Purification method:
Using H13 HEPA + activated carbon filter, it can
filter most of the particulate pollutants in the air,
such as PM2.5,dust particles,dander,pollen,
cigarette smoke and peculiar smell.
Filter reset:
Effective for 3-6 months.(Different standards for different environments)
The power indicator flashes to remind you to replace the filter;
After replacing the filter press the power button seven seconds;
The air purifier will beep three times when the reset is completed.
(1) Humidity resistance
Place the product in an environment with a temperature of 65°C and a humidity
of 65°C (RH),move to a normal indoor environment after 24 hours,and naturally
dried, There is no abnormal appearance such as obvious deformation.
(3) Cold resistance
Placing the product at a temperature of -25 ℃ freezer,move to a normal indoor
environment after 24 hours,there is no abnormal appearance such as obvious
deformation.
(2) Heat resistance
Place the product in a desiccator at a temperature of 65°C,move to a normal indoor
environment after 24 hours,allow it to cool naturally, and there is no abnormal
appearance such as obvious deformation.
Product performance test:
Storage requirements:
This product should be stored at normal temperature, pressure, relative
humidity 20%-95%, avoiding direct sunlight, prevent moisture to keep
indoor natural ventilation.
The product should prevent deformation under heavy pressure.
双面4页
尺寸：180*120mm
H13 HEPA Filter
Compatible With HY3800 Air Purifier
*Notes for use:
(1) No washing
(2) Avoid falling and
collision during operation
PA filter layer
H13 compound high
efficiency HEPA
Activated carbon filter
Metal net
Sealing strip
6.18±0.008inch
（157±0.2mm）
1.08±0.008inch
(27.4±0.2mm)
8.27±0.02inch
(210±0.5mm)
Power must be cut off when replacing the filter
ORIGINAL
(
Green)
3.High-Grade Activated
Carbon Filter
With the high-grade carbon particles to
effectively analyze and chemically
decompose odors and harmful gases in
the air, purify the dust, lint, fibers, hair,
and pet fur.
Suitable for all the
indoor environments.
PET ALLERGY
(Blue)
3.Ammonia Removal
Activated Carbon Filter
With the advanced carbon particle filter
for ammonia removal, which can effectively
remove the pet odors and trap the pet fur,
hair.
Suitable for most indoor
environments especially
with pets.
TOXIN ABSORBER
(
Purple)
3.Toxin Absorber
Activated Carbon Filter
Adopting a method for removing formaldehyde,
toluene, ammonia,acetaldehyde, acetaldehyde,
acidic formula. High-grade granular carbon can
do chemical decomposition and absorb harmful
gases more effectively.
Suitable for the indoor
environments especially
with more toxic and
harmful gases, smoke,
smog, and volatile organic
compounds(VOCs).
As a pre-filter for the HEPA filter, it traps small airborne particles like dust, preserving the
surface area of the HEPA filter.
H13 HEPA filters over 99% of particles down to 0.1 microns such as pollen, pet dander,
dust, and tobacco smoke.
1. Pre-filter
2. H13 HEPA Filter
Customer Service: [email protected]
USER MANUAL
