WEATHER STATION WITH
FORECAST AND ATOMIC TIME
QUICK START GUIDE
MODEL: 308-1417BLV2
DC: 030520
For more product information visit: bit.ly/laxtech_support
POWER UP
1. Insert 2-AA batteries into your Outdoor Sensor.
2. Insert the 5 volt power cord into the outlet, then into your
station. Optional: Insert 3-AA batteries for backup.
3. Adjust time and date settings on the station.
4. Once the Outdoor Sensor is reading to your station, place it
outside in a shaded location.
Watch sensor mounting video: bit.ly/TH_SensorMounting
Outdoor Sensor
TX141TH-Bv3
Weather Station
308-1417BLv2
WWVB ATOMIC TIME SIGNAL
SETTINGS
1. Hold the SET button to enter the Settings Menu.
2. Use the + or - button to adjust, and SET to confirm.
3. Press the SEARCH button anytime to exit the Settings Menu.
Settings Menu order:
• Language: (English, Español, Français)
• Beep ON | OFF
• Atomic ON | OFF
• DST ON | OFF (Daylight Saving Time)
• Time Zone
• 12Hr | 24Hr Format
• Hour
• Minutes
• Year
• Month
• Date
• Temperature Fahrenheit | Celsius
• Pressure units: INHG or HPA
• Pressure number setting
Language: When Español or Francais is selected, the following
instructions and weekday will be presented in that language.
Weekday: Weekday sets automatically when Year, Month and Date
are set.
PRESSURE HISTORY GRAPH
• The station will automatically search for the atomic time signal at
UTC 7:00, 8:00, 9:00, 10:00, and 11:00.
• The Atomic Time Signal Icon will flash while searching, and be
solid when connected.
• Press the SEARCH button anytime, to manually search for the
atomic time signal.
• For information about WWVB visit: bit.ly/AtomicTime
• Read from left to right, your Pressure History Graph indicates
the rise and fall in air pressure over the past 24 hours.
•The graph will scroll continually. This cannot be turned o.
-24h -18h -12h -9h -6h -3h 0h
PRESSURE HISTORY
ADJUSTABLE BACKLIGHT
• Press and release the LIGHT button to adjust the White Backlight;
HI-LOW-OFF.
• When operating on batteries only, press the LIGHT button for a
10 second backlight.
The station will use changes in atmospheric pressure to predict
your weather conditions to come in the next 12 hours. Please allow
up to 10 days for correct calibration and accurate forecast icons.
WEATHER FORECAST ICONS
FORECAST
FORECAST
FORECAST
FORECAST
FORECAST
FORECAST
Time Zones
Note: Snowy icon shows when outdoor temperature is below 32°F
and the forecast calls for rain or thunderstorms.
Page 3
Page 4
Page | 2
WEATHER STATION WITH
FORECAST AND ATOMIC TIME
QUICK START GUIDE
MODEL: 308-1417BLV2
DC: 030520
For more product information visit: bit.ly/laxtech_support
POWER UP
1. Insert 2-AA batteries into your Outdoor Sensor.
2. Insert the 5 volt power cord into the outlet, then into your
station. Optional: Insert 3-AA batteries for backup.
3. Adjust time and date settings on the station.
4. Once the Outdoor Sensor is reading to your station, place it
outside in a shaded location.
Watch sensor mounting video: bit.ly/TH_SensorMounting
Outdoor Sensor
TX141TH-Bv3
Weather Station
308-1417BLv2
WWVB ATOMIC TIME SIGNAL
SETTINGS
1. Hold the SET button to enter the Settings Menu.
2. Use the + or - button to adjust, and SET to confirm.
3. Press the SEARCH button anytime to exit the Settings Menu.
Settings Menu order:
• Language: (English, Español, Français)
• Beep ON | OFF
• Atomic ON | OFF
• DST ON | OFF (Daylight Saving Time)
• Time Zone
• 12Hr | 24Hr Format
• Hour
• Minutes
• Year
• Month
• Date
• Temperature Fahrenheit | Celsius
• Pressure units: INHG or HPA
• Pressure number setting
Language: When Español or Francais is selected, the following
instructions and weekday will be presented in that language.
Weekday: Weekday sets automatically when Year, Month and Date
are set.
PRESSURE HISTORY GRAPH
• The station will automatically search for the atomic time signal at
UTC 7:00, 8:00, 9:00, 10:00, and 11:00.
• The Atomic Time Signal Icon will flash while searching, and be
solid when connected.
• Press the SEARCH button anytime, to manually search for the
atomic time signal.
• For information about WWVB visit: bit.ly/AtomicTime
• Read from left to right, your Pressure History Graph indicates
the rise and fall in air pressure over the past 24 hours.
•The graph will scroll continually. This cannot be turned o.
-24h -18h -12h -9h -6h -3h 0h
PRESSURE HISTORY
ADJUSTABLE BACKLIGHT
• Press and release the LIGHT button to adjust the White Backlight;
HI-LOW-OFF.
• When operating on batteries only, press the LIGHT button for a
10 second backlight.
The station will use changes in atmospheric pressure to predict
your weather conditions to come in the next 12 hours. Please allow
up to 10 days for correct calibration and accurate forecast icons.
WEATHER FORECAST ICONS
FORECAST
FORECAST
FORECAST
FORECAST
FORECAST
FORECAST
Time Zones
Note: Snowy icon shows when outdoor temperature is below 32°F
and the forecast calls for rain or thunderstorms.
Page 3
Page 4
Page | 2
WEATHER STATION WITH
FORECAST AND ATOMIC TIME
QUICK START GUIDE
MODEL: 308-1417BLV2
DC: 030520
For more product information visit: bit.ly/laxtech_support
POWER UP
1. Insert 2-AA batteries into your Outdoor Sensor.
2. Insert the 5 volt power cord into the outlet, then into your
station. Optional: Insert 3-AA batteries for backup.
3. Adjust time and date settings on the station.
4. Once the Outdoor Sensor is reading to your station, place it
outside in a shaded location.
Watch sensor mounting video: bit.ly/TH_SensorMounting
Outdoor Sensor
TX141TH-Bv3
Weather Station
308-1417BLv2
WWVB ATOMIC TIME SIGNAL
SETTINGS
1. Hold the SET button to enter the Settings Menu.
2. Use the + or - button to adjust, and SET to confirm.
3. Press the SEARCH button anytime to exit the Settings Menu.
Settings Menu order:
• Language: (English, Español, Français)
• Beep ON | OFF
• Atomic ON | OFF
• DST ON | OFF (Daylight Saving Time)
• Time Zone
• 12Hr | 24Hr Format
• Hour
• Minutes
• Year
• Month
• Date
• Temperature Fahrenheit | Celsius
• Pressure units: INHG or HPA
• Pressure number setting
Language: When Español or Francais is selected, the following
instructions and weekday will be presented in that language.
Weekday: Weekday sets automatically when Year, Month and Date
are set.
PRESSURE HISTORY GRAPH
• The station will automatically search for the atomic time signal at
UTC 7:00, 8:00, 9:00, 10:00, and 11:00.
• The Atomic Time Signal Icon will flash while searching, and be
solid when connected.
• Press the SEARCH button anytime, to manually search for the
atomic time signal.
• For information about WWVB visit: bit.ly/AtomicTime
• Read from left to right, your Pressure History Graph indicates
the rise and fall in air pressure over the past 24 hours.
•The graph will scroll continually. This cannot be turned o.
-24h -18h -12h -9h -6h -3h 0h
PRESSURE HISTORY
ADJUSTABLE BACKLIGHT
• Press and release the LIGHT button to adjust the White Backlight;
HI-LOW-OFF.
• When operating on batteries only, press the LIGHT button for a
10 second backlight.
The station will use changes in atmospheric pressure to predict
your weather conditions to come in the next 12 hours. Please allow
up to 10 days for correct calibration and accurate forecast icons.
WEATHER FORECAST ICONS
FORECAST
FORECAST
FORECAST
FORECAST
FORECAST
FORECAST
Time Zones
Note: Snowy icon shows when outdoor temperature is below 32°F
and the forecast calls for rain or thunderstorms.
Page 3
Page 4
Page | 2
WEATHER STATION WITH
FORECAST AND ATOMIC TIME
QUICK START GUIDE
MODEL: 308-1417BLV2
DC: 030520
For more product information visit: bit.ly/laxtech_support
POWER UP
1. Insert 2-AA batteries into your Outdoor Sensor.
2. Insert the 5 volt power cord into the outlet, then into your
station. Optional: Insert 3-AA batteries for backup.
3. Adjust time and date settings on the station.
4. Once the Outdoor Sensor is reading to your station, place it
outside in a shaded location.
Watch sensor mounting video: bit.ly/TH_SensorMounting
Outdoor Sensor
TX141TH-Bv3
Weather Station
308-1417BLv2
WWVB ATOMIC TIME SIGNAL
SETTINGS
1. Hold the SET button to enter the Settings Menu.
2. Use the + or - button to adjust, and SET to confirm.
3. Press the SEARCH button anytime to exit the Settings Menu.
Settings Menu order:
• Language: (English, Español, Français)
• Beep ON | OFF
• Atomic ON | OFF
• DST ON | OFF (Daylight Saving Time)
• Time Zone
• 12Hr | 24Hr Format
• Hour
• Minutes
• Year
• Month
• Date
• Temperature Fahrenheit | Celsius
• Pressure units: INHG or HPA
• Pressure number setting
Language: When Español or Francais is selected, the following
instructions and weekday will be presented in that language.
Weekday: Weekday sets automatically when Year, Month and Date
are set.
PRESSURE HISTORY GRAPH
• The station will automatically search for the atomic time signal at
UTC 7:00, 8:00, 9:00, 10:00, and 11:00.
• The Atomic Time Signal Icon will flash while searching, and be
solid when connected.
• Press the SEARCH button anytime, to manually search for the
atomic time signal.
• For information about WWVB visit: bit.ly/AtomicTime
• Read from left to right, your Pressure History Graph indicates
the rise and fall in air pressure over the past 24 hours.
•The graph will scroll continually. This cannot be turned o.
-24h -18h -12h -9h -6h -3h 0h
PRESSURE HISTORY
ADJUSTABLE BACKLIGHT
• Press and release the LIGHT button to adjust the White Backlight;
HI-LOW-OFF.
• When operating on batteries only, press the LIGHT button for a
10 second backlight.
The station will use changes in atmospheric pressure to predict
your weather conditions to come in the next 12 hours. Please allow
up to 10 days for correct calibration and accurate forecast icons.
WEATHER FORECAST ICONS
FORECAST
FORECAST
FORECAST
FORECAST
FORECAST
FORECAST
Time Zones
Note: Snowy icon shows when outdoor temperature is below 32°F
and the forecast calls for rain or thunderstorms.
Page 6Page 5 Page 7
Page 8
OTHER BUTTON FUNCTIONS
SEARCH FOR OUTDOOR SENSOR
• If the sensor loses connection to the station for any reason, the
station will show dashes after 30 minutes.
• The station will automatically search for 3 minutes every hour to
try and reestablish the sensor connection.
• To manually search for your Outdoor Sensor, hold the SEARCH
button until the Reception Icon begins to flash.
• When the sensor is connected, the Reception Icon will be solid.
• If your thermometer is unable to reconnect on its own, a Restart
may be necessary.
LOW BATTERY INDICATOR
• When battery indicator shows next to outdoor temperature, replace
batteries in the outdoor sensor.
• When battery indicator shows next to the indoor humidity, replace
batteries in the station.
SPECIFICATIONS
Indoor:
Temperature Range: 32°F to 99°F (0°C to 37°C)
Humidity Range: 10% to 99% RH
Update Interval: About every 60 seconds
Relative Pressure Range: 23.62 to 32.48 inHg (800 to 1100 hPa)
Update Interval: About every 12 minutes
Outdoor:
Temperature Range: -40°F to 140°F (-40°C to 60°C)
Humidity Range: 10% to 99% RH
Transmission Range: Over 330 feet (100 meters) in open air RF 433MHz
Update Interval: About every 51 seconds
Power Requirements:
308-1417BLv2: 5.0 Volt 150mA adapter included (Primary)
AC6: GPU280500150WAOO Optional: 3 “AA” LR6 Batteries (not included)
The plug on the power adapter is intended to serve as the disconnect
device, the socket-outlet shall be installed near the equipment and shall
be easily accessible.
TX141TH-Bv3: 2 “AA” LR6 Batteries (not included)
Battery Life:
308-1417BLv2: Over 12 months with reputable batteries
TX141TH-Bv3: Over 24 months with reputable batteries
Dimensions:
308-1417BLv2:
6.88” L x 1.25” W x 6.42” H (17.5cm L x 3.2cm W x 16.3cm H)
TX141TH-Bv3: 1.57” L x 0.82” W x 5.11” H (3.98cm L x 2.08cm W x 12.98cm H)
ALERTS: Hold to enter Alert Settings. Press to move to next alert.
In Alert Settings, use the + or - button to arm/disarm an alert. When
alert is armed, use the + or - button to adjust the value.
TEMP: Press to view Indoor/Outdoor HI and LO readings, Heat
Index & Dew Point.
SEARCH: Press to search for WWVB Atomic Time Signal. Hold to
search for Outdoor Sensor.
RESTART
1. Be sure there are fresh batteries in the sensor and the station’s power
cord is securely installed.
2. Hold the ALERTS & LIGHT buttons for 5 seconds to restart the station.
WARRANTY INFO
La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product
relating to manufacturing defects in materials & workmanship.
La Crosse Technology, Ltd, 2830 S. 26th St., La Crosse, WI 54601
For Full Warranty Details, Visit: www.lacrossetechnology.com/support
CARE + MAINTENANCE
•
Do not mix old and new batteries.
•
Do not mix Alkaline, Lithium, standard, or rechargeable batteries.
•
Always purchase the correct size and grade of battery most suitable for intended use.
•
Clean the battery contacts and also those of the device prior to battery installation.
•
Ensure the batteries have with correct polarity (+ / -).
•
Remove batteries from equipment that will not to be used for an extended period.
•
Promptly remove expired batteries.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
CAUTION!
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or duplicated or processed
using electronic, mechanical or chemical process without the written permission
of the publisher.
This booklet may contain errors or misprints. The information it contains is regularly checked and corrections
are included in subsequent editions. We disclaim any responsibility for any technical error or printing error, or
their consequences. All trademarks and patents are recognized.
WARNING: This product can expose you to chemicals including styrene, which is known to the State of
California to cause cancer. For more information go to: www.P65Warnings.ca.gov
• The Sensor Weather Shield is designed to protect your
outdoor sensor from rain and snow.
• This shield will oer limited protection from the sun’s
heat.
• Optional purchase at: bit.ly/925-1418
*Sold separately
SENSOR WEATHER SHIELD*
If you require additional support, get in touch with our friendly customer
support team based out of La Crosse, WI.
Phone: 1-608-782-1610
Online: bit.ly/contact_techsupport
Our knowledgeable customer support team is available:
Monday-Friday, 8am-6pm CST.
JOIN THE CONVERSATION
Ask questions, watch detailed setup videos, and provide feedback on our
social media outlets!
WE’RE HERE TO HELP!
Page 6Page 5 Page 7
Page 8
OTHER BUTTON FUNCTIONS
SEARCH FOR OUTDOOR SENSOR
• If the sensor loses connection to the station for any reason, the
station will show dashes after 30 minutes.
• The station will automatically search for 3 minutes every hour to
try and reestablish the sensor connection.
• To manually search for your Outdoor Sensor, hold the SEARCH
button until the Reception Icon begins to flash.
• When the sensor is connected, the Reception Icon will be solid.
• If your thermometer is unable to reconnect on its own, a Restart
may be necessary.
LOW BATTERY INDICATOR
• When battery indicator shows next to outdoor temperature, replace
batteries in the outdoor sensor.
• When battery indicator shows next to the indoor humidity, replace
batteries in the station.
SPECIFICATIONS
Indoor:
Temperature Range: 32°F to 99°F (0°C to 37°C)
Humidity Range: 10% to 99% RH
Update Interval: About every 60 seconds
Relative Pressure Range: 23.62 to 32.48 inHg (800 to 1100 hPa)
Update Interval: About every 12 minutes
Outdoor:
Temperature Range: -40°F to 140°F (-40°C to 60°C)
Humidity Range: 10% to 99% RH
Transmission Range: Over 330 feet (100 meters) in open air RF 433MHz
Update Interval: About every 51 seconds
Power Requirements:
308-1417BLv2: 5.0 Volt 150mA adapter included (Primary)
AC6: GPU280500150WAOO Optional: 3 “AA” LR6 Batteries (not included)
The plug on the power adapter is intended to serve as the disconnect
device, the socket-outlet shall be installed near the equipment and shall
be easily accessible.
TX141TH-Bv3: 2 “AA” LR6 Batteries (not included)
Battery Life:
308-1417BLv2: Over 12 months with reputable batteries
TX141TH-Bv3: Over 24 months with reputable batteries
Dimensions:
308-1417BLv2:
6.88” L x 1.25” W x 6.42” H (17.5cm L x 3.2cm W x 16.3cm H)
TX141TH-Bv3: 1.57” L x 0.82” W x 5.11” H (3.98cm L x 2.08cm W x 12.98cm H)
ALERTS: Hold to enter Alert Settings. Press to move to next alert.
In Alert Settings, use the + or - button to arm/disarm an alert. When
alert is armed, use the + or - button to adjust the value.
TEMP: Press to view Indoor/Outdoor HI and LO readings, Heat
Index & Dew Point.
SEARCH: Press to search for WWVB Atomic Time Signal. Hold to
search for Outdoor Sensor.
RESTART
1. Be sure there are fresh batteries in the sensor and the station’s power
cord is securely installed.
2. Hold the ALERTS & LIGHT buttons for 5 seconds to restart the station.
WARRANTY INFO
La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product
relating to manufacturing defects in materials & workmanship.
La Crosse Technology, Ltd, 2830 S. 26th St., La Crosse, WI 54601
For Full Warranty Details, Visit: www.lacrossetechnology.com/support
CARE + MAINTENANCE
•
Do not mix old and new batteries.
•
Do not mix Alkaline, Lithium, standard, or rechargeable batteries.
•
Always purchase the correct size and grade of battery most suitable for intended use.
•
Clean the battery contacts and also those of the device prior to battery installation.
•
Ensure the batteries have with correct polarity (+ / -).
•
Remove batteries from equipment that will not to be used for an extended period.
•
Promptly remove expired batteries.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
CAUTION!
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or duplicated or processed
using electronic, mechanical or chemical process without the written permission
of the publisher.
This booklet may contain errors or misprints. The information it contains is regularly checked and corrections
are included in subsequent editions. We disclaim any responsibility for any technical error or printing error, or
their consequences. All trademarks and patents are recognized.
WARNING: This product can expose you to chemicals including styrene, which is known to the State of
California to cause cancer. For more information go to: www.P65Warnings.ca.gov
• The Sensor Weather Shield is designed to protect your
outdoor sensor from rain and snow.
• This shield will oer limited protection from the sun’s
heat.
• Optional purchase at: bit.ly/925-1418
*Sold separately
SENSOR WEATHER SHIELD*
If you require additional support, get in touch with our friendly customer
support team based out of La Crosse, WI.
Phone: 1-608-782-1610
Online: bit.ly/contact_techsupport
Our knowledgeable customer support team is available:
Monday-Friday, 8am-6pm CST.
JOIN THE CONVERSATION
Ask questions, watch detailed setup videos, and provide feedback on our
social media outlets!
WE’RE HERE TO HELP!
Page 6Page 5 Page 7
Page 8
OTHER BUTTON FUNCTIONS
SEARCH FOR OUTDOOR SENSOR
• If the sensor loses connection to the station for any reason, the
station will show dashes after 30 minutes.
• The station will automatically search for 3 minutes every hour to
try and reestablish the sensor connection.
• To manually search for your Outdoor Sensor, hold the SEARCH
button until the Reception Icon begins to flash.
• When the sensor is connected, the Reception Icon will be solid.
• If your thermometer is unable to reconnect on its own, a Restart
may be necessary.
LOW BATTERY INDICATOR
• When battery indicator shows next to outdoor temperature, replace
batteries in the outdoor sensor.
• When battery indicator shows next to the indoor humidity, replace
batteries in the station.
SPECIFICATIONS
Indoor:
Temperature Range: 32°F to 99°F (0°C to 37°C)
Humidity Range: 10% to 99% RH
Update Interval: About every 60 seconds
Relative Pressure Range: 23.62 to 32.48 inHg (800 to 1100 hPa)
Update Interval: About every 12 minutes
Outdoor:
Temperature Range: -40°F to 140°F (-40°C to 60°C)
Humidity Range: 10% to 99% RH
Transmission Range: Over 330 feet (100 meters) in open air RF 433MHz
Update Interval: About every 51 seconds
Power Requirements:
308-1417BLv2: 5.0 Volt 150mA adapter included (Primary)
AC6: GPU280500150WAOO Optional: 3 “AA” LR6 Batteries (not included)
The plug on the power adapter is intended to serve as the disconnect
device, the socket-outlet shall be installed near the equipment and shall
be easily accessible.
TX141TH-Bv3: 2 “AA” LR6 Batteries (not included)
Battery Life:
308-1417BLv2: Over 12 months with reputable batteries
TX141TH-Bv3: Over 24 months with reputable batteries
Dimensions:
308-1417BLv2:
6.88” L x 1.25” W x 6.42” H (17.5cm L x 3.2cm W x 16.3cm H)
TX141TH-Bv3: 1.57” L x 0.82” W x 5.11” H (3.98cm L x 2.08cm W x 12.98cm H)
ALERTS: Hold to enter Alert Settings. Press to move to next alert.
In Alert Settings, use the + or - button to arm/disarm an alert. When
alert is armed, use the + or - button to adjust the value.
TEMP: Press to view Indoor/Outdoor HI and LO readings, Heat
Index & Dew Point.
SEARCH: Press to search for WWVB Atomic Time Signal. Hold to
search for Outdoor Sensor.
RESTART
1. Be sure there are fresh batteries in the sensor and the station’s power
cord is securely installed.
2. Hold the ALERTS & LIGHT buttons for 5 seconds to restart the station.
WARRANTY INFO
La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product
relating to manufacturing defects in materials & workmanship.
La Crosse Technology, Ltd, 2830 S. 26th St., La Crosse, WI 54601
For Full Warranty Details, Visit: www.lacrossetechnology.com/support
CARE + MAINTENANCE
•
Do not mix old and new batteries.
•
Do not mix Alkaline, Lithium, standard, or rechargeable batteries.
•
Always purchase the correct size and grade of battery most suitable for intended use.
•
Clean the battery contacts and also those of the device prior to battery installation.
•
Ensure the batteries have with correct polarity (+ / -).
•
Remove batteries from equipment that will not to be used for an extended period.
•
Promptly remove expired batteries.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
CAUTION!
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or duplicated or processed
using electronic, mechanical or chemical process without the written permission
of the publisher.
This booklet may contain errors or misprints. The information it contains is regularly checked and corrections
are included in subsequent editions. We disclaim any responsibility for any technical error or printing error, or
their consequences. All trademarks and patents are recognized.
WARNING: This product can expose you to chemicals including styrene, which is known to the State of
California to cause cancer. For more information go to: www.P65Warnings.ca.gov
• The Sensor Weather Shield is designed to protect your
outdoor sensor from rain and snow.
• This shield will oer limited protection from the sun’s
heat.
• Optional purchase at: bit.ly/925-1418
*Sold separately
SENSOR WEATHER SHIELD*
If you require additional support, get in touch with our friendly customer
support team based out of La Crosse, WI.
Phone: 1-608-782-1610
Online: bit.ly/contact_techsupport
Our knowledgeable customer support team is available:
Monday-Friday, 8am-6pm CST.
JOIN THE CONVERSATION
Ask questions, watch detailed setup videos, and provide feedback on our
social media outlets!
WE’RE HERE TO HELP!
Page 6Page 5 Page 7
Page 8
OTHER BUTTON FUNCTIONS
SEARCH FOR OUTDOOR SENSOR
• If the sensor loses connection to the station for any reason, the
station will show dashes after 30 minutes.
• The station will automatically search for 3 minutes every hour to
try and reestablish the sensor connection.
• To manually search for your Outdoor Sensor, hold the SEARCH
button until the Reception Icon begins to flash.
• When the sensor is connected, the Reception Icon will be solid.
• If your thermometer is unable to reconnect on its own, a Restart
may be necessary.
LOW BATTERY INDICATOR
• When battery indicator shows next to outdoor temperature, replace
batteries in the outdoor sensor.
• When battery indicator shows next to the indoor humidity, replace
batteries in the station.
SPECIFICATIONS
Indoor:
Temperature Range: 32°F to 99°F (0°C to 37°C)
Humidity Range: 10% to 99% RH
Update Interval: About every 60 seconds
Relative Pressure Range: 23.62 to 32.48 inHg (800 to 1100 hPa)
Update Interval: About every 12 minutes
Outdoor:
Temperature Range: -40°F to 140°F (-40°C to 60°C)
Humidity Range: 10% to 99% RH
Transmission Range: Over 330 feet (100 meters) in open air RF 433MHz
Update Interval: About every 51 seconds
Power Requirements:
308-1417BLv2: 5.0 Volt 150mA adapter included (Primary)
AC6: GPU280500150WAOO Optional: 3 “AA” LR6 Batteries (not included)
The plug on the power adapter is intended to serve as the disconnect
device, the socket-outlet shall be installed near the equipment and shall
be easily accessible.
TX141TH-Bv3: 2 “AA” LR6 Batteries (not included)
Battery Life:
308-1417BLv2: Over 12 months with reputable batteries
TX141TH-Bv3: Over 24 months with reputable batteries
Dimensions:
308-1417BLv2:
6.88” L x 1.25” W x 6.42” H (17.5cm L x 3.2cm W x 16.3cm H)
TX141TH-Bv3: 1.57” L x 0.82” W x 5.11” H (3.98cm L x 2.08cm W x 12.98cm H)
ALERTS: Hold to enter Alert Settings. Press to move to next alert.
In Alert Settings, use the + or - button to arm/disarm an alert. When
alert is armed, use the + or - button to adjust the value.
TEMP: Press to view Indoor/Outdoor HI and LO readings, Heat
Index & Dew Point.
SEARCH: Press to search for WWVB Atomic Time Signal. Hold to
search for Outdoor Sensor.
RESTART
1. Be sure there are fresh batteries in the sensor and the station’s power
cord is securely installed.
2. Hold the ALERTS & LIGHT buttons for 5 seconds to restart the station.
WARRANTY INFO
La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product
relating to manufacturing defects in materials & workmanship.
La Crosse Technology, Ltd, 2830 S. 26th St., La Crosse, WI 54601
For Full Warranty Details, Visit: www.lacrossetechnology.com/support
CARE + MAINTENANCE
•
Do not mix old and new batteries.
•
Do not mix Alkaline, Lithium, standard, or rechargeable batteries.
•
Always purchase the correct size and grade of battery most suitable for intended use.
•
Clean the battery contacts and also those of the device prior to battery installation.
•
Ensure the batteries have with correct polarity (+ / -).
•
Remove batteries from equipment that will not to be used for an extended period.
•
Promptly remove expired batteries.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
CAUTION!
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part, or duplicated or processed
using electronic, mechanical or chemical process without the written permission
of the publisher.
This booklet may contain errors or misprints. The information it contains is regularly checked and corrections
are included in subsequent editions. We disclaim any responsibility for any technical error or printing error, or
their consequences. All trademarks and patents are recognized.
WARNING: This product can expose you to chemicals including styrene, which is known to the State of
California to cause cancer. For more information go to: www.P65Warnings.ca.gov
• The Sensor Weather Shield is designed to protect your
outdoor sensor from rain and snow.
• This shield will oer limited protection from the sun’s
heat.
• Optional purchase at: bit.ly/925-1418
*Sold separately
SENSOR WEATHER SHIELD*
If you require additional support, get in touch with our friendly customer
support team based out of La Crosse, WI.
Phone: 1-608-782-1610
Online: bit.ly/contact_techsupport
Our knowledgeable customer support team is available:
Monday-Friday, 8am-6pm CST.
JOIN THE CONVERSATION
Ask questions, watch detailed setup videos, and provide feedback on our
social media outlets!
WE’RE HERE TO HELP!
