Ø45MM BRAKE PRESSURE BLEEDER CAP 90°
CONNECTOR WITH HOSE
MODEL NO: VS0204C4
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
VS0204C4 Issue:1 08/09/22
Original Language Version
© Jack Sealey Limited
Wear eye
protection
Wear protective
gloves
1. SAFETY
IMPORTANT! These instructions are provided as a guide only. Always refer to the vehicle manufacturer’s service instructions.
9 It is recommended to perform a leak test to ensure if the adaptor is tightly and securely connected on the reservoir.
9 Keep this product in good working order and condition, take immediate action to repair or replace damaged parts.
9 Use approved parts only. Unapproved parts may be dangerous and will invalidate the warranty.
9 Keep children and unauthorised persons away from the work area.
9 Keep work area clean and tidy and free from unrelated materials.
9 Ensure the work area has adequate lighting.
8 DO NOT use the kit to perform a task for which it is not designed.
8 DO NOT allow untrained persons to use the kit.
8 DO NOT use when tired or under the inuence of drugs, alcohol or intoxicating medication.
9 After use, clean equipment and store in a cool, dry, childproof area.
9 Dispose of waste liquids in accordance with local authority regulations.
9 Always read and comply with the warnings on the brake uid container.
9 Wear eye protection and keep skin contact to a minimum. If brake uid enters eyes rinse with plenty of water and seek medical
advice. If swallowed seek medical advice immediately.
WARNING! Only use new Brake Fluid, used Brake Fluid or other uids will contaminate the system and possible brake system
failure may result.
WARNING! DO NOT pollute the environment by allowing uncontrolled discharge of uids.
WARNING! Brake uid is ammable - keep away from sources of ignition, including hot surfaces e.g. exhaust manifold.
WARNING! Brake uid will damage paintwork. Any spillage should be ushed with water immediately.
2. INTRODUCTION
Ø45mm Brake and clutch reservoir bleed cap (2001-2022). 90° Connector with hose for use where access is restricted Manufactured
from aluminium, this adaptor is suitable for pressure bleeding work that requires 1-2bar/14-30psi pressure range. Heavy-duty adaptor
covers most vehicles. Compatible with Sealey brake bleeders VS0204, VS0204A, VS0207, VS820, VS821.
3. CONTENTS
CAP4 European, Ford & Nissan
Model No.: .....................................................VS0204C4
VS0204C4 Issue:1 08/09/22
Original Language Version
© Jack Sealey Limited
4. APPLICATIONS
MAKE MODELS YEAR TYPE No.
Alfa Romeo All models All years 4
Audi All models All years 4
BMW All models All years 4
Buick Cascada 2016-2019 1.6L 4
Buick LaCrosse 2010-2016 2.4L, 3.0L, 3.6L 4
Buick Regal 2011-2017 2.0L, 2.4L 4
Buick Verano 2012-2017 2.0L, 2.4L 4
Chevrolet Cruze 2011-2015 1.4L, 1.8L, 2.0L Diesel 4
Chevrolet Cruze Limited 2016-2016 1.4L, 1.8L 4
Chevrolet Malibu 2013-2016 1.8L, 2.0L, 2.4L, 2.5L 4
Chevrolet Malibu Limited 2016-2016 2.5L 4
Citroen All models All years 4
Fiat All models All years 4
Ford C-Max 2013-2018 2.0L 4
Ford Escape 2013-2016 1.5, 1.6L, 2.0L, 2.5L 4
Ford Focus 2012-2018 1.0L, 2.0L, 2.3L 4
Ford Fusion 2013-2014 4
Ford Transit Connect 2014-2020 1.6L, 2.0L, 2.5L 4
Ford Transit-150 2015-2019 3.2L Diesel, 3.5L, 3.7L 4
Ford Transit-250 2015-2019 3.2L Diesel, 3.5L, 3.7L 4
Ford Transit-350 2015-2019 3.2L Diesel, 3.5L, 3.7L 4
Ford Transit-350 HD 2015-2019 3.2L Diesel, 3.5L, 3.7L 4
Jaguar All models All years 4
Land Rover All models All years 4
Mazda CX-7 2007-2012 2.3L, 2.5L 4
Mazda Mazda3 2004-2013 2.0L, 2.3L, 2.5L 4
Mazda Mazda5 2006-2010 2.3L 4
Mazda Mazda5 2012-2015 2.5L 4
Mazda MX-5 Miata 2006-2015 2.0L 4
Mercedes-Benz All models All years 4
Mini All models All years 4
Nissan Europe-made models All years 4
Opel All models All years 4
Peugeot All models All years 4
Renault Almost all models All years 4
Volvo Almost all models All years 4
VW All models All years 4
5. OPERATION
5.1. Remove the master cylinder reservoir cap.
5.2. Pull out the old brake uid as much as possible.
5.3. Fit the adaptor and connect to the reservoir.
5.4. Connect the pressure bleeding tool or machine to the adaptor (g.1).
5.5. Follow the instructions as specied by the pressure bleeding tool or machine manufacturer.
5.6. It is recommended to perform a leak test to ensure if the adaptor is tightly and securely connected on the reservoir.
5.7. Remove the master cylinder reservoir cap (g.2)
5.8. Screw on the adaptor cap.(g.3)
5.9. You are now ready to commence with bleeding the brakes.
6. MAINTENANCE
6.1. Ensure that the unit is de-pressurized before carrying out any maintenance and drain all fluids from the fluid supply tube.
6.2. Clean up any spilled brake fluid and wipe down with a clean cloth.
6.3. Store in a clean, dry and childproof location.
fig.1
fig.2
fig.3
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
