Built for Reliable Performance
Engineered and built like no other, the Speed Queen
®
front load washer
is designed to be everything people thought a washer couldn’t be,
beginning with its revolutionary suspension and sensing technology.
This groundbreaking innovation manages and redistributes out-
of-balance loads to deliver uninterrupted cycles, virtually eliminate
vibration and operate so quietly neighboring residents won’t even know
it’s running. It also touts an incredible 440 G-Force extraction speed
to maximize moisture removal, reduce dry times and minimize utility
costs. And as if that’s not game-changing enough, this smooth-running,
laundry-optimizing machine delivers increased water efficiency. It’s
everything you never knew it could be. Front controlled products have
met every design standard to be 100% ADA compliant.
Quantum
®
Gold Pro
Prep for Card | Coin Drop Installed
• • Revolutionary balancing technology
• • Industry leading 1200 RPM spin speed exerts
440 G-force extraction
• • Integrated meter case
• • Extra-wide 15.5˝ door opening and 180º door swing
• • Rugged suspension system
• • Easy-to-read digital display
• • Large capacity meter case standard
• • Multi-level vend pricing
• • Individual cycle modier keys
• • Durable stainless steel tub standard
• • Four-compartment soap dispenser
• • Wash Alert™ capability
Quantum
®
Gold Pro Control
The Quantum
®
Gold Pro control delivers a truly premium
experience to residents. From intuitive soft touch buttons
that walk them through cycle options to multiple actuations
(coin, card, mobile) for payment exibility, this control gives
residents the wash and dry options they want, and the
revenue potential managers desire.
SPEED QUEEN
®
MULTI-HOUSING LAUNDRY SOLUTIONS
Front Control Front Load Washer
ENERGY STAR
®
Certied Washer
Front Control Front Load Washer
Quantum
®
Gold Pro
AM21-0042
speedqueencommercial.com
Speed Queen by Alliance Laundry Systems
©2021 Alliance Laundry Systems LLC
Supply inject kits available.
** Average usage based on multiple load sizes and current DOE test protocol. Real usage will vary depending on load size, composition and cycle selectivity.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements, design and specifications
subject to change without notice. The quality management systems at Alliance Laundry Systems are registered to ISO 9001.
A
B
C
D
E
A. Overall Width - in (mm)
26.875 (683)
B. Overall Depth - in (mm)
27.73 (704)
C. Overall Height - in (mm)
44.34 (1126)
D. Floor To Door Opening -in (mm)
14.6 (371)*
E. Door Swing - in (mm)
24 (610)
* For ADA compliance turn legs out from base 0.5 inches
Specifications
Control Option
Quantum Gold Pro
Color
White
Capacity - lb (kg)
21.5 (9.5)
Overall Width - in (mm)
26.875 (683)
Overall Depth - in (mm)
27.73 (704)
Overall Height - in (mm)
44.34 (1126)
Cylinder Volume - cu. ft. (liters)
3.42 (96.8)
Spin Speed G-Force (RPM)
440 (1200)
Motor Size - HP (kw)
0.9 (0.67)
Water Consumption Per Cycle
- g (liter)**
13.68 (51.8)
IWF (Water Factor)
- gal/ft³ (liters/liter/cycle)**
4.0 (0.53)
MEF
J2
(Modied Energy Factor)
ft³/kWh/cycle (Liters/kWh/cycle)**
2.20 (62.3)
Available Water Temperatures
Cold, Warm, Hot
Available Cycles
Normal, Synthetic,
Delicate
Electrical Requirements (v/Hz/Ph-Amp)
120/60/1 - 15 Amp
Water Pressure - p.s.i. (bar)
20-120 (1.4/8.3)
Cylinder Finish
Stainless Steel
Net Weight - lb (kg)
260 (118)
Shipping Weight - lb
(kg)
270 (122.5)
Shipping Dimensions
Approx. - in (mm)
Width
34 (864)
Depth
30 (762)
Height
44.5 (1130)
Agency Approvals
cULus
Models Drain Actuation
SFNNCASP116TW01 Pump
Coin
Drop
Installed
SFNNC A SG116T W01 Gravity
SFNNYASP116TW01 Pump
Prep for
Card
SFNNYASG116T W01 Gravity
