Philips DECT5152S/07 User Manual

IRL

3111 285 21872

User manual

Charge the handset(s) 24 hours

before use.

Quick start guide

http://www.philips.com/faqs/dect

Quick start guide

Answer/end a call

Make a call

Redial a number

Call from phonebook

Add a name in the phonebook

Adjust the earpiece volume during a call

Adjust the handset loudspeaker volume

Mute and unmute the microphone

Read Call log

Read an event

Set the date and time

Set the handset external ring tone

Activate/deactivate the answer machine

Transfer a call/Intercom (if there are

at least 2 handsets)

Predial number & or and dial number

up and browse and

down,browse through the list and

Predial number and select scroll to Store

and select ,enter the name and press OK

Scroll up to increase the volume, scroll down

to decrease the volume

During a handsfree call,up to increase, down to

decrease

During a call press Options,press Mute

press End mute

Press to enter the carousel,scroll to Sounds

and select. ,press to select Handset ring tones.

Press to select External ring tone

Browse through the list to hear the ring tones and select

your ring tone

Press to enter the carousel,scroll to Handset

and select. ,scroll to Date and time and select

Press to select Set date and enter the current date,

press OK. Scroll to Set time and enter the current time,

press OK

Press View

up and browse

Press + number phone

Press on the base station to switch the answer

machine ON or OFF

The pilot key allows you to browse the menus.Up to go left in the menus and down to go

right in the menus & options.

Press to select a menu or an option and validate a setting.It is also used as shortcut to menus

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 1

DECT 511/DECT 515 handset

http://www.philips.com/faqs/dect

Pilot key

Press to enter the carousel or

select a menu or an option

Scroll to move through the

menus & options

Move the cursor left/right

Scroll up to access the Call

Log from idle mode

Scroll down to access the

Phonebook from idle mode

A long press to unlock the keypad

Loudspeaker*

- Short press to take the line or to

activate the handset loudspeaker

during a call

Keypad lock & Editing

- Short press to insert *

- Long press to lock/unlock the

keypad in idle mode

- Long press to insert R (in

between-digit pause) when dialling

- Long press to enter multitap

system or Eatoni

editor when

entering text

- A short press to change the

letter when editing in Eatoni

®.

SMS key

- Short press to directly access

Send new SMS from idle mode

- Short press from the Phonebook

or the Call log menu to edit an SMS

Alarm clock

- A short press to dial 0

- A long press to activate/deactivate

the alarm clock

Do not disturb & case mode

- Short press to insert # when

dialling

- Long press to activate/deactivate

the “Do Not Disturb” mode

- Long press to insert a pause (P)

when dialling

- Press to switch case mode when

editing

Clear/Recall

- To correct a digit when predialling

or a character when editing

- Short press to go back one menu

when navigating

- Long press to return to idle

mode when navigating

- To insert R for operator services

when on line

Talk

- Press to take the line,answer a

call or hang up.

Earpiece

Microphone

Call transfer/Intercom

- Short press to initiate or cancel

internal call

- Short press during internal call to

transfer the call or switch between

internal call and External call

- Short press to answer an internal

call or to release an internal call

DECT 511/DECT 515

Handset

*Warning : Handsfree activation could suddenly increase the volume in the earpiece to a very

high level.Make sure the handset is not too close to your ear.

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 2

Icons on the handset display

http://www.philips.com/faqs/dect

Icons on the handset display

The display gives information about the operation of your telephone

The answer machine is activated (DECT 515).When blinking,this symbol

indicates that there is a new message on the answer machine or on the

operator voice mailbox. When fast blinking it shows that the answer

machine is full.

When charging,the battery bars scroll from empty to full status.

When the handset discharges,the battery shows the status :

Full ,2/3 , 1/3

and empty .

An internal call is in progress. When blinking, this symbol indicates that there

is an internal incoming call.

The handset loudspeaker is activated.When blinking,this symbol shows that

the base loudspeaker is activated (only for DECT 515).

The ring tone is deactivated.

The SMS function is activated.When blinking,this symbol indicates that a

new SMS has been received.When fast blinking,it indicates that the SMS

memory is full.

The handset is registered and in range of the base.When blinking,this symbol

indicates that the handset is not registered to the base.

An external call is in progress. When blinking,this symbol indicates that

there is an incoming external call in progress or that the line is already busy.

On first use, it is sometimes necessary to wait for a few minutes of charge before seeing icons

on the display.

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 1

DECT 511/DECT515 base stations

http://www.philips.com/faqs/dect

Paging key

The paging key enables you to locate a missing handset.Press the key until the handset starts

to ring.Once retrieved,press any key on the handset to end paging.

Delete key

Short press to delete current

message

Long press to delete all the

messages (except unread ones)

ON/OFF key

Press to switch the answer

machine ON or OFF

Play/Stop key

Short press to play new

message

Short press to stop a message

while listening to it

Skip/Fast forward key

Short press to go to the next

message while listening

Long press to fast forward the

current message while listening

Paging key

Press to locate all handsets

New message

indicator

When blinking,it indicates

that there is a new message.

When fast blinking,it indicates

that the answer machine

memory is full.

base station

Loudspeaker

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 2

Table of contents

http://www.philips.com/faqs/dect

Quick start guide 1

DECT 511 / DECT 515 handset 2

Icons on the handset display 3

DECT 511 / DECT 515 base stations 4

Table of Contents 5-6

Menu structure 7-11

Conformity, Environment and Safety 12

Declaration of conformity

Using GAP standard compliance 13

Installing the DECT 511/515

Unpacking your DECT 511 14

Unpacking your DECT 515 14

Installing the base station 15

Installing and replacing the batteries in the handset 15

Battery life and range 15

Introduction

Philips screen saver 16

Idle mode 16

Understanding the menu system 16

How to navigate in the menus 16

Basic principles 17

In-call features 18

Editing systems 19-20

SMS

Send new SMS 21

Read SMS 22

SMS settings 25

Handset

Babysit mode 28

Registration 28

Rename handset 29

Date & time 29

Display contrast 30

Backlight 30

Screen saver 30

Table of contents

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 3

Table of contents

http://www.philips.com/faqs/dect

Answer machine

Saved messages 31

Outgoing messages 33

Answerphone settings 33

Record and listen to a memo 37

Intercom

Internal call 38

Call transfer 38

Conference call 39

Babysit mode 39

Phonebook

Add new 40

Call log

Delete all 45

Call log settings 45

Operator services 46

Extra

Call duration 47

Alarm clock 47

“Do Not Disturb” mode 48

Sounds

Handset ring tones 49

Base ring tones 50

Group ring tones 50

Handset ring tone volume 50

Base ring tone volume 50

My ring tones 51

Record personal melody 51

Settings 52

Base

Enable registration 54

Line settings 54

Service code settings 56

FAQ 57-58

Troubleshooting 59-60

Index

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 4

Menu structure

http://www.philips.com/faqs/dect

SMS

Send new SMS

Choose SMS box*

Send SMS to phone

View number

Forward

Send again

Delete SMS

Copy to phonebook

Call

Read SMS

SMS Settings

Choose SMS box*

Mode

SMS boxes*

SMS centre

Handset

Babysit mode

Registration

Rename handset

Date & time

Display contrast

Backlight

Screensaver

On or Off

Enter name

Set date

Levels (1 to 5)

Off / 10s / 20s

Set time

Enter RC code

On or Off

Un-register handset

Menu structure

By using the “Pilot key” on the side of the handset,you can scroll through the menus.

* only available in the UK

Base selection

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 5

Menu structure

http://www.philips.com/faqs/dect

Call all

Handset list

Intercom

Change code

Answerphone settings

Mode

On or Off

Toll saver / 3 / 5 / 7

Rings before answer

Voice language

Off/Low/Medium/

High/Boost

Call screening

Recording quality

Answer and record

with personalised OGM

Answer only with

personalised OGM

Answer and record

with predefined OGM

Answer only with

predefined OGM

High / Standard

Mode (On or Off)

Remote control

Play

Call

Delete

Store

Send SMS

Answer machine

Saved messages

Record a memo

Outgoing messages

Answ.machine mode

Record outgg msg

Standard OGM for

answ. & record mode

Standard OGM for

answer mode only

Group A

Play/Record new

Delete

Group B

Group C

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 6

Menu structure

http://www.philips.com/faqs/dect

Operator services

Call forward

Cancel call forward

Call forward when

line busy

Call forward when

unanswered

Voice mail

Cancel call back

Withhold identity

Cancel call forward

when line busy

Cancel call forward

when unanswered

All calls

No call

Call log

View

Delete all

Call log settings

Incoming calls

Outgoing calls

All calls

Unanswered calls only

Calls with answer

machine message only

View

Add new

Phonebook

Call

Change number

Change name

Define the group

A / B / C

Change SMS box*

Delete

Send SMS

Play

Call

View number

Store

Delete

Send SMS

* only available in the UK

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 7

Menu structure

http://www.philips.com/faqs/dect

Extra

Call duration

Alarm clock

Do not disturb mode

Activation

Set day

Start time

Stop time

Allowed caller choice A / B / C

Activation On or Off

On or Off

A / B / C

Ring tones

Ring tone volume

Low/Medium/High

Set day

Set time

Settings

* only available in the UK

Settings

Base loudspeaker

volume

Earpiece tone

Key & feedback tones

Notification beep

Music on hold

Sounds

Handset ring tones

Handset ring tone

volume

Base ring tone

volume

My ring tones*

Base ring tones

Group ring tones

External ring tone

Internal ring tone

Ring tone list

Handset

Base

Record melody

Play

Record new

Delete

Rename

Delete

Rename

Delete

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 8

Menu structure

http://www.philips.com/faqs/dect

Base station

Enable registration

Line settings

Service code settings

On or Off

Short flash / Long flash

Dial mode

Tone / Pulse

Recall type

Choose country/oper.

First ring

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 9

Conformity,Environment and Safety

http://www.philips.com/faqs/dect

Safety information

This equipment is not designed to make emergency calls when the power fails.An alternative

has to be made available to allow emergency calls.

Conformity

Hereby,Philips declares that the DECT 511xx and DECT515xx are in compliance with the

essential requirements and other relevant provisions of Directive 1999/5/EC.This product can

only be connected to the analogue telephone network of the UK and Ireland.

Power requirements

This product requires an electrical supply of 220-240 volts,alternating monophased power,

excluding IT installations defined in standard EN 60-950.In case of power failure,the

communication can be lost.

Warning !

The electrical network is classified as hazardous according to criteria in the standard EN 60-

950.The only way to power down this product is to unplug the power supply from the

electrical outlet.Ensure the electrical outlet is located close to the apparatus and is always

easily accessible.

Telephone connection

The voltage on the network is classified as TNV-3 (Telecommunication Network Voltages),as

defined in the standard EN 60-950.

Safety precautions

Do not allow the handset to come into contact with water.Do not open the handset or the

base station.You could be exposed to high voltages.Do not allow the charging contacts or the

battery to come into contact with conductive materials.

Environmental care

Please remember to observe the local regulations regarding the disposal of your packaging

materials,exhausted batteries and old phone and where possible promote their recycling.

Conformity,Environment and Safety

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 10

Declaration of conformity

http://www.philips.com/faqs/dect

Philips has marked the battery and packaging with standard symbols designed to promote the recycling and appropriate

disposal of your eventual waste.

A financial contribution has been paid to the associated national recovery & recycling system.

The labelled packaging material is recyclable.

DECT

is a Trade Mark of ETSI registered for the benefit of the implementers of the DECT technology.

Philips Consumer Electronics

Route d’Angers

72081 Le Mans Cedex 9

France

Declare that the products DECT 511xx and DECT 515xx are in compliance with the Annex III

of the R&TTE-Directive 1999/5/EC and then with the following essential requirements:

Article 3.1.a (protection of the health & the safety of the user) :EN 60950-1 (10/2001)

Article 3.1.b (protection requirements with respect to electromagnetic compatibility :

ETSI EN 301 489-6 V1.2.1 (08/2002) & ETSI EN 301 489-1 V1.4.1 (08/2002)

Article 3.2 (effective use of the radio spectrum) EN 301 406 (2003)

The presumption of conformity with essential requirements regarding Council Directive

1999/5/EC is ensured.

Date :10/05/2004 Le Mans

Quality Manager, Home Communication

Using GAP standard compliance

The GAP standard guarantees that all DECT

GAP handsets and base stations comply with a

minimum operating standard irrespective of their make.Your DECT 511/515 handset and base

station are GAP compliant,which means the minimum guaranteed functions are :register a

handset,take the line, receive a call and dial.The advanced features may not be available if you

use another handset than a DECT 511/515 with your base station.

To register and use your DECT 511/515 handset with a GAP standard base station of a

different make, first follow the procedure described in the manufacturer’s instructions, then

follow the procedure page 28.

To register a handset from another make to the DECT 511/515 base station,place the base

station into registration mode (page 28),then follow the procedure in the manufacturer’s

instructions.

Declaration of conformity

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:00 Page 11

Installing the DECT511/515

http://www.philips.com/faqs/dect

Installing the DECT 511/515

Unpacking your DECT 511

DECT 511

PHILIPS

DECT 515

One DECT 511 base station One DECT 511 handset

NiMh 2HR

AAA 600 mAh

rechargeable

batteries

NiMh 2HR

AAA 600 mAh

rechargeable

batteries

A user guide A guarantee

A power supply A line cord*

The DECT 511 package contains:

Unpacking your DECT 515

DECT 511

PHILIPS

DECT 515

One DECT 515 base station One DECT 515 handset

A user guide A guarantee

The DECT 515 package contains:

In DECT 511 and DECT 515 multi-handset packs,you will also find one or more additional

handsets,chargers with their power supply and additional rechargeable batteries.

*Warning : You may find in the box the line adaptor delivered separately from the line cable.

In this case, please, first plug this line adaptor to the line cable before connecting it to the line

socket.

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:01 Page 12

Installing the DECT511/515

http://www.philips.com/faqs/dect

Installing the base station

Situate your product close enough to the telephone and mains power sockets so that the cables will

reach.To properly install the base station,plug the line cord and the power cable into the base station.

Plug the cord and the cable into the wall.A beep indicates that the phone is properly installed (only

available for DECT515). If you have a broadband DSL Internet Installation, please make sure you have

one DSL filter plugged directly on each line socket used in the house and check the modem and the

phone are plugged in the correct filter slot (one specific for each).

Warning ! The electrical network is classified as dangerous according to criteria in the standard EN 60-

950.The only way to power down this product is to unplug the power supply from the electrical outlet.

Ensure the electrical outlet is located close to the apparatus and is always easily accessible.

Please take care that the power supply and telephone line are connected to the correct sockets as

incorrect placement could damage your equipment.

Warning !Always use the cables provided with the product.

Installing and replacing the batteries in the handset

To insert the batteries, open the battery cover,place the batteries as indicated and put the battery cover

back.When the handset is placed on the base station the 3 battery bars scroll (if charge is needed).Allow

the handset to charge for 24 hours to reach full charge. On first use it may be necessary to wait for a

few minutes before seeing symbols on the display.

In case you need to change the batteries,the following type is mandatory 2HR AAA NiMh 600 mAh.

Warning: the base station must always be plugged into the mains when charging or when in use.Always use

rechargeable batteries.

Connect the power supply

Do not insert anything in this opening

Battery life and range

Batteries should not be disposed of with general household waste.

Battery life in standby

mode

Battery life in

communication

Indoor range Outdoor range

up to 200 hours up to15 hours up to 50 metres up to 300 metres

Optimal battery life is reached after 3 cycles of complete charge & discharge.When reaching the range

limit and the conversation becoming crackly,move closer to the base.To reach optimal range, place the

base station away from electrical appliances.

Connect the telephone line cord

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:01 Page 13

Introduction

http://www.philips.com/faqs/dect

In idle mode, the DECT 511/515 display shows various information:

Understanding the menu system

Idle mode

Introduction

To access the carousel menu from idle mode, press on

the side of the handset The carousel represents a loop of

icons that gives access to the different first level menus.

Scroll up or down to reach the desired menu and select

The sub menus are listed and represented by little squares

at the bottom of the display.To reach one particular sub-menu

use the “pilot key” and press to validate your choice.

A “tick” shows the selected sub-menu or option.The

shows the option you are browsing.

Note:some menus are also directly accessible via a dedicated

key on the keypad like the SMS menu with or the Intercom

with .

Philips screen saver

After 2 minutes of inactivity, the screen saver is displayed:

You can deactivate it (see p.30)

- The date & time,the name of the handset and the instructions to access

the menu.

- “Do Not Disturb” mode , and the alarm clock , if activated.

- Missed calls ,new SMS or new messages (answer machine)

or network voicemailbox message ,if any.

To activate/deactivate these functions press or

How to navigate in the menus

Press to access the carousel menu

Scroll to Sounds, and select

Scroll to Handset ring tone vol. and select

The current level is heard,browse to hear other levels

Browse through the levels and select one

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:01 Page 14

Basic principles

http://www.philips.com/faqs/dect

To store an SMS

To store a name from predial

Basic principles

To make and to answer a call

To call from the phonebook

Redial from call log

Scroll down to directly access Phonebook

Choose a name in the list

Make the call or press to select Call in the options

Scroll to Store and select

Enter the name and press OK

Press to enter the options

Pre dialling

Dial the number

Direct dialling

Answer a call

When ringing

Dial the number

Make the call

Dial the number

Press the key

Take the line

Scroll up to directly access Call log and select

Choose an entry in the list

Make the call or press to select Call in the options

Scroll to Send SMS and select

Enter the Destination box* and press OK

Enter the text and press

Scroll to Store and select

Press to enter the options

Dial the number

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS settings page 25

* only available in the UK

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:02 Page 15

In call features

http://www.philips.com/faqs/dect

In call features

During an external call,some other options are available.Press to enter Options.

During an external call,you can use the intercom in-call option to call another handset and for

example transfer the call to this handset.

To mute the handset microphone

Intercom (available only if you have at least two handsets)

Press to enter Options

Press to activate or deactivate the handset loudspeaker

Scroll up to increase or down to decrease the volume when on line

Press to enter the options. Scroll to Phonebook or Call log and select

There are 5 volume levels available.The last setting is stored for the next calls.

If you subscribe to the Call waiting service,a beep in the earpiece informs you of a second

incoming call.The name or number of the second caller may be displayed if you also subscribe

to Caller Display service.To answer that second call,use + (according to your

network,the code may be different).Please contact your network provider for more details.

To switch the handset loudspeaker ON/OFF

Caller Line identification and Call waiting

To increase/decrease the handset & earpiece/loudspeaker volume during a call

To access the phonebook or the call log

Press again to resume the conversation (End mute)

Press to select Mute (the caller can no longer hear you)

Press to enter Options

If there is only one additional handset it rings automatically,

otherwise select a handset from the list.

Press Transfer when the second handset has taken the line.

Scroll to Record and select

Scroll to Intercom (the caller can no longer hear you)

Other options are available such as Switch and Conference call (see page 38).

To listen to the conversation,go to the call log menu or the messages list

To record a conversation (DECT 515 only)

Press to enter Options

Warning : Handsfree activation could suddenly increase the volume in the earpiece to a very

high level.Make sure the handset is not too close to your ear.

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:02 Page 16

Editing systems

http://www.philips.com/faqs/dect

The Eatoni

system is a predicitive editing system designed to help you to write an SMS.

A little E in the header helps you to know the mode you are using.

Eatoni

is a word editor that chooses the most probable letter.

The operation of the Eatoni

system is the following:

Press the key that displays the character you want to edit.The character that is most likely to

be correct is displayed on the screen.If it does not match the expected letter, press to

display the next most probable character available on the key.

By default,the first letter of a sentence is in upper case. Use to change the case mode:

- all letters in upper case (AB)

- all letters in lower case (ab) or

- the first letter in upper case and the rest of the word in lower case (Ab).

Punctuation and mathematical marks are available through and while other special

characters are also available on (see table page 20).

Scroll to move the cursor left or right.Press to delete a character ;a long press

deletes the whole text.

The standard multi-tap system

This system allows you to enter the text character by character,pressing the corresponding

key as many times as necessary to reach the desired character.

DECT 511/515 uses two editing systems :Multi-tap and Eatoni

.While editing,a long press on

enables you to switch between the two systems.

Case mode

Editing systems

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:02 Page 17

Editing systems

http://www.philips.com/faqs/dect

Multi-tap Sequence

[space] 1 @ _ # = < > ( ) & ¤ £ $ ¥ [ ] { } ¤ §

a b c 2 à ä ç å æ

d e f 3 è é ) N

g h i 4 ì Γ

j k l 5 7

m n o 6 ñ ò ö

p q r s 7 ß A 2 E

t u v 8 ù ü

w x y z 9 f S Ξ Q

.0 ,/ :;" ' ! ¡ ? ¿ * + - % \ ^ ~ |

Keypad Keys

To write “Peter” with multi-tap

Press once :P

Press twice :Pe

Press once :Pet

Press twice :Pete

Press three times :Peter

To write “Peter”

with Eatoni

Press to

change character

Long press

to activate Eatoni

Press to validate the

name

Press

Eatoni

& LetterWise are trademarks of Eatoni Ergonomics,Inc.and

used by Philips under license.

Let’s compare Multitap and Eatoni

systems to write “Peter”.

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:02 Page 18

SMS

http://www.philips.com/faqs/dect

SMS stands for Short Message Service.To benefit from this service you must subscribe to the Caller

Line Identification Service (CLI) together with the SMS service from your network provider.SMS

can be exchanged with a phone (mobile or compatible fixed lines) provided the receiver has also

subscribed to the CLI & SMS services.

Your DECT 511/515 factory settings correspond to the main national

operator. If you wish to send or receive SMS through another service

provider you must set the corresponding numbers (see page 27 and the

SMS leaflet).

A password can protect your SMS box*,but it is not compulsory.

To send an SMS to the receiver’s own SMS box*,you must know his destination box.

To send an SMS to a phone

Press to directly reach Send new SMS and select

Enter the phone number directly and press OK or press to

retrieve the number from the Phonebook

Enter the Destination box* number (optional),press OK.

Note: the destination box is the SMS box of the receiver.

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS settings page 25

Send new SMS

SMS menu is also accessible via the

carousel or

Important information are also

available on the SMS leaflet in the box

Press to select Send now,otherwise

if you want to store your SMS,scroll to Store and select .

The SMS stored can be later retrieved from Read SMS

Enter the text and press (see page 19)

Enter the password if any and press OK (optional)

* only available in the UK

SMS

Send new SMS

Read SMS

SMS settings

The sent SMS can be up to a maximum of 160 characters long.The special characters ¤,] and [

count for 2.The DECT 511/515 can store 25 SMS for the 3 boxes*.

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:02 Page 19

SMS

http://www.philips.com/faqs/dect

The SMS list contains the stored and received SMS.

The received SMS are shown by and the stored SMS are shown .

This option enables to save a downloaded ring tone in your handset or in your base station (only

available for DECT 515 base station) received through an SMS.This saved ring tone will be then

inserted in the menu Sounds in the list of My ring tones (see p.50).

Read SMS

Scroll to Read SMS and select

Enter the password if any and press OK (optional)

Browse the list of SMS and select the SMS containing the ring tone

Press to select Read SMS

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS settings page 25

Press to directly reach Send new SMS

To save a ring tone

When reading the list of received SMS,some options are only available for SMS received from a phone.

Those options are Reply,Forward,Copy to phonebook, Call and View number.The

options Reply and Copy to phonebook use the sender’s own sub-address.

Scroll to Read SMS and select

Enter the password if any and press OK (optional)

Browse the list of SMS and select

or scroll to View number and select

Press to select Read SMS

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS settings page 25

Press to directly reach Send new SMS

To read an SMS/to view the number

only available in the UK

* only available in the UK

Press to select Save ring tone

Press to select Handset or scroll to Base station and select

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:02 Page 20

SMS

http://www.philips.com/faqs/dect

To reply to an SMS

Scroll to Read SMS and select

Enter the password if any and press OK (optional)

Scroll to Reply and press

Enter the text and press

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS Settings page 25

Browse the list of SMS and select the one you want to reply to

Press to directly reach Send new SMS

Press to select Send now

To forward an SMS

Scroll to Read SMS and select

Press to directly reach Send new SMS

Enter the password if any and press OK (optional)

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS Settings page 25

Browse the list of SMS and select the one you want to forward

Enter the number and press OK

Scroll to Forward and press

Enter the Destination box* number (if any) and press OK

You can modify the text if necessary or select

Press to select Send now

* only available in the UK

Warning:

for copyright reasons,it is strictly forbidden to forward a downloaded ring tone.

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:03 Page 21

SMS

http://www.philips.com/faqs/dect

To send again

Scroll to Read SMS and select

Enter the password if any and press OK (optional)

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS Settings page 25

Browse the list of SMS and select the one you want to send again

Press to directly reach Send new SMS

Scroll to Send again and press

To delete an SMS

Scroll to Read SMS and select

Enter the password if any and press OK (optional)

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS Settings page 25

Browse the list of SMS and select the one you want to delete

Press to directly reach Send new SMS

Scroll to Delete SMS and press

Press OK to confirm

To copy a number to the phonebook

Enter the name and press OK

Scroll to Copy to phonebook and select

Scroll to Read SMS and select

Enter the password if any and press OK (optional)

Browse the list of SMS and select

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS Settings page 25

Press to directly reach Send new SMS

* only available in the UK

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:03 Page 22

SMS

http://www.philips.com/faqs/dect

To call from the SMS list

Scroll to Call and select or make the call

To set the SMS mode

If there are 2 SMS-enabled phones on your telephone line, you will have to deactivate the SMS

feature on 1 of the devices.

SMS settings

Scroll to SMS settings and select

Press to select Mode

Press to select On or scroll to OFF and select

Press to directly reach Send new SMS

Scroll to Read SMS and select

Enter the password if any and press OK (optional)

Browse the list of SMS and select

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS Settings page 25

Press to directly reach Send new SMS

To set your personal SMS boxes

Scroll to SMS settings and select

Enter the password twice and press OK (optional)

Scroll to SMS boxes and select

Scroll to Add new and select

Enter the SMS box number and press OK

Press to directly reach Send new SMS

only available in the UK

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:03 Page 23

SMS

http://www.philips.com/faqs/dect

To change the password of an SMS box

Note:If you forgot your password you can delete the corresponding SMSbox

Scroll to SMS settings and select

Enter the old password and press OK

Scroll to SMS boxes and select the one for which you want to change the password

Press to select Change password

To delete an SMS box

Warning:when an SMS box is deleted, all the SMS contained in this box are deleted at the same

time.

Enter the new password twice and press OK

Scroll to SMS settings and select

Scroll to Delete and select

Press OK to confirm

Scroll to SMS boxes and select the one you want to delete

Press to directly reach Send new SMS

To choose by default an SMS centre

Scroll to SMS settings and select

Press to select Choose by default

Scroll to SMS centre and select ,choose an SMS centre

Press to directly reach Send new SMS

only available in the UK

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:03 Page 24

SMS

http://www.philips.com/faqs/dect

Choose an SMS centre and select

Scroll to Edit incoming number and select

Enter the number and press OK

Scroll to Edit outgoing number and select

Enter the number and press OK

The SMS are sent through a centre.To receive an SMS from another operator,you must set the

corresponding numbers.

To set the SMS centre number(s)

Scroll to SMS settings and select

Scroll to SMS centre and select

Press to directly reach Send new SMS

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:03 Page 25

Handset

http://www.philips.com/faqs/dect

Handset

Babysit mode

Registration

Rename handset

Date & time

Display contrast

Backlight

Screen saver

This feature allows you to monitor the baby’s room.Place the handset in the room to be monitored

and you will hear the noise coming from the room on the additional handset.

Babysit mode

Registration

Press to enter the carousel menu

Scroll to Handset and select

Press to select Babysit mode

Select ON or scroll to OFF and select

Up to 6 handsets can be registered to the base station.1 handset can be registered to 4 base stations.

Warning:If you wish to associate non Philips handsets to the DECT 511 or DECT 515 base

station,make sure that this handset is GAP compliant otherwise it will not operate properly (see p 13).

To activate/deactivate the babysit mode

An intercom is necessary to monitor the room (see page 38).

Note:during an intercom,you can still answer a call or make a call with the handset

Unplug and plug back in the mains lead to put the base in registration mode

With the additional handset,press to start the registration

Enter the 4-digit RC code written on the sticker

placed under the base station and press OK

To register a handset

if there are at least 2 handsets

To unregister a handset

Press to enter the carousel menu

Scroll to Handset and select

Note:should you have your handset serviced alone,please make sure it is unregistered from the base

station before taking it back to the repair centre.

Enter the 4-digit RC code and press OK

Scroll to Un-register handset and select

Scroll to Registration and select

Choose the handset to un-register from the list and press OK

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:03 Page 26

Handset

http://www.philips.com/faqs/dect

Press to enter the carousel menu

Scroll to Handset and select

Scroll to Rename handset and select

Enter the name and press OK

To rename a handset

Long press to delete the current name

Rename handset

Press to enter the carousel menu

Scroll to Handset and select

Scroll to Date & time and select

To set the date and time

Date & time

Select Set date

Enter the current date and press OK

Enter the current time and press OK

Scroll to Set time and select

Warning:If your phone is connected to an ISDN line through an adaptor, the date & time may

change after each call.Please check the date & time settings in your ISDN system.Please contact

your network provider (see FAQ p.56).

Press to enter the carousel menu

Scroll to Handset and select

Scroll to Registration and select

Choose the base from the list and press OK

Scroll to Base selection and select

Each DECT 511/515 handset can be used with up to 4 base stations.

To use a handset with another base station,the handset must be first registered to that base

station.

Warning:the handset will automatically operate with the last base station to which it was registered.If the

handset is out of range, it will automatically search for another base station from the list.

To select a base station

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:03 Page 27

Handset

http://www.philips.com/faqs/dect

Display contrast

Press to enter the carousel menu

Scroll to Handset and select

Scroll to Display contrast and select

To set the display contrast

Browse through the levels and select the appropriate one

Press to enter the carousel menu

Scroll to Handset and select

Scroll to Backlight and select

To set the display backlight duration or deactivate it

Browse through the durations OFF / 10 seconds / 20 seconds

and select

Backlight

Press to enter the carousel menu

Scroll to Handset and select

Scroll to Screen saver and select

To activate or deactivate the screen saver

Press to select ON or scroll to OFF and select

Screen saver

After 2 minutes of inactivity,the screen saver is displayed.You can choose to activate or deactivate it

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:04 Page 28

Answer machine

http://www.philips.com/faqs/dect

The DECT 515 includes an answer machine that records the calls when it is activated.You can

reach the answer machine from the base station or the handset.

By default,the answer machine is activated.It can store up to 25 messages within the maximum

recording time of 30 minutes.A message can be up to 3 minutes long.

A press on activates or deactivates the answer machine.Once activated,the red indicator is lit.

Press to enter the carousel menu

From the handset

From the base station

Scroll to Answer machine and select

Scroll to Answphone settings and select

To switch the DECT 515 Telephone Answer Machine ON/OFF

Press to select Mode

You can listen to new or saved messages via the handset or the base station.

Note:the entry shows the number of times the caller tried to reach you. If you have subscribed to

the Caller Identification Service (CLI), the display shows the name of the caller and its group if

activated (see page 39).

To listen to new message(s) via the handset

Saved messages

The display shows that there is 1 or more new messages(s) (1 ).

Press to view.

The message is automatically played.

Press to select ON or scroll to OFF and select

Answer machine

Saved messages

Record a memo

Outgoing messages

Answerphone settings

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:04 Page 29

Answer machine

http://www.philips.com/faqs/dect

To play and browse through saved message(s) via the handset

To play and go to next saved message(s) via the base station

Press to enter the carousel menu

Scroll to Answer machine and select

Select Saved messages,the message which

was recorded first is automatically played

Select Saved messages,the message which

was recorded first is automatically played

Press to access the Options

Press to select Play

To go to next or previous messages,scroll to Next message or

Previous message and select

Note:you can listen to the message(s) via the Call log.Scroll up to access Call log and scroll to

choose the message from the call log list.The entry is marked (see page 42).

To delete a message via the handset

To delete a message via the base station

Press to enter the carousel menu

Scroll to Answer machine and select

Press to access the Options

Press OK to confirm

Scroll to Delete and select

Press to play a message and press once again to stop a message while listening

The other options available from the handset are Call (if number is displayed),Store (if number is

displayed) and Send SMS (if number is displayed).

Press to delete the current message.

Make a long press to delete all the messages (except unread ones)

Press to go to the next message while listening.Make a long press to fast forward the

messages while listening

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:04 Page 30

Answer machine

http://www.philips.com/faqs/dect

Settings

You can select among 2 answer modes :Answer only (when no messages can be left) and Answer &

record (when messages can be left).For each mode,2 outgoing message types are available: predefined

or personal message. By default the answer machine is set to Answer & Record with predefined OGM.

You can record 5 different personal OGM:a specific personal OGM for Answer & record mode for

each group (A,B or C), the standard OGM for Answer & record mode for normal callers (not

belonging to any group) and the standard OGM for Answer only mode for all callers.It is possible

to record specific messages for specific groups only if you subscribe to the Caller Line Identification

service (CLI) and if you have set the groups in the phonebook (see page 41).

You can also download outgoing messages through an online service (see Leaflet

“Download of ring tones and answerphone messages”)*.

To select the answer mode and the outgoing message (OGM) type

To record your personal outgoing message (OGM)

Press to enter the carousel menu

Scroll to Answer machine and select

Select Answ. machine mode

Scroll to Outgoing Messages and select

Choose the appropriate mode among the 4 options above (2 answer

modes and 2 outgoing message types) and select

Note:a predefined message cannot be deleted

Press to enter the carousel menu

Scroll to Answer machine and select

Scroll to Record outgg msg and select

Scroll to Record new and select

Press to start recording and once again to stop recording

Scroll to Outgoing Messages and select

Choose between the different type of OGMs and the various

groups and press

* only available in the UK and depending on technical availability

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:04 Page 31

Answer machine

http://www.philips.com/faqs/dect

The message is automatically played back.You can delete and/or record it again.The personal

message can be up to 1 minute long

Note:Select Standard OGM for answer only mode or Standard OGM for Answ. &

Record mode if you have no CLI subscription.

Warning:Please make sure that you have selected the appropriate answering machine mode

(refer to page 33 “To select the answer mode and the outgoing message type”)

You can set the answer machine to start playing the outgoing message after a given number of rings

(3,5, 7 or Toll saver).The toll saver option (activated by default) is useful when using the remote

access.The answer machine will start playing the outgoing message after 3 rings if there are new

messages.If there is no new message the outgoing message will be played after 5 rings.Hang up

after the 4th ring if you want to check if you have any messages at no cost.

To set the number of rings before answering

Press to enter the carousel menu

Scroll to Answer machine and select

Scroll to Answphone settings and select

Scroll to Number of rings before answering and select

Choose between Toll saver,3 rings,5 rings

or 7 rings and select

You can change the language of the predefined message (OGM).

To set the voice language

Press to enter the carousel menu

Scroll to Answer machine and select

Scroll to Answphone settings and select

Scroll to Voice language and select

Choose the appropriate language among the list and select

DECT511_GBIE_part1_indice2_internet.qxd 26/10/2004 14:04 Page 32

Answer machine

http://www.philips.com/faqs/dect

There are 2 recording qualities:standard and high.In standard quality the total capacity is 30

minutes and in high quality the capacity is up to 15 minutes.

To set the recording quality

Press to enter the carousel menu

Scroll to Answer machine and select

Scroll to Answphone settings and select

Scroll to Recording quality and select

Choose between High or Standard and select

Note:the default setting is OFF.Activate this feature if you want to be able to remotely use the

answer machine.

Press to enter the carousel menu

Scroll to Answer machine and select

Scroll to Answphone settings and select

Scroll to Remote control and select

Select Mode

To activate and deactivate the remote control

Press to select ON or scroll to OFF and select

This feature allows you to activate or deactivate the base station loudspeaker so that you can

choose whether to hear or not the callers leaving a message.

You can set permanent call screening on the base station.

To set the call screening

Press to enter the carousel menu

Scroll to Answer machine and select

Scroll to Answphone settings and select

Scroll to Call screening and select

Press to select Off or scroll to Low, Medium, High or

Boost and select

Call screening “call by call” on the handset is also possible.While the caller is leaving a message,

press to listen and press again to stop listening.Adjust the volume with .

Note:this feature is activated by default on Medium level.

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:39 Page 1

Answer machine

http://www.philips.com/faqs/dect

The default code is the registration code.We advise you to personalize it.

To change the remote control code

Press to enter the carousel menu

Scroll to Answer machine and select

Scroll to Answphone settings and select

Scroll to Remote control and select

Scroll to Change code and select

Delete the default code, enter your new remote control code and

press OK

To remotely access your answer machine :

- from another phone dial home

- if your answer machine is on,during or after the message press the star key on the handset ; if

your answer machine is off,you will hear a beep after 45 seconds,then press the star key

- dial your remote control code (the default code is the registration code RC)

- if you have new messages they will be automatically played.

To remotely control your answer machine

The following table indicates the features available when remotely accessing the answer machine.

Delete dial

Activate answer machine dial

Stop dial

Deactivate dial

Record memo dial

Play previous message dial

Play message dial

Play next message dial

Listen again dial

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:40 Page 2

Answer machine

To listen to a new memo

To listen to a saved memo

The display shows there is 1 new local message (1 ).Press to View. The message is

automatically played.Delete is also available in the options (see page 32)

You can use the Answer machine sub menu Saved messages and select Play or listen to

a new or a saved memo through the base station (see page 32).

This feature allows you to leave local messages for your family on the answer machine.

A memo is recorded from the handset,it is represented by in the call log and can last up to 3 minutes.

To record a memo

Press to enter the carousel menu

Scroll to Answer machine and select

Scroll to Record a memo and select

Press to start recording and once again to stop

Record and listen to a memo

http://www.philips.com/faqs/dect

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:40 Page 3

Intercom

Call all

Handset list

Intercom

http://www.philips.com/faqs/dect

Using the Intercom(if there are at least 2 handsets)

This feature allows you to make free internal calls, transfer external calls from one handset to

another, use the conference option and the babysit feature (room monitoring).

Internal call

Fast call transfer when on line

Call transfer to a specific handset when on line

During a call you can transfer the call without waiting for the other handset to pick up.All the

handsets will then ring.

During a call you can transfer the call to a specific handset.

Press to call the other handset

Hang up

Press to call the selected handset + handset number (for example )

Note:If the handset does not belong to the Philips DECT 511/515 range, this function may not be

available.

Note:the person on hold hears music.A press on allows you to switch between the 2 calls.

Intercom menu is accessible via the carousel or

During a call you can transfer the call via the in call options.

Call transfer via the in-call options

Scroll to Intercom and select

Browse through the handset list and select the one you want to transfer the call to

Press to enter the options (with handset 1).

If there is only one additional handset,it rings automatically. Otherwise:

Press to call the selected handset + handset number (for example )

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:40 Page 4

Intercom

http://www.philips.com/faqs/dect

Conference call via the in-call options

The called handset rings.The external call is put on hold.If there is no answer

from the called handset you can resume the call on the first handset.

Take the line on the called handset,both internal callers can talk

Note:to answer the call on the second handset you can press .

Browse through the handset list and select the one you want to call.

The called handset rings.The external call is put on hold.If there is no answer

from the called handset you can resume the call on the first handset.

Take the line on the called handset,both internal callers can talk

Press to select Transfer (with handset 1)

Scroll to Switch and come back to the external caller

Conference call allows one external call to be shared with two handsets (in intercom).The 3 people

can share the conversation.No operator subscription is needed.

Scroll to the Conference call option and select .

The 3 people can share the conversation.

Scroll to Intercom and select

Press to enter the options (with handset 1)

To use the babysit mode feature you need to activate it (see page 28) & initiate an intercom.Place

the handset in the room to be monitored and you will hear the noise coming from the room on

the additional handset.

Take the line on the called handset,the room monitoring can start.

To initiate the babysit (room monitoring) if there are at least two handsets

Browse through the handset list and select the one you want

to call.The called handset rings.

Scroll to Intercom and select

Press to enter the options

If there is only one additional handset,it rings automatically. Otherwise:

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:40 Page 5

Phonebook

Add new

View

Phonebook

http://www.philips.com/faqs/dect

65 names and numbers can be stored in the phonebook.

The phonebook contains all the information related to the callers,especially the group settings.The

names and numbers are shared with all the handsets registered to your base.

There are 3 groups (group A, group B and group C).When ringing,the ring tone helps you identify

the caller’s group (see p.49) and the screen shows the caller’s name.A subscription to the Caller

Line identification is needed.

The names are stored in alphabetical order.

Group settings

To quickly reach a name in the list,enter the first character (browse through the list if several

names start with the same letter).

To add a name to the phonebook

To store a name and number from predial

Add new

View

Press to enter the carousel menu

Once the number is dialled,press to reach the options,scroll to Store and select .

Enter the name and press OK

Scroll to Phonebook and select

Scroll to Add new and select

Enter the number and press OK

Enter the name and press OK (see page 19 “Editing systems”)

Phonebook menu is accessible via the carousel or

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:40 Page 6

Phonebook

http://www.philips.com/faqs/dect

To change a number

Scroll down to directly reach the list of names

Browse through the list of names and select a name

Scroll to Change number and select

Press to erase the current number

Press to erase the current name

Enter the new number and press OK

To change a name

Note:it is possible to erase the current name with .You can simply change any letter by

moving the cursor to reach the letter and press

Note:it is possible to erase the current number with .You can simply change any digit by

moving the cursor to reach the digit and press

Scroll down to directly reach the list of names

Browse through the list of names and select

Scroll to Change name and select

Enter the new name and press OK

Scroll down to directly reach the list of names

Browse through the list of names and select a name

Or press to reach the options

Make the call

And press again to select Call

To call

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:40 Page 7

Phonebook

http://www.philips.com/faqs/dect

To change the SMS box number

To delete an entry

Enter the destination box number and press OK

Scroll down to directly reach the list of names

Browse through the list of names and select a name

Scroll to Change SMS box and select

Press OK to confirm

Scroll down to directly reach the list of names

Browse through the list of names and select

Scroll to Delete and select

Scroll down to directly reach the list of names

Browse through the list of names and select

Scroll to Send SMS and select

To send an SMS from the phonebook

Note: once in the list of names, press to directly edit an SMS

To define a group for a name and number (see Group settings p.39)

Scroll down to directly reach the list of names

Browse through the list of names and select a name

Scroll to Select group and select

Browse through the groups and select

Enter the Destination box* number (optional),press OK

Enter the password and press OK (optional)

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS settings page 25

Press to select Send now

Enter the text and press OK (see page 19)

* only available in the UK

only available in the UK

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:40 Page 8

Call log

http://www.philips.com/faqs/dect

Call log

View

Delete all

Call log settings

The call log shows the list of incoming calls.

If you have subscribed to the Caller Line Identification (CLI),you will also have the list of outgoing

calls.In this case the name (or number) of the callers will be displayed.The date & time of the call

are also shown.

* DECT 515 only

The call log can store up to 40 entries

- : unanswered calls - : outgoing calls

- : memo or recorded conversation* - : answered calls

- : messages* - : messages (operator voice mail/if operator

sends the information)

View

To view the call log

Scroll up to directly reach the calls list

Browse through the list and read the information

To call / redial

Scroll up to directly reach the calls list

Browse through the list and select an outgoing call entry**

Or press to select Call in the options

Press to call

Call log menu is accessible via the carousel or

To listen to a message (DECT 515 only)

Browse through the list and select

the entry marked with

Select Play in the options

Scroll up to directly reach the calls list

** Note : to be able to call back a correspondent in the case of an incoming call,you need to

subscrible to the Caller Line Identification service.

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:40 Page 9

Call log

http://www.philips.com/faqs/dect

To store the caller’s number

Browse through the list and select an entry

Scroll to Store and select

Enter the name and press OK

To delete a name and a number

To send an SMS from the call log

Browse through the list and select an entry

Scroll to Delete and select

Press OK to confirm your choice

Browse through the list and select an entry

Scroll to Send SMS and select

Warning:if a message is associated to the entry,it is also erased from the answer machine,

whether it is read or not (DECT515 only).(see page 45)

Scroll up to directly reach the calls list

Enter the Destination box* number (optional),press OK

Enter the password and press OK (optional)

Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS settings page 25

To view the number

Scroll up to directly reach the calls list

Browse through the list and select an entry

Scroll to View number and select

* only available in the UK

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:41 Page 10

Call log

http://www.philips.com/faqs/dect

Press to enter the carousel menu

Scroll to Call log and select

Scroll to Delete all and select

Press to confirm OK

Press to enter the carousel menu

Scroll to Call log and select

Scroll to Call log settings and select

Press to select Incoming calls or scroll to Outgoing calls

and select

Browse through the options and select the one that suits you

Delete all

Call log settings

To delete all the call log

You can set the call log to store information about incoming calls and/or outgoing calls.

Note: entries with unread messages will also be deleted (DECT 515 only).

Press to select Send now

Enter the text and press OK (see page 19)

* only available in the UK

Note: once in the list of names, press to directly edit an SMS

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:41 Page 11

Operator services

http://www.philips.com/faqs/dect

Operator services

This feature allows you to activate or deactivate operator services that are subscription dependent.

You need to set up codes (see page 56).

Contact your network operator for more details.You can usually subscribe to Call forward,

operator voice mailbox etc...

Calls can be redirected to another phone number.Set the code (see page 56) and activate it when

necessary.

From now on the calls will be redirected to the assigned phone number.

Example of service: Call forward

To activate call forward

To deactivate call forward

Press to enter the carousel menu

Scroll to Operator services and select

Press to select Call forward

Enter or retrieve from the phonebook the number to which

the calls are to be forwarded and press OK

The number is automatically chained to the call forward prefix

and the system dials the number.

Press to select View

Press to select Cancel

Hang up

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:41 Page 12

Extra

http://www.philips.com/faqs/dect

Extra

Call duration

Alarm clock

Do Not Disturb mode

Call duration

The total communication time is displayed

Press to enter the carousel menu

Scroll to Extra and select

Press to select Call duration

Press to Reset the counter

A long press on activates/deactivates the alarm clock with your own settings.

When the alarm rings,press any key to stop it.The snooze is then activated (will ring again every 5

minutes).To definitely stop it press

Alarm clock

To activate / deactivate the alarm clock

To set the alarm clock

Press to enter the carousel menu

Scroll to Extra and select

Scroll to Alarm clock and select

Scroll to Set day and select .Choose a day.

Scroll to Set time and select

Enter the time and press OK

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:41 Page 13

Extra

http://www.philips.com/faqs/dect

To set the alarm ring tone type and ring tone volume

To set the Do not Disturb mode

Press to enter the carousel menu

Scroll to Extra and select

Scroll to Alarm clock and select

Scroll to Settings and select

Press to select Ring tones

Press to enter the carousel menu

Scroll to Extra and select

Scroll to Do not disturb mode and select

Scroll to Set day and select the day and press

Choose among the available ring tones and select

Scroll to Ring tone volume and select

Choose among the available volume levels and select

A long press on activates/deactivates this mode with your own settings.

Warning! only allowed callers will be able to reach you during the selected day & time

This feature allows you to screen calls after a certain time in the evening or when you do not want

to be disturbed.Enter the time and select the group(s) allowed to call you.If none of the 4 groups

is selected but the feature is activated,then nobody will be able to reach you.If the caller does not

belong to an allowed group, the handset and base station will remain silent,while the caller will hear

ringing.The answer machine (if activated) or the operator voice mail (network dependent) will answer

the call.The feature is deactivated by default. You need to subscribe to the Caller Line Identification

service (CLI).

Do not Disturb mode

Scroll to Start time,enter the time and press OK

Scroll to Stop time,enter the time and press OK

Scroll to Allowed caller choice,activate the callers group(s)

allowed to call you and select

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:41 Page 14

Sounds

http://www.philips.com/faqs/dect

Press to enter the carousel

Handset ring tones

Base ring tones

Scroll to Sounds and select

Press to select External ring tone

Press to select Handset ring tones

Browse through the list of ring tones and select one

To set the external ring tone

Browse through the list of ring tones and select one

Press to enter the carousel

Scroll to Sounds and select

Scroll to Internal ring tone and select

To set the internal ring tone (ring tone for internal calls)

Browse through the list of ring tones and select one

Press to enter the carousel

Scroll to Sounds and select

Scroll to Base ring tones and select

only available for DECT 515

Sounds

Handset ring tones

Base ring tones

Group ring tones

Handset ring tone volume

Base ring tone volume

My ring tones*

Record personal melody

Settings

Press to select Handset ring tones

*only available in the UK

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:41 Page 15

Sounds

http://www.philips.com/faqs/dect

Handset ring tone volume

Group ring tones

Press to enter the carousel

Scroll to Sounds and select

Scroll to Handset ring tone vol. and select

The current level is heard,browse through the levels to hear them

Press to select the appropriate volume

Base ring tone volume

Press to enter the carousel

Scroll to Sounds and select

Scroll to Base ring tone vol. and select

The current level is heard,browse through the levels to hear them

Press to select the appropriate volume

Scroll through the 3 different groups and select one

Browse through the list of ring tones and select

only available for DECT 515

There are 3 groups of callers (see p 40 Group settings).You can associate 1 ring tone to a group.

Press to enter the carousel

Scroll to Sounds and select

Scroll to Group ring tones and select

To set the group ring tones

Warning : We strongly advise to put the handset far from your ear when it is ringing.

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:41 Page 16

Sounds

http://www.philips.com/faqs/dect

only available in the UK

Scroll to My ring tones and select

Browse through the list of downloaded ring tones and select

Scroll to Delete and select

Press to enter the carousel

Scroll to Sounds and select

To delete a downloaded ring tone

My ring tones

Press to enter the carousel

Scroll to Sounds and select

Scroll to My ring tones and select

Press to select Handset or scroll to Base station and select

Press to select Change name

Press to select Handset or scroll to Base station and select

To rename a downloaded ring tone (set on handset or on base station)

This menu gives access to all available downloaded ring tones.These ring tones can be set on your

handset or on your base station (only available for DECT 515 base station) (see page 22).You can

store up to 3 downloaded ring tones.

Record personal melody

Press to enter the carousel

Scroll to Sounds and select

Scroll to Record pers. melody and select

Press to select Play

only available for DECT 515

To play a recorded melody

Press to enter the carousel

Scroll to Sounds and select

To record a new melody

Scroll to Record pers. melody and select

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 17

Sounds

http://www.philips.com/faqs/dect

Press to enter the carousel

To set the earpiece tone

Scroll to Sounds and select

Scroll to Settings and select

Scroll to Earpiece tone and select

Browse through the options and select the appropriate setting

Press to enter the carousel

To set the base loudspeaker volume

Scroll to Sounds and select

Scroll to Settings and select

Press to select Base loudspeaker vol.

Settings

Press to select the appropriate volume

only available for DECT 515

Press to enter the carousel

Scroll to Sounds and select

Scroll to Record pers. melody and select

To delete a recorded melody

Scroll to Delele and select

Press OK to confirm

Press to start recording

Scroll to Record new and select

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 18

Sounds

http://www.philips.com/faqs/dect

Press to enter the carousel

To set the notification beep

Scroll to Sounds and select

Scroll to Settings and select

Scroll to Notification beep and select

Press to select ON or scroll to OFF and select

Press to enter the carousel

To activate/deactivate the music on hold

The feature allows the caller to hear music when the call is put on hold when transferring a call

from one handset to the other.

Scroll to Sounds and select

Scroll to Settings and select

Scroll to Music on hold and select

Press to select ON or scroll to OFF and select

Press to enter the carousel

To set the key & feedback tones

Scroll to Sounds and select

Scroll to Settings and select

Scroll to Key & feedback tones and select

Press to select ON or scroll to OFF and select

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 19

Base station

http://www.philips.com/faqs/dect

Base station

Enable registration

Line settings

Service code settings

This feature allows you to register a DECT peripheral without keypad.Some DECT peripherals,

such as repeaters,do not have any keypad.A special menu-operated procedure is used to register

such peripherals to the base station.Also use the peripheral instructions to register it to the base

Enable registration

Line settings

Press to enter the carousel menu

Scroll to Base station and select

Press to select Enable registration

Enter the peripheral code (RC code) and press OK

Follow the instructions in the peripheral manual

To register a DECT peripheral

To change the dial mode

Press to enter the carousel menu

Scroll to Base station and select

Scroll to Line settings and select

Press to select Dial mode

Press to select Tone or scroll to Pulse and select

Note:this setting allows you to select pulse dialling (also called “Loop disconnect” and used in

countries without DTMF tone dialling capability or using old PABX)

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 20

Base station

http://www.philips.com/faqs/dect

To change the recall type

Note:this setting is useful when using operator services.The use of some services accessed with

+1, +2 and +3 (call waiting, call forward...) will depend on the flash setting (short/long)

according to your installation type (ISDN,Public,PABX).

Press to enter the carousel menu

Scroll to Base station and select

Scroll to Line settings and select

Scroll to Recall type and select

Press to select Short flash or scroll to Long flash and select

To change the configuration

Press to enter the carousel menu

Scroll to Base station and select

Scroll to Line settings and select

Scroll to Choose country/oper. and select

Browse through the countries and select the

appropriate one.

To activate and deactivate the first ring

Press to enter the carousel menu

Scroll to Base station and select

Scroll to Line settings and select

Scroll to First ring and select

Choose between ON or OFF and select

To prevent the phone from ringing when receiving an SMS, the first ring tone is deactivated.You can

activate it.

Browse through the operator type and select the

appropriate one.

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 21

Base station

http://www.philips.com/faqs/dect

When you subscribe to extra services with your operator you may need to set some codes in your

phone.The default codes are the codes used by the main national operator.

If you subscribed to another operator you may need to change the codes.

Contact your network operator for more information on the services.

Service code settings

Press to enter the carousel menu

Scroll to Base station and select

Scroll to Service code settings and select

Browse the list of services and select

Enter the code and press OK

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 22

FAQ

http://www.philips.com/faqs/dect

1/ I have no dialling tone after having installed my phone.How do I solve this problem?

Check that you have connected your phone using the supplied line cable and not the one from any previous

phone (they are often wired differently).

Check that you have fully charged the handset according to the instructions given for the phone.

Check that the aerial icon (radio link with the base station) is displayed.If the handset is not registered you may

need to register it (see p.28).

2/ Can the handset be left on the base all the time?

Yes there is no “memory effect”.The handset can be left on the base station for all current models using NiMh batteries.

3/ Will my phone lose all recorded data (phonebooks entries, recorded messages) in the case of a

general power cut?

No it will not.The data recorded in your phone is not deleted in the case of a general power failure or when

you unplug your base station or when you replace the batteries.

4/ I have set up the date & time on my phone and the information given after a call is not correct.

Why?

If you have a ISDN phone installation,these parameters (date & time) may be transferred directly through the

ISDN to the phone. If you did not set-up the ISDN correctly this can explain why the information transmitted

is not correct.Set-up the date & time directly on the ISDN phone installation or,if this is not possible, call the

Operator/dealer who provided and installed the ISDN.

5/ I cannot use the answering machine of my Philips phone together with my Fax plugged into the

same line, why is this?

To avoid this,it is recommended to set up the number of rings before the answering machine switches on.

Example:if the network mail box or a fax is set to answer the calls after 4 rings,please set up your answering

machine on 3 rings.To set up the number of rings,please see p 34.

6/ What is CLI and how do I make it work?

CLI stands for Caller Line Identification and it is a special service that you may subscribe to from your network

operator.Once you have subscribed to the service, a CLI enabled phone will display the callers number (unless

withheld) as the phone rings so that you may decide whether or not to take the call.

7/ The CLI service does not work on my Philips phone, on my digital phone installation (ISDN,

ADSL). How do I solve this problem?

Our products are designed to work on an analogue network.If you plugged your PHILIPS phone into a digital

installation,the CLI may not be displayed upon incoming calls.Digital phone installations (ISDN) are not always

compatible with analogue phones as far as operator services are concerned.

You may find the information regarding compatibility in the user guide of your ISDN.If not, please contact the

ISDN manufacturer to check if the device is designed to display CLI on analogue phones. ISDN over 2 or 3

years old are generally not compatible with analogue phones for the CLI Service.

Note that the filters used with some ADSL lines can filter out part of the CLI signal and prevent the phone

from displaying CLI correctly. It is possible to purchase better ADSL filters that do not cause this problem.

FAQ

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 23

FAQ

http://www.philips.com/faqs/dect

8/What is CNIP (Caller Name Identification)?

As with the CLI service this new feature is dependent on the Network and it has to be activated by your

Operator (by subscription).It will allow you to have the name of the caller displayed upon an incoming call.

This service may not be available from all Operators yet.We advise you to check with your Operator.

NB.If the name of the caller is registered in your phonebook upon an incoming call it will be the name you

have registered which will be displayed and not the one provided by the Operator.The data in your phonebook

will have priority over the Operator’s data in this particular case.

The CNIP uses the same technology as for the CLI.Therefore the limits of this service are identical (please

refer to the questions related to CLI if the service is not working properly).Remember that it only works with

alphanumeric display.

9/ How many telephones can I have?

All items of telephone equipment have Ringtone Equivalence Number* (REN),which is used to calculate the

number of items which may be connected to any one telephone line.

Your DECT 511/515 has a REN of 1.A total REN of 4 is allowed,if the total REN of 4 is exceeded, the tele-

phones may not ring.

With different telephone types there is no guarantee of ringing,even when the REN is less than 4.

10/ My answering machine does not record the messages left by my correspondents. How do I

solve this problem?

Check the operator voice mail box is not activated.If it is activated,set the answering machine so that it starts

recording first (set up the number of rings before the answering machine switches on).

11/ Which are the conditions required to be able to send an SMS ?

You must first have a subscription to Caller Display (CLI) service from your network operator as well as an

SMS service subscription from the appropriate provider.

12/ Is it possible to write, read send or receive an SMS when the other handset is in communica-

tion (DECT 511 and DECT 515 multi-handset packs only)?

No it is not possible.

13/ What happens if I send an SMS to a fixed line with no SMS phone ?

The correspondent could receive a vocal message (SMS provider dependent).

14/ Is it possible to send an SMS to a fixed line in another country ?

This feature depends on your provider. Please contact your provider for more details.

15/ How can I get the SMS centre number ?

One SMS centre number at least is pre-programmed in your DECT 511/DECT 515.However, should you need

to store another number, other numbers can be set into the phone from the menu SMS/SMS Settings/SMS

centre.Please check the incoming and outgoing centre numbers with the SMS provider or from the enclosed

addendum to your phone user manual.

16/ What is the destination box* useful for ?

This is the number of a personal SMS box.It is a way to send an SMS to someone’s personal box instead of

sending it to the default box,which is a kind of common box.If you send an SMS without specifying an SMS box

number (destination box),then the SMS will be sent to the default box if the receiver’s phone deals with multi-

boxes features (provider dependent).

17/ When using my SMS-enabled Philips phone with another SMS-enabled phone on the same

line, can it cause any problems ?

Yes,this will prevent the phones from receiving SMS.You need to deactivate the SMS feature on one of the

phones.Your DECT 511/DECT 515 has a feature which enables you to turn the SMS feature off.Go to menu

SMS/SMS Settings/Mode/OFF

* only available in the UK

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 24

Troubleshooting

http://www.philips.com/faqs/dect

Troubleshooting

The icon does not

scroll when the handset is

placed on the base

PROBLEMS

No dialling tone

- Crackling on the line

The handset displays ‘not

available’

- when attempting to add

another handset to the base

station

- when using a handset

Noise interference on your

radio or television

Caller Line Identification (CLI)

service does not work

No ring tone

The icon does not appear

The icon is blinking

- Bad battery contact

- Dirty contact

- Battery is full

CAUSES

- No power

- Batteries are empty

- You are too far from the base station

- Wrong cable

- Line adaptor not plugged to the

line cord

- The ring tone is deactivated

- The Do not Disturb mode is ON

- No mains power

- The handset is too far from the

base station

- Handset not registered to the

base station

- You are too far from the base

station

- The base station is too close to

electrical appliances,reinforced

concrete walls or metal door-

frames

- The procedure to add a handset

has failed,try again

- Maximum number of handsets (6)

has been reached

- Base station is already busy with

another handset (ie :phonebook)

The DECT 511/515 base station or

mains power pack are too close to

electrical appliances

- The service is not activated

- Move the handset slightly

- Clean the contact with a cloth

moistened with alcohol

- No need to charge

SOLUTIONS

- Check the connections.Reset

the phone :unplug and plug back

in the mains

- Charge the batteries at least 24

hours

- Move closer to the base station

- Always use the cable provided

- Plug the line adaptor to the line

cord

- Increase the volume (page 50)

- Deactivate it (page 48)

- Check connections

- Move closer to the base station

- Register the handset to the base

(page 28)

- Move closer to the base station

- Move the base station to find a

better place (the higher the

better)

- Disconnect and connect the

base station power supply. Follow

the procedure to register a

handset (page 28)

- Un-register a handset

- Wait until it is available

Move the power pack or base

station as far as possible

- Check your subscription with

your network operator

Telephone troubleshooting

www.philips.com/support

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 25

Troubleshooting

http://www.philips.com/faqs/dect

PROBLEMS CAUSES SOLUTIONS

No new SMS are received

A phonebook entry cannot

be memorised

No SMS can be sent or

received

- SMS memory is full

- The SMS mode is deactivated

The phonebook is full

- The outgoing or incoming SMSC

number is not set or is wrong

- The destination box* is wrong

- SMS mode is OFF

- You have no subscription

- Another SMS-enabled phone is

also on your line

- There is a problem of

compatibility between operators

- The identity is withheld

- Delete old SMS

- Activate it (p 25)

Delete an entry to free memory

- Refer to the SMS leaflet to get

the correct SMSC’s numbers

- See point 16 page 58

- Activate SMS mode (page 25)

- Contact your provider for more

information

- Deactivate the SMS mode on

one of the device.

- Contact your provider for more

information

- Show identity

The answer machine does not

record messages

The remote control access does

not work

It is not possible to record an

outgoing message

The DECT 515 hangs up during

remote access

The answer machine stops

automatically

- The memory is full

-The answer only mode is activated

- The Answer & record is not

activated

The remote control access is not

activated

The memory is full

- 3 failed attempts to send a code

- Duration is too long

- The memory is full

- Message exceeds 3 mn

- Delete messages

- Select the Answer & record mode

- Press

Activate the remote control

access (page 35)

Delete messages

- Enter the correct code

- Manage the remote control quicker

- Play & delete messages

- Messages must not exceed 3 mn

PROBLEMS CAUSES

SOLUTIONS

Answer machine troubleshooting

No caller Id/ poor audio

quality/Poor connection

quality with broadband DSL

internet

- DSL filter(s)/splitter missing or

insufficient number of filters

- Modem &/or phone plugged in

the wrong DSL filter slot

- Defective DSL filter(s)

- Make sure you have one DSL

filter plugged directly on each line

socket used in the house

- Check the modem and the

phone are plugged in the correct

filter slot (one specific for each)

- The filter(s) can be defective.

Replace it/them and make

another test

only available in the UK

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 26

Add new (phonebook) 40

Alarm clock 47

Answer a call 1,17

Answer machine settings 33

Babysit mode 28,39

Base keys 4

Base installation 15

Batteries & battery life 15

Call duration 47

Call forward 46

Call log settings 45

Call transfer 38

Call screening 35

Change name 40

Change number 41

Choose country/operator 55

Conference call 39

Conformity 12

Copy to phonebook 24

Date and time 29

Declaration of conformity 13

Define groups 42

Delete all (call log) 45

Delete call log entry 44

Delete an entry (phonebook) 42

Delete an SMS 24

Destination box 58 (n°16)

Dial mode 54

Display contrast 30

Do Not Disturb mode 48

Earpiece tone 52

Edition mode 19

Enable regisration (DECT peripheral) 54

FAQ 57

First ring 55

Forward SMS 23

GAP 13

Groups 40,50

Handset keys 2

Handset ring tones 49

Idle mode 16

Intercom 18,38

Key & feedback tones 53

Keypad lock/unlock 2

Line settings 54

Listening to messages (Answer machine) 31

Local message (Memo) 37

Loudspeaker 2,18

Make calls 17,25, 41, 43

Music on hold 53

Mute 18

Navigation in menus 16

Notification beeps 53

Outgoing messages 33

PABX/PSTN 54

Phonebook 40

Predial 17

Pulse 54

Range 15

Read SMS 22

Recall type 55

Recording quality 35

Record conversation 18

Record a memo 37

Record personal melody 51

Recording personal outgoing message 33

Redial 17

Remote access to answer machine 36

Remote control code (answer machine) 36

Rename handset 29

Ring tone type (alarm) 48

Ring tone volume (alarm) 48

Rings before answering (Answer machine) 34

Screening calls 35

Screen saver 16, 30

Send new SMS 21

Send SMS (from phonebook) 42

Send SMS (from call log) 44

Service codes settings 56

SMS box 25

SMS centre 26,27

SMS mode 25

SMS settings 25

Toll saver (Answer machine) 34

Tone 54

Unpacking your DECT 511/515 14

Unregister handset 28

View the call log 43

Voice language 34

Volume (earpiece) 18

Volume (ring tone) 50

Index

DECT511_GBIE_part2_indice2_internet.qxd 26/10/2004 14:42 Page 27

IRL

3111 285 21872

User manual

Charge the handset(s) 24 hours

before use.

Printed in Romania 3111 285 22232

Text messaging in the UK see overleaf

INFORMATION ON TEXT MESSAGING (SMS) IN EIRE

SMS and Caller Display disclaimer :The Short Message Service and Caller Display features of your

telephone terminal are network operator dependent.The terminal can provide them only if the network

offers such features and if the user has subscribed to these features.Your phone has been carefully

developed and tested according to the latest version of the SMS and CLI standards, and is up to date at the

time of product release. However, Philips cannot take any responsibility and cannot guarantee the

interoperability with the operator’s network in case of standard modification, network modification and/or of

incomplete or inaccurate implementation of the standard by the network’s operator.

You must first subscribe to your network provider’s Caller Display service.

Example : call EIRCOM free 1901.

Registration to SMS service is done by sending your first SMS.

The network SMS centre numbers are automatically set in your phone on SMS

Centre 1:

Send SMS service number (Outgoing number) : 1740 9900

Receive SMS service number (Incoming number) : 0818 365 135

Contact your network provider for more information.

WARNING ! Change the operator type in your phone :

Go to Base station menu and select Line Settings sub menu.

Select the Choose country/oper. sub menu and choose the appropriate setting among the list (for

example: Eircom).

Please refer to your phone user manual.

SMS and Caller Display subscription : The way to subscribe to and to connect to the Short Message

Service (SMS) as well as the SMS function may be operator dependent and may vary in time. Please contact

your network operator for more information.The following information is believed to be exact at the time

of writing. It is provided for guidance only and does not guarantee accuracy over time.

There is a charge for sending SMS text messages (contact your network provider for more information).

REMINDER ! If there are two SMS- enabled phones on your telephone line, you will have to deactivate the SMS feature on

one of the devices.

Feuillet SMS UK_05_07_04_index2.qxd 13/07/04 11:45 Page 1

INFORMATION ON TEXT MESSAGING (SMS) IN THE UK

You must first subscribe to your network provider’s Caller Display service.

Registration to the SMS service is done by sending your first SMS.

There is a charge for sending SMS text messages (Contact your network operator for more information).

SMS and Caller Display disclaimer :The Short Message Service and Caller Display features of the telephone terminal are network operator

dependent.The terminal can provide them only if the network offers such features and if the user has subscribed to these features.Your phone

has been carefully developed and tested according to the latest version of the SMS and CLI standards, and is up to date at the time of product

release. However, Philips cannot take any responsibility and cannot guarantee the interoperability with the operator’s network in case of standard

modification, network modification and/or of incomplete or inaccurate implementation of the standard by the network’s operator.

SENDING SMS FROM A FIXED LINE TO A FIXED LINE : follow instructions in the user guide.

SENDING SMS FROM A FIXED LINE TO A MOBILE : follow instructions in the user guide.

Warning : When sending an SMS to a mobile phone, do not enter any destination box as your SMS will not be delivered.

USING DESTINATION BOX ON YOUR PHONE (not available on DECT 311) :

In order to receive an SMS in a specific SMS box, you must have previously sent at least one SMS from this box.

SMS and Caller Display subscription : The way to subscribe to and to connect to the Short Message Service (SMS) as well as the SMS

function may be operator dependent, and may vary in time. Please contact British Telecom for more information.The following information is

believed to be exact at the time of writing. It is provided for guidance only and does not guarantee accuracy over time.

REMINDER ! If there are two SMS- enabled phones on your telephone line, you will have to deactivate the SMS feature on

one of the devices.

By default, your phone is set with the SMS centre 1 (British Telecom).

If you change this setting, the SMS service may not work.

Feuillet SMS UK_05_07_04_index2.qxd 13/07/04 11:45 Page 2

The download of ring tones and outgoing messages (only available in

the UK and depending on the network technical availability)

To personalise your cordless telephone, there is nothing better than a melody and a message

of your choice! Simply call 0906 666 0788 and that's it!

The download of ring tones

First of all you must subscribe to the SMS function with your network provider (see SMS

leaflet).

Just call 0906 666 0788 and follow the instructions!

You have chosen your ring tone? You are about to receive it by SMS.Then you will be able to

download it on your telephone (see “SMS” chapter in the user manual, part “Read SMS/To

save a ring tone”). Be careful, only three downloaded ring tones can be saved! If you wish to

download another ring tone, you will have to delete one of them from "My ring tones" list

(see “SOUNDS” chapter in the user manual, part “My ring tones/To delete a ring tone”).

The download of outgoing messages (only available on DECT phones

with answer machines).

By default, your answer machine is switched on.You have to change its settings to the "Answer

and Record with personalised OGM" mode (refer to “ANSWER MACHINE” chapter in the

user manual, part “Settings/To record your personal outgoing message”).These two

conditions are necessary to receive your message. Be careful! On the “Answer and Record

with personalised OGM” mode, recording a new message will automatically delete the

previous one. Before downloading an outgoing message, make sure your answer machine is not

full.

Keep in mind your Remote Control code (RC) written under your base station (see the

“ANSWER MACHINE” chapter in the user manual, part “Settings/To change the

remote control code”).

Just call 0906 666 0788 and follow the instructions!

Remember to free the line. Do not answer the next call and wait for your answer machine to

record the message.

You can choose to welcome all the callers with this message or only the group of your choice.

In this case, you must previously subscribe to the Caller Display Service offered by your

network provider.

3111 285 22324

Printed in Romania

Feuillet 123 multimedia UK_ind4.qxd 19/01/2005 17:09 Page 1

Philips DECT5152S/07

Product's Documents

User manual

Specifications

Philips DECT5152S/07 Questions and Answers
