User manual
Register your product and get support at
www.philips.com/support
TAB8907
8000 Series
Soundbar
2 EN
Contents
Safety 3
Care for your product 4
Care of the environment 4
Declaration of conformity 5
Help and support 5
FCC information 6
2 Your Soundbar 7
What’s in the box 7
Soundbar 7
Connectors 8
Wireless subwoofer 9
Remote control 9
Prepare the remote control 10
Placement 11
Wall mount 12
3 Connect 13
Dolby Atmos® 13
Connect to HDMI socket 13
Connect to Optical in socket 14
Connect to Audio in socket 14
Connect to power 15
Pair up with the subwoofer 15
Connect to Wi-Fi
(Wireless operation) 16
Connect the soundbar to Philips
Play- enabled TV 18
4 Use your soundbar 19
Turn ON and OFF 19
Select modes 20
Adjust the volume 20
Enjoy Dolby Atmos sound 20
Setup menu 20
Play from Bluetooth devices 23
Listen to an external device 23
Play audio through USB 24
Factory reset 24
1 Important safety instructions 3
6 Troubleshooting 27
Trademarks: 29
5
Product specications
25
3EN
1 Important
safety
instructions
Read and understand all instructions
before you use your product. If damage is
caused by failure to follow instructions, the
warranty does not apply.
Safety
Know these safety symbols
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This is CLASS II apparatus with
double insulation, and no
protective earth provided.
AC voltage
Follow the instructions in the user
manual!
WARNING!
Warning: Risk of electric shock!
The exclamatory mark is intended
to alert the user to the presence of
important operating instructions.
Risk of electric shock or re!
• Before you make or change any
connections, make sure that all
devices are disconnected from the
power outlet.
• Never expose the product and
accessories to rain or water. Never
place liquid containers, such as vases,
near the product. If liquids are spilt on
or into the product, disconnect it from
the power outlet immediately. Contact
Consumer Care to have the product
checked before use.
• Never place the product and
accessories near naked ames or other
heat sources, including direct sunlight.
• Never insert objects into the
ventilation slots or other openings
on the product.
• Where the mains plug or an
appliance coupler is used as the
disconnect device, the disconnect
device shall remain readily operable.
• Battery (battery pack or batteries
installed) shall not be exposed to
excessive heat such as sunshine, re
or the like.
• Disconnect the product from the
power outlet before lightning storms.
• When you disconnect the power cord,
always pull the plug, never the cable.
• Use the product in tropical and/or
moderate climates.
Risk of short circuit or re!
• For identication and supply ratings,
see the type plate at the back or
bottom of the product.
• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on
the back or bottom of the product.
Never connect the product to the
power outlet if the voltage is dierent.
Risk of injury or damage to this
product!
• For wall mounting, this product must
be securely attached to the wall in
accordance with the installation
instructions. Use only the supplied
wall mount bracket (if available).
Improper wall mounting may result
in accident, injury or damage. If you
have any query, contact Consumer
Care in your country.
4 EN
• Never place the product or any
objects on power cords or on other
electrical equipment.
• If the product is transported in
temperatures below 5°C, unpack
the product and wait until its
temperature matches room
temperature before connecting it to
the power outlet.
• Parts of this product can be made
of glass. Handle with care to avoid
injury and damage.
Risk of overheating!
• Never install this product in a
conned space. Always leave a
space of at least four inches around
the product for ventilation. Ensure
curtains or other objects never cover
the ventilation slots on the product.
Risk of contamination!
• Do not mix batteries (old and new or
carbon and alkaine, etc.).
• CAUTION: Danger of explosion if
batteries are incorrectly replaced.
Replace only with the same or
equivalent type.
• Remove batteries if they are
exhausted or if the remote control is
not to be used for a long time.
• Batteries contain chemical
substances, they should be disposed
of properly.
Note
•
The rating label is pasted on the bottom or back
of the equipment.
Care for your product
Use only microber cloth to clean the
product.
Care of the environment
Disposal of your old product and
battery
Your product is designed and
manufactured with high quality
materials and components, which
can be recycled and reused.
This symbol on a product means
that the product is covered by
European Directive 2012/19/EU.
This symbol means that the
product contains batteries covered
by European Directive 2013/56/EU
which cannot be disposed of with
normal household waste.
Inform yourself about the local separate
collection system for electrical and
electronic products and batteries.
Follow local rules and never dispose of
the product and batteries with normal
household waste. Correct disposal
of old products and batteries helps
prevent negative consequences for the
environment and human health.
Removing the disposable batteries
To remove the disposable batteries, see
battery installation section.
5EN
EN
For 5G Wi-Fi Device
The device for operation in the
band 5150–5350 MHz is only for
indoor use to reduce the potential
for harmful interference to co-
channel mobile satellite systems.
FR
Pour un appareil Wi-Fi 5G
les dispositifs fonctionnant dans
la bande 5150-5350 MHz sont
réservés uniquement pour une
utilisation à l’intérieur an de
réduire les risques de brouillage
préjudiciable aux systèmes de
satellites mobiles utilisant les
mêmes canaux.
Declaration of conformity
This product complies with the radio
interference requirements of the
European community.
Hereby, MMD Hong Kong Holding
Limited declares that the product
is in compliance with the essential
requirements and other relevant
provisions of RED Directive 2014/53/EU
and UK Radio Equipment Regulations
SI 2017 No 1206. You can nd the
Declaration of Conformity on
www.philips.com/support.
Help and support
For extensive online support, visit
www.philips.com/support to:
• download the user manual and the
quick start guide
• watch video tutorials (available only
for selected models)
• nd answers to frequently answered
questions (FAQs)
• email us a question
• chat with our support representative.
Follow the instructions on the website
to select your language, and then enter
your product model number.
Alternatively, you can contact Consumer
Care in your country. Before you contact,
note down the model number and serial
number of your product. You can nd
this information on the back or bottom
of your product.
6 EN
FCC information
NOTE: This equipment has been tested
and found to comply with the limits
for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio
or television reception, which can be
determined by turning the equipment
o and on, the user is encouraged to
try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an
outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced
radio / TV technician for help.
FCC&IC Warning:
• This equipment should be installed
and operated with minimum
distance 20cm between the radiator
& your body.
• Changes or modications to this unit
not expressly approved by the party
responsible for compliance could
void the user’s authority to operate
the equipment.
FCC & IC Attention
• Cet appareil est conforme à FCC et
IC l’exposition aux rayonnements
limites xées pour un environnement
non contrôlé. Cet appareil doit être
installé et utilisé avec une distance
minimale de 20 cm entre le radiateur
et votre corps. Cet transmetteur ne
doit pas être co-situé ou opérant en
liaison avec toute autre antenne ou
transmetteur.
• Des câbles blindés doivent être
utilisés avec cet apparei l pour
assurer la conformité avec les
limites de la classe B de la FCC.
fonctionnement de I’appareil.
IC-Canada: CAN ICES-003(B)/NMB-003(B)
This device contains licence-exempt
transmitter(s) / receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence-exempt
RSS(s). Operation is subject to the
following two conditions:
1. This device may not cause
interference.
2. This device must accept any interference,
including interference that may cause
undesired operation of the device.
Avis d’Industrie Canada: CAN ICES-003(B)/
NMB-003(B)
L’émetteur/récepteur exempt de licence
contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences
et Développement économique Canada
applicables aux appareils radio exempts
de licence. L’exploitation est autorisée
aux deux conditions suivantes :
1. L’appareil ne doit pas produire de
brouillage;
2. L’appareil doit accepter tout
brouillage radioélectrique subi, même
si le brouillage est susceptible d’en
compromettre le fonctionnement.
7EN
2 Your Soundbar
Congratulations on your purchase,
and welcome to Philips! To fully
benet from the support that Philips
oers, register your soundbar at
www.philips.com/support.
What’s in the box
Check and identify the items in the
package:
• Soundbar x 1
• Remote control x 1
(AAA batteries x 2)
• Wireless subwoofer x 1
• Wall mount kit x 1
(Brackets x2 / Bracket screws x2 /
Wall mounting screws x2 / Wall anchors x2)
• Quick start guide / Warranty card /
Safety sheet x 1
• Wall mount template x 1
• Power cord* x 2
Remote control
(AAA batteries x 2)
Soundbar
Wireless subwoofer
Wall mount kit
(brackets x2 / bracket screws x2 /
wall mounting screws x2 / wall anchors x2)
2 X
2 X
2 X
Quick start guide
Warranty card/Safety sheet
Headphones
s
s
Series
CTN
Saf
ety I
n
formation
Wall mount
template
TAB8907/10TAB8907/37TAB8907/67TAB8907/93TAB8907/98
UL
for US/Canada for Thailand
TISI BS SAA
for Asia
VDEVDE BS
for Europe/UK for China
CCC
• Power cord quantity and plug type
vary by regions.
• Images, illustrations and drawings
shown on this User Manual are for
reference only, actual product may
vary in appearance.
Soundbar
This section includes an overview of the
soundbar.
1 2 3 4 5
6 87
1
- (Volume) button
Decrease the volume.
2
+ (Volume) button
Increase the volume.
3
(Play/Pause) button
Start, pause or resume play.
4
(Source)/Bluetooth pairing button
• Press to select an input source for
soundbar.
• In BT mode, press and hold for 3
seconds to disconnect from current
BT connected devices and enter the
Bluetooth pairing mode.
8 EN
5
(Standby-On) button
Power
state
Action Function
On Follow source state
Semi
standby
Press
the
button
once
• Wi-Fi is connected.
• It supports Play-
and Airplay2
Chromecast,
Spotify connect,
work with Alexa.
Eco
standby
Press
and
hold
3
seconds
• Wi-Fi is o.
• The product enters
the lower power
consumption mode.
• Restarting the
system will take a
relatively longer
time.
6
Power LED
• Turns white when in Eco standby
(network disconnected).
7
Remote control sensor /
Display panel
8
Wi-Fi LED
Wi-Fi LED indicator (Orange)
LED State Status
Blink
Wi-Fi Access Point (AP)
mode
Double blink
Wi-Fi Protected Setup
(WPS) mode
Constant on
Connected / Pairing
successful
Connectors
This section includes an overview of the
connectors available on your soundbar.
8
2
7
1 3 4 5 6
1
(Wi-Fi Setup) button
• Trigger Wi-Fi setup for Play-.
• Press and hold the button for 4
seconds to active the Wps mode.
• Press and hold the button for 8
seconds to active the AP mode.
2
HDMI out (eARC) socket
The port supports the eARC/ARC
HDMI feature, connect to the HDMI
(eARC) input on the TV.
3
HDMI in socket
Connect to an HDMI source device,
such as a DVD player, Blu-ray Disc™
player, or gaming console.
4
Audio in
Audio input from, for example, an
MP3 player (3.5mm jack).
5
USB
• Connect to a USB storage device for
audio media play.
• Upgrade software of this product.
6
Optical in socket
Connect to an optical audio output
on the TV or a digital device.
7
AC in socket
Connect to the power supply.
8
Wall bracket slot
9EN
Wireless subwoofer
This section includes an overview of the
wireless subwoofer.
abc
1
AC~ socket
Connect to the power supply.
2
Pair button
Press and hold to enter the pairing
mode for the subwoofer.
3
Subwoofer indicator
Determine the status based on the
wireless subwoofer indicator.
LED state Status
Fast blink Subwoofer in pairing mode
Constant on Connected / Pairing successful
Slow blink Connection / Pairing failed
Remote control
This section includes an overview of the
remote control.
1
(Standby-On) button
Power
state
Action Function
On Follow source state
Semi
standby
Press
the
button
once
• Wi-Fi is connected.
• It supports Play-
and Airplay2
Chromecast,
Spotify connect,
work with Alexa.
Eco
standby
Press
and
hold
3
seconds
• Wi-Fi is o.
• The product enters
the lower power
consumption mode.
• Restarting the
system will take a
relatively longer
time.
5
6
3
1
8
9
7
4
2
10 EN
2
(Source)
• Press to select an input source for
soundbar.
• In BT mode, press and hold for 3
seconds to disconnect from current
BT connected devices and enter the
Bluetooth pairing mode.
3
(Dolby Atmos)
Select a height eect level for Dolby
Atmos.
4
(Mute)
Mute or restore volume.
5
Navigation buttons
/ (Left/Right)
• Skip to the previous or next track in
USB/BT mode.
• Navigate Left/Right in menu
structure.
/ (Up/Down)
• Navigate up/down in menu structure.
(Center)
• Start, pause or resume play in USB/
BT mode.
• Conrm a selection.
6
(MENU)
Enter setup menu.
7
(Exit)
• Exit menu.
• Press and hold the button for 10
seconds to reset the Wi-Fi module
of soundbar to factory settings.
8
+/- (System’s volume)
Increase / decrease the system’s
volume.
9
+/- (Subwoofer’s volume)
Increase / decrease the subwoofer’s
volume.
Prepare the remote control
• The provided remote control allows
the unit to be operated from a
distance.
• Even if the remote control is
operated within the eective range
19.7 feet (6m), remote control
operation may be impossible if there
are any obstacles between the unit
and the remote control.
• If the remote control is operated
near other products which generate
infrared rays, or if other remote
control devices using infra-red rays
are used near the unit, it may operate
incorrectly. Conversely, the other
products may operate incorrectly.
Replace the remote control battery
Slide to remove the battery compartment
cover, insert 2 AAA batteries (1.5V) with
correct polarity, then slide the battery
compartment cover back into position.
• Make sure the (+) and (–) ends of
the batteries match the (+) and
(–) ends indicated in the battery
compartment.
1
3
2
11EN
Precautions concerning batteries
• Be sure to insert the batteries with
correct positive “” and negative
“” polarities.
• Use batteries of the same type.
Never use dierent types of batteries
together.
• Either rechargeable or non-
rechargeable batteries can be used.
Refer to the precautions on their
labels.
• Be aware of your ngernails when
removing the battery cover and the
battery.
• Do not drop the remote control.
• Do not allow anything to impact the
remote control.
• Do not spill water or any liquid on
the remote control.
• Do not place the remote control on a
wet object.
• Do not place the remote control
under direct sunlight or near sources
of excessive heat.
• Remove the battery from the remote
control when not in use for a long
period of time, as corrosion or
battery leakage may occur and result
in physical injury, and/or property
damage, and/or re.
• Do not use any batteries other than
those specied.
• Do not mix new batteries with old
ones.
• Never recharge a battery unless it is
conrmed to be a rechargeable type.
Placement
Place the subwoofer at least 1 meter (3
feet) away from your soundbar, and 10
centimeters away from the wall.
For best results, place your subwoofer as
shown below.
12 EN
Wall mount
Note
•
Improper wall mounting may result in accident,
injury or damage. If you have any query, contact
Consumer Care in your country.
• Before wall mounting, make sure the wall can
support the weight of your soundbar.
• Before wall mounting, you need not remove
the rubber feet at the bottom of the soundbar,
otherwise the rubber feet cannot be xed back.
• Depending on the type of wall mounting, make
sure that you use screws of a suitable length
and diameter.
• Please check whether the USB port on the back of
the soundbar is connected to a USB device. If it is
found that the connected USB device affects the
wall-mount, you need to use another USB device
of the appropriate size.
Screw length/diameter
3.5-4mm/0.14 -0.16"
4mm/
0.16"
>32mm/1.26"
Suggested wall mounting height
You are recommended to install the TV
rst before wall mounting the soundbar.
With a TV preinstalled, wall mount the
soundbar 50mm/2.0’’ in distance from
the bottom of the TV.
WARNING!
•
To prevent injury, this apparatus must be securely
attached to the oor/wall in accordance with the
installation instructions.
• Suggested wall mounting height: ≤ 1.5 meters.
3
4
1
~50mm/2.0"
628mm / 24.7”
2
3.5-4mm/0.14 -0.16"
4mm/
0.16"
>32mm/1.26"
1 Drill 2 parallel holes (Diameter 3-8mm
each according to wall type) on the
wall.
» The distance between the holes
are: 628 mm / 24.7”
» You can use the wall mount
template provided for helping the
drilling holes position on the wall.
2 Secure the dowels and screws in the
holes.
» Be sure to leave a 3.5-4mm gap
between the wall and the screw’s
head.
3 Attach the wall brackets (x2) into the
back of the unit.
4 Hang the soundbar on the fastening
screws.
13EN
3 Connect
This section helps you connect your
soundbar to a TV and other devices, and
then set it up.
Note
•
For identication and supply ratings, see the
type plate at the back or bottom of the product.
• Before you make or change any connections,
make sure that all devices are disconnected
from the power outlet.
Dolby Atmos®
Dolby Atmos gives you immersive listening
experience by delivering sound in three
dimensional space, and all the richness,
clarity, and power of Dolby sound.
For more information, please visit
dolby.com/technologies/dolby-atmos.
Use Dolby Atmos®
Dolby Atmos® is available in HDMI mode.
For the details of the connection, please
refer to “HDMI Connection”.
1 To use Dolby Atmos® in HDMI in/
HDMI eARC/ARC mode, your TV has
to support Dolby Atmos®
.
2 Make sure that “No Encoding” is
selected for bitstream in the digital
audio output of the connected
external device (e.g. Blu-ray DVD
player, TV etc.).
3 While entering Dolby Atmos / Dolby
Digital / PCM format, the soundbar
will show DOLBY ATMOS / DOLBY
AUDIO / PCM.
Note
• The full Dolby Atmos experience is only
available when the soundbar is connected to
the source via a HDMI 2.0 cable.
• The soundbar will still function when connected
via other methods (such as a Digital Optical
cable) but they are unable to support all of the
Dolby features. Given this, our recommendation
is to connect via HDMI, in order to ensure full
Dolby support.
Connect to HDMI socket
Some 4K HDR TVs require the HDMI
input or picture settings to be set for
HDR content reception. For further setup
details on HDR display, please refer to the
instruction manual of your TV.
Option 1:
HDMI eARC (Enhance Audio Return
Channel)
Your soundbar supports HDMI with
eARC/ARC (Enhance Audio Return
Channel). If your TV is HDMI eARC/ARC
compliant, you can hear the TV audio
through your soundbar by using a single
HDMI cable.
HDMI (eARC/ARC)
HDMI out
(eARC/ARC)
TV
1 On your TV, turn on HDMI-CEC
operations. For details, see the TV
user manual.
• The HDMI ARC connector on the
TV might be labeled dierently. For
details, see the TV user manual.
14 EN
2 Using a High Speed HDMI cable,
connect the HDMI out (eARC/ARC)
connector on your soundbar to the
HDMI ARC connector on the TV.
Note
•
Your TV must support the HDMI-CEC and ARC
function. HDMI-CEC and ARC must be set to On.
• The setting method of HDMI-CEC and ARC may
dier depending on the TV. For details about
ARC function, please refer to your TV user
manual.
• Make sure to use the HDMI cables can support
the ARC function.
Option 2: Standard HDMI
If your TV is not HDMI ARC-compliant,
connect your soundbar to the TV
through a standard HDMI connection.
HDMI in
HDMI out
Blu-ray Player/DVD Player
/Recorder/Set-top Box...
TV
HDMI out
(eARC/ARC)
HDMI in
1 Use an HDMI cable to connect
the soundbar’s HDMI in socket to
your external devices (e.g. games
consoles, DVD players and Blu-ray).
2 Use an HDMI cable to connect the
soundbar’s HDMI out (eARC) socket
to the TV’s HDMI in socket.
Connect to Optical in socket
1 Using an optical cable, connect
the Optical in connector on your
soundbar to the Optical out
connector on the TV or other device.
Optical out
Optical
TV
• The digital optical connector might
be labeled Spdif or Spdif out.
Connect to Audio in
socket
• Use a 3.5mm to 3.5mm audio cable to
connect the TV’s headphone socket to
the Audio in socket on the soundbar.
Headphone
(3.5mm)
Audio out
Audio in
TV
• Use a RCA to 3.5mm audio cable
to connect the TV’s audio output
sockets to the Audio in socket on the
soundbar.
Audio in
R
L
Audio out
TV
15EN
Connect to power
• Before connecting the AC power
cord, ensure you have completed all
other connections.
• Risk of product damage! Ensure that
the power supply voltage corresponds
to the voltage printed on the back or
the underside of the unit.
1 Connect the mains cable to the AC~
socket of the unit and then into a
mains socket.
2 Connect the mains cable to the AC~
socket of the subwoofer and then
into a mains socket.
AC~
* Power cord quantity and plug type
vary by regions.
Pair up with the subwoofer
Automatic pairing
Plug the soundbar and the subwoofer
into the mains sockets and then press on
the unit or remote control to switch the
unit to ON mode. The subwoofer and
soundbar will automatically pair.
» Determine the status based on
the wireless subwoofer indicator.
LED state Status
Fast blink Subwoofer in pairing mode
Constant on Connected / Pairing successful
Slow blink Connection / Pairing failed
Tips
•
Do not press Pair button on the rear of the
subwoofer, except for manual pairing.
Manual pairing
If no audio from the wireless subwoofer
can be heard, manually pair up the
subwoofer.
1 Unplug both the unit and the
subwoofer from the mains sockets
again, then plug them in again after 3
minutes.
2 Press and hold the Pair button on the
rear of the subwoofer for 5 seconds.
» The indicator on the subwoofer
will rapidly blink.
3 Then press
on the unit or remote
control to switch the unit ON.
» The indicator on the subwoofer
will become solid when
successful.
4 If the indicator still keeps blinking,
repeat step 1-3.
Tips
•
The subwoofer should be within 6 m of the
soundbar in an open area (the closer the
better).
• Remove any objects between the subwoofer
and the soundbar.
• If the wireless connection fails again, check if
there is a conict or strong interference (e. g.
interference from an electronic device) around
the location. Remove these conicts or strong
interferences and repeat the above procedures.
16 EN
Connect to Wi-Fi
(Wireless operation)
(For iOS and Android version)
By connecting this unit and mobile
phones, tablets (such as iPad, iPhone,
iPod touch, Android phones, etc.) to the
same Wi-Fi network, you can then use
the Philips Sound app powered by DTS
Play- to control the soundbar to listen
to audio les.
1 Download and install the Philips
Sound app powered by DTS Play- on
a phone or tablet.
Philips Sound
• Make sure your router is turned on
and working properly.
Note
•
Depending on the device version, the operation
screen and the way to perform operations may
vary.
2 Connect your phone or tablet to the
same Wi-Fi network that you want to
connect your soundbar.
<
Wi-Fi
Wi-Fi
3 Press and hold (Wi-Fi) button
located at the back cabinet for 8
seconds to trigger the Wi-Fi
connection
>8 seconds
» Until the speaker make a second
tone and then release the button
Two tone
4 Wait until the Wi-Fi light indicator on
the front cabinet goes from a fast blink
to a slow pulse. When it begins pulsing
slowly, it indicates that the speaker is
entering the Wi-Fi setup mode.
Fast blink Slow pulse
5 Launch the Philips Sound app
powered by DTS Play-. Follow the
instructions in the app to connect
this product to your Wi-Fi network.
Philips Sound
e
X
Settings
Setup Play-Fi Device
SETUP
Return to this app to continue setup.
Ready?
Go To Wi-Fi Settings
PlayFiDevice 1234
Your Home Router
e
X
Wi-Fi Password
Enter the password for the network Your Home Router
1234567890
I
X
Show Password.
17EN
Your Play-Fi device is connecting to
Your Home Router
When the Wi-Fi light on the device stops
blinking and becomes solid the device is
setup and ready to be used.
Select Name
X
Select Nam
e
X
Bedroom
6 After successful Wi-Fi connection, the
Wi-Fi light indicator will stop pulsing
and turn solid. Once you set up this
product on your Wi-Fi network, you
can control it from any smartphone or
tablet on the same network.
7 After connection, you can change
the device name. There are several
names to choose from or create your
own by choosing Custom Name at
the end of the name list. Otherwise,
it follows the default name.
8 After connection, this product may
perform a software update.
Upgrade to the latest software
when it is your rst time set up.
The software upgrade may take
several minutes. Do not unplug your
speaker, turn o your device, or leave
the network during the update.
Note
•
After connection, the product may perform
a software update. Upgrade is required after
initial set up. Without the upgrade, not all
product features can be available.
• When the rst time set up is not successful, hold
down the
(Wi-Fi) button on the soundbar
for 8 seconds until the second tone can be
heard and the Wi-Fi light is changed to a slow
pulse. Reset the Wi-Fi connection, restart the
app and start the set up again.
• If you want to change from one network to
another, you need to set up the connection
again. Press hold down the
(Wi-Fi) button
on the soundbar for 8 seconds to reset the Wi-Fi
connection.
• When the rst time set up is not successful,
please close the Philips Sound app powered by
DTS Play-. Restart the app and try the setup
again.
AirPlay setup
Use AirPlay to set up the Wi-Fi connection
of iOS device (iOS7 or later) and soundbar.
1 iOS device: Settings > Wi-Fi > select
home network【Play- device
(xxxxxx)】
» Go to the Wi-Fi set up. The Play-Fi
device name displays around in 5
seconds.
Settings
» Select the Play-Fi device in the
Airplay set up.
» Press “Done” when set up
complete
» After successful Wi-Fi connection,
the Wi-Fi light indicator will stop
pulsing and turn solid.
Solid
2 Return to Philips Sound App to name
the device.
18 EN
3 After connection, you can change
the device name. There are several
names to choose from or create your
own by choosing Custom Name at
the end of the name list. Otherwise,
it follows the default name.
WPS mode
If your router has Wi-Fi Protected Setup
(WPS), you can set up the connection
without entering a password.
WPS
1 Press and hold
the
(Wi-Fi)
button for 4
seconds. You
will hear a tone
and the Wi-Fi
light will begin double blink.
2 Press the WPS button on your router.
The button is normally marked with
this WPS logo.
3 After successful Wi-Fi connection,
the Wi-Fi light indicator will stop
pulsing and turn solid.
Note
•
WPS is not a standard feature on all routers.
If your router does not have WPS then use
Standard Wi-Fi Setup.
• Press the
(Wi-Fi) button once if you want to
exit the WPS mode or it will automatically exit
after 2 minutes.
Connect the soundbar to
Philips Play- enabled TV
1 Power up your DTS Play- TV
connected to the internet.
» TV sound is muted.
2 Enter the Settings menu on TV.
» Settings > Sound > DTS Play-
Surround sound Setup
Follow the on-screen setup.
1
The home theater speakers are now
independent speakers.
3
2
Two
One
Front Speakers
19EN
TV Audio Setup
You can also stream the TV’s audio
to your home speakers wirelessly.
Follow the on-screen setup.
Stream this TV's audio to wireless speakes
throughout your home.
Learn more about DTS Play-Fi enabled
speakers at play-.com
Connect Speakers
1
DTS Play-Fi TV Audio
Connect Speakers
Select Speakers
Volume
Play-Fi Speaker
2
3TAFB1
DTS Play-Fi TV Audio
B8907
4 Use your
soundbar
This section helps you use the soundbar
to play audio from connected devices.
Before you start
• Make the necessary connections
described in the quick start guide
and the user manual.
• Switch the soundbar to the correct
source for other devices.
Turn ON and OFF
• When you rst connect the unit to
the main socket, the unit will be
in STANDBY mode. The STANDBY
indicator will light up.
Power
state
Action Function
On Follow source state
Semi
standby
Press
the
button
once
• Wi-Fi is
connected.
• It supports Play-
and Airplay2
Chromecast,
Spotify connect,
work with Alexa.
Eco
standby
Press
and
hold
3
seconds
• Wi-Fi is o.
• The product enters
the lower power
consumption
mode.
• Restarting the
system will take a
relatively longer
time.
20 EN
Select modes
Press the button repeatedly on the
unit or on the remote control to select the
Optical, Audio in, USB, BT(Bluetooth),
HDMI in, HDMI eARC/ARC mode.
» The selected mode will show on
the display.
Display Status
OPT
Optical
AUX
Audio in
U5B
USB
BT
Bluetooth
HDMI IN
E-ARC
ARC
HDMI eARC
HDMI ARC
Tips
•
Play- is not an optional source. Play- needs to
be directly controlled by APP.
Adjust the volume
Adjust the system’s volume
Press the +/- buttons on the soundbar
or press
+/- (Volume) buttons on the
remote control to increase or decrease
the system’s volume level.
• To mute sound, press
(Mute)
button on the remote control.
• To restore the sound, press
(Mute) again or press
+/-
(Volume).
Adjust the subwoofer’s volume
Press
+/- (subwoofer) buttons on the
remote control to increase or decrease
the subwoofer’s volume level.
Enjoy Dolby Atmos
sound
Press button to select a height
surround eects level to best suit
your personal taste according to your
environment.
• UPMIX: Make sure that all
speakers are utilized for contents
less than 5.1.2 or 7.1.2 speaker
conguration.
• STANDARD: Original sound.
• AI: The media intelligence
function of Dolby Atmos for
home audio is utilized to drive
the vocal enhancement or
surround eects.
» By default, the audio upmix is set
to 7.1.2.
Tips
•
Display shall show the speaker channels
according with dierent speaker congurations,
such as:
7.1.2: soundbar
7.1.4: soundbar + surround speakers
7.1.4: soundbar + surround speakers+ subwoofer
7.2.2: soundbar + 2 x subwoofer
7.2.4: soundbar + surround speakers + 2x subwoofer
Setup menu
The unit allows you to congure
advanced settings to provide you with an
even better experience.
Button Function
Enter settings menu
/ Last/next sub menu
/ Previous/next selection
Exit setting menu
21EN
Display Description
EQ
Select equalizer (EQ) eect
XX
Adjust the bass level
TRE xx
Adjust the treble level
BT PAIR
Start Bluetooth pairing
XX
Adjust the ATMOS level
FL XX
Front Left Speaker
FR XX
Front Right Speaker
CT XX
Center Speaker
DRC
Dynamic range control
YNC
Set the Audio Delay
Set display brightness
DI5P
Display o setting
5TNBY
Auto-standby ON/OFF
UPGRADE
Update rmware via USB
EQ
Select predened sound modes to suit
your video and music: MOVIE, MUSIC,
VOICE, STADIUM, CUSTOM.
• MOVIE: Create a surround listening
experience. Ideal for watching
movies.
• MUSIC: Create two-channel or
multi-channel stereo sound. Ideal for
listening to music.
• VOICE: Create sound eect which
makes human voice more clear and
outstanding for listening.
• STADIUM: Create an atmosphere
as if watching a sports game in a
stadium.
• CUSTOM: Customize the sound
based on your preferences. Need to
be set via the Fine Tune App.
• By default, the EQ is set to MOVIE.
Bass/Treble
Change the low frequency (bass) and
high frequency (treble) settings of this
product.
• BAS -5 ~ BAS +5
• TRE -5 ~ TRE +5
» By default, the Bass/Treble is set
to 0.
BT PAIR
Enter the Bluetooth pairing mode.
• If you want to connect your
soundbar with another Bluetooth
device, you can activation the pairing
in the menu (BT PAIR) to disconnect
all devices and enter the Bluetooth
pairing mode.
» Press
> select “BT PAIR” > Then
press
(Enter) to conrm the
Bluetooth pairing mode.
• Follow step 2-3 in “Play from
Bluetooth devices“ above to pair
your Bluetooth device.
Tips
•
The “BT PAIR” menu will only be displayed
when the current signal source is in “BT” mode
ATMOS
Select surround mode.
• ATMOS 00: Minimal eect.
• ATMOS 01: Small height eect.
• ATMOS 02: Medium height eect.
• ATMOS 03: Big height eect.
Note
•
For non-HDMI connections (such as use of USB,
Bluetooth, Optical or AUDIO IN), only limited
height surround eects are generated.
22 EN
Adjust speaker level
• Front Left: FL -5 ~ FL +5
• Front Right : FR -5 ~ FR +5
• Center: CT -5 ~ CT +5
» By default, the speaker level is set
to 00.
Dynamic range control (DRC)
You can apply dynamic range control to
Dolby Digital tracks.
• ON : Optimize the dynamic range
• OFF : Turn o dynamic range
adjustment
» AUTO : Dynamic range is
automatically adjusted
» By default, the DRC mode is set
to AUTO.
Note
•
DRC is not available in USB/BT/Play- mode.
AV SYNC
Set the Audio Delay.
Video image processing, sometimes
longer than the time required to process
the audio signal. This is called “delayed.”
Audio Delay feature is designed to
remedy this delay.
• S 00 ~ S 200
» By default, the audio delay is set
to 00.
DIM
Set display brightness.
• HIGH, MID, LOW
» By default, the dimmer is set to
MID.
DISPLAY
Set to turn o the display automatically
(except the Wi-Fi LED indicator) after 10
seconds of idle when no user operation.
• ON: Set to display on
• OFF: Set to display o
» By default, the display is set to
ON.
Auto Standby
The unit automatically turns to Standby
mode after about 15 minutes if the TV or
the external unit is disconnected (or USB, BT
function bit playback pause), switched o.
• STNBY IN 15M: Turn on the
Auto-Standby.
• STNBY OFF: Turn o the Auto-
Standby.
» By default, the key tone is set to
ON.
Note
•
To switch the unit o completely, remove the
mains plug from the mains socket.
• Please turn the unit o completely to save
energy when not in use.
Update rmware via USB
Check if there is the latest rmware
version on www.philips.com/support.
Search for your model and click on
“Software and drivers”.
Copy the software update les into USB
ash drive, insert USB ash drive on the
unit.
» Press
> select “UPGRADE” >
“PLAY TO START”
» Then press
(Enter) button to
conrm.
» Upgrade nished and restart.
23EN
Play from Bluetooth
devices
Through Bluetooth, connect the
soundbar with your Bluetooth device
(such as an iPad, iPhone, iPod touch,
Android phone, or laptop), and then you
can listen to the audio les stored on the
device through your soundbar speakers.
1 Press the
button repeatedly on the
unit or on the remote control to switch
the soundbar to Bluetooth mode.
» BT is displayed on the display
panel.
2 On the Bluetooth device, switch
on Bluetooth, search for and select
“Philips B8907” to start connection
(see the user manual of the Bluetooth
device on how to enable Bluetooth).
3 Wait until you hear the voice prompt
from the soundbar.
» If successfully connected, BT is
displayed on the display panel.
4 Select and play audio les or music
on your Bluetooth device.
• During play, if a call comes in,
music play pauses. Play resumes
when the call ends.
• If your Bluetooth device supports
AVRCP prole, on the remote
control you can press
/ to skip
to a track, or press
to pause/
resume play.
To disconnect and pair a new
Bluetooth device
1 In Bluetooth mode, Press > select
“BT PAIR” > Then press
(Enter) to
disconnect all devices and enter the
Bluetooth pairing mode.
• Alternatively directly press and
hold
button on the soundbar to
disconnect all devices and enter the
Bluetooth pairing mode.
» The display will ashing “PAIR“.
2 Follow step 2-3 in “Play from
Bluetooth devices“ above to pair
your Bluetooth device.
Note
•
In an open space without obstructions.
The maximum operational range between
the soundbar and a Bluetooth device is
approximately 10 meters (33 feet).
• Compatibility with all Bluetooth devices is not
guaranteed.
• The music streaming may be interrupted by
obstacles between the device and soundbar,
such as wall, metallic casing that covers the
device, or other devices nearby that operate in
the same frequency.
Multi-point control
The product support multi-point feature,
and can connect two Bluetooth devices
at same time (such as an iPad, iPhone,
iPod touch, Android phone, or laptop).
• There is audio prompt when the
second Bluetooth device connect the
soundbar.
• When the second Bluetooth device
stream its audio to soundbar, the
rst Bluetooth device will pause the
playback.
• Incoming call has priority over music
playback regardless from rst or
second devices.
Listen to an external
device
Ensure that the unit is connected to the
TV or audio device.
24 EN
1 Press the button repeatedly on the
unit or on the remote control to select
the Optical,
Audio in, HDMI in, HDMI
ARC mode.
2 Operate your audio device directly
for playback features.
3 Press the VOL +/– buttons to adjust
the volume to your desired level.
» When selecting a dierent audio
format, the soundbar will display
the following as follows:
Audio (abbreviation) Display
LPCM 2ch PCM
LPCM 5.1ch PCM
LPCM 7.1ch PCM
Dolby Digital Dolby AUDIO
Dolby TrueHD Dolby AUDIO
Dolby Digital Plus Dolby AUDIO
Dolby Atmos -
Dolby TrueHD
Dolby Atmos
Dolby Atmos -
Dolby Digital Plus
Dolby Atmos
Note
•
The unit may not be able to decode all digital
audio formats from the input source. In this case,
the unit will mute. This is NOT a defect. Ensure
that the audio setting of the input source (e.g.
TV, game console, DVD player, etc.) is set to PCM
or Dolby Digital (Refer to the user manual of the
input source device for its audio setting details)
with HDMI in / HDMI ARC / Optical input.
Play audio through USB
Enjoy audio on a USB storage device,
such as an MP3 player and USB ash
memory, etc.
1 Insert the USB device.
2 Press the button repeatedly on
the unit or on the remote control to
select the USB mode.
3 During playback:
Button Action
Start, pause or resume play.
/ Skip to the previous or next track.
Tips
•
The unit may not be compatible with certain
types of USB storage devices.
• If you use a USB extension cable, USB hub,
or USB multifunctional card reader, the USB
storage device may not be recognized.
• Do not remove the USB storage device during
le reading.
• The unit can support USB devices with up to 32
GB of memory.
• This unit can play MP3 / WAV / FLAC.
• Support a USB port: 5V
500mA.
Factory reset
Reset device to default setting.
• Turn on the soundbar, press and hold
the +/- buttons at the same time for
8 seconds.
» Display shows “RESET” for 5
seconds.
» While system reboots, display
shows “REBOOT”.
25EN
5 Product
specifications
Note
• Specications and design are subject
to change without notice.
Bluetooth / Wireless
Bluetooth proles A2DP, AVRCP
Bluetooth version V 5.3
Bluetooth
frequency band
2402 ~ 2480MHz
Transmitter power ≤ 10dBm
5.8G Wireless
frequency range /
Transmitter power
(EIRP)
5729~5850 MHz
≤ 10dBm
Network supported
WiFi IEEE 802.11a/b/g/n/ac Wireless
frequency band (Wi-Fi) /Radio frequency
power transmitted (EIRP)
2.4G Wi-Fi 2400 ~ 2483.5 MHz / ≤ 20dBm
5G Wi-Fi
5150 ~ 5350 MHz / ≤ 20dBm
5470 ~ 5725 MHz / ≤ 27dBm
5725 ~ 5850 MHz / ≤ 14dBm
Soundbar
Power supply
100-240V~
50/60Hz
RMS output power
MAX output power
240W
480W (10% THD )
Power consumption 45 W
Standby consumption < 0.5 W
Frequency response 150Hz - 20KHz
Speakers impedance 8Ω
Dimension (W x H x D )
940 x 65 x 106
mm
Weight 3.0 kg
Operating
temperature
0°C - 45°C
Subwoofer
Power supply
100-240V~
50/60Hz
RMS output power
MAX output power
120W
240W (10% THD )
Power consumption 35 W
Standby power
consumption
< 0.5 W
Frequency response 35Hz - 150Hz
Impedance 3 Ω
Dimension (W x H x D )
190 x 410 x 309
mm
Weight 6.0 kg
Operating
temperature
0°C - 45°C
USB
USB direct version 2.0 Full Speed
USB 5V
500mA
Extension Codec Sample Rate Bitrate
.mp3
MPEG 1
Layer 1
16 ~ 48 kHz 32 ~ 448 kbps
MPEG 1
Layer 2
16 ~ 48 kHz 8 ~ 384 kbps
MPEG 1
Layer 3
16 ~ 48 kHz 8 ~ 320 kbps
MPEG 2 /
MPEG 2.5
Layer 1
16 ~ 48 kHz 8 ~ 256 kbps
MPEG 2 /
MPEG 2.5
Layer 2
16 ~ 48 kHz 8 ~160 kbps
MPEG 2/
MPEG 2.5
Layer 3
16 ~ 48 kHz 8 ~ 160 kbps
.wav
WAV 16 ~ 48 kHz
Up to 1536
kbps
.ac
FLAC
Up to 48 kHz /
16 bit
Remote control
Distance/Angle 6m/30°
Battery type AAA (1.5V X 2)
26 EN
Supported audio formats
Format Function
HDMI Input HDMI eARC HDMI ARC OPTICAL
LPCM 2ch √ √ √ √
LPCM 5.1ch √ √ √ √
LPCM 7.1ch √ √ -- --
Dolby Digital √ √ √ √
Dolby Digital Plus √ √ √ --
Dolby TrueHD √ √ -- --
Dolby MAT √ √ -- --
Dolby Atmos -
Dolby Digital Plus
√ √ √ --
Dolby Atmos -
Dolby TrueHD
√ √ -- --
Dolby Atmos -
Dolby MAT
√ √ -- --
√ : Supported format.
-- : Unsupported format.
The product shall comply with Dolby indication mandatory requirements
marked below
Input
Signal
Audio format
Dolby
Virtualizer
Format Indication
Dolby Atmos
1
Dolby Surround
1
Dolby Audio
Dolby
Digital
Channel-based
O √
On √
Dolby
Digital Plus
Object-based - √
Channel-based
O √
On √
Dolby
TrueHD
Object-based - √
Channel-based
O √
On √
Dolby MAT
Object-based - √
Channel-based
O √
On √
27EN
6 Troubleshooting
Warning
•
Risk of electric shock. Never remove the
casing of the product.
To keep the warranty valid, never try to
repair the product yourself.
If you have problems using this product,
check the following points before you
request service. If you still have a problem,
get support at www.philips.com/support.
Main unit
The buttons on the main unit do not
work.
• Disconnect form the power supply for
a few minutes, and then connect again.
No power
• Ensure that the AC cord is properly
connected.
• Ensure that there is power at the AC
outlet.
• Press the
button on the remote
control or soundbar to turn the
soundbar on.
Sound
No sound from the soundbar speaker.
• Connect the audio cable from your
soundbar to your TV or other devices.
However, you do not need a separate
audio connection when:
- the soundbar and TV are connected
through HDMl ARC connection, or
- a device is connected to the HDMI in
connector on your soundbar.
• On the remote control, select the
correct audio input.
• Make sure that the soundbar is not
muted.
• Reset this product to its factory
settings (see “Factory reset”).
Distorted sound or echo.
• If you play audio from TV through
this product, make sure that the TV
is muted.
Audio and video are not synchronized.
• Press to synchronize the audio with
the video.
No sound from the wireless subwoofer.
• Manually connect the subwoofer to
the main unit.
• Increase the volume. Press the
+/-
(Volume) on the remote control or
on the soundbar.
• When using either of the Digital
input, if there is no audio:
- Try setting the TV output to PCM or
- Connect directly to your Blu-ray/
other sources. Some TVs do not
pass through digital audio.
• Your TV may be set to variable audio
output. Conrm that the audio
output setting is set to FIXED or
STANDARD, not VARIABLE. Refer
to your TV’s user manual for more
detailed information.
• If using Bluetooth, ensure that the
volume on your source device is
turned up and that the device is not
muted.
• When the playback freezes and
there is no sound in Wi-Fi mode,
please check whether your home
network is normal.
Bluetooth
A device cannot connect with the
soundbar.
• The device does not support the
compatible proles required for the
soundbar.
• You have not enabled the Bluetooth
function of the device. See the user
manual of the device on how to
enable the function.
28 EN
• The device is not correctly connected.
Connect the device correctly.
• The soundbar is already connected
with another Bluetooth device.
Disconnect the connected device,
and then try again.
Quality of audio play from a connected
Bluetooth device is poor.
• The Bluetooth reception is poor.
Move the device closer to the
soundbar, or remove any obstacle
between the device and the
soundbar.
I can’t nd the Bluetooth name of this
unit on my Bluetooth device.
• Ensure the Bluetooth function is
activated on your Bluetooth device.
• Re-pair the unit with your Bluetooth
device.
Wi-Fi
Wi-Fi Connection cannot be established.
• Check the availability of WLAN
network on the router.
• Place the Wi-Fi router closer to the
unit.
• Make sure the password is correct.
• Check the WLAN function or reboot
the modem and Wi-Fi router.
Dolby Atmos
Cannot achieve outstanding Dolby
Atmos eects.
• For non-HDMI connections (such
as use of USB, Bluetooth, Optical or
AUDIO IN), limited height surround
eects are generated. See the
section of ‘Dolby Atmos’ about how
to achieve best Dolby Atmos eects.
Play-
Cannot discover the Play- supported
devices from the app.
• Make sure the device is connected to
the Wi-Fi.
Cannot play Play- music.
• Certain network service or contents
available through the device may
not be accessible in case the service
provider terminates its service.
• When the rst time set up is not
successful, close the Philips Sound
app powered by DTS Play-. Restart
the app.
• When the speaker was set as Stereo
Pairs or Surround Sound, the speaker
need to be disconnected in the App
before use separately.
Remote control does not wor
k
• Before you press any playback
control button, rst select the correct
source.
• Reduce the distance between the
remote control and the unit.
• Insert the battery with its polarities
(+/-) aligned as indicated.
• Replace the battery.
• Aim the remote control directly at
the sensor on the front of the unit.
This is a 15 mins power o function,
one of the ERPII standard requirement
for saving power
• When the unit’s external input
signal level is too low, the unit will
be turned o automatically in 15
minutes. Please increase the volume
level of your external device.
The subwoofer is idle or the indicator of
subwoofer do not light up
• Please unplug power cord from
the mains socket, and plug it in
again after 3 minutes to reset the
subwoofer.
Trademarks:
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS, Inc. (for
companies headquartered in the U.S./Japan/
Taiwan) or under license from DTS Licensing
Limited (for all other companies). DTS, DTS Play-Fi,
Play-Fi and the DTS Play-Fi and Play-Fi logos are
registered trademarks or trademarks of DTS, Inc.
in the United States and other countries. © 2021
DTS, Inc. ALL RIGHTS RESERVED.
The Wi-Fi CERTIFIED™ Logo is a registered
trademark of Wi-Fi Alliance®.
Google, Google Play and Chromecast built-in are
trademark of Google LLC. Google Assistant is not
available in certain languages and countries.
To control this AirPlay 2 -enabled speaker, iOS
11. 4 or later is required. Use of the Works with
Apple badge means that an accessory has been
designed to work specically with technology
identied in the badge and has been certied by
trademarks of Apply Inc. ,registered in the U. S.
and other countries.
Apple® and AirPlay® are trademarks of Apple Inc.,
registered in the U.S. and other countries.
The Spotify Software is subject to third party
licenses found here: www.spotify.com/connect/
third-party-licenses
The Adopted Trademarks HDMI, HDMI High-
Denition Multimedia Interface, HDMI trade
dress and the HDMI Logos are trademarks
or registered trademarks of HDMI Licensing
Administrator, Inc. in the United States and
other countries.
Dolby, Dolby Vision, Dolby Atmos, and the
double-D symbol are registered trademarks
of Dolby Laboratories Licensing Corporation.
Manufactured under license from Dolby
Laboratories. Condential unpublished
works. Copyright © 2012-2021 Dolby
Laboratories. All rights reserved.
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by MMD
Hong Kong Holding Limited is under license.
Other trademarks and trade names are those
of their respective owners.
Roku, the Roku logo, Roku TV, Roku TV
Ready, and the Roku TV Ready logo are
trademarks and/or registered trademarks of
Roku, Inc. This product is Roku TV Ready-
supported in the United States, Canada,
United Kingdom, Mexico and Brazil.
Countries are subject to change. For the
most current list of countries in which this
product is Roku TV Ready-supported, please
emailrokutvr[email protected].
Specications are subject to change without notice. Please visit
www.Philips.com/support for the latest updates and documents.
Philips and the Philips Shield Emblem are registered trademarks of
Koninklijke Philips N.V. and are used under license.
This product has been manufactured by and is sold under the responsibility
of MMD Hong Kong Holding Limited or one of its aliates, and MMD
Hong Kong Holding Limited is the warrantor in relation to this product.
TAB8907RE_UM_EN_V1.0_20220720
