3-SPEED
CENTRIFUGAL
AIR MOVER
Owner’s Manual
Read and save these instructions.
bluedri.com
Owner’s Manual | ONE
33
Unit Assembly
Wear items exempt from warranty consideration include but may
not be limited to: power cords, transport wheels, castors, handle
grips, filters, screens, brushes and carbon brushes. Subject to the
conditions and exceptions stated in this warranty, BlueDri warrants
the BlueDri products to be free from defects in material and
workmanship, under normal use and service, for the periods listed
under the warranty policy to the original purchaser. At any time during
the warranty period, BlueDri will furnish replacement parts for the
BlueDri products to the original purchaser. Such parts will be furnished
and charged including transportation costs, original owner. If the
original part is returned within the warranty policy period from date of
delivery for inspection by BlueDri and is found to be defective, the
owner will be credited for the cost of replacement parts plus shipping
and handling. Replacement parts that have become defective through
wear or abuse are not included in this warranty .This warranty does not
apply to damage or defect caused by accident, misuse, negligence, fire
or to any BlueDri product which has been serviced or repaired by other
than an authorized BlueDri Service Distributor or BlueDri factory
personnel. This warranty is void if products are used for any purpose
other than that which was intended. There are no other warranties
expressed or implied. In no event shall BlueDri be liable for incidental
or consequential damages or any damage to person or property.
(Please note some states do not allow the exclusion or limitations for
incidental and consequential damages.)
Limied Warranty
1-Year Coverage
Subject to the conditions stated below, BlueDri offers a limited
warranty on parts and labor on the following equipment, parts and
accessories to be free from defects in material and workmanship for
a period of one year to the original purchaser.
5-Year Coverage
Subject to the conditions stated below, BlueDri warrants parts
and labor on rotationally molded polyethylene tanks/housings and
injection molded vacuum head assemblies to be free from defects
in materials and workmanship for a period of ten years to the
original purchaser.
Unit Specifications
Certifications C-ETL-US
Motor Rating 0.33 HP
Power 115 V, 60 Hz
Current 2.0/2.5/3.3 amps
Weight 28 Lbs
Dimensions 17.3”W x 16”L x 18”H
Power Cord Length 25’
Speeds 3
Specifications are subject to change without notice.
Operation
Plug your air mover into a standard grounded outlet with the correct voltage
and amperage. If you are unsure about the outlet, contact your supervisor. Turn
on the switch and check that the unit operates properly before letting it run
A 45 degree angle is good for drying furniture after a cleaning.
A 90 degree angle is ideal for walls and ceilings.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Item Desciption QTY
1 Inlet Grill 1
2 Plastic Cover 1
3 Fan wheel 1
4 Fan Housing 1
5 Motor 1
6 Inlet Grill 1
7 Connector 1
8 Power Cord 1
9 Circuit Breaker 1
10 Switch Box 1
11 GFCI 1
12 Switch 1
13 Switch Label 1
14 Switch Knob 1
Flat 45 Degrees 90 Degrees
