IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3 in 1 Magnetic Wireless Charger
Model No. ELA1432
User Manual
User Manual
3 in 1 Magnetic Wireless Charger
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3 in 1 Magnetic Wireless Charger
Model No. ELA1432
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
Whilst using electrical appliances, basic safety precautions should
always be followed:
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
Read and familiarise yourself with all operating instruction before
using this 3 in 1 Wireless Charger.
• Before using your Wireless Charger, visually check that the
unit is intact and has not suffered any transit damage.
• Only charge the Wireless Charger from a suitable USB
outlet, any other power source may cause permanent
damage to the product.
• Do not operate this product after a malfunction or after
being dropped or damaged in any way.
• Never allow children to play with the product. Small parts
may be a choking hazard.
• Do not allow the USB charging cable to hang over sharp
edges or come in contact with hot surfaces.
• This product is intended for household use only and
should not be used for industrial purposes.
• Do not use this product for anything other than its
intended use.
• Do not immerse the product in water or any other liquids.
• Do not expose the product to moisture, rain or humidity,
as it is not waterproof.
• Before cleaning, ensure the product is not connected to
the USB supply.
3
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3 in 1 Magnetic Wireless Charger
Model No. ELA1432
User Manual
• Never clean the product with solvents or harsh or abrasive
cleaners.
• Do not attempt to dismantle the product, it does not
contain any user serviceable parts.
• Whilst not in use, store the product in a cool dry place free
from extreme temperatures, humidity or dust and away
from direct sunlight.
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3 in 1 Magnetic Wireless Charger
Model No. ELA1432
User Manual
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This symbol provides useful additional information on the
use of this product.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste. Please ensure it is
taken to a suitable facility for disposal. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk enter your postcode to find out your nearest
recycling site.
Notes on Your 3 in 1 Magnetic Wireless Charger
• Whilst using this 3 in 1 Magnetic Wireless Charger use a fast charge USB cable
and ensure that a QC/PD3.0 type USB supply (minimum 18W) is used.
• Do not place metal objects onto the Charging Pad during use as this may cause
permanent damage to the unit.
• The magnetic phone charger is compatible with iPhone 12 to 15 with Magsafe.
• The top watch charging area is only compatible with Apple watch. The bottom
earphone charging area is compatible with any Qi
#
-enabled earphones.
Before first use of Your Magnetic 3 in 1 Wireless Charger
Remove all packing materials and discard responsibly.
Check that all the parts are present with your product see ‘Description of Parts’
below.
5
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3 in 1 Magnetic Wireless Charger
Model No. ELA1432
User Manual
Description of Parts
1
3
4
2
1. Smart Watch Wireless Charging Pad
2. Mobile Phone Charging Area
3. Earphone Charging Area
4. Indicator Light
5. C-Type Charging Port
6. Underside Air Vent
5
6
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3 in 1 Magnetic Wireless Charger
Model No. ELA1432
User Manual
Using Your Magnetic 3 in 1 Wireless Charger
1. Insert the C-Type plug of the USB cable into the C-Type USB Charging Port (5).
2. Place the Phone, Watch or earphones onto the appropriate charging pad as
shown below.
The case (if fitted) of the phone must be
removed first before placing it onto the
charger.
3. Connect the large A-Type USB plug to a QC/PD3.0 type charger (not supplied)
and power up the charger.
4. Refer to the table below to show the status of the Indicator Light (4):
State
Indicator Light (4)
Power On
Blue & Green on for 2s and then off
Mobile Phone Charging
Blue light
Earphone Charging
Green light
Mobile Phone detects metal objects or
abnormal charging.
Blue light flashing
Earphones detect metal objects or
abnormal charging.
Green light flashing
Technical Specification
Model Number
ELA1432
Input Type and Power Rating
QC/PD USB Type C 18W min.
USB Input
9V DC – 2A
Rated Output (Phone)
5W/7.5W/10W/15W (max)
Rated Output (Earphone)
3W (max)
Rated Output (iWatch)
3W (max)
Transmission Distance
≤6mm
Conversion Efficiency
≥73%
Dimensions
107 x 67.6 x 117mm
7
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3 in 1 Magnetic Wireless Charger
Model No. ELA1432
User Manual
Recycling Information
Disposal of the Product
You should now recycle your waste electrical goods and in doing so help
the environment. This symbol means waste electrical products at the end
of their useful life should not be disposed of with normal household
waste and not sent to landfill. Please ensure it is taken to a suitable
facility for disposal. Check with your Local Authority or retailer for
recycling advice or visit enter your postcode to find out your nearest
recycling site.
#
Qi and the Qi symbol are trademarks of the Wireless Power Consortium.
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3 in 1 Magnetic Wireless Charger
Model No. ELA1432
User Manual
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House, 1 Brightgate Way, Manchester, M32 0TB, UK.
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006.
www.esgltd.com
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee.
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with
proof of purchase or receipt. If any defect should occur due to faulty workmanship or
material, your faulty product should be returned to the place of purchase, replacement or
refund is at the discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged
through inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of
the original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
