COMPACT DETAIL SAW
241-0995
Owner’s Manual
PRODUCT SPECIFICATIONS
Rating:
120V, 60Hz, AC
Amperes:
0.6 A
Variable speed:
1,000–4,500 SPM (no load)
Stroke length:
15/64" (6mm)
Blade change system:
2.5mm hex key
Blade type:
2 ¼" 17 TPI Wood Detail Saw Blade
(sku: 242-0063)
Cutting depth in wood:
½"(12mm) @ 90°
Base plate bevel:
0–45°
Weight:
1lb 14oz (.84kg)
Need Assistance?
Call us on our toll free customer support line:
1-866-349-8665 (Monday through Friday 9am – 5pm
Eastern Time)
Technical questions
Replacement parts
Parts missing from package

2
Product specifications ………….…………………………………………………….
1
Table of contents ……………………………………………………………………...
2
General safety warnings ……………………………………………………………..
3–4
Eye, ear & lung protection ……………………………………………………………
3–4
Electrical safety ……………………………………………………………………….
4
Power tool safety ……………………………………………………………………...
5–6
General safety rules …………………………………………………………………..
5
Work area ………………………………………………………………….…………..
5
Electrical safety ……………………………………………………………………….
5
Personal safety ………………………………………………………………………..
5
Power tool use and care.……………………………………………………………..
6
Service …………………………………………………………………………………
6
Specific safety rules …………………………………………………………………..
7
Guidelines for extension cords ……………………………………………….……..
8
Symbols ………………………………………………………………………………..
9
Know your detail saw …………………………………………………………….......
10
Assembly and operating ……………………………………………………………..
11–14
Hex key storage ……………………………………………………………………….
11
Installing a blade ………………………………………………………………………
11
Removing a blade …………………………………………………………………….
11
Setting the bevel cutting angle ………………………………………………………
11–12
Variable speed control ………………………………………………………………..
12
ON/OFF switch ………………………………………………………………………..
13
Installing the edge guide ……………………………………………………………..
12–13
Materials you can cut …………………………………………………………………
13
General cutting ………………………………………………………………………..
13–14
Bevel cutting …………………………………………………………………………..
14
Maintenance …………………………………………………………………………..
15
Exploded view …………………………………………………………………………
16
Parts list ………………………………………………………………………………..
17
Warranty ……………………………………………………………………….………
18
TABLE OF CONTENTS

3
EYE, EAR & LUNG PROTECTION
This instruction manual includes the following:
General Safety Rules
Specific Safety Rules and Symbols
Functional Description
Assembly
Operation
Maintenance
Accessories
!
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CSA
REQUIREMENTS or ANSI SAFETY STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage. Prescription
eyeglasses ARE NOT a replacement for proper eye protection.
WARNING: Non-compliant eyewear can cause serious injury if
broken during the operation of a power tool.
SAVE THESE INSTRUCTIONS FOR REFERENCE
GENERAL SAFETY WARNINGS
WARNING: Before using this tool or any of its accessories, read this
manual and follow all Safety Rules and Operating Instructions. The important
precautions, safeguards and instructions appearing in this manual are not
meant to cover all possible situations. It must be understood that common
sense and caution are factors which cannot be built into the product.
!
WARNING: Use hearing protection, particularly during extended
periods of operation of the tool, or if the operation is noisy.
!

4
ELECTRICAL SAFETY
WARNING: To avoid electrical hazards, fire hazards or damage to the
tool, use proper circuit protection.
This tool is wired at the factory for 120V AC operation. It must be connected
to a 120V AC, 15 AMP circuit that is protected by a time-delayed fuse or
circuit breaker. To avoid shock or fire, replace power cord immediately if it
is worn, cut or damaged in any way.
GENERAL SAFETY WARNINGS
SAVE THESE INSTRUCTIONS FOR REFERENCE
WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN
OPERATING A POWER TOOL IN A DUSTY ENVIRONMENT.
WARNING: Dust that is created by power sanding, sawing, grinding,
drilling, and other construction activities may contain chemicals that are
known to cause cancer, birth defects, or other genetic abnormalities. These
chemicals include:
Lead from lead-based paints
Crystalline silica from bricks, cement, and other masonry products
Arsenic and chromium from chemically treated lumber
The level of risk from exposure to these chemicals varies, according to how
often this type of work is performed. In order to reduce exposure to these
chemicals, work in a well-ventilated area, and use approved safety
equipment, such as a dust mask that is specifically designed to filter out
microscopic particles.
!

5
WARNING: Read all safety warnings and
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future
reference.
Work area safety
Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is earthed or
grounded.
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk
of electric shock.
If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of a ground fault
circuit interrupter (GFCI) reduces the risk of
electric shock.
Personal safety
Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the
switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energizing power tools that have the
switch on invites accidents.
Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in
moving parts.
If devices are provided for the connection of
dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
POWER TOOL SAFETY
!
SAVE THESE INSTRUCTIONS FOR REFERENCE

6
Power tool use and care
Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
Hold power tools by insulated gripping
surfaces when performing an operation
where the cutting tool may contact hidden
wiring or its own cord. Contact with a “live“
wire will make exposed metal parts of the tool
“live“ and shock the operator.
Use clamps or another practical way to
secure and support the workpiece to a
stable platform. Holding the work by hand or
against your body leaves it unstable and
may lead to loss of control.
Service
Have your power tool serviced by a qualified
repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
POWER TOOL SAFETY
SAVE THESE INSTRUCTIONS FOR REFERENCE
POWER TOOL SAFETY

7
WARNING: Know your detail saw. Do
not plug in the detail saw until you have read
and understand this Instruction Manual.
Learn the tool’s applications and limitations,
as well as the specific potential hazards
related to this tool. Following this rule will
reduce the risk of electric shock, fire, or serious
injury.
Always wear eye protection. Any
power tool can throw foreign
objects into your eyes and cause
permanent eye damage. ALWAYS
wear safety goggles (not glasses) that comply
with ANSI safety standard Z87.1. Everyday
glasses have only impact resistant lenses. They
ARE NOT safety glasses.
WARNING: Glasses or goggles not in
compliance with ANSI Z87.1 could cause
serious injury when they break.
Always wear safety goggles, hearing protection
and a dust mask. Use only in well-ventilated
areas. Using personal safety devices and
working in a safe environment reduces the risk
of injury.
WARNING: Never cut metals such as
steel, copper or brass. These materials are too
hard and will break the blade and possible
cause injury to the operator.
WARNING: Never attempt to plunge cut
with this tool. The fine blades will likely break
and possibly cause injury to the operator.
Hold the tool by insulated gripping surfaces
when performing an operation where the saw
blade may contact hidden wiring or its own cord.
Contact with a “live” wire will make exposed
metal parts of the tool “live” and shock the
operator.
Always make sure the work surface is free of
nails and other foreign objects. Cutting into a
nail can cause the blade and the tool to jump
and damage the blade.
Never hold the workpiece in one hand and the
tool in the other hand when sawing.
Never place your hands near or below the
cutting surface. Clamping the material and
guiding the tool with both hands is much safer.
Never lay the workpiece on hard surfaces like
concrete, stone, etc. The protruding blade may
cause the tool to jump.
DANGER: Always remove the plug from
the power supply when changing the blade and
when making adjustments.
Use only mini detail saw blades that are
designed specifically for mini or compact detail
saw use. Never use a broken blade, as it will not
be securely held in the tool.
After changing a blade, make sure the blade is
securely held in the blade holder. Loose blades
will be violently thrown.
Never touch the blade during or immediately
after use. After use, the blade is too hot to be
touched by bare hands.
Never use dull or damaged blades. Sharp
blades must be handled with care. Damaged
blades can snap during use. Dull blades require
more force to cut the workpiece, possibly
causing the blade to break.
SAVE THESE INSTRUCTIONS FOR REFERENCE
SPECIFIC SAFETY RULES
!
!
!
!
!

8
Make sure your extension cord is the proper
size. When using an extension cord, be sure to
use one heavy enough to carry the current the
tool will draw. An undersized cord will cause a
drop in line voltage resulting in loss of power
and overheating. The table on at right shows the
correct size to use according to cord length and
nameplate ampere rating. If in doubt, use the
next heavier gauge. The smaller the gauge
number the heavier the cord.
Be sure your extension cord is properly
wired and in good condition. Always replace a
damaged extension cord or have it repaired by a
qualified electrician before using it. Protect your
extension cord from sharp objects, excessive
heat and damp or wet areas.
Use a separate electrical circuit for your
power tools. This circuit must not be less than
14 gauge wire and should be protected with
either a 15A time delay fuse or circuit breaker.
Before connecting the power tool to the power
source, make sure the switch is in the OFF
position and the power source is the same as
indicated on the nameplate. Running at lower
voltage will damage the motor.
WARNING: Repair or replace damaged
or worn extension cords immediately.
Select the appropriate extension cord gauge
and length using the chart below.
When operating a power tool outdoors, use
an outdoor extension cord marked “W-A” or
“W”. These cords are rated for outdoor use and
reduce the risk of electric shock.
WARNING: Keep the extension cord
clear of the working area. Position the cord
so it will not get caught on the workpiece,
tools or any other obstructions while you are
working with the power tool.
GUIDELINES FOR EXTENSION CORDS
!
MINIMUM GAUGE (AWG) EXTENSION
CORDS (120 V use only)
Ampere rating
Total length in feet
More
than
Not
more
than
7.5 m
(25')
15 m
(50')
30 m
(100')
45 m
(150')
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Applicable
!
SAVE THESE INSTRUCTIONS FOR REFERENCE

9
This symbol designates that this tool is listed
with U.S. and Canadian requirements by
Underwriters Laboratories.
Conforms to UL Std. 60745-1 and 60745-2-11.
3042597
JD2814U
LISTED
V
Volts
A
Amperes
Hz
Hertz
W
Watts
kW
Kilowatts
Microfarads
L
Liters
kg
Kilograms
H
Hours
N/cm
2
Newtons per square
centimeter
Pa
Pascals
OPM
Oscillations per minute
Min
Minutes
S
Seconds
or a.c.
Alternating current
Three-phase alternating
current
Three-phase alternating
current with neutral
Direct current
No load speed
Alternating or direct
current
Class II construction
Splash-proof
construction
Watertight construction
Protective grounding at
grounding terminal,
Class I tools
Revolutions or
reciprocations per
minute
Diameter
Off position
Directional arrow
Warning symbol
Wear your safety
glasses
Wear a dust mask
Wear hearing protection
SYMBOLS
WARNING: Some of the following symbols may appear on the detail saw. Study
these symbols and learn their meaning. Proper interpretation of these symbols will
allow for more efficient and safer operation of this tool.
!

10
KNOW YOUR DETAIL SAW
Hex key
3mm
Hex key
2.5mm
Detail Saw Blades
Pkg of 10
ON/OFF
switch
Blade holder
set screw
Blade
holder
Blade guide
roller
Tilting base
plate
Motor vents
Hex
keys
Speed control
wheel
Motor
vents
Blade
Bevel angle
protractor
Edge
guide
Edge guide
adjusting knob
Hanging
loop

11
HEX KEY STORAGE
The 2.5mm hex key (1) for tightening the blade
clamp and the 3mm hex key (2) for adjusting the
bevel angle are stored in the cord guard at the
rear of the tool (3) (Fig. 1).
INSTALLING A BLADE
WARNING: Always remove the plug
from the power source before installing or
removing a blade or adjusting the detail saw
in any way.
1. To install a blade in the detail saw, loosen
the blade holder set screw (1) by turning it
counter clockwise approximatey one full
turn (Fig. 2).
NOTE: Use the 2.5mm hex key (2) that is
stored in the cord guard at the rear of the
tool.
2. Insert the appropriate blade (3) into the
blade holder slot (4) as far as it will go.
NOTE: Make sure the rear edge of the
blade is nested in the blade guide roller (5).
3. Firmly tighten the blade holder set screw
until the blade is firmly clamped in the
blade holder.
REMOVING A BLADE
To remove a blade, simply loosen the blade
holder set screw and remove the blade from the
blade holder.
NOTE: Let the blade cool down before
attempting to remove it. The blade will get very
hot during cutting.
SETTING THE BEVEL CUTTING ANGLE
Bevel cutting angles may be adjusted from 0° to
45° either left or right. To adjust the bevel angle:
1. Loosen the base pivot screw (1) until the
base (2) can be slid forward (Fig. 3).
NOTE: Use (3mm) hex key supplied.
2. Bevel angles (3) are marked on a scale
located on the side of the base (Fig. 4).
3. Slide the base toward the front of the detail
saw and align the bevel angle index mark
(4) with the desired bevel angle on the
base.
ASSEMBLY AND OPERATING
!
Fig. 2
1
2
3
4
5
Fig. 1
1
2
3
Fig. 3
1
2

12
SETTING THE BEVEL CUTTING ANGLE –
cont’d
NOTE: Use a protractor to check the bevel
angle between the blade and the base.
4. Once the desired bevel angle is obtained,
lock the base by tightening base pivot
screws.
5. Make a test cut in a scrap piece of material
and measure the bevel angle. Adjust the
bevel angle if necessary.
VARIABLE SPEED CONTROL
Set the detail saw speed by rotating the variable
speed control wheel (1) to the appropriate
speed (Fig. 5). Rotating the variable speed
control wheel toward the rear of the detail saw
will result in slower speeds. Position the speed
control dial at "1" for the slowest speed, "3" for
medium speed and at "MAX" for the highest
speed.
ON/OFF SWITCH
The ON/OFF switch turns the detail saw ON and
OFF.
1. To turn the detail saw ON, press the rear of
the ON/OFF switch (1) (Fig. 6).
2. To turn the detail saw OFF, press the front
of the ON/OFF switch (2).
INSTALLING THE EDGE GUIDE
This detail saw is equipped with an edge guide
that will assist in cutting narrow edges from a
workpiece.
NOTE: The bevel cutting angle must be set at
0° when using the edge guide (Fig. 4).
1. Install two edge guide mounting screws (1)
(Fig. 7).
2. Insert edge guide (2) into the edge guide
mounting slots (3) in the base plate (4).
3. Set the edge guide at the desired distance
from the blade and lock it into place by
tightening the edge guide mounting
screws.
NOTE: Tighten the mounting screws to
hold the edge guide in place. Do NOT
overtighten the mounting screws as you
will damage the edge guide.
4. Make a test cut on a scrap workpiece to
ensure the edge guide is set correctly.
5. Adjust the edge guide as required.
ASSEMBLY AND OPERATING ASSEMBLY AND OPERATING
Fig. 4
3
4
5
Fig. 5
1
Fig. 6
1
2

13
INSTALLING THE EDGE GUIDE – cont’d
MATERIALS YOU CAN CUT
This detail saw is a versatile tool that allows you
to cut many different types of materials. Some of
these materials include:
Wood products such as plywood,
composite board, laminate and panelling
Drywall
Styrofoam
Fibre board and plastic
GENERAL CUTTING
1. Clearly mark the workpiece to locate the
position of the cut.
2. Hold smaller workpieces with a vise. Clamp
larger workpieces to a workbench or table.
DANGER: Any workpiece that is not
adequately clamped in place may come
loose and cause serious injury. Never hold
the workpiece with your hand.
WARNING: Keep your hands and
fingers away from between the motor
housing and the blade holder. Do not reach
underneath the workpiece while the detail
saw is running.
3. Set the speed control wheel to the desired
speed. Use slower speeds for cutting
plastics and higher speeds for cutting wood
and laminates.
ASSEMBLY AND OPERATING ASSEMBLY AND OPERATING
!
!
Fig. 7
1
2
3
4
For safety reasons, the operator must
read the sections of this Owner’s Manual
entitled "GENERAL SAFETY
WARNINGS", "POWER TOOL SAFETY",
"SPECIFIC SAFETY RULES",
"GUIDELINES FOR EXTENSION CORDS"
and "SYMBOLS" before using this detail
saw.
Verify the following every time the detail
saw is used:
1. The blade is sharp and in good
condition.
2. The blade is firmly clamped into the
blade holder.
3. The workpiece is properly secured.
4. Safety glasses, hearing and
breathing protection are being worn.
Failure to observe these safety rules will
significantly increase the risk of injury.
WARNING
!

14
GENERAL CUTTING – cont’d
NOTE: Higher speeds will generally result
in smoother cuts, but will also generate
more heat and therefore shorten the life of
the blade.
4. Rest the front of the detail saw base plate
(1) on the workpiece and align cutting edge
of the blade with the cutting line (2) on your
workpiece (Fig. 8). Make sure the power
cord is out of your way and not in the path
the blade will follow.
5. While firmly gripping the detail saw, and
with the blade NOT in contact with the
surface to be cut, start the detail saw by
turning the ON/OFF switch ON.
6. Once the detail saw has reached the
desired speed, gradually bring the moving
blade into contact with the workpiece at the
appropriate location.
NOTE: Apply enough downward pressure
to keep the detail saw steady and only
enough forward pressure to keep the blade
cutting freely.
CAUTION: Do not force the detail saw.
Use only enough force to keep the blade
cutting. Do not put sideways pressure on the
blade. Excessive or sideways pressure on
the blade will cause it to bend and twist,
which may result in breaking the blade.
BEVEL CUTTING
Bevel cutting angles may be adjusted from 0° to
45° either left or right. To adjust the bevel angle,
refer to Fig. 3 & 4.
NOTE: Remove the edge guide mounting
screws as shown in Fig. 7 when bevel cutting.
Once the cutting angle has been verified,
proceed with the cutting activity as outlined in
"GENERAL CUTTING" above.
!
ASSEMBLY AND OPERATING
Fig. 8
1
2

15
GENERAL
WARNING: When servicing this tool,
use only identical replacement parts. The
use of any other part may create a hazard or
cause product damage.
DO NOT use solvents when cleaning plastic
parts. Plastics are susceptible to damage from
various types of commercial solvents and may
be damaged by their use. Use a clean cloth to
remove dirt, dust, oil, grease etc.
WARNING: Do not allow brake fluids,
gasoline, petroleum-based products,
penetrating oils, etc. to come into contact
with plastic parts. They contain chemicals
that can damage, weaken or destroy plastic.
DO NOT abuse power tools. Abusive practices
can damage the tool and the workpiece.
WARNING: DO NOT attempt to modify
tools or create accessories. Any such
alteration or modification is misuse and
could result in a hazardous condition leading
to possible serious injury. It will also void
the warranty.
It has been found that electric tools are
subjected to accelerated wear and possible
premature failure when they are used on
fiberglass boats and sports cars, wallboard,
spackling compounds or plaster. The chips and
grindings from these materials are highly
abrasive to electric tool parts such as bearings,
brushes, commutators, etc. Consequently, it is
not recommended that this tool be used for
extended work on any fiberglass material,
wallboard, spackling compounds or plaster.
During any use on these materials it is
extremely important that the tool is cleaned
frequently by blowing the accumulated debris
out with an air jet.
WARNING: Always wear safety goggles
or safety glasses with side shields during all
cutting operations. It is critical that you wear
safety goggles or safety glasses with side
shields and a dust mask while blowing dust
out of the detail saw with an air jet. Failure to
take these safety precautions could result in
permanent eye or lung damage.
LUBRICATION
All of the bearings in this tool are lubricated with
a sufficient amount of high-grade lubricant for
the life of the unit under normal conditions.
Therefore, no further lubrication is required.
MAINTENANCE
!
!
!
!
!

16
EXPLODED VIEW

17
WARNING: When servicing, use only original equipment replacement parts. The use of any
other parts may create a safety hazard or cause damage to the detail saw.
Any attempt to repair or replace electrical parts on this detail saw may create a safety hazard unless
repairs are performed by a qualified technician. For more information, call the Toll-free Helpline, at
1-866-349-8665 (Monday through Friday 9am – 5pm Eastern Time).
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
4030010237
Tapping screw 2.9*20
2
2
4030010145
Tapping screw 2.9*16
4
3
3011100084
Right enclosure
1
4
4020080002
Hex screw M4*12
1
5
1170020036
Blade support roller
1
6
2030010062
Base plate
1
7
1180100012
Edge guide mounting screw
2
8
1150010045
Quick plunger assembly
1
9
4020150010
Hex screw M5*6
1
10
2050080189
Nose guard
1
11
2020050083
End housing
1
12
4030010145
Tapping screw 2.9*16
4
13
2010150056
Front bearing
1
14
2010150057
Back bearing
1
15
2010210025
Roller
1
16
1170040076
Eccentric shaft
1
17
4010010034
Bearing 607
1
18
2010080126
Shaft sleeve
1
19
3150210014
Bearing holder
1
20
2010010125
Gear
1
21
3150010110
Motor fan
1
22
2030220006
Motor flange
1
23
4020010027
Screw M3*6
2
24
1039040011
Motor
1
25
1061150016
Switch
1
26
1130010235
PCB
1
27
3150020001
Cord clamp
1
28
4030010179
Tapping screw 3.9*10
2
29
3140010074
Cord strain relief
1
30
2050080199
Hanging loop
1
31
3011100084
Left enclosure
1
PARTS LIST
!

18
Rev 1.2 03/07/2016
PERFORMAX
®
COMPACT DETAIL SAW WARRANTY
30-DAY MONEY BACK GUARANTEE:
This PERFORMAX
®
brand power tool carries our 30-Day Money Back
Guarantee. If you are not completely satisfied with your PERFORMAX
®
brand
power tool for any reason within thirty (30) days from the date of purchase, return
the tool with your original receipt to any MENARDS
®
retail store, and we will
provide you a refund – no questions asked.
2-YEAR LIMITED WARRANTY:
This PERFORMAX
®
brand power tool carries a 2-Year Limited Warranty to the
original purchaser. If, during normal use, this PERFORMAX
®
power tool breaks
or fails due to a defect in material or workmanship within two (2) years from the
date of original purchase, simply bring this tool with the original sales receipt
back to your nearest MENARDS® retail store. At its discretion, PERFORMAX
®
agrees to have the tool or any defective part(s) repaired or replaced with the
same or similar PERFORMAX
®
product or part free of charge, within the stated
warranty period, when returned by the original purchaser with original sales
receipt. Not withstanding the foregoing, this limited warranty does not cover any
damage that has resulted from abuse or misuse of the Merchandise. This
warranty: (1) excludes expendable parts including but not limited to blades,
brushes, belts, bits, light bulbs, and/or batteries; (2) shall be void if this tool is
used for commercial and/or rental purposes; and (3) does not cover any losses,
injuries to persons/property or costs. This warranty does give you specific legal
rights and you may have other rights, which vary from state to state. Be careful,
tools are dangerous if improperly used or maintained. Seller’s employees are
not qualified to advise you on the use of this Merchandise. Any oral
representation(s) made will not be binding on seller or its employees. The rights
under this limited warranty are to the original purchaser of the Merchandise and
may not be transferred to any subsequent owner. This limited warranty is in lieu
of all warranties, expressed or implied including warranties or merchantability
and fitness for a particular purpose. Seller shall not be liable for any special,
incidental, or consequential damages. The sole exclusive remedy against the
seller will be for the replacement of any defects as provided herein, as long as
the seller is willing or able to replace this product or is willing to refund the
purchase price as provided above. For insurance purposes, seller is not allowed
to demonstrate any of these power tools for you.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free at: 1-866-349-8665 (M-F 8am – 6pm)
SAVE YOUR RECEIPTS. THIS WARRANTY IS VOID WITHOUT THEM.
Distributed by: Menard, Inc., Eau Claire, WI 54703
