Package Contents
1 x Mini Ultrasonic Cool Mist Humidifier
1 x USB Cable
3 x Cotton Bars (1 Pre-Installed)
1 x User Manual
Specifications
Power Supply DC 5V
Rated Power 2.6W
Water Tank
Capacity
1½ US cups / 350 mL
Max Run
Time
Up to 6 hours of continuous use
Up to 17 hours of intermittent use
Note: The humidifier may run
for a longer or shorter time
depending on the environmental
temperature and humidity.
Automatic
Shuto
4 hours
Noise Level ≤ 20dB
Mist Output Continuous Mist Mode: 40 mL/h
Humidifier
Dimensions
Diameter: 2.7 in / 6.8 cm
Height: 6.2 in / 15.7 cm
Cotton Bar
Dimensions
Diameter: 0.3 in / 0.8 cm
Height: 5.1 in / 13 cm
Weight 0.33 lb / 150 g
GETTING TO KNOW
YOUR HUMIDIFIER
READ AND
SAVE THESE
INSTRUCTIONS
SAFETY
INFORMATION
• Only use the humidifier as described in this
manual.
• Place the humidifier and cord so that it will
not be knocked over. Do not place near large
pieces of furniture or in high-trac areas.
• When not in use, turn the humidifier o and
disconnect from power by removing the plug
from the USB port.
• Do not use the humidifier in wet environments.
• Keep the humidifier out of reach from children.
• Always unplug your humidifier from the power
outlet before cleaning your humidifier or
detaching the water tank cover.
• Always make sure to place the humidifier on a
flat, level surface or in a car cup holder before
operation.
• Only fill the water tank with clean water.
Never fill the water tank with any other liquids.
• Do not add essential oil into the water tank or
onto the transducer.
• Do not place the humidifier near sources of
heat, such as stovetops, ovens, or radiators.
To reduce the risk of fire, electric shock, or other
injury, follow all instructions and safety guidelines.
General Safety
Caution: Risk of Leaks & Electric
Shock
Plug & Cord
• Do not place the humidifier directly on floors,
carpets, or rugs.
• Do not use other items as replacement parts
for this product.
• Do not cover the transducer while the
humidifier is on. Doing so may damage the
humidifier.
• Do not immerse the water tank cover, USB
cable, or plug in water.
• If the humidifier is damaged or is not
functioning properly, stop using it and contact
Customer Support immediately.
• Not for commercial use. Household use only.
• Do not add essential oils, supplemental water
treatment liquids, or water filters into the water
tank or onto the transducer. This will damage
the humidifier and cause leaks.
• Ensure that the plug fits properly into a USB
port.
• Do not handle the USB cable or plug with wet
hands. Keep the plug and USB cable away
from liquids.
A. Transducer
B. Power Button
C. Lock / Unlock
Indicators
D. Water Tank Window
E. Micro USB Port
F. Cotton Bar Cover
G. Max Water Line
H. Cotton Bar
I. Cotton Bar Cover Cap
J. USB Connector
K. Micro USB Connector
A
J
Back
Front
B
K
C
D
F
G
H
I
E
GETTING STARTED FILLING & REFILLING
1. Remove all packaging.
2. Clean the humidifier. (See Care & Maintenance)
3. Choose a hard, flat location for the humidifier.
The surface must be water-resistant. [Figure 1.1]
4. If you are using the humidifier in a car, make sure
the humidifier stands up correctly and does not
tip over at any time.
5. Mist should be kept away from walls, furniture,
bedding, and appliances.
1. Turn the water tank cover counterclockwise to
unlock, then lift up to remove. [Figure 2.1]
2. Fill the water tank with room-temperature
purified or distilled water. Do not fill with hot
water.
CAUTION:
• Do not fill past the max water line.
• Do not add essential oils into the humidifier.
• Do not use water treatment liquids or third-
party water filters in this humidifier.
3. Replace the water tank cover, turning it
clockwise until the arrow aligns with .
[Figure 2.2]
USING YOUR
HUMIDIFIER
1. Connect the USB cable to the humidifier and
plug it into a USB port.
Note: Do not reverse the micro USB. Ensure
the cable is correctly inserted into the port.
The cable can be plugged in to any USB port,
including a car charger (not included).
Note: Alternatively, while the humidifier is o,
press and hold the Power button to turn on the
humidifier in Intermittent Mist Mode.
Note: You can also turn the humidifier o at any
time by pressing and holding the Power button
for 2 seconds.
2. Press the Power button once to turn on the
humidifier in Continuous Mist Mode.
CARE &
MAINTENANCE
You should clean your humidifier every 3 days, and
when you’re ready to store it.
Descaling removes any mineral deposits that may
have built up inside the humidifier. Always descale
the humidifier before and after storing for long
periods of time.
1. Unplug the humidifier and pour out all the water.
2. Clean the transducer and water tank interior
using distilled vinegar.
3. If the humidifier has thick scale buildup, scrub
with a non-scratch scrub sponge.
4. Wipe o any remaining scale with a non-abrasive
cloth, sponge, or cleaning brush.
Note:
• All maintenance should be done on a water-
resistant surface, such as a kitchen counter.
• Change the water daily to avoid bacteria
growth.
• Use a cotton swab to clean the transducer
regularly.
• If not using the humidifier for 1 week or longer,
do not leave water inside. Clean and dry the
humidifier instead.
Note:
• Never immerse the water tank cover in
water or liquid. Do not place any part of the
humidifier in a dishwasher.
• Do not use detergents to clean the
humidifier.
Cleaning
Descaling
1. Unplug the humidifier.
2. Remove the water tank cover by turning it
counterclockwise.
3. Clean the transducer with a cotton swab
moistened with room temperature water.
[Figure 3.1]
4. Wipe the interior and exterior of the water tank
with a soft cloth.
5. Dry all parts with a cloth. Make sure all parts are
completely dry before reassembling or storing.
Figure 1.1
Figure 2.1 Figure 2.2
Figure 3.1
3. Press the Power button a second time to turn on
the LED light with color rotation.
4. While the humidifier rotates through colors,
press the Power button to lock a color.
Repeatedly press the Power button to
continue cycling through colors and functions.
Cycle Order Function
1 Turn on the mist
2 Turn on the light with color rotation
3 White
4 Purple
5 Royal Purple
Cycle Order Function
6 Blue
7 Aqua
8 Green
9 Yellow
10 Turn o the humidifier
