APPLICABLE MODEL: K510WB
USER MANUAL
BE A PRO IN YOUR KITCHEN
K510WB
Kucht Wine Cooler
www.kucht.com
2
Table of Contents
Diagram and Description
....................................................................................................................................................................
3
Safety Tips
.............................................................................................................................................................................................
4
Installation Instructions
.......................................................................................................................................................................
5
Operation Instructions
........................................................................................................................................................................
5
Using the control panel
.....................................................................................................................................................................5
Setting Temperature
............................................................................................................................................................................
6
Care and Maintenance
........................................................................................................................................................................
6
Racking Configuration
.........................................................................................................................................................................
7
Moving Racks
........................................................................................................................................................................................
7
Reverse the door
................. .................................................................................................. ..........................................................8
Troubleshooting........................................................................................................................... .......................................................9
Technical Specifications
................................................................................................................................................................
.....10
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
3
Diagram and Description
1. Control Panel
2. Glass Door Handle
3. Door Hinge
4. Storage Shelf
5. Glass Door
6. 54L Drawer Handle
7. 54L Drawer Door
8. 45L Drawer Handle
9. 45L Drawer Door
10. Adjustable Feet
11. Kickplate
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
4
Safety Tips
Before using this appliance, it must be properly positioned and installed as described in this manual, so please read
carefully. To reduce the risk of fire, electrical shock or injury when using the appliance, follow these basic precautions.
Plug into a grounded outlet. Do not under any circumstances cut or remove the third ground prong from
the power cord supplied, do not use an adapter, and do not use an extension cord.
It is recommended that a separate circuit, serving only your appliance be used. Do not use outlets that can
be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids and do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.
Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in electrical
shock or death.
Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this
manual. All other servicing should be referred to a qualified technician.
Use two or more people to move and install appliance. Failure to do so can result in back or other injury.
To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed. Choose
a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C). This unit must be installed
in an area protected from the element, such as wind, rain, water spray or drips.
The appliance should not be located next to ovens, grills or other high heat sources or in areas of extreme cold.
The appliance must be installed in accordance with state and local codes. A standard electrical supply (110-120V
AC only, 60 Hz), properly grounded in accordance with the National Electrical Code and local ordinances is
required.
Do not kink or pinch the power supply cord of appliance.
The fuse (or circuit breaker) size should be 15 amperes.
It is important for the appliance to be leveled in order to work properly. You may need to make several
adjustments to level it.
Never allow children to operate, play with or crawl inside the appliance. Child entrapment and suffocation are
not just problems of the past, junked or abandoned appliances are still dangerous. When no longer using your
old wine cellar, take off the door and leave the shelves in place so that children may not climb inside easily.
Do not use solvent-based cleansers or abrasives on the interior as they may damage or discolor the interior.
Because of potential safety hazards under certain conditions, it is strongly recommended that you do not use an
extension cord with this appliance.
If the appliance is going to be used in an area that is prone to power surges/outages, it is suggested that you
use a power surge protector. The surge protector that you select must have a surge block high enough to
protect the appliance it is connected to. Damages due to power surges are not considered a manufacturer
covered defect and will void your product warranty.
The cord should be secured behind the appliance and not left exposed or dangling to prevent accidental injury.
Never unplug the appliance by pulling the power cord. Always grip the plug firmly and pull straight out from the
receptacle. Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do
not use a cord with cracks or abrasion damage along its length or at either end. When moving the appliance, be
careful not to damage the power cord.
Do not use this apparatus for other than its intended purpose.
Failure to heed these safety warnings may result in extensive product damage, serious personal injury, or death.
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
5
Installation Instructions
BEFORE USE:
Remove the exterior and interior packaging.
Before connecting the unit to the power source, let it stand upright for approximately 8 hours. This will reduce
the possibility of a malfunction in the cooling system from handling during transportation.
Clean the interior surface with lukewarm water using a soft cloth.
This appliance is designed for freestanding use. Ensure that there is 5cm of air space on both sides, and 8cm in
back.
Place the unit on a flat, solid floor that is strong enough to support it when it is fully loaded. To level the
appliance, adjust the front leveling leg at the bottom of the unit.
When moving your wine cellar, please do not incline it more than 45 degrees.
Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator, etc.). Direct sunlight
may affect the acrylic coating and heat sources may increase electrical consumption. Extreme cold ambient
temperatures may also cause the unit to perform improperly. The optimal ambient temperature range is 18°C -
26°C
Avoid locating the unit in damp areas.
Plug the wine cellar into an exclusive, properly installed and grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning power
and/or electrical grounding should be directed to a certified electrician or authorized products service center.
After plugging the appliance into a wall outlet, allow the unit to cool down for 3 to 4 hours before placing
wine bottles or beverage cans in the appliance.
Operation Instructions
The wine cellar should be placed in an area where the ambient temperature range is between 18-26 degrees. If the
ambient temperature is above or below this range, the performance of the unit may be affected. For example, placing
your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate.
Upper: 5-22°C(41°F - 72°F)，lower drawer: 1-8°C(34°F - 46°F)
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
6
To set the desired temperature for the upper or lower zone, press the Temperature Set button, and then use the
Temperature up and down buttons to set the zone to the desired temperature.
Light: Turns the interior light on or off
°C / °F – To toggle the temperature display between Celsius and Fahrenheit, press the button for 3 seconds.
NOTE: If the unit is unplugged, power lost, or turned off, you must wait 3 to 5 minutes before restarting the unit. The
unit contains compressor protection which will prevent the unit from starting until this time period has elapsed.
When you use the wine cooler for the first time or restart the wine cooler after having been shut off for a long time,
there could be a few degrees variance between the temperature you select and the one indicated on the LED readout.
This is normal and once the wine cooler is running for a few hours the display will be correct.
STORAGE CAPACITY
Bottles differ in size and dimensions. The actual number of bottles you are able to store may vary from the amount
quoted.
Bottle capacities are approximate maximums when storing traditional 750ml bottles and include bulk storage.
Setting Temperature
The Wine Cellar has a wide enough temperature range to store either red or white wine, depending on your preference.
Different varietals of wine require different temperature settings. Red wine is generally stored between 10°C(50°F) and
18°C(65°F) , while white wines are stored between 4°C( 40°F) and 10°C (50°F) . White wine can be stored at red wine
temperatures for a short period of time (less than three months), and flash chilled before serving.
You can set the temperature as you desire by touching the UP or DOWN button. When you touch the buttons for the
first time, the LED readout will show the original temperature set at the manufacturing facility. Each push of the button
will adjust the temperature by one degree in the desired direction. Please be aware that the desired temperatures may
fluctuate depending on whether the interior light is ON or OFF and depending on the orientation of the bottles.
PLEASE NOTE:
In the event of a power interruption, all previous temperature settings will be automatically saved and
each compartment will return to the previous temperature setting.
If the unit is unplugged, loses power, or is turned off, you must wait 3 to 5 minutes before restarting. Attempting
to restart the wine cellar before this time has elapsed may prevent it from starting.
When you use the wine cellar for the first time or restart the wine cellar after having been shut off for a long
time, there will be a few degrees variance between the temperature you select and the one indicated on the
LED readout for the first few hours of operation. After a few hours of operation, the temperature will normalize
to the displayed temperature.
Care and Maintenance
Cleaning your wine cellar:
• Turn off the power, unplug the appliance, and remove all items including all shelves.
• Wash the inside surfaces with warm water and baking soda solution. The solution should be about
2 tablespoons of baking soda to a quart of water.
• Wash the shelves with a mild detergent solution.
• Wring excess water out of the sponge or cloth when cleaning area of the controls, or any electrical parts.
• Wash the outside cabinet with warm water and mild liquid detergent.
Rinse and wipe dry with a clean soft
cloth.
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
7
Dust the front grill and back of the unit twice yearly. Make sure the power is off before cleaning.
It is recommended to clean the unit completely inside and out yearly to maximize the longevity of the product.
Moving your wine cellar:
Remove all bottles and any other items you may have inside the unit.
Securely tape down all loose items (shelves) inside your appliance and tape the door shut.
Turn the adjustable leg up to the base to avoid damage.
Be sure the appliance stays secure in the upright position during transportation.
Protect the outside of the appliance with a blanket or similar item.
Racking Configuration
Disperse your bottles evenly throughout the unit so as not to concentrate weight in any one area. This also helps to
provide an even temperature range throughout the unit. Make sure that bottles are not all grouped together either at
the top or bottom of the cabinet. The maximum capacity per shelf is 20kgs. Never try to pull out more than one rolling
shelf at a time as it can cause the appliance to tip forward.
You can remove a shelf to accommodate larger diameter bottles on the shelf below it. To remove a shelf, pull it out as
far as you can. There are levers on each side of the shelf near the rollers. Left the lever on the left hand side and push
down the lever on the right hand side to remove the shelf from the tracks.
This wine cellar has 9 shelves that each shelf can hold up to 11 bottles.
Moving Racks
The shelves have smooth glide-out rollers that are adjustable in 1 1/4" increments to accommodate larger bottles
according to your needs. To move a sliding shelf, first remove all bottles, and then remove the sliding shelf by sliding
guides from walls, making sure not to mix up the right and left guides.
Then refit the sliding shelf as shown below:
GUIDE
SLIDING SHELF
These adjustable shelves allow you to customize the interior of the cabinet to accommodate your specific collection.
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
8
Reverse the door
1. Hold the door, loosen and remove the screws on right upper hinge by tools.
2. Li the door and take it out from the lower hinge and place it on the mat to avoid damage and scratches.
Then remove the right lower hinge.
3. Remove the rubber caps covering the holes on the le side, install the le lower hinge (include in the fings).
4. Put the door on the lower hinge, reverse the upper hinge direction, and fix it on the top of the door. Adjust the door
to make sure it is level with the top of the unit. Then tighten all the screws.
←
←
←
←
←
←
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
9
Troubleshooting
There are many common issues you may experience with your wine cellar that can be solved very easily, without
the need of a service call. Try the tips below to troubleshoot your unit should you experience any problems:
PROBLEM
POSSIBLE CAUSE
Wine cellar does not operate
Not plugged in or the appliance is turned off
The circuit breaker tripped or a fuse has blown out
Wine cellar is not cold enough
Check the temperature control setting
External environment may require a higher setting
The door is opened too often
The door is not closed completely
The door gasket is not sealing properly
Wine cellar is turning on and off frequently
The room temperature is hotter than normal.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work
Not plugged in.
The circuit breaker tripped or a fuse has blown.
The light bulb has burned out.
The light button is “OFF”.
Vibrations
Check to assure that the Wine cellar is on a level surface.
The wine cellar seems to make too much noise
A faint humming noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling sounds caused by
the flow of refrigerator in your wine cellar.
Contraction and expansion of the inside walls may cause
popping and crackling noises.
The wine cellar is not on a level surface.
The door will not close properly
The wine cellar is not on a level surface.
The gasket is dirty.
The shelves are out of position.
Condensation forming inside of the cabinet
Condensation occurs when too much ambient air gets into the
cabinet. Wipe off the doors and walls and leave door closed
as long as possible.
Check that the door gasket and the charcoal filter are properly
in place.
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
10
Technical Specifications
Model
Wine Cooler
Climate Class
Please refer to the information indicated on the product. You will find the information
on the rating label on the back of the unit as well as inside the cooling compartment.
The circuit diagram is displayed on the back of the unit as well as inside the cooling
compartment
Refrigerant Gas
Refrigerant Charge
Temperature Range (°C)
Input Power
Rated Frequency
Rated Voltage
Internal volume
Net Weight
Gross Weight
Foaming Agent
External Dimension (mm)
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
WE TRANSFORM A SIMPLE KITCHEN INTO A PRO ONE.
THIS IS WHY WE CARE ABOUT MAKING VERY HIGH PERFORMANCE
RANGES AND HOODS, TO MAKE YOU FEEL LIKE A PRO AND STYLISH COOKER.
DESIGN: LONDON DC - WWW.LONDON-DC.COM
