Russell Hobbs RHAF18 Satisfry Air Small 1.8L Air Fryer User Manual

SATISFRY AIR

SMALL 1.8L

RHAF18_IB&RB_FA_160622 Part no. T22-9002772

2 YEAR WARRANTY

RHAF18

INSTRUCTIONS & WARRANTY

IMPORTANT SAFEGUARDS

When using this appliance, basic safety precautions should always be followed, including the

following:

Read all instructions before, and follow whilst using this appliance.

1. To protect against electrical hazards, do not immerse the air fryer body in water or any

liquid.

2. Do not use it in a bathroom or near any source of water.

3. Do not use outdoors.

4. This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety.

5. This appliance is NOT a toy. Children should be supervised to ensure they do NOT play

with this appliance.

6. Always follow the instructions when using this appliance.

7. The temperature of accessible surfaces/parts may become very hot when the appliance

is operating and may remain hot for some time after the appliance has been switched

off.

8. To avoid the possibility of scalding, keep clear of steam escaping around the door area.

9. CAUTION: Do not touch any internal surfaces until the air fryer has fully cooled.

10. CAUTION: Do not operate on an inclined plane. Place the air fryer on a stable, level,

heat-resistant surface and out of reach of children.

11. Route the power cord so it does not overhang, and cannot be caught accidentally.

12. Unplug the air fryer when not in use, before moving and before cleaning. Let it cool down

fully before cleaning and storing away.

13. There are no user serviceable parts. If the power cord is damaged, it must be replaced

by the manufacturer or similarly qualied person in order to avoid hazard.

14. Do not operate this appliance with a damaged cord/plug or after the appliance has

malfunctioned, or been dropped or damaged in any manner. Contact Customer Service

for examination, adjustment, repair or replacement.

15. To shut down, press and hold

for 3 seconds, turn off the wall power outlet then grasp

the plug and remove from wall power socket. Never pull by the cord.

16. Leave a clear space of at least 50mm around the air fryer when in use.

17. Do not cover the air fryer or put anything on top of it while in use.

18. Do not use the air fryer near or below curtains, overhead cupboards or or other

combustible materials.

19. Keep the power cord and the air fryer away from hotplates, cook-tops and burners.

20. Cook meat, poultry, and derivatives (mince, burgers, etc.) till the juices run clear. Cook

sh till the esh is opaque throughout.

21. Do not pour oil or any other liquid into the basket.

22. Do not use accessories or attachments other than those supplied as specically for use

with the air fryer.

23. Do not use the air fryer for any purpose other than that described in these instructions.

24. Do not connect this air fryer to an external timer or remote control system.

25. For added safety, electrical appliances should be connected to a power outlet that is

protected by a residual current device (RCD), also often referred to as a ‘Safety Switch’.

Your switchboard may already incorporate an RCD. If unsure, call an electrician for

verication and tting if necessary.

This appliance is intended for use in households and similar applications such as:

- staff kitchen areas in shops, ofces and other working environments

- farm houses

- by clients in hotels, motels and other residential type environments

- bed and breakfast type environments

SAVE THESE INSTRUCTIONS

Legislation in some localities mandates that e-waste (anything with a plug, battery or cord)

is disposed of through controlled recycling facilities and must not be disposed of in general

household waste. For more information about recycling of electrical and battery operated

appliances, please contact your local council or your local household waste disposal service.

PARTS

Congratulations on the purchase of your new Russell Hobbs Satisfry Air Small 1.8L Air Fryer.

Each unit is manufactured to ensure safety and reliability. Before using the air fryer for the

rst time, please read this instruction booklet carefully and keep it for future reference. Pass it

on if you pass on the air fryer.

When using this appliance, basic safety precautions should always be followed.

1. Touch controls and display

2. Body

3. Crisping plate

4. Basket

5. Handle

Caution, hot surface(s)

H i

BEFORE FIRST USE

• Remove all packing materials.

• Hand wash the removable parts.

• When using the fryer for the rst time, you may notice smoke or a slight odour for the rst

few minutes of cooking. This is normal. Ensure the room is well ventilated.

• Slide the basket into the machine until it clicks into place. The appliance will not work

unless the basket is properly inserted.

HOW IT WORKS

• The air fryer uses hot air and radiant heat for cooking.

• Little to no oil is required. If needed, add oil to the food as a coating, don’t pour oil into the

basket.

PREPARATION, BASKET & CRISPING PLATE

• Sit the appliance on a stable, level, heat-resistant surface.

• Leave a space of at least 50mm all-round the appliance.

• Have oven gloves (or a tea towel) on hand, use heat resistant plastic tongs and a

heat-resistant mat or dinner plate to rest the basket on.

Note: Do not use metal tongs as it may scratch the coating. We recommend using only

heat resistant plastic or silicon coated tongs.

• To remove the basket from the body:

1. Hold the top of the body.

2. Grip the basket handle with the other hand.

3. Slide the basket out of the body (Fig. A)

4. Rest the basket on a heat-resistant mat.

• To remove the crisping plate:

1. Remove food from the basket using heat-resistant plastic tongs.

2. Let the basket and crisping plate cool down.

3. Using oven gloves, grip the crisping plate in the centre and pull it out of the basket

(Fig B).

H i

DIGITAL TOUCHSCREEN & SETTINGS

ON/OFF

Setup mode, start and shut off the appliance

COOKING MENU SELECTION

Select auto-cooking or manual mode by navigating through the different

8 setting options (7 auto-cooking + manual)

7 AUTO-COOKING SETTINGS

(1 displayed at a time)

Fries, Chops, Prawns, Bake, Chicken, Steak, Fish

COOKING TEMPERATURE

Press button and adjust Cooking Temperature Control

using the + or – buttons.

COOKING TIME

Press button and adjust Cooking Time Control using the + or – buttons.

+ / -

Increase/decrease cooking time and/or temperature.

DISPLAY SCREEN

Time/Temperature Display

DEFAULT COOKING TIMES AND TEMPERATURE:

The Air Fryer has 7 auto cooking functions with default cooking time/temperature, and

manual mode with adjustable cooking temperature/time settings.

Note: It is possible to adjust the cooking time and/or temperature on auto-cooking, if needed.

COOKING MODE DEFAULT COOKING TIME DEFAULT COOKING TEMP

Fries 15 minutes 200°C

Chops 15 minutes 200°C

Prawns 12 minutes 160°C

Bake 20 minutes 160°C

Chicken 20 minutes 180°C

Steak 10 minutes 180°C

Fish 15 minutes 160°C

Manual mode

15 minutes 180°C

To remove the basket from the body

1. Hold the top of the body.

2. Grip the basket handle with the other hand.

3. Slide the basket out of the body (Fig. A).

4. Rest the basket on a heat-resistant mat.

To remove the crisping plate:

1. Remove food from the basket using heat-resistant plastic tongs.

2. Let the basket and crisping plate cool down.

3. Using oven gloves, grip the crisping plate in the centre and pull it out of the basket (Fig B).

DIGITAL TOUCHSCREEN

ICON DESCRIPTION

On/Oﬀ

Steps through the auto-cooking menu

D I J A B K C

Auto-cook functions: Fries, Pork, Prawns, Bake, Chicken, Steak, Fish

Used to adjust the cooking temperature in conjunction with the + or

– buttons.

Used to adjust the cooking time in conjunction with the + or –

buttons.

Increase/decrease

88:88

Time/Temperature Display

AUTO COOK FUNCTIONS

Your air fryer has 7 auto cooking functions and a manual cooking mode. You can adjust the default cooking

times and temperatures as desired.

Function Default Cooking Time (mins) Default Temperature (ºC)

Fries

15 200

Pork

15 200

Prawns

12 160

Bake

20 160

Chicken

20 180

Steak

10 180

Fish

15 160

Manual - 15 200

To remove the basket from the body

1. Hold the top of the body.

2. Grip the basket handle with the other hand.

3. Slide the basket out of the body (Fig. A).

4. Rest the basket on a heat-resistant mat.

To remove the crisping plate:

1. Remove food from the basket using heat-resistant plastic tongs.

2. Let the basket and crisping plate cool down.

3. Using oven gloves, grip the crisping plate in the centre and pull it out of the basket (Fig B).

DIGITAL TOUCHSCREEN

ICON DESCRIPTION

On/Oﬀ

Steps through the auto-cooking menu

D I J A B K C

Auto-cook functions: Fries, Pork, Prawns, Bake, Chicken, Steak, Fish

Used to adjust the cooking temperature in conjunction with the + or

– buttons.

Used to adjust the cooking time in conjunction with the + or –

buttons.

Increase/decrease

88:88

Time/Temperature Display

AUTO COOK FUNCTIONS

Your air fryer has 7 auto cooking functions and a manual cooking mode. You can adjust the default cooking

times and temperatures as desired.

Function Default Cooking Time (mins) Default Temperature (ºC)

Fries

15 200

Pork

15 200

Prawns

12 160

Bake

20 160

Chicken

20 180

Steak

10 180

Fish

15 160

Manual - 15 200

MAKING ADJUSTMENTS

1. When rst connecting the appliance to a wall power outlet, the digital touchscreen icons

will all illuminate for several seconds. Following this, only the ON/OFF

touch button

will be illuminated.

2. Press the

to turn on the air fryer. The display screen will show the default cooking

temperature/time settings on Manual mode: 180°C and 15 minutes.

3. You can now select an auto cooking function or use the manual cooking mode.

To select Manual Cooking Mode

1. Tap the menu

icon until none of the auto cooking icons are illuminated.

To select an auto-cooking function

1. Press the

button repeatedly to navigate through the 7 different functions until the

desired icon illuminates.

2. Each tap of the menu icon will advance the cooking mode and the icon applicable to that

mode will be illuminated.

Adjusting cooking time and temperature

1. Once you have selected the desired cooking mode, tap the

icon and then tap the

icons to increase or decrease the cooking temperature as desired.

2. To adjust the cooking time, tap the

icon and then tap the

icons to increase or

decrease the cooking time as desired.

USING

• Your air fryer uses hot air and radiant heat for cooking.

• Little to no oil is required. If needed, add oil to the food as a coating, don’t pour oil into

the basket.

PREHEAT

1. We recommend preheating your air fryer for 5 minutes when using the manual mode, or

whenever preheating is necessary.

2. Select manual cooking mode if it is not already selected.

3. Adjust the cooking time to 5 minutes.

4. Press

to start preheating the air fryer.

5. The cooking time and temperature will be displayed alternatively (respectively 3 and 7

seconds) during preheating/cooking cycle.

6. When the timer returns to zero, the air fryer beep 5 times and will switch off.

COOKING

1. Place the crisping plate inside the basket.

2. Place desired food into the cooking basket. Do not overfill the basket, to leave space for

the hot air to circulate between pieces of food.

3. Slide the basket back into the air fryer body, ensuring it clicks into place and sits flush

with the shape of the air fryer body. Your air fryer will not work unless the basket is

properly inserted.

4. Select cooking settings - via either auto-cooking mode or manual mode:

- Select one of the 7 auto cooking functions or;

- Manually adjust both cooking time and temperature by pressing the

refer to the

recipes & cook times in this booklet to determine the correct settings depending on the

food to be cooked.

5. Press

to begin cooking

- To stop the cooking cycle or reset the settings, press again.

6. Half way through cooking, remove the basket, shake it, and/or turn the food over, then

place the basket back into the body to resume the cooking cycle. This ensures the food

is evenly cooked and crispy all over.

7. Once the cooking time has elapsed, the timer will beep 5 times and the unit will switch

off.

8. Slide the basket out of the body and check that the food is cooked.

9. Place the basket on an insulated mat.

10. To remove food from the basket, we recommend using tongs. We do not recommend

tipping the basket upside down as oil residue will drip out.

11. Unplug the appliance, once all cooking is complete.

CAUTION: Hot oil from the ingredients may gather at the bottom of the basket. Be

careful when removing the crisping plate from the basket. To remove food from the

basket, we recommend using tongs. We do not recommend tipping the basket upside

down as oil residue will drip out.

NOTES:

• The air fryer will switch off when you remove the basket.

• The air fryer will switch back on when you replace the basket in to the body and will

automatically resume the cooking cycle from where it stopped.

• During the last minute of the cooking cycle, ‘00’ will be ﬂashing on the display

screen, indicating that there is less than 1 minute of cooking remaining.

NOTE: High fat foods (e.g. pork) may create smoke. This is normal as oil residue is

cooked at a high temperature.

Reducing temperature may decrease the effect of smoke.

CARE AND MAINTENANCE

This product contains no user serviceable parts. Refer service to qualied service personnel.

• IMPORTANT: Before cleaning any part, be sure the air fryer is off, unplugged, and cool. It

is important that you clean the entire appliance after each use to prevent accumulation of

grease and to avoid unpleasant odours.

• If the appliance isn’t cleaned thoroughly, it may produce smoke from the oil residue.

IMPORTANT: Do not immerse the appliance, power cord or plug in any liquid.

Basket & Crisping Plate

1. Once the air-fryer has cooled, grasp the basket handle and remove the basket from the

air-fryer body for cleaning.

2. Roughly wipe the interior of the body to remove any crumb or residue, but NOT the

heating elements at the top.

3. Remove the crisping plate from the basket.

4. Dispose of food residue and oils, and wipe both the crisping plate and basket with a damp

cloth before hand washing them in warm to hot soapy water. Dry thoroughly before placing

back in the air fryer body.

• The basket and crisping tray can also be washed in a dishwasher.

Exterior Surfaces

Clean the exterior with a damp cloth or sponge. Dry thoroughly.

NOTE: Do not use any abrasive material or sharp utensils to clean the air fryer or any of

its parts.

NOTE: Allow all parts and surfaces to dry thoroughly before using the appliance again.

COOKING TIMES & FOOD SAFETY

NOTE: These cooking times are intended as a guide only

• Cook meat, poultry, and derivatives (mince, burgers, etc.) until the juices run clear. Cook

sh till the esh is opaque throughout.

• When cooking pre-packed foods, refer to packaging instructions.

Food Temperature ºC Time (min) Remarks

Chips 200 15-20

Rinse, dry, toss in salt, pepper,

and oil

Potato wedges 200 15-20

Rinse, dry, toss in salt, pepper,

and oil

Sweet potato

wedges

200 15-20

Rinse, dry, toss in salt, pepper,

and oil

Jacket potato 180 30-40 For a crispy jacket, brush with oil

Roast potatoes 180 25-35

Rinse, dry, toss in salt, pepper,

crushed rosemary (optional) and

oil

Mixed Mediterranean

vegetables

180 6-10

All cut to similar sizes, approx.

1-2cm pieces, toss in oil and

season

Chicken Breast 180 15-20

Chicken Thighs 180 25-30

Cooking time depends on size.

Brush with oil, season

Chicken wings 180 23-28

Cooking time depends on size.

brush with oil, season

Burgers 180 8-12

Cooking time depends on size.

brush with oil, season

Sausages 180 8-12

Pork chop 200 10-15 Brush with oil, season

Salmon llet 180 8-12 Brush with oil, season

White sh llet 180 8-12 Brush with oil, season

Sausage Roll 200 13-15 Brush with oil, season

Spring Roll 200 8-10

Mufns 180 15-18

Chips 200 15-20

Potato wedges 200 15-20

French fries 200 12-20

Chicken Nuggets 200 6-10

Fish llets 200 10-12

Fish Fingers 180 6-10

Onion Rings 180 10-15

Scampi 180 10-15

Spectrum Brands Australia Pty Ltd

Locked Bag 3004 Braeside

Victoria 3195 Australia

Customer Service in Australia

TollFree: 1800 623 118

Email: [email protected]

Website: www.spectrumbrands.com.au

Spectrum Brands New Zealand Ltd

PO Box 9817 Newmarket

Auckland 1149 New Zealand

Customer Service in New Zealand

TollFree: 0800 736 776

Email: [email protected]

Website: www.spectrumbrands.co.nz

Spectrum Brands Australia Pty Ltd and Spectrum Brands New Zealand Ltd

Warranty Against Defects

In this warranty:

Australian Consumer Law means the Australian consumer law set out in Schedule 2 to the

Competition and Consumer Act 2010;

CGA means the New Zealand Consumer Guarantees Act 1993;

Goods means the product or equipment which was accompanied by this warranty and

purchased in Australia or New Zealand, as the case may be;

Manufacturer, We or us means:

1. for Goods purchased in Australia, Spectrum Brands Australia Pty Ltd ABN, 78 007 070 573;

2. for Goods purchased in New Zealand, Spectrum Brands New Zealand Ltd, as the case

may be, contact details as set out at the end of this warranty;

Supplier means the authorised distributor or retailer of the Goods that sold you the Goods in

Australia or in New Zealand; and

You means you, the original end-user purchaser of the Goods.

1. Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law, or the CGA. You are entitled to a replacement or refund for a major failure and

compensation for any other reasonably foreseeable loss or damage. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure.

2. The benefits provided by this Warranty are in addition to all other rights and remedies in

respect of the Goods which the consumer has under either the Australian Consumer Law

or the CGA. The original purchaser of the Goods is provided with the following Warranty

subject to the Warranty Conditions:

3. We warrant the Goods for all parts defective in workmanship or materials for

a (Warranty Period) period of 2 years from the date of purchase.

If the Goods prove defective within the Warranty Period by reason of improper workmanship

or material, we may, at our own discretion, repair or replace the Goods without charge.

Warranty Conditions

4. The Goods must be used in accordance with the manufacturer’s instructions. This

Warranty does not apply should the defect in or failure of the Goods be attributable

to misuse, abuse, accident or non-observance of manufacturer’s instructions on the

part of the user. As far as the law permits, the manufacturer does not accept liability

for any direct or consequential loss, damage or other expense caused by or arising

out of any failure to use the Goods in accordance with the manufacturer’s instructions.

5. Exhaustible components (such as batteries, filters and brushes) of the Goods are

included under this Warranty only where there is a defect in workmanship or materials

used.

6. The warranty granted under clause 3 is limited to repair or replacement only.

7. Any parts of the Goods replaced during repairs or any product replaced remain the

property of the manufacturer. In the event of the Goods being replaced during the

Warranty Period, the warranty on the replacement Goods will expire on the same

date as for the Warranty Period on the original Goods which are replaced.

8. In order to claim under the warranty granted under clause 3 you must:

(a) Retain this warranty with your receipt/proof of purchase; and

(b) Return the Goods to us at the relevant address or to the Supplier by prepaid

freight within the Warranty Period accompanied with (i) the legible and unmodified

original proof of purchase, which clearly indicates the name and address of the

Supplier, the date and place of purchase, the product name or other product serial

number and (ii) this warranty.

9. This warranty is immediately void if:

(a) Any serial number or appliance plate is removed or defaced;

(b) The Goods have been serviced or otherwise repaired by a person not authorised

to do so by us or where non approved replaced parts are used.

10. The Goods are designed for domestic use only. The Goods must be connected to the

electrical voltage requirements as specified in the ratings label located on the Goods.

11. This warranty does not cover the cost of claiming under the warranty or transport

of the Goods to and from the Supplier or us.

12. This warranty is only valid and enforceable in Australia against Spectrum Brands

Australia Pty Ltd and in New Zealand against Spectrum Brands New Zealand Ltd.

If you live in Australia please visit: www.spectrumbrands.com.au/warranty

If you live in New Zealand Please visit: www.spectrumbrands.co.nz/warranty

Registration of your warranty is not compulsory, it gives us a record of your purchase

AND entitles you to receive these benefits: Product information; Hints and tips; Recipes

and news; Information on special price offers and promotions.

Any questions? Please contact Customer Service for advice.
