. To avoid re hazard, NEVER place the cord under
rugs or any parts near an open ame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has
been dropped/damaged in any manner. Discard fan
or contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from trafc area and where it will not be
tripped over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high trafc areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all
parts properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of re or electric
shock, do not use this fan with any solid-state speed
control device.
19. This product employs overload protection (fuse).
A blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or contact customer service.
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
A
B
D
Figure 1
A. 4.25 inches (10cm)
Slide on Extender
B. Top Window Support
C. 2 Speed Motor Control
D. Built-in Adjustable
Extender Panel (pulls
out 7 inches/17cm )
FRONT VIEW
Figure 2
LEFT
4.25 inch (10cm)
extender panel
RIGHT
Built-in extender, pulls out
up to 7 inches (17cm)
22 inches (55 cm)
UNIT’S LENGTH
C
Instruction Manual
Item: 17101
Model: 32510027
Twin Window Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 years from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc. may
deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166
(8:30 am - 5:00 pm EST) Monday - Friday
or contact us at info@getholmesfans.com.
Our customer service will be happy to assist you.
www.getholmesfans.com
© 2021 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH015-120321
CLEANING / MAINTENANCE
USER SERVICING INSTRUCTIONS
REPLACEABLE FUSE
If your (5 Amp, 125 Volt) replaceable fuse blows,
please visit our website at www.getholmesfans.com for
information on how to order a new fuse.
REPLACING THE FUSE
1. Unplug your fan.
Grasp plug and remove from the receptacle or other
outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover towards the prongs.
NOTE: Ensure the fuse cover is completely open
before attempting to remove fuse.
3. Remove fuse carefully by
using a small screwdriver to
pry it from the compart-
ment at the metal ends of
the fuse. (See Figure 3)
4. Place plug on a solid, flat
surface. Insert new 5 Amp,
125 Volt fuse into fuse
compartment. Use a small
screwdriver to secure the metal ends of the fuse into
the compartment.
CAUTION: Risk of fire. Replace fuse only with 5
Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure
the fuse is completely secured in place by pressing on
metal ends of the fuse.
CAUTION: Risk of fire. Do not replace the
attachment plug. It contains a safety device (fuse)
that should not be removed. Discard product if the
attachment plug is damaged.
Figure 3
Fuse
Fuse cover
Metal ends
CLEANING/MAINTENANCE
Follow these instructions to correctly and safely care for
your window fan.
FAN CLEANING
• Always unplug the fan before cleaning or
disassembling.
• Do not allow water to drip on or into the fan motor
housing.
• Do not use harsh chemicals such as gasoline, thinner
or benzene as a cleaner.
FAN BLADE AND FRONT GRILL CLEANING
1. Make sure the fan is unplugged.
2. Using a Phillips head screwdriver, remove the screws
located around the perimeter of the rear grill.
3. Carefully separate the front and the rear grills from
the end opposite the built in extender.
NOTE: Do not completely detach the grills as this
may damage the extender clips. Separate them only
enough to access the blades with one hand.
4. Clean the blades and grills with a soft cloth moistened
with a mild soap solution.
5. Securely fasten the front and rear grill back together.
FAN STORAGE
• It is recommended to use the original (or appropriately
sized) box.
• Protect the fan from dirt, dust, and moisture.
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to [email protected]. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste
management facility.
Instruction Manual
Item: 17101
Model: 32510027
Twin Window Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 years from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc. may
deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166
(8:30 am - 5:00 pm EST) Monday - Friday
or contact us at [email protected].
Our customer service will be happy to assist you.
www.getholmesfans.com
© 2021 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH015-120321
CLEANING / MAINTENANCE
USER SERVICING INSTRUCTIONS
REPLACEABLE FUSE
If your (5 Amp, 125 Volt) replaceable fuse blows,
please visit our website at www.getholmesfans.com for
information on how to order a new fuse.
REPLACING THE FUSE
1. Unplug your fan.
Grasp plug and remove from the receptacle or other
outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover towards the prongs.
NOTE: Ensure the fuse cover is completely open
before attempting to remove fuse.
3. Remove fuse carefully by
using a small screwdriver to
pry it from the compart-
ment at the metal ends of
the fuse. (See Figure 3)
4. Place plug on a solid, flat
surface. Insert new 5 Amp,
125 Volt fuse into fuse
compartment. Use a small
screwdriver to secure the metal ends of the fuse into
the compartment.
CAUTION: Risk of fire. Replace fuse only with 5
Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure
the fuse is completely secured in place by pressing on
metal ends of the fuse.
CAUTION: Risk of fire. Do not replace the
attachment plug. It contains a safety device (fuse)
that should not be removed. Discard product if the
attachment plug is damaged.
Figure 3
Fuse
Fuse cover
Metal ends
CLEANING/MAINTENANCE
Follow these instructions to correctly and safely care for
your window fan.
FAN CLEANING
• Always unplug the fan before cleaning or
disassembling.
• Do not allow water to drip on or into the fan motor
housing.
• Do not use harsh chemicals such as gasoline, thinner
or benzene as a cleaner.
FAN BLADE AND FRONT GRILL CLEANING
1. Make sure the fan is unplugged.
2. Using a Phillips head screwdriver, remove the screws
located around the perimeter of the rear grill.
3. Carefully separate the front and the rear grills from
the end opposite the built in extender.
NOTE: Do not completely detach the grills as this
may damage the extender clips. Separate them only
enough to access the blades with one hand.
4. Clean the blades and grills with a soft cloth moistened
with a mild soap solution.
5. Securely fasten the front and rear grill back together.
FAN STORAGE
• It is recommended to use the original (or appropriately
sized) box.
• Protect the fan from dirt, dust, and moisture.
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to info@getholmesfans.com. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste
management facility.
