DS-K1T342 Series Face Recognion Terminal
User Manual
Legal Informaon
©2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DS-K1T342 Series Face Recognion Terminal User Manual
i
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example, for
device with facial recognion features, biometrics data is stored in your device with encrypon
method; for ngerprint device, only ngerprint template will be saved, which is impossible to
reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data protecon laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the eecveness of your
security controls.
DS-K1T342 Series Face Recognion Terminal User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
DS-K1T342 Series Face Recognion Terminal User Manual
iii
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K1T342 Series Face Recognion Terminal User Manual
iv
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two condions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitaon est autorisée aux deux condions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est suscepble d'en compromere le fonconnement.
This equipment complies with FCC/IC RSS-102 radiaon exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum
distance 20 cm between the radiator & your body.
ce matériel est conforme aux limites de dose d'exposion aux rayonnements, FCC / CNR-102
énoncée dans un autre environnement.cee eqipment devrait être installé et exploité avec
distance minimale de 20 entre le radiateur et votre corps.
DS-K1T342 Series Face Recognion Terminal User Manual
v
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●
In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
●
If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
●
The socket-outlet shall be installed near the equipment and shall be easily accessible.
●
1. Do not ingest baery. Chemical burn hazard!
2. This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
3. Keep new and used baeries away from children.
4. If the baery compartment does not close securely, stop using the product and keep it away
from children.
5. If you think baeries might have been swallowed or placed inside any part of the body, seek
immediate medical aenon.
6. CAUTION: Risk of explosion if the baery is replaced by an incorrect type.
7. Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in the case of some lithium baery types).
8. Do not dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
9. Do not leave the baery in an extremely high temperature surrounding environment, which
may result in an explosion or the leakage of ammable liquid or gas.
10. Do not subject the baery to extremely low air pressure, which may result in an explosion or
the leakage of ammable liquid or gas.
11. Dispose of used baeries according to the instrucons.
DS-K1T342 Series Face Recognion Terminal User Manual
vi
Cauons:
●
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●
Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●
The device cover for indoor use shall be kept from rain and moisture.
●
Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●
Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●
Biometric recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use mulple authencaon modes.
●
The serial port of the equipment is used for debugging only.
●
Install the equipment according to the instrucons in this manual. To prevent injury, this
equipment must be securely aached to the oor/wall in accordance with the installaon
instrucons.
●
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●
This bracket is intended for use only with equipped devices. Use with other equipment may
result in instability causing injury.
●
This equipment is for use only with equipped bracket. Use with other (carts, stands, or carriers)
may result in instability causing injury.
DS-K1T342 Series Face Recognion Terminal User Manual
vii
Available Models
Product Name Model Wireless
Face Recognion Terminal DS-K1T342MX 13.56 MHz Card Presenng
Frequency
DS-K1T342MWX 13.56 MHz Card Presenng
Frequency, Wi-Fi (2.4 GHz)
DS-K1T342MFX 13.56 MHz Card Presenng
Frequency
DS-K1T342MFWX 13.56 MHz Card Presenng
Frequency, Wi-Fi (2.4 GHz)
DS-K1T342EX 125 KHz Card Presenng
Frequency
DS-K1T342EWX 125 KHz Card Presenng
Frequency, Wi-Fi (2.4 GHz)
DS-K1T342EFWX 125 KHz Card Presenng
Frequency, Wi-Fi (2.4 GHz)
DS-K1T342DX 13.56 MHz Card Presenng
Frequency
DS-K1T342DWX 13.56 MHz Card Presenng
Frequency, Wi-Fi (2.4 GHz)
Use only power supplies listed in the user instrucons:
Model Manufacturer Standard
ADS-12FG-12N 12012EPG Shenzhen Honor Electronic Co.,
Ltd
PG
DS-K1T342 Series Face Recognion Terminal User Manual
viii
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Overview ................................................................................................................................ 1
1.2 Features ................................................................................................................................. 1
Chapter 2 Appearance ................................................................................................................ 2
Chapter 3 Installaon ................................................................................................................. 5
3.1 Installaon Environment ........................................................................................................ 5
3.2 Install with Gang Box ............................................................................................................. 5
3.3 Surface Mounng .................................................................................................................. 8
3.4 Mount With Bracket ............................................................................................................. 14
3.4.1 Preparaon before Mounng with Bracket ................................................................ 14
3.4.2 Mount Bracket ............................................................................................................ 15
3.5 Mount With Cylinder Bracket .............................................................................................. 16
3.5.1 Preparaon before Mounng with Bracket ................................................................ 16
3.5.2 Cylinder Bracket Mounng ......................................................................................... 18
Chapter 4 Wiring ...................................................................................................................... 20
4.1 Terminal Descripon ............................................................................................................ 20
4.2 Wire Normal Device ............................................................................................................. 21
4.3 Wire Secure Door Control Unit ............................................................................................ 22
4.4 Wire Fire Module ................................................................................................................. 23
4.4.1 Wiring Diagram of Door Open When Powering O .................................................... 23
4.4.2 Wiring Diagram of Door Locked When Powering O .................................................. 25
Chapter 5 Acvaon ................................................................................................................. 27
5.1 Acvate via Device ............................................................................................................... 27
5.2 Acvate via Web Browser .................................................................................................... 29
5.3 Acvate via SADP ................................................................................................................. 30
5.4 Acvate Device via iVMS-4200 Client Soware ................................................................... 31
DS-K1T342 Series Face Recognion Terminal User Manual
ix
Chapter 6 Quick Operaon ....................................................................................................... 33
6.1 Select Language ................................................................................................................... 33
6.2 Set Applicaon Mode .......................................................................................................... 35
6.3 Set Network Parameters ...................................................................................................... 36
6.4 Access to Plaorm ............................................................................................................... 38
6.5 Link to Mobile Client ............................................................................................................ 40
6.6 Privacy Sengs .................................................................................................................... 41
6.7 Set Administrator ................................................................................................................. 43
Chapter 7 Basic Operaon ........................................................................................................ 46
7.1 Login .................................................................................................................................... 46
7.1.1 Login by Administrator ................................................................................................ 46
7.1.2 Login by Acvaon Password ...................................................................................... 49
7.2 Communicaon Sengs ...................................................................................................... 50
7.2.1 Set Wired Network Parameters .................................................................................. 51
7.2.2 Set Wi-Fi Parameters ................................................................................................... 53
7.2.3 Set RS-485 Parameters ................................................................................................ 55
7.2.4 Set Wiegand Parameters ............................................................................................. 57
7.2.5 Set ISUP Parameters .................................................................................................... 59
7.2.6 Plaorm Access ........................................................................................................... 61
7.3 User Management ............................................................................................................... 62
7.3.1 Add Administrator ....................................................................................................... 62
7.3.2 Add Face Picture ......................................................................................................... 64
7.3.3 Add Fingerprint ........................................................................................................... 66
7.3.4 Add Card ..................................................................................................................... 67
7.3.5 View PIN code ............................................................................................................. 68
7.3.6 Set Authencaon Mode ............................................................................................ 69
7.3.7 Search and Edit User ................................................................................................... 69
7.4 Data Management ............................................................................................................... 70
DS-K1T342 Series Face Recognion Terminal User Manual
x
7.4.1 Delete Data ................................................................................................................. 70
7.4.2 Import Data ................................................................................................................. 70
7.4.3 Export Data ................................................................................................................. 71
7.5 Identy Authencaon ........................................................................................................ 71
7.5.1 Authencate via Single Credenal .............................................................................. 71
7.5.2 Authencate via Mulple Credenal .......................................................................... 72
7.6 Basic Sengs ....................................................................................................................... 72
7.7 Set Biometric Parameters .................................................................................................... 74
7.8 Set Access Control Parameters ............................................................................................ 77
7.9 Time and Aendance Status Sengs .................................................................................. 79
7.9.1 Disable Aendance Mode via Device ......................................................................... 80
7.9.2 Set Manual Aendance via Device ............................................................................. 81
7.9.3 Set Auto Aendance via Device .................................................................................. 83
7.9.4 Set Manual and Auto Aendance via Device .............................................................. 85
7.10 Set Preference .................................................................................................................... 87
7.11 System Maintenance .......................................................................................................... 89
Chapter 8 Congure the Device via the Mobile Browser ........................................................... 92
8.1 Login .................................................................................................................................... 92
8.2 Search Event ........................................................................................................................ 92
8.3 User Management ............................................................................................................... 92
8.4 Conguraon ....................................................................................................................... 94
8.4.1 View Device Informaon ............................................................................................. 94
8.4.2 Time Sengs ............................................................................................................... 94
8.4.3 View Open Source Soware License ........................................................................... 95
8.4.4 Network Sengs ......................................................................................................... 95
8.4.5 General Sengs .......................................................................................................... 98
8.4.6 Face Parameters Sengs .......................................................................................... 104
8.4.7 Video Intercom Sengs ............................................................................................ 108
DS-K1T342 Series Face Recognion Terminal User Manual
xi
8.4.8 Access Control Sengs ............................................................................................. 110
Chapter 9 Operaon via Web Browser .................................................................................... 116
9.1 Login .................................................................................................................................. 116
9.2 Live View ............................................................................................................................ 116
9.3 Person Management .......................................................................................................... 118
9.4 Search Event ...................................................................................................................... 119
9.5 Conguraon ..................................................................................................................... 119
9.5.1 Set Local Parameters ................................................................................................. 119
9.5.2 View Device Informaon ........................................................................................... 120
9.5.3 Set Time .................................................................................................................... 120
9.5.4 Set DST ...................................................................................................................... 121
9.5.5 View Open Source Soware License ......................................................................... 122
9.5.6 Upgrade and Maintenance ....................................................................................... 122
9.5.7 Log Query .................................................................................................................. 123
9.5.8 Security Mode Sengs ............................................................................................. 123
9.5.9 Cercate Management ........................................................................................... 124
9.5.10 Change Administrator's Password ........................................................................... 125
9.5.11 View Device Arming/Disarming Informaon .......................................................... 126
9.5.12 Network Sengs ..................................................................................................... 126
9.5.13 Set Video and Audio Parameters ............................................................................ 129
9.5.14 Customize Audio Content ....................................................................................... 131
9.5.15 Set Image Parameters ............................................................................................. 132
9.5.16 Set Supplement Light Brightness ............................................................................ 133
9.5.17 Time and Aendance Sengs ................................................................................ 133
9.5.18 General Sengs ...................................................................................................... 136
9.5.19 Video Intercom Sengs .......................................................................................... 142
9.5.20 Access Control Sengs ........................................................................................... 144
9.5.21 Set Biometric Parameters ....................................................................................... 147
DS-K1T342 Series Face Recognion Terminal User Manual
xii
9.5.22 Set Noce Publicaon ............................................................................................. 151
Chapter 10 Client Soware Conguraon ............................................................................... 154
10.1 Conguraon Flow of Client Soware ............................................................................. 154
10.2 Device Management ........................................................................................................ 154
10.2.1 Add Device .............................................................................................................. 155
10.2.2 Reset Device Password ........................................................................................... 157
10.2.3 Manage Added Devices .......................................................................................... 158
10.3 Group Management ......................................................................................................... 159
10.3.1 Add Group ............................................................................................................... 159
10.3.2 Import Resources to Group ..................................................................................... 159
10.4 Person Management ........................................................................................................ 160
10.4.1 Add Organizaon .................................................................................................... 160
10.4.2 Import and Export Person Idenfy Informaon ...................................................... 160
10.4.3 Get Person Informaon from Access Control Device .............................................. 163
10.4.4 Issue Cards to Persons in Batch ............................................................................... 163
10.4.5 Report Card Loss ..................................................................................................... 164
10.4.6 Set Card Issuing Parameters .................................................................................... 164
10.5 Congure Schedule and Template ................................................................................... 165
10.5.1 Add Holiday ............................................................................................................. 166
10.5.2 Add Template .......................................................................................................... 166
10.6 Set Access Group to Assign Access Authorizaon to Persons .......................................... 168
10.7 Congure Advanced Funcons ........................................................................................ 170
10.7.1 Congure Device Parameters .................................................................................. 170
10.7.2 Congure Device Parameters .................................................................................. 176
10.8 Door Control .................................................................................................................... 179
10.8.1 Control Door Status ................................................................................................. 179
10.8.2 Check Real-Time Access Records ............................................................................ 180
Appendix A. Tips for Scanning Fingerprint ............................................................................... 182
DS-K1T342 Series Face Recognion Terminal User Manual
xiii
Appendix B. Tips When Collecng/Comparing Face Picture .................................................... 184
Appendix C. Tips for Installaon Environment ........................................................................ 186
Appendix D. Dimension .......................................................................................................... 187
Appendix E. Communicaon Matrix and Device Command ..................................................... 188
DS-K1T342 Series Face Recognion Terminal User Manual
xiv
Chapter 1 Overview
1.1 Overview
Face recognion terminal is a kind of access control device for face recognion, which is mainly
applied in security access control systems, such as logisc centers, airports, university campuses,
alarm centrals, dwellings, etc.
1.2 Features
●
4.3-inch LCD touch screen, 272 × 480 screen resoluon, real-me detecon and display of the
maximum face frame.
●
2 MP wide-angle dual-lens
●
Supports mulple authencaon modes: face, ngerprint, card, PIN code and mulple
combinaon authencaon.
●
Supports access control period control (plan template) and authorize door opening on demand.
●
Supports network operaon and issuing personnel authority informaon via the plaorm.
●
Supports data network upload funcon, which can upload device comparison results and linkage
capture pictures to the plaorm in real me.
●
When the device is oine, events generated when the device is connected to the plaorm will
be uploaded again.
●
Supports NTP, manual, and automac me calibraon.
●
Supports video intercom between devices.
●
Supports remote video preview and output video code streams via the RTSP protocol.
●
Support watchdog guard mechanism, tamper design to ensure the device work properly.
●
Supports mask detecon modes including reminder of wearing mode and must wear mask
mode.
●
Supports IP65.
DS-K1T342 Series Face Recognion Terminal User Manual
1
Chapter 2 Appearance
Figure 2-1 With Fingerprint Module
Table 2-1 Appearance Descripon
No. Name
1 USB
Interface
2 Loudspeaker
3 IR Light
4 Camera
5 MIC
6 Camera
7 Touch Screen
8 Fingerprint Recognion Area/Card Presenng Area
9 Debugging Port (for debugging only)
DS-K1T342 Series Face Recognion Terminal User Manual
2
No. Name
10 Wiring Terminal
11 Network
Interface
12 Tamper
Figure 2-2 Without Fingerprint Module
Table 2-2 Appearance Descripon
No. Name
1 USB
Interface
2 Loudspeaker
3 IR Light
4 Camera
5 MIC
6 Camera
DS-K1T342 Series Face Recognion Terminal User Manual
3
No. Name
7 Touch Screen
8 Card Presenng Area
9 Debugging Port (for debugging only)
10 Wiring Terminal
11 Network
Interface
12 Tamper
DS-K1T342 Series Face Recognion Terminal User Manual
4
Chapter 3 Installaon
3.1 Installaon Environment
●
Avoid backlight, direct sunlight, and indirect sunlight.
●
For beer recognion, there should be light source in or near the installaon environment.
●
The minimum bearing weight of the wall or other places should be 3 mes heavier than the
device weight.
●
There shall be no strong reecve objects (such as glass doors/walls, stainless steel objects,
acrylic and other glossy plascs, lacquer, ceramic les, etc.) within 1 m of the eld of view of the
device.
●
Avoid device reecon.
●
Face recognion distance shall be greater than 30 cm.
●
Keep the camera clean.
Note
For details about installaon environment, see Tips for Installaon Environment.
3.2 Install with Gang Box
Steps
1.
Make sure the gang box is installed on the wall.
Note
You should purchase the gang box separately.
DS-K1T342 Series Face Recognion Terminal User Manual
5
Figure 3-1 Install Gang Box
2.
Secure the mounng plate on the gang box with two supplied screws (SC-KA4X22).
Figure 3-2 Install Mounng Plate
3.
Route the cable through the cable hole, wire the cables and insert the cables in the gang box.
DS-K1T342 Series Face Recognion Terminal User Manual
6
Figure 3-3 Apply Silicone Sealant
4.
Align the device with the mounng plate, and secure the device on the mounng plate with 1
supplied screw (SC-KM3X6-T10-SUSS).
DS-K1T342 Series Face Recognion Terminal User Manual
7
Figure 3-4 Secure Device
3.3 Surface Mounng
Steps
1.
According to the datum line on the mounng template, sck the mounng template on the wall
or other surfaces, 1.45 meters higher than the ground.
DS-K1T342 Series Face Recognion Terminal User Manual
8
Figure 3-5 Mounng Template
2.
Drill holes on the wall or other surface according to the Hole 1 on the mounng template.
3.
Insert the plasc sleeve of expansion bolts into the holes.
4.
Align the holes to the mounng plate and secure the mounng plate on the wall with the 2
supplied screws (KA4×22-SUS).
DS-K1T342 Series Face Recognion Terminal User Manual
9
Figure 3-6 Install Mounng Plate
5.
Route the cable through the cable hole of the mounng plate, and connect to corresponding
peripherals cables.
Note
If the device is installed outdoor, you should apply silicone sealant to the wiring exit to avoid
water from entering.
DS-K1T342 Series Face Recognion Terminal User Manual
10
Figure 3-7 Apply Silicone Sealant
6.
Align the device with the mounng plate and hang the device on the mounng plate.
DS-K1T342 Series Face Recognion Terminal User Manual
11
Figure 3-8 Hang Device
7.
Use 1 supplied screw (KM3×6-SUS) to secure the device and the mounng plate.
DS-K1T342 Series Face Recognion Terminal User Manual
12
Figure 3-9 Secure Device
Note
●
The recommended installaon height is 1.45 meters, you can set the installon height
according your needs.
●
It's recommended to use the supplied mounng plate.
8.
Aer installaon, for the proper use of the device (outdoor use), sck the protecon lm (parts
of models supplied) on the screen.
DS-K1T342 Series Face Recognion Terminal User Manual
13
3.4 Mount With Bracket
3.4.1 Preparaon before Mounng with Bracket
Steps
1.
Drill holes on the turnsle's surface according to the gure displayed below. And install water-
proof nut.
Note
Solder aer pressing rivets to avoid water from entering.
Figure 3-10 Drill Holes on Turnsle
2.
If the installaon angle needs to be 180° perpendicular to the body of the turnsle, the
following operaons are required.
1) Take o the 3 screws shown in the following gure.
Figure 3-11 Take o Screws
2) Rotate the xed part by 180°, and install the 3 screws back.
DS-K1T342 Series Face Recognion Terminal User Manual
14
Figure 3-12 Rotate Fixed Part
3.4.2 Mount Bracket
Steps
1.
Install the base on the turnsle.
1) Align the hole on the turnsle and place the base on the turnsle.
2) Rotate the base to the acquired place and make sure the device will face a correct direcon.
3) Secure the base with wrench.
Figure 3-13 Install Base
Note
Install a piece of silicone pad on the front and back of the turnsle.
2.
Install the mounng template on the bracket with 4 supplied screw (SC-K1M4×6-SUS).
DS-K1T342 Series Face Recognion Terminal User Manual
15
Figure 3-14 Secure Mounng Template
3.
Route the cables through the cable hole on the turnsle and x the device into the mounng
plate with 1 SC-KM3×6-T10-SUS screw.
Figure 3-15 Fix the Device
4.
Aer installaon, for the proper use of the device (outdoor use), sck the protecon lm (parts
of models supplied) on the screen.
3.5 Mount With Cylinder Bracket
3.5.1 Preparaon before Mounng with Bracket
Make sure you have drilled holes on the turnsle. If not, follow the steps below to drill holes.
Steps
1.
Use 4 screws (M3 or M4), secured by ange nuts, to install the reinforcing board on the inner
surface of the turnsle.
Note
The distance between the turnsle and the edge should be no longer than 10 mm.
2.
Drill holes on the turnsle's inner surface according to the gure displayed below. And install
water-proof nut.
DS-K1T342 Series Face Recognion Terminal User Manual
16
Note
Solder aer pressing rivets to avoid water from entering.
Figure 3-16 Drill Holes on Turnsle
3.
Solder the other four holes, polish the surface, and implement wire drawing.
4.
Solder circular tubes on the turnsle’s inner surface to avoid water from entering.
DS-K1T342 Series Face Recognion Terminal User Manual
17
Figure 3-17 Solder Tubes
3.5.2 Cylinder Bracket Mounng
Steps
1.
Install the base on the turnsle.
1) Align the hole on the turnsle and place the base on the turnsle.
2) Rotate the base to the acquired place and make sure the device will face a correct direcon.
3) Secure the base with 4 SC-OM6×12-H-SUS screws.
Figure 3-18 Install Base
2.
Fix the mounng plate into the bracket by 4 SC-K1M4×6-SUS screws.
DS-K1T342 Series Face Recognion Terminal User Manual
18
Figure 3-19 Fix Mounng Plate
3.
Route the cables through the cable hole on the turnsle.
4.
Fix the face recognion terminal into the mounng plate with 1 SC-KM3×6-H2-SUS screw.
Figure 3-20 Fix Mounng Plate
5.
Aer installaon, for the proper use of the device (outdoor use), sck the protecon lm (parts
of models supplied) on the screen.
DS-K1T342 Series Face Recognion Terminal User Manual
19
Chapter 4 Wiring
You can connect the RS-485 terminal with the RS-485 card reader, connect the NC/NO and COM
terminal with the door lock, connect the SEN and GND terminal with the door contact, the
BTN/GND terminal with the exit buon, and connect the Wiegand terminal with the access
controller.
If connect the WIEGAND terminal with the access controller, the face recognion terminal can
transmit the authencaon informaon to the access controller and the access controller can
judge whether to open the door or not.
Note
●
If cable size is 18 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 20 m.
●
If the cable size is 15 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 30 m.
●
If the cable size is 12 AWG, you should use a 12 V power supply. And the distance between the
power supply and the device should be no more than 40 m.
●
The external card reader, door lock, exit buon, and door magnec need individual power
supply.
4.1 Terminal Descripon
The terminals contains power input, RS-485, Wiegand output, and door lock.
The descripons of the terminals are as follows:
Table 4-1 Terminal Descripons
Group No. Funcon Color Name Descripon
Group A A1 Power Input Red +12 V 12 VDC Power
Supply
A2 Black GND Ground
Group B B1 RS-485 Yellow 485+ RS-485 Wiring
B2 Blue 485-
B3 Black GND Ground
Group C C1 Wiegand Green W0 Wiegand
Wiring 0
DS-K1T342 Series Face Recognion Terminal User Manual
20
Group No. Funcon Color Name Descripon
C2 White W1 Wiegand
Wiring 1
C3 Black GND Ground
Group D D1 Door Lock White/Purple NC Lock Wiring
(NC)
D2 White/Yellow COM Common
D3 White/Red NO Lock Wiring
(NO)
D4 Yellow/Green SENSOR Door Contact
D5 Black GND Ground
D6 Yellow/Grey BUTTON Exit Door
Wiring
4.2 Wire Normal Device
You can connect the terminal with normal peripherals.
DS-K1T342 Series Face Recognion Terminal User Manual
21
Figure 4-1 Device Wiring
Note
●
You should set the face recognion terminal's Wiegand direcon as Input to connect to a
Wiegand card reader. If connects to an access controller, you should set the Wiegand direcon as
Output to transmit authencaon informaon to the access controller.
●
For details about Wiegand direcon sengs, see Set Wiegand Parameters .
●
Do not wire the device to the electric supply directly.
4.3 Wire Secure Door Control Unit
You can connect the terminal with the secure door control unit.
The wiring diagram is as follows.
DS-K1T342 Series Face Recognion Terminal User Manual
22
Figure 4-2 Secure Door Control Unit Wiring
Note
The secure door control unit should connect to an external power supply separately. The suggested
external power supply is 12V, 0.5A.
4.4 Wire Fire Module
4.4.1 Wiring Diagram of Door Open When Powering O
Lock Type: Anode Lock, Magnec Lock, and Electric Bolt (NO)
Security Type: Door Open When Powering O
Scenario: Installed in Fire Engine Access
Type 1
Note
The re system controls the power supply of the access control system.
DS-K1T342 Series Face Recognion Terminal User Manual
23
Figure 4-3 Wire Device
Figure 4-4 Wire Secure Door Control Unit
Type 2
Note
The re system (NO and COM, normally open when powering o) is connected with the lock and
the power supply in series. When an re alarm is triggered, the door remains open. In normal
mes, NO and COM are closed.
DS-K1T342 Series Face Recognion Terminal User Manual
24
Figure 4-5 Wiring Device
Figure 4-6 Wiring Secure Door Control Unit
4.4.2 Wiring Diagram of Door Locked When Powering O
Lock Type: Cathode Lock, Electric Lock, and Electric Bolt (NC)
Security Type: Door Locked When Powering O
Scenario: Installed in Entrance/Exit with Fire Linkage
DS-K1T342 Series Face Recognion Terminal User Manual
25
Note
●
The Uninterpretable Power Supply (UPS) is required.
●
The re system (NC and COM, normally closed when powering o) is connected with the lock
and the power supply in series. When an re alarm is triggered, the door remains open. In
normal mes, NC and COM are open.
Figure 4-7 Device Wiring
Figure 4-8 Wiring Diagram
DS-K1T342 Series Face Recognion Terminal User Manual
26
Chapter 5 Acvaon
You should acvate the device before the rst login. Aer powering on the device, the system will
switch to Device Acvaon page.
Acvaon via the device, SADP tool and the client soware are supported.
The default values of the device are as follows:
●
The default IP address: 192.0.0.64
●
The default port No.: 8000
●
The default user name: admin
5.1 Acvate via Device
If the device is not acvated, you can acvate the device aer it is powered on.
On the Acvate Device page, create a password and conrm the password. Tap Acvate and the
device will acvated.
DS-K1T342 Series Face Recognion Terminal User Manual
27
Figure 5-1 Acvaon Page
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
DS-K1T342 Series Face Recognion Terminal User Manual
28
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change your
password regularly, especially in the high security system, changing the password monthly or
weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
●
Aer acvaon, you should select a language according to your actual needs.
●
Aer acvaon, you should select an applicaon mode. For details, see Set Applicaon Mode .
●
Aer acvaon, you should set the network. For details, see Set Network Parameters .
●
Aer acvaon, you can add the device to the plaorm. For details, see
Access to Plaorm .
●
Aer acvaon, if you need to set privacy, you should check the item. For details, see Privacy
Sengs .
●
Aer acvaon, if you need to add administrator to manage the device parameters, you should
set administrator. For details, see Add Administrator .
5.2 Acvate via Web Browser
You can acvate the device via the web browser.
Steps
1.
Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press
Enter.
Note
Make sure the device IP address and the computer's should be in the same IP segment.
2.
Create a new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
3.
Click Acvate.
DS-K1T342 Series Face Recognion Terminal User Manual
29
4.
Edit the device IP address. You can edit the IP address via the SADP tool, the device, and the
client soware.
5.3 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
●
Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/en/ , and install the SADP according to the prompts.
●
The device and the PC that runs the SADP tool should be within the same subnet.
The following steps show how to acvate a device and modify its IP address. For batch acvaon
and IP addresses modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
4.
Click Acvate to start acvaon.
DS-K1T342 Series Face Recognion Terminal User Manual
30
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to acvate your IP address modicaon.
5.4 Acvate Device via iVMS-4200 Client Soware
For some devices, you are required to create the password to acvate them before they can be
added to the iVMS-4200 soware and work properly.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Device Management page.
2.
Click on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Check the device status (shown on Security Level column) and select an inacve device.
5.
Click Acvate to open the Acvaon dialog.
6.
Create a password in the password eld, and conrm the password.
DS-K1T342 Series Face Recognion Terminal User Manual
31
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
7.
Click OK to acvate the device.
DS-K1T342 Series Face Recognion Terminal User Manual
32
Chapter 6 Quick Operaon
6.1 Select Language
You can select a language for the device system.
Aer the device acvaon, you can select a language for the device system.
DS-K1T342 Series Face Recognion Terminal User Manual
33
Figure 6-1 Select System Language
By default, the system language is English.
Note
Aer you change the system language, the device will reboot automacally.
DS-K1T342 Series Face Recognion Terminal User Manual
34
6.2 Set Applicaon Mode
Aer acvang the device, you should select an applicaon mode for beer device applicaon.
Steps
1.
On the Welcome page, select Indoor or Others from the drop-down list.
Figure 6-2 Welcome Page
DS-K1T342 Series Face Recognion Terminal User Manual
35
2.
Tap OK to save.
Note
●
You can also change the sengs in System Sengs.
●
If you install the device indoors near the window or the face recognion funcon is not
working well, select Others.
●
If you do not congure the applicaon mode and tap Next, the system will select Indoor by
default.
●
If you acvate the device via other tools remotely, the system will select Indoor as the
applicaon mode by default.
6.3 Set Network Parameters
Aer acvaon and select applicaon mode, you can set the network for the device
Steps
1.
When you enter the Select Network page, tap Wired Network or Wi-Fi for your actual needs.
DS-K1T342 Series Face Recognion Terminal User Manual
36
Figure 6-3 Select Network
Note
Disconnect the wired network before connecng a Wi-Fi.
2.
Tap Next.
Wired Network
DS-K1T342 Series Face Recognion Terminal User Manual
37
Note
Make sure the device has connected to a network.
If enable DHCP, the system will assign the IP address and other parameters automacally.
If disable DHCP, you should set the IP address, the subnet mask, and the gateway.
Wi-Fi
Select a Wi-Fi and enter the Wi-Fi's password to get connected.
Or tap Add Wi-Fi and enter the Wi-Fi's name and the password to get connected.
3.
Oponal: Tap Skip to skip network sengs.
6.4 Access to Plaorm
Enable the funcon and the device can communicate via Hik-Connect. You can add the device to
Hik-Connect modile client and so on.
Steps
1.
Enable Access to Hik-Connect, and set the Server IP and Vericaon Code.
DS-K1T342 Series Face Recognion Terminal User Manual
38
Figure 6-4 Access to Hik-Connect
2.
Tap Next.
Note
If you tap Previous to return to the Wi-Fi conguraon page, you need to tap the connected Wi-
Fi or connect another Wi-Fi to enter the plaorm page again.
DS-K1T342 Series Face Recognion Terminal User Manual
39
6.5 Link to Mobile Client
Aer acvaon, selecng applicaon mode, selecng networking, you can add the device to the
mobile client.
Download and install the mobile client. Use the scan QR code funcon of the mobile client and
scan the QR code displayed on the device to link the device to the mobile client.
Follow the instrucons to link the device to the mobile client.
DS-K1T342 Series Face Recognion Terminal User Manual
40
Figure 6-5 Link to Mobile Client
6.6 Privacy Sengs
Aer acvaon, selecng applicaon mode, and selecng network, you should set the privacy
parameters, including the picture uploading and storage.
DS-K1T342 Series Face Recognion Terminal User Manual
41
Select parameters according to your actual needs.
Figure 6-6 Privacy
Upload Captured Pic. When Auth. (Upload Captured Picture When Authencang)
Upload the pictures captured when authencang to the plaorm automacally.
Save Captured Pic. When Auth. (Save Captured Picture When Authencang)
If you enable this funcon, you can save the picture when Authencang to the device.
DS-K1T342 Series Face Recognion Terminal User Manual
42
Save Registered Pic. (Save Registered Picture)
The registered face picture will be saved to the system if you enable the funcon.
Upload Pic. Aer Linked Capture (Upload Picture Aer Linked Capture)
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pic. Aer Linked Capture (Save Pictures Aer Linked Capture)
If you enable this funcon, you can save the picture captured by linked camera to the device.
Tap Next to complete the sengs.
6.7 Set Administrator
Aer device acvaon, you can add an administrator to manage the device parameters.
Before You Start
Acvate the device and select an applicaon mode.
Steps
1.
Oponal: Tap Skip to skip adding administrator if required.
2.
Enter the administrator's name (oponal) and tap Next.
DS-K1T342 Series Face Recognion Terminal User Manual
43
Figure 6-7 Add Administrator Page
3.
Select a credenal to add.
Note
Up to one credenal should be added.
DS-K1T342 Series Face Recognion Terminal User Manual
44
-
: Face forward at the camera. Make sure the face is in the face recognion area. Click to
capture and click to conrm.
-
: Press your nger according to the instrucons on the device screen. Click to conrm.
-
: Enter the card No. or present card on the card presenng area. Click OK.
4.
Click OK.
You will enter the authencaon page.
Status Icon Descripon
/
Device is armed/not armed.
/
Hik-Connect is enabled/disabled.
/ /
The device wired network is connected/not connected/connecng failed.
/ /
The device' Wi-Fi is enabled and connected/not connected/enabled but not connected.
Shortcut Keys Descripon
Note
You can congure those shortcut keys displayed on the screen. For details, see Basic Sengs .
●
Enter the device room No. and tap OK to call.
●
Tap to call the center.
Note
The device should be added to the center, or the calling operaon will be failed.
Enter PIN code to authencate.
DS-K1T342 Series Face Recognion Terminal User Manual
45
Chapter 7 Basic Operaon
7.1 Login
Login the device to set the device basic parameters.
7.1.1 Login by Administrator
If you have added an administrator for the device, only the administrator can login the device for
device operaon.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture to enter
the admin login page.
DS-K1T342 Series Face Recognion Terminal User Manual
46
Figure 7-1 Admin Login
2.
Authencate the administrator's face, ngerprint or card to enter the home page.
DS-K1T342 Series Face Recognion Terminal User Manual
47
Figure 7-2 Home Page
Note
The device will be locked for 30 minutes aer 5 failed ngerprint or card aempts.
3.
Oponal: Tap and you can enter the device acvaon password for login.
4.
Oponal: Tap and you can exit the admin login page.
DS-K1T342 Series Face Recognion Terminal User Manual
48
7.1.2 Login by Acvaon Password
You should login the system before other device operaons. If you do not congure an
administrator, you should follow the instrucons below to login.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture to enter
password entering page.
2.
Enter the password.
-
If you have added an administrator for the device, tap
and enter the password.
-
If you haven't added an administrator for the device, enter the password.
3.
Tap OK to enter the home page.
Note
The device will be locked for 30 minutes aer 5 failed password aempts.
DS-K1T342 Series Face Recognion Terminal User Manual
49
Figure 7-3 Home Page
7.2 Communicaon Sengs
You can set the wired network, the Wi-Fi parameter, the RS-485 parameters, the Wiegand
parameters, ISUP and access to Hik-Connect on the communicaon sengs page.
DS-K1T342 Series Face Recognion Terminal User Manual
50
7.2.1 Set Wired Network Parameters
You can set the device wired network parameters, including the IP address, the subnet mask, the
gateway, and DNS parameters.
Steps
1.
Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the Communicaon Sengs page, tap Wired Network.
DS-K1T342 Series Face Recognion Terminal User Manual
51
Figure 7-4 Wired Network Sengs
3.
Set IP Address, Subnet Mask, and Gateway.
-
Enable DHCP, and the system will assign IP address, subnet mask, and gateway automacally.
-
Disable DHCP, and you should set the IP address, subnet mask, and gateway manually.
DS-K1T342 Series Face Recognion Terminal User Manual
52
Note
The device's IP address and the computer IP address should be in the same IP segment.
4.
Set the DNS parameters. You can enable Auto Obtain DNS, set the preferred DNS server and the
alternate DNS server.
7.2.2 Set Wi-Fi Parameters
You can enable the Wi-Fi funcon and set the Wi-Fi related parameters.
Steps
Note
The funcon should be supported by the device.
1.
Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the Communicaon Sengs page, tap.
DS-K1T342 Series Face Recognion Terminal User Manual
53
Figure 7-5 Wi-Fi Sengs
3.
Enable the Wi-Fi funcon.
4.
Congure the Wi-Fi parameters.
-
Select a Wi-Fi from the list, and enter the Wi-Fi's password. Tap OK.
-
If the target Wi-Fi is not in the list,tap Add Wi-Fi. Enter the Wi-Fi's name and password. And
tap OK.
DS-K1T342 Series Face Recognion Terminal User Manual
54
Note
Only digits, leers, and special characters are allowed in the password.
5.
Set the Wi-Fi's parameters.
-
By default, DHCP is enable. The system will allocate the IP address, the subnet mask, and the
gateway automacally.
-
If disable DHCP, you should enter the IP address, the subnet mask, and the gateway manually.
6.
Tap OK to save the sengs and go back to the Wi-Fi tab.
7.
Tap
to save the network parameters.
7.2.3 Set RS-485 Parameters
The face recognion terminal can connect external access controller, secure door control unit or
card reader via the RS-485 terminal.
Steps
1.
Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the Communicaon Sengs page, tap RS-485 to enter the RS-485 tab.
DS-K1T342 Series Face Recognion Terminal User Manual
55
Figure 7-6 Set RS-485 Parameters
3.
Select an peripheral type according to your actual needs.
DS-K1T342 Series Face Recognion Terminal User Manual
56
Note
If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set
the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address
according to the door No.
4.
Tap the back icon at the upper le corner and you should reboot the device if you change the
parameters.
7.2.4 Set Wiegand Parameters
You can set the Wiegand transmission direcon.
Steps
1.
Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the Communicaon Sengs page, tap Wiegand to enter the Wiegand tab.
DS-K1T342 Series Face Recognion Terminal User Manual
57
Figure 7-7 Wiegand Sengs
3.
Enable the Wiegand funcon.
4.
Select a transmission direcon.
Output: A face recognion terminal can connect an external access controller. And the two
devices will transmit the card No. via Wiegand 26 or Wiegand 34.
5.
Tap to save the network parameters.
DS-K1T342 Series Face Recognion Terminal User Manual
58
Note
If you change the external device, and aer you save the device parameters, the device will
reboot automacally.
7.2.5 Set ISUP Parameters
Set ISUP parameters and the device can upload data via ISUP protocol.
Before You Start
Make sure your device has connect to a network.
Steps
1.
Tap Comm. → ISUP .
DS-K1T342 Series Face Recognion Terminal User Manual
59
Figure 7-8 ISUP Sengs
2.
Enable the ISUP funcon and set the ISUP server parameters.
ISUP Version
Set the ISUP version according to your actual needs.
Central Group
Enable central group and the data will be uploaded to the center group.
DS-K1T342 Series Face Recognion Terminal User Manual
60
Main Channel
Support N1 or None.
ISUP
Enable ISUP funcon and the data will be uploaded via EHome protocol.
Address Type
Select an address type according to your actual needs.
IP Address
Set the ISUP server's IP address.
Port No.
Set the ISUP server's port No.
Note
Port No. Range: 0 to 65535.
Device ID
Set device serial no.
Password
If you choose V5.0, you should create an account and ISUP key. If you choose other version,
you should create an ISUP account only.
Note
●
Remember the ISUP account and ISUP key. You should enter the account name or the key
when the device should communicate with other plaorms via ISUP protocol.
●
ISUP key range: 8 to 32 characters.
7.2.6 Plaorm Access
You can change the device vericaon code and set the server address before you add the device
to the Hik-Connect mobile client.
Before You Start
Make sure your device has connected to a network.
Steps
1.
Tap Comm. (Communicaon Sengs) on the Home page to enter the Communicaon Sengs
page.
2.
On the Communicaon Sengs page, tap Access to Hik-Connect.
3.
Enable Access to Hik-Connect
4.
Enter Server IP.
5.
Create the Vericaon Code, and you need to enter the vericaon code when you manage the
devices via Hik-Connect.
DS-K1T342 Series Face Recognion Terminal User Manual
61
7.3 User Management
On the user management interface, you can add, edit, delete and search the user.
7.3.1 Add Administrator
The administrator can log in the device backend and congure the device parameters.
Steps
1.
Long tap on the inial page and log in the backend.
2.
Tap User → + to enter the Add User page.
DS-K1T342 Series Face Recognion Terminal User Manual
62
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T342 Series Face Recognion Terminal User Manual
63
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
Up to 32 characters are allowed in the user name.
5.
Oponal: Add a face picture, ngerprints, cards, or Pin for the administrator.
Note
●
For details about adding a face picture, see Add Face Picture .
●
Note
For details about adding a ngerprint, see Add Fingerprint .
●
For details about adding a card, see Add Card .
●
For details about adding a password, see View PIN code .
6.
Oponal: Set the administrator's authencaon type.
Note
For details about seng the authencaon type, see Set Authencaon Mode .
7.
Enable the Administrator Permission funcon.
Enable Administrator Permission
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
8.
Tap to save the sengs.
7.3.2 Add Face Picture
Add user's face picture to the device. And the user can use the face picture to authencate.
Steps
Note
Up to 1500 face pictures can be added.
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → + to enter the Add User page.
3.
Edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T342 Series Face Recognion Terminal User Manual
64
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
5.
Tap the Face Picture eld to enter the face picture adding page.
Figure 7-9 Add Face Picture
DS-K1T342 Series Face Recognion Terminal User Manual
65
6.
Look at the camera.
Note
●
Make sure your face picture is in the face picture outline when adding the face picture.
●
Make sure the captured face picture is in good quality and is accurate.
●
For details about the instrucons of adding face pictures, see Tips When Collecng/
Comparing Face Picture .
Aer completely adding the face picture, a captured face picture will be displayed at the upper
right corner of the page.
7.
Tap Save to save the face picture.
8.
Oponal: Tap Try Again and adjust your face posion to add the face picture again.
9.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
10.
Tap to save the sengs.
7.3.3 Add Fingerprint
Add a ngerprint for the user and the user can authencate via the added ngerprint.
Steps
Note
●
The funcon should be supported by the device.
●
Up to 3000 ngerprints can be added.
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and enter
the device backend.
2.
Tap User → + to enter the Add User page.
3.
Tap the Employee ID. eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not start with 0 and should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T342 Series Face Recognion Terminal User Manual
66
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
5.
Tap the Fingerprint eld to enter the Add Fingerprint page.
6.
Follow the instrucons to add a ngerprint.
Note
●
The same ngerprint cannot be repeatedly added.
●
Up to 10 ngerprints can be added for one user.
●
You can also use the client soware or the ngerprint recorder to record ngerprints.
For details about the instrucons of scanning ngerprints, see Tips for Scanning Fingerprint .
7.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
8.
Tap
to save the sengs.
7.3.4 Add Card
Add a card for the user and the user can authencate via the added card.
Steps
Note
Up to 3000 cards can be added.
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → + to enter the Add User page.
3.
Connect an external card reader according to the wiring diagram.
4.
Tap the Employee ID. eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
5.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T342 Series Face Recognion Terminal User Manual
67
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
6.
Tap the Card eld and tap +.
7.
Congure the card No.
-
Enter the card No. manually.
-
Present the card over the card presenng area to get the card No.
Note
●
The card No. cannot be empty.
●
Up to 20 characters are allowed in the card No.
●
The card No. cannot be duplicated.
8.
Congure the card type.
9.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
10.
Tap
to save the sengs.
7.3.5 View PIN code
Add a PIN code for the user and the user can authencate via the PIN code.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → + to enter the Add User page.
3.
Tap the Employee ID. eld and edit the employee ID.
Note
●
The employee ID should be less than 32 characters. And it can be a combinaon of lower
leers, upper leers, and numbers.
●
The employee ID should not be duplicated.
4.
Tap the Name eld and input the user name on the so keyboard.
DS-K1T342 Series Face Recognion Terminal User Manual
68
Note
●
Numbers, upper case leers, lower case leers, and special characters are allowed in the user
name.
●
The suggested user name should be within 32 characters.
5.
Tap the PIN code to view the PIN code.
Note
The PIN code cannot be edited. It can only be applied by the plaorm.
6.
Set the user role.
Administrator
The user is the administrator. Except for the normal aendance funcon, the user can also
enter the Home page to operate aer authencang the permission.
Normal User
The User is the normal user. The user can only authencate or take aendance on the inial
page.
7.
Tap to save the sengs.
7.3.6 Set Authencaon Mode
Aer adding the user's face picture, password, or other credenals, you should set the
authencaon mode and the user can authencate his/her identy via the congured
authencaon mode.
Steps
1.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and log in
the backend.
2.
Tap User → Add User/Edit User → Authencaon Mode .
3.
Select Device or Custom as the authencaon mode.
Device
If you want to select device mode, you should set the terminal authencaon mode in Access
Control Sengs page rst. For details see Seng Access Control Parameters.
Custom
You can combine dierent authencaon modes together according to your actual needs.
4.
Tap
to save the sengs.
7.3.7 Search and Edit User
Aer adding the user, you can search the user and edit it.
DS-K1T342 Series Face Recognion Terminal User Manual
69
Search User
On the User Management page, Tap the search area to enter the Search User page. Tap Card on
the le of the page and select a search type from the drop-down list. Enter the employee ID, card
No., or the user name for search. Tap to search.
Edit User
On the User Management page, select a user from the user list to enter the Edit User page. Follow
the steps in User Management to edit the user parameters. Tap to save the sengs.
Note
The employee ID cannot be edited.
7.4 Data Management
You can delete data, import data, and export data.
7.4.1 Delete Data
Delete user data.
On the Home page, tap Data → Delete Data → User Data . All user data added in the device will be
deleted.
7.4.2 Import Data
Steps
1.
Plug a USB ash drive in the device.
2.
On the Home page, tap Data → Import Data .
3.
Tap User Data, Face Data or Access Control Parameters .
Note
The imported access control parameters are conguraon les of the device.
4.
Enter the created password when you exported the data. If you do not create a password when
you exported the data, leave a blank in the input box and tap OK immediately.
Note
●
If you want to transfer all user informaon from one device (Device A) to another (Device B),
you should export the informaon from Device A to the USB ash drive and then import from
the USB ash drive to Device B. In this case, you should import the user data before imporng
the prole photo.
●
The supported USB ash drive format is FAT32.
DS-K1T342 Series Face Recognion Terminal User Manual
70
●
The imported pictures should be saved in the folder (named enroll_pic) of the root directory
and the picture's name should be follow the rule below:
Card No._Name_Department_Employee ID_Gender.jpg
●
If the folder enroll_pic cannot save all imported pictures, you can create another folders,
named enroll_pic1, enroll_pic2, enroll_pic3, enroll_pic4, under the root directory.
●
The employee ID should be less than 32 characters. It can be a combinaon of lower leers,
upper leers, and numbers. It should not be duplicated, and should not start with 0.
●
Requirements of face picture should follow the rules below: It should be taken in full-face
view, directly facing the camera. Do not wear a hat or head covering when taking the face
picture. The format should be JPEG or JPG. The resoluon should be 640 × 480 pixel or more
than of 640 × 480 pixel. The picture size should be between 60 KB and 200 KB.
7.4.3 Export Data
Steps
1.
Plug a USB ash drive in the device.
2.
On the Home page, tap Data → Export Data .
3.
Tap Face Data, Event Data, User Data, or Access Control Parameters.
Note
The exported access control parameters are conguraon les of the device.
4.
Oponal: Create a password for exporng. When you import those data to another device, you
should enter the password.
Note
●
The supported USB ash drive format is DB.
●
The system supports the USB ash drive with the storage of 1G to 32G. Make sure the free
space of the USB ash drive is more than 512M.
●
The exported user data is a DB le, which cannot be edited.
7.5 Identy Authencaon
Aer network conguraon, system parameters conguraon and user conguraon, you can go
back to the inial page for identy authencaon. The system will authencate person according
to the congured authencaon mode.
7.5.1 Authencate via Single Credenal
Set the user authencaon type before authencaon. For details, see Set Authencaon Mode .
Authencate face, ngerprint or card.
Face
DS-K1T342 Series Face Recognion Terminal User Manual
71
Face forward at the camera and start authencaon via face.
Fingerprint
Place the enrolled ngerprint on the ngerprint module and start authencaon via ngerprint.
Card
Present the card on the card presenng area and start authencaon via card.
Note
The card can be normal IC card, or encrypted card.
PIN Code
Enter the pin code to authencate via PIN code.
If authencaon completed, a prompt "Authencated" will pop up.
7.5.2 Authencate via Mulple Credenal
Before You Start
Set the user authencaon type before authencaon. For details, see Set Authencaon Mode .
Steps
1.
If the authencaon mode is Card and Face, Password and Face, Card and Password, Card and
Face and Fingerprint, authencate any credenal according to the instrucons on the live view
page.
Note
●
The card can be normal IC card, or encrypted card.
2.
Aer the previous credenal is authencated, connue authencate other credenals.
Note
●
For detailed informaon about scanning ngerprint, see Tips for Scanning Fingerprint.
●
For detailed informaon about authencang face, see Tips When Collecng/Comparing Face
Picture.
If authencaon succeeded, the prompt "Authencated" will pop up.
7.6 Basic Sengs
You can set the voice, me, sleeping (s), language, community No., building No., and Unit No.
Long tap on the inial page for 3 s and slide to the le/right by following the gesture and login the
device home page. Tap Basic.
DS-K1T342 Series Face Recognion Terminal User Manual
72
Figure 7-10 Basic Sengs Page
Voice Sengs
You can enable/disable the voice prompt funcon and adjust the voice volume.
Note
You can set the voice volume between 0 and 10.
DS-K1T342 Series Face Recognion Terminal User Manual
73
Time Sengs
Set the me zone, the device me and the DST.
Sleeping (s)
Set the device sleeping waing me (s). For example, when you are on the inial page and if
you set the sleeping me to 30 s, the device will sleep aer 30 s without any operaon.
Note
20 s to 999 s are available to congure.
Select Language
Select the language according to actual needs.
Community No.
Set the device installed community No.
Building No.
Set the device installed building No.
Unit No.
Set the device installed unit No.
7.7 Set Biometric Parameters
You can customize the face parameters to improve the face recognion performance. The
congurable parameters includes select applicaon mode, face liveness level, face recognion
distance, face recognion interval, face 1:N security level, face 1:1 security level, ECO sengs and
face with mask detecon.
Long tap on the inial page for 3 s and login the home page. Tap Biometric.
DS-K1T342 Series Face Recognion Terminal User Manual
74
Figure 7-11 Biometric Parameters Page
DS-K1T342 Series Face Recognion Terminal User Manual
75
Table 7-1 Face Picture Parameters
Parameter Descripon
Select Applicaon
Mode
Select either others or indoor according to actual environment.
Face Liveness Level Aer enabling face an-spoong funcon, you can set the matching
security level when performing live face authencaon.
Face Recognion
Distance
Set the valid distance between the user and the camera when
authencang.
Face Recognion
Interval
The me interval between two connuous face recognions when
authencang.
Note
You can input the number from 1 to 10.
Face 1:N Security Level Set the matching threshold when authencang via 1:N matching mode.
The larger the value, the smaller the false accept rate and the larger the
false rejecon rate.
Face 1:1 Security Level Set the matching threshold when authencang via 1:1 matching mode.
The larger the value, the smaller the false accept rate and the larger the
false rejecon rate.
ECO Sengs Aer enabling the ECO mode, the device will use the IR camera to
authencate faces in the low light or dark environment. And you can set
the ECO mode threshold, ECO mode (1:N), ECO mode (1:1), Face with
mask & face (1:1 ECO) and Face with mask & face (1:N ECO).
ECO Threshold
When enabling the ECO mode, you can set the ECO mode's threshold.
The larger the value, the easier the device entering the ECO mode.
ECO Mode (1:1)
Set the matching threshold when authencang via ECO mode 1:1
matching mode. The larger the value, the smaller the false accept rate
and the larger the false rejecon rate.
ECO Mode (1:N)
Set the matching threshold when authencang via ECO mode 1:N
matching mode. The larger the value, the smaller the false accept rate
and the larger the false rejecon rate
Face with Mask & Face (1:1 ECO)
DS-K1T342 Series Face Recognion Terminal User Manual
76
Parameter Descripon
Set the matching value when authencang with face mask via ECO
mode 1:1 matching mode. The larger the value, the smaller the false
accept rate and the larger the false rejecon rate.
Face with Mask & Face (1:N ECO)
Set the matching value when authencang with face mask via ECO
mode 1:N matching mode. The larger the value, the smaller the false
accept rate and the larger the false rejecon rate.
Face with Mask
Detecon
Aer enabling the face with mask detecon, the system will recognize
the captured face with mask picture. You can set face with mask & face
1:N level and the strategy.
Strategy
Set the None, Reminder of Wearing and Must Wear strategy.
Reminder of Wearing
If the person do not wear a face mask when authencang, the
device prompts a nocaon and the door will open.
Must Wear
If the person do not wear a face mask when authencang, the
device prompts a nocaon and the door keeps closed.
None
If the person do not wear a face mask when authencang, the
device will not prompt a nocaon.
Face with Mask & Face (1:1)
Set the matching value when authencang with face mask via 1:1
matching mode. The larger the value, the smaller the false accept rate
and the larger the false rejecon rate.
Face with Mask & Face (1:N)
Set the matching value when authencang with face mask via 1:N
matching mode. The larger the value, the smaller the false accept rate
and the larger the false rejecon rate.
7.8 Set Access Control Parameters
You can set the access control permissions, including the funcons of authencaon mode, enable
NFC card, enable M1 card, door contact, open duraon (s) and authencaon interval (s).
On the Home page, tap ACS (Access Control Sengs) to enter the Access Control Sengs page.
Edit the access control parameters on this page.
DS-K1T342 Series Face Recognion Terminal User Manual
77
Figure 7-12 Access Control Parameters
The available parameters descripons are as follows:
DS-K1T342 Series Face Recognion Terminal User Manual
78
Table 7-2 Access Control Parameters Descripons
Parameter Descripon
Terminal Auth. Mode (Terminal
Authencaon Mode)
Select the face recognion terminal's authencaon mode. You
can also customize the authencaon mode.
Note
●
Only the device with the ngerprint module supports the
ngerprint related funcon.
●
Biometric recognion products are not completely applicable
to an-spoong environments. If you require a higher
security level, use mulple authencaon modes.
●
If you adopt mulple authencaon modes, you should
authencate other methods before authencang face.
Reader Auth. Mode (Card
Reader Authencaon Mode)
Select the card reader's authencaon mode.
Enable NFC Card Enable the funcon and you can present the NFC card to
authencate.
Enable M1 Card Enable the funcon and you can present the M1 card to
authencate.
Door Contact You can select "Open (Remain Open)" or "Close (Remian
Closed)" according to your actual needs. By default, it is Close
(Remian Closed).
Open Duraon Set the door unlocking duraon. If the door is not opened for
the set me, the door will be locked. Available door locked me
range: 1 to 255s.
Authencaon Interval Set the device authencang interval. Available authencaon
interval range: 0 to 65535.
7.9 Time and Aendance Status Sengs
You can set the aendance mode as check in, check out, break out, break in, overme in, and
overme out according to your actual situaon.
Note
The funcon should be used cooperavely with me and aendance funcon on the client
soware.
DS-K1T342 Series Face Recognion Terminal User Manual
79
7.9.1 Disable Aendance Mode via Device
Disable the aendance mode and the system will not display the aendance status on the inial
page.
Tap T&A Status to enter the T&A Status page.
Figure 7-13 Disable Aendance Mode
DS-K1T342 Series Face Recognion Terminal User Manual
80
Set the Aendance Mode as Disable.
You will not view or congure the aendance status on the inial page. And the system will follow
the aendance rule that congured on the plaorm.
7.9.2 Set Manual Aendance via Device
Set the aendance mode as manual, and you should select a status manually when you take
aendance.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Tap T&A Status to enter the T&A Status page.
2.
Set the Aendance Mode as Manual.
DS-K1T342 Series Face Recognion Terminal User Manual
81
Figure 7-14 Manual Aendance Mode
3.
Enable the Aendance Status Required.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
DS-K1T342 Series Face Recognion Terminal User Manual
82
The name will be displayed on the T & A Status page and the authencaon result page.
Result
You should select an aendance status manually aer authencaon.
Note
If you do not select a status, the authencaon will be failed and it will not be marked as a valid
aendance.
7.9.3 Set Auto Aendance via Device
Set the aendance mode as auto, and you can set the aendance status and its available schedule.
The system will automacally change the aendance status according to the congured schedule.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Tap T&A Status to enter the T&A Status page.
2.
Set the Aendance Mode as Auto.
DS-K1T342 Series Face Recognion Terminal User Manual
83
Figure 7-15 Auto Aendance Mode
3.
Enable the Aendance Status funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
DS-K1T342 Series Face Recognion Terminal User Manual
84
The name will be displayed on the T & A Status page and the authencaon result page.
6.
Set the status' schedule.
1) Tap Aendance Schedule.
2) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.
3) Set the selected aendance status's start me of the day.
4) Tap Conrm.
5) Repeat step 1 to 4 according to your actual needs.
Note
The aendance status will be valid within the congured schedule.
Result
When you authencate on the inial page, the authencaon will be marked as the congured
aendance status according to the congured schedule.
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
7.9.4 Set Manual and Auto Aendance via Device
Set the aendance mode as Manual and Auto, and the system will automacally change the
aendance status according to the congured schedule. At the same me you can manually
change the aendance status aer the authencaon.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Tap T&A Status to enter the T&A Status page.
2.
Set the Aendance Mode as Manual and Auto.
DS-K1T342 Series Face Recognion Terminal User Manual
85
Figure 7-16 Manual and Auto Mode
3.
Enable the Aendance Status funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
DS-K1T342 Series Face Recognion Terminal User Manual
86
The name will be displayed on the T & A Status page and the authencaon result page.
6.
Set the status' schedule.
1) Tap Aendance Schedule.
2) Select Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, or Sunday.
3) Set the selected aendance status's start me of the day.
4) Tap OK.
5) Repeat step 1 to 4 according to your actual needs.
Note
The aendance status will be valid within the congured schedule.
Result
On the inial page and authencate. The authencaon will be marked as the congured
aendance status according to the schedule. If you tap the edit icon on the result tab, you can
select a status to take aendance manually, the authencaon will be marked as the edited
aendance status.
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
7.10 Set Preference
You can congure preference sengs parameters.
Steps
1.
Tap Basic Sengs → Preference Sengs to enter the preference sengs page.
DS-K1T342 Series Face Recognion Terminal User Manual
87
Figure 7-17 Preference Sengs
Shortcut Key
Choose the shortcut key that displayed on the authencaon page, including the QR code
funcon, the call funcon, call type, and the password entering funcon.
DS-K1T342 Series Face Recognion Terminal User Manual
88
Note
You can select call type from Call Room, Call Center, Call Specied Room No. and Call APP.
Call Room
When you tap the call buon on the authencaon page, you should dial a room No. to
call.
Call Center
When you tap the call buon on the authencaon page, you can call the center directly.
Call Specied Room No.
You should set a room No. When you tap the call buon on the authencaon page, you
can call the congured room directly without dialing.
Call APP
When you tap the call buon on the authencaon page, you will call the mobile client
where the device is added.
Password
Enable this funcon amd you can enter the password to authencate via password.
QR Code
You can use the QR code scanning funcon on the authencaon interface. The device will
upload the informaon associated with the obtained QR code to the plaorm.
Theme
You can set the theme of the prompt window on the authencaon page. You can select
Theme as Default/Simple. If select Simple, the live view of the authencaon page will be
disabled, and in the meanwhile, the person's name, employee ID, face pictures will all be
hidden.
7.11 System Maintenance
You can view the device system informaon and capacity. You can also restore the system to
factory sengs, default sengs, unlink APP account, and reboot the system.
Long tap on the inial page for 3 s and login the home page. Tap Maint.
DS-K1T342 Series Face Recognion Terminal User Manual
89
Figure 7-18 Maintenance Page
System Informaon
You can view the device informaon including serial No., rmware version, MCU version, MAC
address, producon data, device QR code, open source code license.
DS-K1T342 Series Face Recognion Terminal User Manual
90
Note
The page may vary according to dierent device models. Refers to the actual page for details.
Capacity
You can view the number of administrator, user, face picture, card, and event.
Note
Parts of the device models support displaying the ngerprint number. Refers to the actual page
for details.
Upgrade
Plug the USB ash drive in the device USB interface. Tap Upgrade → OK , and the device will
read the digicap.dav le in the USB ash drive to start upgrading.
Unlink APP Account
Unlink the Hik-Connect account from the plaorm.
Restore to Factory
All parameters will be restored to the factory sengs. The system will reboot to take eect.
Restore to Default
All parameters, except for the communicaon sengs, remotely imported user informaon, will
be restored to the default sengs. The system will reboot to take eect.
Reboot
The device will reboot aer the conrmaon.
Long tap , and enter admin password to view device version informaon.
DS-K1T342 Series Face Recognion Terminal User Manual
91
Chapter 8 Congure the Device via the Mobile
Browser
8.1 Login
You can login via mobile browser.
Note
●
Parts of the model supports Wi-Fi sengs.
●
Make sure the device is acvated.
Obtain the IP address from the device aer Wi-Fi is enabled. Make sure the IP segment of the
device and the computer is the same. For details, refers to Set Wi-Fi Parameters .
Enter the device IP address in the address bar of the mobile browser and press Enter to enter the
login page.
Enter the device user name and the password. Click Login.
8.2 Search Event
Click Search to enter the Search page.
Enter the search condions, including the employee ID, the name, the card No., the start me, and
the end me, and click Search.
Note
Support searching for names within 32 digits.
The results will be displayed in the list.
8.3 User Management
You can add, edit, delete, and search users via mobile Web browser.
Steps
1.
Tap User to enter the sengs page.
2.
Add user.
1) Tap+.
DS-K1T342 Series Face Recognion Terminal User Manual
92
Figure 8-1 Add User
2) Set the following parameters.
Employee ID
Enter the employee ID. The Employee ID cannot be 0 or exceed 32 characters. It can be a
combinaon of uppercase, lowercase leers and numbers.
Name
DS-K1T342 Series Face Recognion Terminal User Manual
93
Enter your name. The name supports numbers, uppercase and lowercase English, and
characters. The name is recommended to be within 32 characters.
User Role
Select your user role.
Floor No./Room No.
Enter the oor No./room No.
Face
Add Face picture. Tap Face, then tapImport, and select the mode to import the face.
Fingerprint
Add ngerprint. Tap Fingerprint, then tap +, and add ngerprint via the ngerprint module.
Start Date/End Date
Set Start Date and End Date of user permission.
Administrator
If the user needs to be set as administrator, you can enable Administrator.
Authencaon Type
Set the authencaon type.
3) Tap Save.
3.
Tap the user that needs to be edited in the user list to edit the informaon.
4.
Tap the user that needs to be deleted in the user list, and tap to delete the user.
5.
You can search the user by entering the employee ID or name in the search bar.
8.4 Conguraon
8.4.1 View Device Informaon
View the device name, language, model, serial No., QR code, version, etc.
Tap Conguraon → System → System Sengs → Basic Informaon to enter the conguraon
page.
You can view the device name, language, model, serial No., QR code, version, etc.
8.4.2 Time Sengs
Set the me zone, me sync. mode, and displayed me.
Tap Conguraon → System → System Sengs → Time Sengs to enter the sengs page.
DS-K1T342 Series Face Recognion Terminal User Manual
94
Figure 8-2 Time Sengs
Tap Save to save the sengs.
Time Zone
Select the me zone where the device is located from the drop-down list.
Time Sync. Mode
Manual
By default, the device me should be synchronized manually. You can set the device me
manually.
NTP
Set the NTP server's IP address, port No., and interval.
8.4.3 View Open Source Soware License
Tap Conguraon → System → System Sengs → About , and tap View Licenses to view the
device license.
8.4.4 Network Sengs
You can set the port and Wi-Fi parameters.
DS-K1T342 Series Face Recognion Terminal User Manual
95
Set Port Parameters
You can set the HTTP, RTSP, HTTPS, and Server according to actual needs when accessing the device
via network.
Tap Conguraon → Network → Basic Sengs → Port , to enter the sengs page.
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
RTSP
It refers to the port of real-me streaming protocol.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required when accessing.
Server
It refers to the port through which the client adds the device.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless connecon.
Steps
Note
The funcon should be supported by the device.
1.
Tap Conguraon → Network → Basic Sengs → Wi-Fi to enter the sengs page.
2.
Check Enable Wi-Fi.
DS-K1T342 Series Face Recognion Terminal User Manual
96
Figure 8-3 Wi-Fi
3.
Add Wi-Fi.
1) Tap +.
DS-K1T342 Series Face Recognion Terminal User Manual
97
Figure 8-4 Add Wi-Fi
2) Enter Wi-Fi Name and Wi-Fi Password, and select Working Mode and Encrypon Type.
3) Tap Save.
4.
Select the Wi-Fi name, and tap Connect.
5.
Enter the password and tap Save.
6.
Set WLAN parameters.
1) Set the IP address, subnet mask, and gateway. Or enable DHCP and the system will allocate
the IP address, subnet mask, and gateway automacally.
2) Tap Save.
8.4.5 General Sengs
Set Authencaon Parameters
Set Authencaon Parameters.
Steps
1.
Tap Conguraon → General Sengs → Authencaon Sengs .
DS-K1T342 Series Face Recognion Terminal User Manual
98
Figure 8-5 Authencaon Sengs
2.
Tap Save.
DS-K1T342 Series Face Recognion Terminal User Manual
99
Device Type
Main Card Reader
You can congure the device card reader's parameters. If you select main card reader, you
need to congure the following parameters: Card Reader Type, Card Reader Descripon,
Enable Card Reader, Authencaon, Recognion Interval (s), Minimum Card Swiping
Interval (s), Max. Authencaon Failed Aempts Alarm/Alarm of Max. Failed Aempts,
Enable Tampering Detecon and Enable Card No. Reversing.
Sub Card Reader
You can congure the connected peripheral card reader's parameters. If you select sub
card reader, you need to congure the following parameters: Card Reader Type, Card
Reader Descripon, Enable Card Reader, Authencaon, Recognion Interval (s), Max.
Authencaon Failed Aempts Alarm/Alarm of Max. Failed Aempts, Enable Tampering
Detecon, Communicaon with Controller Every (s) and Max. Interval When Entering
Password (s).
Card Reader Type
Get card reader type.
Card Reader Descripon
Get card reader descripon. It is read-only.
Enable Card Reader
Enable the card reader's funcon.
Authencaon
Select an authencaon mode according to your actual needs from the drop-down list.
Recognion Interval
If the interval between card presenng of the same card is less than the congured value, the
card presenng is invalid. The interval me range is from 0 to 255 seconds (When set to 0, it
means that recognion interval is not enabled, and the same authencaon can be used for
unlimited mes).
Authencaon Interval
You can set the authencaon interval of the same person when authencang. The same
person can only authencate once in the congured interval. A second authencaon will be
failed.
Max. Authencaon Failed Aempts Alarm/Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Enable Tampering Detecon
Enable the an-tamper detecon for the card reader.
Enable Card No. Reversing
The read card No. will be in reverse sequence aer enabling the funcon.
DS-K1T342 Series Face Recognion Terminal User Manual
100
Communicaon with Controller Every (s)
When the access control device cannot connect with the card reader for longer than the set
me, the card reader will turn oine automacally.
Max. Interval When Entering Password (s)
When you entering the password on the card reader, if the interval between pressing two
digits is longer than the set value, the digits you pressed before will be cleared automacally.
Set Privacy Parameters
Set the event storage type, picture upload and storage parameters, and the picture clearing
parameters.
Tap Conguraon → General Sengs → Privacy .
Figure 8-6 Privacy Sengs
Event Storage Sengs
Select a method to delete the event. You can select from Delete Old Events Periodically, Delete
Old Events by Specied Time, or Overwring.
Delete Old Events Periodically
Enter number to set the period for event deleng. All events will be deleted according to the
congured me duraon.
DS-K1T342 Series Face Recognion Terminal User Manual
101
Delete Old Events by Specied Time
Set a me and all events will be deleted on the congured me.
Overwring
The earliest 5% events will be deleted when the system detects the stored events has been over
95% of the full space.
Authencaon Sengs
Display Authencaon Result
Check Face Picture, Name, or Employee ID. When authencaon is completed, the system will
display the selected contents in the result.
Name De-idencaon
The name informaon is desensized with an asterisk.
ID De-idencaon
The ID informaon is desensized with an asterisk.
Picture Uploading and Storage
You can upload and store pictures.
Upload Captured Picture When Authencang
Upload the pictures captured when authencang to the plaorm automacally.
Save Captured Picture When Authencang
If you enable this funcon, you can save the picture when authencang to the device.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Upload Picture Aer Linked Capture
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Clear All Pictures in Device
You can clear registered face pictures and captured pictures in device.
Clear Registered Face Pictures
Select Face Picture, and tap Clear. All registered pictures in the device will be deleted.
Clear Authencaon/Captured Picture
Select Authencaon/Captured Picture, and tap Clear. All authencaon/captured pictures in
the device will be deleted.
DS-K1T342 Series Face Recognion Terminal User Manual
102
Set Card Security
Tap Conguraon → General Sengs → Card Security to enter the sengs page.
Figure 8-7 Card Security
Set the parameters and click Save.
Enable NFC Card
In order to prevent the mobile phone from geng the data of the access control, you can
enable NFC card to increase the security level of the data.
Enable M1 Card
Enable M1 card and authencateing by presenng M1 card is available.
M1 Card Encrypon
M1 card encrypon can improve the security level of authencaon.
Sector
Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is
recommended to encrypt sector 13.
Enable EM Card
DS-K1T342 Series Face Recognion Terminal User Manual
103
Enable EM card and authencang by presenng EM card is available.
Note
If the peripheral card reader supports presenng EM card, the funcon is also supported to
enable/disable the EM card funcon.
Enable CPU Card
The device can read the data from CPU card when enabling the CPU card funcon.
CPU Card Read Content
Aer enable the CPU card content reading funcon, the device can read the CPU card content.
Enable ID Card
Enable ID card and authencang by presenng ID card is available.
Set Card Authencaon Parameters
Set the card reading content when authencate via card on the device.
Tap Conguraon → General Sengs → Card Authencaon Sengs .
Figure 8-8 Card Authencaon Page
Select a card authencaon mode and tap Save.
Full Card No.
All card No. will be read.
Wiegand 26 (3 bytes)
The device will read card via Wiegand 26 protocol (read 3 bytes).
Wiegand 34 (4 bytes)
The device will read card via Wiegand 34 protocol (read 4 bytes).
8.4.6 Face Parameters Sengs
Set face parameters.
DS-K1T342 Series Face Recognion Terminal User Manual
104
Face Parameters Sengs
Tap Conguraon → Smart → Intelligent Parameter .
Figure 8-9 Face Parameters
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Set Face Parameters.
Face An-spoong
Enable or disable the live face detecon funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not.
Live Face Detecon Security Level
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
Recognion Distance
Select the distance between the authencang user and the device camera.
Applicaon Mode
DS-K1T342 Series Face Recognion Terminal User Manual
105
Select Indoor or Others according to actual environment. In the outdoor scene, indoor scene
near the window, or bad environment, you can choose Others.
Note
If the device is not acvated by other tools, the device uses indoor as the environment mode by
default.
Face Recognion Mode
Normal Mode
The device uses a camera to perform face recognion.
Deep Mode
It is applicable for for more complex environments, and the range of people recognized is
wider.
Note
●
The two modes cannot be compable with each other. Do not change the mode once it is
selected. If you change the mode, all face pictures of the previous mode will be cleared.
●
In the deep mode, you can add the face pictures only via the user adding funcon of the
device or the enrollment staon. It is not supported to add face pictures via pictures
imporng.
The device uses a camera to perform face recognion.
Connuous Face Recognion Interval (s)
Set the me interval between two connuous face recognions when authencang.
Note
Value Range: 1 to 10.
1:1 Matching Threshold
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
1:N Matching Threshold
Set the matching threshold when authencang via 1:N matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate. The maximum value is
100.
Face Recognion Timeout Value (s)
Congure the meout period for face recognion. If the face recognion me exceeds the
congured value, the device will prompt the face recognion meout.
Face with Mask Detecon
DS-K1T342 Series Face Recognion Terminal User Manual
106
Aer enabling the face with mask detecon, the system will recognize the captured face with
mask picture. You can set face with mask1:N matching threshold, its ECO mode, and the
strategy.
None
If the person do not wear a face mask when authencang, the device will not prompt a
nocaon.
Reminder of Wearing
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door will open.
Must Wear
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door keeps closed.
Face with Mask & Face (1:1)
Set the matching value when authencang with face mask via 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask 1:N Matching Threshold
Set the matching threshold when authencang with face mask via 1:N matching mode. The
larger the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask & Face (1:1 ECO)
Set the matching value when authencang with face mask via ECO mode 1:1 matching mode.
The larger the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask 1:N Matching Threshold (ECO Mode)
Set the matching threshold when authencang with face mask via ECO mode 1:N matching
mode. The larger the value, the smaller the false accept rate and the larger the false rejecon
rate.
ECO Mode
Aer enabling the ECO mode, the device will use the IR camera to authencate faces in the low
light or dark environment. And you can set the ECO mode threshold, ECO mode (1:1 Matching
Threshold), and ECO mode (1:N Matching Threshold).
ECO Mode Threshold
Set the matching threshold when authencang via ECO mode 1:1 matching mode and ECO
mode 1:N matching mode.
1:1 Matching Threshold
Set the matching threshold when authencang via ECO mode 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
1:N Matching Threshold
DS-K1T342 Series Face Recognion Terminal User Manual
107
Set the matching threshold when authencang via ECO mode 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate. The maximum
value is 100.
Set Recognion Area
Tap Conguraon → Smart → Area Conguraon to enter the page.
Drag the blue frame in the live video to adjust the recognion area. Only the face within the area
can be recognized by the system.
Drag the slider to congure the eecve area of face recognion.
Tap Save to save the sengs.
8.4.7 Video Intercom Sengs
Set Device ID
The device can be used as a door staon, outer door staon, or access control device. You should
set the device ID before usage.
Device ID Sengs
Tap Conguraon → Intercom → Device ID Sengs .
If you set the device type as Door Staon or Access Control Device, you can set the oor No. and
door staon No.
Tap Save to save the sengs aer the conguraon.
Figure 8-10 Device ID Sengs (Door Staon)
Device Type
The device can be used as a door staon, outer door staon, or access control device. Select a
device type from the drop-down list.
DS-K1T342 Series Face Recognion Terminal User Manual
108
Note
If you change the device type, you should reboot the device.
Floor No.
Set the device installed oor No.
Door Staon No.
Set the device installed oor No.
Note
If you change the No., you should reboot the device.
If you set the device type as Outer Door Staon, you can set the outer door staon No.
Figure 8-11 Device ID Sengs (Outer Door Staon)
Outer Door Staon No.
If you select outer door staon as the device type, you should enter a number between 1 and
99.
Note
If you change the No., you should reboot the device.
Congure SIP Parameters
Set the device's IP address and the SIP server's IP address. Aer seng the parameters, you can
communicate among the access control device, door staon, indoor staon, main staon, and the
plaorm.
DS-K1T342 Series Face Recognion Terminal User Manual
109
Note
Only the access control device and other devices or systems (such as door staon, indoor staon,
main staon, plaorm) are in the same IP segment, the two-way audio can be performed.
Tap Conguraon → Intercom → Linked Network Sengs .
Figure 8-12 Linked Network Sengs
Set the video intercom server IP and main staon's IP.
Tap Save.
Press Buon to Call
Steps
1.
Tap Conguraon → Intercom → Press Buon to Call to enter the sengs page.
2.
Set the buon to call.
-
Check Call Indoor Staon and set the indoor staon No to set the buon to call indoor
staon.
-
Check Call Management Center to set the buon to call management center.
8.4.8 Access Control Sengs
Set Door Parameters
Tap Conguraon → Access Control → Door Parameters .
DS-K1T342 Series Face Recognion Terminal User Manual
110
Figure 8-13 Door Parameters Sengs Page
DS-K1T342 Series Face Recognion Terminal User Manual
111
Click Save to save the sengs aer the conguraon.
Door No.
Select the device corresponded door No.
Name
You can create a name for the door.
Open Duraon
Set the door unlocking duraon. If the door is not opened for the set me, the door will be
locked.
Door Open Timeout Alarm
An alarm will be triggered if the door has not been closed within the congured me duraon.
Door Contact
You can set the door contact as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Closed.
Exit Buon Type
You can set the exit buon as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Open.
Door Lock Powering O Status
You can set the door lock status when the door lock is powering o. By default, it is Remain
Closed.
Extended Open Duraon
The door contact can be enabled with appropriate delay aer person with extended access
needs swipes her/his card.
Door Remain Open Duraon with First Person
Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows
mulple persons access the door or other authencaon acons.
Duress Code
The door can open by inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Super Password
The specic person can open the door by inpung the super password.
Note
The duress code and the super code should be dierent. And the digit ranges from 4 to 8.
Set RS-485 Parameters
You can set the RS-485 parameters including the peripheral, address, baud rate, etc.
DS-K1T342 Series Face Recognion Terminal User Manual
112
Tap Conguraon → Access Control → RS-485 .
Figure 8-14 RS-485 Page
Tap Save to save the sengs aer the conguraon.
Peripheral Type
Select a peripheral from the drop-down list according the actual situaon. You can select from
Card Reader, Extension Module, or Access Controller.
Note
Aer the peripheral is changed and saved, the device will reboot automacally.
RS-485 Address
Set the RS-485 Address according to your actual needs.
DS-K1T342 Series Face Recognion Terminal User Manual
113
Note
If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set
the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address
according to the door No.
Baud Rate
The baud rate when the devices are communicang via the RS-485 protocol.
Data Bit
The data bit when the devices are communicang via the RS-485 protocol.
Stop Bit
The stop bit when the devices are communicang via the RS-485 protocol.
Parity/Flow Ctrl/Communicaon Mode
Enabled by default.
Set Wiegand Parameters
You can set the Wiegand transmission direcon.
Steps
1.
Tap Conguraon → Access Control → Wiegand Sengs .
Figure 8-15 Wiegand Page
2.
Enable Wiegand to enable the Wiegand funcon.
3.
Set a transmission direcon.
Input
The device can connect a Wiegand card reader.
Output
DS-K1T342 Series Face Recognion Terminal User Manual
114
The can connect an external access controller. And the two devices will transmit the card No.
via Wiegand 26 or 34.
4.
Click Save to save the sengs.
Note
If you change the peripheral, and aer you save the device parameters, the device will reboot
automacally.
DS-K1T342 Series Face Recognion Terminal User Manual
115
Chapter 9 Operaon via Web Browser
9.1 Login
You can login via the web browser or the remote conguraon of the client soware.
Note
Make sure the device is acvated. For detailed informaon about acvaon, see Acvaon .
Login via Web Browser
Enter the device IP address in the address bar of the web browser and press Enter to enter the
login page.
Note
Make sure that the IP address starts with "Hps:".
Enter the device user name and the password. Click Login.
Login via Remote Conguraon of Client Soware
Download and open the client soware. Aer adding the device, click to enter the Conguraon
page.
9.2 Live View
You can view the live video of the device.
Aer logging in, you will enter the live view page. You can perform the live view, capture, video
recording, and other operaons.
DS-K1T342 Series Face Recognion Terminal User Manual
116
Figure 9-1 Live View Page
Funcon Descripons:
Select the image size when starng live view.
Set the volume when starng live view.
Note
If you adjust the volume when starng two-way audio, you may hear a repeated sounds.
You can capture image when starng live view.
Reserved funcon. You can zoom in the live view image.
Start or stop live view.
Start or stop video recording.
Select the streaming type when starng live view. You can select from the main stream and the
sub stream.
DS-K1T342 Series Face Recognion Terminal User Manual
117
Full screen view.
9.3 Person Management
Click and add the person's informaon, including the basic informaon, authencaon mode, card
and ngerprint. And you can also edit user informaon, view user picture and search user
informaon in the user list.
Click OK to save the person.
Add Basic Informaon
Click User → Add to enter the Add Person page.
Add the person's basic informaon, including the employee ID, the person's name, user level, oor
No., and room No.
Click OK to save the sengs.
Add Card
Click User → Add to enter the Add Person page.
Click Add Card, enter the Card No. and select the Property, and click OK to add the card.
Click OK to save the sengs.
Add Fingerprint
Click User → Add to enter the Add Person page.
Click Add Fingerprint, and press your nger on the ngerprint module of the device to add your
ngerprint.
Click Complete to save the sengs.
Add Face Picture
Click User → Add to enter the Add Person page.
Click + on the right to upload a face picture from the local PC.
Note
The picture format should be JPG or JPEG or PNG, and the size should be less than 200 K.
Click OK to save the sengs.
Set Permission Time
Click User → Add to enter the Add Person page.
Set Start Time and End Time.
Click OK to save the sengs.
Set Access Control
Click User → Add to enter the Add Person page.
DS-K1T342 Series Face Recognion Terminal User Manual
118
Aer check Administrator in Access Control, the added person can log in by authencang face.
You can click Add to enter the Floor No. and Room No. of access control, and click to delete it.
Click OK to save the sengs.
Add Authencaon Mode
Click User → Add to enter the Add Person page.
Set the authencaon type.
Click OK to save the sengs.
9.4 Search Event
Click Search to enter the Search page.
Figure 9-2 Search Page
Enter the search condions, including the employee ID, the name, the card No., the start me, and
the end me, and click Search.
The results will be displayed on the right panel.
9.5 Conguraon
9.5.1 Set Local Parameters
Set the live view parameters, record le saving path, and captured pictures saving path.
DS-K1T342 Series Face Recognion Terminal User Manual
119
Set Live View Parameters
Click Conguraon → Local to enter the Local page. Congure the stream type, the play
performance, auto start live view, and the image format and click Save.
Set Record File Saving Path
Click Conguraon → Local to enter the Local page. Select a record le size and select a saving
path from your local computer and click Save.
You can also click Open to open the le folder to view details.
Set Captured Pictures Saving Path
Click Conguraon → Local to enter the Local page. Select a saving path from your local computer
and click Save.
You can also click Open to open the le folder to view details.
9.5.2 View Device Informaon
View the device name, language, model, serial No., QR code, version, number of channels, IO
input, IO output, lock, RS-485 and alarm output, device capacity, etc.
Click Conguraon → System → System Sengs → Basic Informaon to enter the conguraon
page.
You can view the device name, language, model, serial No., QR code, version, number of channels,
IO input, IO output, lock, RS-485 and alarm output, device capacity, etc.
9.5.3 Set Time
Set the device's me zone, synchronizaon mode, and the device me.
Click Conguraon → System → System Sengs → Time Sengs .
DS-K1T342 Series Face Recognion Terminal User Manual
120
Figure 9-3 Time Sengs
Click Save to save the sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
NTP
You should set the NTP server's IP address, port No., and interval.
Manual
By default, the device me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
9.5.4 Set DST
Steps
1.
Click Conguraon → System → System Sengs → DST .
Figure 9-4 DST Page
2.
Check Enable DST.
3.
Set the DST start me, end me and bias me.
DS-K1T342 Series Face Recognion Terminal User Manual
121
4.
Click Save to save the sengs.
9.5.5 View Open Source Soware License
Go to Conguraon → System → System Sengs → About , and click View Licenses to view the
device license.
9.5.6 Upgrade and Maintenance
Reboot device, restore device parameters, and upgrade device version.
Reboot Device
Click Conguraon → System → Maintenance → Upgrade & Maintenance .
Figure 9-5 Upgrade and Maintenance Page
Click Reboot to start reboot the device.
Restore Parameters
Click Conguraon → System → Maintenance → Upgrade & Maintenance .
Restore All
All parameters will be restored to the factory sengs. You should acvate the device before
usage.
DS-K1T342 Series Face Recognion Terminal User Manual
122
Default
The device will restore to the default sengs, except for the device IP address and the user
informaon.
Unlink APP Account
Unlink the Hik-Connect account from the plaorm.
Import and Export Parameters
Click Conguraon → System → Maintenance → Upgrade & Maintenance .
Export
Click Export to export the logs or device parameters.
Note
You can import the exported device parameters to another device.
Import
Click and select the le to import. Click Import to start import conguraon le.
Upgrade
Click Conguraon → System → Maintenance → Upgrade & Maintenance .
Select an upgrade type from the drop-down list. Click and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
Note
Do not power o during the upgrading.
9.5.7 Log Query
You can search and view the device logs.
Go to Conguraon → System → Maintenance → Log Query .
Set the major and minor type of the log type. Set the start me and end me for searching, and
click Search.
The results will be displayed below, which including the No., me, the major type the minor type,
the channel No., the local/remote user informaon, the remote host IP, etc.
9.5.8 Security Mode Sengs
Set the security mode for logging in the client soware.
On the Device for Management page, click Conguraon → System → Security → Security
Service .
DS-K1T342 Series Face Recognion Terminal User Manual
123
Select a security mode from the drop-down list, and click Save.
Security Mode
High security level for user informaon vericaon when logging in the client soware.
Compable Mode
The user informaon vericaon is compable with the old client soware version when
logging in.
Enable SSH
To raise network security, disable SSH service. The conguraon is only used to debug the
device for the professionals.
Enable HTTP
In order to increase the network security level when vising websites, you can enable HTTP to
acquire a more secure and encrypted network communicaon environment. The
communicaon should authencated by identy and encrypon password aer enabling HTTP,
which is save.
9.5.9 Cercate Management
It helps to manage the server/client cercates and CA cercate.
Note
The funcon is only supported by certain device models.
Create and Install Self-signed Cercate
Steps
1.
Go to Conguraon → System → Security → Cercate Management .
2.
In the Cercate Files area, select a Cercate Type from the drop-down list.
3.
Click Create.
4.
Input cercate informaon.
5.
Click OK to save and install the cercate.
The created cercate is displayed in the Cercate Details area.
The cercate will be saved automacally.
6.
Download the cercate and save it to an asking le in the local computer.
7.
Send the asking le to a cercaon authority for signature.
8.
Import the signed cercate.
1) Select a cercate type in the Import Passwords area, and select a cercate from the local,
and click Install.
2) Select a cercate type in the Import Communicaon Cercate area, and select a cercate
from the local, and click Install.
DS-K1T342 Series Face Recognion Terminal User Manual
124
Install Other Authorized Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to Conguraon → System → Security → Cercate Management .
2.
In the Import Passwords and Import Communicaon Cercate areas, select cercate type
and upload cercate.
3.
Click Install.
Install CA Cercate
Before You Start
Prepare a CA cercate in advance.
Steps
1.
Go to Conguraon → System → Security → Cercate Management .
2.
Create an ID in the Inport CA Cercate area.
Note
The input cercate ID cannot be the same as the exisng ones.
3.
Upload a cercate le from the local.
4.
Click Install.
9.5.10 Change Administrator's Password
Steps
1.
Click Conguraon → User Management .
2.
Click
.
3.
Enter the old password and create a new password.
4.
Conrm the new password.
5.
Click OK.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can beer protect your product.
DS-K1T342 Series Face Recognion Terminal User Manual
125
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
9.5.11 View Device Arming/Disarming Informaon
View device arming type and arming IP address.
Go to Conguraon → Arming/Disarming Informaon .
You can view the device arming/disarming informaon. Click Refresh to refresh the page.
9.5.12 Network Sengs
Set TCP/IP, port, Wi-Fi parameters, report strategy, plaorm access and HTTP listening.
Note
Some device models do not support Wi-Fi sengs. Refer to the actual products when
conguraon.
Set Basic Network Parameters
Click Conguraon → Network → Basic Sengs → TCP/IP .
Set the parameters and click Save to save the sengs.
DHCP
If uncheck the funcon, you should set the IPv4 address, IPv4 subnet mask, IPv4 default
gateway, MTU, and the device port.
If you check the funcon, the system will allocate the IPv4 address, IPv4 subnet mask, and the
IPv4 default gateway automacally.
NIC Type
Select a NIC type from the drop-down list. By default, it is Auto.
DNS Server
Set the preferred DNS server and the Alternate DNS server according to your actual need.
Set Port Parameters
Set the HTTP, RTSP, HTTPS and Server port parmaeters.
Click Conguraon → Network → Basic Sengs → Port .
HTTP
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.0.0.65:81 in the browser for login.
DS-K1T342 Series Face Recognion Terminal User Manual
126
RTSP
It refers to the port of real-me streaming protocol.
HTTPS
Set the HTTPS for accessing the browser. Cercate is required when accessing.
Server
It refers to the port through which the client adds the device.
Set Wi-Fi Parameters
Set the Wi-Fi parameters for device wireless connecon.
Steps
Note
The funcon should be supported by the device.
1.
Click Conguraon → Network → Basic Sengs → Wi-Fi .
Figure 9-6 Wi-Fi Sengs Page
2.
Check Wi-Fi.
3.
Select a Wi-Fi
-
Click
of a Wi-Fi in the list and enter the Wi-Fi password.
-
Click Add, and enter the SSID, working mode, and encrypon type. Click Connect. When the
Wi-Fi is connected, click OK.
4.
Oponal: Set the WLAN parameters.
1) Click Network Sengs.
DS-K1T342 Series Face Recognion Terminal User Manual
127
2) Set the IP address, subnet mask, and default gateway. Or check Enable DHCP and the system
will allocate the IP address, subnet mask, and default gateway automacally.
5.
Click OK.
Report Strategy Sengs
You can set the center group for uploading the log via the ISUP protocol.
Go to Conguraon → Network → Basic Sengs → Report Strategy .
You can set the center group and the system will transfer logs via ISUP protocol. Click Save to save
the sengs.
Center Group
Select a center group from the drop-down list.
Main Channel
The device will communicate with the center via the main channel.
Note
N1 refers to wired network.
Plaorm Access
Plaorm access provides you an opon to manage the devices via plaorm.
Steps
1.
Click Conguraon → Network → Advanced → Plaorm Access to enter the sengs page.
2.
Select the Plaorm Access Mode.
Note
Hik-Connect is an applicaon for mobile devices. With the App, you can view live image of the
device, receive alarm nocaon and so on.
3.
Check the checkbox of Enable to enable the funcon.
4.
Oponal: Check the checkbox of Custom, and you can set the server address by yourself.
5.
Create a Stream Encrypon/Encrypon Key for the device.
Note
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a
combinaon of no less than 8 leers or numbers.
6.
Click Save to enable the sengs.
DS-K1T342 Series Face Recognion Terminal User Manual
128
Set ISUP Parameters
Set the ISUP parameters for accessing device via ISUP protocol.
Steps
Note
The funcon should be supported by the device.
1.
Click Conguraon → Network → Advanced Sengs → Plaorm .
2.
Select ISUP from the plaorm access mode drop-down list.
3.
Check Enable.
4.
Set the ISUP version, and view the alarm receiver type, server address, port, device ID, register
status.
Note
If you select 5.0 as the version, you should set the ISUP key as well.
5.
Set the ISUP listening parameters, including ISUP alarm center IP address/domain name, ISUP
alarm center URL, and ISUP alarm center port.
6.
Click Save.
Congure HTTP Listening
The device can send alarm informaon to the event alarm IP address or domain name via HTTP
protocol/HTTPS protocol.
Before You Start
The event alarm IP address or domain name should support the HTTP protocol/HTTPS protocol to
receive the alarm informaon.
Note
The funcon should be supported by the device.
Steps
1.
Click Conguraon → Network → Advanced → HTTP Listening .
2.
Edit the event alarm IP address or domain name, URL, port, and protocol.
3.
Oponal: Click Default to reset the event alarm IP address or domain name.
4.
Click Save.
9.5.13 Set Video and Audio Parameters
Set the image quality, resoluon, and the device volume.
DS-K1T342 Series Face Recognion Terminal User Manual
129
Set Video Parameters
Click Conguraon → Video/Audio → Video .
Figure 9-7 Video Sengs Page
Set the stream type, the video type, the bitrate type, the frame rate, the Max. bitrate, and the
video encoding.
Click Save to save the sengs aer the conguraon.
Set Audio Parameters
Click Conguraon → Video/Audio → Audio .
Set the audio stream type and audio encoding.
Drag the slider to adjust the device input and output volume.
You can also enable voice prompt.
Click Save to save the sengs aer the conguraon.
Note
The funcons vary according to dierent models. Refers to the actual device for details.
DS-K1T342 Series Face Recognion Terminal User Manual
130
9.5.14 Customize Audio Content
Customize the output audio content when authencaon succeeded and failed.
Steps
1.
Click Conguraon → Video/Audio → Prompt .
Figure 9-8 Customize Audio Content
2.
Select Prompt as TTS(Text to Speech) to turn the text to audio content.
3.
Or you can select Prompt as Custom Prompt Imporng.
1) Select Custom Type or you can import your custom prompt from local PC.
2) You can view the imporng status of the custom prompts in the list.
Note
The audio le shall be in WAV format and mono, and the sampling rate shall be 8 K or 16 K. The
amplitude of the audio le shall not exceed -3dB, and the size of the audio le size shall not
exceed 512 K.
4.
Select me schedule.
5.
Enable the funcon.
6.
Set the appellaon.
7.
Set the me period when authencaon succeeded.
1) Click Add.
2) Set the me duraon and the language.
DS-K1T342 Series Face Recognion Terminal User Manual
131
Note
If authencaon is succeeded in the congured me duraon, the device will broadcast the
congured content.
3) Enter the audio content.
4) Oponal: Repeat substep 1 to 3.
5) Oponal: Click to delete the congured me duraon.
8.
Set the me duraon when authencaon failed.
1) Click Add.
2) Set the me duraon and the language.
Note
If authencaon is failed in the congured me duraon, the device will broadcast the
congured content.
3) Enter the audio content.
4) Oponal: Repeat substep 1 to 3.
5) Oponal: Click to delete the congured me duraon.
9.
Oponal: Add holiday schedule.
1) Click Add to add holiday schedule.
2) Repeat step 3 to 6.
10.
Click Save to save the sengs.
9.5.15 Set Image Parameters
Set the video standard, brightness, contrast, and saturaon.
Steps
1.
Click Conguraon → Image Adjustment .
2.
Congure the parameters to adjust the image.
Video Standard
Set the video frame rate when performing live view remotely. Aer changing the standard,
you should reboot the device to take eect.
PAL
25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East
countries, Europe countries, etc.
NTSC
30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the
Philippines, etc.
Brightness/Contrast/Saturaon
Drag the block or enter the value to adjust the live video's brightness, contrast and
saturaon.
DS-K1T342 Series Face Recognion Terminal User Manual
132
Start/end recording video.
Capture the image.
3.
Click Default to restore the parameters to the default sengs.
9.5.16 Set Supplement Light Brightness
Set the device supplement light brightness.
Steps
1.
Click Conguraon → Image → Supplement Light Parameters .
Figure 9-9 Supplement Light Sengs Page
2.
Select a supplement light type and mode from the drop-down list. If you select the mode as ON,
you should set the brightness.
9.5.17 Time and Aendance Sengs
If you want to track and monitor when the persons start/stop work and monitor their working
hours and late arrivals, early departures, me taken on breaks, and absenteeism, you can add the
person to the shi group and assign a shi schedule (a rule for the aendance dening how the
DS-K1T342 Series Face Recognion Terminal User Manual
133
schedule repeats, the shi type, break sengs, and the card swiping rule.) to the shi group to
dene the aendance parameters for the persons in the shi group.
Disable Aendance Mode via Web
Disable the aendance mode and the system will not display the aendance status on the inial
page.
Steps
1.
Click Conguraon → Aendance to enter the sengs page.
2.
Set the Aendance Mode as Disable.
Result
You will not view or congure the aendance status on the inial page. And the system will follow
the aendance rule that congured on the plaorm.
Time Sengs
Steps
1.
Click Conguraon → Time Sengs to enter the sengs page.
2.
Select Status Type.
3.
Oponal: Edit Schedule Name according to the actual needs.
4.
Drag mouse to set the schedule.
Note
Set the schedule from Monday to Sunday according to the actual needs.
5.
Oponal: Select a meline and click Delete. Or click Delete All to clear the sengs.
6.
Click Save.
Set Manual Aendance via Web
Set the aendance mode as manual, and you should select a status manually when you take
aendance.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Aendance to enter the sengs page.
2.
Set the Aendance Mode as Manual.
3.
Enable the Aendance Status Required and set the aendace status lasts duraon.
4.
Enable a group of aendance status.
DS-K1T342 Series Face Recognion Terminal User Manual
134
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
Result
You should select an aendance status manually aer authencaon.
Note
If you do not select a status, the authencaon will be failed and it will not be marked as a valid
aendance.
Set Auto Aendance via Web
Set the aendance mode as auto, and you can set the aendance status and its available schedule.
The system will automacally change the aendance status according to the congured schedule.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Aendance to enter the sengs page.
2.
Set the Aendance Mode as Auto.
3.
Enable the Aendance Status funcon.
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
6.
Set the status' schedule. Refers to Time Sengs for details.
Set Manual and Auto Aendance via Web
Set the aendance mode as Manual and Auto, and the system will automacally change the
aendance status according to the congured schedule. At the same me you can manually
change the aendance status aer the authencaon.
Before You Start
Add at least one user, and set the user's authencaon mode. For details, see User Management.
Steps
1.
Click Conguraon → Aendance to enter the sengs page.
2.
Set the Aendance Mode as Manual and Auto.
3.
Enable the Aendance Status funcon.
DS-K1T342 Series Face Recognion Terminal User Manual
135
4.
Enable a group of aendance status.
Note
The Aendance Property will not be changed.
5.
Oponal: Select an status and change its name if required.
6.
Set the status' schedule. Refers to Time Sengs for details.
Result
On the inial page and authencate. The authencaon will be marked as the congured
aendance status according to the schedule. If you tap the edit icon on the result tab, you can
select a status to take aendance manually, the authencaon will be marked as the edited
aendance status.
Example
If set the Break Out as Monday 11:00, and Break In as Monday 12:00, the valid user's
authencaon from Monday 11:00 to 12:00 will be marked as break.
9.5.18 General Sengs
Set Authencaon Parameters
Click Conguraon → General → Authencaon Sengs .
Note
The funcons vary according to dierent models. Refers to the actual device for details.
DS-K1T342 Series Face Recognion Terminal User Manual
136
Figure 9-10 Set Authencaon Parameters
Click Save to save the sengs aer the conguraon.
Device Type
Select Main Card Reader or Sub Card Reader from the drop-down list.
Main Card Reader
You can congure the device card reader's parameters.
Sub Card Reader
You can congure the connected peripheral card reader's parameters.
If select Main Card Reader:
Card Reader Type/Card Reader Descripon
Get card reader type and descripon. They are read-only.
DS-K1T342 Series Face Recognion Terminal User Manual
137
Enable Card Reader
Enable the card reader's funcon.
Authencaon
Select an authencaon mode according to your actual needs from the drop-down list.
Recognion Interval
You can set the interval between 2 connuous recognion of a same person during the
authencaon. In the congured interval, Person A can only recognized once. If another person
(Person B) has recognized during the interval, Person A can recognized again.
Authencaon Interval
You can set the authencaon interval of the same person when authencang. The same
person can only authencate once in the congured interval. A second authencaon will be
failed.
Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Max. Authencaon Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Enable Tampering Detecon
Enable the an-tamper detecon for the card reader.
Enable Card No. Reversing
The read card No. will be in reverse sequence aer enabling the funcon.
If select Sub Card Reader:
Card Reader Type/Card Reader Descripon
Get card reader type and descripon. They are read-only.
Enable Card Reader
Enable the card reader's funcon.
Authencaon
Select an authencaon mode according to your actual needs from the drop-down list.
Recognion Interval
If the interval between card presenng of the same card is less than the congured value, the
card presenng is invalid.
Authencaon Interval
You can set the authencaon interval of the same person when authencang. The same
person can only authencate once in the congured interval. A second authencaon will be
failed.
Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
DS-K1T342 Series Face Recognion Terminal User Manual
138
Max. Authencaon Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Communicaon with Controller Every
When the access control device cannot connect with the card reader for longer than the set
me, the card reader will turn oine automacally.
Max. Interval When Entering Password
When you entering the password on the card reader, if the interval between pressing two digits
is longer than the set value, the digits you pressed before will be cleared automacally.
OK LED Polarity/Error LED Polarity
Set OK LED Polarity/Error LED Polarity of the access control device according to the card reader
parameters. Generally, adopts the default sengs.
Enable Tampering Detecon
Enable the an-tamper detecon for the card reader.
Set Privacy Parameters
Set the event storage type, picture upload and storage parameters, and the picture clearing
parameters.
Go to Conguraon → General → Privacy
Event Storage Sengs
Select a method to delete the event. You can select from Delete Old Events Periodically, Delete
Old Events by Specied Time, or Overwring.
Delete Old Events Periodically
Drag the block or enter number to set the period for event deleng. All events will be deleted
according to the congured me duraon.
Delete Old Events by Specied Time
Set a me and all events will be deleted on the congured me.
Overwring
The earliest 5% events will be deleted when the system detects the stored events has been over
95% of the full space.
Authencaon Sengs
Display Authencaon Result
You can check Face Picture, Name, and Employee ID, to display the authencaon result.
Name De-idencaon
You can check Name De-idencaon, and the whole name will not be displayed.
DS-K1T342 Series Face Recognion Terminal User Manual
139
Picture Uploading and Storage
Upload Captured Picture When Authencang
Upload the pictures captured when authencang to the plaorm automacally.
Save Captured Picture When Authencang
If you enable this funcon, you can save the picture when authencang to the device.
Save Registered Picture
The registered face picture will be saved to the system if you enable the funcon.
Upload Picture Aer Linked Capture
Upload the pictures captured by linked camera to the plaorm automacally.
Save Pictures Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Clear All Pictures in Device
Note
All pictures cannot be restored once they are deleted.
Clear Registered Face Pictures
All registered pictures in the device will be deleted.
Clear Captured Pictures
All captured pictures in the device will be deleted.
Set Face Recognion Parameters
You can set face recognion parameters for accessing.
Click Conguraon → General → Face Recognion Parameters .
You can set Working Mode as Access Control Mode. The access control mode is the device normal
mode. You should authencate your credenal for accessing.
Enable Blocklist Authencaon.
Click Save to save the sengs aer the conguraon.
Set Card Security
Click Conguraon → General → Card Security to enter the sengs page.
Set the parameters and click Save.
Enable NFC Card
DS-K1T342 Series Face Recognion Terminal User Manual
140
In order to prevent the mobile phone from geng the data of the access control, you can
enable NFC card to increase the security level of the data.
Enable M1 Card
Enable M1 card and authencateing by presenng M1 card is available.
M1 Card Encrypon
Sector
M1 card encrypon can improve the security level of authencaon.
Enable the funcon and set the encrypon sector. By default, Sector 13 is encrypted. It is
recommended to encrypt sector 13.
Enable EM Card
Enable EM card and authencang by presenng EM card is available.
Note
If the peripheral card reader supports presenng EM card, the funcon is also supported to
enable/disable the EM card funcon.
Enable DESFire Card
The device can read the data from DESFire card when enabling the DESFire card funcon.
DESFire Card Read Content
Aer enable the DESFire card content reading funcon, the device can read the DESFire card
content.
Enable FeliCa Card
The device can read the data from FeliCa card when enabling the FeliCa card funcon.
Set Card Authencaon Parameters
Set the card reading content when authencate via card on the device.
Go to Conguraon → General → Card Authencaon Sengs .
Select a card authencaon mode and click Save.
Full Card No.
All card No. will be read.
Wiegand 26 (3 bytes)
The device will read card via Wiegand 26 protocol (read 3 bytes).
Wiegand 34 (4 bytes)
The device will read card via Wiegand 34 protocol (read 4 bytes).
DS-K1T342 Series Face Recognion Terminal User Manual
141
Congure Authencaon Result Text
Steps
1.
Go to Conguraon → General → Authencaon Result Text .
Figure 9-11 Authencaon Result Text
2.
Enable Customize Authencaon Result Text.
3.
Enter custom texts.
4.
Click Save.
9.5.19 Video Intercom Sengs
Set Video Intercom Parameters
The device can be used as a door staon, outer door staon, or access control device. You should
set the device No. before usage.
Click Conguraon → Intercom → Device No. .
If set the device type as Door Staon or Access Control Device, you can set the oor No., door
staon No., and click Advanced Sengs to set Phase No., Building No., and Unit No.
Click Save to save the sengs aer the conguraon.
Device Type
The device can be used as a door staon or outer door staon. Select a device type from the
drop-down list.
Note
If you change the device type, you should reboot the device.
Floor No.
Set the device installed oor No.
DS-K1T342 Series Face Recognion Terminal User Manual
142
Door Staon No.
Set the device installed oor No.
Note
If you change the No., you should reboot the device.
Phase No.
Set the device phase No.
Building No.
Set the device building No.
Unit No.
Set the device unit No.
Note
If you change the No., you should reboot the device.
If set the device type as Outer Door Staon, you can set the period No., outer door staon No.,
and community No.
Outer Door Staon No.
If you select outer door staon as the device type, you should enter a number between 1 and
99.
Note
If you change the No., you should reboot the device.
Phase No.
Set the device phase No.
Congure SIP Parameters
Set the device's IP address and the SIP server's IP address. Aer seng the parameters, you can
communicate among the access control device, door staon, indoor staon, main staon, and the
plaorm.
Note
Only the access control device and other devices or systems (such as door staon, indoor staon,
main staon, plaorm) are in the same IP segment, the two-way audio can be performed.
Go to Conguraon → Intercom → Linked Network Sengs .
Set the main staon's IP address and SIP server's IP address.
Click Save.
DS-K1T342 Series Face Recognion Terminal User Manual
143
Press Buon to Call
Steps
1.
Click Conguraon → Intercom → Press Buon to Call .
2.
Set the parameters.
-
Edit call No. for every buon.
-
Check Call Management Center to set the buon calling center.
Note
If you check Call Management Center and set the call No. as well, call management center has
higher privilege than call No.
9.5.20 Access Control Sengs
Set Door Parameters
Click Conguraon → Access Control → Door Parameters .
Figure 9-12 Door Parameters Sengs Page
Click Save to save the sengs aer the conguraon.
Door No.
DS-K1T342 Series Face Recognion Terminal User Manual
144
Select the device corresponded door No.
Name
You can create a name for the door.
Open Duraon
Set the door unlocking duraon. If the door is not opened for the set me, the door will be
locked.
Door Open Timeout Alarm
An alarm will be triggered if the door has not been closed within the congured me duraon.
Door Contact
You can set the door contact as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Closed.
Exit Buon Type
You can set the exit buon as Remain Open or Remain Closed according to your actual needs.
By default, it is Remain Open.
Door Lock Powering O Status
You can set the door lock status when the door lock is powering o. By default, it is Remain
Closed.
Extended Open Duraon
The door contact can be enabled with appropriate delay aer person with extended access
needs swipes her/his card.
Door Remain Open Duraon with First Person
Set the door open duraon when rst person is in. Aer the rst person is authorized, it allows
mulple persons access the door or other authencaon acons.
Duress Code
The door can open by inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Super Password
The specic person can open the door by inpung the super password.
Note
The duress code and the super code should be dierent.
Set RS-485 Parameters
You can set the RS-485 parameters including the peripheral, address, baud rate, etc.
Click Conguraon → Access Control → RS-485 Sengs .
Check Enable RS-485, and set the parameters.
DS-K1T342 Series Face Recognion Terminal User Manual
145
Click Save to save the sengs aer the conguraon.
No.
Set the RS-485 No.
Peripheral Type
Select a peripheral from the drop-down list according the actual situaon. You can select from
Card Reader, Extension Module, Access Controller, or Disable.
Note
Aer the peripheral is changed and saved, the device will reboot automacally.
RS-485 Address
Set the RS-485 Address according to your actual needs.
Note
If you select Access Controller: If connect the device to a terminal via the RS-485 interface, set
the RS-485 address as 2. If you connect the device to a controller, set the RS-485 address
according to the door No.
Baud Rate
The baud rate when the devices are communicang via the RS-485 protocol.
Set Wiegand Parameters
You can set the Wiegand transmission direcon.
Steps
Note
Some device models do not support this funcon. Refer to the actual products when conguraon.
1.
Click Conguraon → Access Control → Wiegand Sengs .
DS-K1T342 Series Face Recognion Terminal User Manual
146
Figure 9-13 Wiegand
2.
Check Wiegand to enable the Wiegand funcon.
3.
Set a transmission direcon.
Output
The can connect an external access controller. And the two devices will transmit the card No.
via Wiegand 26 or 34.
4.
Click Save to save the sengs.
Note
If you change the peripheral, and aer you save the device parameters, the device will reboot
automacally.
9.5.21 Set Biometric Parameters
Set Basic Parameters
Click Conguraon → Smart → Smart .
DS-K1T342 Series Face Recognion Terminal User Manual
147
Figure 9-14 Set Face Parameters
DS-K1T342 Series Face Recognion Terminal User Manual
148
Note
The funcons vary according to dierent models. Refers to the actual device for details.
Click Save to save the sengs aer the conguraon.
Face An-spoong
Enable or disable the live face detecon funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not.
Note
Biometric recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use mulple authencaon modes.
Live Face Detecon Security Level
Aer enabling the face an-spoong funcon, you can set the matching security level when
performing live face authencaon.
Recognion Distance
Select the distance between the authencang user and the device camera.
Applicaon Mode
Select either others or indoor according to actual environment.
Face Recognion Mode
Normal Mode
Recognize face via the camera normally.
Deep Mode
In the deep mode, you can add the face pictures only via the user adding funcon of the
device or the enrollment staon. It is not supported to add face pictures via pictures
imporng.
Note
In the deep mode, you can add the face pictures only via the device or the enrollment staon. It
is not supported to add face pictures via pictures imporng.
Connuous Face Recognion Interval
Set the me interval between two connuous face recognions when authencang.
Pitch Angle
The maximum pitch angle when starng face authencaon.
Yaw Angle
The maximum yaw angle when starng face authencaon.
Face Grading
Set the face grading according to your needs.
DS-K1T342 Series Face Recognion Terminal User Manual
149
1:1 Matching Threshold
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
1:N Matching Threshold
Set the matching threshold when authencang via 1:N matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate.
Face Recognion Timeout Value
Set the meout value when face recognizing. If the face recognion me is longer than the
congured value, the system will pop up a prompt.
Face with Mask Detecon
Aer enabling the face with mask detecon, the system will recognize the captured face with
mask picture. You can set face with mask1:N matching threshold, its ECO mode, and the
strategy.
None
If the person do not wear a face mask when authencang, the device will not prompt a
nocaon.
Reminder of Wearing
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door will open.
Must Wear
If the person do not wear a face mask when authencang, the device prompts a
nocaon and the door keeps closed.
Face with Mask & Face (1:1)
Set the matching value when authencang with face mask via 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask 1:N Matching Threshold
Set the matching threshold when authencang with face mask via 1:N matching mode. The
larger the value, the smaller the false accept rate and the larger the false rejecon rate.
ECO Mode
Aer enabling the ECO mode, the device will use the IR camera to authencate faces in the low
light or dark environment. And you can set the ECO mode threshold, ECO mode (1:N), and ECO
mode (1:1).
ECO Mode Threshold
Set the ECO mode's threshold. The larger the value, the easier the device entering the ECO
mode.
ECO Mode (1:1)
DS-K1T342 Series Face Recognion Terminal User Manual
150
Set the matching threshold when authencang via ECO mode 1:1 matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate.
ECO Mode (1:N)
Set the matching threshold when authencang via ECO mode 1:N matching mode. The larger
the value, the smaller the false accept rate and the larger the false rejecon rate
Face with Mask & Face (1:1 ECO)
Set the matching value when authencang with face mask via ECO mode 1:1 matching mode.
The larger the value, the smaller the false accept rate and the larger the false rejecon rate.
Face with Mask 1:N Matching Threshold (ECO Mode)
Set the matching threshold when authencang with face mask via ECO mode 1:N matching
mode. The larger the value, the smaller the false accept rate and the larger the false rejecon
rate.
Fingerprint Security Level
Select the ngerprint security level.
The higher is the security level, the lower is the false acceptance rate (FAR).
Set Recognion Area
Click Conguraon → Smart → Area Conguraon .
Drag the yellow frame in the live video to adjust the recognion area. Only the face within the area
can be recognized by the system.
Set Area Conguraon, Margin (Le), Margin (Right), Margin (Top) and Margin (Boom) as
desired.
Click Save to save the sengs.
Click or to record videos or capture pictures.
9.5.22 Set Noce Publicaon
You can set the theme for the device.
Click Conguraon → Theme → Media Database , click + Add, and click Upload to upload the
material to the media library.
Click Conguraon → Theme → Theme .
DS-K1T342 Series Face Recognion Terminal User Manual
151
Figure 9-15 Theme Page
Display Mode
You can select display theme for device authencaon. You can select Display Mode as Simple
or Normal. When you select Simple, the informaon of name, ID, face picture will be not
displayed.
Sleep
Enable Sleep and the device will enter the sleep mode when no operaon within the congured
sleep me.
Theme Management
You can click + Add Program in the frame and upload the screen saver pictures from the local
PC.
Note
By now, there is only one theme can be added.
Play Schedule
DS-K1T342 Series Face Recognion Terminal User Manual
152
Aer you have created a theme, you can select the theme and draw a schedule on the me line
to set the theme play schedule.
Select the drawn schedule and you can edit the exact start and end me.
Select the drawn schedule and you can click Delete or Delete All to delete the schedule.
Slide Show Interval
Drag the block or enter the number to set the slide show interval. The picture will be changed
according to the interval.
DS-K1T342 Series Face Recognion Terminal User Manual
153
Chapter 10 Client Soware Conguraon
10.1 Conguraon Flow of Client Soware
Follow the ow diagram below to congure on the client soware.
Figure 10-1 Flow Diagram of Conguraon on Client Soware
10.2 Device Management
The client supports managing access control devices and video intercom devices.
DS-K1T342 Series Face Recognion Terminal User Manual
154
Example
You can control entrance & exit and manage aendance aer adding access control devices to the
client; you can perform video intercom with the indoor staons and door staons.
10.2.1 Add Device
The client provides three device adding modes including by IP/domain, IP segment, and EHome
protocol. The client also supports imporng mulple devices in a batch when there are large
amount of devices to be added.
Add Device by IP Address or Domain Name
If you know the IP address or domain name of the device to add, you can add devices to the client
by specifying the IP address (or domain name), user name, password, etc.
Steps
1.
Enter Device Management module.
2.
Click Device tab on the top of the right panel.
The added devices are displayed on the right panel.
3.
Click Add to open the Add window, and then select IP/Domain as the adding mode.
4.
Enter the required informaon.
Name
Create a descripve name for the device. For example, you can use a nickname that can show
the locaon or feature of the device.
Address
The IP address or domain name of the device.
Port
The devices to add share the same port number. The default value is 8000.
User Name
Enter the device user name. By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
DS-K1T342 Series Face Recognion Terminal User Manual
155
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
5.
Oponal: Check Transmission Encrypon (TLS) to enable transmission encrypon using TLS
(Transport Layer Security) protocol for security purpose.
Note
●
This funcon should be supported by the device.
●
If you have enabled Cercate Vericaon, you should click Open Cercate Directory to
open the default folder, and copy the cercate le exported from the device to this default
directory to strengthen the security. See for details about enabling cercate vericaon.
●
You can log into the device to get the cercate le by web browser.
6.
Check Synchronize Time to synchronize the device me with the PC running the client aer
adding the device to the client.
7.
Oponal: Check Import to Group to create a group by the device name, and import all the
channels of the device to this group.
Example
For access control device, its access points, alarm inputs/outputs, and encoding channels (if
exist) will be imported to this group.
8.
Finish adding the device.
-
Click Add to add the device and back to the device list page.
-
Click Add and New to save the sengs and connue to add other device.
Import Devices in a Batch
You can add mulple devices to the client in a batch by entering the device parameters in a pre-
dened CSV le.
Steps
1.
Enter the Device Management module.
2.
Click Device tab on the top of the right panel.
3.
Click Add to open the Add window, and then select Batch Import as the adding mode.
4.
Click Export Template and then save the pre-dened template (CSV le) on your PC.
5.
Open the exported template le and enter the required informaon of the devices to be added
on the corresponding column.
Note
For detailed descripon of the required elds, refer to the introducons in the template.
Adding Mode
Enter 0 or 1 or 2.
DS-K1T342 Series Face Recognion Terminal User Manual
156
Address
Edit the address of the device.
Port
Enter the device port number. The default port number is 8000.
User Name
Enter the device user name. By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Import to Group
Enter 1 to create a group by the device name. All the channels of the device will be imported
to the corresponding group by default. Enter 0 to disable this funcon.
6.
Click and select the template le.
7.
Click Add to import the devices.
10.2.2 Reset Device Password
If you forgot the password of the detected online devices, you can reset the device password via
the client.
Steps
1.
Enter Device Management page.
2.
Click Online Device to show the online device area.
All the online devices sharing the same subnet will be displayed in the list.
3.
Select the device from the list and click on the Operaon column.
4.
Reset the device password.
-
Click Generate to pop up the QR Code window and click Download to save the QR code to
your PC. You can also take a photo of the QR code to save it to your phone. Send the picture
to our technical support.
DS-K1T342 Series Face Recognion Terminal User Manual
157
Note
For the following operaons for reseng the password, contact our technical support.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
10.2.3 Manage Added Devices
Aer adding devices to device list, you can manage the added devices including eding device
parameters, remote conguraon, viewing device status, etc.
Table 10-1 Manage Added Devices
Edit Device Click to edit device informaon including device name, address, user
name, password, etc.
Delete Device Check one or more devices, and click Delete to delete the selected
devices.
Remote Conguraon Click to set remote conguraon of the corresponding device. For
details, refer to the user manual of device.
View Device Status Click to view device status, including door No., door status, etc.
Note
For dierent devices, you will view dierent informaon about device
status.
View Online User Click to view the details of online user who access the device,
including user name, user type, IP address and login me.
Refresh Device
Informaon
Click to refresh and get the latest device informaon.
DS-K1T342 Series Face Recognion Terminal User Manual
158
10.3 Group Management
The client provides groups to manage the added resources in dierent groups. You can group the
resources into dierent groups according to the resources' locaons.
Example
For example, on the 1st oor, there mounted 16 doors, 64 alarm inputs, and 16 alarm outputs. You
can organize these resources into one group (named 1st Floor) for convenient management. You
can control door status, and do some other operaons of the devices aer managing the resources
by groups.
10.3.1 Add Group
You can add group to organize the added device for convenient management.
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
3.
Create a group.
-
Click Add Group and enter a group name as you want.
-
Click Create Group by Device Name and select an added device to create a new group by the
name of the selected device.
Note
The resources (such as alarm inputs/outputs, access points, etc.) of this device will be
imported to the group by default.
10.3.2 Import Resources to Group
You can import the device resources (such as alarm inputs/outputs, access points, etc.) to the
added group in a batch.
Before You Start
Add a group for managing devices. Refer to Add Group .
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
3.
Select a group from the group list and select the resource type as Access Point, Alarm Input,
Alarm Output, etc.
4.
Click Import.
5.
Select the thumbnails/names of the resources in the thumbnail/list view.
DS-K1T342 Series Face Recognion Terminal User Manual
159
Note
You can click or to switch the resource display mode to thumbnail view or to list view.
6.
Click Import to import the selected resources to the group.
10.4 Person Management
You can add person informaon to the system for further operaons such as access control, video
intercom, me and aendance, etc. You can manage the added persons such as issuing cards to
them in a batch, imporng and exporng person informaon in a batch, etc.
10.4.1 Add Organizaon
You can add an organizaon and import person informaon to the organizaon for eecve
management of the persons. You can also add a surbodinate organizaon for the added one.
Steps
1.
Enter Person module.
2.
Select a parent organizaon in the le column and click Add in the upper-le corner to add an
organizaon.
3.
Create a name for the added organizaon.
Note
Up to 10 levels of organizaons can be added.
4.
Oponal: Perform the following operaon(s).
Edit Organizaon Hover the mouse on an added organizaon and click
to edit its name.
Delete
Organizaon
Hover the mouse on an added organizaon and click
to delete it.
Note
●
The lower-level organizaons will be deleted as well if you delete an
organizaon.
●
Make sure there is no person added under the organizaon, or the
organizaon cannot be deleted.
Show Persons in
Sub Organizaon
Check Show Persons in Sub Organizaon and select an organizaon to
show persons in its sub organizaons.
10.4.2 Import and Export Person Idenfy Informaon
You can import the informaon and pictures of mulple persons to the client soware in a batch.
Meanwhile, you can also export the person informaon and pictures and save them in your PC.
DS-K1T342 Series Face Recognion Terminal User Manual
160
Import Person Informaon
You can enter the informaon of mulple persons in a predened template (CSV/Excel le) to
import the informaon to the client in a batch.
Steps
1.
Enter the Person module.
2.
Select an added organizaon in the list, or click Add in the upper-le corner to add an
organizaon and then select it.
3.
Click Import to open the Import panel.
4.
Select Person Informaon as the imporng mode.
5.
Click Download Template for Imporng Person to download the template.
6.
Enter the person informaon in the downloaded template.
Note
●
If the person has mulple cards, separate the card No. with semicolon.
●
Items with asterisk are required.
●
By default, the Hire Date is the current date.
7.
Click to select the CSV/Excel le with person informaon from local PC.
8.
Click Import to start imporng.
Note
●
If a person No. already exists in the client's database, delete the exisng informaon before
imporng.
●
You can import informaon of no more than 2,000 persons.
Import Person Pictures
Aer imporng face pictures for the added persons to the client, the persons in the pictures can be
idened by an added face recognion terminal. You can either import person pictures one by
one, or import mulple pictures at a me according to your need.
Before You Start
Be sure to have imported person informaon to the client beforehand.
Steps
1.
Enter the Person module.
2.
Select an added organizaon in the list, or click Add in the upper-le corner to add an
organizaon and then select it.
3.
Click Import to open the Import panel and check Face.
4.
Oponal: Enable Verify by Device to check whether face recognion device managed in the
client can recognize the face in the photo.
5.
Click
to select a face picture le.
DS-K1T342 Series Face Recognion Terminal User Manual
161
Note
●
The (folder of) face pictures should be in ZIP format.
●
Each picture le should be in JPG format and should be no larger than 200 KB.
●
Each picture le should be named as "Person ID_Name". The Person ID should be the same
with that of the imported person informaon.
6.
Click Import to start imporng.
The imporng progress and result will be displayed.
Export Person Informaon
You can export the added persons' informaon to local PC as a CSV/Excel le.
Before You Start
Make sure you have added persons to an organizaon.
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' informaon will be exported if you do not select any organizaon.
3.
Click Export to open the Export panel.
4.
Check Person Informaon as the content to export.
5.
Check desired items to export.
6.
Click Export to save the exported le in CSV/Excel le on your PC.
Export Person Pictures
You can export face picture le of the added persons and save in your PC.
Before You Start
Make sure you have added persons and their face pictures to an organizaon.
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' face pictures will be exported if you do not select any organizaon.
3.
Click Export to open the Export panel and check Face as the content to export.
4.
Click Export to start exporng.
DS-K1T342 Series Face Recognion Terminal User Manual
162
Note
●
The exported le is in ZIP format.
●
The exported face picture is named as "Person ID_Name_0" ("0" is for a full-frontal face).
10.4.3 Get Person Informaon from Access Control Device
If the added access control device has been congured with person informaon (including person
details, ngerprint, and issued card informaon), you can get the person informaon from the
device and import them to the client for further operaons.
Steps
Note
●
If the person name stored in the device is empty, the person name will be lled with the issued
card No. aer imporng to the client.
●
If the card number or person ID (employee ID) stored on the device already exists in the client
database, the person with this card number or person ID will not be imported to the client.
1.
Enter Person module.
2.
Select an organizaon to import the persons.
3.
Click Get from Device.
4.
Select an added access control device or the enrollment staon from the drop-down list.
Note
If you select the enrollment staon, you should click Login, and set IP address, port No., user
name and password of the device.
5.
Click Import to start imporng the person informaon to the client.
Note
Up to 2,000 persons and 5,000 cards can be imported.
The person informaon, including person details, person's ngerprint informaon (if
congured), and the linked cards (if congured), will be imported to the selected organizaon.
10.4.4 Issue Cards to Persons in Batch
The client provides a convenient way to issue cards to mulple persons in a batch.
Steps
1.
Enter Person module.
2.
Click Batch Issue Cards.
All the added persons with no card issued will be displayed in the right panel.
DS-K1T342 Series Face Recognion Terminal User Manual
163
3.
Oponal: Enter key words (name or person ID) in the input box to lter the person(s) that need
issuing cards.
4.
Oponal: Click Sengs to set the card issuing parameters. For details, refer to Issue a Card by
Local Mode.
5.
Click Inialize to inialize the card enrollment staon or card reader to make it ready for issuing
cards.
6.
Click the Card No. column and enter the card number.
-
Place the card on the card enrollment staon.
-
Swipe the card on the card reader.
-
Manually enter the card number and press the Enter key.
The person(s) in the list will be issued with card(s).
10.4.5 Report Card Loss
If the person lost his/her card, you can report the card loss so that the card's related access
authorizaon will be inacve.
Steps
1.
Enter Person module.
2.
Select the person you want to report card loss for and click Edit to open the Edit Person window.
3.
In the Credenal → Card panel, click
on the added card to set this card as lost card.
Aer reporng card loss, the access authorizaon of this card will be invalid and inacve. Other
person who gets this card cannot access the doors by swiping this lost card.
4.
Oponal: If the lost card is found, you can click to cancel the loss.
Aer cancelling card loss, the access authorizaon of the person will be valid and acve.
5.
If the lost card is added in one access group and the access group is applied to the device
already, aer reporng card loss or cancelling card loss, a window will pop up to nofy you to
apply the changes to the device. Aer applying to device, these changes can take eect on the
device.
10.4.6 Set Card Issuing Parameters
The client provides two modes for reading a card's number: via card enrollment staon or via the
card reader of the access control device. If a card enrollment staon is available, connect it to the
PC running the client by USB interface or COM, and place the card on the card enrollment to read
the card number. If not, you can also swipe the card on the card reader of the added access control
device to get the card number. As a result, before issuing a card to one person, you need to set the
card issuing parameters including the issuing mode and related parameters.
When adding a card to one person, click Sengs to open the Card Issuing Sengs window.
DS-K1T342 Series Face Recognion Terminal User Manual
164
Local Mode: Issue Card by Card Enrollment Staon
Connect a card enrollment staon to the PC running the client. You can place the card on the card
enrollment staon to get the card number.
Card Enrollment Staon
Select the model of the connected card enrollment staon
Note
Currently, the supported card enrollment staon models include DS-K1F100-D8, DS-K1F100-M,
DS-K1F100-D8E, and DS-K1F180-D8E.
Card Type
This eld is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E.
Select the card type as EM card or IC card according to the actual card type.
Serial Port
It is only available when the model is DS-K1F100-M.
Select the COM the card enrollment staon connects to.
Buzzing
Enable or disable the buzzing when the card number is read successfully.
Card No. Type
Select the type of the card number according to actual needs.
M1 Card Encrypon
This eld is only available when the model is DS-K1F100-D8, DS-K1F100-D8E, or DS-K1F180-D8E.
If the card is M1 card, and if you need to enable the M1 Card Encrypon funcon, you should
enable this funcon and select the sector of the card to encrypt.
Remote Mode: Issue Card by Card Reader
Select an access control device added in the client and swipe the card on its card reader to read
the card number.
10.5 Congure Schedule and Template
You can congure the template including holiday and week schedule. Aer seng the template,
you can adopt the congured template to access groups when seng the access groups, so that
the access group will take eect in the me duraons of the template.
Note
For access group sengs, refer to Set Access Group to Assign Access Authorizaon to Persons .
DS-K1T342 Series Face Recognion Terminal User Manual
165
10.5.1 Add Holiday
You can create holidays and set the days in the holidays, including start date, end date, and holiday
duraon in one day.
Steps
Note
You can add up to 64 holidays in the soware system.
1.
Click Access Control → Schedule → Holiday to enter the Holiday page.
2.
Click Add on the le panel.
3.
Create a name for the holiday.
4.
Oponal: Enter the descripons or some nocaons of this holiday in the Remark box.
5.
Add a holiday period to the holiday list and congure the holiday duraon.
Note
Up to 16 holiday periods can be added to one holiday.
1) Click Add in the Holiday List eld.
2) Drag the cursor to draw the me duraon, which means in that duraon of me, the
congured access group is acvated.
Note
Up to 8 me duraons can be set to one holiday period.
3) Oponal: Perform the following operaons to edit the me duraons.
●
Move the cursor to the me duraon and drag the me duraon on the meline bar to the
desired posion when the cursor turns to .
●
Click the me duraon and directly edit the start/end me in the appeared dialog.
●
Move the cursor to the start or the end of me duraon and drag to lengthen or shorten
the me duraon when the cursor turns to .
4) Oponal: Select the me duraon(s) that need to be deleted, and then click
in the
Operaon column to delete the selected me duraon(s).
5) Oponal: Click
in the Operaon column to clear all the me duraon(s) in the me bar.
6) Oponal: Click in the Operaon column to delete this added holiday period from the
holiday list.
6.
Click Save.
10.5.2 Add Template
Template includes week schedule and holiday. You can set week schedule and assign the me
duraon of access authorizaon for dierent person or group. You can also select the added
holiday(s) for the template.
DS-K1T342 Series Face Recognion Terminal User Manual
166
Steps
Note
You can add up to 255 templates in the soware system.
1.
Click Access Control → Schedule → Template to enter the Template page.
Note
There are two default templates: All-Day Authorized and All-Day Denied, and they cannot be
edited or deleted.
All-Day Authorized
The access authorizaon is valid in each day of the week and it has no holiday.
All-Day Denied
The access authorizaon is invalid in each day of the week and it has no holiday.
2.
Click Add on the le panel to create a new template.
3.
Create a name for the template.
4.
Enter the descripons or some nocaon of this template in the Remark box.
5.
Edit the week schedule to apply it to the template.
1) Click Week Schedule tab on the lower panel.
2) Select a day of the week and draw me duraon(s) on the meline bar.
Note
Up to 8 me duraon(s) can be set for each day in the week schedule.
3) Oponal: Perform the following operaons to edit the me duraons.
●
Move the cursor to the me duraon and drag the me duraon on the meline bar to the
desired posion when the cursor turns to .
●
Click the me duraon and directly edit the start/end me in the appeared dialog.
●
Move the cursor to the start or the end of me duraon and drag to lengthen or shorten
the me duraon when the cursor turns to .
4) Repeat the two steps above to draw more me duraons on the other days of the week.
6.
Add a holiday to apply it to the template.
Note
Up to 4 holidays can be added to one template.
1) Click Holiday tab.
2) Select a holiday in the le list and it will be added to the selected list on the right panel.
3) Oponal: Click Add to add a new holiday.
Note
For details about adding a holiday, refer to Add Holiday .
DS-K1T342 Series Face Recognion Terminal User Manual
167
4) Oponal: Select a selected holiday in the right list and click to remove the selected one, or
click Clear to clear all the selected holiday(s) in the right list.
7.
Click Save to save the sengs and nish adding the template.
10.6 Set Access Group to Assign Access Authorizaon to Persons
Aer adding the person and conguring the person's credenals, you can create the access groups
to dene which person(s) can get access to which door(s) and then apply the access group to the
access control device to take eect.
Before You Start
●
Add person to the client.
●
Add access control device to the client and group access points. For details, refer to Group
Management .
●
Add template.
Steps
When the access group sengs are changed, you need to apply the access groups to the devices
again to take eect. The access group changes include changes of template, access group sengs,
person's access group sengs, and related person details (including card number, ngerprint, face
picture, linkage between card number and ngerprint, linkage between card number and
ngerprint, card password, card eecve period, etc).
1.
Click Access Control → Authorizaon → Access Group to enter the Access Group interface.
2.
Click Add to open the Add window.
3.
In the Name text eld, create a name for the access group as you want.
4.
Select a template for the access group.
Note
You should congure the template before access group sengs. Refer to Congure Schedule
and Template for details.
5.
In the le list of the Select Person eld, select person(s) to assign access authority.
6.
In the le list of the Select Access Point eld, select door(s), door staon(s) or oor(s) for the
selected persons to access.
7.
Click Save.
You can view the selected person(s) and the selected access point(s) on the right side of the
interface.
DS-K1T342 Series Face Recognion Terminal User Manual
168
Figure 10-2 Display the Selected Person(s) and Access Point(s)
8.
Aer adding the access groups, you need to apply them to the access control device to take
eect.
1) Select the access group(s) to apply to the access control device.
2) Click Apply All to Devices start applying all the selected access group(s) to the access control
device or door staon.
3) Click Apply All to Devices or Apply Changes to Devices.
Apply All to Devices
This operaon will clear all the existed access groups of the selected devices and then
apply the new access group to the device.
Apply Changes to Devices
This operaon will not clear the existed access groups of the selected devices and only
apply the changed part of the selected access group(s) to the device(s).
4) View the applying status in the Status column or click Applying Status to view all the applied
access group(s).
Note
You can check Display Failure Only to lter the applying results.
The selected persons in the applied access groups will have the authorizaon to enter/exit the
selected doors/door staons with their linked card(s) or ngerprints.
9.
Oponal: Click to edit the access group if necessary.
DS-K1T342 Series Face Recognion Terminal User Manual
169
Note
If you change the persons' access informaon or other related informaon, you will view the
promptAccess Group to Be Applied on the right corner of the client.
You can click the prompt to apply the changed data to the device. You can select either Apply
Now or Apply Later.
Figure 10-3 Data Synchronizaon
10.7 Congure Advanced Funcons
You can congure the advanced funcons of access control to meet some special requirements in
dierent scene.
Note
●
For the card related funcons(the type of access control card), only the card(s) with access group
applied will be listed when adding cards.
●
The advanced funcons should be supported by the device.
●
Hover the cursor on the Advanced Funcon, and then Click to customize the advanced
funcon(s) to be displayed.
10.7.1 Congure Device Parameters
Aer adding the access control device, you can congure the parameters of access control device,
access control points.
DS-K1T342 Series Face Recognion Terminal User Manual
170
Congure Parameters for Access Control Device
Aer adding the access control device, you can congure its parameters, including overlaying user
informaon on picture, uploading pictures aer capturing, saving captured pictures, etc.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
Note
If you can nd Device Parameter in the Advanced Funcon list, Hover the cursor on the
Advanced Funcon, and then Click to select the Device Parameter to be displayed.
2.
Select an access device to show its parameters on the right page.
3.
Turn the switch to ON to enable the corresponding funcons.
Note
●
The displayed parameters may vary for dierent access control devices.
●
Some of the following parameters are not listed in the Basic Informaon page, click More to
edit the parameters.
Voice Prompt
If you enable this funcon, the voice prompt is enabled in the device. You can hear the voice
prompt when operang in the device.
Upload Pic. Aer Linked Capture
Upload the pictures captured by linked camera to the system automacally.
Save Pic. Aer Linked Capture
If you enable this funcon, you can save the picture captured by linked camera to the device.
Face Recognion Mode
Normal Mode
Recognize face via the camera normally.
Deep Mode
The device can recognize a much wider people range than the normal mode. This mode is
applicable to a more complicated environment.
Enable NFC Card
If enable the funcon, the device can recognize the NFC card. You can present NFC card on
the device.
Enable M1 Card
If enable the funcon, the device can recognize the M1 card. You can present M1 card on the
device.
Enable EM Card
DS-K1T342 Series Face Recognion Terminal User Manual
171
If enable the funcon, the device can recognize the EM card. You can present EM card on the
device.
Note
If the peripheral card reader supports presenng EM card, the funcon is also supported to
enable/disable the EM card funcon.
4.
Click OK.
5.
Oponal: Click Copy to, and then select the access control device(s) to copy the parameters in
the page to the selected device(s).
Congure Parameters for Door/Elevator
Aer adding the access control device, you can congure its access point (door or oor)
parameters.
Before You Start
Add access control device to the client.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
2.
Select an access control device on the le panel, and then click to show the doors or oors of
the selected device.
3.
Select a door or oor to show its parameters on the right page.
4.
Edit the door or oor parameters.
Note
●
The displayed parameters may vary for dierent access control devices.
●
Some of the following parameters are not listed in the Basic Informaon page, click More to
edit the parameters.
Name
Edit the card reader name as desired.
Door Contact
You can set the door sensor as remaining closed or remaining open. Usually, it is remaining
closed.
Exit Buon Type
You can set the exit buon as remaining closed or remaining open. Usually, it is remaining
open.
Door Locked Time
Aer swiping the normal card and relay acon, the mer for locking the door starts working.
Extended Open Duraon
DS-K1T342 Series Face Recognion Terminal User Manual
172
The door contact can be enabled with appropriate delay aer person with extended accesss
needs swipes her/his card.
Door Le Open Timeout Alarm
The alarm can be triggered if the door has not been closed in a congured me period. If it is
set as 0, no alarm will be triggered.
Lock Door when Door Closed
The door can be locked once it is closed even if the Door Locked Time is not reached.
Duress Code
The door can open by inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Super Password
The specic person can open the door by inpung the super password.
Dismiss Code
Create a dismiss code which can be used to stop the buzzer of the card reader (by entering
the dismiss code on the keypad).
Note
●
The duress code, super code, and dismiss code should be dierent.
●
The duress code, super password, and the dismiss code should be dierent from the
authencaon password.
●
The length of duress code, super password, and the dismiss code is according the device,
usually it should contains 4 to 8 digits.
5.
Click OK.
6.
Oponal: Click Copy to , and then select the door/oor(s) to copy the parameters in the page to
the selected doors/oor(s).
Note
The door or oor's status duraon sengs will be copied to the selected door/oor(s) as well.
Congure Parameters for Card Reader
Aer adding the access control device, you can congure its card reader parameters.
Before You Start
Add access control device to the client.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
2.
In the device list on the le, click
to expand the door, select a card reader and you can edit the
card reader's parameters on the right.
3.
Edit the card reader basic parameters in the Basic Informaon page.
DS-K1T342 Series Face Recognion Terminal User Manual
173
Note
●
The displayed parameters may vary for dierent access control devices. There are part of
parameters listed as follows. Refer to the user manual of the device for more details.
●
Some of the following parameters are not listed in the Basic Informaon page, click More to
edit the parameters.
Name
Edit the card reader name as desired.
OK LED Polarity/Error LED Polarity/Buzzer Polarity
Set OK LED Polarity/Error LED Polarity/Buzzer LED Polarity of main board according to the
card reader parameters. Generally, adopts the default sengs.
Minimum Card Swiping Interval
If the interval between card swiping of the same card is less than the set value, the card
swiping is invalid. You can set it as 0 to 255.
Max. Interval When Entering PWD
When you inpung the password on the card reader, if the interval between pressing two
digits is larger than the set value, the digits you pressed before will be cleared automacally.
Alarm of Max. Failed Aempts
Enable to report alarm when the card reading aempts reach the set value.
Max. Times of Card Failure
Set the max. failure aempts of reading card.
Tampering Detecon
Enable the an-tamper detecon for the card reader.
Communicate with Controller Every
When the access control device cannot connect with the card reader for longer than the set
me, the card reader will turn oine automacally.
Buzzing Time
Set the card reader buzzing me. The available me ranges from 0 to 5,999s. 0 represents
connuous buzzing.
Card Reader Type/Card Reader Descripon
Get card reader type and descripon. They are read-only.
Fingerprint Recognion Level
Select the ngerprint recognion level in the drop-down list.
Default Card Reader Authencaon Mode
View the default card reader authencaon mode.
Fingerprint Capacity
DS-K1T342 Series Face Recognion Terminal User Manual
174
View the maximum number of available ngerprints.
Exisng Fingerprint Number
View the number of existed ngerprints in the device.
Score
The device will score the captured picture according to the yaw angle, pitch angle, and
pupillary distance. If the score is less than the congured value, face recognion will be failed.
Face Recognion Timeout Value
If the recognion me is more than the congured me, the device will remind you.
Face Recognion Interval
The me interval between two connuous face recognions when authencang. By default,
it is 2s.
Face 1:1 Matching Threshold
Set the matching threshold when authencang via 1:1 matching mode. The larger the value,
the smaller the false accept rate and the larger the false rejecon rate when authencaon.
1:N Security Level
Set the matching security level when authencang via 1:N matching mode. The larger the
value, the smaller the false accept rate and the larger the false rejecon rate when
authencaon.
Live Face Detecon
Enable or disable the live face detecon funcon. If enabling the funcon, the device can
recognize whether the person is a live one or not.
Live Face Detecon Security Level
Aer enabling Live Face Detecon funcon, you can set the matching security level when
performing live face authencaon.
Max. Failed Aempts for Face Auth.
Set the maximum live face detecon failed aempts. The system will lock the user's face for 5
minutes if the live face detecon is failed for more than the congured aempts. The same
user cannot authencate via the fake face within 5 minutes. Within the 5 minutes, the user
can authencate via the real face twice connuously to unlock.
Lock Authencaon Failed Face
Aer enabling the Live Face Detecon funcon, the system will lock the user's face for 5
minutes if the live face detecon is failed for more than the congured aempts. The same
user cannot authencate via the fake face within 5 minutes. Within the 5 minutes, the user
can authencate via the real face twice connuously to unlock.
Applicaon Mode
You can select indoor or others applicaon modes according to actual environment.
4.
Click OK.
DS-K1T342 Series Face Recognion Terminal User Manual
175
5.
Oponal: Click Copy to, and then select the card reader(s) to copy the parameters in the page to
the selected card reader(s).
Congure Parameters for Alarm Output
Aer adding the access control device, if the device links to alarm outputs, you can congure the
parameters.
Before You Start
Add access control device to the client, and make sure the device supports alarm output.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter to enter access control
parameter conguraon page.
2.
In the device list on the le, click to expand the door, select an alarm input and you can edit
the alarm input's parameters on the right.
3.
Set the alarm output parameters.
Name
Edit the card reader name as desired.
Alarm Output Acve Time
How long the alarm output will last aer triggered.
4.
Click OK.
5.
Oponal: Set the switch on the upper right corner to ON to trigger the alarm output.
10.7.2 Congure Device Parameters
Aer adding the access control device, you can set its parameters such as network parameters.
Set Parameters for Face Recognion Terminal
For face recognion terminal, you can set its parameters including face picture database, QR code
authencaon, etc.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click Face Recognion Terminal.
4.
Set the parameters.
DS-K1T342 Series Face Recognion Terminal User Manual
176
Note
These parameters displayed vary according to dierent device models.
COM
Select a COM port for conguraon. COM1 refers to the RS-485 interface and COM2 refers to
the RS-232 interface.
Face Picture Database
select Deep Learning as the face picture database.
Authencate by QR Code
If enabled, the device camera can scan the QR code to authencate. By default, the funcon
is disabled.
Blocklist Authencaon
If enabled, the device will compare the person who want to access with the persons in the
blocklist.
If matched (the person is in the blocklist), the access will be denied and the device will upload
an alarm to the client.
If mismatched (the person is not in the blocklist), the access will be granted.
Save Authencang Face Picture
If enabled, the captured face picture when authencang will be saved on the device.
MCU Version
View the device MCU version.
5.
Click Save.
Set RS-485 Parameters
You can set the access control device's RS-485 parameters including the baud rate, data bit, the
stop bit, parity type, ow control type, communicaon mode, work mode, and connecon mode.
Steps
Note
The RS-485 Sengs should be supported by the device.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click RS-485 to enter the RS-485 Sengs
page.
4.
Select the serial port number from the drop-down list to set the RS-485 parameters.
5.
Set the serial number, external device, authencaon center, baud rate, data bit, stop bit, parity
type, ow control type, communicaon mode, and working mode in the drop-down list.
DS-K1T342 Series Face Recognion Terminal User Manual
177
6.
Click Save.
●
The congured parameters will be applied to the device automacally.
●
When you change the working mode or connecon mode, the device will reboot
automacally.
Set Wiegand Parameters
You can set the access control device's Wiegand channel and the communicaon mode. Aer
seng the Wiegand parameters, the device can connect to Wiegand card reader via Wiegand
communicaon.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click Wiegand to enter the Wiegand
Sengs page.
4.
Set the switch to on to enable the Wiegand funcon for the device.
5.
Select the Wiegand channel No. and the communicaon mode from the drop-down list.
Note
If you set Communicaon Direcon as Sending, you are required to set the Wiegand Mode as
Wiegand 26 or Wiegand 34.
6.
Check Enable Wiegand to enable the Wiegand funcon.
7.
Click Save.
●
The congured parameters will be applied to the device automacally.
●
Aer changing the communicaon direcon, the device will reboot automacally.
Enable M1 Card Encrypon
M1 card encrypon can improve the security level of authencaon.
Steps
Note
The funcon should be supported by the access control device and the card reader.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click M1 Card Encrypon Vericaon to
enter the M1 Card Encrypon Vericaon page.
DS-K1T342 Series Face Recognion Terminal User Manual
178
4.
Set the switch to on to enable the M1 card encrypon funcon.
5.
Set the sector ID.
Note
●
The sector ID ranges from 1 to 100.
●
By default, Sector 13 is encrypted. It is recommended to encrypt sector 13.
6.
Click Save to save the sengs.
10.8 Door Control
In Monitoring module, you can view the real-me status of the doors managed by the added
access control device. You can also control the doors such as open/close the door, or remain the
door open/closed via the client remotely. The real-me access event are displayed in this module.
You can view the access details and person details.
Note
For the user with door control permission, the user can enter the Monitoring module and control
the door. Or the icons used for control will not show. For seng the user permission, refer to
Person Management .
10.8.1 Control Door Status
You can control the status for the door(s), including unlock door, locking door, remaining the door
unlock, remaining the door locked, remain all unlocked, etc.
Before You Start
●
Add person and assign access authorizaon to designed person, and person will have the access
authorizaon to the access points (doors). For details, refer to
Person Management and Set
Access Group to Assign Access Authorizaon to Persons .
●
Make sure the operaon user has the permission of the access points (doors). For details, refer
to .
Steps
1.
Click Monitoring to enter the status monitoring page.
2.
Select an access point group on the upper-right corner.
Note
For managing the access point group, refer to Group Management .
The doors in the selected access control group will display.
3.
Click a door icon to select a door, or press Ctrl and select mulple doors.
DS-K1T342 Series Face Recognion Terminal User Manual
179
Note
For Remain All Unlocked and Remain All Locked, ignore this step.
4.
Click the following buons to control the door.
Unlock
When the door is locked, unlock it and it will be open for once. Aer the open duraon, the
door will be closed and locked again automacally.
Lock
When the door is unlocked, lock it and it will be closed. The person who has the access
authorizaon can access the door with credenals.
Remain Unlocked
The door will be unlocked (no maer closed or open). All the persons can access the door
with no credenals required.
Remain Locked
The door will be closed and locked. No person can access the door even if he/she has the
authorized credenals, except the super users.
Remain All Unlocked
All doors in the group will be unlocked (no maer closed or open). All the persons can access
the doors with no credenals required.
Remain All Locked
All doors in the group will be closed and locked. No person can access the doors even if
he/she has the authorized credenals, except the super users.
Capture
Capture a picture manually.
Note
The Capture buon is available when the device supports capture funcon. The picture is
saved in the PC running the client. For seng the saving path, refer to Set File Saving Path in
the user manual of the client soware.
Result
The icon of the doors will change in real-me according to the operaon if the operaon is
succeeded.
10.8.2 Check Real-Time Access Records
The access records will display in real me, including card swiping records, face recognions
records, ngerprint comparison records, etc. You can view the person informaon and view the
picture captured during access.
DS-K1T342 Series Face Recognion Terminal User Manual
180
Steps
1.
Click Monitoring and select a group from the drop-down list on the upper-right corner.
The access records triggered at the doors in the selected group will display in real me. You can
view the details of the records, including card No., person name, organizaon, event me, etc.
2.
Oponal: Check the event type and event status so that these events will show in the list if the
events are detected. The events of unchecked type or status will not be displayed in the list.
3.
Oponal: Check Show Latest Event and the latest access record will be selected and displayed at
the top of the record list.
4.
Oponal: Click the event to view the accessed person details, including person pictures
(captured picture and prole), person No., person name, organizaon, phone, contact address,
etc.
Note
You can double click the captured picture to enlarge it to view the details.
5.
Oponal: Right click on the column name of the access event table to show or hide the column
according to actual needs.
DS-K1T342 Series Face Recognion Terminal User Manual
181
Appendix A. Tips for Scanning Fingerprint
Recommended Finger
Forenger, middle nger or the third nger.
Correct Scanning
The gure displayed below is the correct way to scan your nger:
You should press your nger on the scanner horizontally. The center of your scanned nger should
align with the scanner center.
Incorrect Scanning
The gures of scanning ngerprint displayed below are incorrect:
DS-K1T342 Series Face Recognion Terminal User Manual
182
Environment
The scanner should avoid direct sun light, high temperature, humid condions and rain.
When it is dry, the scanner may not recognize your ngerprint successfully. You can blow your
nger and scan again.
Others
If your ngerprint is shallow, or it is hard to scan your ngerprint, we recommend you to use other
authencaon methods.
If you have injuries on the scanned nger, the scanner may not recognize. You can change another
nger and try again.
DS-K1T342 Series Face Recognion Terminal User Manual
183
Appendix B. Tips When Collecng/Comparing Face
The posion when collecng or comparing face picture is as below:
Posions (Recommended Distance: 0.5 m)
Expression
●
Keep your expression naturally when collecng or comparing face pictures, just like the
expression in the picture below.
●
Do not wear hat, sunglasses, or other accessories that can aect the facial recognion funcon.
●
Do not make your hair cover your eyes, ears, etc. and heavy makeup is not allowed.
Posture
In order to get a good quality and accurate face picture, posion your face looking at the camera
when collecng or comparing face pictures.
DS-K1T342 Series Face Recognion Terminal User Manual
184
Size
Make sure your face is in the middle of the collecng window.
DS-K1T342 Series Face Recognion Terminal User Manual
185
Appendix C. Tips for Installaon Environment
1. Light Source Illuminaon Reference Value
Candle: 10Lux
Bulb: 100~850Lux
Sunlight: More than 1200Lux
2. Avoid backlight, direct and indirect sunlight
DS-K1T342 Series Face Recognion Terminal User Manual
186
Appendix D. Dimension
Figure D-1 Dimension
DS-K1T342 Series Face Recognion Terminal User Manual
187
Appendix E. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon matrix.
Note that the matrix contains all communicaon ports of Hikvision access control and video
intercom devices.
Figure E-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port commands.
Note that the command list contains all commonly used serial ports commands for all Hikvision
access control and video intercom devices.
Figure E-2 Device Command
DS-K1T342 Series Face Recognion Terminal User Manual
188
UD25849B-B
