INFRARED THERMOMETER
THIS PRODUCT COMPLIES WITH
21 CFR 1040.10 and 1040.11.
LASERGRIP 1260
Etekcity Corporation
1202 N. Miller St., Suite A
Anaheim, CA 92806
0.98 in
1.18 in
recommended
Made in China
Distance-to-Spot (D:S) Ratio = 12:1
14.17 in
11.81 in
PULL
REMOVE
BEFORE USE
Specifications
Function Diagram
A. LCD Display
B. Unit (°C/°F)/Down
C. Emissivity/Max Temperature
Mode
D. Up/Laser Pointer
E. Trigger
F. Battery Compartment
G. Laser
H. IR Sensor
I. Low Battery Indicator
J. Laser On
K. Continue Scanning
L. Temperature Unit
M. Temperature Reading
N. Emissivity/Max
Temperature Reading
O. Max Temperature Mode
P. Emissivity Mode
LCD Display Diagram
Package Contents
1 x Infrared Thermometer
2 x 1.5V AAA Batteries (Pre-Installed)
1 x User Manual
Questions or Concerns?
[email protected] • (855)-686-3835
D
F
E
Infrared Thermometer
User Manual
WARNING: THIS DEVICE PRODUCES CLASS 2 LASER RADIATION. USE EXTREME
CAUTION WHEN IN USE.
DO NOT LOOK INTO DIRECT OR REFLECTED LASER LIGHT BEAM OR VIEW BEAM
WITH OPTICAL INSTRUMENTS.
DO NOT AIM THE LASER AT ANOTHER PERSON OR ANIMAL. LASER RADIATION
MAY DAMAGE YOUR EYE.
DO NOT DISASSEMBLE.
IMPORTANT: READ ALL OF THE
INSTRUCTIONS IN THIS MANUAL.
FAILURE TO COMPLY WITH THE
INSTRUCTIONS IN THIS MANUAL, OR
USE OF THE DEVICE IN WAYS OTHER
THAN THE ONES MENTIONED IN THIS
MANUAL, MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
• Do not point the laser at another person or animal.
• Avoid any eye contact with the laser. Laser radiation may cause eye damage.
Do not point the Lasergrip at an aircraft.
• Do not allow children to use the Lasergrip.
• Do not use the Lasergrip to determine whether a highly reflective surface
is safe to touch. Temperature measurement may be inaccurate, which
may cause burns.
• Keep the Lasergrip away from objects that produce strong
electromagnetic fields, such as arc welders and induction heaters.
• The Lasergrip measures surface temperature, not internal temperature.
Do not use the Lasergrip to measure body temperature.
• Do not expose the Lasergrip to direct sources of heat for extended periods
of time.
• Do not use the Lasergrip near explosive gases or other potentially
explosive areas.
• Household use only.
Please read and follow all instructions and safety guidelines in this manual.
READ AND SAVE THESE INSTRUCTIONS
Model
Lasergrip 1260
Measurement Range
-58°–1130°F / -50°–610°C
Accuracy
± 2% / ± 3.6°F / ± 2°C
Resolution
0.1°F/°C
Maximum Output
< 1MW
Wavelength
630–670 nm
Distance-to-Spot
Ratio
12:1
Response Time
< 500 ms
Emissivity
0.1–1.0
Battery
2 x 1.5V AAA Batteries
(Pre-Installed)
Auto Shutoff
15 seconds
Two new pre-installed 1.5V AAA batteries come inside your Lasergrip.
Follow the steps below to properly set up your Lasergrip.
1. For first-time use, pull the insulation strip out of the battery
compartment and discard. [Figure 1.1]
Battery Installation & Replacement
Note:
• The low battery indicator will appear on the display when the power is low.
Immediately replace the battery when the icon appears.
• Remove the batteries before storing if the Lasergrip is not being used for a long
period of time.
Note: You do not need to remove the batteries to pull out the insulation strip.
[Figure 1.1] [Figure 1.2]
[Figure 1.3]
2. Open the battery compartment, and make sure the batteries are
correctly placed inside the battery terminals. [Figure 1.2]
3. Close the battery compartment. [Figure 1.3 ]
Operation
1. Press the trigger to turn on the Lasergrip.
Surface Temperature Measurement
Sensor Care
HOLD trigger to
continuously read
surfacetemperature
RELEASE trigger to
lock the temperature
reading
Note:
• The Lasergrip cannot measure the temperature of objects behind glass.
• Measurements may be inaccurate when the Lasergrip is exposed to steam,
dust, or other contaminants in the air.
• The Lasergrip can only measure surface temperature, and cannot accurately
measure internal temperature.
• Avoid touching the sensor. This will interfere with measurements.
• To clean the sensor, wipe with a soft cloth or cotton swab. Do not
wipe or clean with other materials.
Note:
• Optionally, press to turn the laser on/off.
• To scan live temperature readings on a surface, keep holding the trigger as you
move the Lasergrip.
Note: Make sure the insulation strip is removed from the battery compartment.
Note: The Lasergrip will display “HI” when the measured temperature is higher than
the measurable range, and “LO” when the measured temperature is lower than the
measurable range.
2. Point the Lasergrip at the surface you want to measure.
3. Press and hold the trigger to measure surface temperature. The laser
will activate for aiming guidance.
4. Release the trigger and the display will show the last measured
temperature. The max temperature reading will show on the bottom
of the display.
The device certification information is labeled
directly on the device. The sticker is located on the
left side of the Lasergrip.
The device warning and aperture safety information
are also labeled directly on the device. The sticker is
located on the right side of the Lasergrip.
Any further updates to the product information
(such as date of manufacturing and manufacturer
address) will be included as adhesive overlays.
Important Safety Information
G
H
A
C
B
L
I
M
N
J
K
O
P
