INSTRUCTION MANUAL
MICROWAVE OVEN
CM-M202RAF(RD)/CM-M202RAF(CM)/CM-M202RAF(GN)
Directory
3
4
7
8
11
14
19
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
IMPORTANT SAFETY INSTRUCTIONS WARNING
GROUNDING INSTRUCTIONS
UTENSILS
SETTING UP YOUR OVEN
OPERATION INSTRUCTION
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND
KEEP FOR FUTURE REFERENCE.
If you follow the instructions, your oven will provide you with many
years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY.
TROUBLE SHOOTING
(a) Do not attempt to operate this oven with the door open
since this can result in harmful exposure to microwave
energy. It is important not to break or tamper with the
safety interlocks.
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired
by a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect the
lifespan of the apparatus and lead to a dangerous situation.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
SPECIFICATIONS
CM-M202RAF(RD)/CM-M202RAF(CM)/CM-M202RAF(GN)
230V-240V ~50Hz
1200W-1270W
750W-800W
20L
255mm
439.5x357.2x258.2mm
11kg
Parameter
Model
Rated Voltage
Rated Input Power(Microwave)
Rated Output Power(Microwave)
Oven Capacity
Turntable Diameter
External Dimensions
Net Weight
Content
EN-3
IMPORTANT SAFETY INSTRUCTIONS WARNING
To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
1. Read and follow the specific:"PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY".
2. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they
are older than 8 and supervised. Children less than 8
years of age shall be kept away unless continuously
supervised.
3. Keep the appliance and its cord out of reach of children
less than 8 years.
4. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.( For appliance with
type Y attachment)
5. WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.
EN-4
EN-5
6. WARNING: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
7. WARNING: Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
8. When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of ignition.
9. Only use utensils that are suitable for use in microwave
ovens.
10. If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
11. Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must be taken
when handling the container.
12. The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
13. Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
14. The oven should be cleaned regularly and any food
deposits removed.
15. Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
16. The appliance must not be installed behind a
decorative door in order to avoid overheating. (This is
not applicable for appliances with decorative door.)
17. Only use the temperature probe recommended for
this oven.(for ovens provided with a facility to use a
temperature-sensing probe.)
EN-6
18. The microwave oven shall not be placed in a cabinet
unless it has been tested in a cabinet.
19. The microwave oven must be operated with the
decorative door open. (for ovens with a decorative door.)
20. This appliance is intended to be used in household
and similar applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- by clients in hotels, motels and other residential type
environments;
- farm houses;
- bed and breakfast type environments.
21. The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
22. Metallic containers for food and beverages are not
allowed during microwave cooking.
23. The appliance shall not be cleaned with a steam
cleaner.
24. The appliance is intended to be used freestanding.
25. The rear surface of appliances shall be placed against
a wall.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
EN-7
TO REDUCE THE RISK OF INJURY TO PERSONS
GROUNDING INSTALLATION
DANGER
Electric Shock Hazard Touching some of the internal components can cause serious
personal injury or death. Do not disassemble this appliance.
WARNING
Electric Shock Hazard Improper use of the grounding can result in electric shock.
Do not plug into an outlet until appliance is properly installed and grounded.
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood or if doubt exists as to whether the appliance is properly
grounded.
If it is necessary to use an extension cord, use only a 3-wire extension cord.
1. A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. If a long cord set or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least
as great as the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord.
3) The long cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over unintentionally.
EN-8
CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a
damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door
glass since they can scratch the surface, which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the food cooked can
touch: Place half a lemon in a bowl, add 300ml (1/2 pint) water and heat on 100%
microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.
Personal Injury Hazard It is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
See the instructions on "Materials you can use in microwave oven or to be avoided in
microwave oven."
There may be certain non-metallic utensils that are not safe to use for microwaving.
If in doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the
utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave
cooking.
4. Do not exceed 1 minute cooking time.
UTENSILS
CAUTION
EN-9
Utensils Remarks
MATERIALS YOU CAN USE IN MICROWAVE OVEN
Browning dish
Dinnerware
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment paper
Plastic
Plastic wrap
Thermometers
Wax paper
Follow manufacturer’s instructions. The bottom of browning
dish must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage may cause the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not
use cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most
glass jars are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Microwave-safe only (meat and candy thermometers).
Use as a cover to prevent splattering and retain moisture.
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic containers
soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as directed
by package.
EN-10
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause arcing and could cause a fire in the oven.
May cause a fire in the oven.
Wood will dry out when used in the microwave oven and may
split or crack.
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Utensils Remarks
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
EN-11
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Turntable Installation
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C BE D
Hub (underside)
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Glass tray
Turntable ring assembly
Turntable shaft
EN-12
Countertop Installation
Installation
Remove all packing material and accessories. Examine the oven for any damage such
as dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to protect
the magnetron.
1. Select a level surface that provide enough open space for the intake and/or outlet
vents.
(1) The minimum installation height is 85cm.
(2) The rear surface of appliance shall be placed against a wall. Leave a minimum
clearance of 30cm above the oven, a minimum clearance of 20cm is required
between the oven and any adjacent walls.
(3) Do not remove the legs from the bottom of the oven.
(4) Blocking the intake and/ or outlet openings can damage the oven.
(5) Place the oven as far away from radios and TV as possible. Operation of microwave
oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the
frequency is the same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing
appliance. If installed near or over a heat source, the oven could be damaged and the
warranty would be void.
20cm
30cm
20cm
min85cm
0cm
The accessible
surface may be
hot during operation.
EN-13
Control Panel
Weight
Auto Menu
Kitchen Timer/Clock
Microwave
Defrost
Stop/Clear
Start/+30Sec.
EN-14
This microwave oven uses modern electronic control to adjust cooking parameters
to meet your needs better for cooking.
Note: 1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press " Stop/Clear " or no
operation in one minute, the oven will exit the setting.
When the microwave oven is electrified,the oven will display "0:00", buzzer will ring
once.
1) Press " Kitchen Timer/Clock " twice ,the hour figures will flash.
2) Turn " " to adjust the hour figures, the input time should be with in 0--23.
3) Press " Kitchen Timer/Clock ", the minute figures will flash.
4) Turn " " to adjust the minute figures, the input time should be with in 0--59.
5) Press " Kitchen Timer/Clock " to finish clock setting. ":" will flash.
OPERATION INSTRUCTION
1.Clock Setting
1) Press " Kitchen Timer/Clock " once,the screen will display "00:00".
2) Turn " " to enter the correct timer. (The maximum cooking time is 95 minutes)
3) Press " Start/+30Sec. " to confirm setting.
4) When the kitchen time is reached, clock indicator will go out. The buzzer will ring
5 times. If the clock has been set (24-hour system), screen will display the current
time.
2.Kitchen Timer
Note: The kitchen Time is different from 24-hour system. Kitchen Timer is a timer.
EN-15
1) Press the " Microwave " key once, and "P100" display.
2) Press the " Microwave " for times or turn " " to select the microwave power
"P100", "P80", "P50", "P30", "P10" will display in order.
3) Press " Start/+30Sec. " to confirm.
4)Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.)
5) Press " Start/+30Sec. " to start cooking.
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
NOTE : the step quantities for the adjustment time of the coding switch are as follow:
Microwave Power Chart
3. Microwave Cooking
1) In waiting state, press " Start/+30Sec. " key to cook with 100% power level for 30
seconds. Each press on the same key can increase 30 seconds. The maximum
cooking time is 95 minutes.
2) During the microwave cooking and time defrost process, press " Start/+30Sec. " to
increase the cooking time.
3) In waiting state , turn " " left to choose the cooking time directly. After choosing
the time, press " Start/+30Sec. " to start cooking. The microwave power is 100%.
Note: Under the states of auto menu and weight defrost, cooking time cannot be
increased by pressing " Start/+30Sec. "
4. Speedy Cooking
Press
Microwave Power
TwiceOnce Thrice 4 times 5 times
80% 50% 30% 10%100%
Display
P100 P80 P50 P30 P10
EN-16
1) Press " Defrost " once, the screen will display "dEF1".
2) Turn " " to select the food weight. The range of weight is 100-2000g.
3) Press " Start/+30Sec. " key to start defrosting.
5. Defrost by weight
1) Press " Defrost " twice, the screen will display "dEF2".
2) Turn " " to select the cooking time.
3) Press " Start/+30Sec. " key to start defrosting.
Note: The defrost power is P30. And it cannot be changed.
6. Defrost By Time
Two stages can be maximumly set. If one stages is defrosting, it should be put in the
first stage. The buzzer will ring once after each stage and the next stage will begin.
Note: Auto menu cannot be set as one of the multi-stage.
Example: if you want to defrost the food for 5 minutes, then to cook with 80%
microwave power for 7 minutes. The steps are as following:
1) Press " Defrost " twice, the screen will display "dEF2".
2) Turn " " to adjust the defrost time of 5 minutes;
3) Press " Microwave " once;
4) Turn " " to choose 80% microwave power till "P80" display;
5) Press " Start/+30Sec. " to confirm;
6) Turn " " to adjust the cooking time of 7 minutes;
7) Press " Start/+30Sec. " to start cooking.
7. Multi-Stage Cooking
EN-17
1) In waiting states, turn " " right to choose the menu from" A-1" to "A-8";
2) Press " Start/+30Sec. " to confirm the menu you choose;
3) Turn " " to choose the food weight;
4) Press " Start/+30Sec. " to start cooking;
5) After cooking finish, the buzzer sounds five times.
8. Auto Menu
1) In cooking state of microwave press " Microwave ", the current power will be
displayed for 3 seconds.
2) During cooking state, press " Kitchen Timer/Clock " to check the current time. It
will be displayed for 3 seconds.
9. Inquiring Function
Lock: In waiting state, press " Stop/Clear " for 3 seconds, there will be a long "beep"
denoting entering the children-lock state .
Lock quitting: In locked state, press " Stop/Clear " for 3 seconds, there will be a long
"beep" denoting that the lock is released.
10. Lock-out Function for Children
1) The buzzer will sound once when turning the knob at the beginning;
2) " Start/+30Sec. " must be pressed to continue cooking if the door is opened during
cooking;
3) Once the cooking programme has been set , " Start/+30Sec. " is not pressed in 1
minute. The current time will be displayed. The setting will be cancelled.
4) The buzzer sounds once by efficient press, inefficient press will be no responce.
5) The buzzer will sound five times to remind you when cooking is finished.
11. Specification
EN-18
Auto menu Chart
Display
300g
50g(with water 450 ml )
100g(with water 800 ml)
350g
450g
200g
200g
400g
600g
400ml
Menu
Weight
A-1
AUTO REHEAT
A-2
VEGETABLE
A-5
PASTA
A-4
MEAT
A-7
PIZZA
A-6
POTATO
A-8
SOUP
300
50
100
350
450
200
400
400
200g
200
400g
400
600g
600
200g
200
400g
400
250g
250
400g
200ml
200
250g
350g
450g
A-3
FISH
250
350
450
400
600
200
Microwave oven interfering
TV reception
Radio and TV reception may be interfered when
microwave oven operating. It is similar to the
interference of small electrical appliances, like
mixer, vacuum cleaner, and electric fan.
It is normal.
Dim oven light
Oven can not
be started.
(1) Power cord not
plugged in tightly.
Unplug. Then plug again
after 10 seconds.
Replace fuse or reset circuit
breaker (repaired by
professional personnel
of our company)
Test outlet with other
electrical appliances.
Close door well.
(3) Trouble with outlet.
(4) Door not closed well.
(2) Fuse blowing or
circuit breaker
works.
Oven does not heat.
In low power microwave cooking, oven light may
become dim. It is normal.
In cooking, steam may come out of food. Most will
get out from vents. But some may accumulate
on cool place like oven door. It is normal.
Steam accumulating on
door, hot air out of vents
Oven started accidentally
with no food in.
It is forbidden to run the unit without any food inside.
It is very dangerous.
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.
Normal
Trouble Possible Cause Remedy
EN-19
TROUBLE SHOOTING
PN:16170000A77449
UKservice_MO@comfeeappliance.com
Midea Home Appliances UK Ltd
5 New Street Square,London, United Kingdom, EC4A 3TW
