BMO625
the Quick Touch
™
Compact
Instruction Booklet
2
CONTENTSCONTENTS
3 Breville recommends safety first
9 Know your Breville product
10 Assembling your Breville product
12 Operating your Breville product
– Smart Reheat settings 18
– Smart Defrost settings 21
– A BIT MORE™ 24
– Shortcuts Panel 26
33 Hints & Tips
35 Care & Cleaning
36 Troubleshooting
3
BREVILLE RECOMMENDS SAFETY FIRSTBREVILLE RECOMMENDS SAFETY FIRST
At Breville we are very safety conscious. We design and manufacture consumer products with
the safety of you, our valued customer, foremost in mind. In addition we ask that you exercise
a degree of care when using any electrical appliance and adhere to the following precautions.
READ ALL INSTRUCTIONS
CAREFULLY BEFORE USE AND
SAVE FOR FUTURE REFERENCE
• Remove and safely discard any packaging
material and promotional labels before
using the Breville microwave oven for the
first time.
• To eliminate a choking hazard for young
children, remove and safely discard the
protective cover that is fitted to the power
plug of the Breville microwave oven.
• Do not place the microwave oven near the
edge of a bench or table during operation.
Ensure all surfaces are level, clean and free
of water or any other substances.
• Do not place the microwave oven on or
near a hot gas or electric burner, or where
it could touch a heated oven.
• When using the microwave oven, provide
adequate air space above and on all sides
for air circulation. (see page 10 Installation,
point 2).
• Always operate the microwave oven on
a heat-resistant surface. Do not use on a
cloth-covered surface, near curtains or
other flammable materials.
• Do not use the microwave oven on a metal
surface, for example a sink drain board.
• Always ensure the microwave oven is
properly assembled before connecting to
the power outlet and operating. Do not use
the oven without the turntable roller and
glass turntable in place. Ensure the glass
turntable is positioned correctly into the
indents on the turntable roller.
• The microwave oven is not intended to be
operated by means of an external timer or
separate remote control system.
• Never use the microwave oven without
food or water in the oven cavity. Operating
the microwave oven when empty could
cause damage to the appliance.
• Do not leave the microwave oven
unattended when in use.
• Do not touch hot surfaces. Allow the
microwave oven to cool before moving or
cleaning any parts.
• Do not place or store anything on top
of the microwave oven except Breville
nominated chopping board.
• Always ensure the microwave oven is
turned off at the power outlet and the cord
is unplugged from the power outlet before
attempting to move the appliance, when
not in use, if left unattended and before
disassembling, cleaning or storing.
• Keep the appliance clean. Follow the
cleaning instructions provided in this
book (page 35).
• Always turn the microwave oven off by
pressing the STOP/CLEAR button, switch
off at the power outlet and unplug at the
power outlet when it is not in use.
• Before cleaning, always press STOP/
CLEAR position, switch off at the power
outlet and unplug at the power outlet.
IMPORTANT SAFETY INSTRUCTIONS
4
BREVILLE RECOMMENDS SAFETY FIRSTBREVILLE RECOMMENDS SAFETY FIRST
IMPORTANT SAFEGUARDS FOR
ALL ELECTRICAL APPLIANCES
• Fully unwind the power cord before use.
• Do not let the power cord hang over
the edge of a bench or table, touch hot
surfaces or become knotted.
• To protect against electric shock do not
immerse the power cord, power plug or
appliance in water or any other liquid.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
• It is recommended to regularly inspect
the appliance. To avoid a hazard do not
use the appliance if power cord, power
plug or appliance becomes damaged in
any way. Return the entire appliance to
the nearest authorised Breville Service
Centre for examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Breville Service Centre.
• This appliance is for household use only.
Do not use this appliance for anything
other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.
• The installation of a residual current
device (safety switch is recommended to
provide additional safety protection when
using electrical appliances. It is advisable
that a safety switch with a rated residual
operating current not exceeding 30mA be
installed in the electrical circuit supplying
the appliance. See your electrician for
professional advice.
• Always turn the appliance to the OFF
position, switch off at the power outlet
and unplug at the power outlet when the
appliance is not in use.
• Before cleaning, always turn the appliance
to the OFF position, switch off at the
power outlet, unplug at the power outlet
and remove the power cord, if detachable,
from the appliance and allow all parts
to cool.
• Do not place this appliance on or near
a heat source, such as hot plate, oven
or heaters.
• Position the appliance at a minimum
distance of 20cm away from walls,
curtains and other heat or stream
sensitive materials and provide
adequate space above and on all sides
for air circulation.
5
BREVILLE RECOMMENDS SAFETY FIRST
BREVILLE RECOMMENDS SAFETY FIRST
SPECIAL SAFETY
INSTRUCTIONS FOR YOUR
MICROWAVE OVEN
• Wipe the oven cavity with a soft, damp
cloth after each use. Leaving food residue,
grease or fat in the cavity could cause the
microwave oven cavity to overheat and
may cause the microwave oven to smoke
or catch fire.
• The microwave oven should be cleaned
regularly and any food splattering inside
the cavity should be removed. Failure to
maintain the microwave oven in a clean
condition could lead to deterioration of the
surface, adversely affecting the life of the
microwave oven and possibly resulting in
a hazardous situation.
• If the door seals or any of the microwave
oven is damaged, the microwave oven
must not be operated until it has been
inspected and/or repaired at an authorised
Breville Service Centre.
• The microwave oven is intended for
heating food and beverages. Drying of food
or clothing and heating or warming pads,
slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
• Ensure all food containers and/or plates
are suitable for use in the microwave oven.
This should be done prior to preparing
food for heating or cooking in the
microwave oven. Monitor foods and liquids
heating or cooking in the microwave
oven at all times due to the possibility of
containers igniting.
• Containers or plates suitable for use in the
microwave oven should not exceed the
width of the glass turntable as this may
impede the rotation of the turntable and
result in food being unevenly cooked.
• Liquids or other foods must not be heated
in sealed containers since they are liable
to explode.
• Some containers and/or plates may appear
suitable for use in the microwave oven but
may be coated in a glaze that will absorb
the microwave energy, overheat and cause
the container to crack. The glaze may also
prevent the food from heating/cooking.
• Food and/or liquids should not be heated
or cooked directly on the glass turntable.
Food and/or liquids must be placed into a
suitable microwave-proof container before
placing onto the glass turntable.
• Food and/or liquids should not be heated
or cooked in plastic or paper containers or
bags, unless specified a suitable for use by
the manufacturer, due to the possibility of
containers exploding or igniting.
• When heating food in plastic or paper
containers, keep an eye on the oven due to
the possibility of ignition.
• Metal clips or twist ties should be removed
from the packaging as these could cause
sparking and/or fire.
• Do not use recycled paper or kitchen paper
towelling when cooking. Recycled paper
may contain small metal or other impurities
which could cause sparking and/or fire.
• Do not use metal containers or utensils in
the microwave oven as these could cause
sparking and/or fire.
6
BREVILLE RECOMMENDS SAFETY FIRST
BREVILLE RECOMMENDS SAFETY FIRST
• Only use utensils that are suitable for use
in microwave ovens.
• Food grade foil should not be used in
the microwave oven as this could cause
sparking and/or fire.
• Ensure that lids and caps covering
containers are removed prior to
placing liquids and/or foods into the
microwave oven.
• Feeding bottles and baby food jars should
have lids and caps removed before
warming or heating in the microwave oven.
To avoid burns or scalding after heating,
the contents should be stirred or shaken
and the temperature checked before
serving.
• Always ensure the temperature of food or
drink which has been heated or cooked
in the microwave oven has been tested
before eating, drinking or serving to others,
especially children, disabled or
elderly people.
• The heating of liquids and beverages in
the microwave oven can result in delayed
eruptive boiling. Care must be taken when
handling any containers containing hot
liquids or beverages.
• Do not heat popcorn in the microwave
oven unless it has been commercially
packaged for microwave use. There may be
a number of un-popped kernels that may
overcook and burn when popping popcorn.
Do not use oil unless recommended by
the manufacturer. Do not pop popcorn
longer than the manufacturer’s instructions
(popping time should not exceed
3 minutes). Longer cooking could cause
scorching or fire.
• Do not cook any food surrounded by a
membrane (such as potatoes, chicken
liver, egg yolks, oysters, etc) without first
piercing the membrane several times with
a fork or similar utensils.
• Eggs in the shell and whole hard boiled
eggs should not be cooked or heated in
the microwave oven as they may explode
during cooking, at the end of cooking or
after removing from the microwave oven.
• Do not heat oil or fat in the microwave
oven. Doing so may cause the microwave
oven and/or the oil to overheat and/or
ignite.
• If any smoke is observed, switch off and
unplug the microwave oven at the power
outlet. Keep the door closed to stifle
any flames.
• Do not attempt to operate the microwave
oven by any method other than those
described in this instruction book.
• Do not disconnect the microwave oven
from the power supply by pulling on the
cord to unplug from the power outlet.
• When storing the microwave oven loosely
wind the cord. Do not wrap the cord around
the microwave oven.
• When heating food in plastic or paper
containers, keep an eye on the oven due to
the possibility of ignition.
• The glass window has been specially
treated to make it stronger, more durable
and safer than ordinary glass, however it
is not unbreakable. If dropped or struck
extremely hard, it may break or weaken,
and could at a later time shatter into many
small pieces without apparent cause.
7
BREVILLE RECOMMENDS SAFETY FIRST
• Do not put any foreign material between
the door and door jam of the microwave
oven as this could cause excessive leakage
of microwave energy.
• It is hazardous for anyone other than a
Breville Service Centre to carry out any
service or repair operation that involves the
removal of a cover which gives protection
against exposure to microwave energy.
• When the appliance is operated in the
combination mode, children should only
use the oven under adult supervision due to
the temperature generated.
• Surfaces may be hot during and after use.
• If the apparatus is not maintained in a
good state of cleanliness, its surface could
be degraded and affect the lifespan of the
product and lead to a dangerous situation.
BREVILLE RECOMMENDS SAFETY FIRST
WARNING
• Do not attempt to operate the oven with the
door open since open-door operation can
result in harmful exposure to microwave
energy. It is important not to defeat or
tamper with the safety interlocks.
• Do not place any object between the oven
front face and the door or allow soil or
cleaner residue to accumulate on sealing
surfaces.
• Liquids and other foods must not be heated
in sealed containers since they are liable to
explode.
• If the door or door seals are damaged, the
oven must not be operated until it has been
repaired by a Breville Service Centre. It is
particularly important that the oven door
closes properly and that there is no damage
to the: (1)Door (bent), (2) Hinges and
latches(broken or loosened), (3) Door seals
and sealing surfaces.
8
BREVILLE RECOMMENDS SAFETY FIRST
BREVILLE RECOMMENDS SAFETY FIRST
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
POWER
CONSUMPTION
230–240V, ~50Hz, 1450W
OUTPUT
900W
OUTSIDE
DIMENSIONS
306mm (H)
513mm (W)
443mm (D) with handle
397mm (D) without handle
GLASS
TURNTABLE
DIAMETER
315mm
NET WEIGHT
Approx. 15kg
OVEN
CAPACITY
25 Litres
These specifications may change without notice.
9
KNOW YOUR BREVILLE PRODUCT
A. Viewing window
B. Door handle
Pull handle to open.
C. LCD screen
D. POWER/AMOUNT dial
Turn dial to adjust the power level,
weight & quantity that corresponds
with the food type selected.
E. +30 INSTANT START BUTTON &
START/ FOOD TYPE/ TIME dial
Each press adds 30 second increments
at 100% power. Turn dial to select food
type or time.
A B C
I
E
F
G
H
D
F. SMART REHEAT & DEFROST buttons
Allow you to choose from a range of
common food types with predetermined
times and power levels for selected
weights.
G. STOP/CLEAR button
Press once to pause without cancelling the
program. Press twice to clear the display.
H. A BIT MORE™ button & CHILD LOCK
Press once to add A BIT MORE™ time at
the end of the cooking cycle. Press and
hold for 3 seconds to set child lock.
I. Shortcuts panel
Refer to operation section for
detailed explanation.
10
ASSEMBLING YOUR BREVILLE PRODUCT
BEFORE FIRST USE
Before first use remove all promotional stickers
and packaging material. Carefully unpack
the microwave oven and keep all the packing
material until all the parts of the microwave
oven have been found and the appliance
has been assembled. It is recommended to
keep all the packing material in a safe place
in case you wish to repack the product for
shipping purposes.
To remove any dust that may have
accumulated during packing, wash the
turntable roller and glass turntable in warm
soapy water, rinse in clean water then dry
thoroughly. Wipe the interior and exterior of
the microwave oven with a soft, damp cloth
then dry thoroughly.
ASSEMBLING THE GLASS
TURNTABLE
1. Insert the turntable roller into position in
the indented space in the oven cavity base.
2. Place the glass turntable on top of the
turntable roller, matching the indents of
turntable roller at the center area.
INSTALLATION AND TURNING ON
THE MICROWAVE OVEN
1. Select a level surface that provides
enough open space for the intake and/or
outlet vents.
2. The rear surface of the appliance should
be placed against a wall. A minimum
clearance of 10cm is required between
the microwave and any adjacent walls.
• Leave a minimum clearance 20cm above
the microwave.
• Do not remove the legs from the bottom of
the microwave.
3. Blocking the intake and/or outlet openings
can damage the microwave.
4. Place the microwave as far away from
radios and TV as possible.
5. Operation of microwave may cause
interference to your radio or TV reception.
6. Plug your microwave into a standard
household outlet. Be sure the voltage and
the frequency is the same as the voltage
and the frequency on the rating label.
7. The microwave must not be placed in
a cabinet.
20cm
5cm
5cm
11
ASSEMBLING YOUR BREVILLE PRODUCT
WARNING
• To avoid an electrical circuit overload, it
is recommended that no other appliances
are plugged into the same circuit as your
microwave oven (or other products) when
it is in use.
• Do not install oven over a range cooktop or
other heat-producing appliances. If installed
near or over a heat source, the oven could be
damaged and the warranty would be void.
• Check the oven for any damage, such as
misaligned or bent door, damaged door
seals and sealing surface, broken or loose
door hinges and latches and dents inside
the cavity or on the door. If there is any
damage, do not operate the oven and
contact a Breville service centre.
• Do not immerse the microwave oven, power
cord or plug in water or any other liquid.
12
OPERATING YOUR BREVILLE PRODUCT
The standby screen is now the clock screen
with the 12hr time.
Setting The Clock - 24 Hour Clock Display
The default time is 1:00. The highlighted digits
flash to show it can be adjusted.
Turn the TIME dial to adjust the hours and
Press START button to confirm.
Minutes now flash to show they can be
adjusted. Turn TIME dial to adjust minutes
and press START button to confirm.
The standby screen is now the clock screen
with the 24hr time.
NOTE
To show the clock before standby mode
is activated, press and hold STOP/
CLEAR for 2 seconds.
SETTING THE CLOCK
Press SET CLOCK on shortcuts panel.
The default time is 12hr. The highlighted digits
will flash to show it can be adjusted.
Turn the TIME dial to change between 12hr
and 24hr time. Press START to confirm
your selection.
Setting The Clock - 12 Hour Clock Display
The default time is 1:00. The highlighted digits
flash to show it can be adjusted.
Turn the TIME dial to adjust the hours.
From 1:00 to 11:00 the AM symbol will show.
From 12:00 to 11:00 the PM symbol will show.
Press START button to confirm.
Minutes now flash to show they can be
adjusted. Turn TIME dial to adjust minutes
and press START button to confirm.
13
OPERATING YOUR BREVILLE PRODUCT
SETTING THE UNIT WEIGHT
CONVERSION MEASURE
Press UNITS on shortcuts panel.
The highlighted ounces (oz) will flash to show
it can be adjusted. Turn POWER dial to toggle
between ounces (oz) and grams (g). Press
START button to confirm.
Unit Weight Conversion During Operation
When weight is on the screen, as seen below in
SMART REHEAT CHICKEN setting, pressing
UNITS on shortcuts panel will convert the
weight from grams (g) to ounces (oz).
x 1
SETTING THE BEEP VOLUME
Press BEEP VOL on shortcuts panel.
The default beep volume is LOW.
Turn POWER dial to toggle between LOW,
MEDIUM and HIGH beep volume. Each
position will sound the BEEP VOL selected.
Press START button to confirm.
NOTE
If you forget to press START to confirm
BEEP VOL, the volume level will default
to your selected setting after 1 minute.
14
OPERATING YOUR BREVILLE PRODUCT
SETTING CHILD LOCK
Press and hold the A BIT MORE™ button
for 3 seconds. The CHILD LOCK
symbol will be displayed on the LCD screen.
The clock will be shown if the clock is set.
PRESS & HOLD
FOR 3 SECONDS
To unlock the microwave, press and hold the
A BIT MORE™ button for 3 seconds.
The CHILD LOCK symbol will disappear
from the LCD screen and you will have full
functionality of your microwave.
STANDBY
When the microwave has been idle for
1 minute, STANDBY mode will be activated.
The backlight of the LCD will turn off and the
buttons will no longer be illuminated.
Stand-by mode when the clock is not set.
When the clock has been set STANDBY will
not be displayed on the LCD screen.
Stand-by mode when the clock is set.
To ‘wake up’ the microwave press any button,
turn any dial or open the door.
INDEPENDENT KITCHEN TIMER
The independent kitchen timer can be used as
either a count down or count up timer.
Setting the count down timer
Press TIMER on control panel.
The default time is 00:00.
The highlighted digits flash to show it can be
adjusted. Turn START dial to adjust to your
desired time in seconds, minutes and hours.
Press START button to begin.
The timer begins to count down. To pause the
timer, press STOP/CLEAR button once.
To clear the timer and return to the default
screen press STOP/CLEAR button twice.
STOP
CLEAR
A Bit More
At the end of the timer function, the microwave
will beep 3 times and the word “End” will flash
on the screen.
15
OPERATING YOUR BREVILLE PRODUCT
Setting the count up timer
Press TIMER on control panel.
The default time is 00:00.
The second digits will flash to show it can be
adjusted. Press START button to begin.
The maximum count up time is 95:00
(95 minutes).
The timer begins to count up to 95 minutes.
To pause the timer, press STOP/CLEAR
button once. To clear the timer and return to
the default screen press STOP/CLEAR button
twice.
At the end of the 95 minutes, the microwave
will beep 3 times and the word “End” will flash
on the screen.
NOTE
END will stay on screen for 1 minute
before returning to the default screen.
TIME & POWER LEVEL ADJUSTMENT
Select different times and microwave power
levels by simply turning the TIME and
POWER dials.
The maximum microwave cooking time is
95 minutes (95:00). There are 10 power levels
available.
Turning the TIME Dial
Turn TIME dial to adjust the time. The default
time will be 30 seconds.
Turning The POWER Dial
Turn the POWER dial clockwise. When the
POWER dial is turned clockwise HIGH will
flash and 100% will be displayed.
16
OPERATING YOUR BREVILLE PRODUCT
When the POWER dial is turned anti-clockwise
the POWER LEVEL% will start to decrease
from 100% to 10%, in 10% increments.
100%
90%
80%
70%
60%
50%
40%
30%
20%
10%
NOTE
When the POWER dial is turned
clockwise or anti-clockwise both MELT
and SOFTEN will show on the LCD for
2 seconds then disappear.
MANUAL POWER & TIME
ADJUSTMENT (SMART SETTINGS
& SHORTCUT SETTINGS)
Smart Settings and Shortcut settings have
pre-determined cook times and power levels
to give the best results. However, to suit your
personal preference adjustment of both power
and time is available during the cooking cycle.
NOTE
Adjusting the power level while heating
does not affect the time.
The power bar will reflect the cooking
power level including programs where
variable power levels are used.
It is completely normal in these
programs to see the power bar change
during the cooking cycle.
+30 SEC INSTANT START
Press START/+30 Sec to begin cooking
instantly for 30 seconds with 100% microwave
power. Each additional press will increase
cooking time by 30 seconds.
WHEN COOKING IS FINISHED
At the end of any cooking cycle, the microwave
will beep 3 times, and the word End will flash
on screen.
The word End will stay flashing on the screen
for 5 minutes or once the door is opened.
17
OPERATING YOUR BREVILLE PRODUCT
STOP/CLEAR
Press STOP/CLEAR once to pause
the current function. Press twice to
clear and return to the default screen.
x2
When in the default screen, press once and
hold STOP/CLEAR for 2 seconds to show
the clock.
To return to the default screen press any
button, turn any dial or open the door.
18
OPERATING YOUR SMART REHEAT SETTING
SMART SETTINGS
Choose from SMART REHEAT and
SMART DEFROST.
Then select from a list of commonly used food
types and press START. The microwave will
automatically set the time and power level for
the selected quantity.
SMART REHEAT
The SMART REHEAT setting uses lower
power levels to gently reheat food without
drying or overcooking.
SMART REHEAT setting will heat your food to
perfect serving temperatures.
Press SMART REHEAT button to
enter SMART REHEAT settings,
the microwave will beep once.
Turn TIME/FOOD TYPE dial to select
food type.
As the TIME/FOOD TYPE dial is turned
the arrow shifts and points to what food type
is selected.
Once you have chosen FOOD TYPE, turn
AMOUNT dial to adjust quantity or weight.
19
Press START to begin reheating.
All unselected FOOD TYPES, the Press Start
and Input Quantity prompts are no longer
displayed on the LCD screen. The TIME
appears and begins to countdown.
NOTE
While the microwave is heating
time can be increased or decreased.
Adjusting the heating time does not
affect selected weight or quantity.
FOR BEST RESULTS
Beverage
This setting is suitable to reheat hot drinks
such as coffee and tea that may have
become cold.
It is based on 200ml of beverage at room
temperature.
Choosing the reheat beverage will warm your
drink to approx. 60–65°C which is suitable to
drink right away.
Be aware, that overheating drinks may scold
or burn.
Always position the cups around the outside of
the turntable
Stir heated drinks and allow to stand for 1–2
minutes before consuming.
Leftovers
Suitable for reheating a plate of leftovers from
the refrigerator (approx. 5°C).
A plate of food is equivalent to 300g.
For even reheating, place food onto a
microwave-safe plate or into a bowl. Cover food
with a vented microwave-safe lid or vented
microwave-safe plastic wrap.
Halfway through the reheat program, the oven
will beep and will flash “stir/turn food”
Pause and stir, reseal and press START/
+30 SEC button.
OPERATING YOUR SMART REHEAT SETTING
20
OPERATING YOUR SMART REHEAT SETTING
Meat
Suitable for reheating already cooked meat
only;
Reheat times are based on meat directly from
the refrigerator (approx. 5°C)
Cover with a microwave-safe vented lid or
microwave-safe vented plastic wrap.
Halfway through the reheat program, the oven
will beep and will flash “stir/turn food”
Pause and stir, reseal and press START/
+30 SEC button.
Fish
Suitable for reheating already cooked fish.
Reheat times are based on fish directly from
the refrigerator (approx. 5°c).
It is designed to reheat gently without drying
and overcooking the edges.
Arrange in a single layer in a shallow
microwave safe dish. Cover with a
microwave-safe vented lid or microwave-safe
vented plastic wrap.
Halfway through the reheat program, the oven
will beep and will flash “stir/turn food”
Pause and carefully turn fish if possible. Reseal
and press START/+30 SEC button.
Soup
Suitable for reheating canned soups at
room temperature.
Place soup into a microwave-safe bowl and
cover with a vented microwave-safe lid or
microwave-safe plastic wrap.
Halfway through the reheat program, the oven
will beep and will flash “stir/turn food”
Pause and stir, starting from the outside to
the center.
Reseal and press START/+30 SEC button.
When reheating cold soups from the
refrigerator (approx. 5°C) add an extra 1–2
minutes to the reheat time.
21
OPERATING YOUR SMART DEFROST SETTING
SMART DEFROST
The SMART DEFROST setting is designed to
gently defrost foods without overheating and
drying out of edges.
Press SMART DEFROST button
to enter SMART DEFROST
setting, the microwave will beep once.
Turn TIME/FOOD TYPE dial to select the
food type.
As the TIME/FOOD TYPE dial is turned
the arrow shifts and points to what food type
is selected.
Once you have chosen FOOD TYPE, turn
AMOUNT dial to adjust quantity or weight.
Press START to commence defrosting.
All unselected FOOD TYPES, the Press Start
and Input Quantity prompts are no longer
displayed on the LCD screen. The TIME
appears and begins to countdown.
NOTE
While the microwave is defrosting
time can be increased or decreased.
Adjusting the defrosting time does not
affect selected weight or quantity.
OPERATING YOUR SMART DEFROST SETTING
22
OPERATING YOUR SMART DEFROST SETTING
FOR BEST RESULTS
• Defrost times are for thoroughly frozen
food that has been in the freezer for at least
24 hours and maintained at temperatures
of –18°C or lower.
• When freezing meats, poultry and fish,
use good quality plastic wrap, bags and
containers.
• Always freeze meats in a single layer no
thicker than 2cm.
• To separate meat, such as chicken pieces
or steak, place wax paper or plastic film
between each layer.
• For best results, form mincemeat into a
doughnut shape before freezing.
• Ensure that all air has been removed and
packaging has been sealed securely.
• Label the packs with type and cut of meat,
date and weight.
• Remove any packaging and bags from
frozen meats before defrosting.
• Shield thin ends of chops, steaks or
chicken with foil to prevent overheating
and cooking of those areas.
• Position foods in a single layer with thinner
parts in the center and thicker ends around
the outside of the turntable.
• After the defrost cycle, most foods will
still be somewhat icy in the center when
removed from the microwave. Stand food
for 5–15 minutes until completely thawed.
Frozen meals
The SMART DEFROST FROZEN MEALS
setting is suitable for defrosting homemade
frozen casseroles, curries and meat sauces.
Defrost times are based on frozen meals
directly from the freezer (approx. –18°C)
Remove frozen meal from any packaging and
place into a microwave-safe container. Cover
with a microwave-safe vented lid or vented
microwave-safe plastic wrap.
OPERATING YOUR SMART DEFROST SETTING
Halfway through the reheat program, the oven
will beep and will flash “stir/turn food”.
Pause and stir food from the outside towards
the center; reseal and press START/
+30 SEC button.
For meals which contain large pieces of meat
such as chicken pieces, carefully break up any
thawed parts and stir or turn meat over. Frozen
meals will not be hot.
Choose from the SMART REHEAT
settings to heat meals to food safe and
serving temperatures.
Chicken
For chicken pieces; position chicken pieces in
a single layer in a microwave-safe dish, plate or
container.
Arrange thicker ends around the outside of the
turntable. Shield thinner pieces such as wings
with foil to prevent overheating and cooking.
Halfway through the defrost program, the oven
will beep and will flash “stir/turn food”.
Pause and turn over chicken pieces. Press
START/+30 SEC button to restart program.
Once program has finished, remove chicken
from oven and stand 15-30 minutes to thaw
completely.
For whole chickens, remove from original
packaging. Shield wings and leg tips with foil.
Place chicken, breast side down onto a
microwave-safe rack placed over a plate to
catch the drips.
Halfway through the defrost program, the oven
will beep and will flash “stir/turn food”
Pause and turn chicken over. Place a strip of
foil large enough to cover the breast meat and
also the parson’s nose. Press START/
+30 button to restart defrost program.
After defrost cycle has ended, remove chicken
from microwave and discard foil. Rinse under
tap water, making sure to wash the cavity well
to loosen the icy core.
Place onto a clean plate and pat dry. Cover with
cling film and refrigerate for 1–2 hours until
completely thawed.
23
OPERATING YOUR SMART DEFROST SETTING
OPERATING YOUR SMART DEFROST SETTING
Meat
The SMART DEFROST MEAT setting is
suitable for defrosting meat such as beef, lamb
and pork.
It is important that the frozen meat is no
thicker than 2cm.
Remove any packaging, foam trays and
absorbent pads from the meat.
Place directly onto a microwave-safe plate or
shallow dish and preferably place dish onto a
microwave-safe rack or upturned bowl or mug.
Halfway through the defrost program, the oven
will beep and will flash “stir/turn food”
Pause and remove any defrosted meat and set
aside in the refrigerator. Turn the frozen meat
over and return to the microwave oven. Press
START/+30 SEC button to restart program.
At the end of the program, remove meat and
stand 5–15 minutes to thaw completely.
Fish
The SMART DEFROST FISH setting is
programmed to gently thaw delicate fish fillets
without cooking and heating the edges.
For best results, place frozen fillets in a single
layer into a microwave-safe shallow dish.
Place dish onto a microwave-safe rack or
upturned bowl or mug.
Halfway through the defrost program, the oven
will beep and will flash “stir/turn food”
Pause and turn fish pieces over. Cover thin
ends of fish fillets with a small strip of foil and
return to oven. Press START/+30 SEC button
to restart program.
At the end of the program, the fish will still be
somewhat icy in the center. Remove from the
microwave and stand for 5–15 minutes until
completely thawed.
Soup
The SMART DEFROST SOUP setting is
suitable for defrosting frozen prepared soups
directly from the freezer (approx. –18°C).
Remove soup from any packaging and place
into a microwave-safe bowl. Cover with a
vented microwave-safe lid or microwave-safe
plastic wrap.
Halfway through the defrost program, the oven
will beep and will flash “stir/turn food”
Pause program and break up any thawed soup.
Reseal and press START/+30 SEC button..
24
A BIT MORE™
A BIT MORE™
A BIT MORE™ BUTTON
Use A BIT MORE™ when cooking
is finished and your food is not
quite cooked or hot enough.
One simple press of A BIT MORE™ will add
a little extra cooking time.
If A BIT MORE™ is pressed and there is no
previous SMART REHEAT, DEFROST or
shortcut setting the microwave will
default to the basic mode and add 20 seconds
at 100% power.
The A BIT MORE™ button can also be used
after any Smart REHEAT, SMART DEFROST
or shortcut setting.
For example
1. User presses the SMART REHEAT button.
2. Using the TIME/FOOD TYPE dial,
select BEVERAGE.
3. Using the AMOUNT dial select 1 Cup.
4. Press START to begin reheating.
5. Reheat process ends.
25
A BIT MORE™
6. Open the Microwave door, check food,
and if A BIT MORE™ reheating time is
required, close the door. The microwave
will return to the default screen.
7. Press the A BIT MORE™ button to add
A BIT MORE™ cooking time. The timer
will start to count down.
NOTE
As soon as A BIT MORE™ button
is pressed the microwave will start
cooking.
FAVOURITE
The FAVOURITE setting will record your most
used and favourite reheat, defrost or shortcut
setting.
At the press of a button, your favourite
program can be duplicated time after time.
1. Set the microwave to your favourite setting.
2. Open door and press and hold
FAVOURITE button on shortcuts
panel for 2 seconds. The FAVOURITE
symbol will be displayed on the LCD
screen.
3. Press START to begin your favourite
setting.
NOTE
The microwave will save this setting
for future use. Pressing the Favourite
button next time will display your saved
Favourite setting on the LCD screen.
To change your Favourite setting at any
time, repeat steps 1 and 2 above.
A BIT MORE™
26
OPERATING YOUR SHORTCUTS PANEL
OPERATING YOUR SHORTCUTS PANEL
Oatmeal
The shortcuts oatmeal setting is designed to
gently cook your oats to tender without drying
or becoming lumpy.
The shortcuts oatmeal setting uses 2 power
levels, firstly 100% to get the starches activated
and then 50% to gently cook to tender. This
setting is suitable for both rolled and quick
cook oats.
1. Weigh out oats accurately and place into
a microwave-safe bowl. Do not cover
the bowl.
2. Add corresponding water amount.
E.g. if you are cooking 100g of oats you
will need 500ml water. For creamy oats,
use 1 part oats to 5 parts water.
See Oats table on this page.
3. Open the door and press OATMEAL
button on the shortcuts panel.
4. Turn the AMOUNT dial to select weight
and press START to begin cooking.
5. Halfway through the cook program, the
oven will beep and will flash Stir/turn
food. Pause and stir oats and press START
button to continue.
Oats
OATS WATER SERVES
40g (
1
⁄3 cup) 200ml 1–2
60g (½ cup) 300ml 2–3
120g (1 cup) 600ml 3–4
180g (1½ cups) 900ml 4–5
240g (2 cups) 1L 5–6
27
OPERATING YOUR SHORTCUTS PANEL
OPERATING YOUR SHORTCUTS PANEL
Veges
The shortcuts veges (vegetables) setting is
designed to cook vegetables such as broccoli,
green beans, cauliflower, zucchini, potatoes
and carrots.
Cook times are based on vegetables from the
refrigerator (approx. 5°C)
1. Cut into even size pieces to ensure even
cooking throughout.
2. Weigh out veges accurately and place
into a microwave-safe bowl. Cover with a
vented microwave-safe plastic lid, paper
towel or vented microwave-safe plastic
wrap but do not seal.
3. Add 1 tablespoon of water per 100g
of vegetables.
4. Open the door and press VEGES
button on the shortcuts panel.
5. Turn the AMOUNT dial to select weight
and press START to begin cooking.
6. Halfway through the cook program, the
oven will beep and will flash Stir/turn food.
7. Pause and stir veges and press START
button to continue.
NOTE
If using frozen vegetables there is no
need to add extra water.
Simply add an extra 3–5 minutes to the
already programmed cook times for
500g, 700g and 1kg values.
28
OPERATING YOUR SHORTCUTS PANEL
Rice
The shortcuts rice setting is designed to
cook rice so the rice grains remain separate
and tender.
The rice program is intelligently programed to
cook your rice on 2 power levels, firstly at 100%
and then at 50%.
The shortcuts rice setting is suitable for white
rice such as long grain rice, arborio, jasmine
and basmati.
1. Weigh dry rice accurately and wash well
with cold water until water runs clear.
2. Place into a microwave-safe bowl. Cover
with a vented microwave-safe plastic lid or
vented microwave-safe plastic wrap but
do not seal.
3. Add corresponding water amount. Water
to rice ratio is based on 1.5 parts water to
1 part rice. See Rice table on this page.
4. Open the door and press RICE
button on the shortcuts panel.
5. Turn the AMOUNT dial to select weight
and press START to begin cooking.
Rice
RICE WATER SERVES
200g (1 cup) 300ml 2–3
300g (1½ cups) 450ml 4–6
400g (2 cups) 600ml 6–8
500g (2½ cups) 750ml 8–10
OPERATING YOUR SHORTCUTS PANEL
29
OPERATING YOUR SHORTCUTS PANEL
Pizza
The shortcuts pizza setting is designed to
reheat already cooked cold pizza from the
refrigerator (approx. 5°C).
1. Line a microwave-safe plate with paper
towel and place pizza on top. Place thicker
ends towards the outside of the turntable.
Do not cover plate.
2. Open the door and press PIZZA
button on the shortcuts panel.
3. Turn the AMOUNT dial to select slices
and press START to begin reheating.
OPERATING YOUR SHORTCUTS PANEL
30
OPERATING YOUR SHORTCUTS PANEL
Popcorn
The shortcuts popcorn setting is designed
to pop the maximum amount of kernels in
each bag.
1. Open door and press POPCORN
button on shortcuts panel.
2. Turn the AMOUNT dial to select weight
and press START to begin cooking.
COMMON BAG(BAG UNFOLDED)
COMMON
BAG WEIGHT
HEAT USING THE BELOW
PROGRAMMED WEIGHT
25g 25g
38g 38g
85g 85g
100g 100g
OPERATING YOUR SHORTCUTS PANEL
31
OPERATING YOUR SHORTCUTS PANEL
Baked beans
The shortcuts baked beans setting is
programed to reheat baked beans to serving
temperatures without splattering and breaking
up of the beans.
1. Place beans into a suitable microwave-safe
bowl and do not cover.
2. Open door and press BAKED BEANS
button on shortcuts panel.
3. Turn AMOUNT DIAL to select weight and
press START button to begin heating.
COMMON
CAN SIZES
COMMON
CAN WEIGHT
SELECTED
WEIGHT ON
MICROWAVE
120g– 130g 120g
220g 220g
420g– 425g 425g
820g– 850g 850g
OPERATING YOUR SHORTCUTS PANEL
32
OPERATING YOUR SHORTCUTS PANEL
OPERATING YOUR SHORTCUTS PANEL
Melt chocolate
The shortcuts melt chocolate setting
is designed to melt chocolate without
overheating and seizing of the chocolate.
NOTE
The melt chocolate setting was tested
with dark chocolate melts. If using
other types of chocolate, check at short
intervals to prevent possible seizing
of chocolate.
1. Place chocolate in a suitable microwave-
safe bowl and do not cover.
2. Open door and press MELT CHOCOLATE
button on shortcuts panel.
3. Turn AMOUNT DIAL to select weight and
press START button to commence melting.
4. Halfway through the program, the
microwave will beep and will flash
Stir/turn food. Pause and stir chocolate
and press START button to continue.
NOTE
At the end, some of the chocolate
may still hold their shape; stir until
completely melted and smooth.
Soften butter
The shortcuts soften butter setting is designed
to soften butter so it is suitable to cream
immediately in a mixer.
The soften butter setting will soften butter that
has been taken directly from the refrigerator
(approx. 5°C).
Cut butter as a whole piece and place on a
microwave-safe plate or bowl. Do not cover.
1. Open door and press SOFTEN BUTTER
button on shortcuts panel.
2. Turn AMOUNT DIAL to select weight
and press START button to commence
softening.
NOTE
The butter should be soft enough to poke
your finger easily into the centre. The
butter should not be melted.
33
HINTS & TIPS
HINTS & TIPS
INTRODUCTION TO
MICROWAVE COOKING
• Microwaves are invisible waves of electro
magnetic energy similar to radio waves.
Instead of being converted to sound as in
a radio or mobile phones, it is converted
into a heat source which heats food from
the inside.
• Microwaves cook because food molecules
of water, fat and sugar react to the energy
provided by the microwaves. That
energy is absorbed by the food causing
the molecules to vibrate quickly. This
movement creates friction which causes
the food to heat up and therefore cook.
• The energy in a microwave is not
distributed evenly throughout the cavity.
The turntable rotates constantly while
cooking which prevents uneven cooking.
• Microwave cooking is considered the
“cool” cooking method as only the food
gets hot and surrounding air stays cool.
• Microwaves are safe and economical on
electricity with savings up to 50%.
• Ovens need no preheating therefore
the kitchen stays cooler. Cooking is
cleaner with less odours and washing up
is reduced.
• Microwave ovens cook foods rapidly, some
foods are better cooked in a microwave
oven as they retain more flavour, texture
and goodness, such as plain fish fillets, soft
fruit, vegetables and fat free cakes.
• In a microwave the heat is produced
INSIDE the food. In all other conventional
cooking methods, heat is applied from
OUTSIDE through transference of heat by
convection or radiation.
• Microwave energy penetrates the food to
a depth of about 25mm. Small foods under
5cm in diameter such as eggs are
penetrated to the centre from all sides.
In larger foods, energy creates heat in the
outer layer; this then moves to the centre
by conduction, as it does with
conventional cooking.
SOME IMPORTANT TIPS FOR
MICROWAVE COOKING
To help equalize energy in the food so that it
cooks evenly follow these helpful tips.
1. Arrange foods with varying size ends, such
as chicken drumsticks and broccoli with
the thicker or tougher part positioned to
the outside of the dish. This ensures the
parts that require more cooking will receive
more energy, so the food will cook evenly.
2. Covering the dish during cooking holds
in the heat and steam to speed up cooking
time. Use a microwave safe lid or plastic
wrap that has been vented by turning back
one edge at the side of the dish to form a
narrow vent to release excess steam.
3. Choose cooking dishes that are shallow
and preferably have straight sides. Shallow
dishes enable the food to cook faster and
straight edges prevent the edges from
being overcooked.
4. Arrange individual items such as ramekins
or whole potatoes around the outside of
the turntable. Make sure to leave space
between items so the energy can penetrate
from all sides.
5. Use round shaped microwave dishes.
Round shapes cook more evenly than
square or rectangle dishes which absorb
most of the energy in the corners causing
food to overcook and toughen.
6. Heat breads, biscuits or oily food on paper
towel. This prevents the build up of steam
between food and glass turntable, keeping
surfaces crisp and dry. Cover foods with
paper toweling to prevent splatters.
34
HINTS & TIPS
7. Stir foods from the outside to centre of
the dish once or twice during cooking to
equalize heat and speed microwaving.
8. Turn medium to large food items over
twice during microwaving. This enables
even exposure to microwaves.
9. Elevating some types of food such as cakes,
roast vegetables and dough products can
be advantageous. It allows more energy
to penetrate the food from all sides, base
and top. Use a microwave safe plastic or
ceramic rack. If a rack is unavailable, use
an upturned bowl or cup to elevate plates
of food.
10. Do not elevate any special browning
dishes, jugs of sauce or custard, small
quantities of food or mugs of beverages.
11. Internal temperatures of foods continue
to rise so that they continue cooking even
after they have been removed from the
microwave oven. It is better to undercook
food as it will continue to cook once
removed from the microwave.
MICROWAVE UTENSILS
• Containers, plates, dishes, etc. used in
the microwave oven should always be
microwave–safe. Check if stated on the
underside of the utensil or contact the
manufacturer.
• To test if a container, plate or dish
is microwave–safe, place it into the
microwave oven with 1 cup of cold water
(in a microwave–safe cup) and heat on
High (100%) Power for 1 minute. If the
container is hot and the water is cold, the
container is not suitable for microwave
oven use. If the container is cold and the
water is hot, then the container is suitable
for microwave oven use.
• Microwave-safe cookware will not become
hot by the microwave energy, but it will
become hot from contact with hot food.
When the food becomes hot, some of this
heat is transferred to the dish. Always use
oven mitts or clothes to remove hot dishes
from the microwave.
• Metal containers and utensils should not
be used in the microwave oven.
35
CARE & CLEANING
CARE & CLEANING
CARE & CLEANING
• Switch off the microwave oven at the power
outlet and remove the plug from the power
outlet before cleaning.
• Keep the inside of the
microwave oven
clean. When food splatters or spilled
liquids adhere to the microwave oven
internal walls, wipe with a damp cloth.
Mild detergent may be used if the cavity
gets very dirty. Avoid the use of spray and
other harsh cleaners as they may stain,
streak or dull the door surface.
• The outside surfaces should be cleaned
with a damp cloth. To prevent damage to
the operating parts inside the microwave
oven cavity, water should not be allowed to
seep into the ventilation openings.
• Wipe the door and window on both sides of
the door seals and adjacent parts frequently
with a damp cloth to remove any spills or
spatters. Do not use an abrasive cleaner.
• Do not allow the control panel to become
wet. Clean with a soft, damp cloth. When
cleaning the control panel, leave the
microwave oven door open to prevent it
from accidentally turning on.
• If steam accumulates inside or around the
outside of the oven door, wipe with a soft
dry cloth. This may occur when cooking
foods high in moisture or if the microwave
oven is operated under high humidity
conditions, this is normal.
• It is occasionally necessary to remove the
glass turntable for cleaning. Wash the glass
turntable in warm soapy water, rinse in
clean water and dry thoroughly.
• The turntable roller and microwave oven
floor should be cleaned regularly to ensure
the glass turntable rotates correctly and
avoids making excessive noise. Simply wipe
the bottom surface of the microwave with a
soft damp cloth. The turntable roller may be
washed in mild soapy water, rinse in clean
water and dry thoroughly. When removing
the turntable roller from the cavity floor
for cleaning, be sure to replace in the
proper position.
• Remove odours from your microwave oven
by combining a cup of water with the
juice of one lemon in a deep microwave-
safe bowl, microwave on High for
5 minutes. Wipe the microwave oven cavity
thoroughly and dry with a soft cloth.
• When it becomes necessary to replace the
oven light, please consult your Breville
Service Centre to have it replaced.
• Please do not dispose this appliance with
domestic rubbish; it should be taken to the
appropriate disposal centre provided by the
local council municipalities.
• If storing the microwave oven, press the
STOP/CLEAR button, switch off at the
power outlet then unplug the power cord.
Ensure the microwave oven is completely
cool, clean and dry. Secure the roller ring
and glass turntable and close the door.
Do not place heavy objects on top. Store
the microwave oven upright.
BEFORE YOU CALL FOR SERVICE
• Check to ensure that the oven is plugged
in securely. If it is not, remove the plug
from the power outlet, wait 10 seconds and
plug it in again securely.
• Check for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be
operating properly, test the power outlet
with another appliance.
• Check to ensure that the control panel is
programed correctly and the timer is set.
• Check to ensure that the door is securely
closed engaging the door safety lock
system. Otherwise, the door safety lock
system will prevent the microwave from
switching on.
NOTE
If none of the above rectify the situation,
then contact your Breville Service
Centre. Do not try to adjust or repair the
oven yourself.
36
TROUBLESHOOTING
TROUBLESHOOTING
POSSIBLE PROBLEM EASY SOLUTION
Microwave oven
interfering with
radio, TV or similar
equipment.
• Clean door and sealing surface of the oven.
• Reorient the receiving antenna of radio or television.
• Relocate the microwave oven with respect to the receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so that
microwave oven and receiver are on different branch circuits.
Dim microwave
oven light.
• When operating on low power levels, the microwave oven light
may be dimmer.
Steam accumulating
on door and hot air
coming out from vents.
• During operation, steam may be produced. Most will exit
through the vents, however some may accumulate around the
oven door.
POSSIBLE PROBLEM POSSIBLE REASON EASY SOLUTION
Microwave oven will
not start.
• Power cord not
plugged in properly or
switched on.
• Fuse blown or circuit
breaker problem.
• Trouble with outlet.
• Unplug, put the plug in again
and switch on.
• Replace the fuse or reset circuit
breaker.
• Have a professional check that
the outlet is not faulty.
Microwave oven
does not heat.
• Door not closed
properly.
• Ensure door is shut properly.
Glass turntable makes
noise during operation.
• Turntable roller not
assembled properly or
needs to be cleaned.
• Reset and clean if necessary.
LCD time digit shows
EA1A then V1:00 or
similar information
then goes to default
mode.
• Both A BIT MORE™
& SMART REHEAT
button are pressed at
the same time under
the default mode.
• No action required. This is
normal and LCD just shows
the model type and software
version.
LCD time digit shows
00 for a short period
of time then shows 1 or
0 and stays at 1 or 0.
• Both A BIT MORE™
& SMART REHEAT
button are pressed at
the same time under
the default mode.
• If the LCD time digit stays at 0,
send the unit back to repair.
• If LCD time digit stays at 1,
Press STOP/CLEAR to set the
unit back to default mode.
37
NOTES
38
NOTES
39
NOTES
