Yardworks LSS020-1 20-Volt Lithium-ion 2-in-1 Shear User Manual

BATTERY MUST BE

CHARGED BEFORE FIRST

USE. TWO TO THREE INITIAL

CHARGING/DISCHARGING

CYCLES MAY BE REQUIRED

TO ACHIEVE MAXIMUM RUN

TIME/CAPACITY.

CA Compliant Charger Included (Model No. CHL82000-1)

Thank you for your purchase.

DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING, ASSEMBLY,

PARTS, SERVICE QUESTIONS? GO TO WWW.AMERICANLAWNMOWER.COM

OR CALL 1-800-633-1501 BETWEEN 8:00 AM—5:00 PM EST FOR

ASSISTANCE.

SAVE THIS MANUAL FOR FUTURE REFERENCE

WARNING: To reduce the risk of injury, the user must read and understand the owner’s manual

before using this product.

Model LSS020-1 | SKU# 267-3225

OWNER’S MANUAL

20-Volt Lithium-ion 2-in-1 Shear Shrubber

With (1) 20-Volt 2.0Ah Lithium-ion Battery

TO REDUCE RISK OF INJURY: Before any use be sure

everyone using this product reads and understands all

safety instructions and other information contained in this

manual.

WARNING: Personal Injury and Damage! Keep your

hands and feet away from the cutting tool, especially

when the products are switched on! Never adjust the

cutting head when the product is in the “on” position. Do

not touch moving blades.

Save these instructions and review frequently prior to

use and in instructing others.

WARNING: When using electric appliances, basic safety

precautions should always be followed to reduce risk of

fire, electric shock, and personal injury, including the

following:

READ ALL INSTRUCTIONS

IMPORTANT SAFETY WARNINGS

2

Model LSS020-1

GENERAL POWER TOOL SAFETY WARNINGS

WARNING: Read all safety warnings and instructions.

Failure to follow the warnings and instructions may result in

electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your

mains-operated (corded) power tool or battery-operated

(cordless) power tool.

Work area safety

• Keep work area clean and well lit. Cluttered or dark

areas invite accidents.

• Do not operate power tools in explosive

atmospheres, such as in the presence of flammable

liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

• Keep children and bystanders away while operating

a power tool. Distractions can cause you to lose

control.

Electrical safety

• Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any adapter

plugs with earthed (grounded) power tools.

Unmodified plugs and matching outlets will reduce risk

of electric shock.

• Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and

refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded.

• Do not expose power tools to rain or wet conditions.

Water entering a power tool will increase the risk of

electric shock.

• Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool. Keep

cord away from heat, oil, sharp edges or moving

parts. Damaged or entangled cords increase the risk of

electric shock.

• When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of a

cord suitable for outdoor use reduces the risk of electric

shock.

• If operating a power tool in a damp location is

unavoidable, use a ground fault circuit interrupter

(GFCI) protected supply. Use of a GFCI reduces the

risk of electric shock.

Personal safety

• Stay alert, watch what you are doing and use

common sense when operating a power tool. Do not

use a power tool while you are tired or under the

influence of drugs, alcohol or medication. A moment

of inattention while operating power tools may result in

serious personal injury.

• Use personal protective equipment. Always wear eye

protection. Protective equipment such as dust mask,

non-skid safety shoes, hard hat, or hearing protection

used for appropriate conditions will reduce personal

injuries.

• Prevent unintentional starting. Ensure the switch is

in the off-position before connecting to power source

and/or battery pack, picking up or carrying the tool.

Carrying power tools with your finger on the switch or

energizing power tools that have the switch on invites

accidents.

• Remove any adjusting key or wrench before turning

the power tool on. A wrench or a key left attached to a

rotating part of the power tool may result in personal

injury.

• Do not overreach. Keep proper footing and balance

at all times. This enables better control of the power tool

in unexpected situations.

• Dress properly. Do not wear loose clothing or

jewelry. Keep your hair, clothing and gloves away

from moving parts. Loose clothes, jewelry or long hair

can be caught in moving parts.

• If devices are provided for the connection of dust

extraction and collection facilities, ensure these are

connected and properly used. Use of dust collection

can reduce dust-related hazards.

Power tool use and care

• Do not force the power tool. Use the correct power

tool for your application. The correct power tool will do

the job better and safer at the rate for which it was

designed.

• Do not use the power tool if the switch does not turn

it on and off. Any power tool that cannot be controlled

with the switch is dangerous and must be repaired.

GENERAL POWER TOOL SAFETY WARNINGS

• Disconnect the plug from the power source and/or the

battery pack from the power tool before making any

adjustments, changing accessories, or storing power

tools. Such preventive safety measures reduce the risk of

starting the power tool accidentally.

• Store idle power tools out of the reach of children and

do not allow persons unfamiliar with the power tool or

these instructions to operate the power tool. Power

tools are dangerous in the hands of untrained users.

• Maintain power tools. Check for misalignment or

binding of moving parts, breakage of parts and any

other condition that may affect the power tool’s

operation. If damaged, have the power tool repaired

before use. Many accidents are caused by poorly

maintained power tools.

• Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges are less

likely to bind and are easier to control.

• Use the power tool, accessories and tool bits etc. in

accordance with these instructions, taking into

account the working conditions and the work to be

performed. Use of the power tool for operations different

from those intended could result in a hazardous situation.

Battery tool use and care

• Recharge only with the charger specified by the

manufacturer. A charger that is suitable for one type of

battery pack may create a risk of fire when used with

another battery pack.

• Use power tools only with specifically designated

battery packs. Use of any other battery packs may

create a risk of injury and fire.

• When battery pack is not in use, keep it away from

other metal objects, like paper clips, coins, keys,

nails, screws or other small metal objects, that can

make a connection from one terminal to another.

Shorting the battery terminals together may cause burns

or a fire.

• Under abusive conditions, liquid may be ejected from

the battery; avoid contact. If contact accidentally

occurs, flush with water. If liquid contacts eyes, seek

medical help. Liquid ejected from the battery may cause

irritation or burns

Service

• Have your power tool serviced by a qualified repair

person using only identical replacement parts. This

will ensure that the safety of the power tool is

maintained.

• When servicing a power tool, use only identical

replacement parts. Follow instructions in the

Maintenance section of this manual. Use of

unauthorized parts or failure to follow Maintenance

instructions may create a risk of shock or injury.

HEDGE TRIMMER SAFETY WARNINGS

• DANGER – Keep hands away from blade. Contact with

blade will result in serious personal injury.

• Use both hands when operating the hedge trimmer.

Using one hand could cause loss of control and

result in serious personal injury.

• Keep all parts of the body away from the cutter blade.

Do not remove cut material or hold material to be cut

when blades are moving. Make sure the switch is off

when clearing jammed material. Blades coast after

turn off. A moment of inattention while operating the

hedge trimmer may result in serious personal injury.

• Carry the hedge trimmer by the handle with the cutter

blade stopped. Proper handling of the hedge trimmer

will reduce possible personal injury from the cutter

blades.

• Hold the power tool by insulated gripping surfaces

only, because the cutter blade may contact hidden

wiring. Cutter blades contacting a “live” wire may make

exposed metal parts of the power tool “live” and could

give the operator an electric shock.

• Keep cable away from cutting area. During operation

the cable may be hidden in shrubs and can be

accidentally cut by the blade.

WARNING – Only use with handle and guard properly

assembled to hedge trimmer. The use of the hedge trimmer

without the proper guard or handle provided may result in

serious personal injury.

WARNING: DO NOT USE ON A LADDER OR UNSTABLE

SUPPORT. Stable footing on a solid surface enables better

control of the power tool in unexpected situations.

CAUTION: Use only with Yardworks 20V batteries

.

WARNING: California Proposition 65: This product

contains chemicals known to the State of California to

cause cancer, birth defect or other reproductive harm.

WARNING: Some dust and debris created by the use of

this tool could contain chemicals known to the State of

California to cause cancer and birth defects or other

reproductive harm. Some examples of these chemicals

are:

 Chemicals in fertilizers

 Compounds in insecticides, herbicides and

pesticides

 Arsenic and chromium from chemically treated

lumber

Your risk from exposure to these chemicals varies,

depending on how often you do this type of work. To reduce

your exposure, work in a well-ventilated area and with

approved safety equipment, such as dust masks that are

specially designed to filter out microscopic particles.

WARNING: Cancer and Reproductive Harm -

www.P65Warnings.ca.gov.

3

Model LSS020-1

Precautions that involve your safety.

CAUTION! Read the instruction manual and follow the warning and safety instructions!

CAUTION! Always wear eye protection.

Do not use in rain or electrical storms. Store in a dry location.

WARNING! Wear protective gloves!

WARNING! Keep bystanders away.

CAUTION! Wear ear protection!

WARNING! Wear safety footwear!

DANGER! The cutter blades continue to run after the motor is switched off. Wait for the blades to come to

a standstill. Risk of injury!

DANGER! Keep hands away from the moving blade.

Waste electrical products should not be disposed of with household waste. Please recycle

where facilities exist. Check with your Local Authority or retailer for recycling advice.

EXPLANATION OF SYMBOLS

Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper

interpretation of these symbols will allow you to operate the product better and safer.

GENERAL SAFETY

FCC Warnings:

Please note that changes or modifications to this

product not expressly approved by the party

responsible for compliance could void the user's

authority to operate the equipment.

NOTE: This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation. This

equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will

not occur in a particular installation. If this equipment

does cause harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to

correct the interference by one or more of the

following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and

receiver.

-- Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

-- Consult the dealer or an experienced radio/TV

technician for help.

4

Model LSS020-1

PRODUCT SPECIFICATIONS

Model: LSS020-1

Input: 20 V DC, 2.0 Ah -Lithium-ion battery

Battery capacity: 2000mAH -4 inch (100mm) grass shear blade width

No load speed: 1200 RPM -8 inch (203mm) shrub trimming blade cutting length

Charger input: 100-240V, 50/60Hz AC -1/4 inch (7mm) shrub trimming blade max. cutting diameter

Battery charging time: 1-2 hours -Tool-less blade changing system

PARTS LIST

1 Grass cutter blade 6 Blade guard for grass cutter

2 Blade release mechanism 7 Battery mount

3 Safety lock-off 8 Blade guard for shrub cutter

4 On / Off switch 9 Rechargeable battery

5 Shrub trimming blade 10 Battery charger

5

Model LSS020-1

1

2

3

4

5

8

6

9

10

7

GENERAL INSTRUCTIONS

PACKING LIST

- Shear with Grass Cutter Blade Assembled

- Shrub Trimming Blade

- Blade Guards

- Rechargeable Battery

- Battery Charger

- Owner’s Manual

UNPACKING

Carefully remove the product from the box. Make sure that

all items listed in the packing list are included.

Inspect all items carefully to make sure no breakage or

damage occurred during shipping.

Do not discard the packing material until you have

carefully inspected and satisfactorily operated the tool.

WARNING: If any parts are damaged or missing please

do not operate this product until the parts are replaced.

Failure to heed this warning could result in serious

personal injury. Call our customer service help line at

1-800-633-1501 for assistance.

ASSEMBLY:

Since the equipment is supplied as grass shear, the

grass cutting blade has to be swapped over for the shrub

trimming blade which is supplied with the product.

Caution! Carry out all the following assembly, dismantling

and adjustment work without a rechargeable battery – risk

of injury.

Always use protective gloves and fit the blade guard

before changing the cutting mechanism.

1.Push the blade release buttons (Fig. 1) on both sides

and remove the blade at the same time. (Fig. 2).

2.Slide the blade housing into the mount on the equipment

housing.

3.Push the blade release buttons on both sides again

(Fig.3) and press the blade into the mount at the same

time. The drive unit on the equipment is now connected to

the blade.

4.Push the battery into the battery mount provided until

you hear the catch click into position. (Fig. 4)

STARTING AND STOPPING

Starting:

1. Remove the blade guard, then push the safety lock

button and press the on/off trigger switch at the

same time.

2. Release the safety lock button.

Stopping:

1. Release the on/off trigger switch. After switching off

wait until the blade is stationary.

2. Mount blade guard.

OPERATING INSTRUCTIONS

This product is intended for light trimming of shrubs,

hedges and lawn edges. Please note that this tool is not

designed for commercial, trade, or industrial use. Only

use this product for the purpose specified in these

instructions. Any other use will void the warranty.

GRASS CUTTER BLADE

Use the grass cutter blade for cutting the edges of lawns

and small areas of grass in private gardens and hobby

areas.

The grass cutter blade is not intended for cutting hedges

of chopping material up for composting.

Edging

Guide the tool along the edge of the lawn.

After use, install the blade guard.

Tips:

− Do not force the unit through dense growth, and if the

blades slow down, reduce your speed.

− Avoid trimming too close to dirt, sand or gravel, as this

could dull the blades and reduce the cutting efficien-

cy.

− Do not allow the blade to contact paved surfaces,

stones or garden walls, as this will rapidly wear down

the blade.

SHRUB TRIMMING BLADE

Use the shrub trimming blade for trimming and shaping

individual bushes, shrubs, and climbing plants in private

domestic and hobby gardens.

The shrub trimming blade is not intended for cutting

grass / edging.

Cutting shrubs

 Before using, check the shrubs for foreign objects

e.g. wire, etc.

 When using the tool hold it away from yourself and

stand in a secure position with your weight evenly

balanced on both feet.

 When cutting, move steadily along the line of cut, so

that stems are fed directly into the cutter blades.

 After use, install the blade guard.

6

Model LSS020-1

Fig.1

Fig.2

Fig.3

Fig.4

Click

7

Model LSS020-1

MAINTENANCE / CLEANING / STORAGE

MAINTENANCE:

CAUTION: Blades can cause injury. Do not press

the safety lock of the shear during maintenance

work.

Note: To ensure long and reliable service, regularly

carry out the following maintenance:

 Check for obvious defects such as a damaged

or loose blade, housing, or components.

 If the tool should stop working properly, repair

should be carried out by a qualified individual,

using identical replacement parts.

CAUTION: Never clean the trimming shears in

water (especially running water), as there is a risk

of personal injury and damage to the shears.

To obtain good cutting results, always make sure

the blades are sharp, and clean them from time to

time with a soft dry cloth.

For easier operation and longer blade life, use light

machine oil to lubricate the trimming and grass

shear blades before and after each use.

Check the condition of the cutting edges of the

blades, and always immediately remove notches

and burrs caused by stones, etc.

There are no parts inside the equipment which

require additional maintenance.

CLEANING / STORAGE

Danger! Remove the rechargeable battery before

cleaning!

 To clean the tool, make sure the battery is

detached from the unit.

 Clean the exterior of the tool thoroughly

using a soft brush and cloth. Do not use water,

solvents, or polishes.

 Remove all debris from the tool.

 After cleaning, cover the blades with the

guards provided.

 Fully recharge the battery before storing.

 If the tool is to be stored for an extended period

of time or during winter storage, charge the

battery at least once every there months to

protect it from damage.

 Store the tool in a dry secure place out of reach

of children.

 Do not place any other objects on top of the

tool.

 The ideal storage temperature is between 5

and 30 °C. Store the tool in its original

packaging.

 Do not store the tool in places with static

electricity.

Troubleshooting

Problem

- Unit does not run

Possible Cause

- Battery not making contact

- Lock off is not fully activated

- Battery not installed properly

- Battery not charged

Possible Solution

- Check battery is fully inserted

- Check that lock off is fully activated before moving trigger

- Check that battery is securely connected to the blower

- Check battery charging requirements

- Battery will not charge

- Battery not inserted into charger

- Charger not plugged in

- Surrounding air temperature too hot

or too cold

- Insert battery into charger until red LED appears

- Plug charger into a working outlet

- Check current at receptacle by plugging in a lamp or

other appliance

- Check to see if receptacle is connected to a light switch

which turns power off when you turn out the lights

- Move charger and tool to a surrounding air temperature

of above 39 degree F (4 degree C) or below 104 degree

F (40 degree C)

CHARGING THE BATTERY PACK

Charge the battery pack only with the charger provided.

Allow at least 60 minutes of charge time before initial use

of the blower.

Make sure the power supply is normal household voltage,

120volts, 60Hz, AC only.

The battery charger should be operated in temperatures

between 39 and 104 degrees F

The battery should be charged in a cool, dry place.

2 to 3 initial charging/discharging cycles may be

required to achieve maximum run time/capacity.

DO NOT attempt to open the charger or the unit. There

are no customer serviceable parts inside. Call customer

service helpline at 1-800-633-1501 for assistance.

DO NOT incinerate battery packs even if they are

severely damaged or completely worn out. They can

explode in a fire causing injury.

DO NOT charge appliance in rain, or in wet locations.

Use the battery charger indoors only.

Disconnect charger from the power supply when not in

use to prevent damage to the charger during a power

surge.

When fully charged, the battery can be safely stored in

temperatures down to -4 degrees F for a period of up to

four weeks, before requiring charging. Fully charge battery

pack every 90 days.

If over a period of time the battery pack quickly runs down

after a full 60 minutes charging period, a replacement

battery pack is needed.

To prevent permanent damage to the battery, never store

in a discharged condition.

WINTER STORAGE - Fully recharge before storage and

then again every 90 days.

Since the battery will not develop a memory, it does not

have to be fully discharged before recharging.

A small leakage of liquid from the battery cells may occur

under extreme usage, charging or temperature

conditions. This does not indicate a failure. However, if the

outer seal is broken and this leakage gets on your skin.

a. Wash quickly with soap and water.

b. Neutralize with a mild acid such as lemon juice of

vinegar.

c. If the battery liquid gets in your eyes, flush them with

clean water for a minimum of 10 minutes and seek

immediate medical attention.

TO CHARGE - SEE CHARGER MANUAL FOR COMPLETE INSTRUCTIONS

BATTERY DISPOSAL

Remove the battery pack from the shrub shear, cover the terminals with heavy duty adhesive tape. Do not

attempt to destroy or disassemble battery pack or remove any components. This product contains lithium-ion

batteries which must be recycled or disposed of properly. Local, state or federal laws may prohibit disposal of

these batteries in the municipal solid waste or rural trash pick up systems.

The RBRC seal on the Li-Ion battery pack indicates that the cost to recycle the battery pack at the end

of its useful life has already been paid by The Great States Corporation/American Lawn Mower

Company. It is illegal to place spent Li-Ion batteries in the local municipal solid waste or in the trash.

RBRC in cooperation with The Great States Corporation/American Lawn Mower Company has

provided an environmentally friendly and easy way to recycle spent Li-Ion batteries. Just contact your

local recycling center or call 1.800.8.BATTERY for information on where to drop off the spent battery.

Constant Red = Battery is charging

Constant Green = Battery is fully charged

Battery Pack

Charger

8

Model LSS020-1

CALL US FIRST !!

Call us first with questions about operating or maintaining your product

at 1.800.633.1501 between 8:00 a.m. – 5:00 p.m. Eastern

Standard Time, or get assistance on americanlawnmower.com.

PARTS AND SERVICE

Always mention the model number when ordering kits/items for this tool.

No. Kit/Item Number Description QTY

1 LSS020-GRASS Grass shear blade assembly kit 1

2 LSS020-SHRUB Shrub shear blade assembly kit 1

3 BL82120-1 20V battery 1

4 CHL82000-1 Charger 1

For parts or service, please call 1-800-633-1501 or visit us online at americanlawnmower.com.

Be sure to provide all relevant information when you call or visit.

REPAIR PARTS (KITS/ ITEMS)

The model/ serial number of this tool is found on a plate or label attached to the housing. Please

record the serial number in the space provided below.

MODEL NUMBER LSS020-1 _

SERIAL NUMBER_______________

9

Model LSS020-1

NOTES

__________________________________________________________________

10

Model LSS020-1

NOTES

__________________________________________________________________

11

Model LSS020-1

American Lawn Mower Company

The Great States Corporation

7444 Shadeland Station Way

Indianapolis, IN 46256 USA

Phone 1-800-633-1501

www.americanlawnmower.com

In a continued commitment to improve quality, the Manufacturer reserves the right to

make component changes or design changes when necessary.

Rev. 10/14/2021

YARDWORKS WARRANTY POLICY

• Two (2) year limited warranty on all Yardworks 20V lithium ion power tools from date of purchase when used for personal,

household, or family use.

• Two (2) year limited warranty on all Yardworks 20V lithium ion batteries and chargers from date of purchase when used for

personal, household, or family use.

The Great States Corp. (GSC) warrants to the original owner that this Yardworks product and service part is free from defects in

materials and workmanship and agrees to repair or replace any defective product or part for the warranty period as stated above.

• Warranty voided if used for commercial or industrial purposes or any other improper use as determined by GSC.

• Warranty does not include repairs necessary due to operator’s abuse or negligence (including overloading the product beyond

capacity or immersion in water), or the failure to assemble, operate, maintain or store the product according to the instructions in

the owner’s manual.

• This warranty does not cover

 Wear items, including but not limited to - drive belts & gears, tines, cutting blades, mower blades, saw chains, mulching

blades, blower fans, spool covers, trimmer line, blower and vacuum tubes, guide bars, high pressure hoses, wheels, handles,

augers, worn bags, power cables, and other items subject to wear over time.

 Wear on batteries, including but not limited to – drops, wear and breakage on charger, exposure to extreme temperature

swings (hot or cold), battery left on charger too long, battery left uncharged for too long, and misuse or abuse of the battery.

• This warranty does not cover damage caused by cold, heat, rain, excessive humidity or other environmental extremes.

• This warranty does not cover normal deterioration of the exterior finish or normal wear and tear on the products including, but not

limited to scratches, cracks, dents, or damage caused by outside chemicals.

• This warranty is not transferable and only applies to new products sold directly from an authorized retailer. This warranty does not

apply to any product, new or used, purchased through unauthorized third-party channels. For information on authorized dealers,

contact our customer support hotline at 1-800-633-1501 (Mon-Fri 8am-5pm Est)

• Any incidental, indirect or consequential loss, damage, or expense that may result from any defect or malfunction of the products is

not covered by the warranty.

• The warranty does not include installation, assembly or normal adjustments explained in the owner’s manual. The expense of de-

livering the product to the vendor and the expense of returning the product or replacement parts to the owner is not covered by the

warranty.

Additional Warranty Limitations

Some states do not allow the exclusion or limitation on how long an implied warranty lasts, so the above limitation may not apply to

you. Products sold damaged or incomplete, sold ―as is, or sold as reconditioned are not covered under the warranty.

Damage or liability caused by shipping, improper handling, improper assembly, incorrect voltage, improper wiring, improper mainte-

nance, improper modification or the use of accessories and/or attachments not specifically recommended is not covered by this

warranty.

Proof of purchase, original dated sales receipt, must accompany all warranty claims.

For claims go to americanlawnmower.com or call our customer support hotline from 8am-5pm EST,

Mon-Fri at 1-800-633-1501

Model LSS020-1 | SKU# 267-3225

OWNER’S MANUAL

20-Volt Lithium-ion Shear Shrubber

With (1) 20-Volt 2.0Ah Lithium-ion Battery

Yardworks LSS020-1 20-Volt Lithium-ion 2-in-1 Shear Shrubber With (1) 20-Volt 2.0Ah Lithium-ion Battery

Product's Documents

OWNER’S MANUAL

Specifications

Yardworks LSS020-1 Questions and Answers
