ASSEMBLY & INSTRUCTION MANUAL
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
INcjd081_US
INcjd081_US_820-250V80
WHEN USING ELECTRICAL APPLIANCES, BASIC PRECUATIONS SHOULD ALWAYS BE
FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO
PERSON, INCLUDING THE FOLLOWING:
● Read all instructions before using this heater.
● This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
Use grip handle when provided.
● Keep combustible materials such as drapes, furniture, pillows, bedding, papers,
clothes, and curtains at least three (3) feet (0.9m) from the front of heater and keep them
at least 1 foot (0.3m) the sides and rear of the heater.
● Extreme caution is necessary when heater is used by or near children or invalids and
whenever the heater is left operating and unattended.
● Always unplug heater when not in use.
● Do not use any heater with a damaged cord or plug or after the heater malfunctions or
has been dropped or damaged in any manner. Return heater to manufacturer for
examination, electrical or mechanical adjustment, or repair. (See Warranty for
information).
● Do not use outdoors.
● This heater is not to be used in bathrooms, laundry areas or other similar indoor
locations. Never locate heater where it may fall into a bathtub or other water container.
● Do not run cord under carpeting. Do not cover cord with throw rugs, runners or the like.
Arrange cord away from traffic area where it will not be tripped over.
● To disconnect heater, turn control to OFF then remove plug from outlet.
● Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause electric shock or fire or damage the heater.
● To prevent possible fire, do not block air intakes or exhaust in any manner. Do not use on
soft surfaces, like a bed, where openings may become blocked.
● A heater has hot and arcing or sparking parts inside. Do not use it in areas where
gasoline, paint or flammable liquids are used or stored.
● Use this heater only as directed in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock or injury to persons.
● Always plug heaters directly into a wall outlet/receptacle. Never use with an extension
cord or relocatable power tap (outlet/power strip).
● If the heater will not operate: See specific instructions in Safety Feature explained in this
manual.
CLEANING/ MAINTENANCE INSTRUCTIONS:
During Season Care:
● Before cleaning, be sure to turn off and unplug the heater.
● Carefully wipe the unit with a soft, damp cloth. Please be very cautious near the motor
and heating elements.
● Do not immerse the heater in water.
● Never use gasoline, benzene or thinner. This will damage the surface of the heater.
● After cleaning, be sure to completely dry the unit with a cloth or towel.
After Season Care:
● Store heater in a cool and dry location with power cord properly secured.
● Please store the unit in its original carton or suitable container.
PRE—OPERATING INSTRUCTIONS:
● Carefully remove your heater from the box (please save the carton for off-season
storage)
● Make sure the unit is in the OFF position before plugging the heater into the outlet.
● Place heater on a firm level surface.
OPERATING INSTRUCTIONS:
--Before inserting the plug into an electrical outlet, make sure that the electrical supply in
your area matches that on the rating label on the unit.
--When plugged in, turn on the Main power switch at the back of the unit.
a) When in Standby mode, only the switch ON/OFF on the control panel will respond
to your touch, and the LED display shows the room temperature. Press ON/OFF to
access the rest of the control panel or remote control.Press it to the lower power,
press it again to turn off the heater.the unit will keep working 30 seconds of cool air
after turn off it . this design can protect item use longer.
b) Low Power: (Press “POWER” to switch it)
c) High Power: (Press “ POWER“to switch it)
d) TIMER: Press ” TIMER ” button repeatedly to set a period after which the heater will
turn itself off (From 0 hour to 12 hours)
e) + , - : adjust room temperature .Temperature setting from 50-95℉ degree. “+” to
increase the desired temperature and “-“ to decrease the desired temperature. (On
Remote control only)
f) Osc : Press “ OSC “to activate oscillation. Press it again to cancel.
g) Press ON/OFF to turn off the heater, the unit will keep working 30 seconds of cool
air after turn off it . this design can protect item use longer.
Warning: The heater will remain hot for some time after it is turned off; handle with
care.
REMOTE CONTROL
The remote control uses on button cell battery, type CR2025(3V).To remove the battery
carriage use your thumb to squeeze the release tab to the right and then pull the carriage
out. Place the battery into the carriage and slide the carriage back into the remote. See
Fig.1. We recommend the use of a Lithium-ion battery for longer use. NOTE: Follow battery
disposal instruction on battery packaging, or contact your local safety council for safely
disposal of batteries.
Before using the remote control, you must remove the insulating film as shown in the figure
below.
1. All functions performed with remote control work identically to the heater control
panel.(Except the temperature settings)
2. Aim the remote control at the heater control panel to operate the heater.
SPECIFICATION
Model No 820-250V80
Voltage 120V AC
Frequency 60Hz
Output Power (W) 1500W
OVERHEAT PROTECTION
This heater is protected with an overheat protection that switches off the appliance
automatically in case of overheat, e.g. due to the total or partial obstruction of the grids. In
this case, unplug the appliance, wait about 30 minutes for it to cool and remove the object
which is obstructing the grids. Then switch it back on as described above. The appliance
should operate normally. Should the problem persist, please contact the nearest customer
service.
TIP-OVER PROTECTION
This heater is protected with a safety switch that turns
off the appliance automatically when the heater falls
over, or is at an excessive angle from the horizontal.
This helps prevent accidents, and the heater will back
to the standby mode when it is put back upright, press
the buttons on control panel or remote control to reset
the heater
