PARTYBOX 710
OWNER’S MANUAL
22
IMPORTANT SAFETY INSTRUCTIONS
For all products:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not block any ventilation openings. Install this apparatus
in accordance with the manufacturer’s instructions.
6. Do not install this apparatus near any heat sources such as
radiators, heat registers, stoves or other apparatus (including
ampliers) that produce heat.
7. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding-type plug has two blades and
a third grounding prong. The wide blade or the third prong
is provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
8. Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles and the point
where they exit from the apparatus.
9. Use only attachments/accessories specied by the
manufacturer.
10. Use only with the cart, stand, tripod, bracket or
table specied by the manufacturer or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination
to avoid injury from tip-over.
11. Unplug this apparatus during lightning storms or when
unused for long periods of time.
12. To disconnect this apparatus from the AC mains completely,
disconnect the power-supply cord plug from the AC
receptacle.
13. The mains plug of the power-supply cord shall remain readily
operable.
14. This apparatus is intended to be used only with the power
supply and/or charging cable provided by the manufacturer.
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
THE LIGHTNING FLASH WITH AN ARROWHEAD SYMBOL, WITHIN AN
EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE
PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE
PRODUCT'S ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO
CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS
INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE PRODUCT.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPARATUS TO RAIN OR MOISTURE.
Caution FCC and IC statement for users (USA and Canada
only)
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
CAN ICES-3(B)/NMB-3(B)
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Caution: Changes or modications not expressly approved
by HARMAN could void the user’s authority to operate the
equipment.
For Products That Transmit RF Energy
FCC AND IC INFORMATION FOR USERS
This device complies with Part 15 of the FCC rules and Industry
Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause
harmful interference; and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
FCC/IC Radiation Exposure Statement
This equipment complies with FCC/IC RSS-102 radiation
exposure limits set forth for an uncontrolled environment.
FCC Caution:
High power radars are allocated as primary users of the 5.25 to
5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations
can cause interference with and/or damage this device. No
conguration controls are provided for this wireless equipment
allowing any change in the frequency of operations outside the
FCC grant of authorization for US operation according to Part
15.407 of the FCC rules.
IC Caution:
User should also be advised that:
(i) The device for operation in the band 5150-5250 MHz is only
for indoor use to reduce the potential for harmful interference to
co-channel mobile satellite systems; (ii) the maximum antenna
gain permitted for devices in the bands 5250-5350 MHz and
5470-5725 MHz shall comply with the e.i.r.p. Limit: and (iii)
The maximum antenna gain permitted for devices in the band
5725-5825 MHz shall comply with the e.i.r.p. Limits specied for
33
www.jbl.com
English
point-to-point and non-point-to-point operation as appropriate.
(iv) Users should also be advised that high-power radars are
allocated as primary users (i.e. priority users) of the bands 5250-
5350 MHz and 5650-5850 MHz and that these radars could
cause interference and/or damage to LE-LAN devices.
Exposure of humans to RF fields (RSS-102)
The computers employ low gain integral antennas that do not
emit RF eld in excess of Health Canada limits for the general
population; consult Safety Code 6, obtainable from Health
Canada’s Website at http://www.hc-sc.gc.ca/
The radiated energy from the antennas connected to the wireless
adapters conforms to the IC limit of the RF exposure requirement
regarding IC RSS-102, Issue 5 clause 4. SAR tests are conducted
using recommended operating positions accepted by the FCC/
RSS with the device transmitting at its highest away from the
body. Non-compliance with the above restrictions may result in
a violation of FCC RF exposure guidelines.
Use Restriction: Attention in France, the operation is limited to
indoor use within the band 5150-5350 Mhz.
For Products with Radio Receivers That Can
Use an External Antenna (USA ONLY)
CATV (Cable TV) or Antenna Grounding
If an outside antenna or cable system is connected to this
product, be certain that it is grounded so as to provide some
protection against voltage surges and static charges. Section
810 of the National Electrical Code (NEC), ANSI/NFPA No. 700-
1984, provides information with respect to proper grounding of
the mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, of grounding conductors, location
of antenna discharge unit, connection to grounding electrodes
and requirements of the electrode.
Note to CATV System Installer
This reminder is provided to call the CATV(cable TV) system
installer’s attention to article 820-40 of the NEC, which provides
guidelines for proper grounding and, in particular, as close to the
point of cable entry as possible.
FOR ALL EU COUNTRIES
For products that include audio out
Prevention of hearing loss
Caution: Permanent hearing loss may occur
if earphones or headphones are used at high
volume for prolonged periods of time.
For France, the products have been tested to
comply with Sound Pressure Level requirement
laid down in the applicable NF EN 50332 L.5232-1.
Note:
– To prevent possible hearing damage, do not listen to high volume
levels for long periods.
WEEE Notice
The Directive on Waste Electrical Equipment (WEEE), which
entered into force as European law on 14/02/2014, resulted in
a major change in the treatment of electrical equipment at end-
of-life.
The purpose of this Directive is, a rst priority, the prevention of
WEEE, and in addition, to promote the reuse, recycling and other
forms of recovery of such wastes as so as to reduce disposal.
The WEEE logo on the product or on its box indicating collection
for electrical and electronic equipment consists of the crossed-
out wheeled bin, as shown below.
This product must not be disposed of or dumped with
your other household waste. You are liable to dispose
of all your electronic or electrical waste equipment by
relocating over to the specied collection point for
recycling of such hazardous waste. Isolated collection
and proper recovery of your electronic and electrical waste
equipment at the time of disposal will allow us to help conserving
natural resources. Moreover, proper recycling, and collection
points, please contact your local city center, household waste
disposal service, shop from where you purchased the equipment,
or manufacturer of the equipment.
RoHS Compliance
This product is in compliance with Directive 2011/65/EU of the
European Parliament and of the Council of 8 June 2011 on the
restriction of the use of certain hazardous substances in electrical
and electronic equipment.
For All Products Except Those with Wireless
Operation
HARMAN International hereby declares that this equipment is in
compliance with EMC 2014/30/EU Directive, LVD 2014/35/EU
Directive. The declaration of conformity may be consulted in the
support section of our Web Site, accessible from www.jbl.com.
For All Products with Wireless Operation
HARMAN International hereby declares that this equipment
is in compliance with the essential requirements and other
relevant provisions of Directive 2014/53/EU. The declaration of
conformity may be consulted in the support section of our Web
Site, accessible from www.jbl.com.
EPILEPSY
WARNING
A few people may experience epileptic
seizures when viewing ashing lights.
44
9. SPECIFICATIONS 14
10. TROUBLESHOOTING 14
11. COMPLIANCE 15
12. TRADEMARK 15
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 2
1. INTRODUCTION 5
2. WHAT’S IN THE BOX 5
3. PRODUCT OVERVIEW 6
3.1 TOP PANEL 6
3.2 BACK PANEL 6
4. PLACEMENT 7
5. POWER ON 8
6. USING YOUR PARTYBOX 8
6.1 BLUETOOTH CONNECTION 8
6.2 USB CONNECTION 9
6.3 MUSIC CONTROL 9
6.4 AUX CONNECTION 10
6.5 MIXING SOUND WITH A MICROPHONE AND /
OR GUITAR 10
6.6 CHARGING YOUR MOBILE DEVICE 11
7. CARRYING YOUR PARTYBOX 11
8. ADVANCED USAGE 12
8.1 LIGHT EFFECT 12
8.2 SOUND EFFECT 12
8.3 TWS MODE 12
8.4 JBL PARTYBOX APP 12
8.5 DAISY CHAIN 13
8.6 FACTORY RESET 13
8.7 IPX4 13
55
www.jbl.com
English
2. WHAT’S IN THE BOX
*
1 2 3
1) Main unit
2) Power cord*
3) Quick Start Guide, Safety Sheet, Warranty Card
*Power cord quantity and plug type vary by regions.
1. INTRODUCTION
Congratulations on your purchase! This manual includes
information about PartyBox 710 speakers. We encourage you
to take a few minutes to read this manual, which describes
the product and includes step-by-step instructions to help you
to set up and get started. Read and understand all the safety
instructions before using your product.
If you have any questions about these products, their installation
or their operation, please contact your retailer or customer
service, or visit us at www.jbl.com.
66
8)
• Press to turn light effect on or off.
• Hold for more than 2 seconds to turn strobe light on or
off.
• Rotate clockwise / counterclockwise to switch between
different light patterns.
9) Mobile device dock
Caution:
– Do not look directly at the light-emitting parts when the speaker
lights are turned on.
LED behavior
Solid white Power on
Solid amber Standby
Off Power off
Flashing white quickly Pairing
White (Constant) Connected
Off Not connected
Solid white
Level 1
Level 2
Off Off
3.2 Back Panel
11
3
2
1
4
5
10
9
8
7
6
1) USB
• Connect to a USB storage device.
• Charge your mobile device.
2) AUX IN
• Connect to an external audio device through a 3.5 mm
audio cable (not supplied).
3) GAIN 2
• Adjust gain of the corresponding microphone ( ) or
guitar input.
3. PRODUCT OVERVIEW
3.1 Top Panel
3
4
2
5
6
8
9
7
1
1) KARAOKE controls (for MIC input only)
- BASS +
• Adjust the bass level.
- TREBLE +
• Adjust the treble level.
- ECHO +
• Adjust the echo level.
2) | |
• Select a special sound effect such as horn, clapping,
scratch.
3)
• Turn the power on or off.
4)
• Play, pause or resume.
• Rotate clockwise / counterclockwise to increase /
decrease the main volume.
5)
• Enhances the bass level: level 1, level 2, or off.
6) LED ring
7)
• Press to enter Bluetooth pairing mode.
• Press and hold for more than 10 seconds to forget all
paired devices.
77
www.jbl.com
English
4) Microphone/guitar volume knob (for )
• Adjust volume of the corresponding microphone ( ) or
guitar (if connected).
5)
• Connect to a microphone or guitar.
6) IN/OUT
• Daisy-chain multiple PartyBox speakers through 3.5 mm
audio cables (not supplied).
7) TWS
• Press to enter True Wireless Stereo (TWS) pairing mode.
8)
• Connect to a microphone.
9) Microphone volume knob (for )
• Adjust volume of the corresponding microphone ( ) (if
connected).
10) GAIN 1
• Adjust gain of the corresponding microphone ( ) input.
11) AC
• Connect to AC power supply.
4. PLACEMENT
Caution:
– Do not sit or lean on the speaker or push it sideways to avoid tip-
over and possible damages.
Place the speaker on a at, stable surface and ensure that the
rubber feet side is down.
88
5. POWER ON
Cautions:
– Use the provided power cords only.
1
2
OFF
ON
1. Connect AC power.
2. Press to power on.
Tip:
– The speaker switches to standby mode automatically after 20
minutes of inactivity. You can press on the speaker to switch to
normal operation.
6. USING YOUR PARTYBOX
Notes:
– Only one sound source can be played at a time. The priority order
is USB -> BLUETOOTH -> AUX.
– Starting a source with higher priority will always interrupt a source
with lower priority.
– To start a source with lower priority, stop the source with higher
priority rst.
6.1 Bluetooth Connection
You can use the speaker with your Bluetooth enabled smartphone
or tablet.
DEVICES
JBL PartyBox 710
Bluetooth
Bluetooth
2
1
<10 m (33 ft)
1. Press on the speaker to enter Bluetooth pairing mode.
2. Choose “JBL PartyBox 710” on your Bluetooth device to
connect.
3. Once successfully connected, you can stream audio from
your Bluetooth device to this speaker.
Notes:
– This speaker can memorize a maximum of 8 paired devices. The
ninth paired device will replace the rst one.
– Enter “0000” if a PIN code is requested for connection to a
Bluetooth device.
– Bluetooth performance can be affected by the distance between
this product and your Bluetooth device and the environment of
operation.
To terminate the Bluetooth-enabled device:
• Turn off this speaker, or
• Disable Bluetooth on your device.
99
www.jbl.com
English
To reconnect the Bluetooth enabled device:
• When you turn on this speaker next time, it tries to reconnect
the last connected device automatically.
• If not, manually select “JBL PartyBox 710” on your Bluetooth
device to connect.
6.2 USB Connection
Plug a USB storage device that contains playable audio contents
into the USB port of the speaker.
J The speaker switches to the USB source automatically.
J Audio playback will start automatically.
Tip:
– The speaker plays audio les on the USB storage device from the
root folder to the last level of subfolders in alphabetical sequence.
Up to 8 levels of subfolders are supported.
Supported audio formats
Extension Codec Sample rate Bitrate
WAVE PCM 44.1KHz ~ 192KHz < 5Mbps
LPCM
44.1KHz ~ 192KHz
< 5Mbps
IMA_
ADPCM
44.1KHz ~ 192KHz
< 5Mbps
MPEG
44.1KHz ~ 192KHz
< 5Mbps
MULAW
44.1KHz ~ 192KHz
< 5Mbps
MP3 MPEG1
layer1/2/3
32KHz ~ 48KHz 32Kbps ~
320Kbps
MPEG2
layer1/2/3
16KHz ~ 24KHz 8Kbps ~
160Kbps
MPEG2.5
layer3
8KHz ~12KHz 8Kbps ~
160Kbps
WMA ≤ 320Kbps 8Kbps ~
48Kbps
6.3 Music Control
x 1
x 2
x 3
• Press once to pause or resume playback.
• Press twice to skip to the next track.
• Press three times to skip to the previous track.
• Rotate the volume knob clockwise or counterclockwise to
increase or decrease main volume.
• Press BASS BOOST to enhance the bass level: level 1, level
2, or off.
Note:
– The skip operation is unavailable in AUX mode.
1010
6.4 AUX Connection
1. Connect an external audio device to the speaker through a
3.5 mm audio cable (not supplied).
2. After stopping playback from any other source, start audio
playback on the external device.
6.5 Mixing Sound with a Microphone and /
or Guitar
By using a microphone or electric guitar (not supplied), you can
mix sound with an audio source.
Notes:
– Always set the guitar or microphone volume to the minimum level
before guitar or microphone connection / disconnection.
– Always disconnect the guitar or microphone when you are not
using them.
6.5.1 Connecting a Microphone
1
2
1. Connect a microphone to the or socket.
2. When connecting a microphone to the socket, switch
the slider to show .
6.5.2 Connecting a Guitar
1
2
1. Connect a guitar to the socket.
2. Switch the slider to show .
1111
www.jbl.com
English
6.5.3 Mixing Sound
Sing through the microphone or play guitar.
• To adjust the volume of the audio source, rotate the volume
knob clockwise or counterclockwise.
• To adjust the volume of the microphone or guitar, rotate the
corresponding microphone or guitar volume knob.
• To adjust the gain of the wired microphone or guitar, rotate
the corresponding GAIN 1 or GAIN 2 control respectively.
• To adjust the echo, treble and bass level of the microphone,
rotate the ECHO, TREBLE and BASS knob respectively.
6.6 Charging Your Mobile Device
7. CARRYING YOUR PARTYBOX
Cautions:
– Before carrying the speaker, ensure that all the cords are
disconnected.
– To avoid personal injury and/or property damage, hold the product
rmly while carrying.
The PartyBox 710 is designed with a handle to help you move
the speaker around easily.
1212
8. ADVANCED USAGE
8.1 Light Effect
2S
x1
• Press to turn light effect on or off.
• Hold for more than 2 seconds to turn strobe light on or off.
• Rotate the knob clockwise / counterclockwise to switch
between different light patterns: Rock, Flow, Cross, Ripple,
or Flash.
8.2 Sound Effect
Press | | to select a special sound effect such as horn,
clapping, scratch.
8.3 TWS Mode
You can connect two PartyBox speakers to each other via TWS
mode.
Press TWS on both speakers.
To exit TWS mode:
Power off or press TWS on either speaker.
Tip:
– By default, the speaker connected to your Bluetooth device acts as
the primary speaker (left channel), while the other one acts as the
secondary speaker (right channel).
8.4 JBL PartyBox App
Download and install the JBL PartyBox App to get more from
the product.
1313
www.jbl.com
English
8.5 Daisy Chain
8.6 Factory reset
To restore the factory settings, hold and for more than 10
seconds.
8.7 IPX4
Caution:
– Always keep the port dry before connecting AC power.
– To ensure splash resistance, always keep the protective covers
closed securely.
The speaker is IPX4 splash resistant.
1414
10. TROUBLESHOOTING
Caution:
– Never try to repair the product by yourself. If you have any
problems while using this product, check the following points
before you request service.
System
The speaker will not turn on.
• Check the AC power connection.
No response from some buttons
• The product may be in demo mode. In demo mode, all the
input sources and buttons, except / / and the
volume and light pattern knobs, are disabled. Hold and
simultaneously for more than 5 seconds to exit.
Sound
No sound from the speaker.
• Ensure that the speaker is powered on.
• Adjust volume.
• Ensure that a sound source is active and not muted.
Bluetooth
A device cannot connect with the speaker.
• Ensure that the Bluetooth function of the device is enabled.
• The speaker is already connected with another Bluetooth
device. Hold
on the speaker for more than 20 seconds to
disconnect and pair with a new device.
Poor audio quality from a connected Bluetooth device
• The Bluetooth reception is poor. Move the device closer to
the speaker, or remove any obstacle between the device and
speaker.
9. SPECIFICATIONS
Transducers: 2 x 216 mm (8") woofer,
2 x 70 mm (2.75") tweeter
Output power: 800 W RMS (IEC60268)
Power input: 100 – 240 VAC ~50 / 60 Hz
Frequency response: 35 Hz – 20 kHz (-6 dB)
Signal-to-noise ratio: > 80 dB
Cable type: right-angle AC power cable (type
varies by regions)
Cable length: 2.0 m / 6.6 ft
USB charge out: 5 V / 2.1 A (max)
USB format: FAT16, FAT32
Bluetooth
®
version: 5.1
Bluetooth
®
prole: A2DP V1.3, AVRCP V1.6
Bluetooth
®
transmitter
frequency range: 2400 MHz – 2483.5 MHz
Bluetooth
®
transmitter
power: ≤ 11 dBm (EIRP)
Bluetooth
®
transmitter
modulation: GFSK, π/4 DQPSK, 8DPSK
Supported formats: .mp3, .wma, .wav
Aux-In: 250 mVrms (3.5 mm connector)
Mic-In: 20 mVrms
Guitar-In: 100 mVrms
Bluetooth/USB input: -12 dBFS
Product dimensions
(W x H x D):
399 mm x 905 mm x 436 mm /
15.7" x 35.6" x 17.2"
Net weight: 27.8 kg / 61.3 lbs
Packaging dimensions
(W x H x D):
1048 mm x 505 mm x 467 mm /
41.26" x 19.88" x 18.39"
Gross weight: 31 kg / 68.34 lbs
1515
www.jbl.com
English
12. TRADEMARK
The Bluetooth
®
word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by
HARMAN International Industries, Incorporated is under license.
Other trademarks and trade names are those of their respective
owners.
Made for iPhone 12 Pro Max, iPhone 12 Pro, iPhone 12, iPhone
12 mini, iPhone SE (2nd generation), iPhone 11 Pro Max, iPhone
11 Pro, iPhone 11, iPhone XS Max, iPhone XS, iPhone XR,
iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7,
iPhone SE, iPhone 6s Plus, and iPhone 6s.
Use of the Made for Apple badge means that an accessory has
been designed to connect specically to the Apple product(s)
identied in the badge and has been certied by the developer
to meet Apple performance standards. Apple is not responsible
for the operation of this device or its compliance with safety and
regulatory standards.
Apple, and iPhone are trademarks of Apple Inc., registered in the
U.S. and other countries.
The trademark “iPhone” is used in Japan with a license from
Aiphone K.K.
11. COMPLIANCE
The product is in compliance with the European Union energy
legislation.
Bluetooth connection mode
The product is intended to be used for streaming music via
Bluetooth connection. A consumer can stream Bluetooth
audio to the speaker. When the product is connected through
Bluetooth, the Bluetooth connection must remain active at all
times to ensure proper operation.
The product will enter sleep mode (networked standby) after
20 minutes without operation. The power consumption in sleep
mode is less than 2.0 Watts, after which it can be re-activated
via Bluetooth connection.
Bluetooth disconnection mode
The product will enter standby mode after 20 minutes without
operation. The power consumption in standby mode is less than
0.5 Watts.
1616
Este produto está homologado pela Anatel, de acordo com os
procedimentos regulamentados para avaliação da conformidade
de produtos para telecomunicações e atende aos requisitos
técnicos aplicados.
Para maiores informações, consulte o site da Anatel –
www.anatel.gov.br
Este equipamento não tem direito à proteção contra interferência
prejudicial e não pode causar interferência em sistemas
devidamente autorizados.
Активная акустическая система
Изготовитель: Харман Интернешнл Индастриз Инкорпорейтед, США, 06901 Коннектикут, г.Стэмфорд, Атлантик Стрит 400, офис 1500
Сделано в Китае
Импортер: OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, г.Москва, ул. Двинцев, д.12, к. 1
Гарантийный период: 1 год
Срок службы: 2 года
Информация о сервисных центрах: www.harman.com/ru
Техническая поддержка: 8 (800) 700 0467
Организация, уполномоченная на принятие претензий потребителей: OOO “ХАРМАН РУС СиАйЭс“
Товар сертифицирован
Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы символов серийного номера изделия,
следующих после разделительного знака «-». Кодировка соответствует порядку букв латинского алфавита, начиная с января 2010 года: 000000-
MY0000000, где «M» - месяц производства (А - январь, B - февраль, C - март и т.д.) и «Y» - год производства (A - 2010, B - 2011, C - 2012 и т.д.).
HARMAN International Industries,
Incorporated 8500 Balboa Boulevard,
Northridge, CA 91329 USA
www.jbl.com
© 2021 HARMAN International Industries, Incorporated. All rights reserved.
JBL is a trademark of HARMAN International Industries, Incorporated, registered in the United
States and/or other countries. Features, specications and appearance are subject to change
without notice.
