PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Instruction Manual
Item: 12863
Model: 32510453
40 Inch
Digital Tower Fan
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this fan.
2. Use fan only for purposes described in the instruction
manual. This fan is not for continuous operation
or equivalent.
3. To protect against electrical shock do not immerse
fan, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC
electrical outlet.
4. Not intended for use by children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under
rugs or any parts near an open flame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
return to an authorized service facility for
examination and/or repair.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
11. WARNING: To reduce the risk of fire, electric
shock, or injury to persons, do not use replacement
parts or attachments not recommended by the
manufacturer (e.g. parts made at home using a 3D
printer).
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all
parts properly in place.
17. This fan is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of electrical shock
and injury to persons, do not use in window.
19. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
20. This fan employs overload protection (fuse). A blown
fuse indicates an overload or short-circuit situation. If
the fuse blows, unplug the product from the outlet.
Replace the fuse as per the user servicing instructions
(follow product marking for proper fuse rating) and
check the product. If the replacement fuse blows, a
short circuit may be present and the product should
be discarded or contact our customer service.
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE THESE IMPORTANT
SAFETY INSTRUCTIONS
21. a) Remove and immediately recycle or dispose of
used batteries according to local regulations and
keep away from children. Do NOT dispose of
batteries in household trash or incinerate.
b) Even used batteries may cause severe injury or
death.
c) Call a local poison control center for treatment
information.
d) Always use the same size and grade battery as
CR2025 for this product.
e) Always use a voltage 3V battery for this product.
f) Non-rechargeable batteries are not to be
recharged.
g) Do not force discharge, recharge, disassemble,
heat above 104ºF or incinerate. Doing so may
result in injury due to venting, leakage or explosion
resulting in chemical burns.
h) Ensure the batteries are installed correctly
according to polarity (+ and -).
i) Do not mix old and new batteries, different brands
or types of batteries, such as alkaline, carbon-zinc, or
rechargeable batteries.
j) Remove and immediately recycle or dispose of
batteries from equipment not used for an extended
period of time according to local regulations.
k) Always completely secure the battery
compartment. If the battery compartment does not
close securely, stop using the product, remove the
batteries, and keep them away from children.
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
WARNI
NG
CR2025/
3
V
• INGESTION HAZARD: This product contains a button cell or coin battery.
• DEATH or serious injury can occur if ingested.
• A swallowed button cell or coin battery can cause Internal
Chemical Burns in as little as 2 hours.
• KEEP new and used batteries OUT OF REACH of CHILDREN
• Seek immediate medical attention if a battery is suspected to be
swallowed or inserted inside any part of the body.
F E AT UR E S - O P ER AT IO N S F E AT U R E S - O P E R AT I O N S
B
A
I
K
J
H
E
F
G
C
D
A. Control Panel
B. LED Display
C. Fan Housing
D. Base Halves
E. Remote Control Storage
F. Cord Clip
G. Remote Control
H. Locking Posts
I. Locking Holes
J. Cord Management
K. Holes
Figure 1
Figure 2
Step 1
Step 2
Step 3
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
A
B
E
D
C
C
C
B
D
A
E
F
F E AT UR E S - O P E R AT I O N S F E AT UR E S - O P E R AT IO N S
ASSEMBLY INSTRUCTIONS:
(SEE FIGURE 1 & 2)
Estimated assembly time: 5-10 minutes.
Tool-Free.
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
1. Assemble Base Halves (D) around power cord. Refer
to Figure 2, Step 1.
2. To secure the base halves together, slide the posts of
one base half into the slots of the second base half.
Refer to Figure 2, Step 1.
3. Line up the Holes (K) with the Locking Posts (H) on
the bottom of the Fan Housing (C). Refer to Figure 2,
Step 2.
4. Secure by turning the base counterclockwise around
the Locking Posts until an audible click is heard. Refer
to Figure 2, Step 2. To remove the base, press the
button "PUSH" with one hand then simultaneously
rotate the base clockwise with the other hand until
the base is removed.
5. Run the power cord through the base Cord
Management (J). Refer to Figure 2, Step 3.
6. Turn fan right side up and place on a dry and
level surface.
OPERATING INSTRUCTIONS:
(SEE FIGURE 3)
1. Plug the cord into a standard 120 volt AC outlet.
2. To turn the fan on, press the POWER button (B) located
on the control panel or remote control, indicator light
will illuminate.
3. Press the SPEED button (C) to cycle through 6 speed
settings in sequence. The corresponding indicator light
will illuminate.
4. To turn the oscillation on and off, press the OSC
button (D) located on the control panel or
remote control.
5. To change the mode, press the MODE button (E) to
cycle through the mode selection; indicator light will
be on to indicate the Normal, Breeze, Sleep, or Power
Breeze modes.
6. To set your fan to automatically shut off, press the
TIMER button (A) located on the control panel or the
remote control. When set, the fan will run and
automatically shut off after the set duration of time
(1, 2, 4, 8, 12 hours) has expired.
7. To silence setting confirmation beeps, press the MUTE
button (F) located on the remote control; MUTE icon
(I) on the LED display will illuminate. Press the button
again to re-activate setting confirmation beeps; MUTE
icon (I) on the LED display will turn off.
8. To turn the fan off press the POWER button (B)
located on the control panel or remote control.
Figure 3
A. Timer Button
B. Power Button
C. Speed Button
D. Oscillation Button
E. Mode Button
F. Mute Button (Remote Control)
G
H
I
J
K
L
H
M
NOTE: Your fan features a LED display panel. When a
specific feature is activated on your fan, the LED panel
will illuminate with the corresponding icon(s) showing
which features have been activated. (See Figure 5) The
display panel will turn off after 30 sec of inactivity
however your fan will continue to operate, press any
button to re-activate panel.
REMOTE CONTROL:
(SEE FIGURE 4)
NOTE: REMOVE THE PROTECTIVE STICKER FROM THE
REMOTE CONTROL BATTERY BEFORE OPERATION.
This remote includes one lithium CR2025/3V button cell
battery. Remove battery before discarding the remote.
Battery Replacement
Button cell batteries should be disposed of properly,
including keeping it away from children. Even used
button cell batteries may cause injury.
1. Locate the battery compartment on the bottom back
of the remote control.
Push tab and pull out battery tray.
2. Remove the old battery.
3. Place the new battery into the battery tray.
4. Slide battery tray into the battery compartment of
the remote control.
NOTES:
1. Remove the battery from the remote control when it
is not being used for an extended period of time.
2. Remove used battery promptly.
3. Do not discard used batteries into household trash
containers.
Contact your local government for disposal or
recycling practices in your area.
F E AT U R E S - O P E R AT I O NS
Figure 5
G. Speed
H. Timer
I. Mute
J. Breeze
K. Sleep
L. Power Breeze
M. Oscillation
Figure 4
C L EA N I N G A N D M A I N TE N A N C E
CLEANING/MAINTENANCE INSTRUCTIONS
Follow these instructions to correctly and safely care for
this fan.
REPLACEABLE FUSE
If the (2.5 Amp, 125 Volt)
replaceable fuse blows, please
contact customer service for
information on how to order
a new fuse. Follow the below
instructions to replace the
fuse on the plug.
User Servicing
Instructions
1. Unplug the fan. Grasp plug and remove from the
receptacle or other outlet device. Do not unplug by
pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover down towards the prongs.
NOTE: Ensure that fuse cover is completely open
before attempting to remove fuse.
3. Remove fuse carefully by using a small screwdriver
to pry the fuse out of the compartment by the metal
ends of the fuse. (see Figure 5)
4. Place plug on a solid, flat surface. Insert new
2.5 Amp, 125 Volt fuse into fuse compartment and
use a small screwdriver to secure the metal ends of
the fuse into the compartment.
CAUTION: Risk of fire. Replace fuse only with
2.5 Amp, 125 Volt fuse.
5. Slide fuse cover closed completely. If fuse cover is
difficult to close, make sure fuse is secured in place
completely by pressing down on metal ends of the
fuse.
6. Risk of fire. Do not replace attachment plug. Contains
a safety device (fuse) that should not be removed.
Discard product if the attachment plug is damaged.
FAN CLEANING
1. Always unplug the fan before cleaning.
2. Do not allow water to drip on or enter into fan
housing.
3. Be sure to use a soft cloth moistened with a mild
soap solution.
4. Do not use gasoline, thinner or benzene as a
cleaner.
Unplug the fan, then clean the fan grill, housing, and
base with a soft, damp cloth. Do not attempt to remove
the fan blade. Use CAUTION around the housing area.
Do not allow the motor or other electrical components to
be exposed to water.
FAN STORAGE
• Store the fan in a clean, dry location between seasons
or when not in use for an extended period.
• Keep the fan protected from dirt and dust during storage.
NOTE: This fan can also be used during the cold winter
season to circulate warm air throughout your home.
Figure 5
Fuse
Metal ends
Fuse cover
For inquiries regarding recycling and proper disposal
of this product, please contact your local waste
management facility.
F C C STAT E M E N T
FCC STATEMENT
Potential for Radio/Television interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
The product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
the interference will not occur in a particular installation. If the product does cause harmful interference to radio or
television reception, which can be determined by turning the product on or off, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
The following importer is the responsible party:
Company Name: SEG Products US Corp.
Address: 8 The Green, Suite #6962, Dover, DE 19901
Telephone: 1-959-202-4223
WA R R A N T Y I NF O R M ATI O N
Printed In China
©
2024 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH026-011124
3 YEAR LIMITED WARRANTY
This device has a 3 Year limited warranty for the original purchaser from the date of purchase against workmanship
and defects in material. If under normal use, your product fails to operate, a replacement or refund will be provided to
you with proof of purchase. Star Elite Inc. may deny claims of damage caused by misuse or modifications of
this product.
Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at:
www.getholmesfans.com
info@getholmesfans.com
1-866-769-3166 (8:30 am - 5:00 pm EST) Monday - Friday
Our customer service will be happy to assist you.
