4.0 QT DIGITAL AIR FRYER
Instruction Manual
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 190190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 1 2023-06-27 4:43 PM2023-06-27 4:43 PM
Thank You for your purchase
Register & sign up for special
announcements and trendy recipes!
Tell us what you think!
Rate, review or ask us a question.
@bellahousewares.com
#getinspired
BellaLife BellaLifestyle
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 290190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 2 2023-06-27 4:43 PM2023-06-27 4:43 PM
Table of Contents
Important Safeguards ........ .........................................................................................2-3
Additional Important Safeguards ........................... .................................................... 4-5
Notes on the Plug ............................ ................................................................................5
Notes on the Cord .........................................................................................................5-6
Plasticizer Warning ..........................................................................................................6
Electric Power ...................................................................................................................6
Getting To Know Your 4 QT Digital Air Fryer ................ .................................................7
Touchscreen Control................ ....................................................................................... 8
Before Using for the First Time.. ................................ ....................................................9
Operating Instructions.. ............... ............................................................................. 9-10
Manual Operation .......................................................................................................... 10
Air Frying Technique ....................................................................................................10-11
A Note on Air Frying Pre-Packaged Frozen Foods ........................................................ 11
For Best Results .................................................................................................................12
User Maintenance Instructions ................. ....................................................................13
Care & Cleaning Instructions .......................... ..............................................................13
Storing Instructions ............................. ...........................................................................13
Warranty.................................................................................................................... 14-15
Table of Contents
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 190190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 1 2023-06-27 4:43 PM2023-06-27 4:43 PM
2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. READ ALL INSTRUCTIONS.
2. Do not touch hot surfaces. Use handles or knobs. Use oven mitts or
potholders.
3. To protect against electric shock do not immerse cord, plugs, or
appliance in water or other liquid.
4. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
5. Children should be supervised to ensure that they do not play with the
appliance.
6. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the appliance.
7. Do not operate any appliance with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner.
Bring it to a qualified technician for examination, repair or electrical or
mechanical adjustment.
8. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
9. Do not use outdoors.
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 290190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 2 2023-06-27 4:43 PM2023-06-27 4:43 PM
3
10. Do not let cord hang over edge of table or counter,
or touch hot surfaces.
11. Do not place on or near a hot gas or electric burner, or in a
heated oven.
12. Extreme caution must be used when moving an appliance containing
hot oil or other hot liquids.
13. Always attach plug to appliance first, then plug cord into the wall
outlet. To disconnect, turn any control to “off”, then remove plug
from wall outlet.
14. Do not use appliance for other than intended use.
15. Make sure the crisping tray is in place before adding food to be
air fried.
16. Make sure the frying basket is locked securely into the front of the Air
Fryer, while the Air Fryer is in operation.
WARNING: The Air Fryer will not operate unless frying basket
is fully closed.
CAUTION: After hot air frying, extreme caution must be used when
handling the hot frying basket, crisping tray, and cooked foods.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 390190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 3 2023-06-27 4:43 PM2023-06-27 4:43 PM
4
ADDITIONAL IMPORTANT
SAFEGUARDS
CAUTION HOT SURFACES: This appliance generates heat and escaping
steam during use. Proper precautions must be taken to prevent the risk
of burns, res, or other injury to persons or damage to property.
CAUTION: This appliance is hot during operation and retains heat for
some time after turning OFF. Always use oven mitts when handling hot
materials and allow metal parts to cool before cleaning. Do not place
anything on top of the appliance while it is operating or while it is hot.
1. All users of this appliance must read and understand this instruction
manual before operating or cleaning this appliance.
2. The cord to this appliance should be plugged into a 120V AC electrical
outlet only.
3. If this appliance begins to malfunction during use, pull the frying
basket drawer out of the body. Then remove plug from wall outlet. Do
not use or attempt to repair the malfunctioning appliance.
4. Do not leave this appliance unattended during use.
5. Do not immerse power cord in any liquid. If the power cord to this
appliance is damaged, it must be replaced by contacting Consumer
Service.
6. Keep the cord out of reach from children and infants to avoid the risk
of electric shock and choking.
7. Place the Air Fryer on a flat, heat-resistant work area.
8. Do not obstruct the air outlet or air inlets on the back and sides of the
Air Fryer, with any objects. Avoid escaping steam from the air outlet
during air frying.
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 490190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 4 2023-06-27 4:43 PM2023-06-27 4:43 PM
5
9. Keep appliance at least 4 inches away from walls or other objects
during operation.
10. Always use the frying basket handle to open frying basket drawer.
11. WARNING: After air frying, make sure to place the frying basket
drawer on a flat, heat-resistant surface.
WARNING: Over-filling the frying basket may damage the Air Fryer and
could result in serious personal injury.
12. Never move a hot Air Fryer or an Air Fryer containing hot food. Allow
to cool before moving.
13. Do not clean with metal scouring pads. Pieces can break off the pad
and touch electrical parts, creating a risk of electric shock.
NOTES ON THE PLUG
This appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug will fit in a polarized outlet
only one way. If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician. Do not modify
the plug in any way.
NOTES ON THE CORD
A. A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce the risk resulting from becoming entangled in or
tripping over a longer cord.
B. Longer detachable power-supply cords or extension cords are
available and may be used if care is exercised in their use.
C. If a long detachable power-supply cord or extension cord is used :
1. The marked electrical rating of the cord or extension cord should
be at least as great as the electrical rating of the appliance;
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 590190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 5 2023-06-27 4:43 PM2023-06-27 4:43 PM
6
2. If the appliance is of the grounded type, the extension cord should
be a grounding-type3-wire cord.
3. The longer cord should be arranged so that it does not drape over
the countertop or table top where it can be pulled on by children or
tripped over unintentionally.
PLASTICIZER WARNING
CAUTION: To prevent Plasticizers from migrating to the finish of the
counter top or table top or other furniture, place NON-PLASTIC coasters
or place mats between the appliance and the finish of the counter top
or table top. Failure to do so may cause the finish to darken; permanent
blemishes may occur or stains can appear.
ELECTRIC POWER
If the electrical circuit is overloaded with other appliances, your appliance
may not operate properly. It should be operated on a separate electrical
circuit from other appliances.
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 690190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 6 2023-06-27 4:43 PM2023-06-27 4:43 PM
7
GETTING TO KNOW YOUR 4 QT DIGITAL AIR FRYER
Product may vary slightly from illustration
1) Touchscreen Control
2) Frying Basket with Cool Touch Handle
3) Power Cord with Polarized Plug (not shown)
4) Non-skid Feet (not shown)
5) Nonstick Coated Crisping Tray
4
2
1
3
5
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 790190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 7 2023-06-27 4:43 PM2023-06-27 4:43 PM
8
TOUCHSCREEN CONTROL
1. There are 5 menu options, each with a preset time and temperature.
2. Press on the desired function and the preset temp/time will be displayed.
Menu Default Time Time Range Default Temp Temp Range
Air Fry 18:00 01:00-60:00 400 ˚ F 170 ˚F -400 ˚F
Bake 25:00 01:00-60:00 350 ˚F 170 ˚F - 400 ˚F
Roast 35:00 01:00-60:00 400 ˚F 350 ˚F -400 ˚F
Broil 10:00 01:00-30:00 400 ˚F -
Reheat 06:00 01:00-60:00 250 ˚F 170 ˚F -400 ˚F
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 890190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 8 2023-06-27 4:43 PM2023-06-27 4:43 PM
9
BEFORE USING FOR THE FIRST TIME
1. Remove all packing material and labels from the inside and outside of the air fryer. Check that
there is no packaging underneath and around the frying basket.
2. Your air fryer is shipped with the frying basket locked inside the air fryer body. Firmly grasp
the frying basket handle to open frying basket and place on a flat, clean work area.
3. Wash frying basket and crisping tray in hot, soapy water.
4. DO NOT IMMERSE THE AIR FRYER BODY IN WATER. Wipe the air fryer body with a damp
cloth. Dry all parts thoroughly.
5.
To ensure the crisping tray fits snugly into the frying basket drawer, there are 4 rubber tips
attached to the sides of the tray. Before using, check to make sure all 4 rubber tips are in place.
If they become separated from the tray, simply slide onto the tabs as shown. (See fig 2.)
OPERATING INSTRUCTIONS
WARNING! This air fryer should not be used to boil water.
NOTE: During first use, the air fryer may emit a slight odor. This is normal.
1. Place the Air Fryer on a flat, heat-resistant work area, close to an electrical outlet.
2. Firmly grasp the frying basket handle to open frying basket; then remove from the machine
and place on a flat, clean surface.
3. Place the crisping tray into the base of the frying basket.
4. Arrange food on top of the crisping tray. Do not overfill frying basket with food. To ensure
proper cooking and air circulation, NEVER fill any frying basket more than 2/3 full. When air
frying fresh vegetables, we do not recommend adding more than 1-1/2 cups of food to the
frying basket.
Figure 2
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 990190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 9 2023-06-27 4:43 PM2023-06-27 4:43 PM
10
5. Fully insert the frying basket into the front of the Air Fryer.
6. Plug cord in the wall outlet. A lone POWER button
will appear on a black background.
7. To begin, press the
button
8. The 5 functions will appear on the display
MANUAL OPERATION
9. Press on the desired function. The function selected will blink and the button will
illuminate.
10. The default Temperature and Time for the selected preset will alternate on the screen every 5
seconds.
11. To adjust the air frying TEMPERATURE, press the
button until you see the temperature
displayed then press
to reduce the temperature and to increase the temperature in
5 degree increments.
12. To adjust the air frying TIME, press the
button until you see the time displayed then
press
to decrease the time and to increase the time in 1 minute increments.
13. When the desired TIME and TEMPERATURE appear on the display, press the
button to
turn the air fryer on to its working mode. The preset temperature and time will alternate on
the display until the time has expired.
IMPORTANT: The air fryer will not heat until the
button is pressed. If no buttons are
pressed, the air fryer will automatically turn OFF within 3minute.
NOTE: If the air fryer basket is removed while the air fryer is in working mode the unit will pause
and the remaining TIME will flash. Once the basket is put back in place the working mode will
resume. If the basket is not put back in place after 10 minutes, the unit will automatically shut off.
14. Once the timer reaches 00:00 a tone will sound and END will be displayed.
AIR FRYING TECHNIQUE
1. Please consult the Air Frying Chart and/or follow package instructions for suggested TIME and
TEMPERATURE.
2. To assure even cooking/browning, ALWAYS open the frying basket halfway through
the cooking time and check, turn or shake foods in the frying basket. Adjust TIME or
TEMPERATURE if needed.
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 1090190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 10 2023-06-27 4:43 PM2023-06-27 4:43 PM
11
WARNING: Extreme caution must be used when handling the hot frying basket
and crisping tray. Avoid escaping steam from the frying basket and the food.
CAUTION: Always use oven mitts when handling the hot air fryer basket.
CAUTION:
Hot oil can collect at the base of the drawer. To avoid risk of burns or personal injury,
or to avoid oil from contaminating air fried foods, always unlock and remove the frying basket
from the drawer before emptying. NEVER turn the drawer upside down with the frying
basket attached.
3. If additional air frying is needed, adjust TEMPERATURE if desired, and set TIME for 2 to 5
minute intervals until fully cooked.
4. Once the timer reaches 00:00 a tone will sound and END will be displayed.
5. To turn the air fryer OFF at any time, simply press the
button.
WARNING! ALWAYS USE A MEAT THERMOMETER TO ENSURE THAT MEAT, POULTRY AND
FISH ARE COOKED THOROUGHLY BEFORE EATING.
6. If recipe instructions instruct, allow cooked foods to rest for 5 to 10 minutes. Remove the
frying basket from the machine and place on a flat, heat resistant surface.
7. Use tongs or a long fork to remove air fried foods onto a serving plate. Promptly replace the
frying basket into the front of the air Fryer. Continue with subsequent batches, if any.
8. Unplug the Air fryer when not in use.
A NOTE ON AIR FRYING PRE-PACKAGED FROZEN FOODS
1. The air fryer is powered with 1300W high performance technology that circulates heat for fast
air fry and recovery.
2. As a general rule, reduce the package cooking time by 30% to 50% depending on the food
and amount to be cooked.
3. Always check food halfway though cooking time to determine final cook time and
temperature.
4. Always check cooking progress after TIME has expired. If more time is needed, cook at short
time intervals until food tests done.
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 1190190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 11 2023-06-27 4:43 PM2023-06-27 4:43 PM
12
FOR BEST RESULTS
1. Use your air fryer to cook pre-packaged foods with a fraction of the oil, in a fraction of
the time!
2. Always check food halfway though cooking time to determine final cook time and
temperature.
3. Always pat food dry before cooking to encourage browning and avoid excess smoke.
4. To avoid excess smoke, when cooking naturally high fat foods, such as chicken wings or
sausages, it may be necessary to empty fat from the frying basket drawer between batches.
5. For crispier results, air fry small batches of freshly breaded foods. Create more surface area
by cutting food into smaller pieces. Press breading onto food to help it adhere. Refrigerate
breaded foods for at least 30 minutes before frying.
6. Arrange breaded food in frying basket so that food is not touching to allow air flow on
all surfaces.
7. Spray olive oil or vegetable oil work best as oil is distributed evenly and less oil is needed.
8. Do not overfill frying basket with food. NEVER fill any frying basket more than 2/3 full. When
air frying fresh vegetables, we do not recommend adding more than 3 cups of food to the
frying basket.
9. Some foods need to be shaken vigorously or turned over during the air fry time. Consult the
Air Frying Chart for a general guide.
PLEASE NOTE: The USDA recommends that meats such as beef and lamb, etc. should be cooked
to an internal temperature of 145°F/63°C. Pork should be cooked to an internal temperature of
160 °F/71 °C and poultry products should be cooked to an internal temperature of 170 °F/77 °C -
180 °F/82 °C to be sure any harmful bacteria has been killed. When reheating meat/poultry
products, they should also be cooked to an internal temperature of 165°F/74°C.
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 1290190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 12 2023-06-27 4:43 PM2023-06-27 4:43 PM
13
USER MAINTENANCE INSTRUCTIONS
This appliance requires little maintenance. It contains no user-serviceable parts. Any servicing
requiring disassembly other than cleaning must be performed by a qualified appliance repair
technician.
CARE & CLEANING INSTRUCTIONS
WARNING! Allow the Air fryer to cool fully before cleaning.
1. Unplug the Air Fryer. Remove frying basket. Make sure the frying basket and crisping tray
have cooled completely before cleaning. Use the center hole of the crisping tray to lift
crisping tray up and out of the frying basket.
2. Wash the frying basket and crisping tray in hot soapy water. Do not use metal kitchen utensils
or abrasive cleansers or cleaning products as this may damage the nonstick coating.
3. The frying basket and crisping tray are dishwasher-safe. For best results, place in the top rack
of your dishwasher to clean.
4. Wipe the air fryer body with a soft, non-abrasive damp cloth to clean.
STORING INSTRUCTIONS
1. Make sure the air fryer is unplugged and all parts are clean and dry before storing.
2. Never store the air fryer while it is hot or wet.
3. Store the air fryer in its box or in a clean, dry place.
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 1390190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 13 2023-06-27 4:43 PM2023-06-27 4:43 PM
Limited Two-Year Warranty
SENSIO Inc. hereby warrants that for
a period of TWO YEARS from the date
of purchase, this product will be free
from mechanical defects in material
and workmanship, and for 90 days in
respect to non-mechanical parts. At its
sole discretion, SENSIO Inc. will either
repair or replace the product found to
be defective, or issue a refund on the
product during the warranty period.
The warranty is only valid for the
original retail purchaser from the date
of initial retail purchase and is not
transferable. Keep the original sales
receipt, as proof of purchase isrequired
to obtain warranty validation. Retail
stores selling this product do not have
the right to alter, modify, or in any way
revise the terms and conditions of the
warranty.
Exclusions:
The warranty does not cover normal
wear of parts or damage resulting
from any of thefollowing: negligent
use of the product, use of improper
voltage or current, improper routine
maintenance, use contrary to the
operating instructions, disassembly,
repair, or alteration by anyone other than
qualified SENSIO Inc. personnel. Also,
the warranty does not cover
Acts of God such as fire, floods,
hurricanes, or tornadoes.
SENSIO Inc. shall not be liable for any
incidental or consequential damages
caused by the breach of any express
or implied warranty. Apart from the
extent prohibited by applicable law, any
implied warranty of merchantability or
fitness for a particular purpose is limited
in time to the duration of the warranty.
Some states, provinces or jurisdictions
do not allow the exclusion or limitation
of incidental or consequential damages,
or limitations on how long an implied
warranty lasts, and therefore, the above
exclusions or limitations may not apply
to you. The warranty covers specific
legal rights which may vary by state,
province and/or jurisdiction.
14
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 1490190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 14 2023-06-27 4:43 PM2023-06-27 4:43 PM
15
How To Obtain Warranty Service:
You must contact Customer Service at
our toll-free number: 1-866-832-4843.
A Customer Service Representative
will attempt to resolve warranty issues
over thephone. If the Customer Service
Representative is unable to resolve the
problem, you will be provided with a
case number and asked to return the
product to SENSIOInc. Attach a tag to
the product that includes: your name,
address, daytime contact telephone
number, case number, and description of
the problem.
Also, include a copy of the original sales
receipt. Carefully package the tagged
product with the sales receipt, and send
it (with shipping and insurance prepaid)
to SENSIO Inc.’s address. SENSIO Inc.
shall bear no responsibility or liability
for the returned product while in transit
to SENSIO Inc.’s Customer Service
Center.
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 1590190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 15 2023-06-27 4:43 PM2023-06-27 4:43 PM
For customer service questions or comments
1-866-832-4843
bellahousewares.com
90190 Rev. 0
Sensio Inc.
New York, NY 10016/USA
90190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 1890190 BELLA PRO 4QT Digital Air Fryer IM R0.indd 18 2023-06-27 4:43 PM2023-06-27 4:43 PM
