Model
Number
Diag.
Size
Aspect
Ratio
Screen Material Gain
Viewing
Width (A)
Overall
Width (A1)
Viewing
Height (B)
Overall
Height (B1)
Frame
Width (C)
Frame
Depth(D)
SB100WH2 100" 16:9 CineWhite® UHD-B Gain 1.3 87.2 92.7 49 54.5 2.8 1.6
SB110WH2 110" 16:9 CineWhite® UHD-B Gain 1.3 95.9 101.4 53.9 59.4 2.8 1.6
SB120WH2 120" 16:9 CineWhite® UHD-B Gain 1.3 104.6 110.1 58.8 64.3 2.8 1.6
SB135WH2 135" 16:9 CineWhite® UHD-B Gain 1.3 117.7 123.2 66.1 71.6 2.8 1.6
SB150WH2 150" 16:9 CineWhite® UHD-B Gain 1.3 130.7 136.2 73.6 79.1 2.8 1.6
SB100WH2 100" 16:9 CineWhite® UHD-B Gain 1.3 2215 2355 1245 1384 70 41
SB110WH2 110" 16:9 CineWhite® UHD-B Gain 1.3 2436 2576 1369 1509 70 41
SB120WH2 120" 16:9 CineWhite® UHD-B Gain 1.3 2657 2797 1494 1633 70 41
SB135WH2 135" 16:9 CineWhite® UHD-B Gain 1.3 2990 3129 1679 1819 70 41
SB150WH2 150" 16:9 CineWhite® UHD-B Gain 1.3 3320 3459 1869 2009 70 41
Note: Data Error ±1"
Unit: Inch
Unit: mm
Sable Frame B2 Series Dimensions Table
The listed measurements are for general reference only. Please contact Elite Screens to verify product design and dimensions bef
ore
attempting to integrate its products with any structural or furniture modification. Although a manufacturer may offer product
advice, it may be taken or disregarded at the integrator’s discretion. Elite Screens will not be held responsible or be otherwise liable
for faulty installations.
Rev. 031221-BR www.elitescreens.com
