INSTRUCTION MANUAL
LED BULKHEAD
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
TECHNICAL DATA
MODEL VT-8096
SKU 10198, 10199, 10200
POWER 18W
LUMENS 1820 Lm
INPUT POWER AC: 220-240V, 50/60Hz
BEAM ANGLE 110°
CRI ≥80
DF ≥0.7
LIFE SPAN 25,000 Hours
ON/OFF CYCLE >15,000
OPERATING TEMPERATURE -20°C to +40°C
DIMENSION 195x38mm
*This product contains a light source of energy eciency class<F>, where <F> shall be replaced by the
energy class of the contained light source.
