+I'M _"]l+[+"]!4_+vl_!l[,_VJ=l+l
11/4" Dia.ConduitAccessHole*
2 5/8" PlywoodFloor(MustSupport200ibs.)
DIMENSIONS
inches cm
A 27 MIN 68.58
B 24 MIN 60.96
C 29 1/16+_1/16 73.82
D 24 MIN 60.96
E 25 1/2+ 1/16 64.77
F 29 1/2 74.93
G 26 3/4 67.95
H 25 7/16 64.61
I 4to31 10.2to 78.7
P;r+ II[,]lJ :1! :liV_vl:1! I[o_'J:1+I
11/4" Dia.ConduitAccessHole*
2 5/8" PlywoodFloor(MustSupport310 Ibs.)
DIMENSIONS
inches cm
A 27 MIN 68.58
B 24 MIN 60.96
C 51 7/8+1/16 131.76
D 24 MIN 60.96
E 25 1/2+ 1/16 64.77
F 52 1/4 132.72
G 26 3/4 67.95
H 25 1/2 64.77
I 4to 10 10.2to 25.4
I_[e]id_l
Donotblockairexhaustslotsalongbottom
ofoven.
Y Gasorelectriccooktopsmaybe installed
overovens.Seecooktopinstallation
instructionsforcutoutsize.**
W Electricalconnectionforelectriccooktop
mustinadjacentaccessiblelocation.Cook
topand wallovenmustbe onseparate
120/240or 120/208volt60HzACcircuits.
Built-In 27" & 30"
Electric Wall Ovens =JENN-AIR 1
403 WEST FOURTH STREET, NORTH
NEWTON, IA 50208
2
A
B
C
D
E
F
G
H
I
kI,]iIJl,llJ :]! 4W;I ! I[,]'1::I +I
1 1/4" Dia. ConduitAccessHole*
2 5/8" PlywoodFloor(MustSupport310Ibs.)
DIMENSIONS
inches cm
A 30MIN 76.20
B 24MIN 60.96
C 517/8+_1/16 131.76
D 24MIN 60.96
E 281/2+_1/16 72.39
F 52 1/4 132.72
G 293/4 75.57
H 25 1/2 64.77
I 4to10 10.2to25.4
i'_I+1rI_,IIl[l_.+'l::I+II J+Ii]::I:ll..ll].lJ+II ::I:
1 1 1/4" Dia.ConduitAccessHole*
2 5/8" PlywoodFloor(MustSupport200Ibs.)
DIMENSIONS
inches cm
A 25 63.50
B 24 MIN 60.96
C 291/16+_1/16 73.82
D 24 MIN 60.96
E 281/2 72.39
F 291/2 74.93
G 293/4 75.57
H 257/16 64.61
I 36 91.44
J 1 1/2 3.81
1 1/4" Dia.ConduitAccessHole*
5/8" PlywoodFloor(MustSupport200Ibs.)
DIMENSIONS
inches
30 MIN
24 MIN
291/16+1/16
24 MIN
281/2+1/16
291/2
293/4
257/16 Art #: 9220-025
4to 31
CAUTION
For European style cabinets (flush
front) the required clearance for
operation of the oven door is
minimum spacing of 7/8" between
the cutout and the door. hinge or
drawer of the cabinet.
Some built-in cabinets may not be
wide enough, due to their construc-
tion to allow this installation.
cm
AiI JA Cooktops 7.62 MAX
DOUBLEWALL OVEN
'.-Z
UNDER COUNTERWALL OVEN
See pages 5, 6 and 7 for detailed installation
instructions.
J
Art #: 9220-027
NOTE:
* Holemustbecutas closeto cornerofcabinetas possible.
** Seedealerforapprovedcooktops.
8101 P602-60
(11-03-00)
