17
13
16
FRONT VIEW
RIGHT SIDE VIEW
TOP VIEW
21
15
16
SPEC SHEET OUTLINE
ITEM # 89975
DESCRIPTION -
VERTICAL SINGLE DOOR
RIGHT HINGE
WWW.BULLBBQ.COM
NOTES:
1)
ALL DIMENSIONS ARE IN INCH UNITS
2)
REFER TO PERSPECTIVE VIEW FOR INSTALLATION CUTOUT DIMENSIONS.
3)
REFER TO TOP OF PAGE FOR PART INFORMATION
4)
PAGES 2 - 4 FOR WARRANTY POLICY
PERSPECTIVE VIEW
WITH INSTALLATION
CUT OUT DIMENSIONS
19
1
8
19
1
4
AT
RIVITS
15
3
8
OUTSIDE
EDGE
v.2022.05.12
1
15
16
OD
1
1
4
INSIDE OF FLANGE
TO CENTER LINE TO SLOTS
(Typ.)
1
7
8
ID
15
7
8
"
19
5
8
"
REPLACEMENT PARTS LIST
DWG ITEM # PART # DESCRIPTION
QTY
1
16572
SS DOOR HANDLE
1
2
16515
HANDLE SET SCREW
1 SET
3 16548
DOOR MAGNET
2
