使用說明書
MM-2MM20PC(WH)
微波爐
操作前請先閱讀本說明書。
目錄
注意
產品安全
避免接觸過量微波能量的預防措施 ....................................................................................ZH-01
重要安全說明 ...............................................................................................................................ZH-03
減少接地安裝人士受傷的風險 ..............................................................................................ZH-07
清潔 ...................................................................................................................................................ZH-09
器皿 ................................................................................................................................................... ZH-10
可在微波爐中使用的物料......................................................................................................... ZH-11
不可用於微波爐的材料 ............................................................................................................ZH-13
產品設置
設定爐具 .........................................................................................................................................ZH-14
使用說明
第一次使用前 ...............................................................................................................................ZH-17
操作
................................................................................................................................................... ZH-18
清潔及保養
清潔 ...................................................................................................................................................ZH-19
故障排除 .........................................................................................................................................ZH-21
操作本產品前，請閱讀、理解及遵循本說明書。
請確保妥善保管本小冊子，以供日後參考。
產品安全
避免接觸過量微波能量的預防措施
附錄
如果設備沒有保持清潔，其表面可能會變質，從而影響設備的
使用壽命並導致危險。
(a). 爐門開啟時請勿操作微波爐，因為這可能會接觸到微波能量
而造成傷害。請勿破壞或更改安全連鎖。
(b). 請勿在爐具正面及爐門之間放置任何物
品，或讓泥土或清潔劑殘留物在密封表
面積聚。
(c). 警告： 爐門或爐門密封條如有損壞，
必須由合資格人士修理，然後才操作微
波爐。
ZH-01
規格
型號
額定電壓 220V~50Hz
MM-2MM20PC(WH)
1270W
額定輸出功率（微波） 800W
額定輸入功率（微波）
ZH-02
重要安全說明
警告
為減少使用產品時發生火災、觸電、人身傷害或
接觸過量微波爐能量的風險，請遵循以下基本預
防措施：
不會把玩產品。
在缺乏負責其安全的人士
監督或指導之下，身體感
到不適、精神狀態不佳或
缺乏相關經驗與知識的人
士（包括兒童），均不適
宜使用本產品。
請閱讀並遵循：「《避免
接觸過量微波能量的預防
措施」。
ZH-03
電線如有損壞，請由製造
商、代理商或具類似資格
的專業人士更換，以免發
生危險。
應
看管兒童，確保他們
警告： 更換燈泡之前，請
確保已關閉產品電源，以
免觸電。
警告： 切勿在密封容器中
加熱液體及其他食物，否
則可能會爆炸。
警告： 除合資格人士外，
任何涉及拆除防微波外罩
的保養或維修操作均十分
危險。
使用塑膠或紙製容器加熱
食物時，請注意微波爐，
因為可能會著火。
僅使用適合在微波爐使用
的器皿。
如果冒煙，請關閉產品或
拔下電源插頭，並保持爐
門關閉，以消滅火種。
微波加熱飲品可導致延遲
沸騰，因此在處理容器時
必須小心。
奶瓶及嬰兒食品瓶中的內
容物，應在食用前攪拌或
搖動，並檢查溫度，以免
燙傷。
重要安全說明
ZH-04
微波爐應定期清潔，並清
除所有食物沉積物。
沒有保持微波爐清潔，可
能會導致表面變質，從而
對產品的使用壽命產生不
良影響，並導致危險。
請保持微波引導區清潔。
當微波引導區或腔體上有
食物飛濺的殘留物時，請
使用柔軟的濕布進行清
理。如果不清理食物殘
渣，可能會導致微波爐腔
內出現無害的火花或一些
煙霧，爐腔內也可能出現
變色。
請僅使用推薦用於此爐具
的溫度探針。（如微波爐
配備使用溫度感應探針
設備。）
微波爐在操作時必須開啟
飾門。（適用於帶有裝飾
門的爐具。）
本產品供家居及類似環境
使用，如：
1. 店舖內的員工廚房區
域、辦公室及其他工作
環境；
2. 供客戶於酒店、汽車旅
館及其他住宅類型
環境；
3. 農舍；
4. 民宿類型環境。
微波爐用於加熱食物及
飲品。用於乾燥食物或
衣物，以及加熱保溫
墊、拖鞋、海綿、濕布
等可能會導致受傷、著
火或火災的危險。
重要安全說明
ZH-05
本產品僅供獨立使用。
產品背面應靠牆擺放。
切勿在微波爐加熱連殼雞
蛋或整隻烚蛋，否則可能
會在微波加熱後爆炸。
切勿將本產品安裝在裝飾
門後面，以免過熱。
（不適用於帶裝飾門的
電器。）
除非已在櫥櫃對微波爐進
行測試，否則請勿將微波
爐放入櫥櫃。
微波烹調期間不得使用金
屬容器盛載食物及飲品。
不得使用蒸汽清潔器清潔
產品。
請仔細閱讀並保存以備日後參考
重要安全說明
ZH-06
減少接地安裝人士受傷的風險
本產品必須接地。如發生電氣短路，接地可通過為電流提供
逃逸通路來降低觸電危險。
本產品配備帶有接地線及接地插頭的電源線。插頭必須插入
正確安裝並接地的插座。
警告 - 接地使用不當可導致觸電。如未充分理解接地說明，或
對產品是否正確接地存有疑問，請諮詢合資格電工或維修人
員。如需要使用延長線，請僅使用 3 線延長線。
危險
觸電危險：
觸摸部分內部組件，可導致嚴重的人身傷害或
死亡。請勿拆解本產品。
ZH-07
警告
觸電危險：
接地使用不當可導致觸電。在正確安裝產品並將
其接地之前，請勿插入電源插座。
1. 產品隨附短電源線，以減低長電源線纏繞及絆
到造成的危險。
2. 如使用長電源線或延長線：
(1). 電源線組或延長線標記的電氣額定值應至少
與產品的電氣額定值一樣大。
(2). 延長線必須為接地型 3 線電源線。
(3). 應妥善擺放長電源線，使其不會掛在檯面或
桌面，以免被兒童拉扯或意外絆倒。
減少接地安裝人士受傷的風險
ZH-08
清潔
確保從電源插座拔下產品插頭。
1. 使用後，用濕布清潔微波爐腔。
2. 用一般的方法在肥皂水中清潔配件。
3. 爐門框、密封條及附近零件骯髒時，必須小心用濕布清潔。
4. 請勿使用粗糙的研磨劑或鋒利的金屬刮刀來清潔微波爐爐門
玻璃，否則會劃傷表面，導致玻璃破碎。
5. 清潔提示——為了能更輕鬆清潔烹調食物會接觸到的腔壁：
將半個檸檬放入碗中，加入 300亳升（1/2品脫）水，並用
100% 微波火力加熱 10 分鐘。用柔軟的乾布擦拭微波爐。
ZH-09
器皿
注意
人身傷害危險：
除合資格人士外，任何涉及拆除防微波外罩的保
養或維修操作均十分危險。
請參閱「可用於微波爐的材料」或「不可用於微
波爐的材料」的說明」
部分非金屬器皿可能不適用於微波。如有疑問，
可以按照以下步驟測試相關器皿。
器皿測試：
1. 在適用於微波爐的容器加入 1 杯冷水
（250亳升），並與相關器皿一同放
入微波爐。
2. 以最大火力煮一分鐘。
3. 小心觸摸器皿。如果空的器皿很熱，
請勿將其用於微波爐烹調。
4. 烹調時間切勿超過1分鐘。
注意
保持爐腔和波導 區 清潔
ZH-10
蓋
域
可在微波爐中使用的物料
器皿 備註
燒烤盤
請遵循製造商說明。
燒烤盤底部必須在轉盤上方至少 3/16 英寸（5毫米）。
不正確使用可能會導致轉盤破裂。
餐具
僅限可用於微波的餐具。請遵循製造商說明。請勿使
用破裂或有缺口的盤子。
玻璃瓶
務必取下蓋子。僅用於加熱食物至溫熱。大部分玻璃
瓶均不耐熱，且可能會破裂。
玻璃器皿
僅限耐熱微波爐玻璃器皿。確保沒有金屬裝飾。
請勿使用破裂或有缺口的盤子。
微波爐烹調袋
請遵循製造商說明。請勿用金屬帶索緊。
預留縫隙以便蒸汽逸出。
紙碟及紙杯
僅用於短時間烹飪/加熱。烹調時請勿離開。
廚房紙
用於覆蓋食物進行加熱和吸收油脂。僅用於短時間
烹調，烹調時請勿離開。
烘焙紙
用於覆蓋食物以防止飛濺或包裹蒸煮的食物。
ZH-11
塑膠
僅限可用於微波的餐具。請遵循製造商說明。應標有
「可用於微波」標籤。部分塑膠容器會因內裏的食物
變熱而變軟。「蒸煮袋」和密封塑膠袋應按照包裝說
明切開、穿洞或開孔。
保鮮膜
僅限可用於微波的餐具。用於在烹調期間覆蓋食物以
保留水分。請勿讓保鮮膜接觸食物。
溫度計
僅使用適用於微波爐者（肉類及糖類溫度計）。
食品蠟紙
用於覆蓋食物，以防止飛濺並保留水分。
ZH-12
可在微波爐中使用的物料
器皿 備註
鋁盤
可能引起擊穿。將食物轉移到適用於微波的盤子。
帶金屬手柄的食品紙箱
可能引起擊穿。將食物轉移到適用於微波的盤子。
金屬或金屬飾面的器皿
金屬會隔離食物吸收微波能量。
金屬裝飾可能會引起擊穿。
金屬紮帶
可能引起擊穿並導致微波爐著火。
紙袋
可能導致微波爐著火。
塑膠泡沫
塑膠泡沫處於高溫時，可能會熔化或污染內裏的
液體。
木材
在微波爐使用時，木材會變乾，並可能裂開或
破裂。
ZH-13
不可用於微波爐的材料
器皿 備註
E
G
F
B
AD C H
微波爐零件和附件名稱
從紙箱及微波爐腔取出微波爐及所有材料。
（如果設備與本說明書中的圖片有任何差異，則概以實際產品為準）。
A. 控制面板
B. 玻璃托盤
C. 轉盤軸
D. 轉盤環組件
E. 爐門組件
F. 觀察窗
G. 安全連鎖系統
H. 波導蓋
產品設置
設定爐具
ZH-14
使用說明書
玻璃轉盤
轉盤環組件
轉盤軸
設定爐具
轉盤安裝
清潔烹飪艙並放置轉盤。
新安裝時，請確保所有包裝和運送膠帶都已從轉盤軸移除。
在第一次使用設備準備食物之前，你需要將轉盤正確放置。你必須清潔烹飪艙和附件。
你也可以就其參閱清潔部分。
如何把轉盤放好：
1. 將轉盤環組件③，放入烹飪室的凹槽中。
2. 將玻璃托盤①，放在轉盤環組件③上。將凸
起的弧形線裝入玻璃托盤底部的中心，位於軸
的三個輻條之間。確保玻璃托盤①妥為接觸
烹飪艙下方中央的轉盤軸②。軸上的滾輪應
貼合轉盤底脊內。
注意
• 永遠不要在沒有轉盤的情況下使用此電器。確保正確貼合。轉盤可
以順時針或逆時針轉動。
• 切勿將玻璃托盤倒置。玻璃托盤永遠不應受限制。
• 烹調期間必須使用玻璃托盤及轉盤環組件。
• 烹調期間所有食物及食物容器均須放上玻璃托盤。
• 千萬不要限制轉盤移動。
• 玻璃托盤或轉盤環組件如有損壞或破裂，請聯絡就近的授權服務
中心。
ZH-15
3
2
1
1) 玻璃托盤
2) 轉盤軸
3) 轉盤環組件
2.將微波爐插入標準家用插座。確保電壓及頻率與額定標籤上標示的相同。
注意
• 請勿將微波爐安裝在爐灶或其他發熱電
器之上。如果安裝在熱源附近或上方，
微波爐可能會損壞，保證將會無效。
操作期間，可接觸表面可能會變熱
1.選擇一個進氣口及/或出氣口均有足夠空間的水平表面。
a. 安裝高度應不少於 85 厘米。
b. 產品背面應靠牆擺放。在烤箱上方至少留出 30 厘米的間隙。爐具與任何相鄰的牆壁之
間，需要有至少 20 厘米的間隙。
c. 請勿拆除微波爐底部的支架。
d. 阻塞進氣口及/或出氣口會損壞微波爐。
e. 將微波爐置於遠離收音機及電視的地方。操作微波爐可能會干擾收音機或電視接收
信號。
工作台安裝
安裝
拆除所有包裝材料及配件。檢查微波爐是否有任何損壞，如凹痕或爐門破損。微波爐如有損
壞，請勿安裝。
微波爐：取下微波爐表面的所有保護膜。請勿取下附在微波爐腔上用於保護磁電管的波
導蓋。
ZH-16
0 厘米
20 厘米
30 厘米
20 厘米
> 85 厘米
側面
距離
厘米
頂部 30 厘米
左側 20 厘米
右側 20 厘米
背面 0 厘米
正面 開放
使用說明
第一次使用前
第一次使用爐具時，可能會產生難聞的氣味，這是正常現象。
本節告訴你在第一次使用微波爐準備食物之前需要如何處理。事先閱讀標題為 「產品安全」
的章節。
在你可以使用你的新電器之前，你需要把轉盤正確放好。你亦必須清潔烹飪艙和附件。
注意
• 永遠不要在沒有轉盤的情況下使用此電器。
• 確保其正確貼合。轉盤可以順時針或逆時針轉動。
ZH-17
操作
功能／功率 輸出
17% 微波
33% 微波
55% 微波
77% 微波
100% 微波
應用
軟化雪糕
燉湯、軟化牛油或解凍
飯、魚、雞肉、肉碎
燉湯、魚
翻熱、牛奶、煲水、蔬菜、飲品
從爐具中取出食物時，請確保將定時器開關調至 0（零），以關閉
爐具電源。
如果不這樣做，並在沒有食物在內的情況操作微波爐，則可能導致
過熱和損壞磁控管。
1. 通過將功率旋鈕旋轉到所需的水平，以
設定烹飪功率。
2. 根據你的食物烹飪指南，通過旋轉計時
器旋鈕到所需時間，以設置烹飪時間。
3. 在完成設定好功率等級及時間後，微波
爐會自動開始烹飪。
4. 烹飪時間結束時，裝置將發出「咚」一
聲以表示停止。
5. 不使用本設備時，請確保將時間設定為
「0」。
注意
火力
計時器
ZH-18
低
中低(解凍)
中
中高
高
微波火力
時間
分鐘 解凍
公斤
警告
清潔劑
為確保使用正確的清潔劑，以免損壞各個表面，請遵循表內說明。使用前請徹底清洗新的
海綿布。
切勿使用：
粗糙或研磨性清潔劑 金屬或玻璃刮刀清潔門板 金屬或玻璃刮刀清潔門
封條
堅硬的百潔布或海綿 酒精含量高的清潔劑
電器正面
熱肥皂水：
用抹布清潔，然後用軟布擦乾。
切勿使用金屬或玻璃刮刀進行清潔。
清潔及保養
清潔
透過妥善保養及清潔，您的產品將保持外觀，並在一段長時間維持正常運作。這裡將說明
應如何正確保養及清潔產品。
ZH-19
• 爐門上的玻璃刮痕可能發展成裂縫。切勿使用玻璃刮刀、鋒利或
具研磨性的清潔用品或清潔劑。
• 如果清潔不當，設備的表面可能會受損。微波能量可能會逸出。
定期清潔電器，並立即清除任何食物殘渣。
• 請勿將電器浸泡在水中或者在水柱下清洗。
不銹鋼器具的正面
熱肥皂水：
用抹布清潔，然後用軟布擦乾。
立即清除水垢、油脂、澱粉和白蛋白的飛濺和斑塊。這些斑
塊或飛濺物下，可形成腐蝕。切勿使用玻璃清洗劑或金屬或
玻璃刮刀清潔。
以不銹鋼製成的烹飪間隔
熱肥皂水或醋溶液：
用抹布清潔，然後用軟布擦乾。切勿使用爐具噴劑或任何其
他腐蝕性的爐具清潔劑或研磨材料。洗滌墊、粗糙的海綿和
鍋具清潔劑亦不合適使用。這些物品會擦花表面。待內裡表
面完全變乾。
烹飪艙中的凹槽
濕布：
不得讓水通過轉盤驅動裝置流入電器。用布擦乾轉盤驅動器。
轉盤和滾環
熱肥皂水：
當把轉盤放回其凹槽時，必須正確接合。
門板
玻璃清潔劑：
用抹布清潔。切勿使用玻璃刮刀。
ZH-20
故障排除
正常
微波爐干擾電視接收信號
微波爐運行時可能會干擾收音機及電視接收
信號。這與攪拌機、吸塵器及電風扇等小型
電器的干擾相似。此屬正常現象。
微波爐燈變暗
低火力微波烹調期間，微波爐的燈光可能會
變暗。此屬正常現象。
蒸汽積聚在爐門，熱空氣從通風孔流出
烹調期間，食物可能會冒出蒸汽。大部分蒸
汽會從通風口逸出。但是部分蒸汽可能會積
聚在微波爐門等陰涼的地方。此屬正常
現象。
微波爐在沒有放入食物時意外地開始烹調。
嚴禁在沒有任何食物的情況下運作本設備。
這會非常危險。
問題 可能的原因 解決方法
微波爐無法啟動。
(1) 電源線並未插實。 拔出電源線。然後 10 秒後再次
插入。
(2) 保險絲熔斷或斷路器運作。
更換保險絲或重設斷路器
（由本公司的專業人士進行維修）。
(3) 插座出現問題。
使用其他電器測試插座。
微波爐沒有加熱。 (4) 爐門尚未關好。 關好爐門。
根據廢棄電子及電力裝置（WEEE）指令，WEEE 須單獨收集及處理。如
果將來你需要處理本產品，請勿將本產品與家庭垃圾一起處理。請將此
產品傳送至適用 WEEE 收集點。
ZH-21
#
Details
Matter
INSTRUCTION MANUAL
MICROWAVE OVEN
MM-2MM20PC(WH)
Please review this instruction manual before operating.
Cleaning ................................................................................................................................................................ EN-19
CLEANING AND MAINTENANCE
Trouble shooting ............................................................................................................................................... EN-21
NOTE
BEFORE OPERATING THIS PRODUCT, READ,
UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE
REFERENCE.
PRODUCT SAFETY
Precautions to avoid possible exposure to excessive microwave energy .................................... EN-01
Important safety instructions ....................................................................................................................... EN-03
To reduce the risk of injury to persons grounding installation ......................................................... EN-07
Cleaning ................................................................................................................................................................ EN-09
Utensils .................................................................................................................................................................. EN-10
Materials you can use in microwave oven ............................................................................................... EN-11
Materials can not be used in microwave oven ...................................................................................... EN-13
PRODUCT SETTING
Setting up your oven ....................................................................................................................................... EN-14
INSTRUCTION FOR USE
....................................................................................................................... EN-17
Operation ............................................................................................................................................................. EN-18
CONTENTS
EN-01
PRODUCT SAFETY
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a). Do not attempt to operate this oven with the door open since
this can result in harmful exposure to microwave energy. It is
important not to break or tamper with the safety interlocks.
(b). Do not place any object between the
oven front face and the door or allow
soil or cleaner residue to accumulate on
sealing surfaces.
(c). WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by a
competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its
and lead to a dangerous situation.
EN-02
SPECIFICATIONS
MODEL
MM-2MM20PC(WH)
220V~ 50Hz
RATED VOLTAGE
1270 W
800 W
EN-03
IMPORTANT SAFETY INSTRUCTIONS
Read and follow the
PRECAUTIONS
TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY".
This appliance is not
intended for use by
persons (including
children) with reduced
physical, sensory or
mental capabilities,
or lack of experience
and knowledge, unless
they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.
Children should be
supervised to ensure that
they do not play with the
appliance.
If the supply cord is
damaged, it must
be replaced by the
manufacturer, its service
persons in order to avoid a
hazard.
WARNING
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
EN-04
WARNING: Ensure that the
before replacing the lamp
to avoid the possibility of
electric shock.
WARNING: It is hazardous
for anyone other than a
competent person to carry
out any service or repair
operation that involves the
removal of a cover which
gives protection against
exposure to microwave
energy.
WARNING: Liquids and
other foods must not be
heated in sealed containers
since they are liable to
explode.
When heating food in
plastic or paper containers,
keep an eye on the oven
due to the possibility of
ignition.
Only use utensils that
are suitable for use in
microwave ovens.
If smoke is emitted, switch
and keep the door closed
Microwave heating of
beverages can result in
delayed eruptive boiling,
therefore care must be
taken when handling the
container.
The contents of feeding
bottles and baby food jars
shall be stirred or shaken
and the temperature
IMPORTANT SAFETY INSTRUCTIONS
checked before
consumption, in order to
avoid burns.
The oven should be
cleaned regularly and any
EN-05
food deposits removed
.
Failure to maintain the
oven in a clean condition
could lead to deterioration
of the surface that could
the appliance and possibly
result in a hazardous
situation.
Only use the temperature
probe recommended
for this oven. (for ovens
provided with a facility to
use a temperature-sensing
probe.)
The microwave oven must
be operated with the
decorative door open. (for
ovens with a decorative
door.)
This appliance is intended
to be used in household
and similar applications
such as:
1.
working environments;
2. by clients in hotels,
motels and other
residential type
environments;
3. farm houses;
4. bed and breakfast type
environments.
The microwave oven is
intended for heating food
and beverages. Drying
of food or clothing and
heating of warming pads,
slippers, sponges, damp
cloth and similar may lead
to risk of injury, ignition or
IMPORTANT SAFETY INSTRUCTIONS
Please keep the waveguide
area clean. Use soft damp
cloth to clean it up when
there is food splash residue
on the waveguide area or
the cavity.Failure to clean
food residue may cause
innocuous sparking or some
smoke in the microwave
cavity,discoloration of the
cavity
may also occur.
EN-06
IMPORTANT SAFETY INSTRUCTIONS
The appliance is intended
to be used freestanding.
The rear surface of
appliances shall be placed
against a wall.
Eggs in their shell and
whole hard-boiled eggs
should not be heated in
microwave ovens since
they may explode, even
after microwave heating
has ended.
The appliance must not
be installed behind a
decorative door in order
to avoid overheating.
(This is not applicable for
appliances with decorative
door.)
The microwave oven shall
not be placed in a cabinet
unless it has been tested in
a cabinet.
Metallic containers for food
and beverages are not
allowed during microwave
cooking.
The appliance shall not
be cleaned with a steam
cleaner.
READ CAREFULLY AND KEEP FOR
FUTURE REFERENCE
EN-07
TO REDUCE THE RISK OF INJURY TO
PERSONS GROUNDING INSTALLATION
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire
with a grounding plug. The plug must be plugged into an outlet
that is properly installed and grounded.
WARNING - Improper use of the grounding can result in a risk of
grounding instructions are not completely understood or if doubt
exists as to whether the appliance is properly grounded.
If it is necessary to use an extension cord, use only a 3-wire
extension cord.
DANGER
Electric Shock Hazard:
Touching some of the internal components can
cause serious personal injury or death. Do not
disassemble this appliance.
EN-08
WARNING
Electric Shock Hazard:
Improper use of the grounding can result in electric
shock. Do not plug into an outlet until appliance is
properly installed and grounded.
1. A short power-supply cord is provided to reduce
the risks resulting from becoming entangled in or
tripping over a longer cord.
2. If a long cord or extension cord is used:
(1). The marked electrical rating of the cord set or
extension cord should be at least as great as
the electrical rating of the appliance.
(2). The extension cord must be a grounding-type
3-wire cord.
(3). The longer cord should be arranged so that it
will not drape over the counter top or tabletop
where it can be pulled on by children or
tripped over unintentionally.
TO REDUCE THE RISK OF INJURY TO
PERSONS GROUNDING INSTALLATION
EN-09
CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp
cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the
food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10
minutes. Wipe the oven clean using a soft, dry cloth.
EN-10
UTENSILS
CAUTION
Personal Injury Hazard:
It is hazardous for anyone other than a competent
person to carry out any service or repair operation
that involves the removal of a cover which gives
protection against exposure to microwave energy.
See the instructions on " Materials you can use in
microwave oven " or " Materials can not be used
in microwave oven "
There may be certain non-metallic utensils that are
not safe to use for microwaving. If in doubt, you can
test the utensil in question following the procedure
below.
Utensil
Test:
1. Fill a microwave-safe container with 1 cup
of cold water (250ml) along with the utensil
in question.
2. Cook on maximum power for 1 min.
3. Carefully feel the utensil. If the empty
utensil is warm, do not use it for microwave
cooking.
4. Do not exceed 1 min cooking time.
NOTE
KEEP THE CAVITY AND
WAVEGUIDE AREA CLEAN
EN-11
MATERIALS YOU CAN USE IN
MICROWAVE OVEN
UTENSILS REMARKS
Browning dish
Follow manufacturer’s instructions.
The bottom of browning dish must be at least 3/16 inch
(5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Dinnerware
Microwave-safe only. Follow manufacturer’s
instructions. Do not use cracked or chipped dishes.
Glass jars
Always remove lid. Use only to heat food until just
warm. Most glass jars are not heat resistant and may
break.
Glassware
Heat-resistant oven glassware only. Make sure there is
no metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags
Follow manufacturer’s instructions. Do not close with
metal tie.
Make slits to allow steam to escape.
Paper plates and cups
Use for short–term cooking/warming only. Do not leave
oven unattended while cooking.
Paper towels
Use to cover food for reheating and absorbing fat. Use
with supervision for a short-term cooking only.
Parchment paper
Use as a cover to prevent splattering or a wrap for
steaming.
EN-12
UTENSILS REMARKS
Plastic
Microwave-safe only. Follow the manufacturer’s
instructions. Should be labeled “Microwave Safe”. Some
plastic containers soften, as the food inside gets hot.
“Boiling bags” and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Plastic wrap
Microwave-safe only. Use to cover food during cooking
to retain moisture. Do not allow plastic wrap to touch
food.
Thermometers
Microwave-safe only (meat and candy thermometers).
Wax paper
Use as a cover to prevent splattering and retain
moisture.
MATERIALS YOU CAN USE IN
MICROWAVE OVEN
EN-13
MATERIALS CAN NOT BE USED IN
MICROWAVE OVEN
UTENSILS REMARKS
Aluminum tray
May cause arcing. Transfer food into microwave-safe
dish.
Food carton with metal
handle
May cause arcing. Transfer food into microwave-safe
dish.
Metal or metal trimmed
utensils
Metal shields the food from microwave energy.
Metal trim may cause arcing.
Metal twist ties
May cause arcing and could cause a fire in the oven.
Paper bags
May cause a fire in the oven.
Plastic foam
Plastic foam may melt or contaminate the liquid
inside when exposed to high temperature.
Wood
Wood will dry out when used in the microwave oven
and may split or crack.
EN-14
PRODUCT SETTING
SETTING UP YOUR OVEN
NAMES OF MICROWAVE OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the carton and oven cavity.
Instruction Manual
Glass turntable
Turntable Ring Assembly
(In case of any dierences between the appliance and the pictures in this manual, the product
shall prevail.)
Turntable Shaft
A. Control panel
B. Glass tray
C. Turntable shaft
D. Turntable ring assembly
E. Door assembly
F. Observation window
G. Safety interlock system
E
G
F
B
AD C
H
H. Waveguide cover
TURNTABLE INSTALLATION
SETTING UP YOUR OVEN
• Never use the appliance without the turntable. Make sure that it is
properly engaged. The turntable can turn clockwise or anti-clockwise.
• Never place the glass tray upside down. The glass tray should never
be restricted.
• Both glass tray and turntable ring assembly must always be used
during cooking.
• All food and containers of food are always placed on the glass tray
for cooking.
• Never restrict the movement of the turntable.
• If glass tray or turntable ring assembly cracks or breaks, contact your
nearest authorized service center.
NOTE
Clean the cooking compartment and place the turntable.
For new installations, make sure all packaging and shipping tape has been removed from the
turntable shaft.
Before using the appliance to prepare food for the first time, you will need to put the turntable
in place correctly. You must clean the cooking compartment and accessories. You can also refer
How to put the turntable in place:
1. Place the turntable ring assembly into the
recess in the cooking compartment.
2. Place the glass tray
①
on the turntable ring
assemblies . Fit the raised, curved lines in
the center of the glass tray bottom between
the three spokes of the shaft. Make sure that
the glass tray ① engages in the turntable
shaft ② in the centre of the cooking
compartment oor. The rollers on the shaft
should t inside the turntable bottom ridge.
1) Glass Tray
2) Turntable Shaft
3) Turntable Ring Assembly
③
③
them to the cleaning section.
EN-15
3
2
1
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage such as dents
or broken door. Do not install if oven is damaged.
INSTALLATION
2. Plug microwave oven into a standard household outlet. Be sure the voltage and the frequency
is the same as the voltage and the frenquency on the rating label.
NOTE
• Do not install oven over a range cooktop
or other heat-producing appliance.
If installed near or over a heat source, the
oven could be damaged and the warranty
would be avoid.
The accessible surface may be
hot during operation
a.The minimum installation height is 85cm.
b.The rear surface of appliance shall be placed against a wall. Leave a minimum clearance of
30cm above the oven. A minimum clearance of 20cm is required between the oven and any
adjacent walls.
c.Do not remove the legs from the bottom of the oven.
d.Blocking the intake and/or outlet openings can damage the oven.
e.Place the oven as far away from radios and TV as possible. Operation of microwave oven
may cause interference to your radio or TV reception.
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
EN-16
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not
remove the waveguide cover that is attached to the oven cavity to protect the
magnetron.
0 cm
20 cm
30 cm
20 cm
>
85
SIDE
DISTANCE
CM
Top 30cm
Left 20cm
Right 20cm
Behind 0cm
Front Open
cm
INSTRUCTION FOR USE
BEFORE USING FOR THE FIRST TIME
This section tells you what you need to do before using your microwave to prepare food for the
first time. Read the section entitled "PRODUCT SAFETY" beforehand.
Before you can use your new appliance, you will need to put the turntable in place correctly.
You must also clean the cooking compartment and accessories.
• Never use the appliance without the turntable.
• Make sure that it is properly engaged.The turntable can turn clockwise
or anti-clockwise.
NOTE
It is normal that the oven may produce unpleasant odors when it is used for the first time.
EN-17
EN-18
OPERATION
Function/Power Output
17% micro.
33% micro.
55% micro.
77% micro.
100% micro.
Application
soften ice cream
soup stew, soften butter or defrost
stew, sh
rice, sh, chicken, ground meat
reheat, milk, boil water, vegetables, beverage
When removing food from the oven, please ensure that the oven
power is switched o by turning the timer switch to 0(zero).
Failure to do so, and operating the microwave oven without
food in it, can result in overheating and damage to the magnetron.
1.To set cooking power by turning the
power knob to desired level.
2.To set the time of cooking by turning
the timer knob to desired time per
your food cooking guide.
3.The microwave oven will
automatically start cooking after
power level and time are set.
4.When the cooking time is up, the unit
will
"
Dong
"
to stop.
5.If the unit is not in use, always set
time to
" 0
.
"
NOTE
POWER
TIMER
Low
Mid Low (Defrost)
Mid
Mid High
High
微波火力
時間
分鐘 解凍
公斤
EN-19
CLEANING
With good care and cleaning, your appliance will retain its appearance and remain fully functioning
for a long time to come. We will explain here how you should correctly care for and clean your appliance.
WARNING
• Scratched glass in the appliance door may develop into a crack.
Do not use a glass scraper, sharp or abrasive cleaning aids or
detergents.
• The surface of the appliance may become damaged if it is not
cleaned properly. Microwave energy may escape.
Clean the appliance on a regular basis, and remove any food
remnants immediately.
• Do not immerse the appliance in water or clean under a jet of
water.
Cleaning agent
To ensure that the dierent surfaces are not damaged by using the wrong cleaning agent, observe
the information in the table. Wash new sponge cloths thoroughly before use.
Do not use:
APPLIANCE FRONT
Hot soapy water:
Clean using a dish cloth and then dry with a soft cloth.
Do not use metal or glass scrapers for cleaning.
CLEANING AND MAINTENANCE
Harsh or abrasive cleaning
agents
Metal or glass scrapers to
clean the door panels
Metal or glass scrapers to
clean the door seal
Hard scouring pads or
sponges
Cleaning agents with a
high alcohol content
COOKING COMPARTMENT MADE OF STAINLESS STEEL
RECESS IN THE COOKING COMPARTMENT
TURNTABLE AND ROLLER RING
DOOR PANELS
APPLIANCE FRONT WITH STAINLESS STEEL
Glass cleaner:
Clean with a dish cloth. Do not use glass scrapers.
Hot soapy water:
When placing the turntable back into its recess,
it must engage properly.
Damp cloth:
Water must not be allowed to run into the appliance through the
turntable drive. Dry the turntable drive with a cloth.
Hot soapy water or vinegar solution:
Clean using a dish cloth and then dry with a soft cloth. Do not
use oven spray or any other aggressive oven cleaners or
abrasive materials. Scouring pads, rough sponges and pan
cleaners are also unsuitable. These items scratch the surface.
Allow the interior surfaces to dry completely.
Hot soapy water:
Clean using a dish cloth and then dry with a soft cloth.
Remove splashes and patches of limescale, grease, starch and
albumin immediately. Corrosion can form under these patches
or splashes. Do not use glass cleaners or metal or glass scrapers
for cleaning.
EN-20
EN-21
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.
Microwave oven interfering
TV reception
Radio and TV reception may be interfered when
microwave oven operating. It is similar to the
interference of small electrical appliances, like
mixer, vacuum cleaner, and electric fan.
It is normal.
In cooking, steam may come out of food. Most will
get out from vents. But some may accumulate on
cool place like oven door. It is normal.
Steam accumulating on
door, hot air out of vents
Oven started accidentally
with no food in.
It is forbidden to run the unit without any food inside.
It is very dangerous.
Normal
Oven cannot
be started.
(1) Power cord is not
plugged in tightly.
Unplug. Then plug again after
10 seconds.
Replace fuse or reset circuit
breaker (repaired by
professional personnel of our
company)
Test outlet with other electrical
appliances.
Close door well.
(3) Trouble with outlet.
(4) Door is not closed
well.
(2) Fuse blowing or
circuit breaker
works.
Oven does not heat.
TROUBLE SHOOTING
Dim oven light
In low power microwave cooking, oven light may
become dim. It is normal.
Trouble Possible Cause Remedy
PN:16170000A97841
#
Details
Matter
