Quick Installation Guide
Thank you for purchasing ProHT Projection Screen
Before Installation:
1. Check the package for the following items included:
Screen Case manual type: Screen Case Electric type (with in-line control):
Drywall Anchor/Screw (4 sets); Leveling (1 pc); Remote Control w/accessory (if Electric Type)
2. Prepare some tools such as: screwdriver, pencil, hammer, and drill (option), stud finder (option).
Installation (For Drywall)
Step 1: Install one drywall anchor and screw (leave ¼” out) at a proper area on the wall.
Step 2: Hook on one end of the screen case. Hold another end to the same level and make the mark (using leveling)
Step 3: Install the second anchor and screw. Hook on the other end of the case and install the rest anchors with screws for
more secure.
For wood or concrete surface, you may need stud finder and drill.
You can also hang the screen on a ceiling by using 2 chains (not included), and 2 hooks (not included) directly connecting to the
two upper side holes.
Operation:
Pull down the screen from the rope or the handle only in 90-degree angle. DO NOT attempt to pull down the screen by the
screen surface or touch the screen, as it will damage the screen and void the warranty. An internal auto-lock system will cause
the screen to stop and lock on the position in 2 intervals. If you want the screen to retract back, simply pull down the screen
more than 2 inches and quickly, smoothly releasing it up gently. Always release in a 90-degree angle.
