NEC Direct View LED – Intelligent display solutions for a brighter world
The NEC Q Series II Outdoor DvLED is designed to provide high-bright, quality imaging
in outdoor environments. The Q Series II is rated IP65 to stand up to some of the
harshest environments. With pixel spacing options of 2.8mm, 3.9mm, & 4.8mm the
optimum display resolution can be achieved regardless of viewing distance. The Q
Series Outdoor dvLED is engineered to deliver vivid content visualization, even in harsh
outdoor settings. The square, modular design can be scaled to any size and allows
for creative installations to be realized. The front and rear serviceable design helps to
minimize downtime by providing easy access and quick maintenance. The Q-series
outdoor dvLED is the ideal solution for live event venues, DOOH, airports, train and
bus stations. NEC offers full design & planning services plus post installation service
plans, ensuring you get a custom-tailored solution allowing you to focus on what’s most
important – your business.
BENEFITS
Durable Construction ensures reliable operation even in the harshest conditions
Unmatched Brightness for clear and vivid imagery in intense ambient light
IP65 Rating allows for safe and worry-free operation in all weather conditions
Easy Front/Rear Access for quick and easy maintenance when needed, minimizing
downtime
NEC Direct View LED-Q028e2
(2.8mm Q Series II Outdoor)
DISPLAY
Panel Technology Direct View LED
Pixel Configuration 3-1 SMD (Black)
Panel Resolution 176 x 176
Pixel Pitch 2.84mm
Brightness (typical) 4000 cd/m²
Lifetime 100,000 hours
Contrast Ratio(typical) 7000:1
Viewing Angle 70/70 horizontal / 60/60 vertical
Dimming Capability 256 levels
Color Processing Up to 16 bit
Displayable Colors 281 Trillion
Refresh Rate(Hz) Up to 3840Hz
Orientation Landscape / Portrait
Connectivity
Input Terminals
Digital: DVI-D Dual Link in/out or HDMI External
Control: RS232 / USB
External Control USB
PowerConsumption(typical)
On 270Watts/sqm
Max 720Watts/Sqm
Physical Specifications
Dimensions (W x H x D) [mm] 500 x 500 x 70mm
Weight 18.7lbs / 8.5kg
Environmental Conditions
Operating Temperature -22° to 122°F / -30° to 50°C
Environmental Conditions 10% to 90%
Storage Temperature -4° to 122°F / -20° to 50°C
Servicability
Front/Rear Service
IP Level
IP65
NEC Direct View LED-Q028e2 (2.8mm Q Series 2 Outdoor) - Technical Specication
All other brand or product names are trademarks or registered trademarks of their respective holders.
Product specifications subject to change.
©2022 Sharp NEC Display Solutions of America, Inc. | All rights reserved.
Cat.No. 25.NEC.80.GL.UN.364 | Rev. 08.16.2022
