TABLE OF CONTENTS
www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352
All about the
Use &Care
of your
Dehumidifier
2020264A0336 (June 2009)
Location
.......................................................
2
How It Works 2
..............................................................
Important Safety Instructions ............................... 2 Care And Cleaning .............................................. 5
Storage .............................................................
Before You Call ................................................... 6
Major Appliance Warranty ................................... 7
5
3-5Operating Instructions ..........................................
Important Safety Instructions, Location & How It Works
2
2009 Electrolux Home Products, Inc. All rights reserved.
WARNING
For Your Safety
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance. Read product labels for flammability and other warnings.
Discard water from bucket. Water is not potable and cannot be used for drinking.
WARNING
Child Safety Precautions
Destroy the carton, plastic bags, and any packing materials immediately after the
dehumidifier is unpacked. Children should never use these items for play.
Do not leave children unattended in an area where the appliance is operating.
Do not allow them to sit or stand on the appliance.
Power supply cord
with 3-prong grounding
plug
Grounding type wall
receptacle
Do not, under any
circumstances, cut,
remove, or bypass the
grounding prong.
WARNING
Avoid fire hazard or electric shock. Do not
use an extension cord or an adaptor plug. Do
not remove any prong from the power cord.
For your safety and protection, this dehumidifier is equipped with a three-prong grounding
plug on the power cord. Do not, under any circumstances, cut or remove the round ground
prong from the plug.
Your dehumidifier must be plugged directly into a properly grounded and polarized
three-prong receptacle. lf the wall receptacle you intend to use will not accept a
three-prong plug, or if you are not sure the outlet is adequately grounded or protected
by a time delay fuse or circuit breaker, have a qualified electrician install the proper outlet
according to the National Electrical Code and applicable local codes and ordinances. Do not
use an extension cord or an adapter plug.
Never unplug the dehumidifier by pulling on the power cord. Always grip the plug firmly
and pull straight out from the receptacle.
WARNING
Electrical Information
Do not pinch, bend, or knot the power cord.
NOTE:
This USE & CARE MANUAL provides specific operating instructions for your model. Use the room air conditioner only as instructed in this USE &
CARE MANUAL. These instructions are not meant to cover every possible condition and situation that may occur. Common sense and caution
must be practiced when installing, operating, and maintaining any appliance.
The coils condense or draw moisture from the air, and air flows through the side louvers into the
room as dry, warm air. Moisture removed from air is collected in a bucket on the front of the
dehumidifier.
4. The dehumidifier must be installed on a level floor that will support it with a full bucket of
water.
5. There should be a minimum of 30.5cm clearance around the dehumidifier.
2. Place dehumidifier in a location that does not restrict airflow through the front of the unit or
out of the louvers on the left side of cabinet.
3. A dehumidifier operating in a basement will have little or no effect in drying an adjacent
enclosed storage area, such as a closet, unless there is adequate circulation of air in and out
of the area. lt may be necessary to install a second dehumidifier in the enclosed area for
satisfactory drying.
1. Dehumidifier must be operated in an enclosed area to be most effective. Close all doors,
windows, and other outside openings to the room. The effectiveness of the dehumidifier
depends on the rate at which new moisture-laden air enters the room.
Location
Selecting a Location
IMPORTANT:
How It Works
When the unit is started, the fan begins to pull moisture-laden air across the dehumidifying coils.
The unit is designed to operate between 5 °C (41 °F), and 35 °C (96 °F).
The "Compressor" circuit has an automatic 3 minute time delayed start if the unit is turned off
and on quickly. This prevents overheating of the compressor and possible circuit breaker tripping.
Make sure the tank is fitted correctly otherwise unit will not turn on.
3
2009 Electrolux Home Products, Inc. All rights reserved.
Allow the unit to reach room temperature before operating.
To begin operating the dehumidifier, follow these steps:
1. Plug the power cord into a properly grounded 115 volt AC outlet. Note the POWER indicators will illuminate.
If the "BUCKET FULL" light is on, remove the bucket and re-install to reset the float switch.
NOTE:
2. To turn the unit on rotate the knob until it points to the CONTINUOUS setting. It is recommended you leave the
unit running in the CONTINUOUS setting for the first three or four days until any sweating and dampness odors
have ceased.
3. After a few days when the Relative Humidity has declined, rotate the HUMIDITY knob to a desired point on the
dial so the room is kept at a comfortable concentration. The unit will cycle on and off keeping the desired level
of comfort.
Operating Instructions
Operating Instructions
Unit must be upright for one hour prior to operating.
NOTE:
4
2009 Electrolux Home Products, Inc. All rights reserved.
1. To shut the unit down, rotate the humidity knob to the OFF position.
Removing Collected Water
1. Emptying the Bucket:
a. When the bucket is full the unit will shut down and the BUCKET FULL indicator light will illuminate.
b. Do not move the unit at this point otherwise water may spill on the floor.
c. Press sides of bucket gently to unclip the bucket from the unit.
d. Remove the bucket as shown in the photographs below and empty the bucket.
Operating Instructions
Operating Instructions
(continued)
e. Replace the empty bucket back into the unit and once seated correctly the unit will start
up again.
f. You should hear a click when the bucket is in the correct position
If the bucket full light does not extinguish, check that the float is correctly snapped in place
as indicated by the diagram.
Discard water from bucket. Water is not potable and cannot be used for drinking.
WARNING
While the power indicator lit, rotate the humidity knob to the OFF position or removing the plug will extinguish this light.
NOTE:
Care And Cleaning
Operating Instructions, Care And Cleaning & Storage
5
2009 Electrolux Home Products, Inc. All rights reserved.
2. Continuous Drainage:
Removing Collected Water
(continued)
a. For constant drainage operation, you will need a garden hose and a drain nearby to discharge the water into.
b. Remove the bucket from the unit and set aside.
c. Lift up the side flap located on the right side of the unit as Iooking from the front. (fig.1)
d. Insert the female threaded end of the hose through the opening. (fig.2)
e. Screw the garden hose onto the threaded portion of the tray underneath the bucket opening. (fig.3)
f. Make sure the hose is secure so there are no leaks.
g. Direct the hose toward the drain, making sure that there are no kinks that will stop the water flowing.
h. Place the end of the hose into the drain.
i. Place the bucket back in the unit and make sure that it is located correctly. (fig.4)
j. Select the desired humidity setting and fan speed on the unit for continuous draining to start.
fig. 1 fig. 3 fig. 4fig. 2
If the unit stops operating check that the bucket full light is illuminated. If it is remove the bucket and empty the
contents and then check the seal between the hose and the drip tray. If there is a small leak then replace the hose
gasket and re-tighten the hose．
NOTE:
1. Filter
a. Remove the filter every two weeks based on normal operating conditions.
b. To remove the filter.
c. Wash the filter with clean water then dry.
d. Re-install the filter.
2. Cabinet
a. Dust cabinet with an oil-free cloth, or using a damp cloth.
b. Vacuum grill using brush attachment.
3. Water Bucket
a. Clean bucket with warm water and detergent.
Storage
When unit is not in use unplug and use the cord wrap shown for your model type.
2.
1.
OCCURRENCE SOLUTION
Wall plug disconnected. Push plug firmly into wall outlet.
House fuse blown or circuit breaker tripped. Replace fuse with time delay type or reset circuit breaker.
Water in the bucket has reached its preset level. Dehumidifier automatically turns off when this
occurs. Empty bucket and return bucket to position.
The dryness level you selected has been reached. Dehumidifier automatically shuts off when selected
amount of moisture has been removed from the air. If you want to remove more moisture, rotate the
knob until it points to the CONTINUOUS setting.
Control to the desired setting.
Bucket not installed properly. See “Removing Collected Water“.
Dehumidifier is not turned on, rotate the knob to “CONTINUOUS“.
“BUCKET FULL“ light is on. Remove bucket, empty water and re-install correctly.
DEHUMIDIFIER DOES NOT
OPERATE.
DEHUMIDIFIER IS OPERATING
BUT ROOM IS NOT DRY ENOUGH.
Humidity setting is too high. rotate the knob to a lower setting.
Dehumidifier has been installed or restarted recently. The higher the moisture in the room air, the
longer it takes for the room air to become dry.
Dehumidifier does not have sufficient clearance to operate. Air flow to front grill is blocked. See
“Selecting a Location“.
Room temperature is too low. Unit will not operate satisfactorily if the room temperature is below
5 °C(41 °F). See “Operating Conditions“.
Refer to causes under DEHUMlDIFIER RUNS TOO MUCH.
FROST APPEARS ON COILS ABOVE
BUCKET OR DRIP TRAY.
Dehumidifier has been turned on recently. This is normal due to refrigerant rushing through the coil.
Frost will usually disappear within 60 minutes.
Room Temperature is too low. All models will operate satisfactorily at temperatures greater than
5 °C(41 °F).
FAN NOISE.
Air is moving through the dehumidifier. This is a normal sound.
If These Solutions Fail, Call 1-800-265-8352 For Frigidaire Service.
Before You Call
6
2009 Electrolux Home Products, Inc. All rights reserved.
DEHUMIDIFIER RUNS TOO MUCH.
Air movement through dehumidifier is blocked. Grill may be dirty. Use brush attachment of vacuum
cleaner to clean grill. See “Care and Cleaning“. Dehumidifier must be placed in a space that does
not restrict air flowing into the rear coil or out of the front grill.
Dehumidifier has been installed or restarted recently. The higher the moistuire in the room, the longer
the dehumidifier will operate.
Windows or doors near dehumidifier are open to outdoors. Close all windows or doors to outside.
Area to be dehumidified is too large. Check with your dealer to see if capacity is adequate.
Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not
the result of defective workmanship or materials in this appliance.
Major Appliance Warranty
7
Your appliance is covered by a full one-year warranty and a limited 2-5 year warranty(sealed system). For one year from your
original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be
defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided
instructions. From the second to the fifth year from your original purchase date, Electrolux will repair or replace any parts in the
Sealed Refrigeration System (compressor, condenser, evaporator and tubing) proves to be defective in materials or workmanship.
The consumer will be responsible for diagnostic costs and any removal, transportation and reinstallation costs which are required
because of service. Costs for labor, parts and transportation other than with respect to the Sealed Refrigeration System.
Exclusions
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
This warranty does not cover the following:
2. Product that has been transferred from its original owner to another party or removed outside the USA or
Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased "as-is" are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not
in ordinary household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,
etc., which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or knobs,
handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip
charges, or mileage expense for service calls to remote areas, including the state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but not limited to floors,
cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or external
causes such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR OR
REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST
PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES
RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME
STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSE-
QUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS
OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS.
YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need
Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period
should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
Service under this warranty must be obtained by contacting Electrolux at the addresses or phone
numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances North
America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp.
Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described
or illustrated are subject to change without notice.
USA
1.800.944.9044
Electrolux Major Appliances
North America
P.O. Box 212378
Augusta, GA 30907
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
2009 Electrolux Home Products, Inc. All rights reserved.
