CONTENTS
• For Customer Assistance ..... 2
• Precautions to Avoid Possible
Exposure to Excessive
Microwave Energy .................... 3
• Consumer Limited Warranty ....................... 4
• Important Safety Instructions ..................... 5
• Federal Communication Commission Radio
Frequency Interference Statement ............ 6
• Grounding Instructions ............................... 7
• Installation Guide ........................................ 8-9
• Specifications .............................................. 10
• Features Diagram ........................................ 11-13
• Operation Procedure ..................................
• Controls ....................................................... 18-31
• Care and Cleaning ......................................
• Before You Call ............................................ 37
• Questions and Answers ............................. 38
• Cooking Instructions .................................. 39-49
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
MODEL
OVER THE RANGE
MICROWAVE OVEN
OPERATION MANUAL
※ Keep the waveguide cover clean at all times.
Wipe the oven interior wth a soft damp cloth after each use.
If you leave grease or fat anywhere in the cavity it may overheat, smoke or even catch
fire when next using the oven.
SMO19 9JS
14-17
32-36
9
FOR CUSTOMER ASSISTANCE
CUSTOMER ASSISTANCE UNITED STATES ONLY
REGISTER YOUR PRODUCT
Registering your new product is easy and offers benets that help you get the most out of
your Sharp product including:
9 Convenience: Ifyoueverneedwarrantysupport,yourproductinformationisalreadyonle.
9 Communication: StayuptodatewithimportantnoticationsandspecialoffersfromSHARP.
9 Support: QuicklyaccesssupportcontentincludingOwnersManuals,FAQ’s,How-toVideos,
andmuchmore.
3 EASY WAYS TO REGISTER TODAY!
PRODUCT SUPPORT
If you have questions about the setup or operation of your product, please refer to the
corresponding section within this manual.
Additionally, visit www.sharpusa.com/support to access exclusive content about your product
including:
Æ FAQ’s and How-To Videos
Æ Find or Request Service
Æ Purchase an Extended Warranty
Æ Downloads including the Installation Guide, Spec Sheet, and Owner’s Manual
CONTACT US
If at any time you have questions or comments concerning your SHARP product, please
contact the SHARP Customer Assistance Center. We are available to assist you through
multiple contact methods for your convenience:
Scan this QR Code on your smart phone Visit http://www.sharpusa.com/register
ONLINE
Visit our sites to learn
more about your
product at
sharpusa.com and
sbl.sharpusa.com
See the Contact Us section on our sites U.S. | www.sharpusa.com/support Contact a Sharp Advisor on the phone
Contact a Sharp Advisor on the phone
CALL US
US 800-BE-SHARP
800-237-4277
Mon-Fri: 7am-7pm CST
Sat-Sun: 9am-7pm CST
CALL US
US 800-BE-SHARP
800-237-4277
Mon-Fri: 7am-7pm CST
Sat-Sun: 9am-7pm CST
EMAIL
Available 24/7
US: sharpusa.com
CHAT ONLINE
Mon-Fri: 7am-7pm CST
Sat-Sun: 9am-7pm CST
SCAN
Use the camera or
QR code scanning
application on your
smart phone
2
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper
with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door
close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches
(broken or loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
3
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand
(the “Product”), when shipped in its original container, will be free from defective workmanship
and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product
or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor
for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s)
set forth below nor to any Product the exterior of which has been damaged or defaced, which has been
subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered
or modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth
below and provide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to
purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH
BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other
than those described herein, or to extend the duration of any warranties beyond the time period described
herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be
the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the
period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of
Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether
based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way
responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs
performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible
for any incidental or consequential economic or property damage. Some states do not allow the exclusion
of incidental or consequential damages, so the above exclusion may not apply to you.
THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF
COLUMBIA AND PUERTO RICO.
Your Product Model Number &
Description:
SMO1969JS Home Use Carousel Microwave Oven. (Be sure to have
this information available when you need service for your Product.)
Warranty Period for this Product:
One (1) year parts and labor. The warranty period continues for an
additional six (6) years, for a total of seven (7) years, with respect to
the magnetron tube in the Product for parts only; labor and service
are not provided free of charge for this additional period.
Additional Item(s) Excluded from
Warranty Coverage (if any):
Where to Obtain Service:
provided it was installed according to Sharp’s Installation Instructions.
To find the location of the nearest Sharp Authorized Servicer, call
Sharp toll free at 1-800-BE-SHARP (1-800-237-4277).
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP OR VISIT www.sharpusa.com.
SAVE THE PROOF OF PURCHASE AS IT IS NEEDED SHOULD YOUR OVEN EVER REQUIRE WARRANTY SERVICE.
CONSUMER LIMITED WARRANTY
Non-functional accessories, turntable and light bulb. Service calls
to your home to instruct how to use your appliance.
From a Sharp Authorized Servicer located In the United States. Be
sure to have Proof of Purchase available. For in-home service, the
servicer will come to the product location. If it is necessary to remove
the product for repair, the servicer will reinstall the product at no extra charge,
4
When using electrical appliances, basic safety precautions should be followed, including the following:
WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive
microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” found on page 3.
3. This appliance must be grounded. Connect only to
properly grounded outlet. See “GROUNDING
INSTRUCTIONS” found on page 6.
4. Install or locate this appliance only in accordance with
the provided installation instructions.
5. Some products such as whole eggs and sealed
containers - for example, closed glass jars are able to
explode and should not be heated in this oven.
6. Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specifically designed to heat, cook, or dry food.
It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary
when used by children.
8. Do not operate this appliance if it has a damaged cord
or plug, if it is not working properly, or if it has been
damaged or dropped.
9. This appliance should be serviced only by qualified
service personnel.
Contact nearest authorized service facility for
examination, repair or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this
product near water — for example, near a kitchen sink,
in a wet basement, near a swimming pool, or similar
locations.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that
comes together on closing the door, use only mild,
non-abrasive soaps or detergents applied with a
sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully attend appliance
when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags
before placing bag in oven.
c) If materials inside the oven ignite, keep oven door
closed, turn oven off, and disconnect the power
cord, or shut off power at the fuse or circuit breaker
panel.
d) Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in
the cavity when not in use.
17. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing
to be boiling due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed from
the microwave oven is not always present. THIS
COULD RESULT IN VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN A SPOON OR OTHER
UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through
heating it.
c) Do not use straight-sided containers with narrow
necks.
d) After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
e) Use extreme care when inserting a spoon or other
utensil into the container.
18. Do not use this microwave oven to heat corrosive
chemicals (for example, sulfides and chlorides). Vapors
from such corrosive chemicals may interact with the
contact and springs of the safety interlock switches
thereby rendering them inoperable.
19. Never heat oil or fat for deep frying as you cannot
control the temperature and doing so may lead to
overheating and fire.
20. Do not operate the oven without the glass tray in place.
Be sure it is properly sitting on the rotating base.
21. Use care when cleaning the vent hood filters.
Corrosive cleaning agents such as lye-based oven
cleaners may damage the filters.
22. Clean the ventilating hood frequently. Do not allow
grease to accumulate on the hood or the filters.
23. Suitable for use above both gas and electric cooking
equipment up to 30 inches wide.
24. Do not use this oven for commercial purposes It is
designed for household use only.
25. When flaming foods under the hood, turn the fan on.
Keep the area under the hood properly ventilated at all
times. Turn off cooking equipment if you see flames or
a fire occurs.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
5
WARNING:
This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in
strict accordance with the manufacturer's instructions, may cause interference to radio and television
reception.
It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part 18 of FCC
Rules, which are designed to provide reasonable protection against such interference in a residential
installation.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the followings.
• Reorient the receiving antenna of radio or television.
• Relocate the Microwave oven with respect to the receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so that microwave oven and receiver are on
different branch circuits.
THE MANUFACTURER is not responsible for any radio or TV interference caused by
UNAUTHORIZED MODIFICATION to this microwave oven. It is the responsibility of the user to correct
such interference.
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
6
This device complies with part 15 of the FCC Rules . Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Changes or modications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which thereceiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This device and its antenna must not be co-located or operating in conjunction with any other antenna
or transmitter.
“To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile
Congurations. The antennas used for this transmitter must be installed to provide a separation distance
of at least 20 cm from all persons and must not be colocated or operating in conjunction with any other
antenna or transmitter.”
7
This appliance must be grounded. In the event of an electrical short circuit, the grounding plug reduces the risk of
electric shock by providing an escape wire for electric current. This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and
grounded.
WARNING:
Improper use of the grounding can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if
doubt exists as to whether the appliance is properly grounded, and either
1) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding
plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension
cord shall be equal to or greater than the electrical rating of the appliance, or
2) Do not use an extension cord. If the power supply cord is too short, have a qualified electrician or
serviceman install an outlet near the appliance.
WARNING:
Do not cut or remove the third (ground) prong from the power cord under any circumstances.
GROUNDING INSTRUCTIONS
1. Examine the oven after unpacking.
Unpack the oven, remove all packaging material and examine the oven for any damage such as dents on the
interior or exterior of the oven, broken door latches, cracks in the door, or a door that is not lined up correctly. If
there is any damage, do not operate the oven and notify your dealer immediately.
2. Checking the parts
Carefully unpack your microwave oven, and make sure you’ve received all the parts shown below. If your
microwave oven was damaged during shipping, or if you do not have all the parts, call 1-800-BE-SHARP.
INSTALLATION GUIDE
Image Part & Description Q’ty
Hardware Kit
(Screws)
1
Damper
(Exhaust Adapter)
1
Mounting Plate
1
Top Cabinet
Template
Top Cabinet Template
1
Wall Template
Rear Wall Template
1
3. Location
• The installation of this appliance must be performed by a qualified technician or service company.
Failing to have a qualified technician install the oven may result in electric shock, fire, an explosion, problems
with the product, or injury.
• Do not install this appliance in a humid, oily, or dusty location, or in a location exposed to direct sunlight or water
(rain drops).
• Plug the power plug into the wall socket firmly. Do not use a damaged power plug, damaged power cord, or
loose wall socket.
• Do not mount over a sink.
• Do not stand on top of the microwave or place objects (such as laundry, oven covers, lighted candles, lighted
cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
This may result in electric shock, fire, problems with the product, or injury.
4. Power supply.
• Check your local power source.
This microwave oven requires a current of approximately 14 amperes, 120Volts, 60Hz and a grounded outlet.
a) A short power-supply cord is provided to reduce the risks of the user becoming entangled in or tripping over a
longer cord.
b) Longer cord sets or extension cords are available and may be used if care is exercised in their use.
c) If a long cord or extension cord is used:
- The marked electrical rating of the cord set or extension cord should be at least as great as the electrical
rating of the oven.
- The extension cord must be a grounding type 3-wire cord.
- The longer cord should be arranged so that it will not drape the table top or counter where it can be pulled on
by children or tripped over unintentionally.
1
Image Part & Description Q’ty
Installation
Manual
Installation Manual 1
Operation
Manual
Operation Manual 1
Guide Roller Ring 1
2
Glass Turntable 1
Charcoal Filter
Model # RK233
Grease Filters
Model # RK245
1
Metal Rack
8
• Check power cord and outlet
- Remove all foreign substances such as dust or water from the power plug terminals and contact points using
a dry cloth on a regular basis.
- Unplug the power plug and clean it with a dry cloth.
- Plug the power cord into a properly grounded 3 pronged outlet. Your oven should be the only appliance
connected to this circuit.
- Sharing a wall socket with other appliances, using a power strip, or extending the power cord may result in
electric shock or fire.
- Do not use an electric transformer. It may result in electric shock or fire.
- Ensure that the voltage, frequency and current provided match the product’s specifications.
5. Critical usage WARNINGS
If the microwave appliance is flooded, please contact your nearest service center. Failing to do so may result in
electric shock or fire.
Read and follow the specific “Precautions to Avoid Possible Exposure to Excessive Microwave Energy” found on
Page 3.
If the microwave generates a strange noise, a burning smell or smoke, unplug it immediately and contact your
nearest service center.
• In the event of a gas leak (propane gas, LP gas, etc.), ventilate the room immediately. Do not touch the
microwave, power cord, or plug.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
Take care that the door or any of the other parts do not come into contact with your body while cooking or just
after cooking.
• In the event of a grease fire on the surface units below the oven, smother the flaming pan on the surface unit by
covering the pan completely with a lid, a cookie sheet or a flat tray.
Never leave surface units beneath your oven unattended at high heat settings. Boil overs cause smoking and
greasy spills that may ignite and spread if the vent fan is operating. To minimize automatic fan operation, use
adequate sized cookware. Use high heat on surface units only when necessary.
If materials inside the oven should ignite, keep the oven door closed, turn the oven off and disconnect the power
cord, or shut off power at the fuse or circuit breaker panel. If the door is opened, the fire may spread.
• Always observe Safety Precautions when using your oven. Never try to repair the oven on your own. There is
dangerous voltage inside. If the oven needs to be repaired, contact an authorized service center near you.
When use 3-pronged plug
3-prong Receptacle
Receptacle
Box cover
3-prong plug
When use grounding adaptor, make sure
the receptacle box is fully grounded.
Receptacle Box Cover
Receptacle
Grounding
Lead
Grounding
Adaptor
“THE CANADIAN ELECTRICAL CODE DOES NOT ALLOW THE USE OF THE GROUNDING ADAPTOR”
INSTALLATION GUIDE
9
SPECIFICATIONS
POWER SUPPLY
MICROWAVE
INPUT POWER
ENERGY OUTPUT
FREQUENCY
OUTSIDE DIMENSIONS (W x H x D)
CAVITY DIMENSIONS (W x H x D)
CAVITY VOLUME
NET WEIGHT
TIMER
POWER SELECTIONS
1650 W
1100 W
2,450MHz
29.9 x 16.4 x 15.7 in
21.1 x 10.6 x 14.6 in
1.9 cu.ft
APPROX. 56.2 lbs
99 min. 99 sec.
11 Levels
* Specifications are subject to change without notice.
29.9" 15.7"
16.4"
120V AC, 60Hz SINGLE PHASE WITH
GROUNDING
10
1 DOOR LATCHES
2 WINDOW with METAL SHIELD - Screen allows
cooking to be viewed while keeping microwaves
confined in oven.
3
MODEL NUMBER PLATE - Located on the front
wall of the microwave oven.
4
CHARCOAL FILTER (behind Vent Grille)
6
WAVEGUIDE COVER
Protects the microwave outlet from splashes of
cooking foods.
7
TOUCH CONTROL PANEL and DIGITAL
DISPLAY - For detailed information on each
feature, see Features Diagram section,
page 11, 12.
COOKTOP LIGHT
GREASE FILTERS
TURNTABLE / GLASS TRAY - Composed of glass
tray and roller guide. The roller guide is placed first
on the bottom of the microwave oven of which
supports the glass tray. Both parts must be in
place when using the microwave oven.
VENTILATION MOTOR - Your microwave oven is
designed for adaptation to the following three
types of ventilation.
(Recirculation ventilation system, Vertical
ventilation system, Horizontal ventilation system)
See installation manual to Select the type of
ventilation required for your installation.
10
12
FEATURES DIAGRAM
HEAT DEFLECTOR
GUIDE ROLLER RING
5
- Automatically turns
on when the
oven door is open and
operating.
OVEN LIGHT
4 5 6
7
11
1 2
3
9 8
13
e
w
q
0
9
8
14
METAL RACK
Coupler has already been installed at the center and
11
FEATURES DIAGRAM
The Touch Control Panel allows you to set the oven controls with the press of a finger.
It’s designed to be easy to use and understand.
◆ Each time a pad is pressed, a BEEP will sound.
◆ When STOP/CLEAR pad is pressed during oven operation, the oven
will stop, however, all programmed information is retained. To clear all
information, press the STOP/CLEAR pad again.
18 7 11 1 14 9 17
20 12 8 19 15 10 1613
3
4 5
6
2
21
12
1 DISPLAY - Displays time of day, time or
power level being used, cooking mode and
instructions.
2
5
AUTO COOK -
6
7
8
9
0
TIME COOK - Press this pad to set the
Microwave cooking time.
◆ Power Level 10 (High) is automatic but
lower heat levels may be programmed.
w
Press and hold this pad
reset time after replacing
the filter.
Charcoal filters must be replaced every 6
months.
FEATURES DIAGRAM
3
4
POPCORN -
prepackaged microwave popcorn weight
1.75/3.0/3.5 ounces.
BEVERAGE -
POWER LEVEL - Press this pad if you want
to change from automatic Power Level 10
(High) for cooking.
q
AUTO DEFROST -
for 3 seconds to
TIMER/FILTER
Press this pad to use as a minute timer,
delay cooking, hold setting after cooking.
Press this pad to cook
preprogramed menus.
MELT/SOFTEN - P ress this pad to melt or
reheat food.
SENSOR REHEAT -
SIDES -
TURNTABLE On/Off - Press this pad to
turn turntable on or off.
r
NUMBER PADS - Press these pads to
enter cooking time, defrosting time or
weight, time of day, power level.
y
EXPRESS COOK - Press these pads to set
1-10 minutes preset cooking time at 100%
power level.
u
i
o
STOP/CLEAR - When pressed once, it
pauses the oven operation. When pressed
twice, it resets the oven and erases all
p
- Press this pad to turn on or off the
cooktop light.
- P
on turbo, high, medium, low or off.
START/+30 SEC - After all selections are
made, press this pad to start the oven or timer.
CLOCK - Press this pad to enter time of
day.
e
Also press and hold this pad for 3
seconds to turn sound on off. For
detailed information on this feature, see
Controls section, page 29.
t
a
Also press and hold this pad for 3
seconds to set child safety lock function.
For detailed information on this feature,
see Controls section, page 30.
WIFI CONNECT -
ENTREES -
Press this pad to turn
on or off your oven s Wi-Fi connection
Press this pad to cook Fresh
Vegetables, Frozen Vegetables, Rice, or
Potatoes. The microwave oven sensor
will automatically adjust cooking time to
the type and amount of food.
Press this pad to cook
Frozen Dinner, Chicken, Fish,
Casserole/Pizza, or Frozen Breakfast.
The microwave oven sensor will
automatically adjust cooking time to the
type and amount of food.
,
Milk or coffee.
ress this pad to turn the fan
13
soften Butter, Chocolate, Cheese, Cream
Cheese and Ice Cream.
Press this pad to select
Meat, Poultry, or Fish, then select weight
option.
Press this pad to cook
Press this pad to
Press this pad to reheat
settings (except clock and Wi-Fi connection).
Plug power supply cord into a standard 3-pronged
15 Amps 120V AC 60Hz power outlet.
After placing the food in a suitable container, open
the oven door and put it on the glass tray.
The glass tray and roller guide must always be in
place during cooking.
Close the door. Make sure that it is firmly closed.
The oven light is on when the microwave oven is
operating.
The oven door can be opened at any time during
operation by pulling the door open using the
pocket handle. The oven will automatically stop.
Each time a pad is pressed, a BEEP will sound to
acknowledge the press.
The oven automatically cooks on full power unless
set to a lower power level.
The display will flash 12:00 when the oven CLOCK
is not set.
1
2
3
4
5
6
7
8
19
10
11
Make sure the oven is properly installed and
plugged into the electrical outlet.
TO SET POWER LEVEL
OPERATION PROCEDURE
This section includes useful information about oven operation.
PRESS POWER PAD AND NUMBER POWER LEVEL (DISPLAY)
APPROXIMATE PERCENTAGE OF POWER
POWER LEVEL + 1 + 0 PL-Hi 100%
POWER LEVEL + 9 PL-90 90%
POWER LEVEL + 8 PL-80 80%
POWER LEVEL + 7 PL-70 70%
POWER LEVEL + 6 PL-60 60%
POWER LEVEL + 5 PL-50 50%
POWER LEVEL + 4 PL-40 40%
POWER LEVEL + 3 PL-30 30%
POWER LEVEL + 2 PL-20 20%
POWER LEVEL + 1 PL-10 10%
POWER LEVEL + 0 PL-0 0%
NOTE : If “PL-0” is selected, the oven will work with the fan but no power. You can use this level to remove odors.
Time clock returns to the present time when the
cooking time ends.
When the STOP/CLEAR pad is pressed during the
oven operation, the oven stops cooking and all
information retained. To erase all information (except
the present time), press the STOP/CLEAR pad once
more. If the oven door is opened during the oven
operation, all information is retained.
If the START pad is pressed and the oven does not
operate, check the area between the door and door
seal for obstructions and make sure the door is
closed securely. The oven will not start cooking until
the door is completely closed or the program has
been reset.
•
The power level is set by pressing the POWER LEVEL pad and number pad. f you wish to use a differen power
level, press TIME COOK, set the desired cook time, then press the POWER LEVEL pad and then press the
START pad.
Enter the power level desired by pressing the appropriate number pad. The chart shows the display, the power
level and the percentage of power.
tI
14
SETTING UP ALEXA ON YOUR MICROWAVE OVEN
Your microwave oven can be controlled with Alexa using any Alexa-enabled device such as Echo or
Echo Dot. To control your microwave oven using Alexa, you’ll need to set up your microwave and
connect to Alexa using one of the below pairing methods.
Alexa. (If the Wi-Fi icon is off, press the Wi-Fi button once to turn the Wi-Fi on.)
Microwave should appear in the list of devices.
In order to pair using this method, all pre-requisites listed below must be met. If not, go to pairing
method #2 or #3.
You opted-in to store your Wi-Fi credentials to your Amazon account in the past. This occurs
when you previously set up another Echo family device or a Works with Alexa device.
The microwave must have been ordered from the same Amazon account and while ordering you
must have opted to link the device upon purchase. If microwave was purchased/received as a
gift, or user de-selected this option upon purchase, the microwave will not be linked to end user's
Amazon/Alexa account and ZTS will not be enabled. Please go to pairing method #2 or #3.
The microwave would need to be within the Wi-Fi range of the user’s Wi-Fi network.
The microwave should be within the wireless range of an Echo family device, which was signed
into using the same Amazon account.
Pairing Method 1: Zero-Touch Setup (ZTS)
If Zero-Touch Setup (ZTS) is not possible, you can set up your microwave and connect to Alexa using
Barcode Setup (BCS).
Pairing Method 2: Barcode Setup (BCS)
If above conditions are met:
•
•
Setup mode : While the device is in setup mode, the Wi-Fi icon is flashing until
Turning off the Wi-Fi on the device : Used to turn on or off your device’s Wi-Fi
connection. If you turn the Wi-Fi off on the device by pressing the Wi-Fi CONNECT button,
icon is off on the microwave LED display and Alexa will no longer be able to send
commands to your oven. But you can still cook using the oven’s keypad.
1. Ensure that home Wi-Fi is on and the device is in setup mode.
2. If the Wi-Fi icon stops blinking and stays on steadily, the device is ready to be controlled by using
3. Open Alexa app on your phone and sign into the same Amazon account as the one above. The
the Wi-Fi
OPERATION PROCEDURE
1. Install the latest version of Alexa app on your smart device and login with your Amazon account.
4. Open the Alexa App, tap the Devices icon in the lower right, and tap the “+” icon in the top right.
reset the microwave oven by pressing Wi-Fi CONNECT button.)
Select “Add Device” and “Microwave” press "Sharp" to begin set up for your microwave oven. Follow
on-screen instructions.
2. Ensure your mobile device is connected to a 2.4 GHz Wi-Fi network.
3 . When Wi-Fi icon starts flashing, the microwave oven is ready for setup. (If the Wi-Fi icon is off,
Before you pair, ensure your mobile device is connected to a 2.4 GHz Wi-Fi network.
15
successfully paired. Setup mode is activated for 5 minutes. After 5 minutes, setup mode will
time out and display "FFFF", then goes back to displaying the clock.
6. If the Wi-Fi icon stops blinking and is off after 5 minutes, reset the microwave oven by pressing
the step 5.
If the QR code on the device is lost or has been damaged and you cannot use Pairing Method #2, you
can set up your microwave and connect to Alexa using User Guided Setup (UGS).
1. Install the latest version of Alexa app on your smart device and login with your Amazon account.
2. Open the Alexa App, tap the Devices icon in the lower right, and tap the “+” icon in the top right.
Select “Add Device” and “Microwave” to begin set up for your microwave
instructions.
3. When a screen with 2D Barcode appears, Press DON’T HAVE A BARCODE to continue setup.
4. Follow the on-screen instructions to set up your microwave oven.
a. Ensure your mobile device is connected to a 2.4GHz Wi-Fi network.
b.
c. Press NEXT to continue setup.
5. If the Wi-Fi icon stops blinking and is off after 5 minutes, setup times out. Restart from the step
4.b.
After setup, the LED display will turn on the Wi-Fi icon and show local time in your location.
Pairing Method 3: User Guided Setup (UGS)
NOTE: It may take a few minutes for the LED display to show the correct local time.
Once setup is completed, it is automatically setup even after turning the power of the oven off and on.
NOTE: When you delete the product from the Alexa app, you must set up again.
restart from
oven. Follow on-screen
Wi-Fi CONNECT button
press "Sharp"
Press Wi-F CONNECT button once, "ON PAIR "will appear on the microwave LED display. The
Wi_-Fi icon will start blinking.
OPERATION PROCEDURE
NOTE: The QR code used for microwave oven setup is attached
inside the product. Please open the door and scan the
QR code to the right of a key image on the front side of
the product.
i
16
OPERATING YOUR MICROWAVE OVEN
You can use your oven without setting it up for Alexa control.
However, we highly recommend using your oven with Alexa control to unlock the full potential.
Throughout this section, the following icons indicate:
Instructions to operate the oven with voice.
OPERATION PROCEDURE
NOTE: As a safety measure, the oven can only be commanded using voice within 10 minutes
of the door being closed.
17
SETTING THE CLOCK
When the oven is first plugged in, the display will flash "12:00" and a tone will sound. If the AC power ever goes
off, the display show “12:00” when the power comes back on.
SETTING THE TIMER
Timer operates as a minute timer.
Timer operates without microwave energy.
1. Press the CLOCK pad.
This is a 12 hour clock system.
Enter the correct time of day by 2.
pressing the number pads in
sequence.
1. Press TIMER/FILTER pad.
2. Press the amount of time you want
to count down.
This digital clock allows you to set from 1:00 to
12:59.
The current CLOCK is displayed.
The display will show what you pressed.
NOTE:
1. If you attempt to enter an incorrect time, the time will not be set and a error signal tone will sound. Press the
CLOCK pad and re-enter the time.
2. If you want to turn sound on or off, press and hold CLOCK pad for 3 seconds. For detailed information on
this feature, see Controls section, page 29.
CONTROLS
HOW TO USE AS A MINUTE TIMER
When you press the START/+30 SEC pad, the display counts down the time
remaing in TIMER mode.
When TIMER mode ends, you will hear 2 beeps
. To end the timer early, press the TIMER/FILTER pad once
while the display is counting down.
3. Press START/+30 SEC pad.
3. Press START/+30 SEC pad.
Pressing the STOP/CLEAR button also stops the timer early.
18
"ENTER TIME" is displayed.
If you connect to an Alexa device, there is no need to manually set the time.
CONTROLS
AUTO COOK
MEAL IN A CUP Meal
2.4 oz
FROZEN KIDS
MEAL
Frozen Kids Meal
8.8 oz
HOT CEREAL Hot Cereal
1 serving
2 servings
3 servings
1
2
3
P A DDISPLA YPRESS P A D
S E L E C T
F OOD ITEM
QUANTITY /WEIGHT/S IZE
SCRAMBLED
EGGS
Scrambled Eggs
1 Egg
2 Eggs
3 Eggs
4 Eggs
5 Eggs
6 Eggs
1
2
3
4
5
6
Once
Twice
Three
Four times
"Alexa, microwave X hot cereal."
"Alexa, microwave frozen kids meal to the microwave."
"Alexa, microwave X scrambled eggs."
"Alexa, microwave X of bacon."
"Alexa, microwave frozen pizza."
"Alexa, microwave stuffed mushrooms."
"Alexa, microwave fudge brownies."
"Alexa, microwave X of hot dogs."
19
CONTROLS
BACON Bacon
FROZEN PIZZA Frozen Pizza
1 Slices
2 Slices
3 Slices
12 oz
16 oz
18 oz
STUFFED
MUSHROOMS
FUDGE
BROWNIES
Fudge Brownies
Stuffed Mushrooms
1
2
3
HOT DOGS Hot dogs
1 Hot Dog
1
2
3
4
5
6
Five times
Six times
Seven times
Eight times
2 Hot Dogs
3 Hot Dogs
4 Hot Dogs
5 Hot Dogs
6 Hot Dogs
Nine times
20
CONTROLS
3. Press number pads for the desired
defrosting weight.
4. Press START/+30 SEC pad.
The display will show what you pressed.
When you press START/+30 SEC pad, the DEFR. indicator will show the oven is in the AUTO DEFROST
The
display counts down the time to show you how much defrosting time is left in the AUTO DEFROST mode.
beeps during the defrosting cycle to signal that the food needs to be turned or rearranged. When the defro-
ends, you will hear 2 beeps.
mode.
The oven
sting time
1. Press
pad once for
for Fish.
The display will show what you pressed.
2. Press START/+30 SEC pad.
AUTO DEFROST
times
The display will show "ENTER WEIGHT"
NOTE : Your oven can be programmed for
0.1 to 6.0 lbs.
WEIGHT DEFROSTING
Auto Defrost x1 Meat 0.1~6.0 lbs
Auto Defrost x2 Poultry 0.1~6.0 lbs
Auto Defrost x3 Fish 0.1~6.0 lbs
PRESS P A D F OOD ITEM QUANTITY /WEIGHT/S IZE
AUTO DEFROST
AUTO DEFROST lets you easily defrost food by eliminating guesswork in determining defrosting time. See
the chart for specic settings to use
Meat, twice for Poultry, three
"Alexa, defrost X of meat."
"Alexa, defrost X of Poultry."
"Alexa, defrost X of Fish."
21
CONTROLS
MELT/SOFTEN ITEM CHART
MELT/SOFTEN
The melt/soften feature can be used to melt or soften butter, chocolate,
See the chart for specific settings to use.
1. Press MELT/SOFTEN pad once for
melt butter, twice for melt chocolate,
times for soften cheese, four times
soften cream cheese, five times for
The display will show what you pressed.
2. Press START/+30 SEC pad.
three
for
soften ice cream.
MELT BUTTER Butter
MELT CHOCOLATE Chocolate
SOFTEN CHEESE Cheese
SOFTEN CREAM CHEESE
1.75 o z
3.5 o z
1.5 Quart
SOFTEN ICE CREAM
DISPLA Y
1
2
1
2
1
2
1
2
1
2
SELECT P A DPRESS P A D
e times
F OOD ITEM
QUANTITY /WEIGHT/S IZE
oz
1 Pint
"Alexa, melt X of butter."
"Alexa, melt X of chocolate."
"Alexa, soften X of cheese."
"Alexa, soften X of ice cream to the microwave."
"Alexa, soften X of cream cheese."
8 oz
Cream Cheese
lce Cream
3 oz
3.5 oz
7 oz
7
10 o z
Once
Three times
Twice
Four times
Fiv
22
cream cheese and ice cream.
CONTROLS
TIME COOK
1. Press TIME COOK pad.
2. Press number pads for the cooking
time.
3. Press POWER LEVEL pad.
4. Press number pads for power level
(0~10).
5. Press START/+30 SEC pad.
“ ENTER COOK TIME” is displayed.
The display will show what you pressed.
The display will show PL-Hi.
The display will show PL-0 ~ PL-Hi.
When you press START/+30 SEC pad, the MICRO indicator starts display to show the oven is cooking.
The display counts down the time to show how much cooking time is left. When the cooking time ends, you will hear
2 beeps.
NOTE : Your oven can be programmed for 99
minutes 99 seconds. (99:99)
NOTE : Using lower power levels increases the cooking time which is recommended for foods such as cheese,
milk and slow cooking of meats.
NOTE : By default, the oven will microwave at power 10 (maximum power)
To microwave by time, say “Alexa, microwave for X,” where X is the amount of time you’d like to cook for
For example, to cook for 5 minutes, say “Alexa, microwave for 5 minutes.” Or, to cook for 2 minutes and
39 seconds, say “Alexa, microwave for 2 minutes and 39 seconds.”
While microwaving, you can ask to cook for additional time by saying “Alexa, add X in the microwave.”
where X is the amount of time you’d like to add. For example, to add 2 minutes to the cooking time while
the microwave is already running, say “Alexa, add 2 minutes to the microwave.”
By default, your oven will microwave at power 10 (maximum power). To cook at a specific power, say
“Alexa, microwave for X on power level Y,” where X is the amount of time you’d like to cook for and Y is the
power level.
For example, to cook at power 5 for 3 minutes, say “Alexa, microwave for 3 minutes at power level 5.”
MICROWAVE COOK MODE
"Alexa, microwave for X."
"Alexa, add X to microwave."
"Alexa, microwave for X on power level Y."
23
Cooking + Cooking
CONTROLS
1. Press TIME COOK pad.
2. Press number pads for the cooking
time.
5. Press TIME COOK pad.
6. Press number pads for the cooking
time.
3. Press POWER LEVEL pad.
4. Press number pads for power level
(0~10)
. Press START/+30 SEC pad.9
The display will show what you pressed.
The display will show what you pressed.
When you press START/+30 SEC pad, the COOK indicator starts blinking to show the oven is in cook for stage 1.
At the end of stage 1, the oven will beep and start stage 2. The display counts down the time remaining in stage 2
mode. When stage 2 ends, you will hear 2 beeps.
NOTE : Your oven can be programmed for 99
minutes 99 seconds. (99:99)
COOKING IN TWO STAGES
(0~10)
7. Press POWER LEVEL pad.
8. Press number pads for power level
“ENTER COOK TIME” is displayed.
The display will show PL-Hi.
The display will show PL-0 ~ PL-Hi.
“ENTER COOK TIME” is displayed.
The display will show PL-Hi.
The display will show PL-0 ~ PL-Hi.
24
+30 SEC
+30 sec allows you to reheat for 30 seconds at 100% (full power) by simply pressing the
When you press the START/+30 SEC pad,
CONTROLS
EXPRESS COOK
Express Cook is a quick way to set cooking time from 1-10 minutes at 100% (full power).
1. Press one of the Express Cook
pads (from 1-10) for 1-10 minutes of
cooking at 100% (full power).
cooking time and the oven starts cooking.
The display is changed into
99 seconds by 30 second increments.
pad. By repeatedly pressing the START/+30 SEC pad, you can also extend reheating
START/+30 SEC
":30" is displayed and the oven starts reheating.
during a cooking cycle,
time to 99 minutes
"Alexa, microwave for 30 seconds."
"Alexa, cook for 30 seconds."
"Alexa, add 30 seconds to microwave."
25
CONTROLS
ONE TOUCH COOK (PRESET)
One touch cooking allows you to cook or reheat many of your favorite foods by pressing just one pad.
To increase quantity, press the chosen pad until the number in the display is same as desired quantity to cook.
1. Press BEVERAGE pad once for MILK,
1. Press POPCORN pad once for 1.75
oz bag, twice for 3.0 oz bag or
three times for 3.5 oz bag.
2. Press START/+30 SEC pad.
When you press POPCORN pad once, “1.75” is
displayed.
NOTE : 1. Use prepackaged room temperature microwave popcorn.
2. Place bag in oven according to manufacturer’s directions.
3. Pop only one bag at a time.
4. After popping, open bag carefully; popcorn and steam are extremely hot.
5. Do not reheat unpopped kernels or reuse bag.
6. Do not leave oven unattended while popping popcorn.
CAUTION : If prepackaged popcorn is of a different weight than the recommended weight, do not use the
popcorn pad. Follow the manufacturer's instruction.
3. Press number pads for the desired
4. Press START/+30 SEC pad.
The display will show what you pressed.
twice for COFFEE.
The display will show what you pressed.
2. Press START/+30 SEC pad.
The display will show "1-3 CUP"
NOTE : Your oven can be programmed for
1 to 3.
"Alexa, microwave X of popcorn."
"Alexa, microwave X cup of milk."
"Alexa, microwave X cup of coffee. "
amount of cups.
26
SENSOR OPERATIONS
The Sensor Cook categories are designed to detect the increasing humidity released by the food during the cooking
process. The microwave oven sensor will automatically adjust the cooking time to the type and amount of food.
Using Sensor Settings
1. After the oven is plugged in, wait 2 minutes before
using Sensor Cook.
2. Be sure the exterior of the cooking container and the
interior of the oven are dry. Wipe off any moisture with
a dry cloth or paper towel.
3. The oven works with foods at normal storage
temperature.
4. More or less food than the quantity listed in the chart
should be cooked following the guidelines in any
microwave cookbook.
5. Do not open the oven door or press STOP/CLEAR
pad until cooking time appears on the display
window. The measurement of vapor will be
interrupted.
When the sensor detects the vapor emitted from the
food, the remainder of cooking time will appear. The
door may be opened when remaining cooking
time appears on the display. At this time, you may stir
or season food, as desired.
6. Always use microwave-safe containers and cover
them with loose fitting lids or vented plastic wrap.
Never use tight sealing plastic containers. They will
prevent steam from escaping and this will mislead the
sensor, usually causing the food to overcook.
7. Check food for temperature or doneness after
cooking. If food is not completely cooked, enter
additional cooking time manually. Do not use one
of the Sensor Cook categories twice in succession on
the same food portion. This may result in severely
overcooked or burnt food.
Covering Foods
Some foods work best when covered. Use the cover
recommended in the Sensor Cook Chart for these
foods.
1. Casserole lid.
2. Plastic wrap: Use plastic wrap recommended for
microwave cooking. Cover dish loosely; allow
approximately 1/2 inch to remain uncovered to allow
steam to escape. Plastic wrap should not touch
food.
3. Wax paper : Cover dish completely; fold excess wrap
under dish to secure. If dish is wider than paper,
overlap two pieces at least one inch to cover.
Be careful when removing any covering to allow steam
to escape away from you.
CONTROLS
1. Press SENSOR REHEAT pad. The SENSOR and
“ REHEAT” is displayed.
”
2. Press START/+30 SEC pad.
SENSOR REHEAT
SENSOR REHEAT allows you to reheat a chilled meal with one press of pad. I t is not necessary to select
power level or cooking time. The built-in sensor measures the humidity of the food and calculates the
cooking time.
“
27
ENTREES MENU CHART
CONTROLS
SENSOR MENU
Sensor is semi-conductor device that detects the vapor emitted from the food as it heats. The sensor adjusts
the cooking time and power level for various food and quantities and you don't need to enter the weight or
quantity of the food.
FROZEN DINNER Frozen Dinner
CHICKEN
Chicken
FISH Fish
CASSEROLE Casserole/Pasta
9-18 oz
7-18 oz
7-18 oz
2-6 oz
6-8 oz
8-12 oz
PIZZA
FROZEN BREAKFAST
Pizza
Frozen Breakfast
PRESS P A D
D I S P L Y
QUANTITY /WEIGHT
F O O D
A
"Alexa, microwave frozen dinner."
"Alexa, microwave chicken."
"Alexa, microwave fish."
"Alexa, microwave casserole/ pasta."
"Alexa, microwave pizza."
"Alexa, microwave frozen breakfast."
"Alexa, microwave fresh vegetables."
"Alexa, microwave frozen vegetables."
"Alexa, microwave rice."
"Alexa, microwave potato."
Once
Twice
Three times
Four times
Fve times
Si x times
28
1. TURNTABLE ON/OFF pad.
1. Press p
fan speed, twice for high fan speed ,
three times medium fan speed,four times
The options are displayed for 2 seconds.
The options are displayed for 2 seconds.
CONTROLS
TURNTABLE ON-OFF
For best cooking results, the turntable should be on. However the turntable can be turned off so that it does not
rotate when extra large dishes are used.
VENT FAN
The vent fan removes steam and other vapors from surface cooking. You can control the 4-speed fan by
pressing the VENT FAN pad.
NOTE :
1. This option is not available in auto cook and defrost.
2. Sometimes the turntable can become too hot to touch. Be careful touching the turntable during and after
cooking.
3. Do not run the oven empty.
"Alexa, set the microwave vent fan to high."
"Alexa, turn off turntable on microwave."
"Alexa, turn on turntable on microwave."
SIDES MENU CHART
FRESH VEGGIES Fresh Veggies
FROZEN VEGGIES
Frozen Veggies
RICE Rice
POTATO Potato
7-20 oz
7-20 oz
1-2 cups
1-4 potatoes
PRESS P A D
D I S P L Y
F O O D
A
Once
Twice
Three Times
Four Times
"Alexa, set the microwave vent fan to low."
"Alexa, set the microwave vent fan to off."
"Alexa, turn off turntable on microwave."
"Alexa, set the microwave vent fan to turbo."
"Alexa, set the microwave vent fan to medium."
for low fan speed or five times to turn the
fan off.
QUANTITY /WEIGHT
ad once for turbo
29
CONTROLS
MUTE
Audible signals are available to guide you when setting and using your oven.
To mute, press CLOCK pad for 3 seconds. OFF will be displayed. To sound on,
press CLOCK pad for 3 seconds. A beep sounds and ON will be displayed.
FILTER RESET
If your oven is vented to the inside, the charcoal filter should be replaced approximately
every 6 months. The charcoal filter cannot be cleaned.
The FILTER indicator will light up when it is time to replace the charcoal filter.
Press and hold TIMER/FILTER pad for 3 seconds after replacing the filter.
See page 35.
TO SET POWER SAVE MODE
1. Press the STOP/CLEAR pad.
LED is blank.
The display will turn off and a beep sounds.
The options are displayed for 2 seconds.
You can control the light by pressing the LIGHT pad.
COOKTOP LIGHT
1. Press pad once to turn the light
on High, twice to turn the light on Low
or three times to turn off the light
"Alexa, turn ON cooktop light on microwave."
"Alexa, turn OFF cooktop light on microwave."
"Alexa, turn ON sound on microwave."
"Alexa, turn OFF sound on microwave."
2. Press STOP/CLEAR pad again to turn display back on.
30
TO STOP THE OVEN WHILE THE OVEN IS OPERATING
1. Press the STOP/CLEAR pad.
• You can restart the oven by pressing the START pad.
2. Open the door.
• You can restart the oven by closing the door and pressing the START/+30 SEC pad.
NOTE : Oven stops operating when door is opened.
CONTROLS
CHILD SAFETY LOCK
Child safety lock feature may lock the control panel to prevent the oven from being
seconds.
A beep sounds and "LOCKED" will be displayed.
NOTE :
2. Microwave oven cannot be used while Child Lock is activated.
1. While the
Child Lock is active, only the STOP/CLEAR pad works to unlock it.
accidentally started or used by children. To lock, press and hold STOP/CLEAR pad for 3
To unlock, press and hold STOP/CLEAR pad for 3 seconds.
"Alexa, stop the microwave."
"Alexa, pause the microwave."
"Alexa, restart/resume the microwave."
"Alexa, turn ON child lock on microwave."
"Alexa, turn OFF child lock on microwave."
31
will be displayed.
A beep sounds and "UNLOCK"
MICROWAVE OVEN INTERIOR
The oven interior should be cleaned after each use with a damp cloth to keep it free from grease and soil
buildup. Stubborn soils can be removed with a plastic scrub pad. When cleaning interior surfaces and surfaces
of door and oven that come together when the door is closed, use only mild, non-abrasive soaps or detergents
applied with a sponge or soft cloth.
Odors can be eliminated from the inside of the oven by boiling a solution of one cup of water and several
tablespoons of lemon juice in the oven for 5-7 minutes. This also helps loosen any dried soil in the oven. Wipe
off excess moisture after use.
OVEN BOTTOM
Wash oven bottom with hot sudsy water, rinse and dry.
Do not use excessive amounts of water when cleaning
the oven, especially around the turntable. Do not allow
water or cleaning agents to seep into turntable gears
located underneath.
GLASS TRAY/TURNTABLE
Allow to cool before removing and cleaning. Wash in
soapy water or dishwasher.
ROLLER GUIDE
Clean frequently to prevent excessive noise. Wash in
soapy water or dishwasher.
OVEN EXTERIOR
Wipe the outside of your oven with a soapy cloth, rinse
and dry. Do not use abrasive cleaners. They may
scratch the surface.
LIGHT COMPARTMENT
Clean off the grease and dust on the light compartment
cover on the bottom side of the microwave oven often
with warm water and detergent.
CONTROL PANEL
Wipe with a damp cloth. Dry. Do not spray cleaners
directly on panel. Spray cleaners on cloth and then
wipe.
WAVEGUIDE COVER
The waveguide cover is located on the right side wall of
the oven cavity. It is made from mica so requires special
care. Keep the waveguide cover clean to assure good
oven performance. Carefully wipe with a damp cloth
any food spatters from the surface of the cover
immediately after they occur. Built-up splashes may
overheat and cause smoke or possibly catch fire. DO
NOT REMOVE THE WAVEGUIDE COVER.
NOTE :
• Do not spray or pour liquid cleansers directly onto a surface. Spray or pour cleanser onto a cloth or sponge and
then clean.
• Do not use abrasive cleaners, oven cleaners, abrasive cleaning pads or steel wool, as they can scratch or dull
oven surfaces.
• Do not remove or insert knife around the stirrer cover to clean, it may damage the cover or affect the cooking
performance of your oven.
WARNING:
The oven should be cleaned regularly and any food deposits removed.
Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly result in a hazardous situation.
Disconnect the power cord before cleaning or leave the door open to inactivate the oven during cleaning.
CARE AND CLEANING
32
CARE AND CLEANING
THE EXHAUST FEATURE
The exhaust hood feature on your microwave oven is equipped with two metal filters which collect grease.
When the fan is being operated, air is drawn up through the filters and is then discharged through the venting
to the outside or through the charcoal filters if not vented to the outside.
REUSABLE GREASE FILTERS
The reusable grease filters should be cleaned at least once a month. Never operate the microwave without the
filters in place. In situations where flaming might occur on surfaces below the hood, filters will stop the entry of
flames into the unit.
TO REMOVE GREASE FILTER
To remove, slide them to the rear using the tabs. Pull down and out.
TO CLEAN GREASE FILTER
To clean grease filters, soak and then agitate filter in solution of hot water and detergent. Do not use ammonia
or ammonia products because they will darken the metal. Light brushing can be used to remove embedded
dirt. Rinse, shake and remove moisture before replacing.
TO REPLACE GREASE FILTER
To replace, slide the filters into the frame slots on the back of each opening. Press up and to the front to lock
into place.
METAL GREASE
FILTER
COOKTOP
LIGHT
METAL GREASE
FILTER
You can purchase Grease Filters from 1-800-BE-SHARP. Accessory Model # RK24 5.
33
CARE AND CLEANING
LIGHT REPLACEMENT
Cooktop Light
When replacing the cooktop light, make sure that you are wearing gloves to avoid injury from the heat of the
lamp.
Oven Light
When replacing the oven light, make sure that you are wearing gloves to avoid injury from the heat of the
light.
1. Disconnect the main power supply；
2. Remove the 7 screws from the Baseplate;
1. Disconnect power to your microwave at the circuit
breaker or by unplugging it.
2. Remove the vent grille mounting screws from the
top center of the vent grille, then push down on
the tabs at
3. Pull the vent grille away from the unit.
Vent grille mounting screws
Vent grille
3. Unplug the wire harness of LED plate lamp
4. Take out LED Cover
5. Remove screw from Cover and replace LED plate lamp
6. Reassemble LED cover on the Baseplate
7. Insert the wire harness again
8. Relock the 7 screws on the Baseplate;
Reconnect
the main power supply.
9 .
34
CARE AND CLEANING
5. Open the light cover by removing the light cover
screw, then carefully pull up on the front edge.
7. Replace the microwave light cover by carefully
pushing it into place, then replace the mounting
screws.
8. Push the vent grille back into place and replace
the vent grille mounting screws.
Light cover screw
Light cover
Vent grille
4. Remove the charcoal lter.
Charcoal lter
6. Unplug the wire harness of the lamp, remove
the old light bulb, and replace it.
35
INSTALL/REPLACE CHARCOAL FILTER
Charcoal Filter
If your oven is vented to the inside, the charcoal filter should be replaced if it is used for approximately
6 months.
CARE AND CLEANING
1. Unplug the oven or turn off the power at the main
power supply.
2. Remove the grille air mounting 2 screws and open
the door.
3. Slide the grille air to the left, then pull it straight out.
4. Push the charcoal lter backwards and remove it.
5. Slide a new charcoal lter into place.
6. Replace the grille air and 2 screws and close the
door.
7. Plug the oven in or turn on the power at the main
power supply.
Vent grille mounting screws
Vent grille
Charcoal lter
You can purchase Charcoal Filter from 1-800-BE-SHARP. Accessory Model # RK233.
36
BEFORE YOU CALL
If nothing on the oven operates:
• Check for a blown circuit fuse or a tripped main circuit
breaker.
• Check if oven is properly connected to electric circuit
in house.
• Check that controls are set properly.
• Check that the cooking time is set.
If the oven interior light does not work:
• The LED light may be loose or defective. See page 33
or call 1-800-BE-SHARP.
If oven will not cook:
• Check that control panel was programmed correctly.
• Check that door is firmly closed.
• Check that START/+30 SEC pad was pressed.
• Auto Start may have been set.
• The Control Lockout may have been set
• Check the area between the door and seal for
obstructions.
If oven takes longer than normal to cook or cooks
too rapidly:
• Be sure the Power Level is programmed properly.
• Check instructions on food density, etc.
• Verify that voltage to the microwave oven is not low.
If the time-of-day clock does not always keep
correct time:
• Check that the power cord is fully inserted into the
outlet receptacle.
• Check that the oven is properly grounded.
• Try plugging the oven into an outlet on a separate
electrical circuit.
If oven floor or glass tray are hot:
• This is normal. The floor is absorbing heat from the
food.
If the interior of oven collects moisture:
• This is normal. Food gives off moisture when cooking
and the steam collects on the door and the oven
surface. Wipe off excess moisture from oven after
each use.
If food cooks unevenly:
• Refer to your recipe for proper cooking procedures.
• Be sure food is evenly shaped.
• Be sure food is completely defrosted before cooking.
• Check placement of aluminum strips used to prevent
overcooking.
If food is undercooked:
• Check recipe to be sure all directions (amount, time,
and power levels) were correctly followed.
• Check household voltage.
• Try plugging the oven into an outlet on a separate
electrical circuit.
• Be sure food was completely defrosted before
cooking.
If food is overcooked:
• Check recipe to be sure all directions (amount, time,
and power levels) were correctly followed.
• The initial temperature of food may have been higher
than normal.
If arcing (sparks) occur:
• Be sure microwave-safe dishes were used.
• Be sure wire twist ties were not used.
• Be sure oven was not operated when empty.
If the display shows a time counting down but the
oven is not cooking:
• Check that door is firmly closed.
Check the following to be sure a service call is necessary:
37
* Q : I accidentally ran my microwave oven without
any food in it. Is it damaged?
* A : Running the oven empty for a short time will not
damage the oven. However, it is not
recommended.
* Q : Can the oven be used with the glass tray or
roller guide removed?
* A : No. Both the glass tray and roller guide must
always be used in the oven before cooking.
* Q : Can I open the door when the oven is
operating?
* A : The door can be opened anytime during the
cooking operation. Then microwave energy will be
instantly switched off and the time setting will
maintain until the door is closed.
* Q : What does "Er01" message mean?
* A : "Er01" means SENSOR ERROR and will appear if
you open the oven door or press STOP/CLEAR
pad while cooking times is displayed. To continue
cooking, press the STOP/CLEAR pad and cook
manually.
* Q : Why do I have moisture in my microwave oven
after cooking?
* A : The moisture on the side of your microwave oven
is normal. It is caused by steam from cooking food
hitting the cool oven surface.
* Q : Will the microwave oven be damaged if it
operates while empty?
* A : Yes. Never run it empty.
* Q : Why do eggs sometimes pop?
* A : When baking or poaching eggs, the yolk may pop
due to steam build-up inside the yolk membrane.
To prevent this, simply pierce the yolk with a
toothpick before cooking. Never cook eggs without
piercing their shells.
* Q : Why is this standing time recommended after
the cooking operation has been completed?
* A : Standing time is very important.
With microwave cooking, the heat is in the food,
not in the oven. Many foods build up enough
internal heat to allow the cooking process to
continue, even after the food is removed from the
oven. Standing time for joints of meat, large
vegetables and cakes is to allow the inside to cook
completely, without overcooking the outside.
* Q : What does “standing time” mean?
* A : “Standing time” means that food should be
removed from the oven and covered for additional
time to allow it to finish cooking.
* Q : Why does my oven not always cook as fast as
the microwave cooking guide says?
* A : Check your cooking guide again, to make sure
you’ve followed directions exactly; and to see
what might cause variations in cooking time.
Cooking guide times and heat settings are
suggestions, to help prevent over-cooking. The
most common problem in getting used to a
microwave oven.
Variations in the size, shape and weights and
dimensions could require longer cooking time. Use
your own judgement along with the cooking guide
suggestions to check whether the food has been
properly cooked just as you would do with a
conventional cooker.
* Q : Does microwave energy pass through the
viewing screen in the door?
* A : No. The metal screen bounces back the energy to
the oven cavity. The holes are made to allow light
to pass through. They do not let microwave energy
pass through.
* Q : Can I operate my microwave oven without the
turntable or turn the turntable over to hold a
large dish?
* A : No. If you remove or turn over the turntable, you will
get poor cooking results. Dishes used in your oven
must fit on the turntable.
* Q : Is it normal for the turntable to turn in either
direction?
* A : Yes. The turntable rotates clockwise or
counterclockwise, depending on the rotation of the
motor when the cooking cycle begins.
* Q : Can I pop popcorn in my microwave oven?
How do I get the best results?
* A : Yes. Pop packaged microwave popcorn following
manufacture’s guidelines. Do not use regular paper
bags. Use the “listening test” by stopping the oven
as soon as the popping slows to a “pop” every 1
or 2 seconds. Do not repop unpopped kernels. Do
not pop popcorn in glass cookware.
QUESTIONS AND ANSWERS
38
UTENSIL GUIDE
Only use utensils that are suitable for use in microwave ovens.
To cook food in the microwave oven, the microwave must be able to penetrate the food, without being
reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is
marked microwave-safe, you do not need to worry. The following table lists various utensil and indicates
whether and how they should be used in a microwave oven.
● : Recommended use
▲ : Limited Use
✕ : Not Recommended
COOKING INSTRUCTIONS
UTENSIL SAFE COMMENTS
Aluminium Foil ▲ Can be used in small quantities to protect areas against
overcooking. Arcing can occur if the foil is too close to
the oven wall or if too much foil is used.
Crisp Plate ● Do not preheat for more than 8 minutes.
China and Earthenware ● Porcelain, pottery, glazed earthenware and bone china
are usually suitable, unless decorated with a metal trim.
Disposable Polyester
Cardboard Dishes
● Some frozen foods are packaged in these dishes.
Fast-Food Packaging
• Polystyrene Cups Containers
• Paper Dags or Newspaper
• Recycled Paper or Metal Trims
●
✕
✕
Can be used to warm food. Overheating may cause the
polystyrene to melt.
May catch fire.
May cause arcing.
Glassware
• Oven-To-Table Ware
• Fine Glassware
• Glass Jars
●
●
●
Can be used, unless decorated with a metal trim.
Can be used to warm foods or liquids.
Delicate glass may break or crack if heated suddenly.
Must remove the lid. Suitable for warming only.
Metal
• Dishes
• Freezer Bag Twist Ties
✕
✕
May cause arcing or fire.
Paper
• Plates, Cups, Napkins and Kitch-
en Paper
• Recycled Paper
●
✕
For short cooking times and warming. Also to absorb
excess moisture.
May cause arcing.
Plastic
• Containers
• Cling Film
• Freezer Bags
●
●
▲
Particularly with heat-resistant thermoplastic. Some
other plastics may warp or discolour at high
temperatures. Do
not use Melamine plastic.
Can be used to retain moisture. Should not touch the
food.
Take care when removing the film as hot steam will
escape.
Only if boilable or oven-proof. Should not be airtight.
Prick with a fork, if necessary.
Wax or Grease-Proof Paper ● Can be used to retain moisture and prevent spattering.
39
ARCING
If you see arcing, open the door and correct the problem.
Arcing is the microwave term for sparks in the oven.
Arcing is caused by:
• Metal or foil touching the side of the oven.
• Foil not molded to food (upturned edges act like
antennas).
• Metal, such as twist-ties, poultry pins, or gold rimmed
dishes, in the microwave.
• Recycled paper towels containing small metal pieces
being used in the microwave.
• Dirt or grease on waveguide cover.
USE YOUR MICROWAVE OVEN SAFELY
Food
General UseGeneral Use
COOKING INSTRUCTIONS
Do not attempt to defeat or tamper with safety
interlocks.
Do not place any object between the oven front frame
and the door or allow residue to build up on sealing
surfaces. Wipe with a mild detergent, rinse and dry.
Never use abrasive powders or pads.
Do not subject the oven door to strain or weight such as
a child hanging on an open door.
This could cause the oven to fall forward resulting in
injury to you and damage to the oven.
Do not operate the oven if door seals or sealing surfaces
are damaged; or if door is bent; or if hinges are loose or
broken.
Do not operate the oven empty. This will damage the
oven.
Do not attempt to dry clothes, newspapers or other
materials in the oven. They may catch on fire.
Do not use recycled paper products as they may
contain impurities which may cause sparks or fires.
Do not hit or strike the control panel with hard objects.
This can damage the oven.
Do not attempt to defeat or tamper with safety
interlocks.
Do not place any object between the oven front frame
and the door or allow residue to build up on sealing
surfaces. Wipe with a mild detergent, rinse and dry.
Never use abrasive powders or pads.
Do not subject the oven door to strain or weight such as
a child hanging on an open door.
This could cause the oven to fall forward resulting in
injury to you and damage to the oven.
Do not operate the oven if door seals or sealing surfaces
are damaged; or if door is bent; or if hinges are loose or
broken.
Do not operate the oven empty. This will damage the
oven.
Do not attempt to dry clothes, newspapers or other
materials in the oven. They may catch on fire.
Do not use recycled paper products as they may
contain impurities which may cause sparks or fires.
Do not hit or strike the control panel with hard objects.
This can damage the oven.
Never use your microwave oven for home canning. The
oven is not designed for proper home canning.
Improperly canned food may spoil and be dangerous to
consume.
Always use the minimum recipe cooking time. It is better
to undercook rather than overcook foods.
Undercooked foods can be returned to the oven for
more cooking. If food is overcooked, nothing can be
done.
Heat small quantities of food or foods with low moisture
carefully. These can quickly dry out, burn or catch on
fire.
Do not heat eggs in the shell. Pressure may build up and
eggs can explode.
Potatoes, apples, egg yolks and sausages are examples
of food with non-porous skins.
These must be pierced before cooking to prevent
bursting.
Do not attempt to deep fat fry in your microwave oven.
Always allow a standing time of at least 20 seconds after
the oven has been switched off to allow the temperature
to even out, stir during heating, if necessary, and
ALWAYS stir after heating. To prevent eruptive boiling
and possible scalding, you should put a spoon or glass
stick into the beverages and stir before, during and after
heating.
Do not leave the oven unattended while popping corn.
Do not pop corn in a paper bag unless it is the
commercially prepared Microwave Popcorn product.
The kernels can overheat and ignite a brown paper bag.
Do not exceed the Microwave Popcorn manufacturers
suggested popping time.
Longer popping does not yield more popcorn but it can
result in scorch, burn or fire. Remember, the Popcorn
bag and tray can be too hot to handle. Remove with
caution and use pot holders.
40
The microwaves cause the water molecules to vibrate
which causes FRICTION, i.e. HEAT. This heat then
cooks the food. Microwaves are also attracted to fat and
sugar particles, and foods high in these will cook more
quickly. Microwaves can only penetrate to a depth of 1½
- 2 inches(4-5cm) and as heat spreads through the food
by conduction, just as in a traditional oven, the food
cooks from the outside inwards.
Then they pass through the
cooking containers to be
absorbed by the water
molecules in the food, all
foods contain water to a
more or lesser extent.
MICROWAVING PRINCIPLES
Microwave energy has been used in this country to cook and reheat food since early experiments with RADAR in
World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade sources.
Manmade sources include radar, radio, television, telecommunication links and car phones.
CONVERSION CHARTS
HOW MICROWAVES COOK FOOD
In a microwave oven,
electricity is converted
into microwave by the
MAGNETRON.
The microwaves bounce
off the metal walls and
the metal door screen.
Oven Cavity
Magnetron
Waveguide
Turntable
REFLECTION
TRANSMISSION
ABSORPTION
Microwave Water Molecule Absorption Vibration
COOKING INSTRUCTIONS
FLUID MEASUREMENTS
1 Cup = 8 fl.oz = 240 ml
1 Pint = 16 fl.oz. (UK 20 fl.oz.) = 480 ml (UK 560 ml)
1 Quart = 32 fl.oz. (UK 40 fl.oz.) = 960 ml (UK 1120 ml)
1 Gallon = 128 fl.oz. (UK 160 fl.oz.) = 3840 ml (UK 4500 ml)
WEIGHT MEASURES
15 g 1/2 oz.
25 g 1 oz.
50 g 2 oz.
100 g 4 oz.
175 g 6 oz.
225 g 8 oz.
450 g 1 lb.
VOLUME MEASURES
30 ml 1 fl.oz.
100 ml 3 fl.oz.
150 ml 5 fl.oz. (1/4 pt)
300 ml 10 fl.oz. (1/2 pt)
600 ml 20 fl.oz. (1pt)
SPOON MEASURES
1.25 ml 1/4 tsp
2.5 ml 1/2 tsp
5 ml 1 tsp
15 ml 1 tbsp
41
STANDING TIME
Dense foods e.g. meat, jacket potatoes and cakes,
require standing time (inside or outside of the oven) after
cooking, to allow heat to finish conducting to cook the
center completely. Wrap meat joints and jacket potatoes
in aluminium foil while standing. Meat joints need
approx. 10-15 minutes, jacket potatoes 5 minutes.
Other foods such as plated meal, vegetables, fish etc
require 2-5 minutes standing. After defrosting food,
standing time should also be allowed. If food is not
cooked after standing time, return to the oven and cook
for additional time.
MOISTURE CONTENT
Many fresh foods e.g. vegetables and fruit, vary in their
moisture content throughout the season, particularly
jacket potatoes. For this reason cooking times may have
to be adjusted. Dry ingredients e.g. rice, pasta, can dry
out during storage so cooking times may differ.
DENSITY
Porous airy foods heat more quickly than dense heavy
foods.
CLING FILM
Cling film helps keep the food moist and the trapped
steam assists in speeding up cooking times. Pierce
before cooking to allow excess steam to escape.
Always take care when removing cling film from a dish
as the build-up of steam will be very hot.
SHAPE
Even shapes cook evenly. Food cooks better by
microwave when in a round container rather than
square.
SPACING
Foods cook more quickly and evenly if spaced apart.
NEVER pile foods on top of each other.
STARTING TEMPERATURE
The colder the food, the longer it takes to heat up. Food
from a fridge takes longer to reheat than food at room
temperature.
LIQUIDS
All liquids must be stirred before and during heating.
Water especially must be stirred before and during
heating, to avoid eruption. Do not heat liquids that have
previously been boiled. DO NOT OVERHEAT.
TURNING & STIRRING
Some foods require stirring during cooking. Meat and
poultry should be turned after half the cooking time.
ARRANGING
Individual foods e.g. chicken portions or chops, should
be placed on a dish so that the thicker parts are towards
the outside.
QUANTITY
Small quantities cook faster than large quantities, also
small meals will reheat more quickly than large portions.
PIERCING
The skin or membrane on some foods will cause steam
to build up during cooking. These foods must be
pierced or a strip of skin should be peeled off before
cooking to allow the steam to escape. Eggs, potatoes,
apples, sausages etc, will all need to be pierced before
cooking. DO NOT ATTEMPT TO BOIL EGGS IN THEIR
SHELLS.
COVERING
Cover foods with microwave cling film or a lid. Cover
fish, vegetables, casseroles, soups. Do not cover cakes,
sauces, jacket potatoes or pastry items.
COOKING TECHNIQUES
COOKING INSTRUCTIONS
42
DEFROSTING GUIDE
▶ Do not defrost covered meat. Covering might allow
cooking to take place. Always remove outer wrap and
tray. Use only containers that are microwave-safe.
▶ Begin defrosting whole poultry breast-side-down.
Begin defrosting roasts fat-side-down.
▶ The shape of the package alters the defrosting time.
Shallow rectangular shapes defrost more quickly than
a deep block.
▶ After
1
/3 of the defrost time has elapsed, check the
food. You may wish to turn over, break apart, rearrange
or remove thawed portions of the food.
▶ During defrost, the oven will prompt you to turn the
over. At this point, open oven door and check the
food. Follow the techniques listed below for optimum
defrost results.
Then, close oven door, press the START pad to
complete defrosting.
▶ When defrosted, food should be cool, but softened in
all areas. If still slightly icy, return to microwave oven
very briefly, or let stand a few minutes. After
defrosting, allow food to stand 5-60 minutes if there
are any icy areas.
Poultry and fish may be placed under running cool
water until defrosted.
➪ Turn over : Roast, ribs, whole poultry, turkey breasts,
hot dogs, sausages, steaks, or chops.
➪ Rearrange : Break apart or separate steaks, chops,
hamburger patties, ground meat, chicken or seafood
pieces, chunks of meat such as stew beef.
➪ Shield : Use small strips of aluminum foil to protect
thin areas or edges of unevenly shaped foods such
as chicken wings. To prevent arcing, do not allow foil
to come within 1-inch of oven walls or door.
➪ Remove : To prevent cooking, thawed portions
should be removed from the oven at this point. This
may shorten defrost time for food weighing less than
3 lbs.(1350g).
DEFROSTING CHART (by Time Defrost)
COOKING INSTRUCTIONS
ITEM & WEIGHT
DEFROSTING
TIME
STANDING
TIME
SPECIAL TECHNIQUES
BEEF
Minced beef
1 lb./450g 8-10 min. 15-20 min.
Break apart and remove thawed portions
with fork.
Stew Meat
1 1/2 lbs./675g 12-14 min. 25-30 min. Separate and rearrange on
Patties
4(4oz./110g) 6-8 min. 15-20 min. Turn over after half the time.
PORK
1 lb./450g 6-8 min. 25-30 min. Separate and rearrange once.
Chops
4(5oz./125g) 6-8 min. 25-30 min. Separate and turn over once.
Minced pork
1 lb./450g 7-8min. 15-20 min.
Break apart and remove thawed portions
with fork.
POULTRY
Whole Chicken
2 1/2 lbs./1125g 22-24 min. 45-90 min.
Break side down. Turn over after half the
time. Shield as needed.
Chicken Breasts
1 lbs./450g 8-10 min. 15-30 min. Separate and rearrange once.
Fried Chicken(cut up)
2 lbs./900g 17-19 min. 25-30 min. Separate and rearrange once.
Chicken Thighs
1 1/2 lbs./675g 12-14 min. 15-30 min. Separate and rearrange once.
FISH & SEAFOOD
Whole Fish
1 lb./450g 6-8 min. 15-20 min.
Turn over after half the time.
Shield as needed.
Fish Fillets
1 1/2 lb./675g 8-10 min. 15-20 min.
Turn over after half the time.
Shield as needed.
Shrimp
1/2 lb./225g 2-3 min. 15-20 min.
Turn over after half the time.
Shield as needed.
Spare Ribs
43
COOKING INSTRUCTIONS
COOKING & REHEATING CHART
Cooking chart
ITEM POWER LEVEL
COOKING TIME
PER LB./450G
SPECIAL INSTRUCTION
MEAT
Beef joint - Rare
- Medium
- well done
Pork Joint
Bacon joint
6-8 min.
7-10 min.
9-11 min.
9-12 min.
5-7 min.
- Chilled meat and poultry should be
removed from the refrigerator at least
30 minutes before cooking.
- Always let the meat and poultry stand,
covered after cooking.
POULTRY
Whole chicken
Portions chicken
Breast (boned)
4-9 min.
5-7 min.
6-8 min.
FISH
Fish Fillets
Whole Mackerel, Cleaned
and prepared
Whole Trout, Cleaned
& Prepared
Salmon steaks
3-5 min.
3-5 min.
4-6 min.
4-6 min.
- Brush a little oil or melted butter over
the fish, or add 15~30ml(1-2 tbsp)
lemon juice, wine, stock, milk or water.
- Always let the fish stand, covered,
after cooking
NOTE : The above times should be regarded only as a guide. Allow for difference in individual tastes and preferences.
The times may vary due to the shape, cut, and composition of the food. Frozen meat, poultry and
fish must be thoroughly thawed before cooking.
PL-80
PL-80
PL-80
PL-Hi
PL-Hi
PL-Hi
PL-80
PL-80
PL-Hi
PL-Hi
PL-Hi
PL-Hi
44
Reheating chart
• Baby food particularly needs to be checked carefully before serving to prevent burns.
• When heating pre-packaged ready-cooked foods, always follow the pack instructions carefully.
• If you freeze foods which were bought from the fresh or chilled counters, remember that they should be thoroughly
thawed before following the heating instructions on the packed. It’s worth putting a note on them so that other
members of the household will remember too.
• Remember to remove metal ties and transfer food from foil containers before reheating.
• Chilled (refrigerated) food takes longer to reheat than food at room temperature (such as just-cooled food or food
from the store cupboard).
• All foods should be reheated using full microwave power.
COOKING & REHEATING CHART
COOKING INSTRUCTIONS
ITEM COOKING TIME SPECIAL INSTRUCTIONS
Baby food
4.5oz.
20 sec. Empty into a small serving bowl.
Stir well once or twice during heating.
Before serving, check the temperature carefully.
Baby milk
100ml / 4fl.oz.
225ml / 8fl.oz.
20-30 sec.
40-50 sec.
Stir or shake well and pour into a sterilized bottle.
Before serving, shake well and check the temperature care-
fully.
Sandwich roll or bun
1 roll 20-30 sec. Wrap in paper towel and place on glass microwaveable
rack.
*Note: Do not use recycled paper towels.
Lasagna
1 serving
(10 ½ oz./300g)
4-6 min. Place lasagna on microwaveable plate.
Cover with plastic wrap and vent.
Casserole
1 cup
4 cups
1 ½-3 min.
5-7 min.
Cook covered, in microwaveable casserole.
Stir once halfway through cooking.
Mashed potatoes
1 cup
4 cups
2-3 min.
6-8 min.
Cook covered, in microwaveable casserole.
Stir once halfway through cooking.
Baked beans
1 cup 2-3 min. Cook covered, in microwaveable casserole.
Stir once halfway through cooking.
Ravioli or pasta in sauce
1 cup
4 cups
2-3 min.
6-9 min.
Cook covered, in microwaveable casserole.
Stir once halfway through cooking.
45
Cooking Guide for fresh vegetables
Cooking Guide for frozen vegetables
Use a suitable glass pyrex bowl with lid. Add 30-45ml cold water (2-3 tbsp.) for every 250g unless another water
quantity is recommended - see table. Cook covered for the minimum time - see table.
Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or butter after
cooking. Cover during a standing time of 3 minutes.
Hint : cut the fresh vegetables into even sized pieces. The smaller they are cut, the quicker they will cook.
All vegetables should be cooked using full microwave power.
VEGETABLE CHART
COOKING INSTRUCTIONS
VEGETABLES WEIGHT TIME COMMENTS
Broccoli ½ lb./250g
1 lb./500g
3-5 min
6-8 min
Prepare even sized florets.
Arrange the stems to the centre.
Brussels sprouts ½ lb./250g
3-5 min Add 60-75ml(4-5 tbsp.) water.
Carrots ½ lb./250g 3-5 min Cut carrots into even sized slices.
Cauliflower ½ lb./250g
1 lb./500g
3-5 min
6-8 min
Prepare even sized florets. Cut big florets into halves.
Arrange stems to the center.
Zucchini ½ lb./250g 3-4 min Cut Zucchini into slices. Add 30ml(2tbsp.) water or a
knob of butter. Cook until just tender.
Aubergine
(eggplant)
½ lb./250g 3-4 min Cut
tablespoon lemon juice.
Leeks ½ lb./250g 3-4 min Cut leeks into thick slices.
Mushrooms 0.3 lb./125g
½ lb./250g
2-3 min
3-4 min
Prepare small whole or sliced mushrooms. Do not add
any water. Sprinkle with lemon juice. Spice with salt and
pepper. Drain before serving.
Onions ½ lb./250g 2-3 min Cut onions into slices or halves. Add only 15ml(1tbsp.)
water.
Pepper ½ lb./250g 2-4 min Cut pepper into small slices.
Potatoes ½ lb./250g
1 lb./500g
4-5 min
6-8 min
Weigh the peeled potatoes and cut them into similar
sized halves or quarters.
Turnip cabbage ½ lb./250g 4-6 min Cut turnip cabbage into small cubes.
VEGETABLES WEIGHT TIME INSTRUCTIONS
Spinach 0.3 lb./125g 2-3 min Add 15ml(1tbsp.) cold water.
Broccoli ½ lb./250g 4-5 min Add 30ml(2 tbsp.) cold water.
Peas ½ lb./250g 4-5 min Add 15ml(1 tbsp.) cold water.
Green beans ½ lb./250g 4-5½ min Add 30ml(2 tbsp.) cold water.
Mixed vegetables
(carrots/peas/corn)
½ lb./250g 4-5 min Add 15ml(1 tbsp.) cold water.
Mixed vegetables
(Chinese style)
½ lb./250g 4-6 min Add 15ml(1 tbsp.) cold water.
eggplant into small slices and sprinkle with 1
46
RECIPES
COOKING INSTRUCTIONS
TOMATO & ORANGE SOUP
1 oz.(25g) butter
1 medium onion, chopped
1 large carrot & 1 large potato, chopped
13/4lb(800g) canned, chopped tomatoes
juice and grated rind of 1 small orange
11/2pints(900ml) hot vegetable stock
salt and pepper to taste
1. Melt the butter in a large bowl on PL-Hi for 30 seconds.
2. Add the onion, carrot and potato and cook on PL-Hi for
4 minutes. stir halfway through cooking.
3. Add the tomatoes, orange juice, orange rind and stock.
Mix thoroughly. Season with salt and pepper to taste.
Cover the bowl and cook on PL-Hi for 15 minutes. stir
2-3 times during cooking, until the vegetables are
tender.
4. Blend and serve immediately.
FRENCH ONION SOUP
1 large onions, sliced
1 tbsp (15ml) corn oil
2 oz.(50g) plain flour
2 pints(1.2 liters) hot meat
or vegetable stock
salt and pepper to taste
2 tbsp (30ml) parsley, chopped
4 thick slices French bread
2 oz.(50g) cheese, grated
1. Place the onion and oil a bowl, mix well and cook on
PL-Hi for 1 minutes.
2. Stir in the flour to make a paste and gradually add
stock. Season and add the parsley.
3. Cover the bowl and cook on PL-70 for 16 minutes.
4. Pour the soup into serving bowls, submerge bread and
sprinkle generously with cheese.
5. Cook on PL-70 for 2 minutes, until the cheese has
melted.
STIR FRIED VEGETABLES
1 tbsp(15ml) sunflower oil
2 tbsp (30ml) soy sauce
1 tbsp (15ml) sherry
1"(2.5cm) root ginger,
peeled and finely grated
2 medium carrots, cut into fine strips
4 oz.(100g) button mushrooms,
chopped
2 oz.(50g) beansprouts
4 oz.(100g) mange-tout
1 red pepper, seeded and thinly sliced
4 spring onions, chopped
4 oz.(100g) canned water chestnuts,
sliced
1/4 head of chinese leaves, thinly sliced
1. Place the oil, soy sauce, sherry, ginger, garlic and
carrots in a large bowl, mix thoroughly
2. Cover and cook on PL-Hi for 3-5 minutes, stirring once.
3. Add the button mushrooms, beansprouts, mange-tout,
red pepper, spring onions, water chestnuts and chinese
leaves. Mix thoroughly.
4. Cook on PL-Hi for 5-6 minutes, until the vegetables are
tender. Stir 2-3 times during cooking.
Stir fried vegetables are ideally served with meat or
fish.
HONEYED CHICKEN
4 boneless chicken breasts
2 tbsp(30ml) clear honey
1 tbsp(15ml) whole grain mustard
1/2 tsp(2.5ml) dried tarragon
1 tbsp(15ml) tomato puree
1/4 pint(150ml) chicken stock
1. Place the chicken breasts in a casserole dish.
2. Mix all remaining ingredients together and pour over the
chicken. Salt and pepper to taste.
3. Cook on PL-Hi for 13-14 minutes. Rearrange and coat
the chicken with the sauce twice during cooking.
47
COOKING INSTRUCTIONS
BLUE CHEESE & CHIVE JACKETS
2 baking potatoes,
(approx.9 oz.(250g) each)
2 oz.(50g) butter
4 oz.(100g) blue cheese, chopped
1 tbsp(15ml) fresh chives, chopped
2 oz.(50g) mushrooms, sliced
salt and pepper to taste
1. Prick each potato in several places. Cook on PL-Hi for
7-9 minutes. Halve and scoop the flesh into a bowl, add
the butter, cheese, chives, mushrooms, salt and
pepper, mix thoroughly.
2. Pile mixture into the potato skins and place in a flat
dish.
3. Cook on PL-50 for 10 minutes.
WHITE SAUCE
1 oz.(25g) butter
1 oz.(25g) plain flour
1/2 pint(300ml) milk
salt and pepper to taste
1. Place the butter in a bowl and cook on PL-Hi for 30
seconds, until melted.
2. Stir in the flour and whisk in the milk. Cook on PL-Hi for
3-4 minutes, stirring every 2 minutes until thick and
smooth. Season with salt and pepper to taste.
STRAWBERRY JAM
11/2 lb.(675g) strawberries, hulled
3 tbsp(45ml) lemon juice
11/2 lb.(675g) caster sugar
1. Place strawberries and lemon juice in a very large bowl,
heat on PL-Hi for 4 minutes, or until the fruit has
softened. Add sugar, mix well. Without covered.
2. Cook on PL-70 for 20-25 minutes, until setting point*is
reached, stir every 4-5 minutes.
3. Pour into hot, clean jars. Cover, seal and label.
* setting point : To determine setting point, place 1 tsp(5ml)
jam onto chilled saucer. Allow to stand for 1 minute.
Move surface of jam gently with your finger, if the surface
wrinkles setting point has been reached.
PLAIN MICROWAVE CAKE
4 oz.(100g) margarine
4 oz.(100g) sugar
1 eggs
4 oz.(100g) self raising flour, sifted
2-3 tbsp(30-45ml) milk
1. Line the base of 8" (20.4cm) cake dish with grease-proof
paper.
2. Cream the margarine and sugar together until light and
fluffy. Beat in the eggs and fold in the sifted flour
alternately with the milk.
3. Pour into prepared container. Cook on PL-Hi for 4-5
minutes, until a skewer comes out cleanly.
4. Leave the cake to stand for 5 minutes before turning
out.
OMELETTE
1/2 oz.(15g) butter
4 eggs
6 tbsp(90ml) milk
salt & pepper
1. Whisk together eggs and milk.
2. Place butter in 10"(26cm) flan dish. Cook on PL-Hi for
30 seconds, until melted. Coat the dish with the melted
butter.
3. Pour omelette mixture into flan dish. Cook on PL-Hi for
2 minutes. whisk mixture and cook again on PL-Hi for 1
minutes.
48
SCRAMBLED EGG
1/2 oz.(15g) butter
2 eggs
2 tbsp(30ml) milk
salt & pepper
1. Melt the butter in a bowl on PL-Hi for 30 seconds.
2. Add the eggs, milk and seasoning and mix well.
3. Cook on PL-Hi for 3 minutes, stirring every 30 seconds.
SAVORY MINCE
1 small onion, diced
1 clove garlic, crushed
1 tsp(5ml) oil
7 oz.(200g) can chopped tomatoes
1 tbsp(15ml) tomato puree
1 tsp(5ml) mixed herbs
8 oz.(225g) minced beef
salt and pepper
1. Place onion, garlic and oil in casserole, and cook on
PL-Hi for 2 minutes or until soft.
2. Place all other ingredients in casserole. Stir well.
3. Cover and cook on PL-Hi for 5 minutes then PL-50 for
8-13 minutes or until the meat is cooked.
COOKING INSTRUCTIONS
49
SHARP ELECTRONICS CORPORATION
100 Paragon Drive, Montvale, NJ 07645
