FORM NO. Z2547
REV. A-05/01/2018
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKERS
To prevent appliance damage and injury, read these instrucons
thoroughly prior to installaon.
H80CIM/-AD
PRODUCT MANUAL
H80CIM* 15” SIGNATURE SERIES CUBELET ICE MAKER
H80CIM*-AD 15” ADA COMPLIANT CUBELET ICE MAKER
1A5237-01
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
2 | perlick.com/residential
INTRODUCTION
Congratulaons on your purchase of a Perlick Residenal
undercounter appliance. This manual has been prepared to
assist you in the installaon of your undercounter ice maker.
We dedicate considerable me to ensure that our products
provide the highest level of customer sasfacon. We thank
you for selecng Perlick products for your home and assure you
of our connuing interest in your sasfacon.
WARRANTY REGISTRATION
To register your Perlick product, visit our website at
www.perlick.com/RegisterMyPerlick and ll out the form.
Once completed, click on the ‘Submit Warranty Registraon’. Be
sure to register your product immediately upon installaon to
receive the warranty from installaon date instead of shipment
date. If le blank, the date will revert back to shipment date.
CONTENTS
3 Safety Consideraons
5 Prior To Installaon
6 Niche / Product Dimensions / Connecons
10 Construcon
11 Electrical / Refrigerant
12 Installaon Instrucons
20 Setup
21 Electrical Connecon
22 Water Supply And Drain Connecons
23 Final Checklist
24 Operang Instrucons
25 Startup
26 Maintenance
32 Preparing The Appliance For Periods Of Non-Use
33 Disposal
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 3
DANGER
!
SAFETY CONSIDERATIONS
IMPORTANT SAFETY INFORMATION
This manual should be read carefully before the ice maker
is installed and operated. Only qualied service technicians
should install, service, and maintain the ice maker. Read the
warnings contained in this booklet carefully as they give
important informaon regarding safety. Please retain this
booklet for any further reference that may be necessary.
DAN This indicates that a hazardous situaon
may occur when instrucons are not followed. It is imperive
that direcons in this guide are followed to prevent possible
serious injury or death.
This indicates a situaon where minor
injury, product or cabinet damage may occur if the following
instrucons are not followed.
This highlights informaon that is of
signicant importance.
WARNING
DANGER
!
CAUTION
This ice maker should be desned only to
the use for which it has been expressly conceived. Any other
use should be considered improper and therefore dangerous.
The manufacturer cannot be held responsible for eventual
damage caused by improper, incorrect, and unreasonable
use. To reduce the risk of death, electric shock, serious injury,
or re, follow basic precauons including the following:
Only qualied service technicians should
install and service the appliance.
The appliance must be installed in
accordance with applicable naonal, state, and local codes
and regulaons.
The appliance requires an independent
power supply of proper capacity. See the nameplate for
electrical specicaons. Failure to use an independent power
supply of proper capacity can result in a tripped breaker,
blown fuse, damage to exisng wiring, or component failure.
This could lead to heat generaon or re.
THE APPLIANCE MUST BE GROUNDED:
The appliance is equipped with a NEMA 5-15 three-prong
grounding plug to reduce the risk of potenal shock hazards.
It must be plugged into a properly grounded, independent
3-prong wall outlet. If the outlet is a 2-prong outlet, it is your
personal responsibility to have a qualied electrician replace
it with a properly grounded, independent 3-prong wall outlet.
Do not remove the ground prong from the power cord and
do not use an adapter plug. Failure to properly ground the
appliance could result in death or serious injury.
Do not use an extension cord.
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands. Make sure
the control switch is in the “OFF” posion before plugging in
or unplugging the appliance.
Do not use an appliance with a damaged
power cord. The power cord should not be altered, jerked,
bundled, weighed down, pinched, or tangled. Such acons
could result in electric shock or re. To unplug the appliance,
be sure to pull the plug, not the cord, and do not jerk the
cord.
Do not make any alteraons to the
appliance. Alteraons could result in electric shock, injury,
re, or damage to the appliance.
Do not place ngers or any other objects
into the ice discharge opening.
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
4 | perlick.com/residential
The appliance is not intended for use by
persons (including children) with reduced physical, sensory,
or mental capabilies, or lack of experience and knowledge,
unless they have been given supervision or instrucon
concerning use of the appliance by a person responsible for
their safety.
Young children should be properly
supervised around the appliance.
Do not climb, stand, or hang on the
appliance or appliance door or allow children or animals to
do so. Serious injury could occur or the appliance could be
damaged.
Be careful not to pinch ngers when
opening and closing the door. Be careful when opening and
closing the door when children are in the area.
Do not use combusble spray or place
volale or ammable substances near the appliance. They
might catch re.
Keep the area around the appliance clean.
Dirt, dust, or insects in the appliance could cause harm to
individuals or damage to the appliance.
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
SAFETY CONSIDERATIONS
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 5
PRIOR TO INSTALLATION
Protect the oor when moving the appliance
to prevent damage to the oor.
Follow the water supply, drain connecon,
and maintenance instrucons carefully to reduce the risk of
costly water damage.
In areas where water damage is a concern,
install in a contained area with a oor drain.
Install the appliance in a locaon that stays
above freezing. Normal operang ambient temperature must
be within 45°F to 100°F (7°C to 38°C).
If using the oponal drain pump (63802A),
test its operaon every me the appliance is cleaned and
sanized. See Oponal Drain Pump 63802A (pg 31) for details. If
the oponal drain pump is not operang properly, water could
back up and overow, leading to costly water damage.
To help ensure the storage bin drain remains
clear, follow the instrucons in Storage Bin Drain (pg 30) once
every 3 months or as oen as necessary for condions. If the
storage bin drain becomes clogged, water could build up in the
bin and overow, leading to costly water damage.
If water collects in the bin and will not drain,
turn o the appliance and close the water supply line shut-o
valve. Call for service.
If water seeps from the base of the appliance,
turn o the appliance and close the water supply line shut-o
valve. Call for service. Failure to do so could lead to costly water
damage.
Do not leave the appliance on during
extended periods of non-use, extended absences, or in sub-
freezing temperatures. To properly prepare the appliance
for these occasions, follow the instrucons in Preparing the
Appliance for Periods of Non-Use (pg 32).
Keep venlaon openings, in the appliance
enclosure or in the built-in structure, clear of obstrucon.
Do not place objects on top of the appliance.
The storage bin is for ice use only. Do not
store anything else in the storage bin.
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
6 | perlick.com/residential
NICHE / PRODUCT DIMENSIONS/CONNECTIONS
1. H80CIMS-L/R
Units: mm [in.]
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 7
NICHE / PRODUCT DIMENSIONS/CONNECTIONS
2. H80CIMW
Units: mm [in.]
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
8 | perlick.com/residential
NICHE / PRODUCT DIMENSIONS/CONNECTIONS
3. H80CIMS-ADL/R
Units: mm [in.]
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 9
NICHE / PRODUCT DIMENSIONS/CONNECTIONS
Units: mm [in.]
4. H80CIMW-AD
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
10 | perlick.com/residential
CONSTRUCTION
Top Panel
Ice Discharge
Opening
Scoop Holder
Front Panel
Control Switch
Louver
Bin Control
Thermostat
Bulb
Slope
Magnet
Catch
Door
Power Cord
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 11
ELECTRICAL/REFRIGERANT
The nameplate provides electrical and refrigerant data. The
nameplate is located inside the storage bin. For cercaon
marks, see the nameplate.
We reserve the right to make changes in specicaons and
design without prior noce.
Model Number H80CIMS-L
H80CIMS-R
H80CIMW
H80CIMS-ADL
H80CIMS-ADR
H80CIMW-AD
Electrical Supply 115-120V, 60 Hz., Phase 1
Power/Cord Type/ Length NEMA 5-15P w/6’ power cord
Design Pressure HI-240PSI LO-120PSI
Refrigerant 134a 3.92 OZ.
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
12 | perlick.com/residential
INSTALLATION INSTRUCTIONS
The appliance must be installed in
accordance with applicable naonal, state, and local codes
and regulaons.
CHOKING HAZARD: Ensure all components,
fasteners, and thumbscrews are securely in place aer
installaon. Make sure that none have fallen into the storage
bin.
A. Checks Before Installaon
Visually inspect the exterior of the shipping container
and immediately report any damage to the carrier. Upon
opening the container, any concealed damage should also be
immediately reported to the carrier.
Remove the shipping carton, tape, and packing material. If any
are le in the appliance, it will not work properly.
Remove the package containing the accessories.
Remove the protecve plasc lm from the panels. If the
appliance is exposed to the sun or to heat, remove the lm
aer the appliance cools.
See the nameplate inside the storage bin, and check that your
voltage supplied corresponds with the voltage specied on the
nameplate.
B. Locaon
1. General
The appliance is approved for indoor or outdoor use.
Normal operang ambient temperature
must be within 45°F to 100°F (7°C to 38°C); Normal operang
water temperature must be within 45°F to 90°F (7°C to 32°C).
Operaon of the appliance, for extended periods, outside
of these normal temperature ranges may aect appliance
performance.
The appliance will not work at sub-freezing
temperatures. To prevent damage to the water supply line,
drain the appliance if the air temperature is going to go below
32°F (0°C).
The appliance should not be located next to ovens, grills, or
other high heat producing equipment.
The locaon must provide a rm and level foundaon for the
appliance.
DANGER
!
DANGER
!
The appliance requires no side or top clearance. But allow
enough space at rear for water supply and drain connecons
and at least 15” (38 cm) clearance at front.
The appliance must be at oor level on a nished oor even
if under a cabinet. In areas where water damage is a concern,
install in a contained area with a oor drain.
Do not let the weight of the counter rest on
the appliance.
Do not install the appliance in a corner where
the door will interfere with other equipment or where the
appliance cannot be pulled out for service.
WARNING
WARNING
WARNING
WARNING
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 13
INSTALLATION INSTRUCTIONS
H80CIMS
H80CIMW
Min. 34"
(864 mm)
H80CIMS-AD
H80CIMW-AD
Min. 32"
(814 mm)
Min. 15"
(381 mm)
Between Two Cabinets Between a Cabinet and
the End of a Counter
Support: Do not
let the weight of
the counter rest
on the appliance
Min. 15"
(381 mm)
H80CIMS
H80CIMW
Min. 34"
(864 mm)
H80CIMS-AD
H80CIMW-AD
Min. 32"
(814 mm)
Min. 23"
(584 mm)
Oven
Appliance
Between a Cabinet and a Wall
or Tall Cabinet
In a Corner
Secure: Do not let
the weight of the
counter rest on
the appliance
Installaon Space
Model Height Width Depth
H80CIMS
H80CIMW
34" (864 mm) minimum
15" (381 mm) minimum
24" (610 mm) mini-
mum
H80CIMS-AD
H80CIMW-AD
32" (814 mm) minimum
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
14 | perlick.com/residential
INSTALLATION INSTRUCTIONS
(
)
(
)
(
)
(
)
(
)
(
)
(
)
(
)
(
)
(
)
H80CIMW Overlay Panel Specicaon
Panel Height 29 17/32" (750 mm)
Panel Width 14 13/16" (376 mm)
Panel Thickness 5/8" (16 mm) min;
3/4" (19 mm) max
Panel and Door Weight (total) 20 lb. (9 kg) max
H80CIMW
Overlay Panel Parts
No. Descripon Part Number Qty.
1 Threaded Wood Insert 4A4004-01 6
2 T2 Screw 4x8 SS 7P32-0408 3
3 Pan Head Screw M4x25 SS 7C12-0425 4
4 Truss Head Screw M4x8 SS 7C32-0408 2
5 Canoe Clip 4A5835-01 2
6 Sheet Metal Bracket 4A3998-01 1
OVERLAY PANEL SPECIFICATION
Use the specicaon that applies to your appliance (H80CIMW
or H80CIMW-AD) and the direcons that follow to prepare your
overlay panel.
OVERLAY PANEL FABRICATION AND ATTACHMENT
The overlay panel must be craed by a professional cabinet
maker to ensure quality results.
PARTS
Ensure that all parts required for the overlay panel assembly are
contained in the accessories bag.
1 2 3 4 5
6
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 15
H80CIMW-AD Overlay Panel Specicaon
Panel Height 27 9/16" (700 mm)
Panel Width 14 13/16" (376 mm)
Panel Thickness 5/8" (16 mm) min;
3/4" (19 mm) max
Panel and Door Weight (total) 20 lb. (9 kg) max
(
)
(
)
(
)
(
)
(
)
(
)
(
)
(
)
(
)
(
)
INSTALLATION INSTRUCTIONS
FABRICATION OF OVERLAY PANEL
Fabricate the overlay panel as outlined in the specicaon on
the previous page and the instrucons below.
1) Rout a channel at the boom of the overlay panel
to the proper dimensions. See “(C) Routed Area” in the
specicaon diagram and Fig. 1.
2) Drill six 1/4” diameter (hardwood may require slightly
larger diameter) holes 3/8” (10 mm) deep in the
locaons designated.
WARNING
Routed Channel
Fig. 1
Fig. 2
Holes Holes
3) Screw the 6 threaded wood inserts into the 1/4” holes
drilled in the previous step. Make sure that the inserts
are threaded straight and that the tops of the inserts
are ush to the overlay panel surface. Otherwise, the
overlay panel cannot be properly fastened to the door.
4) Mount the door handle hardware. Perlick recommends
that the door handle hardware be mounted on the
edge opposite of the door hinge side (oponal hinge
reversal is covered in step 6. Countersunk screw heads
are required to ensure that the hardware fasteners do
not interfere with the overlay panel ng ush with
the door.
H80CIMW-AD
Use care when drilling holes for mounng
hardware. All drilled holes must be straight and drilled to the
correct diameter and depth.
See “(A) Threaded Inserts” and “(B) Threaded Inserts” in
the specicaon diagram and Fig. 2.
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
16 | perlick.com/residential
INSTALLATION INSTRUCTIONS
6) If you would like to reverse the door hinges, do the
following:
a) Contact your local distributor to purchase Perlick
70084. The kit contains “hinge (A)-le.”
b) Remove the 2 bolts securing the top panel, then li
it o (See Fig. 4).
Hinge (A)-Le
Bracket
Screw
Top Brace
Gasket Notch
Screw
Hinge (A)-Right
Not Needed
Fig. 4
Bolts
Top Panel
d) Remove hinge (B) from the right side of the
appliance and the 2 ller screws from the le side.
Aach the 2 ller screws to the right side and aach
hinge (B) to the le side (See Fig. 6).
e) Rotate the top panel 180° from its previous posion.
This brings the notch that was previously in the
right rear to the le front (See Fig. 7). Hook the rear
part of the panel on the body, then secure the front
with the 2 bolts removed in step 6a.
f) Remove hinge (C1) from the top right part of the
door, ip it and reaach to the boom le. Remove
hinge (C2) from the boom right part of the door,
ip it and reaach to the top le (See Fig. 8).
Proceed to step 7.
Fig. 6
Hinge (B)
Filler
Screws
Screws
c) Remove hinge (A)-right and the bracket from the
right side of the appliance. Set aside hinge (A)-right;
it is not needed. Remove the top brace from the le
side. Fasten hinge (A)-le and the bracket to the le
side and the top brace to the right side (See Fig. 5).
Note: When on the proper side, the gasket notch for hinge (A) is
to the inside.
Fig. 3
Hinge Stop Pin
Hinge (B)
Hinge (A)
5) While maintaining a hold on the door, remove the
hinge stop pin from hinge (B). Pull out the boom of
the door slightly and gently remove the door from
hinge (A) (See Fig. 3). If you are leaving the door right
hinged, skip to step 7. If you would like to reverse the
door hinges, proceed to step 6.
Fig. 5
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 17
Notch
Top Panel
Fig. 7
Hinge (C1)
Hinge (C2)
Fig. 8
Screws
Screws
7) Remove the bushings from hinge (C1) and hinge (C2)
(the hinges aached to the door) (See Fig. 9).
8) Remove the gasket from the door (See Fig. 10).
Hinge
Bushing
Fig. 9
Gasket
Fig. 10
9) Temporarily fasten the overlay panel to the door using
2 of the M4×25 pan head screws provided.
Ensure that the back surface of overlay panel
is at before aaching (See Fig. 11).
WARNING
Screws
Fig. 11
10) Mark the centerpoint of the hinge (C1) and hinge (C2)
holes that extend over the overlay panel (See Fig. 12).
11) Remove the overlay panel from the door.
12) Drill 3/8” diameter holes 1/4” (7 mm) deep where you
marked on the overlay panel to accommodate the
hinge (C1) and hinge (C2) bushings.
Fig. 12
Mark the center point.
Overlay Panel
Door
Hinge
INSTALLATION INSTRUCTIONS
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
18 | perlick.com/residential
INSTALLATION INSTRUCTIONS
ATTACHMENT OF OVERLAY PANEL TO DOOR
1) Fasten the sheet metal bracket to the overlay panel
using the two M4×8 truss head screws provided. Snug
the screws, but do not ghten (See Fig. 13).
2) Temporarily fasten the overlay panel to the door using
2 of the M4×25 pan head screws provided (See Fig. 14).
Screws
Fig. 14
Fig. 13
Sheet Metal Bracket
Overlay Panel
Snug the screws,
but do not ghten.
3) Adjust the sheet metal bracket so that it is ush with
the boom of the door (See Fig. 15).
4) Remove the overlay panel from the door and ghten
the two M4×8 truss head screws securing the sheet
metal bracket to the overlay panel (See Fig. 16).
Door
Sheet Metal Bracket
Fig. 15
Sheet Metal Bracket
Overlay Panel
Tighten the screws.
Fig. 16
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 19
INSTALLATION INSTRUCTIONS
5) Fasten the overlay panel to the door using the four
M4×25 pan head screws provided. Snug the screws,
but do not ghten (See Fig. 17).
6) Fasten the sheet metal bracket to the boom of the
door with the three T2 screws provided. Tighten the
screws to the door (See Fig. 18).
8) Replace the door gasket in its proper orientaon.
Reinsert the bushings into hinge (C1) and hinge (C2)
(the hinges aached to the door) (See Fig. 20).
Snug the screws,
but do not ghten.
Fig. 17
Sheet Metal Bracket
Screws
Overlay Panel
Door
Fig. 18
7) Tighten the four M4×25 pan head screws installed in
step 5 (See Fig. 19).
Fig. 19
Tighten the screws.
Bushing
Bushing
Gasket
Fig. 20
9) Aach the door to hinge (A), then connue to maintain
a hold on the door. Screw the hinge stop pin into hinge
(B) unl it is ght (See Fig. 21).
10) Insert the 2 canoe clips included in the accessory bag
into the holes on top of the door (See Fig. 22).
Hinge Stop Pin
Hinge (B)
Fig. 21
Canoe Clips
Fig. 22
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
20 | perlick.com/residential
SETUP
SETUP
1) Posion the appliance in the selected permanent
locaon.
2) Level the appliance from side-to-side and front-to-rear
by adjusng the feet.
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 21
ELECTRICAL CONNECTION
Electrical connecon must meet naonal,
state, and local electrical code requirements. Failure to meet
these code requirements could result in death, electric shock,
serious injury, re, or damage.
The appliance requires an independent
power supply of proper capacity. See the nameplate for
electrical specicaons. Failure to use an independent power
supply of proper capacity can result in a tripped breaker,
blown fuse, damage to exisng wiring, or component failure.
This could lead to heat generaon or re.
THE APPLIANCE MUST BE GROUNDED:
The appliance is equipped with a NEMA 5-15 three-prong
grounding plug to reduce the risk of potenal shock hazards.
It must be plugged into a properly grounded, independent
3-prong wall outlet. If the outlet is a 2-prong outlet, it is your
personal responsibility to have a qualied electrician replace
it with a properly grounded, independent 3-prong wall outlet.
Do not remove the ground prong from the power cord and
do not use an adapter plug. Failure to properly ground the
appliance could result in death or serious injury.
Do not use an extension cord.
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands. Make sure
the control switch is in the “OFF” posion before plugging in
or unplugging the appliance.
Do not use an appliance with a damaged
power cord. The power cord should not be altered, jerked,
bundled, weighed down, pinched, or tangled. Such acons
could result in electric shock or re. To unplug the appliance,
be sure to pull the plug, not the cord, and do not jerk the
cord.
The GREEN ground wire in the factory-
installed power cord is connected to the appliance. If it
becomes necessary to remove or replace the power cord, be
sure to connect the power cord’s ground wire to this screw
upon reaachment.
Usually an electrical permit and services of a licensed
electrician are required.
The maximum allowable voltage variaon is ±10 percent of the
nameplate rang.
For oponal drain pump (63802A) installaon, refer to the
instrucons included with the pump.
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
22 | perlick.com/residential
WATER SUPPLY AND DRAIN CONNECTIONS
WATER SUPPLY AND DRAIN CONNECTIONS
Water supply and drain connecons must
be installed in accordance with applicable naonal, state, and
local regulaons.
Normal operang water temperature must be
within 45°F to 90°F (7°C to 32°C). Operaon of the appliance,
for extended periods, outside of this normal temperature range
may aect appliance performance.
Water supply pressure must be a minimum of
7 PSIG and a maximum of 113 PSIG. If the pressure exceeds 113
PSIG, the use of a pressure reducing valve is required.
External lters, strainers, or soeners may be
required depending on water quality. Contact your local Perlick
Cered Service Representave or local Perlick distributor for
recommendaons.
Connect to potable water supply only. Do not
connect to a hot-water supply.
In areas where water damage is a concern,
install in a contained area with a oor drain.
WARNING
DANGER
!
WARNING
WARNING
WARNING
Water line installaon to the appliance is not
warranted by Perlick.
Water-hammer issues must be resolved
by a qualied plumber before installing the appliance. Water
hammer can cause appliance damage that may lead to water
leakage or ooding.
A minimum of 1/2” nominal ID hard pipe
or equivalent is required for the drain line. Installing a smaller
diameter drain line will reduce water ow and may lead to
water leakage or ooding.
If using the oponal drain pump (63802A),
test its operaon every me the appliance is cleaned and
sanized. If the oponal drain pump is not operang properly,
water could back up and overow, leading to costly water
damage.
WARNING
WARNING
WARNING
WARNING
WARNING
Water Supply Inlet Minimum Water Supply Line Size Drain Outlet Minimum Drain Line Size
1/2" Female Pipe Thread (FPT) 1/4" Nominal ID Copper
Water Tubing or Equivalent
1/2" Female Pipe Thread (FPT) 1/2" Nominal ID
Hard Pipe or Equivalent
A plumbing permit and services of a licensed plumber may be
required in some areas.
A water supply line shut-o valve and drain valve must be
installed.
Be sure there is sucient extra water supply line and drain line
for the appliance to be pulled out for service.
Drain line should not be piped directly to the sewer system
An air gap of a minimum of 2 vercal inches (5 cm) must be
between the end of the drain pipe from the appliance and the
oor drain.
For gravity drain installaon, drain must have 1/4” fall per foot
(2 cm per 1 m) on horizontal runs to get good ow. A vented
tee connecon is also required for proper ow. Extend the vent
at least 12” (30 cm) above the drain outlet. For oponal drain
pump installaon, refer to the instrucons included with the
pump.
Fig. 23
Piping to approved drain. Leave a 2-inch (5-cm)
vercal air gap between the end of the pipe and
the drain.
2-inch (5-cm)
air gap
Floor
Drain
Shut-O Valve
Drain Valve
Water Supply Inlet
1/2" FPT
Drain Outlet
1/2" FPT
Vented Tee Connecon
Extend the vent at least 12" (30
cm) above the drain outlet.
Minimum 1/4" Nominal ID Copper Water Tubing or Equivalent
Minimum 1/2" Nominal ID Hard Pipe or
Equivalent
Be sure there is sucient extra water supply line
and drain line for the appliance to be pulled out
for service.
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 23
FINAL CHECKLIST
FINAL CHECKLIST
CHOKING HAZARD: Ensure all components,
fasteners, and thumbscrews are securely in place aer
installaon. Make sure that none have fallen into the
storage bin.
1. Is the appliance level?
2. Is the appliance in a site where the ambient temperature
is within 45°F to 100°F (7°C to 38°C) and the water
temperature within 45°F to 90°F (7°C to 32°C) all year
around?
3. Have the shipping carton, tape, and packing material been
removed from the appliance? Has the protecve plasc
lm been removed from the panels?
4. Have all electrical and water connecons been made? Do
electrical and water connecons meet all naonal, state,
and local code and regulaon requirements?
5. Has the power supply voltage been checked or tested
against the nameplate rang? Is the power supply a
properly grounded, independent 3-prong wall outlet?
DANGER
!
6. Are the water supply and drain lines sized as specied?
Are the water supply line shut-o valve and drain valve
installed? Has the water supply pressure been checked to
ensure a minimum of 7 PSIG and a maximum of 113 PSIG?
7. Are all components, fasteners, and thumbscrews securely
in place?
8. Has the end user been given this instrucon manual,
and instructed on how to operate the appliance and the
importance of the recommended periodic maintenance?
9. Has the end user been given the name and telephone
number of an authorized service agent?
10. Has the warranty tag been lled out and forwarded to the
factory for warranty registraon?
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
24 | perlick.com/residential
Protect the oor when moving the appliance
to prevent damage to the oor.
If using the oponal drain pump (63802A),
test its operaon every me the appliance is cleaned and
sanized. If the oponal drain pump is not operang properly,
water could back up and overow, leading to costly water
damage.
To help ensure the storage bin drain remains
clear, follow the instrucons in Storage Bin Drain once every 3
months or as oen as necessary for condions. If the storage
bin drain becomes clogged, water could build up in the bin and
overow, leading to costly water damage.
If water collects in the bin and will not drain,
turn o the appliance and close the water supply line shut-o
valve. Call for service.
If water seeps from the base of the appliance,
turn o the appliance and close the water supply line shut-o
valve. Call for service. Failure to do so could lead to costly water
damage.
Do not leave the appliance on during
extended periods of non-use, extended absences, or in
sub-freezing temperatures. To properly prepare the appliance
for these occasions, follow the instrucons in Preparing the
Appliance for Periods of Non-Use.
Keep venlaon openings in the appliance
enclosure or in the built-in structure clear of obstrucon.
Do not place objects on top of the appliance.
The storage bin is for ice use only. Do not
store anything else in the storage bin.
If ice is not used on a regular basis, it may bond together in the
storage bin. In this case, discard the bonded ice and allow the
appliance to make fresh ice.
OPERATING INSTRUCTIONS
IMPORTANT NOTES ABOUT USAGE
Only qualied service technicians should
install and service the appliance.
Failure to install, operate, and maintain the
equipment in accordance with this manual will adversely
aect safety, performance, component life, and warranty
coverage.
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands. Make sure
the control switch is in the “OFF” posion before plugging in
or unplugging the appliance.
The appliance must be maintained in
accordance with the instrucon manual and labels provided
with the appliance. Consult with your local Perlick Cered
Service Representave about maintenance service.
The appliance must be cleaned and
sanized at least twice a year. More frequent cleaning and
sanizing may be required in some water condions.
Wash your hands before removing ice. Use
the plasc scoop provided.
Do not place ngers or any other objects
into the ice discharge opening.
The appliance is not intended for use by
persons (including children) with reduced physical, sensory,
or mental capabilies, or lack of experience and knowledge,
unless they have been given supervision or instrucon
concerning use of the appliance by a person responsible for
their safety.
Young children should be properly
supervised around the appliance.
Do not climb, stand, or hang on the
appliance or appliance door or allow children or animals to
do so. Serious injury could occur or the appliance could be
damaged.
Be careful not to pinch ngers when
opening and closing the door. Be careful when opening and
closing the door when children are in the area.
Do not use combusble spray or place
volale or ammable substances near the appliance. They
might catch re.
Keep the area around the appliance clean.
Dirt, dust, or insects in the appliance could cause harm to
individuals or damage to the appliance.
DANGER
!
WARNING
WARNING
WARNING
WARNING
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
WARNING
WARNING
WARNING
WARNING
WARNING
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 25
STARTUP
STARTUP
All parts are factory-adjusted. Improper
adjustments may adversely aect safety, performance,
component life, and warranty coverage.
If the appliance is turned o, wait for at least
3 minutes before restarng the appliance to prevent damage to
the compressor.
At startup, conrm that all internal and
external connecons are free of leaks.
1. Open the water supply line shut-o valve.
2. Make sure the control switch is in the “OFF” posion. Plug
the appliance into the electrical outlet.
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands. If you
have to slide the appliance back for a built-in installaon,
make sure you do not damage or pinch the water supply line,
drain line, or power cord.
3. If required by sanitaon code in your area, seal the
perimeter where the appliance touches the oor with
approved caulk compound in a smooth and easily cleanable
manner.
4. Move the control switch to the “ICE” posion to start the
automac icemaking process.
5. Once the appliance starts to produce ice, allow it to run for
another 30 minutes.
6. Move the control switch to the “OFF” posion.
7. Remove the ice produced, then clean the storage bin liner,
door liner, and door gasket using a neutral cleaner. Rinse
thoroughly aer cleaning.
8. Move the control switch to the “ICE” posion to start the
automac icemaking process.
9. To conrm bin control operaon, hold ice in contact with
the bin control thermostat bulb. If the icemaker does not
stop within 10 seconds, the bin control thermostat must be
adjusted. Installaons at higher altude locaons are more
likely to require adjustment.
DANGER
!
WARNING
WARNING
DANGER
!
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
26 | perlick.com/residential
MAINTENANCE
MAINTENANCE
The appliance must be maintained in accordance with the
instrucon manual and labels provided with the appliance.
Consult with your local Perlick Cered Service Representave
about maintenance service. To obtain the name and phone
number of your local Perlick Cered Service Representave,
visit www.perlick.com.
Only qualied service technicians should
service the appliance.
Failure to install, operate, and maintain the
equipment in accordance with this manual will adversely
aect safety, performance, component life, and warranty
coverage.
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands. Make sure
the control switch is in the “OFF” posion before plugging in
or unplugging the appliance.
Move the control switch to the “OFF”
posion and unplug the appliance from the electrical outlet
before servicing.
CHOKING HAZARD: Ensure all components,
fasteners, and thumbscrews are securely in place aer any
maintenance is done to the appliance. Make sure that none
have fallen into the storage bin.
Do not place ngers or any other objects
into the ice discharge opening.
Aer service, make sure that there are no
wires pinched between the panels and appliance. Make sure
you do not damage or pinch the water supply line, drain line,
or power cord.
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 27
MAINTENANCE
MAINTENANCE SCHEDULE
Frequency Area Task
Weekly Scoop Clean the scoop using a neutral cleaner. Rinse thoroughly aer cleaning.
Monthly
Drain the Appliance Move the control switch to the "DRAIN" posion. Allow the water system to drain for
1 minute. Clear ice away from the thermostac bin control bulb. Move the control
switch to the "ICE" posion. Aer the gear motor starts, move the control switch to
the "DRAIN" posion. Allow the water system to drain for 1 minute. Move the control
switch to the "ICE" posion to start the automac icemaking process.
Appliance Exterior Wipe down with clean, so cloth. Use a damp cloth containing a neutral cleaner to
wipe o oil or dirt build up. Clean any chlorine staining (rust colored spots) using a non-
abrasive cleanser.
Every 3 Months Storage Bin Drain Maintain as outlined in Storage Bin Drain (pg 30)
Every 6 Months Icemaker and
Storage Bin
Clean and sanize per the cleaning and sanizing instrucons provided in this manual.
Evaporator
Condensate Drain
Pan and Gear Motor
Drain Pan
Wipe down with clean cloth and warm water.
Gear Motor
Drain Pan
Evaporator
Condensate
Drain Pan
Oponal Drain Pump
(63802A)
Test as outlined in Oponal Drain Pump 63802A instrucons
External Water Filters Check for proper pressure and change if necessary.
Yearly Water Supply Inlet Close the water supply line shut-o valve and drain the water system. Clean the water
supply inlet screen.
Condenser Inspect. Clean if necessary.
Water Hoses Inspect the water hoses and clean/replace if necessary.
Upper Bearing
(extruding head)
Check for wear using .02" round stock or pin gauge. Replace both upper bearing and
lower bearing if wear exceeds factory recommendaons.
Aer 3 Years,
then Yearly
Upper Bearing
(extruding head);
Lower Bearing
and O-Ring (lower
housing); Mechanical
Seal; Evaporator
Cylinder; Auger
Inspect. Replace both upper bearing and lower bearing if wear exceeds factory
recommendaons. Replace the mechanical seal if the seal's contact surfaces are worn,
cracked, or scratched.
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
28 | perlick.com/residential
MAINTENANCE
CLEANING AND SANITIZING INSTRUCTIONS
The appliance must be cleaned and sanized at least twice a
year. More frequent cleaning and sanizing may be required
in some condions.
To prevent injury to individuals and damage
to the appliance, do not use ammonia type cleaners.
Carefully follow any instrucons provided
with the cleaning and sanizing soluons.
Always wear liquid-proof gloves and goggles
to prevent the cleaning and sanizing soluons from coming
into contact with skin or eyes.
DANGER
!
DANGER
!
DANGER
!
Do not use ice made from the cleaning and
sanizing soluons. Aer cleaning and sanizing, be careful
not to leave any soluon in the appliance.
Do not place ngers or any other objects
into the ice discharge opening (extruding head).
DANGER
!
DANGER
!
1. Cleaning Soluon
Dilute 1.6 . oz. (47 ml or 3.2 tbs) of Nu-Calgon “Liquid Ice
Machine Cleaner” with 1 qt (1 l) of warm water. This is a
minimum amount. Make more soluon if necessary.
For safety and maximum eecveness, use
the soluon immediately aer diluon.
2. Cleaning Procedure
1) Move the control switch to the “OFF” posion.
2) Remove all ice from the storage bin.
3) Move the control switch to the “DRAIN” posion.
4) Allow the water system to drain for 1 minute.
5) Move the control switch to the “OFF” posion.
6) Using a clean funnel and hose (not included),
pour 1 qt (1 l) of cleaning soluon over the extruding
head (See Fig. 24.) Allow the appliance to sit for
10 minutes before operaon.
7) Make sure at least 10 minutes have elapsed since you
poured the cleaning soluon over the extruding head,
then move the control switch to the “ICE” posion.
8) Allow the appliance to make ice for 20 minutes, then
move the control switch to the “DRAIN” posion.
9) Allow the water system to drain for 1 minute.
10) Move the control switch to the “ICE” posion.
11) Aer the gear motor starts, move the control switch
to the “DRAIN” posion.
12) Allow the water system to drain for 1 minute.
13) Move the control switch to the “OFF” posion. In
severe water condions, repeat the cleaning
procedure.
Fig. 24
Slope
Scoop Holder
Extruding Head
Funnel and Hose
(not included)
CAUTION
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 29
MAINTENANCE
CLEANING AND SANITIZING INSTRUCTIONS (cont.)
3. Sanizing Soluon
Dilute 1.25 . oz. (37 ml or 2.5 tbs) of a 5.25% sodium
hypochlorite soluon (chlorine bleach) with 2.5 gallons
(9.5 l) of warm water. This is a minimum amount. Make
more soluon if necessary. Using a chlorine test strip or
other method, conrm that you have a concentraon
of about 200 ppm.
For safety and maximum eecveness, use
the soluon immediately aer diluon.
4. Sanizing Procedure - Inial
1) Using a clean funnel and hose, pour 1 qt (1 l) of
sanizing soluon over the extruding head. Allow the
appliance to sit for 10 minutes before operaon.
2) Remove the slope from the storage bin by carefully
bending it in the center and releasing it from the
2 slope shas.
3) Remove the scoop. Remove the 2 thumbscrews
securing the scoop holder, then remove it.
4) Pour some of the sanizing soluon into a separate,
clean container. Using this sanizing soluon and a
clean cloth, wipe down the slope, scoop, scoop
holder, inside of the spout, and bin liner.
5) Rinse the parts and areas sanized in step 4
thoroughly with clean water.
6) Replace all removed parts in their original and
correct posions.
CHOKING HAZARD: Ensure all components,
fasteners, and thumbscrews are securely in place. Make sure
that none have fallen into the storage bin.
7) Make sure at least 10 minutes have elapsed since you
poured the sanizing soluon over the extruding
head, then move the control switch to the “ICE”
posion.
8) Allow the appliance to make ice for 20 minutes, then
move the control switch to the “DRAIN” posion.
9) Allow the water system to drain for 1 minute.
10) Move the control switch to the “ICE” posion.
11) Aer the gear motor starts, move the control switch
to the “DRAIN” posion.
12) Allow the water system to drain for 1 minute.
13) Move the control switch to the “OFF” posion.
5. Sanizing Procedure - Final
1) Using a clean funnel and hose, pour 1 qt (1 l) of
sanizing soluon over the extruding head. Allow the
appliance to sit for 10 minutes before operaon.
2) Move the control switch to the “ICE” posion.
3) Allow the appliance to make ice for 20 minutes, then
move the control switch to the “DRAIN” posion.
4) Allow the water system to drain for 1 minute.
5) Move the control switch to the “ICE” posion.
6) Aer the gear motor starts, move the control switch
to the “DRAIN” posion.
7) Allow the water system to drain for 1 minute.
8) Move the control switch to the “ICE” posion and
allow the appliance to run. Check for leaks.
9) Aer 30 minutes, move the control switch to the
“OFF” posion.
10) Pour warm water into the storage bin to melt all of the
ice, then clean the storage bin liner, door liner, and
door gasket with a neutral cleaner. Rinse thoroughly
aer cleaning.
11) Move the control switch to the “ICE” posion to start
the automac icemaking process.
DANGER
!
CAUTION
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
30 | perlick.com/residential
MAINTENANCE
STORAGE BIN DRAIN
In some condions, slime may build up inside the storage bin
drain and prevent water from draining properly. To prevent this
buildup, perform the following procedure once every 3 months
or as oen as necessary for condions.
If the storage bin drain becomes clogged,
water could build up in the bin and overow, leading to costly
water damage.
1) Move the control switch to the “OFF” posion
To reduce the risk of electric shock, do not
touch the control switch with damp hands.
2) Remove all ice from the storage bin.
3) Mix a batch of sanizing soluon by dilung
1.25 .oz. (37 ml or 2.5 tbs) of a 5.25% sodium
hypochlorite soluon (chlorine bleach) with
2.5 gallons (9.5 l) of warm water. Using a chlorine test
strip or other method, conrm that you have a
concentraon of about 200 ppm.
For safety and maximum eecveness, use
the soluon immediately aer diluon.
4) Slowly pour the sanizing soluon into the
storage bin.
5) Aer all of the soluon has drained, clean the storage
bin liner with a neutral cleaner. Rinse thoroughly with
clean water.
6) Move the control switch to the “ICE” posion to start
the automac icemaking process.
CONDENSER
Check the condenser once a year, and clean if required by
following the steps below. More frequent cleaning may be
required depending on locaon.
Condenser ns are sharp. Use care when
cleaning.
1) Move the control switch to the “OFF” posion, then
unplug the appliance from the electrical outlet
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands.
2) Remove the screws securing the front panel, then
remove it (See Fig. 25).
3) Remove the screws securing the louver, then
remove it.
4) Use a brush aachment on a vacuum cleaner to gently
clean the condenser ns. Do not use too much force,
otherwise the ns could be damaged.
5) Replace the louver and front panel in their correct
posions. Ensure that the screws are securely in place.
6) Plug the appliance back in. Move the control switch to
the “ICE” posion to start the automac ice making
process.
DANGER
!
Front Panel
Louver
Fig. 25
Screws
Screws
Condenser
DANGER
!
DANGER
!
CAUTION
WARNING
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 31
MAINTENANCE
OPTIONAL DRAIN PUMP
If the oponal drain pump (63802A) is installed, test its
operaon at least twice a year as outlined below. Note that the
pump has power even when the control switch is in the “OFF”
posion.
If the oponal drain pump is not operang
properly, it will adversely aect performance, component life,
and warranty coverage and may result in costly water damage.
1) Move the control switch to the “OFF” posion, then
unplug the appliance from the electrical outlet
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands.
2) Remove all ice from the storage bin.
3) Plug the appliance back in.
4) Slowly pour 24 to 30 oz. (710 to 890 ml) of water over
the storage bin drain hole in the storage bin.
5) If water pumps out properly and the drain pump
then de-energizes, proceed to step 6. If water does
not pump out properly and/or the drain pump does
not de-energize, the appliance must be serviced by a
qualied service technician before proceeding.
6) Move the control switch to the “ICE” posion.
7) Pour another 24 to 30 oz. (710 to 890 ml) of water
into the appliance’s ice storage bin, then completely
restrict the discharge hose while the drain pump is
operang (See Fig. 26). Pour more water into the
appliance’s ice storage bin unl the appliance turns
o. The drain pump will connue to operate. Check
for leaks.
8) Remove the discharge hose restricon and allow the
water to be pumped out normally. Power to the
appliance will be restored when the water in the drain
pump returns to a normal level.
9) If the appliance fails to turn o with the discharge
hose restricted or the pump fails to pump out the
water, the appliance must be serviced by a qualied
service technician.
WARNING
DANGER
!
Fig. 26
Discharge Hose
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
32 | perlick.com/residential
PREPARING THE APPLIANCE FOR PERIODS OF NON-USE
PREPARING THE APPLIANCE FOR PERIODS
OF NON-USE
During extended periods of non-use, extended absences, or in
sub-freezing temperatures, follow the instrucons below. When
the appliance is not used for two or three days under normal
condions, it is sucient to move the control switch to the
“OFF” posion.
Only qualied service technicians should
service the appliance.
During extended periods of non-use,
extended absences, or in sub-freezing temperatures, follow the
instrucons below to reduce the risk of costly water damage.
1) Move the control switch to the “OFF” posion.
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands.
2) Close the water supply line shut-o valve, then open
the water supply line drain valve. See Fig. 23.
3) Allow the line to drain by gravity.
4) Move the control switch to the “DRAIN” posion.
5) Allow the water system to drain for 1 minute.
6) Aach a compressed air or carbon dioxide supply to
the water supply line drain valve.
7) Move the control switch to the “ICE” posion.
8) Blow the water supply line out using the compressed
air or carbon dioxide supply.
9) Close the water supply line drain valve.
10) Move the control switch to the “OFF” posion, then
unplug the appliance from the electrical outlet.
11) Remove the screws securing the upper rear panel,
then remove it (See Fig. 27).
DANGER
!
WARNING
DANGER
!
12) Remove the clamp securing the reservoir outlet hose
to the reservoir. Disconnect the reservoir outlet hose
from the reservoir.
13) Aach a compressed air or carbon dioxide supply to
the reservoir outlet hose.
14) Plug the appliance back in, then move the control
switch to the “DRAIN” posion.
15) Blow out the reservoir outlet hose using the
compressed air or carbon dioxide supply.
16) Move the control switch to the “OFF” posion, then
unplug the appliance from the electrical outlet.
17) Reconnect the reservoir outlet hose to the reservoir,
then secure with the clamp. Make sure all hoses are
connected and secure.
18) Replace the rear panel in its correct posion.
19) Clean the storage bin by using a neutral cleaner. Rinse
thoroughly aer cleaning.
Fig. 27
Upper Rear Panel
Clamp
Reservoir
Outlet
Hose
Reservoir
Overow Hose
PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 33
DISPOSAL
DISPOSAL
The appliance contains refrigerant and must be disposed of in
accordance with applicable naonal, state, and local codes and
regulaons. Refrigerant must be recovered by properly cered
service personnel.
8300 West Good Hope Road, Milwaukee, WI 53223, USA
perlick.com/residenal • (800) 558-5592
Perlick Residential is a division of Perlick Corporation
© 2018 Perlick Corporation
FORM NO. Z2547
REV. A-05/01/2018
1A5237-01
