MICROWAVE OVEN
Read these instructions carefully before using your
microwave oven, and keep it carefully. If you follow
the instructions, your oven will provide you with
many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
Model:
(rev. 05/ 28/ 21 M D)
FM12SSG
Farberware is a registered trademark of Farberware Licensing Company, LLC
Manufactured and sold pursuant to a license from Farberware Licensing Company, LLC
© Farberware Licensing Company, LLC. All rights reserved.
2021
Tables of Contents
PRECAUTIONS....................………………………………………….……….. 4
SPECIFICATIONS……………………………………………………..…........… 4
SAFETY………………………………………………………………………..…. 7
GROUNDING………………………………………………………….……..... 6
UTENSILS………………………................................................................... 8
SETTING UP YOUR OVEN……………...................................................... 10
CONTROL PANEL………………………………......................................... 12
OPERATION……………………………….................................................. 13
MAINTENANCE……………………………………………………………….. 19
WARRANTY INFORMATION.……………………………………………….. 20
3
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a)
result in harmful exposure to microwave energy.
It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allows soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the:
(1) DOOR (bent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACES
(d) Theovenshouldnotbeadjustedorrepairedbyanyoneexceptproperlyqualied
service personnel
SPECIFICATIONS
Model:
FM12SSG
Rated Voltage: 120V~60Hz
Rated Input Power(Microwave): 1550W
Rated Output Power(Microwave):
1100W
Oven Capacity: 1.2 cubic feet
Turntable Diameter:
12.4 inches
External Dimensions:
Net Weight: Approx 34.8 LBbs
4
Rated Output Power(Grill):
1150W
20.5x17.1x12.8 inches
WARNING:
This product can expose you to chemicals
including Phthalates or other chemicals which are know to
the State of California to cause cancer birth defects and
other reproductive harm.
For more information, visit www.P65Warnings.ca.gov
n
,
2. Readandfollowthespecic:“PRECAUTIONSTOAVOIDPOSSIBLEEXPOSURETO
EXCESSIVEMICROWAVEENERGY”foundonpage4.
3. This appliance must be grounded. Connect only to properly grounded outlet. See
“GROUNDINGINSTRUCTIONS”foundonpage .6
4. Install or locate this appliance only in accordance with the provided installation
instructions.
5. Some products such as whole eggs and sealed containers - for example, closed glass
jars - are able to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in the manual. Do not
usecorrosivechemicalsorvaporsinthisappliance.Thistypeofovenisspecically
designed to heat, cook or dry food. It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when used by children.
8. Do not operate this appliance if it has a damaged cord or plug, if it is not working
properly, or if it has been damaged or dropped.
9. Thisapplianceshouldbeservicedonlybyqualiedservicepersonnel.Contact
nearest authorized service facility for examination, repair, or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this product near water - for
example, near a kitchen sink, in a wet basement, near a swimming pool, or similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes together on closing the door,
use only mild, nonabrasive soaps, or detergent applied with a sponge or soft cloth.
16. Toreducetheriskofreintheovencavity:
1). Do not overcook food. Carefully attend appliance when paper, plastic, or
other combustible materials are placed inside the oven to facilitate cooking.
2). Remove wire twist-ties from paper or plastic bag before placing bag in oven.
3). If material inside of the oven ignite, keep oven door closed, turn oven off, and
disconnect the power cord, or shut off power at the fuse or circuit breaker panel.
4). Do not use the cavity for storage purposes. Do not leave paper products,
cooking utensils, or food in the cavity when not in use.
5
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including
the following:
WARNING – Toreducetheriskofburns,electricshock,re,injurytopersonsorexposure
to excessive microwave energy:
1. Read all instructions before using the appliance.
To reduce the risk of injury to persons:
1) Do not overheat the liquid.
2) Stir the liquid both before and halfway through heating it.
3) Do not use straight-sided containers with narrow necks.
4) After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
5) Use extreme care when inserting a spoon or other utensil into the container.
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces
the risk of electric shock by providing an escape wire for the electric current. This appliance is
equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged
into an outlet that is properly installed and grounded.
WARNING – Improper use of the grounding can result in a risk of electric shock.
Consultaqualiedelectricianorservicemanifthegroundinginstructionsarenotcompletely
understood, or if doubt exists as to whether the appliance is properly grounded. If it is necessary
to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounded plug,
and 3-slot receptacle that will accept the plug on the appliance. The marked rating of the
extension cord shall be equal to or greater than the electrical rating of the appliance.
DANGER – Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death. Do not
disassemble this appliance.
WARNING – Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an outlet until
appliance is properly installed and grounded.
1. A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised
in their use.
6
17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling
point without appearing to be boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present.
THISCOULDRESUL
TINVERYHOTLIQUIDSUDDENLYBOILINGOVERWHENTHE
CONTAINERISDISTURBEDORAUTENSILISINSERTEDINTOTHELIQUID.
3. If a long cord or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at
least as great as the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord.
3) The longer cord should be arranged so that it will not drape over the counter
top or tabletop where it can be pulled on by children or tripped over unintentionally.
RADIO INTERFERENCE
1. Operation of the microwave oven may cause interference to your radio, TV or
similar equipment.
2. When there is interference, it may be reduced or eliminated by taking the
following measures:
1) Clean door and sealing surface of the oven
2) Reorient the receiving antenna of radio or television.
3) Relocate the microwave oven with respect to the receiver.
4) Move the microwave oven away from the receiver.
5) Plug the microwave oven into a different outlet so that microwave oven and
receiver are on different branch circuits.
SAFETY
1. The oven must be on a leveled surface.
2. The turntable and turntable roller rest must be in the oven during cooking. Place the
cookware gently on the turntable and handle it carefully to avoid possible breakage.
3. Incorrect use of browning dish may cause the turntable to break.
4. UseonlythespeciedbagsizewhenusingDirectAccessPopcorn.
5. The oven has several built-in safety switches to ensure that the power remains off when
the door is open. Do not tamper with these switches.
6. Do not operate the microwave oven empty. Operating the oven with no food or food that
isextremelylowinmoisturecancausere,charringorsparking.
7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable
may cause the turntable to break.
8. Do not heat baby bottles or baby food in the microwave oven. Uneven heating
may occur and could cause physical injury.
7
9. Do not heat narrow-necked containers, such as syrup bottles.
10. Do not attempt to deep-fry in your microwave oven.
11. Do not attempt home canning in this microwave oven, as it is impossible to be sure
all contents of the jar have reached boiling temperature.
12. Do not use this microwave oven for commercial purpose. This microwave oven is made
for household use only.
13. To prevent delayed eruptive boiling of hot liquids and beverages or scalding yourself, stir
liquid before placing the container in the oven and again halfway through cooking time. Let
stand in the oven for a short time and stir again before removing the container.
14. Use carefully when cooking food in the microwave oven to avoid burning due to
excessive cooking.
15. When the appliance is operated in the combination mode, children should only use the
oven under adult supervision due to the temperatures generated.
16. Failure to maintain the oven in a clean condition could lead to deterioration that could
adversely affect the life of the appliance and possibly result in a hazardous situation.
UTENSILS
!
CAUTION – Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches
should be pierced before cooking.
Seetheinstructionson“Materialsyoucanuseinmicrowaveovenortobeavoidedin
microwaveoven.”
There may be certain non-metallic utensils that are not safe to use for microwaving. If in
doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
8
MATERIALS YOU CAN USE IN MICROWAVE OVEN
Utensils Remarks
Browningdish Follow manufacturer* instructions. The bottom of browning dish must
be at least 3/16 inch (5mm) above the turntable. Incorrect usage may
cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use
cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass
jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer* instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Paper plates and cups Use for short term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic
Microwave-safe only. Follow the manufacturer* instructions. Should
belabeled“MicrowaveSafe”.Someplasticcontainerssoften,asthe
foodinsidegetshot.“Boilingbags”andtightlyclosedplasticbags
should be slit, pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
9
Grill Rack
Consumer must place on a resistant glass turntable or other heat resistant
cookware which can afford the high temperature form the heating
elements on the top. DO NOT USE METAL.
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal
trim may cause arcing.
Metal twist ties Maycausearcingandcouldcauseareintheoven.
Paper bags Maycauseareintheoven.
Plastic foam Plastic foam may melt or contaminate the liquid inside
when exposed to high temperature.
Wood Wood will dry out when used in the microwave oven
and may split or crack.
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity. Your oven comes with the
following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
F
G
CB
E
D
A) Control panel
B) Turntableshaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
10
H) Grill Rack
H
A
Turntable Installation
Counter-top Installation
Hub (underside)
Glass tray
Tu
rntable ring assembly
Turntable shaft
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Bothglasstrayandturntableringassembly
must always be used during cooking.
c. All food and containers of food are always
placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Cabinet:Removeanyprotectivelmfound
on the microwave oven cabinet surface. Do
not remove the light brown Mica cover that
is attached to the oven cavity to protect the
magnetron.
1. Select a level surface that provide enough
open space for the intake and/or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is
required between the oven and any adjacent
walls. One side must be open.
(1) Leave a minimum clearance of 12 inches
(30cm) above the oven.
2) Do not remove the legs from the
bottom of the oven.
(3) Blockingtheintakeand/oroutletopenings
can damage the oven.
(4) Place the oven as far away from radios
and TV as possible. Operation of
microwave oven may cause interference
to your radio or TV reception.
2. Plug your oven into a standard household
outlet.Besurethevoltageandthefrequency
is the same as the voltage and the frequency
on the rating label.
WARNING – Do not install oven over
a range cook-top or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and the
warranty would be void.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
11
(1) Time Cook
(2) Weight/Time Defrost
(3) Clock/Kitchen Timer
(4) Power (10 power levels available)
(5)
(6) Auto Cook Menu (Popcorn,
Potato, Frozen Pizza, Frozen Vegetable,
Beverage, Meat,Dinner Plate)
(7) Number Pad (0-9)
(8) Express Cook (Number Pad 1-6)
(9) START/ 30SEC(Begincooking.
time or add time to cooking)
(10) Stop/CANCEL(Beforecookingstarts,
press to clear all previous settings;
during cooking, press once to stop
oven; press twice to stop oven and
clear all settings.
(11) Memory function
12
CONTROL PANEL
+
Grill/Combo
(1)
(2)
(4)
(6)
(7)
(10)
(11)
(8)
(5)
(9)
(3)
OPERATION
1. POWER LEVEL
10 power levels are available.
Level
10 9 8 7 6 5 4 3 2 1
Power
100% 90% 80% 70% 60% 50% 40%
20% 10%
Display
PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1
2. CLOCK SETTING
(1) Press“Clock/Kitchen Timer“once,“00:00”willdisplay.
(2) Press the number keys and enter the current time. For example, time is 10:12 now, please
press“1,0,1,2”inturn.
(3) Press“Clock/Kitchen Timer“tonishclocksetting.“:”willashandtheclockwillbelighted.
(4) If the numbers input are not within the range of 1:00--12:59, the setting will be invalid until
valid numbers are input.
Note:
1. Intheprocessofclocksetting,ifthe“STOP/CANCEL“buttonispressedorifthereisnooperation
within 1 minute, the oven will go back to the former setting automatically.
2. If the clock need to be reset, please repeat step 1 to step 3.
3. MICROWAVE COOK
(1) Press“ COOKTIME ”once,thescreenwilldisplay“00:00”.
(2) Press number keys to input the cooking time; the maximum cooking time is 99 minutes and
99 seconds.
(3) Press“POWER“once,screenwilldisplay“PL10”.Thedefaultpoweris100%power.
Now you can press number keys to adjust the power level.
(4) Press“START/ 30SEC.“tostartcooking.
Example: To cook the food with 50% microwave power for 15 minutes.
a. Press once.”00:00”displays.
b. Press“1”,”5”,”0”,”0”inorder.
c. Press“POWER”once,thenpress“5”toselect50%microwavepower.
d. Press to start cooking.
“ COOKTIME ”
13
+
“START/ 30SEC.“
+
30%
Note:
1. Intheprocessofsetting,ifthe“STOP/CANCEL“buttonispressedorifthereisnooperationwithin1
minute, the oven will go back to the former setting automatically.
2. Youcanskipthestepof“c”andcookat100%microwavepower.
14
4. KITCHEN TIMER
(1)Press “Clock/Kitchen Timer“ twice,the screen will display 00:00.
(2)Press the number keys and enter the timer time. (The maximum cooking time is 99 minutes and 99
seconds.)
(3)Press “START/ + 30sec.“ to confirm setting.
(4)When the timer time arrives, the buzzer will ring 5 times, screen display the current time.
NOTE:
1.The kitchen time is different from 12-hour system, Kitchen Timer is a timer.
2.Kitchen Timer and cooking (including microwave, defrosting, Auto menu) are independent,
3.all the cooking functions cannot be set during running Kitchen Timer, Kitchen Timer cannot be set
during running other cooking functions.
5 . GRILLING COOKING
FunctionDisplay
Microwave
Power
Grill Power
Combi.1 C-1 55% 45%
Combi.2 C-2 36% 64%
(1)Press “Grill/Combo.“once, “G-1” will display.
(2)Press number keys to input the cooking time; the maximum cooking time is 99 minutes and 99
seconds.
(3)Press “START/+30SEC.“ to start cooking.
6 . COMBINATION COOKING
(1)Press “Grill/Combo.“twice or three times, “C-1” or “C-2” will display.
(2)Press number keys to input the cooking time; the maximum cooking time is 99 minutes and 99
seconds.
(3)Press “START/+30SEC.“ to start cooking.
7. EXPRESS COOKING
(1)In waiting state, instant cooking at 100% power level with 30 seconds’ cooking time can be started
by pressing “START/+30SEC.“. Each press on the same button will increase cooking time by 30 seconds.
The maximum cooking time is 99 minutes and 99 seconds.
(2)If not ready cooking, press number pads 1-6 to quickly cook from 1-6 minutes at 100% power.
Press “ START/ + 30sec. " to increase the cooking time; the maximum cooking time is 99 minutes and
99 seconds.
Note:
During microwave cooking, time defrost , time can be added by pressing “START/ + 30sec." button.
Note:If you need to use the metal rack, you need to place the metal rack on resistant glass
turntable.
Note:If you need to use the metal rack, you need to place the metal rack on resistant glass
turntable.
8. CANCEL QUICKLY
(1) During setting or running procedure, only pressing “STOP/CANCEL“ can stop current states and turn
back to the waiting states.
9. WEIGHT DEFROST FUNCTION
(1)Press “Weight/Time Defrost“ once, screen will display “dEF1”;
(2)Press numerical buttons to input weight to be defrosted. Input the weight ranged between 4~100 Oz. If the
weight input is not within 4~100 Oz, the input will be invalid.
(3)Press “START/+30SEC.“ to start defrosting and the cooking time remained will be displayed.
15
(1)Press “Weight/Time Defrost“ twice, screen will display “dEF2”.
(2)Press number pads to input defrosting time. The effective time range is 0:01~99:99.
(3)Press “POWER“ once, screen will display “PL3”. The default power is 30% power. Now you can
press number keys to adjust the power level.
(4)Press “START/+30SEC.“ to start defrosting. The remained cooking time will be displayed.
(1)Press “POPCORN“ repeatedly until the number you wish appears in the display,
“1.75”,”3.0”,”3.5” Oz will display in order. For example, press “POPCORN” once, “1.75” appears.
(2)Press “START/+30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds
five times and screen will display the current time.
10. TIME DEFROST FUNCTION
11. POPCORN
12.BEVERAGE
(
1
)Press “BEVERAGE“ repeatedly until the number you wish appears in the display, “1”,”2”,”3” cup
will display in order. One cup is about 120ml. For example, press “BEVERAGE” once,“1” appears.
(2)Press “START/+30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five
times and then turns back to waiting state.
13. FROZEN PIZZA
(1)Press “FROZEN PIZZA“ repeatedly until the number you wish appears in the display,
“4.0”,”8.0”,”14.0”Oz will display in order. For example, press “FROZEN PIZZA“once, “4.0” appears.
(2)Press “START/+30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five
times and then turns back to waiting state.
14. POTATO
15. FROZEN VEGETABLE
(1) Press “ FROZEN VEGETABLE “ repeatedly until the number you wish appears in the display,
“4.0”,”8.0”,”16.0” Oz will display in order. For example, press “FROZEN VEGETABLE” once, “4.0”
appears.
(2)Press “START/+30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five
times and then turns back to waiting state
16
16. DINNER PLATE
(1) Press “ DINNER PLATE “ repeatedly until the number you wish appears in the display,
“9.0”,”12.0”,”18.0” Oz will display in order. For example, press “DINNER PLATE” once, “9.0” appears.
(2) Press “START/+30SEC.“to cook, buzzer sounds once. When cooking finish, buzzer sounds five times
and then turns back to waiting state
(1)Press “POTATO“ repeatedly until the number you wish appears in the display, “1”,”2”,”3” will
display in order. For example, press “POTATO” once, “1” appears.
(2)Press “START/+30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five
times and then turns back to waiting state.
17. MEAT
A. Chicken Menu
(1)Press “MEAT“ once to choose chicken menu,CHIC displays.
(2)Press “START/+30SEC.“ to confirm the menu. 14.0 displays.
(3)Keep pressing “MEAT“ to choose chicken weight. 22.0, 30.0, 38.0 or 46.0 Oz can be selected.
(4)Press “START/+30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five times
and then turns back to waiting state.
18. MEMORY FUNCTION
(1) Press “0/MEMORY” to choose memory 1-3 procedure. The screen will display 1,2,3.
(2) If the procedure has been set, press “START/+30SEC.“ to use it. If not, continue to set the
procedure. Only one or two stages can be set.
(3) If the procedure has not been set, after finishing the setting, press“START/+30SEC.“once to
save the procedure and turn back to the waiting states. If press“START/+30SEC.“ it will start
cooking at once and save the procedure too.
Example: To set the following procedure as the second memory, that is memory 2. To cook the food
with 80% microwave power for 3minutes and 20 seconds.
The steps are as follow:
a. In waiting states, press “0/MEMORY” twice, stop pressing until the screen displays “2”.
b. Press “ TIME COOK “ once,then press “3”,”2”,”0” in order.
c. Press “POWER“ once, ”PL10” display, then press “8” and “PL8” displays.
d. Press “START/+30SEC.“once to save the setting. Buzzer sounds once then the screen will
display “2”.
If you press “START/+30SEC.“ again, the procedure will be operated as the memory 2.
e. If the electricity is not cut off, the procedure will be saved all the time. If it is, the procedure
need to reset.
f. When you want to run the saved procedure, in waiting states, press“0/MEMORY” twice,
screen displays “2”, then press “START/+30SEC.“ to start cooking.
Note:
Auto menu can not be set in memory function.
(1)Press “MEAT“ three times to choose pork menu, PO displays.
(2) Press “START/+30SEC.“ to confirm the menu. 6.0 displays.
(3)Keep pressing “MEAT“ to choose pork weight. 11.0, 16.0, 21.0 or 26.0 Oz can be selected.
(4)Press “START/+30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five
times and then turns back to waiting state.
C. Pork Menu
(1)Press “MEAT“ twice to choose beef menu, BEEF displays.
(2)Press “START/+30SEC.“ to confirm the menu. 12.0 displays.
(3)Keep pressing “MEAT“ to choose beef weight. 19.0, 26.0, 33.0 or 40.0 Oz can be selected.
(4)Press “START/+30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five
times and then turns back to waiting state.
B. Beef Menu
17
(1)In standby state, if the set clock digital tube displays current time, the icon “:“ would flash; otherwise,
it shows “0:00“.
(2)In setting function state, the screen displays corresponding setting.
(3)In working or pause state, the screen displays surplus cooking time.
(4)When the cooking is finish, the screen will display the current time. Opening the door or pressing
“STOP/CANCEL“ can make the oven enter waiting state.
18
19. MULTI-STAGE COOKING
At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is defrosting, then defrosting shall
be placed at the first stage automatically.
Note:
Auto menu cannot work in the multi-stage cooking.
Example: If you want to cook with 80% microwave power for 5 minutes + 60% microwave power for 10
minutes. The cooking steps are as following:
a.Press“ TIME COOK “ once,then press “5”,”0”,”0” to set the cooking time;
b.Press “POWER“ once,then press “8” to select 80% microwave power.
c.Press“ TIME COOK “ once,then press “1”,”0”,”0”,”0” to set the cooking time;
d.Press “POWER“ once,then press “6” to select 60% microwave power.
e.Press “START/+30SEC.“to start cooking.
20. INQUIRING FUNCTION
In the microwave cooking state, press “POWER“ to inquire microwave power level, and
the current microwave power will be displayed. After three seconds, the oven will turn back to the previous
state. In multi-stage state, the inquiring way can be done by the same way as above.
In the microwave cooking state, press “CLOCK/KITCHENTIMER“ to inquire the current time.
21. LOCK FUNCTION FOR CHILDREN
Lock: In waiting state, press “STOP/CANCEL“ for 3 seconds, there will be a long “beep” denoting the entering
into the children-lock state, and the lock indicator will light. The screen will display the
Unlock: In locked state, press “STOP/CANCEL “ for 3 seconds, there will be a long “beep” denoting that lock is
released.
22. COOKING END REMINDING FUNCTION
When the cooking is over, the buzzer will sound 5 “beep” to alert user the cooking is finished.
23. OTHER SPECIFICATIONS
MAINTENANCE
Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the
microwave oven still does not work properly, contact the nearest authorized service center.
Trouble Possible Cause Possible Remedy
Oven will not
start
a. Electrical cord for oven is not
plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try again.
c. Check instructions.
Arcing or
sparking
a. Materials to be avoided in
microwave oven were used.
b. The oven is operated when empty.
c. Spilled food remains in the cavity.
a. Use microwave-safe cookware only.
b. Do not operate with oven empty.
c. Clean cavity with wet towel.
Unevenly
cooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted completely.
c. Cooking time, power level is
not suitable.
d. Food is not turned or stirred.
a. Use microwave-safe cookware only.
b. Completely defrost food.
c. Use correct cooking time, power level.
d. Turn or stir food.
Overcooked
foods
Cooking time, power level is
not suitable.
Use correct cooking time, power level.
Undercooked
foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted completely.
c. Oven ventilation ports are restricted.
d. Cooking time, power level is not
suitable.
a. Use microwave-safe cookware only.
b. Completely defrost food.
c. Check to see that oven ventilation
ports are not restricted.
d. Use correct cooking time, power level.
Improper
defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe cookware only.
b. Use correct cooking time, power level.
c. Turn or stir food.
19
20
ONE YEAR LIMITED WARRANTY
This warranty applies to products purchased and used in the U.S and Canada
This is the only express warranty for this product and is in lieu of any other warranty or
condition.
This product is warranted to be free from defects in material and workmanship for a period
of one (1) year from the date of original purchase. This warranty is valid for the original
retail purchaser or gift recipient from the date of initial retail purchase and is not
transferable.
Keep your original sales receipt as proof of purchase is required to make a warranty claim.
IMPORTANT: This warranty does not cover damages resulting from use not in conformity
with the printed directions, accident, misuse or abuse, alternation, the affixing of any
attachments not provided with the product, loss of parts, or subjecting the appliance to any
but the specified voltage. (Read directions carefully.) This warranty is void if the product is
used for other than single-family household use or subjected to any voltage and waveform
other than as specified on the rating label (e.g., 120V ~ 60 Hz).
excludes all claims for special, incidental, and consequential
damages caused by breach of express or implied warranty. All liability is limited to the
amount of the purchase price. Every implied warranty, including any statutory warranty or
condition of merchantability or fitness for a particular purpose, is disclaimed except to
the extent prohibited by law, in which case such warranty or condition is limited to the
duration of this written warranty. This warranty gives you specific legal rights. You may
have other legal rights that vary depending on where you live. Some states or provinces do
not allow limitations on implied warranties or special, incidental, or consequential damages,
so the foregoing limitations may not apply to you.
To make a warranty claim or if service is required, please call our CUSTOMER SERVICE
NUMBER.
For faster service, please have the model, type, and series numbers ready for the operator
to assist you.
.
Customer Service Number
In the US 844-918-0509
Email: [email protected]
Englewood Marketing LLC
Englewood M arketing LLC
roduct registration is not mandatory.Failure to complete and return the card f m does
.
not diminish the consumer s warranty rights
P
or or
'
