SUINT1000LCD2U
(Series Number: AGPS8294)
SUINT1500LCD2U
(Series Number: AGPS8295)
SUINT2200LCD2U
(Series Number: AGPS7958)
SUINT3000LCD2U
(Series Number: AGPS7959)
SU3000LCD2UHV
(Series Number: AGPS8296)
Quick
Start Guide—
Page 7
1
Owner’s Manual
SmartOnline
®
Single-Phase Rackmount Online UPS Systems
with Built-in LCD Monitoring & Control Screen
Not suitable for mobile applications.
1. Overview 2
Parts List 2
Additional Accessory Options 2
Model Specific Accessories 2
2. Important Safety Instructions 2
3. UPS Circuit Block Diagram 3
4. Installation 4
Rack Mounting 4
Tower Mounting 5
Smart Battery Communications 6
Connection
5. Basic Connections 7
and Start-Up
Quick Start Guide 7
6. Features 9
Front Panel Controls, LEDs and 9
LCD Screen
Rear Panel Features 9
7. Operations 11
LCD Front-Panel Display and Controls 11
Front Panel Button Functions 12
Home Screen Layout 12
Power Strategy Selection Options 13
Front Panel LCD Selection and 14
Configuration Options
Configuring External Battery Packs 18
8. Optional Connections 20
9. Troubleshooting and Event Log 23
10. Internal Battery Replacement 25
11. Storage and Service 26
12. Product Registration and 27
Regulatory Compliance
Español 28
Français 55
Русский 82
Deutsch 109
NOTE: External battery pack options require configuration using front panel LCD interface or via Tripp Lite’s EXTERNAL BATTERY CONFIGURATION software.
