P/N A23057901 210927
B. Ice Maker (x1) C. Ice Bucket (x1)
E. Shoulder Screws (x2) F. Screw (x1)
Cobra FRZ IM Numbers:
• CD: IMKFD23A
• SD: IMKFD28A
AUTOMATIC ICE MAKER
INSTALLATION INSTRUCTIONS
An authorized service technician is recommended to install the Ice Maker Kit.
Tools Needed:
• Phillips Screwdriver
• Flat-head Screwdriver
• ¼-inch Socket Wrench or Nut Driver
• Adjustable Wrench
Kit Components
