VOLTAGE CONVERTER
UNIVERSAL INSTRUCTION MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL:SV-500VA/SV-1000VA/SV-2000VA/SV-3000VA/SV-5000VA
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
VOLTAGE CONVERTER
- 2 -
ATTENTION
The voltage input range of this product can be selected by toggle switch,
please check that the voltage of the mains and the switching voltage of the
product should be consistent before powering on.
[I] PRODUCT PARAMETERS
[II] Instructions for use of the product
Set the input toggle switch of the product to a position consistent with the
mains voltage.(As shown in the figure below).
1.Set the input toggle switch of the product to a position consistent with the
mains voltage.(As shown in the figure below).
The input voltage is 220V-240V rule Switch to position 220
Model
SV-500VA
SV-1000VA
SV-2000VA
SV-3000VA
SV-5000VA
Input
voltage
AC110V
±
15% or AC 230V
±
15%
Output
voltage
AC110V±15% and AC 230V±15%
Output
power
500VA
1000VA
2000VA
3000VA
5000VA
Overload
protector
5A
10A
18A
28A
45A
Operating
temperature
-30℃~55℃
relative
humidity
5%~95%
- 3 -
The input voltage is 100V-120V rule Switch to position 110
2.Insert the input power cord into the end of the product, and then insert
the plug of the power cord into the mains outlet.
✮Note:Before plugging in the mains, please check whether the position
of the input voltage transfer switch is consistent with the mains voltage.
3.Please use the load according to the voltage of the panel output socket,
the load power must be less than the nominal power of the device, and the
recommended load power is 80% of the rated power.
✮Because the equipment itself has a certain loss, the load use power
must be less than the nominal power of the equipment, otherwise there
is a risk of damage to the equipment.
4.The panel USB output port outputs 5V/1.5A DC as an emergency to
charge other smart devices.
Notes:
1.This equipment is equipped with an overcurrent fuse (SV-500VA or
SV2000VA), which will blow when the load exceeds the load of the
equipment. When you find that there is no output, check the replacement
fuse.
2.This equipment has an overload protection switch, when the load
exceeds the load of the equipment, the overload protection switch will
automatically spring up and disconnect the output; When the load overload
is solved, you can press the overload protection by hand to open it and
resume work.
3.This equipment is equipped with an air switch, when the load is
overloaded for a long time, or the load is short-circuited, the air switch will
immediately turn off the output, thereby protecting the equipment from
damage. When the load fault is lifted, close the air again and open it, and it
can work normally.
- 4 -
Device panel：
Power switch（Air switch）
Input transfer switch
Overload protection
switch
Warning:
This equipment is a high voltage device, please do not attempt to
disassemble this equipment at any time to avoid danger. After a device
failure, if the external switch fails to restart the device, please contact your
reseller for handling.
Made In China
Glass fuse(Only:500VA-2000VA
