Holmes 32510056 40" Wi-Fi SmartConnect Digital Tower Fan User Manual

5. When the fan is successfully found by Bluetooth

click the green "+" on the fan icon that appears.

6. Enter your Wi-Fi name and password.

7. Wait for the connection to be established (green

checkmark), then press Next.

8. Press done (top right-hand corner). The fan is now

available to control from your smartphone.

CONTROLLING THE FAN WITH THE

HOLMES

APP

The Holmes

App has the same functionality as the

remote control, as well as additional features.

1. Power

2. Fan Speed

3. Oscillation

Note: The control panel display on

the tower fan will change to match

the setting selected in the app.

1. POWER: Press to turn ON/OFF

2. SPEED: Slide your finger across

the speed level scroll bar to increase

or decrease fan speed.

3. OSCILLATION: Press to turn

ON/OFF.

4. MODE: Press icons to select

preferred mode.

• Normal - Steady Fan Speed

• Sleep - Low Fan Speed

• Breeze - Alternating Fan Speed

• Power Breeze - Maximum Air

Velocity

5. TIMER:

To set your fan for auto-shutoff, select

a run-time from 1 hour to 15 hours.

• The default setting is 1 hour.

• Choose the number of hours from

the list.

6. SCHEDULE

To Set Schedule:

1. Press Schedule.

2. Select Add on the next page.

3. Select the time of day the fan should turn on or off.

Be sure to choose the hour and minutes.

4. Click on “Repeat” and select

which day of the week the schedule

will be active.

5. Click "Power" and select whether

the fan should turn on or off.

6. Click "save" to save selection and

return to the previous menu.

7. Your saved schedule will appear

on the Schedule screen.

8. To turn OFF the schedule, press

the slider button to the right. It will

change from red to gray to indicate

the schedule is off. To turn ON the

schedule, press the slider button

again. It will change from gray to

green to indicate the schedule is ON.

REPLACING THE PLUG FUSE

If your (5 Amp, 125 Volt) replaceable fuse blows,

please visit our website at www.getholmesfans.com

for information on how to order a new fuse. Follow the

below instructions to replace the fuse on the plug.

User Servicing Instructions

1. Unplug the fan. Grasp plug and remove from the

receptacle or other outlet device. Do not unplug by

pulling on cord.

2. Open fuse cover, located on the top of the plug, by

using your thumb or a flathead screwdriver to slide

the cover down towards the prongs.

NOTE: Ensure that the

fuse cover is completely

open before attempting

to remove fuse.

3. Remove fuse carefully by

using a small screwdriver

to pry the fuse from the

compartment by the

metal ends of the fuse. (see Figure 6)

4. Place plug on a solid, flat surface. Insert new

5 Amp, 125 Volt fuse into fuse compartment and

use a small screwdriver to secure the metal ends of

the fuse into the compartment.

CAUTION: Risk of fire. Replace fuse only with

5 Amp, 125 Volt fuse.

5. Slide fuse cover closed completely.

If fuse cover is difficult to close, make sure fuse is

secured in place completely by pressing the metal

ends of the fuse

6. Risk of fire. Do not replace attachment plug. Contains

a safety device (fuse) that should not be removed.

Discard product if the attachment plug is damaged.

CLEANING

1. Always unplug the fan before cleaning.

2. Do not allow water to drip on into fan housing.

3. Be sure to use a soft cloth moistened with a mild

soap solution.

4. Do not use gasoline, thinner or benzene as a

cleaner.

Clean the fan grill, housing and base with a soft, damp

cloth.

Do not attempt to remove the fan blade. Please use

caution around the motor housing area. Do not allow

the motor or other electrical components to be exposed

to water.

STORAGE

• Store the fan in a clean, dry location between

seasons or when not in use for an extended period of

time.

• Keep the fan protected from dirt and dust during

storage.

• Remove battery from the remote control before

storage or disposal.

FCC STATEMENT

Potential for Radio/Television interference

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15

of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. The product generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that the interference will not occur in a particular installation. If the product does cause

harmful interference to radio or television reception, which can be determined by turning the product on or off,

the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the product and the receiver.

3. Connect the product into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

5. Changes or modifications not expressly approved by the party responsible for compliance could void the

mk]jkYml`gjalqlggh]jYl]l`]]imahe]fl&

FCC STATEMENT

WARRANTY INFORMATION

CLEANING AND MAINTENANCE

PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS

Instruction Manual

40 Inch Digital Tower Fan

with SmartConnect App

VOICE ASSISTANT INSTRUCTIONS MOBILE APP INSTRUCTIONS

Figure 6

Fuse

Metal ends

Fuse cover

Printed In China

HOLMES

is a registered trademark of Sunbeam Products, Inc. used under license.

Distributed by Star Elite Inc., Montreal, Canada H3B 3X9

SEH020-120822

3 YEAR LIMITED WARRANTY

This device has a limited warranty of 3 years from the original date of purchase against workmanship and defects

in material. If under normal use, your product fails to operate, please contact our customer service department at

info@getholmesfans.com. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc.

eYq\]fq[dYaekg^\YeY_][Ymk]\Zqeakmk]gjeg\aÚ[Ylagfkg^l`akhjg\m[l&

Warranty Service

Contact our customer service at www.getholmesfans.com/en/contact-us

or info@getholmesfans.com or 1-866-769-3166 (8:30 am - 5:00 pm EST) Monday-Friday.

Our team will be happy to assist.

www.getholmesfans.com

Item: 12059

Model: 32510056

SETTING UP VOICE ASSISTANT

To pair the Tower Fan with Amazon Alexa and Google Voice Enabled Devices:

1. Open the Holmes

App.

2. Select the device you wish to connect to a voice assistant.

3. In the top right corner of the screen select the pencil icon.

4. Choose the icon of the Voice Assistant you wish to connect.

5. Follow the instructions that appear.

Voice Assistant Functionality

Use the following command sequence for Amazon Alexa enabled devices: “Alexa, “Primary Command” + “Device

Name” + “Secondary Command”(if applicable). For example, “Alexa, Activate Holmes® Fan” or “Alexa, Turn Up

Holmes

Fan speed by 3”.

Use the following command sequence for Google Assistant enabled devices: “Hey Google, “Primary Command” +

“Device Name” + “Secondary Command”(if applicable) For example, “Hey Google, Activate Holmes® Fan” or “Hey

Google, Turn Up Holmes

Fan speed by 3”.

Note: The default “Device Name” is “Holmes

Fan”. To personalize the device name, see below.

Action Command

Turn the fan On “Activate,” “Power On,” “Turn on,” “Start”

Turn the fan Off “Power Off,” “Turn Off,” “Deactivate,”

Increase the speed “Turn Up,” “Raise,” “Increase”, “Set the fan speed to __” (1,2 or 3)

Decrease the speed “Turn Down,” “Lower,” “Decrease”, “Set the fan speed to __” (1,2 or 3)

Set the timer “Set Countdown to ___ hours” (choose between 1-15 hours)

Oscillation On “Turn On Oscillation,” “Start Oscillation,” “Activate Oscillation”

Oscillation Off “Turn Off Oscillation,” “Stop Oscillation,” “Deactivate Oscillation”

Mode “Set Mode to Normal” “Set Mode to Breeze” “Set Mode to Sleep” “Set Mode to Power Breeze”

PERSONALIZING THE DEVICE NAME

To personalize the fan name for easier voice commands:

1. Open the Holmes

App.

2. Select the product name you wish to change.

3. Select the pencil icon in the top right corner.

4. On the following screen, click on or tap the name of the product.

5. Tap the current name of the fan.

6. Rename the product and press save.

Note: The name will automatically update for both Amazon Alexa and Google Voice Enabled Devices.

Google, Google Play and Google Home are trademarks of Google LLC.

Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates.

App Store is a service mark of Apple Inc.

4. Mode

5. Timer

6. Schedule

For inquiries regarding recycling and proper disposal

of this product, please contact your local waste

management facility.

REMOTE CONTROL

NOTE: THIS UNIT INCLUDES ONE LITHIUM BATTERY,

CR2025/3V. PLEASE REMOVE THE PROTECTIVE PLASTIC

FROM THE REMOTE CONTROL BATTERY BEFORE OPERATION.

To operate the fan with the remote control, aim it

towards the control panel on top of the fan tower.

The remote control can operate from a distance up to

approximately 16 feet from the fan body and at an

angle variation of 15-20 degrees.

Avoid exposing the display panel to direct sunlight, as it

may interfere with signal transmission.

Replacing the Remote Control Battery (Figure 5)

The cells should be disposed of properly, including

keeping them away from children. Even used cells may

cause injury.

1. Locate the battery compartment on the back of the

remote control handset. Press tab and pull out battery.

2. Remove old battery.

3. Place new battery into

battery compartment.

4. Slide battery

compartment into the

remote control handset.

NOTES:

1. Remove the battery

from the remote when it

is not in use for an

extended period.

2. Remove the battery

before discarding the remote at the end of its useful

product life.

3. Do not discard used batteries into household trash

containers. Contact your local government for disposal

or recycling practices in your area.

SETTING UP THE HOLMES MOBILE APP

Note: A 2.4 GHz Wi-Fi network is required.

1. Download the Holmes

App from Google Play, the

Apple App Store or the QR code located on the back of

this Instruction Manual.

2. Create an account by following the steps in the App.

3. Enter the verification code you received to confirm

your account and create a password.

4. Select "Add Device" or the plus (+) sign in the top

right corner.

Auto Pairing

(Recommended Method)

1. Ensure Bluetooth

, Wi-Fi, and

GPS are activated on your mobile

device.

2. Press and hold the OSC/WIFI

PAIRING button on the fan's

control panel for 5 seconds, until an

audible beep is heard and the red

indicator light is flashing which

indicates the device is in pairing

mode. Note: if pairing is not

completed within 2-3 minutes, the device will exit pairing

mode and step 2 will need to be repeated.

3. Select “Auto Scan” at the top of the screen.

You should see an icon for the fan that has been found.

4. Click "Next."

5. Input your Wi-Fi name and password.

6. Wait for the connection to be established.

7. Press "Done" (top right-hand corner).

Your fan is now available to control from your smartphone.

Manual Pairing

If Auto Pairing is unsuccessful:

1. Ensure Bluetooth

, Wi-Fi, and GPS are activated on

your mobile device.

2. Ensure the fan has been powered off for 10 seconds

or more, then power on the fan.

3. Press and hold the OSC/WIFI PAIRING button on

the fan's control panel for 5 seconds, until the red

indicator light is flashing. The device is now in pairing

mode. Note: if pairing is not completed within 2-3

minutes, the device will exit pairing mode and step 3 will

need to be repeated.

4. On your mobile device, click "add device", then

select "add manually" at the top of the screen.

Click the fan icon.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions

should always be taken including the following:

1. Read all instructions before using this appliance.

2. Use fan only for purposes described in the

instruction manual. This fan is not for continuous

operation or equivalent.

3. To protect against electrical shock do not immerse

unit, plug or cord in water or spray with liquids and

plug the appliance directly into a 120V AC electrical

outlet.

4. Close supervision is necessary when any appliance

is used near children.

5. Not intended for use by children

6. Unplug from outlet when not in use, when moving

fan from one location to another, before putting on

or taking off parts and before cleaning.

7. Avoid contact with moving parts.

8. Do not operate in the presence of explosive and/or

flammable fumes.

9. To avoid fire hazard, NEVER place the cord under

rugs or any parts near an open flame, cooking or

other heating appliance.

10. Do not operate any appliance with a damaged cord

or plug after the appliance malfunctions, or has

been dropped/damaged in any manner. Discard

fan or contact customer service.

11. Do not run cord under carpeting. Do not cover cord

with throw rugs, runner, or similar coverings. Do

not route cord under furniture or appliances.

Arrange cord away from traffic area and where it

will not be tripped over.

12. The use of attachments not recommended or sold

by the appliance manufacturer may cause hazards.

13. Do not let the cord hang over the edge of a table,

counter or come in contact with hot surfaces or

leave exposed to high traffic areas.

14. Do not use outdoors.

15. To disconnect, grip plug and pull from wall outlet.

Never yank on cord.

16. Always use on a dry, level surface.

17. Do not operate fan until fully assembled with all

parts properly in place.

18. This product is intended for household use ONLY

and not for commercial or industrial applications.

19. WARNING: To reduce the risk of electrical shock and

injury to persons, do not use in window.

20. WARNING: To reduce the risk of fire or electric

shock, do not use this fan with any solid-state

speed control device.

21. This product employs overload protection (fuse).

A blown fuse indicates an overload or short-circuit

situation. If the fuse blows, unplug the product

from the outlet. Replace the fuse as per the user

servicing instructions (follow product marking for

proper fuse rating) and check the product. If the

replacement fuse blows, a short circuit may be

present and the product should be discarded or

contact customer service.

22. Use the fan in a well-ventilated area. When in use,

place the fan at least 8" from any walls to ensure

proper air flow. The fan must not be located

immediately below or beside a curtain.

23. Do not obstruct the airflow with any objects or

place anything inside the fan opening.

24. Do not use in extreme temperatures, humidity, or

dusty environments.

25. Do not place any objects on the fan.

26. Do not place the fan directly below a power outlet

or you risk the cord being sucked in.

27. When the fan is oscillating do not manually turn

the fan to avoid damage.

28. This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

WARNING: Chemical Burn Hazard. Keep batteries

away from children. This product contains a lithium

button/coin cell battery. If a new or used lithium button/

coin cell battery is swallowed or enters the body, it can

cause severe internal burns and can lead to death in as

little as 2 hours. Always completely secure the battery

compartment. If the battery compartment does not close

securely, stop using the product, remove the batteries, and

keep it away from children. If you think batteries might

have been swallowed or placed inside any part of the body,

seek immediate medical attention.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY

INSTRUCTIONS

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit in

a polarized outlet only one way. If the plug does not fit fully in the

outlet, reverse the plug. If it still does not fit, contact a qualified

electrician to install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

REMOTE CONTROL AND MOBILE APP

INSTRUCTIONS

ASSEMBLY

Estimated assembly time: 5-10 minutes

No tools required.

NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM

THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR

PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.

1. Align and press together the base halves (figure 2).

2. Remove the lock nut from the fan housing by

rotating counterclockwise (Figure 2, 3).

3. Place the base onto the bottom of the fan housing

and rotate to secure.

4. Place the lock nut onto the bottom of the base and

rotate clockwise to tighten (Figure 3).

5. Place fan upright on a dry, level surface.

OPERATING INSTRUCTIONS (Figure 4)

1. Plug the cord into a standard 120 Volt AC outlet.

2. To turn the fan ON, press the POWER button (A)

located on the control panel or remote control.

The fan will start running in the lowest setting "I"

(LOW).

3. Press the SPEED button (C) to cycle through the 3

speed settings in sequence.

The corresponding indicator light will illuminate to

confirm the selection:

I-Low II-Medium III-High

4. To turn OSCILLATION ON and OFF, press the

Oscillation (B) button.

5. To set automatic shutoff, press the TIMER button (E).

When set, the fan will run and automatically shut off

after the set duration of time (1-15 hours) has expired.

Note: To set the timer for 15 hours, press the timer

button until all four lights (1H, 2H, 4H, 8H) are

illuminated.

6. To activate SLEEP mode, press the MODE button (D).

This function slows the BREEZE setting by one level

every ten minutes until it reaches LOW.

To activate BREEZE mode, press the MODE button

again.

The fan will cycle through alternating speeds with

brief pauses to simulate a natural outdoor breeze:

BREEZE I: Cycles through low and medium speeds.

BREEZE II: Cycles through medium and low speeds.

BREEZE III: Cycles through medium, high and low

speeds.

To activate POWER BREEZE mode, press the MODE

button again. This function will provide maximum air

velocity.

7. Press mute on the remote control to silence setting

confirmation beeps. To re-activate setting

confirmation beeps, press mute again.

A. Power Button

B. Oscillation/Wifi Pairing Button

C. Speed Button

D. Mode Button

E. Timer Button

F. Speed Setting Indicator Lights

G. Timer Indicator Lights

H. Mode Indicator Lights

I. Mute Button

J. Wifi Indicator Light

E A B

A. Control Panel

B Fan Housing

C. Base Halves

D. Remote Control

Storage

E. Remote Control

Figure 1

Lock Nut

Figure 2

Figure 3

Power Cord

Figure 5

ASSEMBLY AND OPERATING

INSTRUCTIONS

PARTS AND ASSEMBLY

Figure 4

REMOTE CONTROL

NOTE: THIS UNIT INCLUDES ONE LITHIUM BATTERY,

CR2025/3V. PLEASE REMOVE THE PROTECTIVE PLASTIC

FROM THE REMOTE CONTROL BATTERY BEFORE OPERATION.

To operate the fan with the remote control, aim it

towards the control panel on top of the fan tower.

The remote control can operate from a distance up to

approximately 16 feet from the fan body and at an

angle variation of 15-20 degrees.

Avoid exposing the display panel to direct sunlight, as it

may interfere with signal transmission.

Replacing the Remote Control Battery (Figure 5)

The cells should be disposed of properly, including

keeping them away from children. Even used cells may

cause injury.

1. Locate the battery compartment on the back of the

remote control handset. Press tab and pull out battery.

2. Remove old battery.

3. Place new battery into

battery compartment.

4. Slide battery

compartment into the

remote control handset.

NOTES:

1. Remove the battery

from the remote when it

is not in use for an

extended period.

2. Remove the battery

before discarding the remote at the end of its useful

product life.

3. Do not discard used batteries into household trash

containers. Contact your local government for disposal

or recycling practices in your area.

SETTING UP THE HOLMES MOBILE APP

Note: A 2.4 GHz Wi-Fi network is required.

1. Download the Holmes

App from Google Play, the

Apple App Store or the QR code located on the back of

this Instruction Manual.

2. Create an account by following the steps in the App.

3. Enter the verification code you received to confirm

your account and create a password.

4. Select "Add Device" or the plus (+) sign in the top

right corner.

Auto Pairing

(Recommended Method)

1. Ensure Bluetooth

, Wi-Fi, and

GPS are activated on your mobile

device.

2. Press and hold the OSC/WIFI

PAIRING button on the fan's

control panel for 5 seconds, until an

audible beep is heard and the red

indicator light is flashing which

indicates the device is in pairing

mode. Note: if pairing is not

completed within 2-3 minutes, the device will exit pairing

mode and step 2 will need to be repeated.

3. Select “Auto Scan” at the top of the screen.

You should see an icon for the fan that has been found.

4. Click "Next."

5. Input your Wi-Fi name and password.

6. Wait for the connection to be established.

7. Press "Done" (top right-hand corner).

Your fan is now available to control from your smartphone.

Manual Pairing

If Auto Pairing is unsuccessful:

1. Ensure Bluetooth

, Wi-Fi, and GPS are activated on

your mobile device.

2. Ensure the fan has been powered off for 10 seconds

or more, then power on the fan.

3. Press and hold the OSC/WIFI PAIRING button on

the fan's control panel for 5 seconds, until the red

indicator light is flashing. The device is now in pairing

mode. Note: if pairing is not completed within 2-3

minutes, the device will exit pairing mode and step 3 will

need to be repeated.

4. On your mobile device, click "add device", then

select "add manually" at the top of the screen.

Click the fan icon.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions

should always be taken including the following:

1. Read all instructions before using this appliance.

2. Use fan only for purposes described in the

instruction manual. This fan is not for continuous

operation or equivalent.

3. To protect against electrical shock do not immerse

unit, plug or cord in water or spray with liquids and

plug the appliance directly into a 120V AC electrical

outlet.

4. Close supervision is necessary when any appliance

is used near children.

5. Not intended for use by children

6. Unplug from outlet when not in use, when moving

fan from one location to another, before putting on

or taking off parts and before cleaning.

7. Avoid contact with moving parts.

8. Do not operate in the presence of explosive and/or

flammable fumes.

9. To avoid fire hazard, NEVER place the cord under

rugs or any parts near an open flame, cooking or

other heating appliance.

10. Do not operate any appliance with a damaged cord

or plug after the appliance malfunctions, or has

been dropped/damaged in any manner. Discard

fan or contact customer service.

11. Do not run cord under carpeting. Do not cover cord

with throw rugs, runner, or similar coverings. Do

not route cord under furniture or appliances.

Arrange cord away from traffic area and where it

will not be tripped over.

12. The use of attachments not recommended or sold

by the appliance manufacturer may cause hazards.

13. Do not let the cord hang over the edge of a table,

counter or come in contact with hot surfaces or

leave exposed to high traffic areas.

14. Do not use outdoors.

15. To disconnect, grip plug and pull from wall outlet.

Never yank on cord.

16. Always use on a dry, level surface.

17. Do not operate fan until fully assembled with all

parts properly in place.

18. This product is intended for household use ONLY

and not for commercial or industrial applications.

19. WARNING: To reduce the risk of electrical shock and

injury to persons, do not use in window.

20. WARNING: To reduce the risk of fire or electric

shock, do not use this fan with any solid-state

speed control device.

21. This product employs overload protection (fuse).

A blown fuse indicates an overload or short-circuit

situation. If the fuse blows, unplug the product

from the outlet. Replace the fuse as per the user

servicing instructions (follow product marking for

proper fuse rating) and check the product. If the

replacement fuse blows, a short circuit may be

present and the product should be discarded or

contact customer service.

22. Use the fan in a well-ventilated area. When in use,

place the fan at least 8" from any walls to ensure

proper air flow. The fan must not be located

immediately below or beside a curtain.

23. Do not obstruct the airflow with any objects or

place anything inside the fan opening.

24. Do not use in extreme temperatures, humidity, or

dusty environments.

25. Do not place any objects on the fan.

26. Do not place the fan directly below a power outlet

or you risk the cord being sucked in.

27. When the fan is oscillating do not manually turn

the fan to avoid damage.

28. This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

WARNING: Chemical Burn Hazard. Keep batteries

away from children. This product contains a lithium

button/coin cell battery. If a new or used lithium button/

coin cell battery is swallowed or enters the body, it can

cause severe internal burns and can lead to death in as

little as 2 hours. Always completely secure the battery

compartment. If the battery compartment does not close

securely, stop using the product, remove the batteries, and

keep it away from children. If you think batteries might

have been swallowed or placed inside any part of the body,

seek immediate medical attention.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY

INSTRUCTIONS

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit in

a polarized outlet only one way. If the plug does not fit fully in the

outlet, reverse the plug. If it still does not fit, contact a qualified

electrician to install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

REMOTE CONTROL AND MOBILE APP

INSTRUCTIONS

ASSEMBLY

Estimated assembly time: 5-10 minutes

No tools required.

NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM

THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR

PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.

1. Align and press together the base halves (figure 2).

2. Remove the lock nut from the fan housing by

rotating counterclockwise (Figure 2, 3).

3. Place the base onto the bottom of the fan housing

and rotate to secure.

4. Place the lock nut onto the bottom of the base and

rotate clockwise to tighten (Figure 3).

5. Place fan upright on a dry, level surface.

OPERATING INSTRUCTIONS (Figure 4)

1. Plug the cord into a standard 120 Volt AC outlet.

2. To turn the fan ON, press the POWER button (A)

located on the control panel or remote control.

The fan will start running in the lowest setting "I"

(LOW).

3. Press the SPEED button (C) to cycle through the 3

speed settings in sequence.

The corresponding indicator light will illuminate to

confirm the selection:

I-Low II-Medium III-High

4. To turn OSCILLATION ON and OFF, press the

Oscillation (B) button.

5. To set automatic shutoff, press the TIMER button (E).

When set, the fan will run and automatically shut off

after the set duration of time (1-15 hours) has expired.

Note: To set the timer for 15 hours, press the timer

button until all four lights (1H, 2H, 4H, 8H) are

illuminated.

6. To activate SLEEP mode, press the MODE button (D).

This function slows the BREEZE setting by one level

every ten minutes until it reaches LOW.

To activate BREEZE mode, press the MODE button

again.

The fan will cycle through alternating speeds with

brief pauses to simulate a natural outdoor breeze:

BREEZE I: Cycles through low and medium speeds.

BREEZE II: Cycles through medium and low speeds.

BREEZE III: Cycles through medium, high and low

speeds.

To activate POWER BREEZE mode, press the MODE

button again. This function will provide maximum air

velocity.

7. Press mute on the remote control to silence setting

confirmation beeps. To re-activate setting

confirmation beeps, press mute again.

A. Power Button

B. Oscillation/Wifi Pairing Button

C. Speed Button

D. Mode Button

E. Timer Button

F. Speed Setting Indicator Lights

G. Timer Indicator Lights

H. Mode Indicator Lights

I. Mute Button

J. Wifi Indicator Light

E A B

A. Control Panel

B Fan Housing

C. Base Halves

D. Remote Control

Storage

E. Remote Control

Figure 1

Lock Nut

Figure 2

Figure 3

Power Cord

Figure 5

ASSEMBLY AND OPERATING

INSTRUCTIONS

PARTS AND ASSEMBLY

Figure 4

REMOTE CONTROL

NOTE: THIS UNIT INCLUDES ONE LITHIUM BATTERY,

CR2025/3V. PLEASE REMOVE THE PROTECTIVE PLASTIC

FROM THE REMOTE CONTROL BATTERY BEFORE OPERATION.

To operate the fan with the remote control, aim it

towards the control panel on top of the fan tower.

The remote control can operate from a distance up to

approximately 16 feet from the fan body and at an

angle variation of 15-20 degrees.

Avoid exposing the display panel to direct sunlight, as it

may interfere with signal transmission.

Replacing the Remote Control Battery (Figure 5)

The cells should be disposed of properly, including

keeping them away from children. Even used cells may

cause injury.

1. Locate the battery compartment on the back of the

remote control handset. Press tab and pull out battery.

2. Remove old battery.

3. Place new battery into

battery compartment.

4. Slide battery

compartment into the

remote control handset.

NOTES:

1. Remove the battery

from the remote when it

is not in use for an

extended period.

2. Remove the battery

before discarding the remote at the end of its useful

product life.

3. Do not discard used batteries into household trash

containers. Contact your local government for disposal

or recycling practices in your area.

SETTING UP THE HOLMES MOBILE APP

Note: A 2.4 GHz Wi-Fi network is required.

1. Download the Holmes

App from Google Play, the

Apple App Store or the QR code located on the back of

this Instruction Manual.

2. Create an account by following the steps in the App.

3. Enter the verification code you received to confirm

your account and create a password.

4. Select "Add Device" or the plus (+) sign in the top

right corner.

Auto Pairing

(Recommended Method)

1. Ensure Bluetooth

, Wi-Fi, and

GPS are activated on your mobile

device.

2. Press and hold the OSC/WIFI

PAIRING button on the fan's

control panel for 5 seconds, until an

audible beep is heard and the red

indicator light is flashing which

indicates the device is in pairing

mode. Note: if pairing is not

completed within 2-3 minutes, the device will exit pairing

mode and step 2 will need to be repeated.

3. Select “Auto Scan” at the top of the screen.

You should see an icon for the fan that has been found.

4. Click "Next."

5. Input your Wi-Fi name and password.

6. Wait for the connection to be established.

7. Press "Done" (top right-hand corner).

Your fan is now available to control from your smartphone.

Manual Pairing

If Auto Pairing is unsuccessful:

1. Ensure Bluetooth

, Wi-Fi, and GPS are activated on

your mobile device.

2. Ensure the fan has been powered off for 10 seconds

or more, then power on the fan.

3. Press and hold the OSC/WIFI PAIRING button on

the fan's control panel for 5 seconds, until the red

indicator light is flashing. The device is now in pairing

mode. Note: if pairing is not completed within 2-3

minutes, the device will exit pairing mode and step 3 will

need to be repeated.

4. On your mobile device, click "add device", then

select "add manually" at the top of the screen.

Click the fan icon.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions

should always be taken including the following:

1. Read all instructions before using this appliance.

2. Use fan only for purposes described in the

instruction manual. This fan is not for continuous

operation or equivalent.

3. To protect against electrical shock do not immerse

unit, plug or cord in water or spray with liquids and

plug the appliance directly into a 120V AC electrical

outlet.

4. Close supervision is necessary when any appliance

is used near children.

5. Not intended for use by children

6. Unplug from outlet when not in use, when moving

fan from one location to another, before putting on

or taking off parts and before cleaning.

7. Avoid contact with moving parts.

8. Do not operate in the presence of explosive and/or

flammable fumes.

9. To avoid fire hazard, NEVER place the cord under

rugs or any parts near an open flame, cooking or

other heating appliance.

10. Do not operate any appliance with a damaged cord

or plug after the appliance malfunctions, or has

been dropped/damaged in any manner. Discard

fan or contact customer service.

11. Do not run cord under carpeting. Do not cover cord

with throw rugs, runner, or similar coverings. Do

not route cord under furniture or appliances.

Arrange cord away from traffic area and where it

will not be tripped over.

12. The use of attachments not recommended or sold

by the appliance manufacturer may cause hazards.

13. Do not let the cord hang over the edge of a table,

counter or come in contact with hot surfaces or

leave exposed to high traffic areas.

14. Do not use outdoors.

15. To disconnect, grip plug and pull from wall outlet.

Never yank on cord.

16. Always use on a dry, level surface.

17. Do not operate fan until fully assembled with all

parts properly in place.

18. This product is intended for household use ONLY

and not for commercial or industrial applications.

19. WARNING: To reduce the risk of electrical shock and

injury to persons, do not use in window.

20. WARNING: To reduce the risk of fire or electric

shock, do not use this fan with any solid-state

speed control device.

21. This product employs overload protection (fuse).

A blown fuse indicates an overload or short-circuit

situation. If the fuse blows, unplug the product

from the outlet. Replace the fuse as per the user

servicing instructions (follow product marking for

proper fuse rating) and check the product. If the

replacement fuse blows, a short circuit may be

present and the product should be discarded or

contact customer service.

22. Use the fan in a well-ventilated area. When in use,

place the fan at least 8" from any walls to ensure

proper air flow. The fan must not be located

immediately below or beside a curtain.

23. Do not obstruct the airflow with any objects or

place anything inside the fan opening.

24. Do not use in extreme temperatures, humidity, or

dusty environments.

25. Do not place any objects on the fan.

26. Do not place the fan directly below a power outlet

or you risk the cord being sucked in.

27. When the fan is oscillating do not manually turn

the fan to avoid damage.

28. This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

WARNING: Chemical Burn Hazard. Keep batteries

away from children. This product contains a lithium

button/coin cell battery. If a new or used lithium button/

coin cell battery is swallowed or enters the body, it can

cause severe internal burns and can lead to death in as

little as 2 hours. Always completely secure the battery

compartment. If the battery compartment does not close

securely, stop using the product, remove the batteries, and

keep it away from children. If you think batteries might

have been swallowed or placed inside any part of the body,

seek immediate medical attention.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY

INSTRUCTIONS

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit in

a polarized outlet only one way. If the plug does not fit fully in the

outlet, reverse the plug. If it still does not fit, contact a qualified

electrician to install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

REMOTE CONTROL AND MOBILE APP

INSTRUCTIONS

ASSEMBLY

Estimated assembly time: 5-10 minutes

No tools required.

NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM

THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR

PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.

1. Align and press together the base halves (figure 2).

2. Remove the lock nut from the fan housing by

rotating counterclockwise (Figure 2, 3).

3. Place the base onto the bottom of the fan housing

and rotate to secure.

4. Place the lock nut onto the bottom of the base and

rotate clockwise to tighten (Figure 3).

5. Place fan upright on a dry, level surface.

OPERATING INSTRUCTIONS (Figure 4)

1. Plug the cord into a standard 120 Volt AC outlet.

2. To turn the fan ON, press the POWER button (A)

located on the control panel or remote control.

The fan will start running in the lowest setting "I"

(LOW).

3. Press the SPEED button (C) to cycle through the 3

speed settings in sequence.

The corresponding indicator light will illuminate to

confirm the selection:

I-Low II-Medium III-High

4. To turn OSCILLATION ON and OFF, press the

Oscillation (B) button.

5. To set automatic shutoff, press the TIMER button (E).

When set, the fan will run and automatically shut off

after the set duration of time (1-15 hours) has expired.

Note: To set the timer for 15 hours, press the timer

button until all four lights (1H, 2H, 4H, 8H) are

illuminated.

6. To activate SLEEP mode, press the MODE button (D).

This function slows the BREEZE setting by one level

every ten minutes until it reaches LOW.

To activate BREEZE mode, press the MODE button

again.

The fan will cycle through alternating speeds with

brief pauses to simulate a natural outdoor breeze:

BREEZE I: Cycles through low and medium speeds.

BREEZE II: Cycles through medium and low speeds.

BREEZE III: Cycles through medium, high and low

speeds.

To activate POWER BREEZE mode, press the MODE

button again. This function will provide maximum air

velocity.

7. Press mute on the remote control to silence setting

confirmation beeps. To re-activate setting

confirmation beeps, press mute again.

A. Power Button

B. Oscillation/Wifi Pairing Button

C. Speed Button

D. Mode Button

E. Timer Button

F. Speed Setting Indicator Lights

G. Timer Indicator Lights

H. Mode Indicator Lights

I. Mute Button

J. Wifi Indicator Light

E A B

A. Control Panel

B Fan Housing

C. Base Halves

D. Remote Control

Storage

E. Remote Control

Figure 1

Lock Nut

Figure 2

Figure 3

Power Cord

Figure 5

ASSEMBLY AND OPERATING

INSTRUCTIONS

PARTS AND ASSEMBLY

Figure 4

REMOTE CONTROL

NOTE: THIS UNIT INCLUDES ONE LITHIUM BATTERY,

CR2025/3V. PLEASE REMOVE THE PROTECTIVE PLASTIC

FROM THE REMOTE CONTROL BATTERY BEFORE OPERATION.

To operate the fan with the remote control, aim it

towards the control panel on top of the fan tower.

The remote control can operate from a distance up to

approximately 16 feet from the fan body and at an

angle variation of 15-20 degrees.

Avoid exposing the display panel to direct sunlight, as it

may interfere with signal transmission.

Replacing the Remote Control Battery (Figure 5)

The cells should be disposed of properly, including

keeping them away from children. Even used cells may

cause injury.

1. Locate the battery compartment on the back of the

remote control handset. Press tab and pull out battery.

2. Remove old battery.

3. Place new battery into

battery compartment.

4. Slide battery

compartment into the

remote control handset.

NOTES:

1. Remove the battery

from the remote when it

is not in use for an

extended period.

2. Remove the battery

before discarding the remote at the end of its useful

product life.

3. Do not discard used batteries into household trash

containers. Contact your local government for disposal

or recycling practices in your area.

SETTING UP THE HOLMES MOBILE APP

Note: A 2.4 GHz Wi-Fi network is required.

1. Download the Holmes

App from Google Play, the

Apple App Store or the QR code located on the back of

this Instruction Manual.

2. Create an account by following the steps in the App.

3. Enter the verification code you received to confirm

your account and create a password.

4. Select "Add Device" or the plus (+) sign in the top

right corner.

Auto Pairing

(Recommended Method)

1. Ensure Bluetooth

, Wi-Fi, and

GPS are activated on your mobile

device.

2. Press and hold the OSC/WIFI

PAIRING button on the fan's

control panel for 5 seconds, until an

audible beep is heard and the red

indicator light is flashing which

indicates the device is in pairing

mode. Note: if pairing is not

completed within 2-3 minutes, the device will exit pairing

mode and step 2 will need to be repeated.

3. Select “Auto Scan” at the top of the screen.

You should see an icon for the fan that has been found.

4. Click "Next."

5. Input your Wi-Fi name and password.

6. Wait for the connection to be established.

7. Press "Done" (top right-hand corner).

Your fan is now available to control from your smartphone.

Manual Pairing

If Auto Pairing is unsuccessful:

1. Ensure Bluetooth

, Wi-Fi, and GPS are activated on

your mobile device.

2. Ensure the fan has been powered off for 10 seconds

or more, then power on the fan.

3. Press and hold the OSC/WIFI PAIRING button on

the fan's control panel for 5 seconds, until the red

indicator light is flashing. The device is now in pairing

mode. Note: if pairing is not completed within 2-3

minutes, the device will exit pairing mode and step 3 will

need to be repeated.

4. On your mobile device, click "add device", then

select "add manually" at the top of the screen.

Click the fan icon.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions

should always be taken including the following:

1. Read all instructions before using this appliance.

2. Use fan only for purposes described in the

instruction manual. This fan is not for continuous

operation or equivalent.

3. To protect against electrical shock do not immerse

unit, plug or cord in water or spray with liquids and

plug the appliance directly into a 120V AC electrical

outlet.

4. Close supervision is necessary when any appliance

is used near children.

5. Not intended for use by children

6. Unplug from outlet when not in use, when moving

fan from one location to another, before putting on

or taking off parts and before cleaning.

7. Avoid contact with moving parts.

8. Do not operate in the presence of explosive and/or

flammable fumes.

9. To avoid fire hazard, NEVER place the cord under

rugs or any parts near an open flame, cooking or

other heating appliance.

10. Do not operate any appliance with a damaged cord

or plug after the appliance malfunctions, or has

been dropped/damaged in any manner. Discard

fan or contact customer service.

11. Do not run cord under carpeting. Do not cover cord

with throw rugs, runner, or similar coverings. Do

not route cord under furniture or appliances.

Arrange cord away from traffic area and where it

will not be tripped over.

12. The use of attachments not recommended or sold

by the appliance manufacturer may cause hazards.

13. Do not let the cord hang over the edge of a table,

counter or come in contact with hot surfaces or

leave exposed to high traffic areas.

14. Do not use outdoors.

15. To disconnect, grip plug and pull from wall outlet.

Never yank on cord.

16. Always use on a dry, level surface.

17. Do not operate fan until fully assembled with all

parts properly in place.

18. This product is intended for household use ONLY

and not for commercial or industrial applications.

19. WARNING: To reduce the risk of electrical shock and

injury to persons, do not use in window.

20. WARNING: To reduce the risk of fire or electric

shock, do not use this fan with any solid-state

speed control device.

21. This product employs overload protection (fuse).

A blown fuse indicates an overload or short-circuit

situation. If the fuse blows, unplug the product

from the outlet. Replace the fuse as per the user

servicing instructions (follow product marking for

proper fuse rating) and check the product. If the

replacement fuse blows, a short circuit may be

present and the product should be discarded or

contact customer service.

22. Use the fan in a well-ventilated area. When in use,

place the fan at least 8" from any walls to ensure

proper air flow. The fan must not be located

immediately below or beside a curtain.

23. Do not obstruct the airflow with any objects or

place anything inside the fan opening.

24. Do not use in extreme temperatures, humidity, or

dusty environments.

25. Do not place any objects on the fan.

26. Do not place the fan directly below a power outlet

or you risk the cord being sucked in.

27. When the fan is oscillating do not manually turn

the fan to avoid damage.

28. This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

WARNING: Chemical Burn Hazard. Keep batteries

away from children. This product contains a lithium

button/coin cell battery. If a new or used lithium button/

coin cell battery is swallowed or enters the body, it can

cause severe internal burns and can lead to death in as

little as 2 hours. Always completely secure the battery

compartment. If the battery compartment does not close

securely, stop using the product, remove the batteries, and

keep it away from children. If you think batteries might

have been swallowed or placed inside any part of the body,

seek immediate medical attention.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY

INSTRUCTIONS

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit in

a polarized outlet only one way. If the plug does not fit fully in the

outlet, reverse the plug. If it still does not fit, contact a qualified

electrician to install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

REMOTE CONTROL AND MOBILE APP

INSTRUCTIONS

ASSEMBLY

Estimated assembly time: 5-10 minutes

No tools required.

NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM

THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR

PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.

1. Align and press together the base halves (figure 2).

2. Remove the lock nut from the fan housing by

rotating counterclockwise (Figure 2, 3).

3. Place the base onto the bottom of the fan housing

and rotate to secure.

4. Place the lock nut onto the bottom of the base and

rotate clockwise to tighten (Figure 3).

5. Place fan upright on a dry, level surface.

OPERATING INSTRUCTIONS (Figure 4)

1. Plug the cord into a standard 120 Volt AC outlet.

2. To turn the fan ON, press the POWER button (A)

located on the control panel or remote control.

The fan will start running in the lowest setting "I"

(LOW).

3. Press the SPEED button (C) to cycle through the 3

speed settings in sequence.

The corresponding indicator light will illuminate to

confirm the selection:

I-Low II-Medium III-High

4. To turn OSCILLATION ON and OFF, press the

Oscillation (B) button.

5. To set automatic shutoff, press the TIMER button (E).

When set, the fan will run and automatically shut off

after the set duration of time (1-15 hours) has expired.

Note: To set the timer for 15 hours, press the timer

button until all four lights (1H, 2H, 4H, 8H) are

illuminated.

6. To activate SLEEP mode, press the MODE button (D).

This function slows the BREEZE setting by one level

every ten minutes until it reaches LOW.

To activate BREEZE mode, press the MODE button

again.

The fan will cycle through alternating speeds with

brief pauses to simulate a natural outdoor breeze:

BREEZE I: Cycles through low and medium speeds.

BREEZE II: Cycles through medium and low speeds.

BREEZE III: Cycles through medium, high and low

speeds.

To activate POWER BREEZE mode, press the MODE

button again. This function will provide maximum air

velocity.

7. Press mute on the remote control to silence setting

confirmation beeps. To re-activate setting

confirmation beeps, press mute again.

A. Power Button

B. Oscillation/Wifi Pairing Button

C. Speed Button

D. Mode Button

E. Timer Button

F. Speed Setting Indicator Lights

G. Timer Indicator Lights

H. Mode Indicator Lights

I. Mute Button

J. Wifi Indicator Light

E A B

A. Control Panel

B Fan Housing

C. Base Halves

D. Remote Control

Storage

E. Remote Control

Figure 1

Lock Nut

Figure 2

Figure 3

Power Cord

Figure 5

ASSEMBLY AND OPERATING

INSTRUCTIONS

PARTS AND ASSEMBLY

Figure 4

REMOTE CONTROL

NOTE: THIS UNIT INCLUDES ONE LITHIUM BATTERY,

CR2025/3V. PLEASE REMOVE THE PROTECTIVE PLASTIC

FROM THE REMOTE CONTROL BATTERY BEFORE OPERATION.

To operate the fan with the remote control, aim it

towards the control panel on top of the fan tower.

The remote control can operate from a distance up to

approximately 16 feet from the fan body and at an

angle variation of 15-20 degrees.

Avoid exposing the display panel to direct sunlight, as it

may interfere with signal transmission.

Replacing the Remote Control Battery (Figure 5)

The cells should be disposed of properly, including

keeping them away from children. Even used cells may

cause injury.

1. Locate the battery compartment on the back of the

remote control handset. Press tab and pull out battery.

2. Remove old battery.

3. Place new battery into

battery compartment.

4. Slide battery

compartment into the

remote control handset.

NOTES:

1. Remove the battery

from the remote when it

is not in use for an

extended period.

2. Remove the battery

before discarding the remote at the end of its useful

product life.

3. Do not discard used batteries into household trash

containers. Contact your local government for disposal

or recycling practices in your area.

SETTING UP THE HOLMES MOBILE APP

Note: A 2.4 GHz Wi-Fi network is required.

1. Download the Holmes

App from Google Play, the

Apple App Store or the QR code located on the back of

this Instruction Manual.

2. Create an account by following the steps in the App.

3. Enter the verification code you received to confirm

your account and create a password.

4. Select "Add Device" or the plus (+) sign in the top

right corner.

Auto Pairing

(Recommended Method)

1. Ensure Bluetooth

, Wi-Fi, and

GPS are activated on your mobile

device.

2. Press and hold the OSC/WIFI

PAIRING button on the fan's

control panel for 5 seconds, until an

audible beep is heard and the red

indicator light is flashing which

indicates the device is in pairing

mode. Note: if pairing is not

completed within 2-3 minutes, the device will exit pairing

mode and step 2 will need to be repeated.

3. Select “Auto Scan” at the top of the screen.

You should see an icon for the fan that has been found.

4. Click "Next."

5. Input your Wi-Fi name and password.

6. Wait for the connection to be established.

7. Press "Done" (top right-hand corner).

Your fan is now available to control from your smartphone.

Manual Pairing

If Auto Pairing is unsuccessful:

1. Ensure Bluetooth

, Wi-Fi, and GPS are activated on

your mobile device.

2. Ensure the fan has been powered off for 10 seconds

or more, then power on the fan.

3. Press and hold the OSC/WIFI PAIRING button on

the fan's control panel for 5 seconds, until the red

indicator light is flashing. The device is now in pairing

mode. Note: if pairing is not completed within 2-3

minutes, the device will exit pairing mode and step 3 will

need to be repeated.

4. On your mobile device, click "add device", then

select "add manually" at the top of the screen.

Click the fan icon.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic safety precautions

should always be taken including the following:

1. Read all instructions before using this appliance.

2. Use fan only for purposes described in the

instruction manual. This fan is not for continuous

operation or equivalent.

3. To protect against electrical shock do not immerse

unit, plug or cord in water or spray with liquids and

plug the appliance directly into a 120V AC electrical

outlet.

4. Close supervision is necessary when any appliance

is used near children.

5. Not intended for use by children

6. Unplug from outlet when not in use, when moving

fan from one location to another, before putting on

or taking off parts and before cleaning.

7. Avoid contact with moving parts.

8. Do not operate in the presence of explosive and/or

flammable fumes.

9. To avoid fire hazard, NEVER place the cord under

rugs or any parts near an open flame, cooking or

other heating appliance.

10. Do not operate any appliance with a damaged cord

or plug after the appliance malfunctions, or has

been dropped/damaged in any manner. Discard

fan or contact customer service.

11. Do not run cord under carpeting. Do not cover cord

with throw rugs, runner, or similar coverings. Do

not route cord under furniture or appliances.

Arrange cord away from traffic area and where it

will not be tripped over.

12. The use of attachments not recommended or sold

by the appliance manufacturer may cause hazards.

13. Do not let the cord hang over the edge of a table,

counter or come in contact with hot surfaces or

leave exposed to high traffic areas.

14. Do not use outdoors.

15. To disconnect, grip plug and pull from wall outlet.

Never yank on cord.

16. Always use on a dry, level surface.

17. Do not operate fan until fully assembled with all

parts properly in place.

18. This product is intended for household use ONLY

and not for commercial or industrial applications.

19. WARNING: To reduce the risk of electrical shock and

injury to persons, do not use in window.

20. WARNING: To reduce the risk of fire or electric

shock, do not use this fan with any solid-state

speed control device.

21. This product employs overload protection (fuse).

A blown fuse indicates an overload or short-circuit

situation. If the fuse blows, unplug the product

from the outlet. Replace the fuse as per the user

servicing instructions (follow product marking for

proper fuse rating) and check the product. If the

replacement fuse blows, a short circuit may be

present and the product should be discarded or

contact customer service.

22. Use the fan in a well-ventilated area. When in use,

place the fan at least 8" from any walls to ensure

proper air flow. The fan must not be located

immediately below or beside a curtain.

23. Do not obstruct the airflow with any objects or

place anything inside the fan opening.

24. Do not use in extreme temperatures, humidity, or

dusty environments.

25. Do not place any objects on the fan.

26. Do not place the fan directly below a power outlet

or you risk the cord being sucked in.

27. When the fan is oscillating do not manually turn

the fan to avoid damage.

28. This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

WARNING: Chemical Burn Hazard. Keep batteries

away from children. This product contains a lithium

button/coin cell battery. If a new or used lithium button/

coin cell battery is swallowed or enters the body, it can

cause severe internal burns and can lead to death in as

little as 2 hours. Always completely secure the battery

compartment. If the battery compartment does not close

securely, stop using the product, remove the batteries, and

keep it away from children. If you think batteries might

have been swallowed or placed inside any part of the body,

seek immediate medical attention.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY

INSTRUCTIONS

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit in

a polarized outlet only one way. If the plug does not fit fully in the

outlet, reverse the plug. If it still does not fit, contact a qualified

electrician to install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

REMOTE CONTROL AND MOBILE APP

INSTRUCTIONS

ASSEMBLY

Estimated assembly time: 5-10 minutes

No tools required.

NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM

THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR

PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.

1. Align and press together the base halves (figure 2).

2. Remove the lock nut from the fan housing by

rotating counterclockwise (Figure 2, 3).

3. Place the base onto the bottom of the fan housing

and rotate to secure.

4. Place the lock nut onto the bottom of the base and

rotate clockwise to tighten (Figure 3).

5. Place fan upright on a dry, level surface.

OPERATING INSTRUCTIONS (Figure 4)

1. Plug the cord into a standard 120 Volt AC outlet.

2. To turn the fan ON, press the POWER button (A)

located on the control panel or remote control.

The fan will start running in the lowest setting "I"

(LOW).

3. Press the SPEED button (C) to cycle through the 3

speed settings in sequence.

The corresponding indicator light will illuminate to

confirm the selection:

I-Low II-Medium III-High

4. To turn OSCILLATION ON and OFF, press the

Oscillation (B) button.

5. To set automatic shutoff, press the TIMER button (E).

When set, the fan will run and automatically shut off

after the set duration of time (1-15 hours) has expired.

Note: To set the timer for 15 hours, press the timer

button until all four lights (1H, 2H, 4H, 8H) are

illuminated.

6. To activate SLEEP mode, press the MODE button (D).

This function slows the BREEZE setting by one level

every ten minutes until it reaches LOW.

To activate BREEZE mode, press the MODE button

again.

The fan will cycle through alternating speeds with

brief pauses to simulate a natural outdoor breeze:

BREEZE I: Cycles through low and medium speeds.

BREEZE II: Cycles through medium and low speeds.

BREEZE III: Cycles through medium, high and low

speeds.

To activate POWER BREEZE mode, press the MODE

button again. This function will provide maximum air

velocity.

7. Press mute on the remote control to silence setting

confirmation beeps. To re-activate setting

confirmation beeps, press mute again.

A. Power Button

B. Oscillation/Wifi Pairing Button

C. Speed Button

D. Mode Button

E. Timer Button

F. Speed Setting Indicator Lights

G. Timer Indicator Lights

H. Mode Indicator Lights

I. Mute Button

J. Wifi Indicator Light

E A B

A. Control Panel

B Fan Housing

C. Base Halves

D. Remote Control

Storage

E. Remote Control

Figure 1

Lock Nut

Figure 2

Figure 3

Power Cord

Figure 5

ASSEMBLY AND OPERATING

INSTRUCTIONS

PARTS AND ASSEMBLY

Figure 4
