HEAVY-DUTY SACK TRUCK WITH PU TYRES
300KG CAPACITY
MODEL NO: CST990HD
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Always load evenly with the centre of gravity of the load as near the centre and
rear of the plate as possible.
9 Obtain additional support for large or wide loads to prevent tipping.
8 DO NOT overload the truck - see Specication.
8 DO NOT leave unattended, especially when loaded, unless the wheels are
chocked or the truck is otherwise secured.
8 DO NOT use truck on uneven ground and do not run over curbs or steps - use a
ramp.
8 DO NOT allow others to ride on the truck.
8 DO NOT use the truck if any part is damaged, paying particular attention to the
wheels.
2. INTRODUCTION
Heavy-duty tubular steel construction with welded joints with 300kg capacity.
Puncture proof heavy-duty PU tyres with powder coated steel hubs. Features
foldaway toe plate for added extension when transporting larger loads.
3. SPECIFICATION
Model No:......................................................CST990HD
Capacity: ............................................................... 300kg
Height(s): .......................................................... 1220mm
Overall Width: ..................................................... 580mm
Platform Depth Fixed: ......................................... 300mm
Platform Depth Folding: ...................................... 600mm
Wheel Bore Size: ............................................... Ø20mm
Wheel Size: ...................................................... Ø250mm
Wheel Width: .........................................................85mm
4. ASSEMBLY
4.1. Wheels. Ensure each axle is clean from dust and dirt to allow free movement of
the wheel. You will need to slide the axle through the frame bushes first.
4.2. Slide the wheel (fig.2.2) onto the axle (fig.2.1), followed by the washer (fig.2.3)
and complete by pushing the split pin (fig.2.4) through the hole in the end of the
axle and bending over to retain.
4.3. Repeat for the other side.
g.1
g.2
CST990HD Issue 2 (3) 24/08/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear safety
footwear
CST990HD Issue 2 (3) 24/08/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please
email or call our technical team on technical@sealey.co.uk or 01284 757505.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 36 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
