360° 3W COB & 1W SMD LED RECHARGEABLE LITHIUM-
POLYMER INSPECTION LIGHT
MODEL NO: LED3601R.V3, LED3601G.V3, LED3601CF.V3, LED3601.V3
1. SAFETY
9 Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
9 Ensure the lamp is fully charged before initial use.
8 DO NOT charge in damp conditions.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with
cool water and seek immediate medical attention.
2. INTRODUCTION
Mini, lightweight light with exclusive patented design owned by and registered to Sealey. Unique and innovative 360° swivel and tilt
function enables the light source to be positioned in any direction. Featuring a super bright 3W COB LED light source, which gives
an even and constant spread of light. Produces up to 300 lumens with a CRI-80 rating. Recessed lens for added protection. 1W
SMD LED directional torch located on top of the light, produces up to 100 lumens. Rubber covered magnet in base and swivel hook
for hands-free operation. High quality rechargeable 3.7V 1.5Ah Lithium-Polymer battery for longer life. Supplied with Micro USB
cable.
3. SPECIFICATION
The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time. We will
provide warranty against mechanical and electrical defect for a period of one year - this DOES NOT cover fair wear and tear. If the
battery is not properly charged before rst use, or regularly conditioned, its capacity will diminish. Under these circumstances we
will not replace the battery regardless of whether it is less than one year old.
NOTE: The lithium battery does not suer from memory eect and once fully charged may be stored for up to six months without
another charge. (Not supplied with mains adaptor).
4. OPERATION
Refer to
instructions
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Original Language Version
© Jack Sealey Limited
Model No: LED3601R, LED3601G, LED3601CF, LED3601
Battery: 3.7V 1.5Ah Li-Poly
LED Type: 3W COB + 1W SMD
Lumen Output Side/Top: 300/100lm
CRI Rating: (Side): 80
Operating Time Side/Top: 3/6hr
Charging Time: 3hr
IP Rating: IP20
Maximum Length: 170mm
Minimum Length: 160mm
LED3601R.V3, LED3601G.V3, LED3601CF.V3, LED3601.V3. Issue:3 (H,3) 20/09/23
V 360° 3W COB & 1W SMD LED Rechargeable Lithium-Polymer Inspection Light
4.1. Connect the Micro USB cable into the charging port on the back of the light. Plug into power source and turn on, the charging LED
on the light will light RED to show charging has commenced.
4.2. When the battery has fully charged the LED will turn GREEN.
4.3. Direct the lens away from your eyes before switching on.
4.4. Toggle the light between 1W SMD end and 3W COB using the push switch.
4.5. Suspend the light by the hanging hook. When the light is hanging from the hook it can be rotated through 360° for more precise
positioning.
4.6. Alternatively use the magnet on the base to attach the light to any ferrous surface.
BATTERY REMOVAL
Remove the 6 screws on the back of the lamp. Remove the back casing and disconnect the wiring from the circuit board. Remove the
battery mounting screws. Dispose of according to local government guidelines.
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of prod-
ucts containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme.
Jack Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
