Operating Instructions
Model: GCPF350
40cm Whisper Quiet Pedestal Fan
General Care and Safety Guide
Thank you for choosing this Jackson product. This Jackson appliance has been designed
and manufactured to high standards of engineering and with proper use and care, as
described in this leaflet, will give you years of useful service. Please read these
instructions carefully and keep them for future reference.
1. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
4. Ensure that the fan is switched off from the supply mains before removing the
guard.
5. Use only the voltage specified on the rating plate of the appliance.
6. Keep all objects at least 1 Metre from the front, sides and rear of the appliance
7. This appliance is intended for household use only and not for commercial or
industrial use.
8. Use this appliance only as described in this manual. Any other use is not
recommended by the manufacturer and may cause fire, electric shock or injury.
9. The common cause of overheating is deposits of dust or fluff in the appliance.
Ensure these deposits are removed regularly by unplugging the appliance and
vacuum cleaning the air vents and grills.
10. Always unplug appliance when not in use.
11. When the appliance has been unpacked, check it for transport damage and ensure
all parts have been delivered. If parts are missing or the appliance has been
damaged, contact the Jackson Customer Services Team.
12. If your appliance does not work, or is not working properly, contact the place of
purchase. Repair work on the appliance by unqualified persons can cause serious
risk to the user.
13. Ensure hands are dry before handling the plug or the main unit.
14. Carry out regular checks of the supply cord to ensure no damage is evident.
15. Ensure that the cord is fully extended (not coiled) while in use.
16. Avoid contact with the moving parts. Keep hands, hair, clothing, away from blade
of the fan during operation to reduce the risk of injury to person and/or damage
to the unit.
17. Switch off and use handles provided when moving.
18. It is recommended that this fan is plugged directly into the wall socket.
19. A correctly specified, undamaged extension cord may be used with this fan
provided it is used in a safe manner.
20. Never place appliance close to radiant heat source.
21. Never operate in areas where petrol, paint or other flammable liquids are used or
stored.
General Care and Safety Guide
22. Never use the appliance to dry clothes.
23. Never insert or allow foreign objects to enter any ventilation or exhaust opening,
as this may cause an electric shock, fire or damage to the appliance.
24. Never use abrasive cleaning products on this appliance. Clean with a damp cloth
(not wet) rinsed in hot soapy water only. Always remove plug from the mains
supply before cleaning.
25. Never connect the appliance to mains supply until completely assembled and
adjusted.
26. Never remove plug from power socket until the appliance has been switched off.
27. Never remove plug from power socket by pulling cord – always grip plug.
28. Never twist, kink or wrap the cord around the appliance, as this may cause the
insulation to weaken and split. Always ensure that all cord has been removed from
any cord storage area and is unrolled before use.
29. Never use this appliance in the immediate surrounds of a bath, a shower, or a
swimming pool or other liquids. The appliance must not be immersed in any
liquids.
30. Due to the risk of injury, never use this appliance for any purpose other than its
intended use. This appliance is intended for use in household and similar
applications such as staff kitchen areas in shops, offices and other working
environments; farm houses, by clients in hotels, motels, bed and breakfast type
environments and other residential type environments
31. Never use this appliance outdoors.
32. Never operate the appliance with a damaged cord or plug, after it malfunctions, or
if it has been damaged in any manner. Have the appliance checked and repaired
by a qualified electrician if repair is necessary.
33. Never place the unit in wardrobes or other enclosed spaces as this may cause fire
hazards.
1. Front grill
2. Grill protective ring
3. Blade knob
4. Blade
5. Rear grill mounting nut
6. Rear grill
7. Shaft
8. Motor assembly
9. Oscillating pin
10. Remote storage
11. Control panel
12. Inner pole
13. Height adjuster
14. Outer pole
15. Base
16. Base locking mechanism
17. Remote control
18. Fasten clip
Components
Warning: Never operate the fan without all components assembled
correct. The fan must only operate in the up-right position.
Place the base on a flat surface. Remove the locking
mechanism from the pole and insert the pole onto the
base.
Turn over the base with the pole inserted and secure by
turning the locking mechanism clockwise until completed
fastened.
Place the motor assembly and control panel onto the
extension pole and secure by turning the assembly knob
clockwise.
Remove the rear grill mounting nut by turning it counter-
clockwise.
Place the rear grill onto the motor housing aligning the 3
raised knobs on the top of the motor housing with the 3
holes on the grill.
Place the rear grill mounting nut and tighten turning
clockwise.
Assembly
Fix the front grill and the rear grill with the fastening ring
around the grill.
You will hear it click into place around the grill.
Align the blade onto the shaft and secure it by
tightening the blade knob counter-clockwise.
Then use a screwdriver to tighten the fastening
ring.
Always choose a safe location for the fan, keeping in mind the safety precautions
outlined. Ensure all packaging has been removed from the unit before use. This
appliance requires no installation, it should be used solely as a portable appliance.
WARNING: Keep all objects at least 1 metre from the front, sides and
rear of the appliance
Place the fan on a dry, level and sturdy surface.
Plug the power cord into the socket ensuring the fan switch is in the off position.
This Fan may be operated by the Manual Controls located on the
front of the unit or by the Remote Control.
On/Off: To turn fan on, press the Power button.
The fan will start on high speed.
Speed Control: Press the Fan button repeatedly
to change speed.
Whisper Quiet is fan speed 1 and the fan will operate
at about 35 decibels
Auto-off Timer: This setting will automatically turn
your fan off after 1, 2, 4, or 8 hours.
1 hour: Press one time
2 hours: Press two times
4 hours: Press three times
8 hours: Press four times
Turn Timer off: Press five times or press power button
To turn off, press the Power button.
To activate Oscillation, press the knob on the back of the motor
housing. To turn off Oscillation, pull the knob back up again.
Remote Control
Install 2 x AAA batteries (not supplied) into the back of the remote
control .
All the functions performed with the Remote-Control work
identically to the Manual Controls.
Do not mix old and new batteries. Do not mix alkaline, standard
(carbon-zinc) or rechargeable (nickel- cadmium) batteries.
DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY EXPLODE
OR LEAK.
IMPORTANT! NEVER COVER THIS APPLIANCE!
Operating your Fan
The fan requires regular cleaning to ensure trouble free operation.
Ensure that the fan is switched off from the supply mains before removing the guard.
Unplug the fan from the mains supply before cleaning.
Use a damp cloth (not wet) to wipe the exterior of the fan to remove dust and dirt.
Use a vacuum cleaner to remove dust and fluff from around the grills.
Ensure the fan is dry before plugging back into the mains supply.
Do not attempt to dismantle the fan. There are no user serviceable parts. For service
or repair, contact an authorised electrical service technician.
Cleaning
SUPPORT AND TECHNICAL ADVICE
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase. (Refer to back of booklet).
Goldair – New Zealand
Monday – Friday 8am-5pm
Phone +64 (0)9 917 4000
Phone 0800 232 633
Goldair – Australia
Monday – Friday 8am-5pm
Phone +61 (0)3 9365 5100
Phone 1300 465 324
info@cdbgoldair.com.au
Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in normal
domestic use for a period of one year. In non-domestic use Goldair limits the voluntary warranty to three months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the
warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone
other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits to you given by this warranty are in addition to other rights and remedies available to you under a law in relation to
the goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
One Year Warranty
Goldair One Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
