Dual 150 Ultrasonic Cool Mist Humidifier
Product Series: Dual 150
Model: LUH-D302-WUS
Questions or Concerns?
Please contact us MonFri, 9:00 am5:00 pm PST/PDT
at [email protected] or at 888 7268520.
USER MANUAL
SAFETY INFORMATION
• Only use the humidifier as
described in this manual.
• Place the humidifier and cord so
that it will not be knocked over.
Do not place near large pieces of
furniture or in high-trac areas.
• When not in use, turn the humidifier
o and disconnect from power by
removing the plug from the outlet.
• Do not use the humidifier in wet
environments.
• Keep the humidifier out of reach
from children.
• Do not open the base or remove
the water level sensor for self-
servicing.
• Always unplug your humidifier from
the power outlet before cleaning
your humidifier or detaching the
water tank from the humidifier base.
• Always make sure to place the
humidifier on a flat, level surface
before operation.
• Only fill the water tank with clean
water. Never fill the water tank with
any other liquids.
• Do not place the humidifier near
sources of heat, such as stovetops,
ovens, or radiators.
• Do not place the humidifier directly
on floors, carpets, or rugs.
To reduce the risk of fire, electric shock, or other injury, follow all instructions
and safety guidelines.
General Safety
• Do not use other items as
replacement parts for this product.
• Do not cover the nozzle while
the humidifier is on. Doing so may
damage the humidifier.
• Remove the water tank from the
base before moving the humidifier.
• Do not immerse the humidifier
base, power cord, or plug in water.
If the humidifier is damaged or is
not functioning properly, stop using
it and contact Customer Support
immediately (see page 10).
• This humidifier is not to be used
by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible
for their safety.
• Supervise children when they are
near the humidifier.
• Children should not clean or
perform maintenance on the
humidifier without supervision.
• Children should be supervised to
ensure that they do not play with
the humidifier.
• Household use only. Not for
commercial use.
READ AND SAVE THESE
INSTRUCTIONS
Power & Cord
• Ensure that the plug fits properly into
a polarized socket.
• Do not handle the power cord or
plug with wet hands. Keep the plug
and power cord away from liquids.
• Your humidifier has a polarized plug
(one prong is wider than the other),
which fits into a polarized outlet only
one way. This is a safety feature to
reduce the risk of electric shock. If
the plug does not fit, reverse the
plug. If it still does not fit, do not
use the plug in that outlet. Do not
bypass this safety feature.
• If the power supply cord is damaged,
it must be replaced by Arovast
Corporation or similarly qualified
persons in order to avoid an electric
or fire hazard. Please contact
Customer Support (page 10).
SAFETY INFORMATION (CONT.)
Do not add supplemental
water treatment liquids into the
water tank or base chamber.
This will damage the humidifier
and cause leaks.
Caution: Risk of Leaks
and Electric Shock
1 × Ultrasonic Cool Mist Humidifier
2 × Water Filter Sponges (1 Pre-Installed)
1 × Cleaning Brush
1 × User Manual
Specifications
Package Contents
Power Supply AC 120V, 60Hz
Rated Power 25W
Water Tank
Capacity
0.79 gal / 3 L
Max Run Time
Up to 25 hours on
minimum mist setting
Note: The humidifier may
run for a longer or shorter
time depending on the
environmental temperature
and humidity.
Noise Level ＜ 28dB
Eective
Range
107290 ft / 1027 m
Dimensions
7.2 × 8.1 × 11.6 in /
18.3 × 20.6 × 29.4 cm
Weight 3 lb / 1.38 kg
GETTING TO KNOW YOUR HUMIDIFIER
A. Nozzle
B. Water Tank Cover
C. Water Filter Housing
D. Water Filter
E. Mist Tube
F. Water Tank
G. Float
H. Refill Indicator Light
I. Control Knob
J. Base
K. Cleaning Brush
L. Power Cord
M. Max Water Line (Tank)
N. Water Outlet Valve
O. Noise Silencer
P. Air Outlet
Q. Max Water Line (Base)
R. Float Brackets
S. Transducer
T. Secondary Float
U. Feet
V. Air Inlet
CONTROLS
Control Knob
• Rotate clockwise to turn on the
humidifier and to adjust the mist level.
• Rotate counterclockwise to turn o
the humidifier.
Refill Indicator Light
• The red light turns on when the water
tank is empty. Refill the water tank (see
page 5).
• The red light turns o when the water
tank is filled.
Note:
There is a clicking sound when
the humidifier turns on/o.
2 3 4 5
A
B
N
G
H
L
K
U
T
S
D
O
M
F
E
C
J
I
P
Q
R
V
Water tank, upside down
GETTING STARTED
1. Remove all packaging.
2. Take the water tank o of the base and
remove all tape. Figure 1.1
3. Rinse and reassemble all parts before first use
(see Cleaning, page 6).
Figure 1.3
Figure 1.1
Figure 1.4
Figure 1.5
Figure 1.2
Note:
• Check to make sure that the water filter
is correctly in place. If not, then rotate
the filter clockwise to secure it in place.
Figure 1.2
4. Choose a hard, flat location for the humidifier
at least 12 inches / 30 cm away from any
walls. The surface must be water-resistant.
Figure 1.4
5. Mist should be directed away from walls,
furniture, bedding, and appliances. Figure 1.5
• Check to make sure that the float is
securely in place. Figure 1.3
12 in /
30 cm
12 in /
30 cm
Filling & Refilling
1. Turn the humidifier o.
2. Remove the water tank cover by holding the
nozzle and pulling upward. Figure 1.6
3. Fill the tank with room-temperature water.
Figure 1.7
Figure 1.6 Figure 1.7
4. Replace the water
tank cover.
Note:
• We recommend using purified or distilled water
to fill the tank.
• Do not fill past the tank’s max water line.
• Do not fill with hot water.
Figure 1.8 Figure 1.9
• Do not add water directly into the base
chamber. Figure 1.8
• Do not add water through the mist tube.
Figure 1.9
CAUTION
Note:
Make sure the water tank is clean before filling.
Figure 1.10
Note:
Make sure the
nozzle on the water tank
cover is placed over
the mist tube, or the
humidifier may not work
correctly. Figure 1.10
