INTERCHANGEABLE 3-IN-1 COB LED
RECHARGEABLE INSPECTION LIGHT
MODEL NO: LED0131R
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
9 Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
9 Ensure the lamp is fully charged before initial use.
8 DO NOT charge in damp conditions.
8 DO NOT turn the lamp on when it is being charged.
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the lamp.
8 DO NOT handle or move the lamp whilst it is being charged.
8 DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
IMPORTANT WARRANTY INFORMATION
The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time.
We will provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
If the battery is not properly charged before rst use, or regularly conditioned, its capacity will diminish.
Under these circumstances we will not replace the battery regardless of whether the battery is less than one year old.
2. INTRODUCTION
Innovative 3-in-1 worklight. Threaded interface enables user to change between 1000 lumen torch with sliding focus, 450 lumen
worklight and a 300 lumen exi-head. Features a power indicator on the switch and a magnet on the base for hands-free operation.
Supplied in a presentation box with a high quality micro USB cable.
3. SPECIFICATION
4. OPERATION
4.1. The LED0131R has been tted with a protective disc to protect the battery from switching the light on when in transportation. Remove
protective disc before operation by undoing the battery compartment screw cap, remove protective disc. Screw compartment screw cap
back up.
4.2. CHARGING
4.2.1. Insert USB cable into mains plug (Not supplied) and plug into mains supply.
4.2.2. Remove USB socket cover on side of main body of torch.
4.2.3. Connect the USB lead to the port on the side of the main body and a USB power socket. Turn on the power supply.
Refer to
instructions
LED0131R Issue 3 (4) 02/02/24
Original Language Version
© Jack Sealey Limited
Model No: LED0131R
Battery: 3.7V 2200mAh Lithium-ion
Charging Time: 7hrs
LED Type: 5W LED + 5W COB + 10W SMD
Lumen Output COB: 450lm, Flexi-head light: 300lm. Torch:1000lm
IP Rating IPX4
Operating Time (High): Flexi-headlight: 11hrs COB:4.2hrs. Torch 3.3hr
4.2.4. Switch o power supply, remove charging lead and replace socket cover.
4.3. OPERATION
4.3.1. TORCH
4.3.1.1. Attach torch head by screwing onto main body.
4.3.1.2. To turn on press the on/off button, once for brightest, again for low light and once more to turn off.
4.3.1.3. The torch has a sliding focus.
4.3.1.4. To remove the torch head unscrew from main body.
4.3.1.5. Torch has a magnetic base for hands free use.
4.3.2. INSPECTION LAMP
4.3.2.1. Attach inspection lamp head by screwing onto main body.
4.3.2.2. The inspection lamp can be tilited through 180°.
4.3.2.3. To turn on press the on/o button once for low light, twice for brightest and once more for o.
4.3.2.4. Press on/o to turn o.
4.3.3. FLEXIBLE INSPECTION LAMP
4.3.3.1. Press on/o to turn on and o.
4.3.3.2. Flexible inspection lamp has adjustable focus and a 350mm exible neck for use in areas where access is limited.
4.4. BATTERY INSTALLATION/REMOVAL
4.4.1. Unscrew end cap on main body of torch.(fig.1)
4.4.2. Slide the battery into/out of the body of the torch.
4.4.3. Screw end cap back onto torch body.
5. MAINTENANCE
5.1. Keep lamp clean and check for damage before every use. If damage is observed, remove from use until unit is repaired.
Original Language Version
© Jack Sealey Limited
LED0131R Issue 3 (4) 02/02/24
g.1
Torch
Torch
Slide for
Focus
Battery compartment
screw cap
Magnetic base
On / O
Lamp
180
o
Flexible
USB charging
socket on rear
BATTERY REMOVAL
See section 4.3. Batteries should be disposed of in an environmentally protective way. Under the Waste Batteries and Accumulators
Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products containing batteries (as defined within these
regulations), that they are registered with Valpak’s registered compliance scheme. Jack Sealey Ltd’s Batteries Producer Registration
Number (BPRN) is BPRN00705.
Parts support is available for this product. Please email sales@sealey.co.uk or telephone 01284 757500
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
