Instruction Manual
Item: 12096
Model: 32510091
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
© 2023 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH022-071823
Printed In China
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 years from the original date of purchase against workmanship and defects in
material. If under normal use, your product fails to operate, please contact our customer service department at
info@getholmesfans.com. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc. may
\]fq[dYaekg^\YeY_][Ymk]\Zqeakmk]gjeg\aÚ[Ylagfkg^l`akhjg\m[l&
Warranty Service
Contact our customer service at www.getholmesfans.com/en/contact-us
or info@getholmesfans.com or 1-866-769-3166 (8:30 am - 5:00 pm EST) Monday-Friday.
Our team will be happy to assist.
www.getholmesfans.com
CLEANING / MAINTENANCE
FAN CLEANING
• Always unplug the fan before cleaning.
• Do not allow water to drip on or into fan housing.
• Use only a soft cloth moistened with a mild soap
solution.
• Do not use harsh chemicals such as gasoline, thinner
or benzene as a cleaner.
FAN BLADE CLEANING
1. Always unplug the fan before cleaning
2. Remove the front grill by taking off the grill screw
and nut (W) located on the bottom of the grill.
3. Clean the fan blade, front and rear grills with a soft
cloth moistened with a mild soap solution.
4. Securely fasten the front grill to the rear grill by
replacing the grill screw and nut (W). Tighten with
screw driver. (Use Philips head screw driver).
FAN HEAD, BASE AND POLE CLEANING
Using a soft, moist cloth (with or without a mild soap
solution), carefully clean the fan base, pole and head.
Use CAUTION around the housing area. Do not allow the
motor or other electrical components to be exposed to
water.
FAN STORAGE
This fan can be stored either partially disassembled or
assembled.
• Store the fan in a clean, dry location between
seasons or when not in use for an extended period
of time.
• Keep the fan protected from dirt and dust during
storage.
For inquiries regarding recycling and proper
disposal of this product, please contact your local
waste management facility.
16 Inch
Outdoor Misting Fan
USER SERVICING INSTRUCTIONS
Follow these instructions to safely and correctly care for
this fan.
REPLACEABLE FUSE
If the (5 Amp, 125 Volt) replaceable fuse blows, please
visit our website at www.getholmesfans.com
for information on how to order a new fuse. Follow the
below instructions to replace the fuse on the plug.
1. Unplug your fan. Grasp plug and remove from the
receptacle or other outlet device. Do not unplug by
pulling on cord.
2. Locate the fuse holder on the power cord. Use
screwdriver to remove the fuse cover and take out
the O-ring (see Figure 4).
Note: Ensure that fuse
cover is completely open
before attempting to
remove fuse.
3. Remove fuse carefully by
using a small screwdriver
to pry the fuse out of
the compartment by the
metal ends of the fuse
(see Figure 4).
4. Place Fuse Box on a solid
ÛYlkmj^Y[]&Afk]jlf]o-
Amp, 125 Volt fuse into fuse compartment and use
a small screwdriver to secure the metal ends of the
fuse into the compartment.
;Ymlagf2Jakcg^Új]&J]hdY[]^mk]gfdqoal`-9eh$
125 Volt fuse.
5. Replace the O-ring, close the fuse cover in place
and secure with the 2 screws (see Figure 4). If fuse
[gn]jak\a^Ú[mdllg[dgk]$eYc]kmj]^mk]akk][mj]\
in place completely by pressing down on metal ends
of the fuse.
CAUTION: Risk of Fire. Do not remove or replace
the Fuse Box. It contains a safety device (fuse).
Discard product if the fuse box is damaged.
