E8 (EC/ECS/SC/SCS/INTC)
Instructions for Use
jura.com/support-E8C
Additional online content
Tap, click or scan the QR code to access
additional online resources.
There are video tutorials to help you
operate your E8.
Contents
2
Contents
1 Control elements ....................................................................................................................................................................................3
2 For your safety ...................................................................................................................................................................................... 4
Comply with the instructions for use ............................................................................................................................................................................ 4
Proper use .......................................................................................................................................................................................................................... 4
User limitations ................................................................................................................................................................................................................. 4
Use by children ..................................................................................................................................................................................................................4
What to do in the event of damage ..............................................................................................................................................................................4
Preventing damage .......................................................................................................................................................................................................... 5
Danger of electric shock .................................................................................................................................................................................................. 5
Danger of burns, scalding and injury ............................................................................................................................................................................ 5
3 Preparing and using for the first time ................................................................................................................................................. 6
Setting up the machine ................................................................................................................................................................................................... 6
Filling the bean container................................................................................................................................................................................................ 6
Determining the water hardness ...................................................................................................................................................................................6
First-time use .....................................................................................................................................................................................................................6
Managing your E8 – the JURA Cockpit ........................................................................................................................................................................8
Connecting milk ................................................................................................................................................................................................................ 8
Establishing a Wi-Fi connection ..................................................................................................................................................................................... 8
4 Preparation ........................................................................................................................................................................................... 9
Preparation with preselection (Speciality Selection) .................................................................................................................................................. 9
Espresso and coffee .......................................................................................................................................................................................................... 9
Latte macchiato, cappuccino and other speciality coffees with milk ..................................................................................................................... 10
Americano and lungo ....................................................................................................................................................................................................10
Espresso doppio ............................................................................................................................................................................................................... 10
Ground coffee ................................................................................................................................................................................................................... 10
Hot water ............................................................................................................................................................................................................................ 11
Adjusting the grinder .......................................................................................................................................................................................................11
Adjusting the product settings......................................................................................................................................................................................12
5 Daily operation .................................................................................................................................................................................... 12
Switching the machine on and off................................................................................................................................................................................12
Filling the water tank .......................................................................................................................................................................................................13
Maintenance actions ....................................................................................................................................................................................................... 13
6 Machine settings .................................................................................................................................................................................14
7 Maintenance ........................................................................................................................................................................................14
Rinsing the machine ........................................................................................................................................................................................................14
Rinsing the milk system .................................................................................................................................................................................................15
Cleaning the milk system ............................................................................................................................................................................................... 15
Dismantling and rinsing the fine foam frother ..........................................................................................................................................................16
Inserting/changing the filter ..........................................................................................................................................................................................17
Cleaning the machine ..................................................................................................................................................................................................... 17
Descaling the machine ..................................................................................................................................................................................................18
Descaling the water tank ............................................................................................................................................................................................... 20
Cleaning the bean container.........................................................................................................................................................................................20
8 Display messagess .............................................................................................................................................................................. 20
9 Troubleshooting ................................................................................................................................................................................. 20
10 Transport and environmentally friendly disposal ............................................................................................................................. 21
Transport/ Emptying the system .................................................................................................................................................................................21
Disposal .............................................................................................................................................................................................................................21
11 Technical data .....................................................................................................................................................................................22
12 Index ...................................................................................................................................................................................................22
13 JURA contact details/ Legal information .......................................................................................................................................... 24
1 Control elements
3
6
1 Control elements
q
On/Off button Q
w
Bean container with aroma preservation cover
e
Multi-function buttons (button function depends on what is shown in the display)
r
Display
t
Milk system with fine foam frother
z
Height-adjustable coffee spout
u
Hot-water nozzle
i
Cup grille with aperture
o
Insert for drip tray
p
Drip tray
a
Coffee grounds container
s
Mains cable (permanently connected or plug-in)(back of the machine)
d
Water tank
f
Water tank cover
g
Service socket for optional JURA Wi-Fi Connect
h
Filler funnel for ground coffee (removable)
j
Cover
k
Grinder adjustment switch
l
Container for milk system cleaning
y
Measuring spoon for ground coffee
19 20
1816 17
14
12
13
15
2
3
4
7
8
11
9
1
10
5
6
2 For your safety
4
2 For your safety
Comply with the instructions for use
Before using the machine, read these instructions for use thoroughly and completely and comply with
the instructions they contain. Keep these instructions for use close to the machine and pass them on to
the next user.
Failure to observe the instructions for use may result in serious injuries or damage to property. Safety
information is therefore indicated as follows:
J
WARNING
Indicates circumstances that may result in serious injuries or death.
J
CAUTION
Indicates circumstances that may result in minor injuries.
CAUTION Indicates circumstances that may result in damage to property.
Proper use
The machine is intended for private domestic use. It should only be used for coffee preparation and to
heat milk and water. Use for any other purpose will be deemed improper.
User limitations
People, including children, who
U
do not have the physical, sensory or mental capabilities to use the machine safely or
U
are inexperienced or lack knowledge
must be supervised by a responsible person when using it, or must be instructed in how to use it cor-
rectly.
When using the CLARIS Smart
+
filter cartridge or a JURA Wi-Fi Connect, wireless connections are estab-
lished. Specific details on the frequency band used and the maximum transmission power can be found
in the ‘11 Technical data’ section.
Use by children
Children must be able to recognise and understand the potential dangers arising from incorrect use:
U
Keep children under the age of 8 away from the machine, or supervise them constantly.
U
Children aged 8 and over may only operate the machine without supervision if they have been
instructed in how to use it safely.
U
Children may not clean or service the machine unless supervised by a responsible person.
U
Do not allow children to play with the machine.
What to do in the event of damage
Never use a damaged machine or mains cable. This could result in fatal electric shock.
U
In the event of signs of damage, disconnect the machine from the mains. To do this, first switch the
E8 off with the On/Off button
Q
. Only then should you remove the mains plug from the power
socket.
U
Replace a damaged plug-in mains cable with an original JURA mains cable. Unsuitable mains cables
may result in consequential damage.
U
Only permit authorised JURA service centres to carry out repairs to the machine and the perman-
ently connected mains cable. Unsuitable repairs may result in consequential damage.
2 For your safety
5
Preventing damage
To avoid damage to the machine and the mains cable:
U
Do not use the E8 and the mains cable near hot surfaces.
U
Do not allow the mains cable to rub against sharp edges and ensure that it does not become
trapped.
U
Never allow the mains cable to loosely hang down. The mains cable could pose a tripping hazard or
become damaged.
U
Protect the E8 from weather and direct sunlight.
U
Only connect the E8 to a mains voltage corresponding to that stated on the rating plate. The rating
plate is located on the underside.
U
Connect the E8 directly to a domestic power socket. Using multi-socket adapters or extension cords
may cause overheating.
U
Do not use alkaline or alcohol-based cleaning agents; only use mild cleaning agents and a soft cloth.
U
Do not use any coffee beans treated with additives or caramelised coffee beans.
U
Only fill the water tank with fresh, cold, non-carbonated water.
U
Switch the machine off with the On/Off button
Q
if you are going to be absent for a longer period of
time and remove the mains plug from the power socket.
U
Only use original JURA maintenance products. Use of products that are not explicitly recommended
by JURA could damage your E8.
Danger of electric shock
Water conducts electricity. Do not bring water and electricity into contact with one another:
U
Never touch the mains plug with wet hands.
U
Do not immerse the E8 and/or mains cable in water.
U
Do not put the E8 or any individual parts in the dishwasher.
U
Before cleaning, switch the E8 off with the On/Off button
Q
. Always wipe the E8 with a damp cloth
rather than a wet one, and protect it from prolonged exposure to water splash. The E8 must not be
cleaned with a jet of water.
U
The E8 is not suitable for installation on a surface where a jet of water can be used.
Danger of burns, scalding and injury
U
Do not touch the spouts during operation. Use the handles provided.
U
Optionally, your E8 can be remotely operated using mobile devices. When preparing a product or
initiating a maintenance programme, make sure that other people are not put at risk – for example,
through contact with the spouts.
U
Be careful to ensure that the fine foam frother is correctly installed and clean, otherwise the fine
foam frother (or parts of it) may come loose.
3 Preparing and using for the first time
6
3 Preparing and using for the first time
Setting up the machine
T
Choose a spot for your E8 which protects the machine against overheating. Ensure that the ventilation slots are not covered.
T
Place the E8 on a horizontal surface that is not sensitive to water.
Filling the bean container
The aroma preservation cover on the bean container ensures that the aroma of the beans is retained for longer.
CAUTION
Coffee beans which have been treated with additives (e.g. sugar), ground coffee or freeze-dried coffee will damage the grinder.
T
Only use roasted, untreated coffee beans to fill the bean container.
T
Remove the aroma preservation cover.
T
Fill the bean container with coffee beans and close the aroma preservation cover.
Determining the water hardness
When you use the machine for the first time, you must set the water hardness. If you know the hardness of your water, go straight to the
next section. If you do not know the water hardness, you can find this out first:
T
Hold the Aquadur
®
test strip supplied under running water for one second. Shake off the water.
T
Wait for about 1minute.
T
You will then be able to read the degree of water hardness from the discolouration of the Aquadur® test strip and the description on
the packaging.
First-time use
J
WARNING
If the machine is operated with a defective mains cable, there is a danger of potentially fatal electric shock.
T
Never use a machine which is damaged or has a defective mains cable.
CAUTION
Milk, sparkling mineral water or other liquids can damage the water tank or the machine.
T
Only fill the water tank with fresh, cold water.
Precondition:The bean container has been filled.
T
For machines with a plug-in mains cable: Connect the mains cable to the machine.
T
Insert the mains plug into a power socket.
T
Press the On/Off button Q to switch the E8 on.
‘Sprachauswahl’
T
Press the 0 or 9 button until the desired language is displayed, e.g. ‘English’.
T
Press the ‘Save’ button.
‘Water hardness’
E Please refer to the section above for a description of how to determine the water hardness.
3 Preparing and using for the first time
7
T
Press the 0 or 9 button to change the setting for the water hardness.
T
Press the ‘Save’ button.
‘Filter operation’ / ‘Insert filter’
T
Place a receptacle under the hot-water nozzle.
T
Remove the water tank and rinse it with cold water.
T
Fit the filter cartridge extension supplied on top of the CLARIS Smart
+
filter cartridge.
T
Insert the filter cartridge with its extension into the water tank.
T
Turn the filter cartridge clockwise until it audibly clicks into place.
T
Fill the water tank with fresh, cold water and reinsert the tank.
E The machine automatically detects that you have just inserted the filter cartridge.
‘Filter is beingrinsed’, water flows directly into the drip tray.
‘System is filling’, water flows out of the hot-water nozzle.
‘Empty drip tray’
T
Empty the drip tray and put it back into the machine.
T
Place one receptacle under the coffee spout and another under the fine foam frother.
‘Machine is heating’
‘Machine is rinsing’
‘Milk system is being rinsed’
The start screen is displayed. Your E8 is ready for use.
3 Preparing and using for the first time
8
Managing your E8 – the JURA Cockpit
The JURA Cockpit allows you to manage your E8. Press the 0 button several times until the JURA Cockpit is displayed on page äääö
of the start screen.
Symbol Meaning
c
‘Maintenance’ area (blue)
f
‘Machine settings’ area (green)
$
Filter mode
Connecting milk
Your E8 creates fine, creamy, feather-light milk foam with a perfect consistency. The most important requirement for frothing milk is a milk
temperature of 4–8°C. We would therefore recommend using a milk cooler or a milk container.
T
Remove the protective cover from the fine foam frother.
T
Connect the milk pipe to the fine foam frother.
E The milk system of your E8 has a connector HP3 and an interchangeable milk spout CX3.
T
Connect the other end of the milk pipe to a milk container or a milk cooler.
Establishing a Wi-Fi connection
Your E8 can be connected with your JURA app (J.O.E.
®
).
Precondition:J.O.E.
®
is installed on your mobile end device and you have logged into your home network. The optionally available JURA
Wi-Fi Connect is inserted into the service socket of your E8. (After the JURA Wi-Fi Connect has been inserted, the E8 must be switched off
and then on again.)
T
Press the 0 button several times until the JURA Cockpit is displayed on page äääö of the start screen.
T
Press the f button.
T
Press the 0 button several times until page ääö is displayed.
T
Press the ‘Wi-Fi connection’ button.
T
Press the ‘Connect’ button.
T
Now follow the instructions on the display.
<
<
$
ä ä ä
ö
c
f
4 Preparation
9
4 Preparation
Basic information about preparing drinks:
Aim What to do
Change the coffee strength of a single product
Press the 9 or 0 button during grinding
Change the amount for a single product
Press the 9 or 0 button during preparation
E The longer you press the 9 and 0 buttons, the faster your setting changes.
Aim What to do
Permanently save the amount for a single product Press ‘Save’ straight after preparation
Change the amount, coffee strength and temperature for any
given product
Press the button for a product for two seconds and configure the
desired settings in ‘Product settings’
Display more products
Press the 0 button to display the next product page
Prepare two speciality coffees (for coffee and espresso) Press the preparation button twice within two seconds
Stop preparation Press the ‘X’ button
Coffee tastes best served hot. A cold porcelain cup cools the beverage – and impairs the taste. We therefore recommend prewarming the
cups. You can purchase a JURA cup warmer from your specialised dealer.
Preparation with preselection (Speciality Selection)
Press the ~ button to open the Speciality Selection.
Now choose the desired preselection for the product:
Speciality Selection Meaning
s – ‘Extra Shot’
(for latte macchiato, cappuccino and flat white)
The product is prepared with two brewing operations, with half the amount of
water – for a speciality coffee with a particularly intense taste.
£ – ‘Ground coffee’
(all speciality coffees except for espresso doppio)
The product is prepared with ground coffee.
Espresso and coffee
Example:Coffee
T
Place a cup under the coffee spout.
T
Press the ‘Coffee’ button (on pageäöää).
The preset amount of water for coffee flows into the cup.
×
s
£
Save
4 Preparation
10
Latte macchiato, cappuccino and other speciality coffees with milk
Your E8 prepares the following speciality coffees with milk at the touch of a button:
U
Cortado
U
Latte macchiato
U
Macchiato
U
Flat white
U
Cappuccino
Example:Latte macchiato
T
Place a glass under the fine foam frother.
T
Press the ‘Latte macchiato’ button (on page öäää).
The preset amount of milk foam flows into the glass.
E There is a short interval while the hot milk separates from the milk foam. This allows the typical layers of a latte macchiato to form.
The preset amount of water for espresso flows into the glass.
To ensure that the fine foam frother always works properly, you must clean it daily when you have been preparing milk (see chapter 7 ‘Main-
tenance – Cleaning the milk system’).
Americano and lungo
For the americano and lungo, the E8 blends the coffee with hot water using a special preparation method. This results in a full-bodied spe-
ciality coffee which is particularly easy to digest. You can change the amount of this additional water (see chapter 4 ‘Preparation – Adjust-
ing the product settings’).
Espresso doppio
‘Doppio’ is Italian for ‘double’. When you select Espresso doppio, two espressi are prepared one after the other. The result is an extra full-bod-
ied and aromatic speciality coffee.
Ground coffee
You can choose to use a second coffee variety, for example decaffeinated coffee, with the filter funnel for ground coffee.
Basic information about ground coffee:
U
Never add more than two level measuring spoons of ground coffee.
U
Use ground coffee which is not ground too finely. Very fine coffee can block up the system so that the coffee only comes out in drips.
U
If you did not fill the machine with a sufficient amount of ground coffee, ‘Not enough ground coffee’ is displayed and the E8 stops the
operation.
U
The desired speciality coffee must be prepared within approximately one minute after filling with the ground coffee. Otherwise the E8
stops the operation and is once more ready for use.
U
All speciality coffees with ground coffee are always prepared following the same model.
Example:Espresso with ground coffee
T
Place an espresso cup under the coffee spout.
T
Press the ~ button to open the Speciality Selection.
T
Press the ‘Ground coffee’ £ button.
T
Press the ‘Save’ button.
T
Press the ‘Espresso’ button (on page öäää).
‘Please add ground coffee’
4 Preparation
11
T
Open the cover behind the bean container.
T
Add the desired amount of ground coffee to the filler funnel (max. 2 level measuring spoons).
E The amount of ground coffee determines the intensity and aroma of the beverage, so you can adjust it to your personal preferences.
T
Close the cover.
T
Press the ‘Next’ button.
The preset amount of water for espresso flows into the cup.
Hot water
J
CAUTION
There is a danger of scalding from hot water splashes.
T
Avoid direct contact with the skin.
T
Place a cup under the hot-water spout.
T
Press the ‘Hot water’ button (on page ääöä).
The preset amount of water flows into the cup.
Adjusting the grinder
You can adjust the grinder to suit the degree of roast of your coffee.
The consistency of grind is correct if the coffee flows regularly from the coffee spout. In addition a fine, thick crema forms.
T
Open the cover behind the bean container.
T
Turn the grinder adjustment switch to the desired position.
T
Close the cover.
5 Daily operation
12
Adjusting the product settings
Press a product button for about two seconds to view the list of settings:
U
‘Product settings’: Specify individual settings such as coffee strength, amount of water, etc.
U
‘Reposition the product’: Replace the products on the start screen with your favourites.
Permanent settings in programming mode always follow the same model.
Example:Proceed as follows to change the coffee strength for one coffee.
T
Press the ‘Coffee’ button for about two seconds.
T
Press the ‘Product settings’ button.
‘Coffee strength’
E Different settings will be available depending on the selected product: Press the 1 or ^ button to navigate the various settings.
T
Press the 0 or 9 button to change the setting.
T
Press the ‘Save’ button.
T
Press the ‘X’ button to return to the start screen.
5 Daily operation
Switching the machine on and off
T
Place one receptacle under the coffee spout and another under the fine foam frother.
T
Press the On/Off button Q.
‘Machine is rinsing’
Your E8 is switched on or off.
E When the machine is switched off, the system is only rinsed if a speciality coffee has been prepared.
E If milk has been prepared before switching off, you will be prompted to carry out milk system cleaning (‘Clean the milk system’).
After 30 seconds the switch-off process continues automatically.
Tap, click or scan to watch
the video tutorial on YouTube
Tap, click or scan to watch
the video tutorial on YouTube
5 Daily operation
13
Filling the water tank
Daily maintenance of the machine and hygiene when handling milk, coffee and water are key to a perfect coffee result in the cup every
time. You should therefore change the water daily.
CAUTION
Milk, sparkling mineral water or other liquids can damage the water tank or the machine.
T
Only fill the water tank with fresh, cold water.
T
Remove the water tank and rinse it with cold water.
T
Fill the water tank with fresh, cold water and reinsert the tank.
Maintenance actions
Optimal coffee quality depends on many factors. One important prerequisite is regular maintenance of your E8. Carry out the following
steps:
Maintenance action Daily If necessary Note
Empty the drip tray and coffee grounds container
and rinse with warm water
(The insert for the drip tray, including the drip
tray itself, and the coffee grounds container are
dishwasher-safe)
Z
Always empty the coffee grounds container when the
machine is switched on. This is the only way of
resetting the coffee grounds counter.
Clean the milk system (if heavily soiled, also
dismantle it)
Z
See chapter 7 ‘Maintenance – Cleaning the milk system’
Rinse the milk pipe
Z
Rinse the water tank
Z
Wipe the surface of the machine with a clean,
soft, damp cloth (e.g. microfibre cloth)
Z
Changing milk pipe with connector HP3 approx. every
3 months
Change the interchangeable milk spout CX3 approx. every
3 months
Clean the inside of the water tank with a brush
Z
Clean the top and bottom of the cup grille
Z
Thoroughly clean the drip tray and coffee
grounds container
Z
E You will find more information about the maintenance of your E8 in the ‘Maintenance’ area c in the programme item ‘Information’.
6 Machine settings
14
6 Machine settings
Press the 0 button several times until the JURA Cockpit is displayed on page äääö of the start screen. In the ‘Machine settings’ area f,
you can save the following settings:
Programme item Explanation
Page öää
‘Switch off after’ Set the automatic switch-off time to save energy (switch-off after 15minutes, 30minutes or
1 – 9 hours after the last action on the machine)
‘Water hardness’ Set the hardness of the water used (1°dH to 30°dH) to prevent limescale building up in your
machine
‘Product name’ Display product images with/without product names on the start screen
‘Units’ Set the unit for the amount of water (ml or oz)
Page äöä
‘Choose language’ Set language
‘Rinse the milk system’ Automatic: Milk system rinsing starts automatically after preparation of a speciality coffee with milk.
Manual: The milk system rinsing can be initiated manually via the Cockpit in the c section.
‘Empty system’ Empty the system to protect the E8 from frost during transport (see chapter 10 ‘Transport and
environmentally friendly disposal – Transport/ Emptying the system’)
‘Version’ View software version
Page ääö
‘Factory setting’ Reset your E8 to factory settings (the machine then switches off)
‘Connect accessory’
(only displayed if JURA Wi-Fi
Connect is being used)
Establish a wireless connection between your E8 and the Cool Control milk cooler or disconnect it
again
‘Wi-Fi connection’
(only displayed if JURA Wi-Fi
Connect is being used)
Wirelessly connect the E8 to the JURA app (J.O.E.
®
) or disconnect again (see chapter 3 ‘Preparing and
using for the first time – Establishing a Wi-Fi connection’)
7 Maintenance
Basic information about maintenance:
U
Press the 0 button several times until the JURA Cockpit is displayed on page äääö of the start screen. You can manage the
maintenance of your E8 in the c section.
U
In the Cockpit of your E8, maintenance programmes that need to be carried out are shown in the form of messages with red
backgrounds. Press the button that corresponds to the message to go straight to the maintenance programme.
Maintenance programmes that are due imminently are indicated on your E8 by means of a bar display within the message.
U
Carry out each maintenance programme when you are prompted to do so.
Rinsing the machine
You can start coffee system rinsing manually at any time.
Precondition:The start screen is displayed.
T
Place one receptacle under the coffee spout and another under the fine foam frother.
Tap, click or scan to watch
the video tutorial on YouTube
7 Maintenance
15
T
Press the 0 button several times until the JURA Cockpit is displayed on page äääö of the start screen.
T
Press the c button.
T
Press the ‘Rinse the coffee system’ button to start the rinse operation.
‘Machine is rinsing’
The operation stops automatically.
Rinsing the milk system
After each milk preparation, the E8 prompts you to perform a milk system rinse.
In the machine settings, you can set whether the milk system rinsing is to be initiated manually or automatically 15 minutes after prepara-
tion (see chapter ‘6 Machine settings’).
Precondition:The start screen is displayed.
T
Place a receptacle under the fine foam frother.
T
Press the 0 button several times until the JURA Cockpit is displayed on page äääö of the start screen.
T
Press the c button.
T
Press the ‘Rinse the milk system’ button to start the rinse operation.
The fine foam frother is rinsed. The operation stops automatically.
Cleaning the milk system
The fine foam frother must be cleaned daily if milk has been prepared to make sure it functions perfectly and also in the interests of hygiene.
CAUTION
If the wrong cleaning agent is used, the machine could be damaged and/or traces could be left behind in the water.
T
Use only original JURA maintenance products.
E JURA milk system cleaner is available from specialised dealers.
E Use the container supplied for milk system cleaning.
Precondition:‘Clean the milk system’ is displayed in the Cockpit.
T
Press the 0 button several times until the JURA Cockpit is displayed on page äääö of the start screen.
T
Press the ‘Clean the milk system’ button.
T
Press the ‘Start’ button.
‘Clean the milk system’ / ‘Milk system cleaner’
T
Remove the milk pipe from the milk container or milk cooler.
T
Pour one dosing unit of milk system cleaner into the container for milk system cleaning.
Tap, click or scan to watch
the video tutorial on YouTube
7 Maintenance
16
T
Place the container under the hot-water nozzle and the fine foam frother and connect the milk pipe to the container.
E To connect the milk pipe to the container correctly, the pipe must be fitted with a connector HP3.
T
Press the ‘Next’ button.
The fine foam frother and the milk pipe are cleaned.
The operation stops automatically.
Dismantling and rinsing the fine foam frother
If insufficient foam is produced when the milk is frothed or milk sprays out of the fine foam frother, this may get dirty. If this happens, dis-
mantle and rinse the fine foam frother.
T
Remove the milk pipe and rinse it thoroughly under running water.
T
Remove the fine foam frother.
T
Dismantle the fine foam frother into its individual parts.
T
Rinse all the parts under running water. If there are severely dried-on milk residues, firstly immerse the individual parts in a solution of
250ml water and one dosing unit of JURA milk system cleaner. Then rinse the individual parts thoroughly.
T
Re-assemble the fine foam frother.
E Ensure that all individual parts are correctly and firmly connected to ensure optimum operation.
T
Re-fit the fine foam frother on the milk system.
1
2
7 Maintenance
17
Inserting/changing the filter
Once the filter cartridge stops working (depending on the water hardness setting), the E8 will prompt you to change the filter.
E Your E8 no longer has to be descaled if you are using the CLARIS Smart
+
filter cartridge.
E CLARIS Smart
+
filter cartridges are available from specialised dealers.
Precondition:The start screen is displayed. (Alternatively, ‘Filter’ is displayed in the Cockpit if the filter’s capacity has been exhausted.)
T
Remove and empty the water tank.
T
Turn the filter cartridge anticlockwise and remove it along with the extension from the water tank.
T
Fit the filter cartridge extension on top of a new CLARIS Smart
+
filter cartridge.
T
Insert the filter cartridge with its extension into the water tank.
T
Turn the filter cartridge clockwise until it audibly clicks into place.
T
Fill the water tank with fresh, cold water and reinsert the tank.
The machine automatically detects that you have just inserted/changed the filter cartridge.
‘Filter is beingrinsed’, water flows directly into the drip tray.
Cleaning the machine
After 180preparations or 80switch-on rinses, the E8 will prompt you to clean it.
CAUTION
If the wrong cleaning agent is used, the machine could be damaged and/or traces could be left behind in the water.
T
Use only original JURA maintenance products.
E The cleaning programme lasts approximately 20 minutes.
E Do not interrupt the cleaning programme. The quality of cleaning will be impaired if you do so.
E JURA cleaning tablets are available from specialised dealers.
Precondition:‘Clean’ is displayed in the Cockpit.
Tap, click or scan to watch
the video tutorial on YouTube
Tap, click or scan to watch
the video tutorial on YouTube
7 Maintenance
18
T
Press the 0 button several times until the JURA Cockpit is displayed on page äääö of the start screen.
T
Press the ‘Clean’ button.
T
Press the ‘Start’ button.
‘Empty grounds’
T
Empty the drip tray and coffee grounds container and put them back into the machine.
‘Clean’
T
Place one receptacle under the coffee spout and another under the fine foam frother.
T
Press the ‘Next’ button.
Water flows out of the coffee spout and the fine foam frother.
The operation is interrupted, ‘Add cleaning tablet’.
T
Open the cover behind the bean container.
T
Insert a JURA cleaning tablet into the filler funnel.
T
Close the cover.
T
Press the ‘Next’ button.
Water flows repeatedly out of the coffee spout and the fine foam frother.
‘Empty grounds’
T
Empty the drip tray and coffee grounds container and put them back into the machine.
Descaling the machine
The E8 builds up deposits of limescale over time and automatically prompts you to descale it when necessary. The degree of calcification
depends on the hardness of your water.
E If you are using a CLARIS Smart
+
filter cartridge, you will not be prompted to descale.
J
CAUTION
If the descaling agent comes into contact with the skin or eyes, this can cause irritation.
T
Avoid contact with the skin or eyes.
T
Rinse off the descaling agent with clean water. Should you get any descaling agent in your eye, see a doctor.
CAUTION
If the wrong descaling agent is used, the machine could be damaged and/or traces could be left behind in the water.
T
Use only original JURA maintenance products.
CAUTION
If the descaling operation is interrupted, there may be damage to the machine.
T
Allow the descaling programme to run to the end.
Tap, click or scan to watch
the video tutorial on YouTube
7 Maintenance
19
CAUTION
If the descaling agent comes into contact with sensitive surfaces (e.g. marble), damage cannot be ruled out.
T
Clean up any splashes immediately.
E The descaling programme lasts approximately 40minutes.
E JURA descaling tablets are available from specialised dealers.
Precondition:‘Descale’ is displayed in the Cockpit.
T
Press the 0 button several times until the JURA Cockpit is displayed on page äääö of the start screen.
T
Press the ‘Descale’ button.
T
Press the ‘Start’ button.
‘Empty drip tray’
T
Empty the drip tray and coffee grounds container and put them back into the machine.
‘Agent in tank’
T
Remove and empty the water tank.
T
Completely dissolve 3JURA descaling tablets in a receptacle holding 500ml of water. This may take several minutes.
T
Pour the solution into the empty water tank and insert it into the machine.
T
Place one receptacle under the hot-water nozzle and another under the fine foam frother.
T
Press the ‘Next’ button.
Water flows repeatedly out of the hot-water nozzle and the fine foam frother.
‘Empty drip tray’.
T
Empty the drip tray and coffee grounds container and put them back into the machine.
‘Rinse the water tank’ / ‘Fill water tank’
T
Empty the receptacles and place them back under the coffee spout and the fine foam frother.
T
Remove the water tank and rinse it thoroughly.
T
Fill the water tank with fresh, cold water and reinsert the tank.
T
Press the ‘Next’ button.
Water flows repeatedly out of the hot-water nozzle and the fine foam frother.
‘Empty drip tray’
T
Empty the drip tray and coffee grounds container and put them back into the machine.
E If the descaling operation stops unexpectedly, rinse the water tank thoroughly.
3x
8 Display messagess
20
Descaling the water tank
Limescale deposits may form in the water tank. To ensure correct function of the machine, descale the water tank from time to time.
T
Remove the water tank.
T
If you use a CLARIS Smart
+
filter cartridge, remove this.
T
Completely fill the water tank and dissolve 3 JURA descaling tablets in it.
T
Leave the water tank with the descaling solution for several hours (e.g. overnight).
T
Empty the water tank and rinse it thoroughly.
T
If you use a CLARIS Smart
+
filter cartridge, insert this again.
T
Fill the water tank with fresh, cold water and reinsert the tank.
Cleaning the bean container
Coffee beans may be covered with a slight oil film which remains on the walls of the bean container. These traces may negatively affect the
coffee result. For this reason clean the bean container from time to time.
Precondition:‘Fill bean container’ is displayed.
T
Switch the machine off with the On/Off button Q.
T
Remove the aroma preservation cover.
T
Clean the bean container with a soft, dry cloth.
T
Fill the bean container with coffee beans and close the aroma preservation cover.
8 Display messagess
Messages on the start screen
Message Cause/Result Action
‘Fill water tank’ The water tank is empty. You cannot prepare any
products.
T
Fill the water tank (see chapter 5 ‘Daily operation –
Filling the water tank’).
‘Empty grounds’ /
‘Empty drip tray’
The coffee grounds container is full. / The drip tray is
full. You cannot prepare any products.
T
Empty the coffee grounds container and the drip
tray (see chapter 5 ‘Daily operation – Maintenance
actions’).
‘Drip tray not fitted’ The drip tray is not inserted correctly or is not
inserted at all. You cannot prepare any products.
T
Fit the drip tray.
‘Fill bean container’ The bean container is empty. You cannot prepare
any speciality coffees, but you can prepare hot water
and milk.
T
Fill the bean container (see chapter 3 ‘Preparing
and using for the first time – Filling the bean
container’).
‘Too hot’ The system is too hot to start a maintenance
programme.
T
Wait for several minutes until the system has
cooled or prepare a speciality coffee or hot water.
Messages in the Cockpit
Message Cause/Result Action
The filter symbol $
lights up red.
‘Filter’
The filter cartridge no longer works.
T
Replace the CLARIS Smart
+
filter cartridge (see chapter 7
‘Maintenance – Inserting/changing the filter’).
‘Clean’ The E8 is prompting you to clean it.
T
Perform cleaning (see chapter 7 ‘Maintenance – Cleaning the
machine’).
‘Descale’ The E8 is prompting you to descale it.
T
Perform descaling (see chapter 7 ‘Maintenance – Descaling
the machine’).
‘Clean the milk
system’
The E8 prompts you to clean the milk system.
T
Perform milk system cleaning (see chapter 7 ‘Maintenance –
Cleaning the milk system’).
9 Troubleshooting
Problem Cause/Result Action
Insufficient foam is produced when the
milk is frothed or milk sprays out of the
fine foam frother.
The fine foam frother is dirty.
T
Clean the fine foam frother (see chapter 7
‘Maintenance – Cleaning the milk system’).
T
Dismantle and rinse the fine foam frother
(see chapter 7 ‘Maintenance – Dismantling
and rinsing the fine foam frother’).
10 Transport and environmentally friendly disposal
21
Problem Cause/Result Action
Coffee only comes out in drips when it is
being prepared.
The coffee is ground too finely and
obstructs the system.
T
Set the grinder to a coarser setting (see
chapter 4 ‘Preparation – Adjusting the
grinder’).
The water hardness may not have been
correctly set.
T
Perform descaling (see chapter 7
‘Maintenance – Descaling the machine’).
There is dry ground coffee behind the
coffee grounds container.
The beans used are resulting in an
above-average volume of ground coffee.
T
Reduce the coffee strength or choose a
finer grinder setting (see chapter 4
‘Preparation – Adjusting the product
settings’).
Little or no water or steam comes out of
the fine foam frother. The pump is very
quiet.
The connector of the fine foam frother
may be blocked by milk residues or
limescale fragments loosened during
descaling.
T
Remove the fine foam frother.
T
Unscrew the black connector with the aid
of the hexagonal hole on the measuring
spoon for ground coffee.
T
Clean the connector thoroughly.
T
Screw the connector back on tightly by
hand.
Grinder is making a very loud noise. There are foreign objects in the grinder.
T
Contact customer support in your
country (see chapter ‘13 JURA contact
details/ Legal information’).
‘Error2’ or ‘Error5’ is displayed. If the machine has been exposed to the
cold for a long period of time, heating may
be disabled for safety reasons.
T
Warm the machine at room temperature.
Other ‘Error’ messages are displayed. –
T
Contact customer support in your
country (see chapter ‘13 JURA contact
details/ Legal information’).
E If you were unable to solve the problem, contact customer support in your country (see chapter ‘13 JURA contact details/ Legal
information’).
10 Transport and environmentally friendly disposal
Transport/ Emptying the system
Keep the packaging for your E8. It should be used to protect the machine during transport.
In order to protect the E8 from frost during transport, the system must be emptied.
Precondition:The start screen is displayed.
T
Place one receptacle under the coffee spout and another under the fine foam frother.
T
Press the 0 button several times until the JURA Cockpit is displayed on page äääö of the start screen.
T
Press the f button.
T
Press the 0 button several times until the programme item ‘Empty system’ is displayed (page äöä).
T
Press the ‘Empty system’ button.
T
Remove and empty the water tank.
‘System is emptying’
Steam will continue to be discharged from the fine foam frother until the system is empty. Your E8 is switched off.
Disposal
Please dispose of old machines in an environmentally neutral way.
H
Old machines contain valuable, recyclable materials which should be recycled. Please therefore dispose of old machines via suitable collec-
tion systems.
11 Technical data
22
11 Technical data
Voltage 220–240V~, 50Hz
Power 1450W
Conformity mark
A
Pump pressure static, max. 15bar
Holding capacity of water tank (without filter) 1.9l
Holding capacity of bean container 280g
Holding capacity of coffee grounds container max. 16 portions
Cable length approx. 1.1m
Weight approx. 9.6kg
Dimensions (W×H×D) 28.0 × 35.1 × 44.6cm
Milk system with connector HP3
Interchangeable milk spout CX3
CLARIS filter cartridge Smart
+
(RFID technology) Frequency band 13.56 MHz
Max. transmission power < 1 mW
JURA Wi-Fi Connect (Wi-Fi connection) Frequency band 2.4 GHz
Max. transmission power < 100 mW
JURA type 776
Information for testers (repeat test in accordance with DIN VDE 0701-0702): The central grounding point (CGP) is located on the underside
of the machine, right next to the mains cable’s connection point.
A
Addresses 24
Adjusting the product settings 12
Americano 10
Aroma preservation cover
Bean container with aroma preservation cover 3
B
Bean container
Bean container with aroma preservation cover 3
Cleaning 20
Filling 6
Bus bar
Technical data 22
Button
On/Off button 3
C
Cappuccino 10
Central grounding point 22
Children 4
CLARIS Smart filter cartridge
Changing 17
Inserting 17
Cleaning
Bean container 20
Machine 17
Cockpit 8, 14
Coffee 9
Coffee grounds container 3
Coffee spout
Height-adjustable coffee spout 3
Connecting an accessory 8
Consistency of grind
Adjusting the grinder 11
Grinder adjustment switch 3
Contact details 24
12 Index
Cortado 10
Cover 3
Water tank 3
Cup grille 3
Customer support 24
D
Damage
Preventing damage 5
What to do in the event of damage 4
Declaration of Conformity 24
Descaling
Machine 18
Water tank 20
Display 3
Cockpit 8
Display messages 20
Disposal 21
Drip tray 3
Insert 3
E
Emptying the system 21
Errors
Troubleshooting 20
Espresso 9
Espresso doppio 10
EU Declaration of Conformity 24
F
Filler funnel
Filler funnel for ground coffee 3
Filling
Bean container 6
Water tank 13
Filter
Changing 17
Inserting 17
12 Index
23
Fine foam frother 3
Dismantling and rinsing 16
First-time use 6
Flat white 10
G
Grinder adjustment switch 3
Ground coffee 10
Measuring spoon for ground coffee 3
Grounding point 22
H
Height-adjustable coffee spout 3
Hotline 24
Hot water 11
Hot-water nozzle 3
I
Insert for drip tray 3
Instant coffee
Ground coffee 10
Interchangeable milk spout 22
J
JURA
Contact details 24
L
Latte macchiato 10
Lungo 10
M
Machine
Descaling 18
Rinsing 14
Setting up 6
Machine settings 14
Mains cable 3
Maintenance 14
Maintenance actions 13
Measuring spoon for ground coffee 3
Messages, display 20
Milk
Connecting milk 8
Milk system 22
Clean 15
Fine foam frother 3
Rinsing 15
Milk system rinsing 15
P
Preparation 9, 10
Americano 10
Cappuccino 10
Coffee 9
Cortado 10
Espresso 9
Espresso doppio 10
Flat white 10
Ground coffee 10
Hot water 11
Latte macchiato 10
Lungo 10
Macchiato 10
Speciality Selection 9
Problems
Troubleshooting 20
Product settings
Adjusting 12
Proper use 4
R
RFID 22
Rinsing
Machine 14
S
Safety information 4
Service socket 3
Setting up
Setting up the machine 6
Speciality Selection
Extra Shot 9
Ground coffee 9
Switching off 12
Switching on 12
Symbol description 4
T
Technical data 22
Interchangeable milk spout 22
Milk system 22
Tel 24
Transport 21
Troubleshooting 20
U
Use, first time 6
Users 4
W
Water hardness
Determining the water hardness 6
Water tank 3
Descaling 20
Filling 13
Wi-Fi 22
Wi-Fi Connect 3, 8
Wi-Fi connection 8
Wireless connection 6, 8, 17, 22
13 JURA contact details/ Legal information
24
E8
(C)
/en/20230926_BA-Online
13 JURA contact details/ Legal information
JURA Elektroapparate AG
Kaffeeweltstrasse 10
CH-4626 Niederbuchsiten
Tel. +41 (0)62 38 98 233
E You can find additional contact details for your country at jura.com.
E If you need assistance with using your machine, you can find this at jura.com/service.
E Your opinion is important to us! Use the contact details at jura.com.
Directives
The machine complies with the following directives:
U
2014/35/EU– Low Voltage Directive
U
2014/30/EU– Electromagnetic Compatibility
U
2009/125/EC– Ecodesign Directive
U
2011/65/EU– RoHS Directive
U
2014/53/EU – Wireless Voltage Directive
A detailed EU Declaration of Conformity for your E8 can be found at jura.com/conformity.
Technical changes
We reserve the right to make technical changes. The diagrams used in these instructions for use are for illustration purposes only and do
not represent the original colours of the machine. Some details of your E8 may vary.
