Sealey SPB160W AC Power Pack 160W 115Wh User Manual

115WH LITHIUM AC POWER PACK 160W

MODEL NO: SPB160W.V2

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

1.1. ELECTRICAL SAFETY FOR USE OF POWER PACK

 WARNING! It is the user’s responsibility to read, understand and comply with the following electrical instructions:

You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices.

9 You must also read and understand the following instructions concerning electrical safety.

 TheElectricityAtWorkAct1989requiresallportableelectricalappliances,ifusedonbusinesspremises,tobetestedbyaqualied

electrician, using a Portable Appliance Tester (PAT).

9 The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and

 thesafetyoftheapplianceoperator.Ifinanydoubtaboutelectricalsafety,contactaqualiedelectrician.

You must ensure that you:

9 Inspect the Power Pack, charge cables and connectors for wear and damage to ensure items are safe before use. If worn or

damaged DO NOT use.

9 Uncoil used cables between Power Pack and devices when in use.

9 DO NOT pull the Power Pack from any sockets by the lead used.

8 DO NOT try to take the Power Pack apart.

8 DO NOT get the Power Pack wet, or use in wet, damp conditions (for indoor use only).

 WARNING! Modern vehicles contain extensive electronic systems.

 YouarerequiredtocheckwiththevehicleManufacturer,foranyspecicinstructionsregardingtheuseofthistypeofequipmenton

each vehicle. No liability will be accepted for damage / injury, where this product is not used in accordance with all instructions.

1.2. BATTERY SAFETY

9 Recycle or dispose of used battery as stipulated by local regulation.

9 Ensure the internal battery is fully charged before initial use.

 WARNING!Toreducetheriskofburnsorre:

8 DO NOT attempt to open, disassemble, modify or service the battery pack.

8 DO NOTcrush,puncture,shortexternalcontactsordisposeofinreorwater.

8 DO NOT expose to temperatures above 60°C (140°F).

8 DO NOT move/handle/use the Power Pack when it is being charged.

8 DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently

recharge the battery at least once every three months of non-use.

1.3. GENERAL SAFETY INSTRUCTIONS

9 Familiarise yourself with the application and limitations of the Power Pack as well as the potential hazards.

9 Keep children and unauthorised persons away from the working area.

9 When not in use, store carefully in a safe, dry, childproof location.

9 Use the cables provided with this unit only.

8 DO NOT short circuit this unit and keep it way from metal objects such as coins, keys, jewellery etc.

8 DO NOT pull the cables or clamps from any connections.

8 DO NOT use the unit outdoors, or in damp, or wet locations and DO NOT operate within the vicinity of flammable liquids or gases.

8 DO NOT use for a task for which it is not designed.

8 DO NOT modify or disassemble the Power Pack.

8 DO NOTdropunit.Ifunitreceivesasharpbloworisotherwisedamagedinanywayhaveitcheckedbyaqualiedtechnician.

NOTE: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of

the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

SPB160W.V2 Issue 3 18/09/23

Original Language Version

Refer to

instructions

Electrical shock

hazard

Keep in dry area

protect from rain

Warning:

explosive

material

2. INTRODUCTION

 Poweredbylithium-iontechnology.Easilytsinagloveboxorbackpack,weighingat1.5kg.Multiplehighamperageoutputs.Fitted

 witha115Whbattery.ThisunitcanalsosupplymultiplefullchargestobatteriesintheSealey20V,14Vand12Vpowertoolranges.

Supplies several full charges for smartphones (e.g. iPhone ; seven charges and Samsung Galaxy ; six charges) or two full charges

for your tablet/laptop (based on an 8800mAh battery) as well as many other devices. Fully charges in 8 hours with an 18W fast charger

 (notincluded).SuppliedwithType-Cchargingcable.Includesasmallintegralworklight.Inputs:2xBi-DirectionalType-C(5VDC

 2A,9VDC2A,12VDC1.5A).Outputs:230V~50HZAC,2x12V8ADCOutputs(100WMAX.),StandardUSB5VDC2A,QC3.0USB

 (5VDC2A,9VDC2A,12VDC1.5A),3xType-COutputs(5VDC2A,9VDC2A,12VDC1.5A).

3. SPECIFICATION

Model No.: ..................................................................SPB160W.V2

Inputs: ...........................................2 x Bi-Directional TYPE-C

Outputs: .................................................................................

230V~50HzAC,2x12V8ADCOutputs(100WMax),StandardUSB5VDC2.1A,USBQC3.0(5VDC2.1A,

9VDC2.1A,12VDC1.5A),Type-Coutput(5VDC2.1A,9VDC2.1A,12VDC1.5A)

Capacity: ............................................ 115WhLithiumBattery

Accessories: ..... USB Type-C Cable, DC Car Socket Adaptor

Charge Times: ............................... 8hrs on 18W Fast Charge

Dimensions (W x D x H): ...........................263x115x40mm

4. OPERATION

4.1. CHARGING THE POWER PACK

4.1.1.  UsingtheTYPE-CChargingcableincluded,insertthecableineitherport(g1.7or1.8).Connecttheotherendofthecableintoeither

a USB-A Plug adapter (not supplied), car accessory charger (not supplied) or directly into a wall mounted USB-A output.

4.1.2.  Whilecharging,theLEDchargeindicator(g.1.1),willdisplaybatterylevel.Onelightlitindicates0-20%,allvelightslitindicate

 80-100%.Oncefullycharged,theunitwillswitcho󰀨.

4.2. USING THE POWER PACK

4.2.1. To charge USB digital devices, select appropriate cable for your device. Plug the charging cable into any of the 2 USB-A outputs (Fig

 1.3andg1.4)or3USBTYPE-Coutputs(Fig1.5,Fig1.6orFig1.7).Disconnectafteruse.

4.2.2.  TousetheDC12Voutput,plugthecaraccessorysocketcableintotheDCoutputport(g.1.2)andinsertcharger(notsupplied)into

the accessory socket.

4.2.3. Disconnect after use.

4.2.4. Insert a suitable 3 pin plug into the AC output while ensuring the device is within the recommended wattage.

4.2.5. Pressandholdthepowerbutton(g.1.9)downfor3secondstoturnontheACoutput.

4.2.6.  Whennishedwiththisfeature,pressandholdthepowerbuttontoturno󰀨theACoutput.

4.2.7. Disconnect after use.

4.3. LED WORK LIGHT

4.3.1.  Doublepressthepowerbutton(g.1.9)toturnLEDon.

4.3.2. Press the power button when LED is lit to change between three modes (Normal, SOS and Strobe).

4.3.3.  DoublepressthepowerbuttontoturntheLEDo󰀨.

5. MAINTENANCE

5.1. After usage recharge the unit.

5.2. After charging / usage remove all cables / connections.

5.3. Use a clean, dry cloth to wipe down the unit after use.

5.4. ` Store in clean, dry environment with ambient temperature between 4

C and 30

1 LED Charge Indicator

2 Dual 12V DC Output

3 5V/2.1AUSBOutput

4 USBOutput(QC3.0)

5 TYPE-C Output

6 LED Light

7 Bi-Directional TYPE-C 1

8 Bi-Directional TYPE-C 2

9 Power button

Original Language Version

g.1

SPB160W.V2 Issue 3 18/09/23

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,

taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product

becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and

dispose of the product and fluids according to local regulations.

WEEE REGULATIONS

Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment

(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid

waste authority for recycling information.

BATTERY REMOVAL

Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products

containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack

SealeyLtd’sBatteriesProducerRegistrationNumber(BPRN)isBPRN00705.

Partssupportisavailablefortheseproducts.Pleaseemailsales@sealey.co.ukortelephone01284757500

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice. Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
