Sealey CST985 Stair Climbing Sack Truck Solid Tyres 150kg User Manual

150KG STAIR CLIMBING SACK TRUCK

WITH SOLID TYRES

MODEL NO: CST985.V3

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

9 Always load evenly with the centre of gravity of the load as low as possible.

9 Use additional support for large or wide loads to prevent movement.

9 When used on steps or stairs ensure that the load is well within your capability to lift and control.

9 Make multiple trips rather than exceed your lifting capabilities.

8 DO NOT overload the truck - maximum capacity 150kg.

8 DO NOT allow others to ride on the truck.

8 DO NOT use the truck if any part is damaged.

2. INTRODUCTION

Tubular steel construction gives 150kg maximum load capacity. Deep foot ensures cartons stay on trolley during transit. Fitted with

 solidrubberwheels.Handledesignallowsarmgripwhilstascendinganddescendingstairways.Idealfordeliverydriversand 

couriers.

3. SPECIFICATION

Model No: ..........................................................CST985

Capacity: ............................................................... 150kg

Height(s): .......................................................... 1300mm

Overall Width: ..................................................... 510mm

Platform Depth: ...................................................230mm

Wheel Size: ...................................................... Ø165mm

Wheel Width: .........................................................30mm

4. ASSEMBLY

NOTE: Numbers/Letters in brackets refer to the parts in (Fig 1.)

4.1. Slide axle (C) through tubes (A).

4.2. Fit wheel assembly (1) to each end of axle and retain with plain

washers and nuts (2).

4.3. Slide handle (D) over tubes (B) and retain with bolts, plain washers

and nuts (2).

CST985.V3Issue3(H,2,3,F)12/06/23

Original Language Version

Refer to

instructions

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 sales@sealey.co.uk www.sealey.co.uk

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutpriornotice.

Pleasenotethatotherversionsofthisproductareavailable.Ifyourequiredocumentationforalternativeversions,pleaseemailorcallourtechnicalteam

on technical@sealey.co.uk or 01284 757505.

Important: No Liability is accepted for incorrect use of this product.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

g.1

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,

taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product

becomescompletelyunserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersand

dispose of the product and fluids according to local regulations.
