5 SHELF RACKING UNIT (350KG CAPACITY PER
LEVEL)
MODEL NO: AP6350.V3 & AP6350GS.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, and local authority regulations are adhered to when assembling and using this rack.
9 Locate rack in a suitable area where it will not be an obstruction.
9 Keep the general area clean, uncluttered and ensure there is adequate lighting.
WARNING! Erect rack on a level and solid surface such as concrete.
9 Keep children and unauthorised persons away from the storage area.
8 DO NOT use the rack for any purpose other than that for which it is are designed.
8 DO NOT use rack outdoors.
8 DO NOT get the rack wet or use in damp or wet locations or areas where there is condensation.
8 DO NOT clean the shelf supports with any solvents which may damage the surface.
9 Ensure that the rack is properly assembled before loading them with heavy items.
WARNING! Maximum load for each shelf is 350kg.
9 Where possible the rack should be fixed to the wall with suitable fixings.
9 Place heavier items on the lower shelves.
9 Heavier items should be evenly distributed across the shelves.
2. INTRODUCTION
Fully painted steel/galvanised frame with five MDF shelves (AP6350 painted/AP6350GS galvanised). 350kg capacity per level giving a
maximum capacity of 1750kg per rack. No nuts and bolts for easy assembly. Clips together in minutes. Two piece uprights allow use as a
single bay rack, or split in two separate shelf systems or workstations.
3. SPECIFICATION
4. CONTENTSo
Carefully unpack the product and check the contents against the list below. Should any items be missing or damaged make immediate
contact with your Sealey stockist.
Refer to
instructions
Wear protective
gloves
Model No: AP6350.V3/AP6350GS.V3
Overall Size (WxDxH): 900x400x1800mm
Shelf Capacity: 350Kg
AP6350.V3, AP6350GS.V3 Issue 3 (4) 22/05/24
Original Language Version
© Jack Sealey Limited
5. a ASSEMBLY
5.1.
5.2.
5.3.
.
Decide on height of
lowest shelf.
Use shelf to support
uprights ‘B’.
Refer to Step1B
below.
Build ends rst by joining B sections together refer to Step 2B
Use soft hammer/mallet
to tap down horizontal sup-
ports.
Use screwdriver to bend
tabs down.
Joining pieces
Step 1
Step 2
Step 1B
Step 2B
AP6350.V3, AP6350GS.V3 Issue 3 (4) 22/05/24
Original Language Version
© Jack Sealey Limited
AP6350.V3, AP6350GS.V3 Issue 3 (4) 22/05/24
Original Language Version
© Jack Sealey Limited
Step 3
Step 4
Fit shelves and last 2 C and E pieces.
Fit last shelf.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please
email or call our technical team on technical@sealey.co.uk or 01284 757505.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
